Ordering Matters: An Experimental Study of Ranking Inﬂuence on

Results Selection Behavior during Exploratory Search

Emanuel Felipe Duarte

, Lucas Pupulin Nanni

, Ricardo Theis Geraldi

, Edson OliveiraJr

Val´eria Delisandra Feltrim

and Roberto Pereira

Informatics Department, State University of Maring´a, Maring´a-PR, Brazil

Institute of Computing, State University of Campinas, Campinas-SP, Brazil

Keywords:

Search User Interfaces, Exploratory Search, Ranking Inﬂuence, Relevance Judgement.

Abstract:

The design of Exploratory Search tools acquires more importance as the amount of information on the Web

grows. Accordingly, informed design decisions concerning the users’ behavior during search activities can

be used in novel approaches for Exploratory Search tools. With regard to users’ behavior on search result

selection, literature indicates higher ranked results tend to attract more attention and, therefore, more hits.

However, the cause of such behavior is not clear. We experimentally investigate the hypothesis of this behavior

being due to ranking. A group of 72 participants was asked to select a search result from a randomly ordered

results list. The experiment was carried out on paper to remove speciﬁc search engine and digital medium

biases. We obtained evidence indicating there is a trend towards choosing higher ranked results even in a

different medium and in the context of an Exploratory Search, corroborating to the hypothesis that ranking has

inﬂuence on users’ selection behavior.

1 INTRODUCTION

According to White and Roth (2009), exploration is

part of the human nature and, as explorers, we aim

to constantly expand our knowledge through explo-

ration. Blandford and Attﬁeld (2010) discuss that

continuous advances in information technology over

the past decades and, in particular, the advent of the

Web have revolutionized the way people interact with

information. Consequently, the amount of available

information to be explored has become abundant.

However, Blandford and Attﬁeld (2010) discuss

how the abundance of information, most of it located

on the Web, became a signiﬁcant problem in recent

years. According to White and Roth (2009), there is

a growing need for Interactive Information Retrieval

systems capable of safeguarding the user’s attention

through information ﬁltering.

White et al. (2005) argued search technologies

available at that time already provided adequate sup-

port for users with well-deﬁned information needs,

but lacked support for situations where users do

not have the knowledge or contextual awareness to

formulate queries or navigate complex information

spaces (Bates, 1989). According to White et al.

(2013), current search technologies still provide in-

sufﬁcient support for this kind of activity, denom-

inated Exploratory Search: an activity where the

user performs a search with open and abstract goals

and need to build knowledge about a particular sub-

ject. Saving users’ attention is critical in Exploratory

Search activities, therefore, there is a growing need

for models and tools that support users in Exploratory

Search activities.

Current major Web search engines, such as

Google, Bing, Yahoo! and Baidu, adopt the listing

format of ranked search results in their user interface.

In this schema, studies reveal the results that appear

at ﬁrst positions of the list tend to receive most of the

attention and, therefore, more hits than the results pre-

sented at last positions (Granka et al., 2004; Joachims

et al., 2005; Pan et al., 2007).

However, it is not clear whether the position itself

is enough to inﬂuence users to select the ﬁrst results.

The interaction possibilities of the digital medium

(e.g., scrolling, clicking, opening in a new tab) along

with the additional tricks used by traditional search

engines (e.g., graphical signs, additional result infor-

mation, highlights for sponsored links) might also in-

ﬂuence results selection.

Understanding the user’s behavior towards search

activities may provide basis for informed design deci-

Duarte, E., Nanni, L., Geraldi, R., OliveiraJr, E., Feltrim, V. and Pereira, R.

Ordering Matters: An Experimental Study of Ranking Inﬂuence on Results Selection Behavior during Exploratory Search.

In Proceedings of the 18th International Conference on Enterprise Information Systems (ICEIS 2016) - Volume 2, pages 427-434

ISBN: 978-989-758-187-8

427

sions in search user interfaces, including Exploratory

Search tools in particular. Among the myriad of in-

volved behaviors, the user’s decision of selecting a

search result plays an important role in the presenta-

tion of results. The way results are presented in the

user interface should always be adapted to the user’s

behavior, promoting access to most relevant docu-

ments for a given information need. In Exploratory

Search, for instance, this behavior has a stronger in-

ﬂuence on the activity outcome, since the ﬁrst results

alone are usually not enough to satisfy the informa-

tion need. If the ﬁrst results are chosen with not

even regarding their relevance, the listing presenta-

tion might not be the best choice for the design of Ex-

ploratory Search tools, since low ranked results may

not be visited even if they are more relevant to the

user’s information need. Therefore, it is necessary to

investigate and better understand users’ behavior at

result selection regardless the web search tool in use.

In this paper we present an experimental study

with 72 participants that analyzes the user’s decision

on which search result to access ﬁrst during an Ex-

ploratory Search activity. This study was conducted

to examine whether the behavior of selecting the ﬁrst

results would remain in a situation where the results

were presented on other medium than a Web search

engine. A paper sheet presenting all the results in

the same page for easy comparison and selection is

the ideal artifact for this experiment because it is a

medium in which users’ attention tends to be more

equally distributed between its contents. Further-

more, it does not introduce other graphical elements

or interaction possibilities that may inﬂuence users’

perception of relevance and disturb their attention.

The paper is structured as follows: in Section 2 we

brieﬂy present and discuss the literature review and

some related work; in Section 3 we detail the experi-

mental study considering a structure with deﬁnition,

planning, operation, results analysis and interpreta-

tion, and evaluation of experiment validity; in Section

4 we present and discuss the main results; ﬁnally, in

Section 5 we present the main conclusion and direc-

tions for future research.

2 LITERATURE REVIEW AND

RELATED WORK

According to Hearst (2009), users rarely look beyond

the ﬁrst page of search results. If they do not ﬁnd im-

mediately what they want on the ﬁrst page, the most

common behavior is to give up on those results and

reformulate the query. Furthermore, studies suggest

that Web users expect the best answer to be in the ﬁrst

or second position, and this expectation has inﬂuence

on the result accessing behavior.

In a study by Granka et al. (2004) with 26 partici-

pants and 397 queries, it was found the ﬁrst search re-

sult was selected approximately 56% of the time, and

the second about 14%. It was concluded the ﬁrst two

search results are considerably the most viewed and

accessed, accumulating about 70% of all accesses.

From the third result onwards there is a dramatic de-

crease in not only access, but also on visualization

(assessed by eye tracking).

In study by Joachims et al. (2005) with 29 partic-

ipants, it was found the probability of a search result

being accessed was 45% for the ﬁrst one, 17% for the

second, 11% for the third and 5% or less for the subse-

quents, accumulating about 73% of all accesses in the

ﬁrst three results. Such behavior persisted even for 5

participants whose results were presented in reversed

order, and also for other 5 participants where only the

ﬁrst two results were reversed. An additional analysis

comparing the access frequency of the ﬁrst and sec-

ond results with a previous relevance judgment indi-

cated participants still prioritized the ﬁrst result even

though its relevance was previously assigned inferior

compared to the second result.

A divergent behavior was observed in a study car-

ried out by Aula et al. (2005) with 42 students and 10

pre-deﬁned queries. They found the presence of two

different styles of visual exploration over search re-

sults: (1) nearly 46% of the participants were found,

in the words of the authors, “economic”, visualizing

only 3 or 4 results at most in 50% of the tasks; and

(2) the other 54% were found, also in the words of the

authors, “exhaustive”, visualizing more than half the

results, and in some cases even all the 10 results, for

the most of queries. The authors suggest that more

experienced users are more likely to adopt the “eco-

nomic” proﬁle, while less experienced users are more

likely to adopt the “exhaustive” proﬁle. Thereby, they

argue the study conducted by Granka et al. (2004) has

employed only experienced searchers, which would

explain the difference in results between studies.

Another factor to be considered is the effect

caused by trust in search engine brand. As shown

in studies by Jansen et al. (2009) and Jansen et al.

(2012), users usually show a bias toward trusting

some search engines. Participants were presented

with the same results in different search engines, and

attributed more relevance for the results from their fa-

vorite search engine. As another example, in a study

carried out by Pan et al. (2007), users tended to trust

and select the ﬁrst results from Google even though

their snippets were considered less relevant than fol-

lowing results.

ICEIS 2016 - 18th International Conference on Enterprise Information Systems

428

The above studies identify the users’ behavior dur-

ing the analysis and selection of search results re-

trieved by a search engine. They show higher ranked

results attract more attention and, therefore, have a

higher chance of being accessed. In addition, the

user’s experience with search also contributes to the

depth of results exploration, in which less experi-

enced users tend to go further in the list whereas

more experienced users tend to stick to the ﬁrst re-

sults. However, such studies do not allow to con-

clude whether the behavior exhibited by users is a

ranking consequence (in the sense of the presentation

model, not the trust in the search engine ranking algo-

rithm), a medium consequence (eye tracking analysis

by Granka et al. (2004) show not every result receives

the same attention) or a combination of both.

In an earlier study with 78 participants sepa-

rated in two experiments, Eisenberg and Barry (1988)

found that the order in which documentsare presented

has inﬂuence on the user relevance judgment. The

authors veriﬁed that when the documents were pre-

sented to participants in a high to low relevance rank-

ing, they consistently underestimated the signiﬁcance

of documents at the end of the list. In a low to high

situation, there was overestimationof documents, par-

ticularly in the ﬁrst middle range. These results may

have been inﬂuenced by the medium: the documents

were presented in paper sheets, one document at a

time, and participants were not able to return to pre-

vious analyzed documents.

In the studies we presented in this section, par-

ticipants’s attention is not distributed equally across

the documents, either on account of the media or the

manner in which documents are presented. Hence, a

similar study where the participants’s attention tend

to be evenly distributed between the presented search

results might provide useful information.

3 EXPERIMENTAL STUDY

We (1) scoped, (2) planned, (3) operated, (4) analyzed

and interpreted the results and (5) evaluated the ex-

periment validity according to the experiment struc-

ture suggested by Wohlin et al. (2012). This structure

was chosen because it describes systematically how

to conduct and evaluate experiments not only in Soft-

ware Engineering (its original purpose), but also in

Computer Science in general. Each step is described

in this section.

3.1 Experiment Scoping

We applied the Goal Question Metric (GQM) tem-

plate by Basili et al. (1994) and expanded by

Van Solingen and Berghout (1999) to structure, con-

duct and summarize the experiment’s nature as well

as the main aspects involved.

The following description about the experiment

objective was elaborated: we are interested in ob-

serving and analyzing users’ behavior when select-

ing a search result from a list, removing possible ad-

ditional inﬂuences conventional search engines may

exert; for the purpose of understanding relevant as-

pects of user behavior during Exploratory Search ac-

tivities, which can be applied in informed design de-

cisions for Exploratory Search tools; with respect to

ranking inﬂuence in search result selection behavior

shown by users; from the viewpoint of the design of

Exploratory Search tools; and in the context of un-

dergraduate and graduate students of Computer Sci-

ence and Informatics performing Exploratory Search

activities.

3.2 Experiment Planning

Experiment planning was composed of ﬁve main

steps. In general terms, we: (1) elaborated the hy-

potheses to be tested; (2) planned the search results

selection; (3) selected the experiment participants;

(4) deﬁned the experiment variables; and (5) elabo-

rated the experiment instrumentation. Each step is

described as follows.

3.2.1 Hypotheses Formulation

The following hypotheses were elaborated and tested:

• Null Hypothesis (H

): Users are not inﬂuenced

by the search results ranking when selecting re-

sults to access.

Corr(SampleDist,StandardDist) = 0 (1)

• Alternative Hypothesis (H

): Users are nega-

tively inﬂuenced by the search results ranking

when selecting results to access.

Corr(SampleDist,StandardDist) < 0 (2)

• Alternative Hypothesis (H

): Users are posi-

tively inﬂuenced by the search results ranking

when selecting results to access.

Corr(SampleDist,StandardDist) > 0 (3)

In Equations 1, 2 and 3, Corr is a correlation

function. SampleDist is the access distribution ob-

served for each position in the search results list and

StandardDist is the access probability for each posi-

tion in the results list, according to the related work of

Granka et al. (2004) and Joachims et al. (2005). These

two studies are used since the data can be compared

with the data collected in this experiment.

Ordering Matters: An Experimental Study of Ranking Inﬂuence on Results Selection Behavior during Exploratory Search

429

3.2.2 Planning of Search Results Selection

To perform the experiment in a consistent manner

with an Exploratory Search activity, we deﬁned an

information need compatible with this type of activ-

ity and speciﬁed it as a query. Such compatibility is

grounded on Exploratory Search attributes listed by

Kules and Capra (2009) and expanded by Wildemuth

and Freund (2012). The information need and query

were presented to the participants so that they could

identify the search context and associate it to the pre-

sented search results. The information need and the

query employed in this study are (translated from Por-

tuguese):

• Information Need: Suppose you want to enter to

the job market with a good job. A large, well-

known and praised company in your area is hiring

promising professionals and invited you for a job

interview. As you would like so much to get the

job, but have never taken part in a interview be-

fore, you want to know more about how job inter-

views are conducted and how to get prepared to

succeed and get the job.

• Query: “how to get prepared for a job interview”.

We issued the query to Google. This information

was omitted from the participant to avoid a possible

conﬁdence bias on the search engine brand. We re-

trieved a list consisting of 100 search results and pre-

selected an aleatory sample of 10 results. We eval-

uated the relevance of these 10 pre-selected results

by their snippets (title, URL and description), and

they all were considered relevant to the information

need. Then a set of 200 random conﬁgurations of the

10 pre-selected results was created from its random-

ization. The generation of random conﬁgurations al-

lowed to neutralize the search engine intrinsic ranking

factor, disassociating the result potential quality from

its ranking order. Therefore, the behavior of results

selection could be evaluated only according to is po-

sition in the ranking.

Participants were asked to select the search result

likely to be the ﬁrst one accessed by them in a natu-

ral search condition. Only one search result must be

selected since, at this time, we were interested only

in the behavior of the ﬁrst selection, which could be

compared with the literature.

3.2.3 Participant Selection

Participant selection included students engaged daily

in Exploratory Search activities. For viability reasons,

we selected undergraduate and graduate students of

Computer Science and Informatics during class with

the permission of their professor. Every student in

class was invited to participate and there was no re-

jection. In addition, everyone authorized the use of

their experimental data and there was no exclusion of

participants after the data was collected. This pro-

cess resulted in a sample of N = 72. Participation

was voluntary, unpaid, with the possibility to leave

the study at any time with no justiﬁcation. The par-

ticipants were not randomly selected due to viability

reasons. However, the assignment of search results

lists was randomized among the participants, charac-

terizing this study, according to Wohlin et al. (2012),

as a quasi-experiment.

Preparing for interviews - Skillsroad

www.skillsroad.com.au/job.../preparing-for-intervie...

Failing to prepare for your job interview can be the most common reason why ... the

difference between landing the job of your dreams and getting rejected.

Prepare for Interviews: Get a Job: Arts & Sciences Career ...

ascs.indiana.edu/get-job/interviews.html

We'll show you how to get past interview jitters and tell employers why you're the right

candidate for the job.

Figure 1: A fragment exemplifying how the results are pre-

sented to the participants.

3.2.4 Variable Deﬁnition

The following variables were deﬁned: (1) a list of 10

search results randomly sampled (independent, as it

represents the input, the possible cause for the anal-

ized effect); and (2) the ranking inﬂuence rate on

users’ search result selection behavior (dependent, as

it represents the output, the analized effect).

3.2.5 Instrumentation

The objects used in the experimentation process were:

• a document describing the experiment, the gen-

eral context of the proposed information need and

the query issued to obtain the search results, along

with a consent form;

• a form containing a checklist with 10 search re-

sults in random order, in which, checking a re-

sult means the participant would access it. This

instrument does not contain any search user inter-

face element other than the results themselves and

selection checkboxes, as shown in Figure 1; and

• a participant characterization questionnaire ask-

ing educational level and experience with search.

Regarding experience with search, those were the

categorization options: (i) very experienced: I

know how to use advanced search features such

as logical operators and ﬁlters, and I can ﬁnd any-

thing I search for; (ii) experienced: I am not fa-

miliar with advanced search features, but I do per-

form searches daily and I easily ﬁnd what I need;

(iii) intermediate: I perform searches daily, but I

ICEIS 2016 - 18th International Conference on Enterprise Information Systems

430

do not always ﬁnd what I need; and (iv) inexpe-

rienced: I only perform searches casually, and I

have difﬁculty knowing how to search properly.

The independent variable (list of 10 search results

randomly sampled) was measured from the partici-

pant’s selected item in the checklist. The dependent

variable (ranking inﬂuence rate on users’ search re-

sult selection behavior) was measured from the cor-

relation between the user’s behavior observed in re-

lated studies and the curve generated from the selec-

tion made by the participants.

3.3 Operation

We prepared and presented the experiment instru-

ments (Section 3.2.5) to the participants, who became

aware of the information need and proceeded to se-

lected the ﬁrst search result they potentially would ac-

cess in the given context. Participants were instructed

to check only one search result in a way as natural

as possible. To promote a natural behavior they were

told there was not a “correct” answer. The experiment

was performed individually by every participant, with

no external aid and time limit. Since we did not detect

any kind of cheating or improper answering during

the experiment, the obtained results were considered

valid for the purpose of this study.

3.4 Analysis and Interpretation

We collected and summarized the data to identify the

total number of hits for each search result position

in the list. Data concerning the participants’ char-

acterization, consisting of their education and their

experience with search was also accounted for. In a

sample of N = 72 participants, 65 of them (90.28%)

are undergraduate students and 7 (9.72%) are gradu-

ate students. Regarding the experience with search, 8

(11.11%) participants claimed to be intermediate, 46

(63.89%) experienced and 18 (25.00%) very experi-

enced. No participant claimed to be inexperienced.

For purposes of comparison, the data analysis

requires a distribution to be used as a referential.

Therefore, we established an equation based on data

obtained by Granka et al. (2004) and as well by

Joachims et al. (2005). The equation is based on the

decay of access probability according to the search

result position. A curve that represents this behavior

can be described as StandardDist= a/x, such that the

area under the curve in the interval [1;10] is equal to

1, the accumulated probability for the search result

selection. This constraint can be written as:

dx = 1 (4)

Solving Equation 4 we ﬁnd a= 1/ ln10. Thus, the

probability curve can be rewritten as:

StandardDist =

xln10

, (5)

where x is the position in the search results list and

x ∈ [1;10].

We validated this curve by performing the correla-

tion between its points (StandardDist) and the distri-

bution obtained in the experiments by Granka et al.

(2004) (which we call GrankaDist) and Joachims

et al. (2005) (which we call JoachimsDist). The cor-

relation statistic was applied because it is able to di-

rectly measure the relationship signiﬁcance between

two ranked distributions, which can be interpreted by

a predeﬁned scale. As the three sets of values are non-

normal distributions (according to Shapiro-Wilk test

with a signiﬁcance level of 1%), the Spearman corre-

lation test was applied with a correlation range pass-

ing through −1.0 (perfect negative correlation), 0.0

(no correlation) and 1.0 (perfect positive correlation).

Values obtained for the Spearman correlation for the

distributions were, both with signiﬁcance level equal

to 0.1%:

Corr(GrankaDist,StandardDist) = 0.8842

Corr(JoachimsDist,StandardDist) = 0.9232

These values indicate the StandardDist curve is

consistent with previous studies, showing a strong

positive correlation. Therefore, the curve can be used

as a reference in correlation with the results sampled

in this study.

In Figures 2, 3 and 4 we illustrate the graphics

generated for the performed correlation. In Figures 2

and 3 the data proximity to the curve StandardDist is

clearly visible, which is plausible since the positive

correlation is strong. Although the correlation illus-

trated in Figure 4 is not clearly visible, the Spear-

man correlation (employed since the study sample

comes from a normal distribution and StandardDist is

a non-normal distribution, according to the Shapiro-

Wilk test with signiﬁcance level of 1%) shows there

is a strong positive correlation, with signiﬁcance level

equal to 1%:

Corr(SampleDist,StandardDist) = 0.7693

Therefore, this correlation value allows the null

hypothesis (H

) and the alternative hypothesis (H

) to

be rejected with a reliability of 99%, and the alterna-

tive hypothesis (H

) to be accepted, indicating users

are positively inﬂuenced by the search results ranking

during selection since:

Corr(SampleDist,StandardDist) > 0

Ordering Matters: An Experimental Study of Ranking Inﬂuence on Results Selection Behavior during Exploratory Search

431

10%

20%

30%

40%

50%

60%

1 2 3 4 5 6 7 8 9 10

Percentage of accesses

Search result position

GrankaDist

StandardDist

Figure 2: Correlation between GrankaDist and

StandardDist distributions.

10%

20%

30%

40%

50%

60%

1 2 3 4 5 6 7 8 9 10

Percentage of accesses

Search result position

JoachimsDist

StandardDist

Figure 3: Correlation between JoachimsDist and

StandardDist distributions.

10%

20%

30%

40%

50%

60%

1 2 3 4 5 6 7 8 9 10

Percentage of accesses

Search result position

SampleDist

StandardDist

Figure 4: Correlation between SampleDist and

StandardDist distributions.

3.5 Validity Evaluation

Regarding the conclusion validity, the sample size

(N = 72), although larger than those of related work,

may not be sufﬁcient to represent the population of

students who perform Exploratory Search activities.

The main risk for the conclusion generalization is

that all the participants are students from the IT area

in the same institution. Replications of this experi-

ment should consider participants from other areas of

knowledge, from different institutions and cultures.

Regarding the construct validity, there was a great

care for the participants to understand correctly what

should be done in the experiment. The information

need was described and explained clearly and suc-

cinctly, and the task to be performed by the partici-

pants was simple enough given their education. No

participant had difﬁculties in understanding and car-

rying out the experiment.

Regarding the experiment internal validity, the

following threats were considered:

• Answers Accuracy: each participant selected

only one search result. They were requested to

select the ﬁrst result they would access on a real

search situation; it was a simple activity that ev-

eryone easily understood, so the responses were

considered accurate.

• Fatigue Effects: the experiment, including expla-

nation, lasted approximately 15 minutes and the

requested task did not require any form of exces-

sive cognitive load. Thus, fatigue effects were not

a problem.

• Inﬂuence Among Participants: the experiment

was supervised by the authors and there was

no exchange of information between participants

during the study. Therefore, the inﬂuence among

participants was not a problem.

• Participants Diversity: the study sample can not

guarantee this behavior also holds for people from

other areas of knowledge and other cultures. As

pointed out by Weinschenk (2011), culture can af-

fect how people think. Western cultures (the ex-

periment case) have a tendency to focus on in-

dividual elements, whereas eastern cultures have

a tendency to focus on context and relationships.

Furthermore, the predominant amount of users

who consider themselves very experienced or ex-

perienced (88.89% in total) may have inﬂuenced

the observed behavior due to the “economic” pro-

ﬁle commonly adopted by this kind of user (Aula

et al., 2005).

Regarding the experiment external validity, the

following threats were considered:

• Artiﬁcial Task: Russell and Grimes (2007) argue

that artiﬁcial search activities do not accurately re-

ﬂect the behavior of natural search activities, thus,

to “impose” a search activity for the participant

is not an ideal approach. The authors, however,

admit that artiﬁcial search activities are necessary

due to research viability, and that they can provide

useful information.

• Atypical Media: in this study, the digital media

on which searches actually occur was replaced by

the printed medium. As a consequence, the be-

havior of comparison and selection was different

in terms of scan and selection time. However, al-

though the printed medium is not the natural con-

text of a search activity, the choice was deliber-

ate so that participants could distribute their atten-

tion more evenly between the search results, and

were not inﬂuenced by graphical elements and in-

teractions possibilities offered by traditional web

search engines.

ICEIS 2016 - 18th International Conference on Enterprise Information Systems

432

4 RESULTS DISCUSSION

The correlation found in the present study (0.7693)

was not as high as the correlation found in the other

two distributions from Granka et al. (2004) (0.8842)

and from Joachims et al. (2005) (0.9232). However, it

is still a strong positive correlation, and hence it still

corroborates the evidence that the search result se-

lection behavior is inﬂuenced by ranking, with users

showing a tendency to select higher ranked results.

As a possible reason for the relatively lower cor-

relation value, it can be noted that users, on average,

selected lower ranked search results when compared

to related work. In the present study, the selected re-

sult average position was µ = 4.37 with a standard

deviation of σ = 2.87, whereas in the related studies,

users where mostly concentrated in the ﬁrst two re-

sults. Although this average may appear as an homo-

geneous distribution, approximately 71% of the se-

lections were concentrated in the ﬁve higher ranked

results, corroborating that higher ranked results are

selected more often. The selection of lower ranked

results in comparison with related work can be at-

tributed to factors such as:

• the participants’ experience with search com-

bined with their education and area of knowledge:

88.89% of the participants declared themselves

very experienced or experienced, hence an “eco-

nomic” proﬁle would be expected, however, their

level of education and their area of knowledge

may lead to other behaviors;

• the experiment was carried out in paper, evok-

ing a different behavior from a real search activ-

ity. While people rarely look at everything in Web

pages, not even seeing most of the search results,

with paper sheets they tend to give at least a look

at every result. At the same time, they can’t go

beyond the 10 results presented to them, as they

can on the Web; and

• the participants had performed a suggested search

task, and not a natural search activity, which may

have implied in an unnatural search behavior, and

thereafter, an unnatural search result selection be-

havior.

Overall, the evidence acquired through this study

can be useful during informed design decisions for

Exploratory Search tools. Since the observed be-

havior can represent a risk to the success of an Ex-

ploratory Search activity, Exploratory Search tools

should try to encourage users to take a different ap-

proach by exploring more deeply the results. This

could be approached, for example, with novel user in-

terfaces or recommendation systems.

5 CONCLUSION

Although Exploratory Search has been discussed in

several studies in recent years, current search engines

still lack support for this kind of activity. Therefore,

there is still room for models and tools to support the

user in Exploratory Search activities, and the design

of such models and tools can beneﬁt from understand-

ing users’ behavior during this kind of activity. Ac-

cordingly, information about the search result selec-

tion behavior can be particularly useful for informed

design decisions in Exploratory Search tools.

Studies indicate users give more attention and,

therefore, more hits to higher ranked search re-

sults. However, such studies do not allow to con-

clude whether this behavior is only due to the rank-

ing schema, whereas there are other factors possi-

bly inﬂuencing user behavior. Therefore, we inves-

tigated whether such behavior remains in a medium

which the user’s attention tends to be distributed more

evenly between the presented results and with no ad-

ditional graphical tricks and interaction possibilities.

We deﬁned a standard distribution of access prob-

ability based on a decay curve according to the search

result position. This standard distribution was eval-

uated against two other distributions from the litera-

ture to be used as a baseline for the experiment. The

sample distribution was then compared to the base-

line and, by means of a strong positive correlation, we

provided evidence the users’ behavior on search result

selection is indeed inﬂuenced by the ranking schema.

Such ﬁnding is complementary to the aforemen-

tioned related work, with the addition that the inﬂu-

ence occurred even though the results were randomly

reordered, and participants tended to distribute their

attention more equally between the results. Since giv-

ing more attention and, therefore, more hits to higher

ranked results is not ideal for Exploratory Search ac-

tivities, tools for these kind of activities should en-

courage users to explore more deeply the results.

Thereby, the listing presentation may not be the best

choice for the design of Exploratory Search tools,

once it is not guaranteed the most relevant results will

always be high ranked.

For future work we aim to (i) replicate the exper-

iment aiming to achieve a more distributed sample;

(ii) carry out a new experiment containing varied in-

formation needs and, consequently, different results

lists; (iii) conduct another experiment allowing the

participants to select as many results as they want; and

(iv) carry out both qualitative and quantitative stud-

ies to analyze different behaviors of users engaged in

Exploratory Search activities from users engaged in

simpler search activities.

Ordering Matters: An Experimental Study of Ranking Inﬂuence on Results Selection Behavior during Exploratory Search

433

ACKNOWLEDGEMENTS

This study was ﬁnancially supported by Coorde-

nao de Aperfeioamento de Pessoal de Nvel Supe-

rior (CAPES) and Conselho Nacional de Desenvolvi-

mento Cientﬁco e Tecnolgico (CNPq). The authors

would like to dedicate this work to Professor Srgio

Roberto Pereira da Silva who is dearly missed.

REFERENCES

Aula, A., Majaranta, P., and R¨aih¨a, K.-J. (2005). Eye-

tracking reveals the personal styles for search result

evaluation. In Proc. Int. Conf. IFIP TC13 on Human-

Computer Interaction, pages 1058–1061. Springer-

Verlag.

Basili, V., Caldiera, G., and Rombach, H. D. (1994). Ency-

clopedia of Software Engineering, chapter The Goal

Question Metric Approach, pages 528–532. John Wi-

ley & Sons, Inc.

Bates, M. J. (1989). The design of browsing and berrypick-

ing techniques for the online search interface. Online

Information Review, 13(5):407–424.

Blandford, A. and Attﬁeld, S. (2010). Interacting with In-

formation, volume 3 of Synthesis Lectures on Human-

Centered Informatics. Morgan & Claypool Publishers.

Eisenberg, M. and Barry, C. (1988). Order effects: A study

of the possible inﬂuence of presentation order on user

judgments of document relevance. Journal of the

American Society for Information Science, 39(5):293–

300.

Granka, L. A., Joachims, T., and Gay, G. (2004). Eye-

tracking analysis of user behavior in www search. In

Proc. Int. Conf. ACM SIGIR on Research and De-

velopment in Information Retrieval, pages 478–479.

ACM.

Hearst, M. (2009). Search User Interfaces. Search User

Interfaces. Cambridge University Press.

Jansen, B. J., Zhang, L., and Mattila, A. S. (2012). User

reactions to search engines logos: investigating brand

knowledge of web search engines. Electronic Com-

merce Research, 12(4):429–454.

Jansen, B. J., Zhang, M., and Schultz, C. D. (2009). Brand

and its effect on user perception of search engine per-

formance. Journal of the American Society for Infor-

mation Science and Technology, 60(8):1572–1595.

Joachims, T., Granka, L., Pan, B., Hembrooke, H., and

Gay, G. (2005). Accurately interpreting clickthrough

data as implicit feedback. In Proc. Int. Conf. ACM

SIGIR on Research and Development in Information

Retrieval, pages 154–161. ACM.

Kules, B. and Capra, R. (2009). Designing exploratory

search tasks for user studies of information seeking

support systems. In Proc. ACM/IEEE-CS Joint Conf.

on Digital libraries, pages 419–420.

Pan, B., Hembrooke, H., Joachims, T., Lorigo, L., Gay, G.,

and Granka, L. (2007). In google we trust: Users de-

cisions on rank, position, and relevance. Journal of

Computer-Mediated Communication, 12(3):801–823.

Russell, D. and Grimes, C. (2007). Assigned tasks are not

the same as self-chosen web search tasks. In Proc. Int.

Conf. HICSS on System Sciences, pages 83–83.

Van Solingen, R. and Berghout, E. (1999). The

Goal/Question/Metric Method: A Practical Guide

for Quality Improvement of Software Development.

McGraw-Hill Higher Education.

Weinschenk, S. (2011). 100 Things Every Designer Needs

to Know About People. New Riders Publishing.

White, R. W., Capra, R., Golovchinsky, G., Kules, B.,

Smith, C., and Tunkelang, D. (2013). Introduction to

special issue on humancomputer information retrieval.

Information Processing & Management, 49(5):1053 –

1057.

White, R. W., Kules, B., and Bederson, B. (2005). Ex-

ploratory search interfaces: categorization, cluster-

ing and beyond: report on the XSI workshop at the

human-computer interaction laboratory, university of

maryland. SIGIR Forum, 39(2):52–56.

White, R. W. and Roth, R. A. (2009). Exploratory

Search: Beyond the Query-Response Paradigm, vol-

ume 1 of Synthesis Lectures on Information Concepts,

Retrieval, and Services. Morgan & Claypool Publish-

ers.

Wildemuth, B. M. and Freund, L. (2012). Assigning search

tasks designed to elicit exploratory search behaviors.

In Proc. Symp. on Human-Computer Interaction and

Information Retrieval, pages 4:1–4:10. ACM.

Wohlin, C., H¨ost, M., Runeson, P., Ohlsson, M., Regnell,

B., and Wessl´en, A. (2012). Experimentation in Soft-

ware Engineering. Computer Science. Springer.

ICEIS 2016 - 18th International Conference on Enterprise Information Systems

434
