Security Scores for Medical Devices

Johannes Sametinger

and Jerzy Rozenblit

Department of Business Informatics - Software Engineering, Johannes Kepler University Linz,

Altenbergerstraße 69, 4040 Linz, Austria

Department of Electrical and Computer Engineering, University of Arizona,

1230 E Speedway Blvd, 85718 Tucson AZ, U.S.A.

Keywords: Security, Security Score, Medical Devices, Sensitivity, Impact, Safety, Vulnerability, Security Risk.

Abstract: Medical devices are indispensable for millions of patients worldwide. They increasingly depend on software

and hardware components, and interoperate with other devices wirelessly and through the Internet. The sen-

sitive nature of health records, the increasing interoperability of medical devices, and the fact that human

well-being and life are at stake, puts medical device security at the forefront in healthcare technology. In this

paper, we contrast medical devices’ safety with their security and introduce a stratification of security scores.

We need such a grading to increase security awareness in the medical domain and as a guideline for designers

and developers who will have to act appropriately to ensure devices’ trustworthiness and as a basis for stake-

holders’ course of action when devices pose risks. We motivate and illustrate the scores by examples.

1 INTRODUCTION

Medical devices have more and more embedded soft-

ware with communication mechanisms that now

qualify them as information systems. Security is

about protecting information and information sys-

tems from unauthorized access and use. Confidential-

ity, integrity, and availability of information are core

design and operational goals. Software security is

“the idea of engineering software so that it continues

to function correctly under malicious attack”

(McGraw, 2004). In this sense, medical device secu-

rity is quite similar. Its goal is to engineer such de-

vices so that they ideally would be immune to mal-

ware implantation or if a breach occurred, they would

continue to function correctly. Medical devices com-

prise a broad range of instruments and utensils. In this

paper, we discuss only devices with hardware, soft-

ware, and some form of interoperability. For exam-

ple, most artificial joints are not “powered” by soft-

ware (yet). Thus, we can ignore them from a security

perspective. However, they are indeed critical from a

safety point of view. Researchers have demonstrated

successful hacking of medical devices on several oc-

casions. For example, Jay Radcliffe was able to send

commands to his insulin pump (raise or lower insulin

levels) and to disable it wirelessly within a distance

of up to 150 feet (Kaplan, 2011). Chunxiao et al.,

(2012) have shown security attacks and defenses for

a diabetes therapy system. FDA's safety division has

issued a warning to device makers and healthcare pro-

viders to put safeguards in place to prevent cyber-at-

tacks (FDA, 2013). We do not know about any deaths

or injuries yet, but hypothetical ramifications, e.g.,

ransomware on medical devices, are obvious. The IT

landscape can also pose a threat to medical opera-

tions. For example, when computers around the world

came to a halt after an antivirus program identified a

normal Windows file as a virus, hospitals had to post-

pone elective surgeries and stop treating non-critical

patients in emergency rooms (Fox, 2010). The fact

that there are still many medical devices based on an

old version of the Windows operating system is an-

other problem (Fu and Blum, 2013).

People increasingly manage their health and

wellness with mobile medical applications (FDA,

2015). Such apps may promote healthy living and

provide access to useful health information. Mobile

apps can extend medical devices by connecting to

them for the purpose of displaying, storing,

analyzing, or transmitting patient-specific data (FDA,

2013b). Not every mobile medical application

necessarily poses a security risk. However, as soon as

it processes or transmits sensitive information or even

controls the medical device, we have to take security

precautions. Mobile and cloud frontiers pose new

Sametinger, J. and Rozenblit, J.

Security Scores for Medical Devices.

DOI: 10.5220/0005838805330541

In Proceedings of the 9th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2016) - Volume 5: HEALTHINF, pages 533-541

ISBN: 978-989-758-170-0

533

challenges, where designers and developers of

healthcare IT must address pre-existing security

vulnerabilities and undiagnosed future threats (Kotz

et al., 2011).

Over the last years, wearable devices have be-

come popular. With sensors attached to the body, they

detect and monitor changes in body signatures of var-

ious areas. Athletes, people aware of personal fitness,

but also patients use wearable devices. For our dis-

cussion, it is not relevant whether a medical device is

wearable. Many consumer-acquired wearable devices

like fitness trackers or heart rate monitors do not qual-

ify as medical devices. They cannot have a direct neg-

ative effect on their wearers, but they may contain

sensitive information. Therefore, they are not com-

pletely out of our scope even though we concentrate

on medical devices. We propose security scores for

medical devices in order to increase security aware-

ness and, thus, to motivate stakeholders to plan coun-

termeasures accordingly. Someone's security aware-

ness is her knowledge and attitude regarding the pro-

tection of a device's information system. In the con-

text of medical devices, it is important that all stake-

holders, not just device manufacturers, display this

knowledge and attitude and, most of all, work to-

gether to explicitly know a device’s security status

and improve it when needed.

In Section 2, we briefly introduce medical devices

and contrast safety to security. In Section 3, we dis-

cuss levels of concern comprising sensitivity, impact

and exposure of medical devices. Vulnerabilities and

the suggested security scores follow in Section 4. In

Section 5, we give a discussion of the proposed

scores. A conclusion follows in Section 6.

2 MEDICAL DEVICES

Medical devices include everything from simple

wooden tongue depressors to highly sophisticated

computerized medical equipment (World Health Or-

ganization, 2003). According to the WHO, a medical

device is “an instrument, apparatus, implement, ma-

chine, contrivance, implant, in vitro reagent, or other

similar or related article” intended for use in the diag-

nosis, prevention, monitoring, treatment, etc. of a dis-

ease or other conditions (World Health Organization,

2003). The FDA uses a similar definition (FDA,

2014). Classes of medical devices are different in var-

ious countries. In the US, FDA's Center for Devices

and Radiological Health is responsible for regulating

firms, which manufacture, repackage, relabel, or im-

port medical devices. The FDA has established clas-

sifications for about 1,700 different generic types of

devices. They further group them into medical spe-

cialties, called panels. Examples for FDA’s specialty

panels include cardiovascular, dental, and orthopedic

devices (FDA, 2014).

A more general classification divides medical de-

vices into everyday use, diagnostic, therapeutic, and

life-supporting equipment (Smith, 2012). Doctors

and nurses use such equipment daily during routine

medical procedures. Examples include needles, latex

gloves, syringes and stethoscopes. The main purpose

of diagnostic equipment is to help doctors detect and

diagnose diseases. Examples include ultrasound ma-

chines, positron emission tomography (PET) scan-

ners, computer tomography (CT) scanners, and mag-

netic resonance imagery (MRI) machines. Therapeu-

tic equipment helps patients to recover and improve

their health after surgeries and other medical treat-

ments. Examples are devices such as infusion pumps

and medical lasers. Life-support equipment is helpful

in cases of physiological organ failure or major

trauma. Examples include heart-lung machines, med-

ical ventilators, and dialysis machines.

What makes medical devices stand out is not just

the fact that they may potentially threaten life. We

also need to secure our IT infrastructure. This infra-

structure comprises not only physical devices but also

personnel, security companies, emergency response

teams, etc. We typically rely upon these entities,

should IT-related problems occur. Patients and

healthcare providers are not IT experts and are very

much at the mercy of the devices’ manufacturers who

only now are beginning to take security seriously. The

goal of our suggested security scores is to fill this gap

and to make devices’ security states better accessible,

visible, and understandable to all stakeholders.

2.1 Device Safety

The FDA has assigned generic device types to the

regulatory classes I, II or III, which are based on the

level of control that is necessary to assure the safety

and effectiveness of a device. The higher a device’s

risk, the higher its class (FDA, 2014). Class I includes

devices with the lowest risk, class III those with the

highest risk. Class III devices need a pre-market ap-

proval process. Examples include implanted devices

and devices that may be necessary to sustain life like

artificial hearts or automated external defibrillators.

2.2 Device Security

Whether a medical device is active or passive is im-

portant in many respects. Passive devices do nothing

by themselves, e.g., a stethoscope or a simple artifi-

SmartMedDev 2016 - Special Session on Smart Medical Devices - From Lab to Clinical Practice

534

cial joint. Active devices may or may not involve

software, hardware, and interfaces, which are crucial

when considering security issues. These devices can

do some processing, receive inputs outside of the de-

vice (sensors), output values to the outer world (actu-

ators), and communicate with other devices. Medical

devices are security-critical if they do some form of

processing and communicating, typically by running

software on specialized hardware, and often, by em-

ploying a range of sensors (Sametinger et al., 2015).

The devices do not need to be re-configurable in order

to be security-relevant. All medical devices as de-

fined by the WHO or by the FDA have aspects that

are inherently safety related. However, not all of these

devices are relevant from a security point of view; re-

member the above-mentioned artificial joint. Typi-

cally, security is an issue as soon as software is in-

volved. There are, however, security-relevant instru-

ments and appliances that the WHO or the FDA do

not consider medical. Examples include smartphones

that run fitness apps handling sensitive information,

or regular PCs in a hospital for processing medical

records.

Paul et al., have proposed a security-based classi-

fication of medical devices where the primary factor

is how patients use the device (Paul et al., 2011).

Class I includes devices that are completely external

to the body. Examples include smartphones and per-

sonal computers. Naturally, devices in class I are also

a part of the medical enterprise. Class II contains de-

vices that are implanted but external to the body. Ex-

amples include infusion pumps. Finally, class III con-

tains devices that are completely implanted and are

not physically, externally accessible. Examples are

pacemakers and internal cardiac defibrillators.

2.3 Interoperability

According to a study by the West Health Institute, de-

vice interoperability with electronic medical records

(EHRs) could save the U.S. healthcare industry $30B

annually (Versel, 2013). In fact, medical devices are

increasingly communicating health information, e.g.,

insulin pumps or pacemakers may transmit logs di-

rectly to physicians or hospitals, or receive modified

settings and commands (Kramer et al., 2012). Storing

and transmitting patients’ medical information re-

quires state-of-the-art technology. Networked mobile

devices enable individuals and their physicians or

hospital personnel to better monitor and manage their

medical conditions (Kotz, 2011). If device communi-

cation is wireless or over the Internet, then transmit-

ted information is at risk of exposure. We can wire-

lessly connect devices with mobile medical applica-

tions to wearable, portable, and even embeddable sen-

sors (Kotz, 2011). They enable effortless continuous

medical monitoring. Examples of monitored values

are glucose levels in diabetic patients or the weight of

individuals seeking to lose it. In such settings, people

involved need subtle control over the collection, re-

cording, dissemination, and access to monitored data.

When patients use new sensing devices, they add a

new dimension to the confidentiality challenge. In the

near future, it is likely that we will witness the prolif-

eration of tiny sensors that detect a widening range of

compounds and report it to our mobile devices like

smartphones. We may then transmit the collected val-

ues to healthcare institutions or to public clouds, ena-

bling the powerful and cost-effective screening, diag-

nosing, monitoring, and tracking of people’s health.

Sensors and microelectronics integrated into the sole

of running shoes are one recent example. They meas-

ure the biomechanical data of the runner and evaluate

her form with real-time measurements, which they

then transmit to a smartphone and to an external

server for further evaluation. Google’s proposed

smart contact lenses to monitor diabetics provide an-

other example with a hint of how the future might

look like. Increased use of sensors may one day allow

us to monitor medical conditions and help develop in-

dividualized treatments. Clearly, the increased in-

teroperability of devices leads to increased security

risks and, hence, requires increased security measures

in order to protect these devices from attacks.

3 LEVELS OF CONCERN

The FDA has introduced the level of concern for med-

ical devices. It is a measure referring “to an estimate

of the severity of injury that a device could permit or

inflict, either directly or indirectly, on a patient or op-

erator as a result of device failures, design flaws, or

simply by virtue of employing the device for its in-

tended use” (FDA, 2005). The FDA’s severity of in-

jury distinguishes death, minor and serious injury. We

will consider device failures or design flaws in Sec-

tion 4. In addition to the impact of a device, we sug-

gest to also consider the fact whether devices store

and process sensitive information and how much a

device is exposed to its environment.

Thus, we propose a level of concern for medical

devices based on whether they process or communi-

cate sensitive information, whether they process or

communicate safety-critical information, and how ex-

posed they are to their environment. To keep things

Security Scores for Medical Devices

535

simple, we have chosen to use four levels for all cat-

egories, i.e., low, moderate, high, and very high.

3.1 Sensitivity

In a medical context, sensitive information includes

anything about a patient, e.g., medical records, and

values from sensing devices that report information

about a person’s or her device’s state, e.g., glucose

level, ID, or parameter settings of a pacemaker. We

introduce a medical device’s sensitivity to indicate

the amount of sensitive information on that device.

There are several approaches to define sensitive in-

formation in the health domain, e.g., HIV test results,

information from reproductive health clinics, and in-

formation about celebrities’ medical issues. At this

point, we emphasize that we typically do not catego-

rize information as slightly or highly sensitive. Either

it is sensitive or it is not. We propose a pragmatic ap-

proach for scoring the sensitivity and use an estimate

of the amount of sensitive information on a device,

and an estimate of how easily we can attribute this

information to a specific patient. Thus, we categorize

the information to be slightly sensitive, sensitive, or

highly sensitive. Table 1 summarizes our suggested

sensitivity levels. We will later use the numbers in pa-

rentheses for calculations. We make the distinction

between high and very high based on the fact whether

sensitive information is stored of a single person or of

multiple persons. We refrain from using a finer gran-

ularity for the sake of simplicity.

Table 1: Sensitivity of medical devices.

Sensitivity Description Examples

Low (0)

No sensitive

information on device

Dental laser

Moderate

(1)

Moderately sensitive

information (sensor

values, no personal

info)

Insulin pump storing

glucose levels,

Blood glucose meter

High (2) Sensitive information

PC storing individual

health records

Very High

(3)

Highly sensitive

information (personal

information, health

information)

Server storing many

health records

3.2 Impact

Medical devices differ in the degree of impact that

they can have on a patient. Typically, devices with a

high benefit (utility) also pose a high potential harm.

For example, a cardiac pacemaker can save the life of

patients, but it can also threaten the life of a patient if

it malfunctions. A pacemaker has a direct impact on

the patient as it can directly influence the heart rate.

Other devices can have indirect impact. Determining

the indirect impact of a device is much more difficult

than determining its direct impact. For example, a

blood glucose meter has no direct impact, but the val-

ues it provides indirectly influence the insulin dose a

patient delivers to herself. This dose influences the

patient’s health. If a BGM displays wrong values,

then it may influence the amount of insulin its user

will deliver. In a worst-case scenario, this may even

result in the death of that person.

We introduce a device’s impact to indicate the in-

fluence a device has on a patient, i.e., the potential

benefit and the potential harm a device can do to a

patient, be it directly or indirectly. Table 2 summa-

rizes medical devices’ impact. Again, the coarse gran-

ularity may sometimes prohibit an easy assignment to

one of the values. For example, well-being may affect

health and the other way round. Generally, we can say

that the higher the level, the higher the impact. When

one device has a higher impact than another device,

then we assign the former to a higher level than the

latter, even though both may influence well-being or

health.

Table 2: Impact of medical devices.

Impact Description Examples

Low (0) No impact

Administrative PC in

hospital Heart rate

watch

Moderate (1)

Impact on

well-being

Drug dispensing

device, Dental laser

High (2) Impact on health Blood glucose meter

Very High

(3)

Impact on life

Pacemaker, X-ray,

Insulin pump,

Heart-lung machine

3.3 Exposure

Modern devices tend to increase interoperability. In-

teroperability refers to the mode in which devices

work with one another. Medical devices can operate

as stand-alone (low exposure) or they can interoperate

with other devices and even connect to the Internet

(high exposure). High exposure offers a big attack

surface for potential intrusions. However, it also pro-

vides flexibility and benefits. For example, a cardiol-

ogist may save a patient’s life by remotely controlling

her pacemaker in a medical emergency. An infor-

mation security exposure is “a system configuration

issue or a mistake in software that allows access to

information or capabilities that can be used by a

hacker as a stepping-stone into a system or network”

(MITRE).

A system’s attack surface is the set of ways in

SmartMedDev 2016 - Special Session on Smart Medical Devices - From Lab to Clinical Practice

536

which an adversary can enter the system and poten-

tially cause damage (Manadhata, 2008). Every fea-

ture of a system adds a certain amount of risk. A large

attack surface provides potential for intrusions. Nev-

ertheless, it also provides flexibility and benefits.

Table 3 summarizes medical devices’ exposure

levels. Devices connected to the Internet may have an

IP address, but they may also be accessible through

an intermediate device that connects to the Internet

and allows access to the medical device in some form.

Please note that this level is independent from any se-

curity measures that we may have taken to protect the

device. If a medical device has a high exposure, then

it is possible to control its impact and to access sensi-

tive information externally. This can be done by au-

thorized parties, e.g., medical doctors in charge, or, if

the device is not properly secured, by malicious at-

tackers. Needless to say that we need safeguards too

to prevent voluntary or involuntary harm by author-

ized parties.

Table 3: Exposure of medical devices.

Exposure Description Examples

Low (0)

Stand-alone device

without communication

features

Dental laser, Bone

growth stimulator

Moderate (1)

Device with

near-field

communication

Pacemaker

High (2)

Device with “plug-and-

play” interoperability or

distant wireless

communication

Tablets used by

physicians

Very High (3)

Device with Internet

connection

Server with

health records

3.4 Privacy and Safety Concerns

When we combine exposure with sensitivity, then we

obtain the degree of exposure of sensitive infor-

mation. If a highly exposed device stores highly sen-

sitive information, then the exposure of the sensitive

information is high. We introduce a simple formula to

calculate numerical values. By multiplying sensitivity

or impact with exposure, we get values between zero

and nine. The result is zero when either sensitivity or

exposure is zero, i.e., there neither is sensitive infor-

mation on the device nor does it interoperate with

other devices. Multiplying the values 0...3 by 0...3

yields values in the range 0,1,2,3,4,6,9. The resulting

values can be classified as low (0, 1), moderate (2, 3),

high (4, 6) and very high (9).

From a privacy perspective, we do not have to be

concerned about devices that do not store or process

sensitive information. In addition, there is no need to

be worried if the device is not exposed. From a safety

perspective, we do not have to be concerned about de-

vices without an impact on patients. Again, no need

to worry if there is no exposure of the device. From a

security perspective, devices not exposed to their en-

vironment are not an issue. At this point, we refrain

from considering situations where malware may in-

fect devices during the manufacturing process (Same-

tinger et al., 2015). Privacy is at stake if there is sen-

sitive information and we can access it from outside

the device. Safety is at stake if there is an impact on

patients and we can control this impact from outside

the device.

3.5 Examples

We discuss a blood glucose meter (BGM), a cardiac

pacemaker (CPM), an ultrasound imaging device

(USI), a magnetic resonance imagery machine (MRI),

and a diabetes logbook app (DLA) as illustrative ex-

amples. A stand-alone blood glucose meter allows its

user to read blood glucose values from the device’s

display. The device does not have any information

about the patient who uses it but may store several

historic values. An implanted cardiac pacemaker en-

ables a cardiologist to program it via wireless com-

munication. The device stores some basic information

about its wearer. An ultrasound-imaging device pro-

vides a LAN connection to store patients’ images in

an in-house database. The same is true for the mag-

netic resonance imagery machine. The diabetes log-

book app runs on a smartphone and allows its user to

log information about meals, blood glucose values

(from the BGM) as well as insulin levels and dosages.

If the app is a registered (class 1) medical device, pa-

tients’ doctors can use generated reports to make

medical decisions. The app stores backup data on the

manufacturer’s cloud infrastructure.

Table 4 shows all the levels of concern we have

defined for these devices. We can see at a glance

where we need security countermeasures. Please note

that the devices we have chosen as examples exist in

many different forms from various vendors. These

devices will vary in the levels of concern also. A de-

vice can store more or less sensitive information and

interoperate with its environment to a greater or lesser

extent. Therefore, it is important to define the levels

of concern for specific devices of a specific manufac-

turer, rather than for a group of devices. We have cho-

sen the numbers in Table 4 to represent a specific de-

vice category. It is interesting to see that the blood

glucose meter does not need any security precautions

even though there is an indirect impact on patients.

Missing exposure makes it impossible for attackers to

Security Scores for Medical Devices

537

manipulate the device. We have rated the impact of

the diabetes logbook app higher than the impact of the

blood glucose meter, because the logbook may con-

tain a much longer history of values that, if manipu-

lated, may have more serious consequences if used

for therapeutic decisions. We have specified different

sensitivity and impact levels for the two imaging de-

vices USI and MRI, simply to demonstrate different

level combinations. Not surprisingly, Table 4 shows

that our MRI needs more security precautions than

our BGM.

Table 4: Levels of concern for sample medical devices.

Device Sn Im Ex PLC SLC

BGM 0 1 0 0 0

CPM 1 3 1 1 3

USI 1 1 3 3 3

MRI 3 2 3 9 6

DLA 3 2 3 9 6

Sn … Sensitivity, Im … Impact, Ex … Exposure

PLC … Privacy level of concern, SLC … Safety level of concern

BGM … Blood glucose meter, CPM … Cardiac pacemaker

USI … Ultrasound imaging device, MRI … Magnetic resonance imagery

DLA … Diabetes logbook app

4 SECURITY SCORES

Regardless of a device’s level of concern, i.e., its sen-

sitivity, impact, and exposure, it can be secure or in-

secure depending on whether there are vulnerabilities

and on whether somebody knows these. “100% se-

cure” devices are as unlikely as zero-fault software.

We will have to find a way to manage insecure de-

vices. Devices with high exposure of sensitive infor-

mation pose a higher privacy risk, but if we have

taken proper security countermeasures, then the pri-

vacy threat may still be low. The same holds for de-

vices with a high exposure of impact and a higher

safety risk. Whether a device is actually at risk de-

pends on whether there are security vulnerabilities

and potential exploits. Thus, we have to define the

current vulnerability level and then calculate the pri-

vacy and safety scores depending on a device’s sen-

sitivity and impact, respectively.

4.1 Vulnerability

We have stated in the introduction that secure devices

have to continue to function correctly even if under a

malicious attack. Vulnerabilities are errors in devices,

typically in software, which we can directly use to

gain unauthorized access to the device. They pose a

threat to the device itself, to the information it con-

tains, to other devices it communicates with, and to

its environment. Today, most stakeholders are con-

cerned about the safety of medical devices. They pay

less attention to the devices’ vulnerabilities. These

can be quite volatile. When we detect vulnerabilities,

our rating of the device’s threat may increase rapidly.

It is important for everyone involved to have a clear

picture of the current security status and to make rea-

soned decisions about necessary steps in order to de-

crease the threat, if needed. We propose vulnerability

levels as described in Table 5.

Table 5: Vulnerability of medical devices.

Security Description Examples

Low (0)

Neither

vulnerabilities nor

malware on device

New device

Device with upgraded

software version

Moderate (1)

Vulnerabilities

on device,

no exploits yet

Weakness in protocol

Potential buffer

overflow

High (2)

Vulnerabilities

on device with

known exploits

Protocol weakness or

buffer overflow can be

used for unauthorized

access

Very High (3) Malware on device

Hardware Trojan or

software backdoor on

device

At this point, we clearly have to distinguish be-

tween two different perspectives, i.e., the attacker’s

and the risk analyst’s perspective. If a potential at-

tacker detects vulnerabilities, then the actual threat,

but not necessarily the analyst's assessment of it, will

increase. Thus, a device’s vulnerability level repre-

sents a person’s knowledge about this device’s vul-

nerabilities. Not knowing any vulnerability does not

necessarily mean that none exists. A device’s vulner-

ability provides a dynamic property, as found vulner-

abilities and exploits increase the risk, and later

patches and updates reduce the risk.

Both software and hardware take time to mature.

Therefore, a five year old product may potentially be

safer than a new product out in the market. However,

we argue that it is reasonable to assume that a new

device or software upgrade is low on the vulnerability

scale, cf. Table 5. At that time, vulnerabilities are not

yet known and, for software upgrades, known vulner-

abilities have usually been fixed.

4.2 Privacy and Safety Scores

A medical device is at risk when it is vulnerable and

stores sensitive information. It also poses a risk when

it is vulnerable and it has an impact on a patient. Pri-

vacy concerns exist when personally identifiable in-

formation or other sensitive information is processed

SmartMedDev 2016 - Special Session on Smart Medical Devices - From Lab to Clinical Practice

538

or stored. Insufficient access control or inappropriate

sharing are often the cause of privacy issues. Privacy

is about the ability to conceal information about a pa-

tient. Disclosure of sensitive information may result

in negative consequences. For example, an employer

may not be willing to employ people with HIV. Sen-

sitive information may also constitute a threat, be-

cause wrong values may later induce therapeutically

wrong decisions by doctors or devices. We calculate

privacy and safety scores again by using multiplica-

tion. Sensitivity multiplied by the vulnerability yields

the privacy score; impact multiplied by vulnerability

yields the safety score.

The levels of concern provide general information

about how important security precautions are for a de-

vice. Vulnerability levels and security scores, i.e., pri-

vacy and safety score, indicate a device’s current se-

curity status. The higher it is, the more we have to

expect security breaches.

4.3 Examples

In Table 6, we present different vulnerability levels

for the devices introduced in the previous section. If

we assume that there are no known vulnerabilities,

then we set the appropriate level to zero. This is the

case, for example, when a new device comes to mar-

ket. There is no risk yet at that time. Later, when we

know about vulnerabilities, risk increases. In Table 6,

we show devices as defined above with various vul-

nerability levels and the resulting privacy and safety

scores. A quick glance at the table reveals that privacy

and safety are at risk in the logbook app, and that the

cardiac pacemaker’s safety is at risk. We will discuss

consequences from that information below. Please

note that we use values for sample devices in Table 6.

These devices may have different values than speci-

fied in our table. The values depend on the specific

implementation and equipment by the manufacturers.

Table 6: Privacy and safety scores for sample devices.

Device Sn Im Vu Priv Saf

BGM 0 1 3 0 3

CPM 1 3 2 2 6

USI 1 1 1 1 1

MRI 3 2 0 0 0

DLA 3 2 3 9 6

Sn … Sensitivity, Im … Impact, Vu … Vulnerability

Priv … Privacy Score, Saf … Safety Score

BGM … Blood glucose meter, CPM … Cardiac pacemaker

USI … Ultrasound imaging device, MRI … Magnetic resonance imagery

DLA … Diabetes logbook app

We have to mention at this point that knowledge

about the existence or non-existence of vulnerabilities

may differ among different persons. It is always pos-

sible that only malicious attackers are aware of vul-

nerabilities. In this case, we may assume a low score

even though the danger of an attack is indeed high.

The malicious attackers who know about the vulner-

ability are able to determine the appropriate score.

5 DISCUSSION

We imagine having levels of concern as well as pri-

vacy and safety scores defined for any medical de-

vice. Levels of concern include sensitivity, impact,

and exposure. Manufacturer can define them for the

approval process. The vulnerability level as well as

privacy and safety scores of a device are dynamic

properties; we have to maintain them in order to de-

scribe the current risk associated with using a device.

It should be mandatory that they be maintained and

publicly available. Thus, doctors and patients would

be able to check out both the levels of concern and

security scores of a specific device. As manufacturers

may be hesitant to admit increased vulnerability, we

imagine a neutral third-party organization to be in

charge, e.g., the MITRE Corporation that operates

CVE, a dictionary of publicly known information se-

curity vulnerabilities and exposures. We may deduct

a device’s vulnerability level from the number and se-

verity of its CVEs.

Risk management includes risk framing, risk as-

sessment, risk response and risk monitoring (Ross,

2011). Our suggested security scores contribute to the

assessment and to the monitoring of risks of medical

devices. The number of entry points that an attacker

may use to access the device defines the attack sur-

face. The exposure we have suggested does not dif-

ferentiate between devices with big or small attack

surfaces. Minimizing the attack surface can reduce

the risk of attacks, but it does not change the general

exposure of a device. Proper authentication and au-

thorization also makes a huge difference in securing

a device. If a device’s manufacturer has chosen to im-

plement adequate security measures like authentica-

tion or encryption, then the level of concern will be

unchanged. However, these measures will affect pri-

vacy and safety scores, because proper security mech-

anisms will have an effect on the emergence of vul-

nerabilities.

We definitely need mandatory security analyses

for devices that may threaten human life. Our pro-

posed scores and levels of concern provide a black-

box view to medical devices. If manufacturers ana-

Security Scores for Medical Devices

539

lyze security properly, it will later have a positive ef-

fect on the number of vulnerabilities that we will get

to know. We will see positive effects in low values

for our privacy and safety scores. Threat analysis is

another activity that we need to evaluate security risks

posed to a device. Such analysis is important in order

to plan for countermeasures. A device manufacturer

should include such activities into the development of

the devices. The results will not be publicly available,

as it would provide valuable information to attackers.

We do not use such information to characterize med-

ical devices, but they will have a positive effect to

their security scores.

We have presented a numerical system that still

represents work in progress. As a next step, we plan

to perform a proof of concept. The fundamental prin-

ciple of design science research is that we acquire

knowledge of a design problem and its solution in the

creation and application of design artifacts (Hevner,

2007). The research outcome not only includes the

design artifact itself but also a clearly defined contri-

bution to scientific knowledge. Another next step is

to define rules of action, such that stakeholders have

defined process models as guidance for further action.

Further action can be manifold and depends on the

device. For example, if we have a safety score of nine

in a pacemaker, then one option is to remove the pace-

maker from the patient and replace it with another

model. A less expensive and less time-consuming al-

ternative is to provide future medical devices with an

option to cut off communication features. Whatever

the response to an increased risk of a device might be,

we should have predefined courses of action in order

to act quickly. The security scores described in this

paper are a first step in this direction.

6 CONCLUSIONS

Medical devices increasingly use wireless communi-

cation and Internet connections. Additionally, we see

an increased use of mobile medical applications in

connection with a plethora of medical sensors still to

come. We have introduced security scores in an effort

to increase the security awareness of all involved par-

ties and to provide a knowledge base that makes it

possible to make sound decisions in different security

situations. Sensitivity, impact, and exposure are static

properties of devices. They reflect whether a device

handles sensitive or safety-critical information and

how exposed it is to its environment. Vulnerability

and risk are dynamic. If they increase, we have to take

appropriate countermeasures, or the doors will stand

wide open for the misuse of sensitive medical data

and for malware and attacks that put human life in

danger.

We have not provided any information on how to

implement effective defense mechanisms. It is the

manufacturer’s task to pay due attention to the devel-

opment of secure devices. Our suggested scores can

provide information about how concerned we have to

be in general about security precautions of specific

devices and about security and safety risks at specific

points of time. The consequences may be manifold.

Manufacturers may fix problems or patients and hos-

pitals may decide to refrain from using these devices.

REFERENCES

Chunxiao, L., Raghunathan, A., Jha, N. K., 2011. Hijacking

an insulin pump: Security attacks and defenses for a di-

abetes therapy system. 13th IEEE International Confer-

ence on e-Health Networking Applications and Services

(Healthcom), pp 150-156. https://ieeexplore.ieee.org/

xpl/articleDetails.jsp?arnumber=6026732

FDA, 2005. Guidance for the Content of Premarket Sub-

missions for Software Contained in Medical Devices,

May 11, 2005.

http://www.fda.gov/MedicalDevices/DeviceRegulatio

nandGuidance/GuidanceDocuments/ucm089543.htm

FDA 2013. FDA Safety Communication: Cybersecurity for

Medical Devices and Hospital Networks. June.

http://www.fda.gov/MedicalDevices/Safety/Alertsand

Notices/ucm356423.htm

FDA, 2013b. Mobile Medical Applications – Guidance for

Industry and Food and Drug Administration Staff. Sept.

2013.

http://www.fda.gov/downloads/MedicalDevices/Devi

ceRegulationandGuidance/GuidanceDocuments/UCM

263366.pdf

FDA, 2014. Medical Devices – Classify Your Medical De-

vice. http://www.fda.gov/MedicalDevices/DeviceRegu

lationandGuidance/Overview/ClassifyYourDevice/de

fault.htm

FDA, 2015. Mobile Medical Applications – Guidance for

Industry and Food and Drug Administration Staff, Feb.

09. http://www.fda.gov/downloads/MedicalDevices/.../

UCM263366.pdf.

Fox News, 2010. Antivirus Program Goes Berserk, Freezes

PCs. April 22. http://www.foxnews.com/tech/2010/

04/22/antivirus-program-goes-berserk-freezes-pcs/

Hevner, A. R., 2007. A Three Cycle View of Design Sci-

ence Research, Scandinavian Journal of Information

Systems, Vol. 19: Issue 2, Article 4.

http://aisel.aisnet.org/sjis/vol19/iss2/4

Fu K. and Blum J., 2013. Controlling for cybersecurity risks

of medical device software, Communications of the

ACM, vol. 56, no. 10, p. 35.

Kaplan D., 2011. Black Hat: Insulin pumps can be hacked.

SC Magazine, August 04. http://www.scmagazine.com/

black-hat-insulin-pumps-can-be-hacked/article/209106

SmartMedDev 2016 - Special Session on Smart Medical Devices - From Lab to Clinical Practice

540

Kotz, D., Fu, K., Gunter, C., and Rubin, A., 2015. Security

for mobile and cloud frontiers in healthcare, Communi-

cations of the ACM, vol. 58, no. 8, pp. 21–23.

Kramer, D. B., Baker, M., Ransford, B., Molina-Markham,

A., Stewart, Q., Fu, K., Reynolds, M. R., 2012. Security

and Privacy Qualities of Medical Devices: An Analysis

of FDA Postmarket Surveillance. http://www.plosone.

org/article/info:doi/10.1371/journal.pone.0040200

McGraw, G., 2004. Software Security, IEEE Security &

Privacy, vol. 2, no. 2, pp. 80-83, March-April.

doi:10.1109/MSECP.2004.1281254

Kotz, D., 2011. A threat taxonomy for mHealth privacy,

Workshop on Networked Healthcare Technology

(NetHealth), January. http://ieeexplore.ieee.org/xpl/ar-

ticleDetails.jsp?arnumber=5716518

Paul, N., Kohno, T., Klonoff, D. C., 2011. A Review of the

Security of Insulin Pump Infusion Systems, Journal of

Diabetes Science and Technology, vol. 5, Issue 6.

https://www.ncbi.nlm.nih.gov/pmc/articles/PMC3262

727

Manadhata, P., 2008. An Attack Surface Metric, CMU-CS-

08-152. http://reports-archive.adm.cs.cmu.edu/anon/

2008/CMU-CS-08-152.pdf

MITRE. The MITRE Corporation: Common Vulnerabili-

ties and Exposures – The Standard for Information Se-

curity Vulnerability Names. https://cve.mitre.org

Ross, R. S., 2012. Guide for Conducting Risk Assessments,

NIST Special Publication 800-30 Revision 1.

http://csrc.nist.gov/publications/nistpubs/800-30-rev1/

sp800_30_r1.pdf

Sametinger, J., Rozenblit, J., Lysecky, R., and Ott, P., 2015.

Security Challenges for Medical Devices, Communica-

tions of the ACM, vol. 58, no. 4, pp. 74–82.

Smith, E., 2012. Types of Medical Equipment. HIVE

Health Media. January 22. http://www.hivehealthme

dia.com/types-medical-equipment/

Versel, N., 2013. West: Device interoperability with EHRs

could save $30B annually. Mobihealthnews.

http://mobihealthnews.com/21120/west-device-interop

erability-with-ehrs-could-save-30b-annually/

World Health Organization, 2003. Medical device regula-

tions: global overview and guiding principles, ISBN

92-4-154618-2. http://whqlibdoc.who.int/

publications/2003/9241546182.pdf

Security Scores for Medical Devices

541
