Exploiting Vehicles’ Reputation to Mitigate DoS Attack

Gianpiero Costantino, Fabio Martinelli and Ilaria Matteucci

Istituto di Informatica e Telematica, CNR, Via G. Moruzzi, 1, Pisa, Italy

Keywords:

Security and Safety in Automotive, Connected Vehicles, Reputation, DoS Attack.

Abstract:

Recently the convergence of safety and security needs in automotive systems is one of the main challenges

of the research community. However, the different nature of safety and security metrics suggests that no

individual assessment technique is sufﬁcient, in isolation, to validate large systems that are intended to be

both safe and secure. The introduction of new generation ICT systems into vehicles makes them potentially

vulnerable to security attacks that may impact on the safety of passengers, pedestrians, and vehicle itself.

Hence, entities involved in a communication have to be evaluated trustable by means of speciﬁc mechanisms

of the vehicle or infrastructure system. This work aims at proposing an algorithm for the calculation of

reputation of vehicles in a Vehicular Ad Hoc Network (VANET) based on the type and number of exchanged

messages. The ultimate goal is to mitigate the Denial of Service (DoS) attack in such kind of communication

by acting as a ﬁrewall with respect to not trustable vehicles. Indeed, the DoS is a security attack that affects

the availability of network bandwidth. This may have an impact on safety of drivers and vehicles since it may

prevent the communication and spread of important information for, e.g., human life.

1 INTRODUCTION

Nowadays, the more and more pervasive usage of

ICT in automotive ecosystem is raising the need to

consider security issues related to cars, trucks, and

motorbikes. In the last 5 years, both car manufac-

turers and academics have performed studies in the

ﬁeld of automotive cyber-security to identify a de-

tailed list of threats that can be exploited by attackers.

This research has provided a set of recommendations

to car manufacturers to overcome the found threats.

Based on inputs from the Automotive Cyber Security

Thought Leadership event (held in November 2014),

the Institution of Engineering and Technology (IET)

has been recently published a report (IET, The Insti-

tution of Engineering and Technology, 2014) on auto-

motive cyber-security issues. IET provides some rec-

ommendations to address such issues to ensure that

future connected vehicles be safe and more efﬁcient.

New technologies make vehicles connected and

users able to interact with own vehicles through mo-

bile devices. These new opportunities represent an

advantage in terms of connectivity, revenue, and

safety but they have also some drawbacks in terms

of security. The main issues are mostly related to

security CIA triad, i.e., Conﬁdentiality, Integrity, and

Availability. In automotive systems, Conﬁdentiality

is intended related to exchange of information be-

tween the user mobile device and the vehicle. The

exchanged data may be conﬁdential and must not be

stolen by an untrusted party. Integrity means that

shared data or information are not modiﬁed or altered

by another entity different from the source. In auto-

motive, this can be violated through applications able

to interact with the vehicle system. The same for the

information (requests, data, etc.) exchanged between

the mobile device and the connectivity system that

might be misinterpreted and cause failure in control

units. Thus, a hacker may use these vulnerabilities to

get internal data of the vehicle or try to acquire control

of parts of the car. Availability is a guarantee of reli-

able access to the information by authorized people.

In automotive systems, it is mostly related to com-

munication services that have to guarantee the correct

ﬂow of information, such as trafﬁc information, safe

alerts, and so on, among circulating vehicles.

In this paper we focus on vehicle-to-infrastructure

(V2X for short) and on vehicle-to-vehicle (V2V for

short) communications. Both of them are subjects

to several security attacks, and among others, one of

the most common is the attack on network availability

also referred as Denial of Service (DoS) attack (Raz-

zaque et al., 2013). The DoS attack is an attempt to

make a communication network resource unavailable

to its intended users, such as to temporarily or indef-

initely interrupt or suspend services of vehicles con-

Costantino, G., Martinelli, F. and Matteucci, I.

Exploiting Vehicles’ Reputation to Mitigate DoS Attack.

DOI: 10.5220/0005844500750082

In Proceedings of the International Workshop on domAin speciﬁc Model-based AppRoaches to vEriﬁcaTion and validaTiOn (AMARETTO 2016), pages 75-82

ISBN: 978-989-758-166-3

nected with other vehicles or with the infrastructure.

Moreover, DoS is a very common attack where the

attacker can overpower a vehicles resources or jam

the communication channel used by the Vehicular Ad

Hoc Networks (VANET) to bring down the VANET

itself or even cause an accident with a damage of

safety drivers.

We consider that both V2X and V2V communi-

cations mainly happen through a VANET, that is a

speciﬁc type of Mobile Ad Hoc Network (MANET)

providing communications between nearby vehicles

and roadside equipment. A MANET is a structure

composed only by wireless nodes, without any ﬁxed

devices, that is set up instantly, as soon as devices,

which do not even know each other, are available. A

MANET survives until the participants remain linked

together. Similarly, vehicles of a VANET are consid-

ered communication nodes able to belong to a self-

organized network without any prior knowledge of

the presence or identity of the others.

Starting from these considerations, we propose an

algorithm to calculate the reputation of vehicles while

they are circulating on road. Our algorithm is based

on the direct observation of the messages generated

and forwarded by vehicles. These pieces of informa-

tion are collected and sent to a central entity that is

able to establish the reputation of each vehicle. So,

established reputation values are sent back to the ve-

hicles to notify them about their current behaviours.

This approach helps vehicles to detect the occurrence

of an anomalous behaviour with respect to a possible

DoS attack, and intrinsically the presence of a ma-

licious entity in the network. Finally, our algorithm

tries to validate the communications by providing a

way for isolating the attacker.

The paper is organized as follows: Section 2 pro-

vides some background notions about Vehicle Ad

Hoc Network. Section 3 describes the reference sce-

nario we use in the paper to exemplify the proposed

approach. Section 4 introduces the technique used

to calculate the reputation of vehicles, to verify the

behaviour of a vehicle and, eventually, to isolate it

whether considered as malicious. Section 5 discusses

the related work on security issues in automotive

systems with a particular eye to security aspects of

VANET. Finally, Section 6 draws the conclusion and

proposes some possible for future work.

2 VEHICULAR AD HOC

NETWORKS IN A NUTSHELL

A modern vehicle can be considered as a network

of sensors/actuators on wheels. VANET is a special

kind of Mobile Ad-hoc Network (MANET) where

vehicles equipped with the technologies are the key

constituents. According to (Razzaque et al., 2013) a

VANET differs from a MANET in several aspects: i)

Large scale, potentially billion of vehicles, ii) Fleet-

ing contact with other vehicles, iii) Nodes not as con-

strained in terms of energy, storage, and computation,

iv) Higher mobility, and v) Privacy requirements.

One of the main objective of a VANET is to al-

low communication between vehicles on the roads

and their environments with the aim of improving the

safety of drivers. To this aim, each vehicle belong-

ing to a VANET needs to have an OBU (On-Board

Unit), which is a communication device mounted on

vehicles, and a Wireless Sensor Network (WSN) sup-

ported roadside unit (RSU).

By using OBUs, vehicles can be connected with

other vehicles as well as with the roadside unit. The

RSU is also connected with the backbone network,

e.g., the roadside infrastructure, in such a way that

it can communicate with many other network appli-

cations and services, including the Internet access,

which can be provided to the vehicles (Qian and

Moayeri, 2008).

To improve the functionalities and capabilities

of VANET, multiple ad-hoc networking technologies

have been integrated on them, such as WiFi IEEE

802.11p, WAVE IEEE 1609, WiMAX IEEE 802.16,

Bluetooth, IRA, and ZigBee. These technologies

make more easy, accurate, effective, and simple all

communication between vehicles. Furthermore, the

IEEE 1609 (P1609.2) explicitly deﬁnes security as-

pects such as secure message formatting, processing,

and message exchange to put in evidence their impact

on vehicle safety aspects.

VANETs are expected to implement a variety of

wireless technologies such as Dedicated Short Range

Communications (DSRC). Other candidate wireless

technologies are Cellular, Satellite, and WiMAX.

Thus, VANETs are envisioned as the most important

entity of the Intelligent Transportation Systems (ITS).

The main security issues of V2X communica-

tion mainly concerns security issues peculiar of WiFi

connection. Indeed, in (Chou et al., 2009) the au-

thors state that, even though V2V and V2X are

both wireless mobile networks, they are different and

participate in vehicular network with different com-

munication modalities. For that reason, they pro-

pose WiMAX instead of WiFi for V2X infrastruc-

ture. They focus on a static setting in urban environ-

ment and describe some measurements by showing

that WiMAX technology provides a longer communi-

cation range and, for applications like ﬁle download-

ing, one might want to use a larger frame size to have

AMARETTO 2016 - International Workshop on domAin speciﬁc Model-based AppRoaches to vEriﬁcaTion and validaTiOn

a better throughput. The setting of frame size has a

strong impact on performance of WiMAX.

Hereafter we focus on the DoS security attack

within V2V communications, how it can impact on

safety aspects, and we provide a possible solution for

mitigating the attack. As we will see in the next sec-

tion, our approach works at application level so it is

independent from the used physical technology.

3 REFERENCE SCENARIO

As reference scenario, we consider a vehicular net-

work in which all vehicles are connected with the

roadside infrastructure exploiting the WiMAX tech-

nology. Vehicles communicate with each other by

exploiting the OBU technology. Like any other net-

works, also these communications are affected upon

the Denial of Service (DoS) attack. The DoS is an ac-

tive and malicious attack in nature. For instance, if a

malicious adversary wants to create a massive pileup

on the highway, he could exploit an accident and then

use a DoS attack to prevent the dissemination of warn-

ings to other drivers.

The reference scenario is the one graphically de-

picted in Figure 1. Let us consider two vehicles both

circulating on a sector of a roadway. Let us also as-

sume the presence of a trafﬁc jam some miles ahead.

Vehicles belonging to the VANET of that sector of the

roadway start to communicate each other to spread the

information as much as possible. Receiving this kind

of information on time increases the safety of drivers.

Indeed, according to (Wang and Thompson, 1997),

about 60% roadway collisions could be avoided if the

driver was provided warning at least one-half second

prior to a collision.

3.1 Modelling the Vehicles’ Behaviour

Vehicles that travel in a distributed environment can

assume several behaviours that may depend on differ-

ent reasons. A vehicle may decide to be fully collab-

orative and to constantly participate in the V2V com-

munications. On the other side, a vehicle can decide

to assume a dishonest behaviour and to deny V2V

communications by dropping messages it receives,

Black hole attack (Deng et al., 2002).

According to the BUG threat model (Bella et al.,

2005), an attacker can assume three different states of

behaviour that we recast when the goal is reputation:

• Bad: when the vehicle is essentially selﬁsh, and

damages the network intentionally by neglecting

or limiting particular communications;

• Ugly: when the vehicle essentially assumes an op-

portunist behaviour according to its cost/beneﬁt

analysis of the context.

• Good: when the vehicle uses its resources to pro-

vide V2V communications nodes without any di-

rect interest.

4 UNDERSTANDING THE

VEHICLES’ BEHAVIOUR

In this section we present our technique to calculate

the reputation of vehicles, and to isolate those one that

are suspected to be attackers. We consider the reputa-

tion as main information to understand the behaviour

of vehicles, and more speciﬁcally, it is used as param-

eter to identify malicious vehicles. Indeed, reputation

is calculate in accordance to a principle of collabora-

tion: vehicles in a VANET work in an open net and

their collaboration is the sole mean to allow commu-

nications and the survival of the VANET itself (Bella

et al., 2008).

In the algorithm we propose, vehicles are able to

observe the behaviour of other vehicles that they meet

during the journey. The algorithm is composed of

four steps: as a ﬁrst step, each vehicle performs a di-

rect observation of neighbours and evaluates their be-

haviour by comparing the number of messages they

generate and forward. Indeed, a trustworthy vehicles

has a collaborative behaviour and forwards messages

as much as possible to allow the information is cir-

culated and distributed uniformly over the network.

Then (second step), at ﬁxed time, each vehicle trans-

mits the collected values to a central server belonging

to the roadside infrastructure by using V2X commu-

nications. In particular, a central server of the road-

side infrastructure acts as a collector of all local ob-

servations done by vehicles. As third step, the central

server calculates a single value of reputation for each

vehicle that is travelling in the considered roadway.

Finally, in the fourth step, the complete set of repu-

tation values is sent to all vehicles that will receive

updated reputation values of other vehicles they are

able to communicate with.

The main goal of the proposed algorithm is to pro-

vide a method of vehicles to rapidly identify and even-

tually isolate malicious vehicle. It is designed to de-

tect and overcome DoS attacks. Consequently, it al-

lows drivers to improve trafﬁc safety and road efﬁ-

ciency. Furthermore, by guaranteeing the availabil-

ity of communications network and road efﬁciency, it

leads to a reduction of pollution, thus positively im-

pacting on the environment.

Exploiting Vehicles’ Reputation to Mitigate DoS Attack

Roadside

Infrastructure

Figure 1: A graphical representation of the reference scenario.

4.1 Direct Observation

Figure 2: A graphical representation of V2V communica-

tions.

In Figure 2 we show an example of communications

among three vehicles. Vehicle A generates a message

and sends it to vehicle B. When, B receives the mes-

sage, it propagates the message to C and so on. Ba-

sically, according to this propagation mechanism, B

and C vehicles are able to locate the vehicle that gen-

erated the message by observing the packet structure.

In particular, B understands that A generated the mes-

sage, and C understands that the message was only

forwarded by B but not generated.

We call Direct Observation the phase in which a

vehicle calculates the number of packets generated

and forwarded by close vehicles. Vehicles are con-

sidered close when the distance between them is only

a single hop. So, when a vehicle receives a message, it

checks whether such a message has been generated or

forwarded by the close car. This information is stored

into a local table that we call Vehicles Local Observa-

tion (VLO).

Table 1: Example of Vehicles Local Observation Table.

B 19 5

G 5 16

... ... ...

P 12 40

An example of VLO calculated by C is illustrated

in the Table 1, where, V

says that the table belongs

to vehicle C, while G

and F

show the number of

Generated and Forwarded messages of met vehicles,

such us B, G, P, and others. Note that each vehicle

can be uniquely identiﬁed by the other, for instance,

through its license plate.

4.2 Collecting the VLO Tables

Once VLO tables are populated and updated, each

vehicle sends its VLO to the central server that be-

longs to the motorway infrastructure. Such commu-

nications exploit V2X connections. We assume that,

at ﬁxed time, for instance every 5 minutes

, vehicles

send their VLO tables to the server, which collects

them. We point out that communications with the

server are not performed all at the same time, but they

depend on the moment when a vehicles entered in the

roadway sector under observation.

VLR

Server

V2X

Figure 3: Sending VLOs to the central server.

In Figure 3 we pictorially show the phase in which

cars share their VLO with the server. When, the server

receives VLOs, it populates its table that contains all

and F

aggregated for each vehicle. We call this

table Vehicles Global Observation (VGO), and in Ta-

ble 2, we illustrate the VGO that contains the aggre-

gated values of G

and F

of each vehicle circulating

on the considered sector.

The strategy to populate the VGO table works in

the following way. If the server receives a VLO that

contains a new vehicle identity, i.e., information about

a vehicle that is not already present in the VGO, the

server just creates a new entry in the table and ap-

pends its values of G

and F

. On the contrary, if

the server has already values of G

and F

for certain

Note that this is an approximate value that should be

ﬁxed only after performing accurate simulations.

AMARETTO 2016 - International Workshop on domAin speciﬁc Model-based AppRoaches to vEriﬁcaTion and validaTiOn

Table 2: Example of Vehicles Global Observation Table.

V G

B 1509 150

G 501 1654

... ... ...

P 350 467

vehicles contained in the VLO, then it updates those

values in the following way:

new

= G

old

+ G

rcv

(1)

where G

old

represents the number of messages

generated stored in the VGO for the vehicle j, G

rcv

represents the number of messages generated stored

into the VLO for the vehicle j, and G

new

is the new

value for the number of messages generated by j.

The same approach is also applied to calculate the

aggregated values of messages for vehicle j to store

in the VGO. So, the formula is the following:

new

= F

old

+ F

rcv

(2)

where F

old

is the value of forwarded messages

stored in the VGO, F

rcv

is the number of forwarded

messages calculated locally, and F

new

represents the

aggregation of the previous two values.

4.3 Vehicles’ Reputation

As we presented above, the VGO contains an overall

observation of the behaviour of each vehicle travel-

ling in the roadway. Such a behaviour expresses the

reputation taken by the vehicle up to the moment it

has been established. According to the principle of

collaboration, the reputation of each vehicle is calcu-

lated as the ratio of F

and F

+ G

. The formula that

calculates the reputation of a generic vehicle j is:

Rep

+ G

(3)

Let F

and G

the aggregated values of forwarded

and generated messages of the vehicle j stored in the

VGO. It is worth noting that the result of Equation 3

is normalized to obtain value in the interval between 0

and 1. Thus, the structure of the VGO table is updated

as we show in Table 3:

The VGO table with the reputation value of each

car basically shows the behaviour taken by cars in the

motorway. More speciﬁcally, we say that a Rep

≤

0.3 is an indication of an anomalous and bad be-

haviour, for instance a DoS attack. On the contrary,

Table 3: Vehicles Global Observation Table with Reputa-

tion Values.

V G

Rep.

B 1509 150 0.09

G 501 1654 0.77

... ... ... ...

P 350 467 0.57

Rep

≥ 0.7 indicates a collaborative and also good be-

haviour.

Note that, even thought the reputation is calcu-

lated considering both newer and older message, our

reputation algorithm does not imply that a malicious

vehicle will be always tagged as malicious. In fact,

by reverting to a collaborative behaviour, that vehicle

will improve its reputation.

Remark. The proposed calculation is intended to

not be optimal in general. Our aim is to mitigate

the DoS attack by monitoring the number of mes-

sages that are input on the considered network. The

proposed algorithm can be reﬁned to better estimate

the reputation of a vehicle. So, it may exploit ad-

ditional parameters that may help to mitigate secu-

rity issues related to data-integrity and privacy of ex-

changed messages.

4.4 Broadcating the VGO Table

In this last step, the central server is in charge of noti-

fying the vehicles with the reputation values available

in the VGO. Here, vehicles receive the VGO and use

the reputation values as indication of the behaviour of

the cars.

Figure 4: Isolation strategy against DoS attack.

In Figure 4 we show an attempt of DoS attack per-

formed by vehicle B. This car continuously generates

messages that may ﬂood the V2V communications.

Nevertheless, vehicles E and F already know the be-

haviour of B because they checked the VGO table.

So, when E and F receive messages from B, they may

decide to isolate B by dropping the messages gener-

ated by it. This approach is close to that one applied

Exploiting Vehicles’ Reputation to Mitigate DoS Attack

by ﬁrewalls when they detect a DoS or bruteforce at-

tack. In the same fashion, here vehicles may decide

to isolate the “spammer vehicle”.

However, it may happen that the vehicle, which

is considered an attacker, may also generate an alarm

message that should not be dropped by its neighbours.

In this situation, we foresee that vehicles close to the

attacker do not directly drop the packet, but before

they check the content, for instance a bit indicating

the particular type of message, i.e., alarm. However,

this way to manage alarm situations may suggest the

attacker to ﬂood the communications with alarm bit

set to 1. So, to avoid this scenario, we suggest to

accept only a maximum number of alarm messages

within a time-window, for instance 5msg/hour

5 RELATED WORK

Concerning security aspects in automotive design, the

authors of (Sagstetter et al., 2013) outline the upcom-

ing security challenges in automotive architecture de-

sign and discuss the application of a model-based de-

sign approach. This analysis was done in combina-

tion with formalized veriﬁcation methods that aimed

at checking and avoiding vulnerabilities already dur-

ing the design process of a future automotive archi-

tectures based on Ethernet/IP.

The work in (Studnia et al., 2013) provides an

overview of the protection mechanisms that could be

adopted as countermeasures to identiﬁed threats.

Some solutions for automotive have been also

developed. For instance, European projects such

as SeVeCOM (Leinm

uller et al., 2006; Wieder-

sheim et al., 2009; Papadimitratos et al., 2008),

PRESERVE (https://www.preserve-project.eu/), and

EVITA (http://www.evita-project.org/) aimed at de-

signing secure communication architectures for inter-

nal or inter-vehicular communications. In particular,

the SeVeCOM EU project (Leinm

uller et al., 2006;

Wiedersheim et al., 2009) developed a modular sys-

tem supporting security and privacy features in V2V

Ad Hoc Networks. This solution describes an archi-

tecture for integrating into the network stack a sys-

tem for generating and verifying signatures based on

PKI with short term key and certiﬁcates in order to

guarantee the authenticity of communication partners.

It is important to note that the SeVeCom system has

been integrated into the network stack by inserting In-

ter Layer Proxies into the network stack to intercept

communication messages.

As we have already state above, also this value can be

further improved after performing simulations.

Many protection mechanisms and frameworks

have been developed to enforce security properties in

the VANET. For instance, there are generic security

mechanisms not customized for automotive but that

work for any mobile ad hoc network. Some solutions

for automotive have been also developed. Indeed,

the US Dept. of Transport identiﬁed several applica-

tion scenario where VANETs can be useful (National

Highway Trafﬁc Safety Administration and others,

2005). These applications can be categorized in safety

and non-safety. Basically, the non safety are related to

trafﬁc, congestion and so on. This points out how se-

curing VANETs is important. For this reason in (Raz-

zaque et al., 2013), the authors provide a possible list

of all possible adversaries in any security system and

present also several security solutions able to cope

with different issues. It is worth noticing that the main

security issues of V2X communication mainly con-

cerns security issues peculiar of WiFi connection.

The authors of (Malip et al., 2014), propose a pro-

tocol for securing communication in VANETs which

exploits “certiﬁcate-less” signature. This protocol

uses a reputation server, which is responsible for the

distribution and management of identities and crypto-

graphic credentials of vehicles. The main purpose is

to guarantee the reliability of messages. The solution

we propose is also based on a reputation system but

with the aim to deal with issues related to the avail-

ability of the VANET and its services for drivers.

Further approaches listed in (Chen et al., 2011) do

not require authentication to guarantee the authentic-

ity of a broadcast announcement. These approaches

take into account the number of received messages

with the same warning; if this number is greater than

a threshold, the announce is considered true. The se-

curity aspects they mainly consider are reliability of

messages, privacy, and auditability. They do not care

about availability of the VANET. Both solutions are

based on an algorithm that takes as input the num-

ber of exchanged messages but our algorithm, being

focused on DoS attack, considers also the source of

the messages as input information and calculates the

reputation of a vehicle.

In (Raya and Hubaux, 2005), the authors sur-

vey about security issues in VANET and sketches

some possible solutions for some of them. For in-

stance, in order to mitigate the DoS attacks, they

propose the capability of switching between different

channels or even communication technologies (e.g.,

DSRC, UTRA-TDD, or even Bluetooth for very short

ranges), if they are available, when one of them is

brought down. However, this could be not feasible

in case vehicles have not all the necessary technolo-

gies. The approach we propose overcomes this issue

AMARETTO 2016 - International Workshop on domAin speciﬁc Model-based AppRoaches to vEriﬁcaTion and validaTiOn

by identifying the possible attacker and dropping his

messages. In this way, the algorithm works as a ﬁre-

wall by isolating the possible malicious vehicle.

The authors of (Leinm

uller et al., 2010) present

a solution to protect VANET communications from

roadside attackers. In this scenario, the attacker is

someone located next to a road and it is a vehicle that

generates messages that are not distinguishable from

the other cars. In this way, the attacker is able to send

fake messages on the net to inﬂuence the behaviour of

drivers on the road. Even though the problem we face

is similar, we focus on internal attackers, i.e., vehicles

that send too much messages to reduce the availability

of the VANET. Furthermore, the approach they pro-

posed in based on the distance of the attacker while

we propose an algorithm based on reputation of a ve-

hicle.

Being more general, literature about reputation

system in peer-to-peer network can be also consid-

ered. As an example, the work in (Stakhanova et al.,

2004) presents a fully decentralized approach to com-

pute the reputation of peers based on the trafﬁc be-

tween a node and its peers, independently of these

peers willingness to cooperate in calculation of their

reputation. A part form the different network commu-

nication, the main difference between this work and

the one we propose is the ﬁnal goal: in (Stakhanova

et al., 2004) they want to ﬁnd the optimal peers for the

communication, while we want to identify the possi-

ble attacker and prevent it to badly affect the commu-

nication among all the other nodes in the VANET.

6 CONCLUSION AND FUTURE

WORK

Automotive systems present many security challenges

that depend on several factors such as, the heterogene-

ity of embedded systems and communication tech-

nologies to make vehicle connected. In this paper

we focus on Vehicle to Vehicle communication and,

in particular, we provide a reputation based algorithm

able to evaluate whether a vehicle behaves as an at-

tacker. As a result we are able to verify if a DoS attack

happens and mitigate it to preserve the availability of

vehicle communications for safety communication.

As ongoing work, we are simulating the perfor-

mance of the proposed algorithm to evaluate its efﬁ-

ciency and feasibility in the veriﬁcation and valida-

tion of both V2V and V2X communications. In the

future, we aim at enhancing our proposal to overcome

other security issues, such as data integrity and con-

ﬁdentiality. We will reﬁne our algorithm to prevent

malicious vehicles, for instance, from sharing wrong

identity information and creating messages that look

like forwarded messages but are actually newly cre-

ated ones. Furthermore, we would like to consider

the possibility that a malicious vehicle tries to attack

the infrastructure by, for instance, uploading fake ob-

servation tables to the server to arbitrarily change the

reputation scores The ultimate goal will be the deeply

analysis of the impact of the proposed solution on

safety aspects, such as, how much we are able to im-

prove the trafﬁc on a road and to reduce trafﬁc jam.

ACKNOWLEDGEMENT

Work partially supported by the H2020-MSCA-ITN-

2015-NeCS 675320.

REFERENCES

Bella, G., Bistarelli, S., and Massacci, F. (2005). Retalia-

tion: Can we live with ﬂaws? In WORKSHOP ON

INFORMATION SECURITY ASSURANCE AND SE-

CURITY.

Bella, G., Costantino, G., and Riccobene, S. (2008). Man-

aging reputation over manets. In Rak, M., Abra-

ham, A., and Casola, V., editors, Proccedings of

the Fourth International Conference on Information

Assurance and Security, IAS 2008, September 8-10,

2008, Napoli, Italy, pages 255–260. IEEE Computer

Society.

Chen, L., Ng, S.-L., and Wang, G. (2011). Threshold

anonymous announcement in vanets. Selected Areas

in Communications, IEEE Journal on, 29(3):605–615.

Chou, C.-M., Li, C.-Y., Chien, W.-M., and Lan, K.-

c. (2009). A feasibility study on vehicle-to-

infrastructure communication: Wiﬁ vs. wimax. In

Mobile Data Management: Systems, Services and

Middleware, 2009. MDM’09. Tenth International

Conference on, pages 397–398. IEEE.

Deng, H., Li, W., and Agrawal, D. (2002). Routing security

in wireless ad hoc networks. Communications Maga-

zine, IEEE, 40(10):70–75.

IET, The Institution of Engineering and Technology (2014).

Automotive Cyber Security: An IET/KTN Thought

Leadership Review of risk perspective for connected

vehicles.

Leinm

uller, T., Buttyan, L., Hubaux, J.-P., Kargl, F., Kroh,

R., Papadimitratos, P., Raya, M., and Schoch, E.

(2006). Sevecom-secure vehicle communication. In

IST Mobile and Wireless Communication Summit,

number LCA-POSTER-2008-005.

Leinm

uller, T., Schmidt, R. K., and Held, A. (2010). Co-

operative position veriﬁcation-defending against road-

side attackers 2.0. In Proceedings of 17th ITS World

Congress.

Malip, A., Ng, S.-L., and Li, Q. (2014). A certiﬁcate-

less anonymous authenticated announcement scheme

Exploiting Vehicles’ Reputation to Mitigate DoS Attack

in vehicular ad hoc networks. Security and Communi-

cation Networks, 7(3):588–601.

National Highway Trafﬁc Safety Administration and others

(2005). Vehicle safety communications project task 3

ﬁnal report: Identify intelligent vehicle safety appli-

cations enabled by dsrc. DOT HS S09 S, 59.

Papadimitratos, P., Buttyan, L., Holczer, T. S., Schoch, E.,

Freudiger, J., Raya, M., Ma, Z., Kargl, F., Kung, A.,

and Hubaux, J.-P. (2008). Secure vehicular communi-

cation systems: design and architecture. Communica-

tions Magazine, IEEE, 46(11):100–109.

Qian, Y. and Moayeri, N. (2008). Design of secure and

application-oriented vanets. In Vehicular Technol-

ogy Conference, 2008. VTC Spring 2008. IEEE, pages

2794–2799. IEEE.

Raya, M. and Hubaux, J.-P. (2005). The security of vehic-

ular ad hoc networks. In Proceedings of the 3rd ACM

workshop on Security of ad hoc and sensor networks,

pages 11–21. ACM.

Razzaque, M., Salehi, A., and Cheraghi, S. M. (2013). Se-

curity and privacy in vehicular ad-hoc networks: sur-

vey and the road ahead. In Wireless Networks and

Security, pages 107–132. Springer.

Sagstetter, F., Lukasiewycz, M., Steinhorst, S., Wolf,

M., Bouard, A., Harris, W. R., Jha, S., Peyrin, T.,

Poschmann, A., and Chakraborty, S. (2013). Security

challenges in automotive hardware/software architec-

ture design. In Proceedings of the Conference on De-

sign, Automation and Test in Europe, pages 458–463.

EDA Consortium.

Stakhanova, N., Ferrero, S., Wong, J. S., and Cai, Y. (2004).

A reputation-based trust management in peer-to-peer

network systems. In Bader, D. A. and Khokhar, A. A.,

editors, Proceedings of the ISCA 17th International

Conference on Parallel and Distributed Computing

Systems, September 15-17, 2004, The Canterbury Ho-

tel, San Francisco, California, USA, pages 510–515.

ISCA.

Studnia, I., Nicomette, V., Alata, E., Deswarte, Y.,

aniche, M., and Laarouchi, Y. (2013). Survey on

security threats and protection mechanisms in embed-

ded automotive networks. In Dependable Systems

and Networks Workshop (DSN-W), 2013 43rd Annual

IEEE/IFIP Conference on, pages 1–12. IEEE.

Wang, C. and Thompson, J. (1997). Apparatus and method

for motion detection and tracking of objects in a

region for collision avoidance utilizing a real-time

adaptive probabilistic neural network. US Patent

5,613,039.

Wiedersheim, B., Sall, M., and Reinhard, G. (2009).

Sevecom—security and privacy in car2car ad hoc net-

works. In Intelligent Transport Systems Telecommuni-

cations,(ITST), 2009 9th International Conference on,

pages 658–661. IEEE.

AMARETTO 2016 - International Workshop on domAin speciﬁc Model-based AppRoaches to vEriﬁcaTion and validaTiOn
