Mutating OWLs: Semantic Mutation Testing for Ontologies

Cesare Bartolini

Interdisciplinary Centre for Security, Reliability and Trust (SnT), Universit

e du Luxembourg, Esch-sur-Alzette, Luxembourg

Keywords:

Mutation Testing, Ontology, OWL, Mutant Generation.

Abstract:

Ontologies are an essential component of semantic knowledge bases and applications, and nowadays they are

used in a plethora of domains. Despite the maturity of ontology languages, support tools and engineering

techniques, the testing and validation of ontologies is a ﬁeld which still lacks consolidated approaches and

tools. This paper attempts at partly bridging that gap, taking a ﬁrst step towards the extension of mutation

testing techniques to ontologies expressed in a widely-used format. Mutation testing techniques, revisited

in the light of the peculiar features of the ontology language and structure, can help in the engineering and

reﬁnement of ontologies and software based on them.

1 INTRODUCTION

The use of semantics in information technology is

greatly enhancing the expressiveness of knowledge

bases, especially with respect to information repre-

sentation and retrieval. Information is classiﬁed ac-

cording to domain-speciﬁc structures which describe

the concepts and the relations between them, and this

organization allows an efﬁcient access to such infor-

mation. Cross-domain organization is also made pos-

sible through the use of formal languages to describe

the domains. Nowadays, knowledge bases structured

according to description logic (Quillian, 1967) are

popular, and they can also be generated using Natu-

ral Language Processing (NLP) techniques to classify

unstructured documents.

Semantic knowledge is a wide ﬁeld of research

and application, and it is based on a multi-layered

framework of components and technologies. How-

ever, at the very basic level, there is the need to de-

scribe the domains. This result is achieved by means

of ontologies. Ontologies are a general concept to de-

note the deﬁnition of a domain, describing it at vari-

ous level of abstraction.

Of course, to be used in computer systems, on-

tologies need to be described according to some for-

mal language. Early attempts at deﬁning a language

to structure knowledge resulted in the Resource De-

scription Framework (RDF) language (World Wide

Web Consortium (W3C), 2014a). However, the pur-

pose of RDF is mainly to describe resources by means

of metadata, and it is too low level to provide an efﬁ-

cient means of describing an ontology. For that pur-

pose, the Web Ontology Language (OWL) speciﬁca-

tion (World Wide Web Consortium (W3C), 2012) has

been deﬁned.

OWL, that was developed starting from another

ontology language (Antoniou and van Harmelen,

2004) called DAML+OIL (Horrocks, 2002), is a fam-

ily of abstract languages which are expressed in sev-

eral different syntaxes, some of which are based on

eXtensible Markup Language (XML). The primary

syntax is RDF/XML, which easily maps onto RDF

concepts and integrates with other XML languages.

It is widely known that there is no “right” way of

deﬁning an ontology. Its deﬁnition really depends on

the domain, the desired level of abstraction, the pur-

pose for which the ontology is intended, and a number

of choices by the developer. In other words, the same

domain could be represented by several totally differ-

ent ontologies, which would result in different struc-

tures of the respective knowledge bases (and conse-

quently, with different results when classifying and

querying information). However, for ontology-based

applications to be integrated, it is necessary that they

are based on the same ontology.

Ontologies have a number of uses, primarily that

of describing some domain of knowledge from a spe-

ciﬁc perspective. In this sense, they act much like a

vocabulary, similarly to a database. They have found

their place as the basis of knowledge representation

in many application ﬁelds, from web searches to the

medical and legal domains (Horrocks, 2013).

Ontologies are also used for decision sup-

port (Rospocher and Seraﬁni, 2013), therefore it is

important that they are as complete as possible (within

Bartolini, C.

Mutating OWLs: Semantic Mutation Testing for Ontologies.

DOI: 10.5220/0005844600430053

In Proceedings of the International Workshop on domAin speciﬁc Model-based AppRoaches to vEriﬁcaTion and validaTiOn (AMARETTO 2016), pages 43-53

ISBN: 978-989-758-166-3

their domain and purpose), and also that they do not

contain errors. Previous experiences (Kershenbaum

et al., 2006) have highlighted the risks of using an in-

correct ontology as a structure for a knowledge base.

However, despite the acknowledged importance of

the correctness of ontologies, few methodologies and

tools exist for the testing and validation of ontologies.

This paper aims at partly ﬁlling this void by

proposing a mutation testing methodology for OWL

ontologies. Mutation testing is a well-known testing

method that assesses the validity of a test suite by gen-

erating mutants, i.e., incorrect versions of the Sys-

tem Under Test (SUT), by introducing single errors

in the trustworthy version. The ontology-based soft-

ware could then be linked to the mutants generated in

this way, and run against the test suite. The mutants

thus killed can provide important information about

the ontology and the program using it, including cov-

erage details and fault detection.

The paper is organized as follows. Section 2 pro-

vides a survey of existing literature in ontology test-

ing and mutation testing. Section 3 offers a high-level

description of mutation testing. Section 3.1 describes

the proposed methodology, explaining the various op-

erators used for the mutation of an OWL ontology.

It also contains a high-level description of the imple-

mentation of the mutation tool. Section 4 shows the

methodology in action, applying the mutation oper-

ators to various ontologies in different domains. Fi-

nally, Section 5 summarizes the results and envisions

some directions for future research.

2 RELATED WORK

Although knowledge bases and semantic applications

are a very consolidated domain nowadays, it appears

that there has been little attention to the validation of

ontologies (Blomqvist et al., 2012).

The World Wide Web Consortium (W3C) pro-

vides a set of test cases for evaluating the OWL on-

tology from a structural point of vies (World Wide

Web Consortium (W3C), 2004b). (Wang et al., 2005)

deﬁnes an algorithm to “debug” ontologies in search

of inconsistent classes. (Garc

ıa-Ramos et al., 2009)

offer a means of ontology validation through user-

deﬁned test cases, whereas (McGuinness et al., 2000)

deﬁnes an approach to merge large ontologies and

ﬁnd inconsistencies.

A lot of research addresses metrics and

benchmarks for ontologies. The work proposed

by (Gangemi et al., 2006) deﬁnes some measures for

assessing an ontology, and evaluates these measures

by means of a meta-ontology against which the

ontology under validation is compared. This work

does not seem to address the semantic correctness of

the ontology but mainly its structure and engineering

methodology. A similar approach, but with a greater

attention to semantics, is proposed by (Burton-Jones

et al., 2005). (Ma et al., 2006) deﬁnes a benchmark

for the analysis of ontologies based on two different

semantics, OWL Lite and OWL DL.

In (Blomqvist et al., 2012), the authors propose

a methodology and tool for testing an ontology. The

methodology addresses three main perspectives: veri-

ﬁcation of the Competency Questions (CQs) to which

the ontology is supposed to provide an answer, veri-

ﬁcation of the inferences by means of an OWL rea-

soner, and provocation of errors. The last perspective

differs signiﬁcantly from the current work because it

does not modify the ontology structure, but rather in-

troduces test data that are inconsistent with the ontol-

ogy.

An interesting approach is described in (Poveda-

Villal

on et al., 2012). The authors have built a testing

tool which tries to search for potential pitfalls in on-

tology development. The list pitfalls has been intro-

duced by the authors in (Poveda-Villal

on et al., 2010).

Although different from the idea of introducing er-

rors in the ontology, their work can provide interest-

ing suggestions for the deﬁnition of mutation opera-

tors.

An approach that combines ontology evaluation

with software engineering techniques is described

by (Denny Vrande

c, 2006), which introduces a pro-

posal to adapt unit testing to OWL ontologies. In the

past, several tools have been developed for ontology

unit testing, although it does not appear to be a main-

stream testing approach for ontologies. Another in-

teresting approach is presented in (Granitzer et al.,

2007): instances are generated from an ontology, and

hypotheses are formulates on these instances. The

validation of the generated hypotheses is then fed as

an input to reﬁne the ontology.

Some previous work concerning mutation testing

in the OWL language can be found in (Lee et al.,

2008). The methodology does not apply to the gen-

eral ontology language OWL, but rather to a speciﬁc

ontology called OWL-S (World Wide Web Consor-

tium (W3C), 2004a) which can be used as a seman-

tic descriptor web services, and it applies mutation to

classes, conditions, control ﬂows and data ﬂows. The

purpose of that paper is not to improve an ontology

and its related test suite, but rather to detect errors in

the web service speciﬁcation. However, some of the

concepts introduced in that work are similar to those

introduced in the current work.

AMARETTO 2016 - International Workshop on domAin speciﬁc Model-based AppRoaches to vEriﬁcaTion and validaTiOn

3 MUTATION TESTING

Mutation testing is a testing technique originally pro-

posed in (DeMillo et al., 1978; Hamlet, 1977), al-

though allegedly the initial idea can be traced back to

a few years earlier (Lipton, 1971). It is classiﬁed ei-

ther among the syntax-based testing techniques (Am-

mann and Offutt, 2008), or among the error-based or

fault-based testing techniques (Howden, 1982; Jia and

Harman, 2011). It is normally, but not exclusively,

meant for unit testing (Offutt, 1994).

In its essence, it is a methodology in which small

parts of a software code are changed. Its main pur-

pose is not to test the SUT proper, but the quality of

its test suite. However, it has an indirect beneﬁt on the

SUT, because the detection of faults in the test suite

can often also lead to detecting errors in the SUT.

According to the description provided by (Am-

mann and Offutt, 2008), mutation is carried out by ap-

plying a set of mutation operators to a ground string.

The ground string is expressed in the grammar, and

a mutation operator is “[a] rule that speciﬁes syntac-

tic variations of strings generated from a grammar”.

These operators can also be applied directly to the

grammar if no ground string exists. Mutation can be

used to generate both invalid strings and strings that

are valid but different from the ground string. In both

cases, the strings thus generated are called mutants.

The mutants generated from the SUT are then ex-

ecuted on the test suite, and the test results are com-

pared against those of the original code. Those mu-

tants which behave differently with respect to the test

suite are killed by the test suite. An ideal test suite

would kill n out of n generated mutants. The whole

process is generally automated by means of batch

scripts, because the generation of a high number of

mutants and the execution of the test suite on each is

a complex and tedious process which is well-suited

for automatization. Mutation can be also carried out

by introducing simpliﬁcations that reduce the number

of mutants (Offutt and Untch, 2001; Bartolini et al.,

2008) to lower the complexity of the testing process.

Mutation testing has generally been applied to

software code, particularly to Java (Ma et al., 2005;

Ma et al., 2005). Previous research (Offutt et al.,

1996; Ammann and Offutt, 2008) has identiﬁed a set

of operators for mutation.

Traditional mutation testing operates at the syn-

tax level, by introducing errors in the code. However,

semantic mutation testing has also been deﬁned (Of-

futt and Hayes, 1996; Mottu et al., 2006; Clark et al.,

2010), in which mutation operators affect the seman-

tics of the code. In other words, the code is still

syntactically correct, but its functionality is different

from the intended one.

3.1 Mutation Testing Applied to OWL

To apply the mutation testing methodology to an on-

tology, some premises are in order.

First off, the mutation operators will be applied to

the ontology. However, the testing can be carried out

in two different ways: either by viewing the ontology

as the SUT, independently of what it is used for; or

when the SUT is the knowledge base or software that

relies upon the ontology. Choosing either perspective

has signiﬁcant consequences in the testing and the test

suite that is used.

The mutation proposed in this paper is a kind of

semantic mutation. The syntax of an ontology is man-

aged satisfactorily by the various parsers and editors

available, so unless the SUT is a new OWL editor or

parser there would be little need for a syntactic mu-

tation testing. What is signiﬁcantly more interesting

is the evaluation of the ontology deﬁnition. Addition-

ally, using OWL as the underlying speciﬁcation, there

is no point in working at the syntax level because

OWL does not have a syntax per se, but can be built

according to different syntaxes. In fact, the proposed

methodology has been executed using the OWL/RDF,

OWL/XML and Manchester (Horridge et al., 2006)

syntaxes with identical results.

The mutation operators have therefore been de-

ﬁned as a set of operations that conceptually modify

the ontology. An ontology refers to entities, which

are the main building blocks used to represent real-

world objects. The ontology does not deﬁne the enti-

ties, which are deﬁned by the domain itself. For the

purposes of this work, the following entity types have

been used as the ground string for mutation:

Classes: represent the core concepts in the ontology.

A class is the abstraction which subsumes all in-

dividuals of a given type;

Individuals: are the real-world objects, single in-

stances of a class;

Object Properties: describe the relationships be-

tween individuals;

Data Properties: are used to associate information

data to classes.

In addition to entity-speciﬁc mutation operators,

it is also possible to deﬁne some general operators.

In particular, some static information can be added to

any entity by means of annotations. Typical annota-

tions include label and comment, which are part of

RDF Schema (RDFS) and are language speciﬁc.

All mutation operators affect some axiom, which

is the base expression in the ontology. Axioms are

connections between entities, and some examples of

axioms are:

Mutating OWLs: Semantic Mutation Testing for Ontologies

• a subclass relationship between two classes;

• the belonging of an individual to a class;

• the domain or the range of an object or data prop-

erty;

• association of an annotation with its entity.

3.2 Mutation Operators

This section describes the various classes of mutation

operators deﬁned for OWL mutation testing. Enti-

ties in OWL can be declared using either a human-

readable Internationalized Resource Identiﬁer (IRI),

or an auto-generated one. When using the latter nam-

ing convention, which is recommended by the Prot

software, the domain-speciﬁc names must be referred

to by means of label annotations. This solution is very

versatile, because it does not force a naming, but an

entity can have a number of names, also in different

languages. However, when referring to entities using

labels, the absence of a label can cause errors.

Table 1 offers an overview of all the mutation op-

erators.

Some of the mutation operators produce identical

mutants: for instance, the ORI operator, when applied

to a class and to its inverse, generates two identical

mutants.

3.2.1 Entities

Some mutation operators are general and can be ap-

plied to any entity:

ERE. Remove entity. This operator deletes the dec-

laration of an entity from the ontology, be it a

class, property, or individual. All axioms concern-

ing the deleted entity are removed as well.

ERL. Remove label. This operator removes a label

annotation from an entity.

ECL. Change label language. A label annotation is

composed by the actual label and a language at-

tribute. This operator removes the language at-

tribute, setting it to a meaningless value.

While it is possible to also apply mutation oper-

ators to comment annotations, comments are gener-

ally not meant for processing purposes, but only to

provide a description to the human user. Therefore,

no mutation on comment annotations has been intro-

duced in this work. Similarly, no mutation operators

have been deﬁned for other annotations such as ver-

sionInfo or seeAlso.

3.2.2 Classes

Classes are entities which describe the conceptual ab-

straction of real-world objects. Class relations can be

described in hierarchical terms, from the general to

the particular. In other words, a class can be deﬁned

as the subclass of another class, by means of an “is

a” relationship. Classes can be subclasses of more

than one superclass. If a class is not deﬁned as a sub-

class, then it is implicitly a subclass of the top-level

class, Thing. A class can also be the subclass of an

anonymous class, i.e., a class deﬁned “on the ﬂy” us-

ing properties.

In addition to the mutation operators applicable to

all entities, the following operators have been deﬁned

for class entities:

CRS. Remove subclass axiom. This operator re-

moves a subclass axiom, thus changing the hier-

archical structure of the ontology. If the class has

a single superclass, then it will become a subclass

of the top-level class.

CSC. Swap subclass axiom. This operator ex-

changes a class with one of its superclasses. Sim-

ply put, it reverses part of the hierarchical struc-

ture.

CRD. Remove disjoint class. A class can be declared

as being disjoint from other classes. This operator

erases a disjoint declaration, so the two classes are

no longer disjoint.

CRE. Remove equivalent class. A class can be de-

clared as being equivalent to other classes. This

operator erases an equivalent declaration, so the

two classes are no longer equivalent.

3.2.3 Object Properties

Object properties represent relations between classes

which cannot be in hierarchical terms. All relations

except “is a” must be deﬁned in terms of object prop-

erties.

An object property normally has at least one do-

main and one range. The domain represents the

classes (which can also be anonymous classes, de-

ﬁned for example using set operations) to which the

object property applies. A range represents the possi-

ble values that the property can have. In other words,

domain and ranges are limitations to the individuals

to which the property can be applied and to the indi-

viduals that it can have as its values, respectively.

The following mutation operators speciﬁc to ob-

ject properties have been deﬁned:

OND. Remove domain. One domain (set of entities

to which the property can apply) is removed from

AMARETTO 2016 - International Workshop on domAin speciﬁc Model-based AppRoaches to vEriﬁcaTion and validaTiOn

Table 1: List of mutation operators.

Entity Operator Effect

Any entity

ERE Remove the entity and all its axioms

ERL Remove entity labels

ECL Change label language

Class

CRS Remove a single subclass axiom

CSC Swap the class with its superclass

CRD Remove disjoint class

CRE Remove equivalent class

Object property

OND Remove a property domain

ONR Remove a property range

ODR Change property domain to range

ORD Change property range to domain

ODP Assign domain to superclass

ODC Assign domain to subclass

ORP Assign range to superclass

ORC Assign range to subclass

ORI Remove inverse property

Data property

DAP Assign property to superclass

DAC Assign property to subclass

DRT Remove data type

Individual

IAP Assign to superclasses

IAC Assign to subclasses

IRT Remove data type

the object property. Since the actual domain is the

intersection of all ranges, this operator actually

widens the possible entities to which the property

can apply.

ONR. Remove range. One range is removed from

the object property. Since the actual range is the

intersection of all ranges, this operator actually

widens the possible values that the property can

have.

ODR. Change domain to range. One of the domains

of the property is changed to a range, actually

restricting its possible values but increasing the

classes it can apply to.

ORD. Change range to domain. One of the ranges of

the property is changed to a domain.

ODP. Assign to superclass. One of the domains

of the property is replaced with one of the su-

perclasses of that domain. This operator cannot

be applied to anonymous domains or to domains

which are only subclass of the top-level class.

ODC. Assign to subclass. One of the domains of the

property is replaced with one of the subclasses of

that domain. This operator cannot be applied to

anonymous domains.

ORP. Set range to superclass. One of the ranges of

the property is replaced with one of the super-

classes of that range. This operator cannot be ap-

plied to anonymous ranges or to range which are

only subclass of the top-level class.

ORC. Set range to subclass. One of the ranges of

the property is replaced with one of the subclasses

of that range. This operator cannot be applied to

anonymous ranges.

ORI. Remove inverse property. The property can be

declared as being inverse to another one. This op-

erator removes the inverse declaration, but it does

not remove the other property.

3.2.4 Data Properties

Data properties are used to describe additional fea-

tures of an entity. Technically, they represent a con-

nection between entities and literals (such as XML

strings and integers). Data properties have a domain

which limits the entities it can be applied to, and a

range which limits the set of possible literals it can

have as values.

In addition to the general operators, the following

operators have been deﬁned for data properties:

DAP. Assign to superclass. One of the domains

of the property is replaced with one of the

superclasses of that domain. This operator cannot

be applied to anonymous domains or to domains

which are only subclass of the top-level class.

Mutating OWLs: Semantic Mutation Testing for Ontologies

DAC. Assign to subclass. One of the domains of the

property is replaced with one of the subclasses of

that domain. This operator cannot be applied to

anonymous domains.

DRT. Remove data range. One of the data ranges of

the property is removed, and it is implicitly re-

placed with the top-level literal rdfs:Literal, actu-

ally increasing the set of possible literals that this

property can have.

3.2.5 Individuals

Individuals represent single instances of a class (in-

cluding anonymous classes). Individuals are very

similar to classes, but they represent a single object

and not an abstract generalization. Therefore, they

can be deﬁned as belonging to one or more classes.

The following speciﬁc operators have been de-

ﬁned for individuals.

IAP. Assign to superclass. One of the types of the

individual is replaced with one of its superclasses.

This operators can be applied only to those types

which have a superclass different from the top-

level class.

IAC. Assign to subclass. One of the types of the in-

dividual is replaced with one of its subclasses.

IRT. Remove type. One of the types to which the

individual belongs is removed (both named and

anonymous classes). If the individual is of a single

type, then it becomes an individual of the top-level

class.

4 EXPERIMENTS

The proposed mutation testing methodology has been

implemented and executed on several existing ontolo-

gies. This section describes the test platform, the ref-

erence ontologies and the results of the application of

the methodology.

4.1 Experimental Setup

The implementation of the proposed mutation testing

approach was done using Eclipse 4.5 (Mars) as a de-

velopment environment. The programming language

used is Java (Sun Java 1.8). The setup is platform-

independent and has been successfully tested on Win-

dows 7, Ubuntu Linux 14.04 and Mac OS X 10.10

machines, both at 32 and 64 bit.

The implementation is lightweight and only re-

quires the OWL API libraries

, managed through

smallhttp://owlapi.sourceforge.net/.

Maven

The mutation testing tool, called Mutating OWLs,

is available as a Git repository

. The repository also

contains the test ontologies described below.

4.2 Reference Ontologies

The proposed methodology has been executed on

three different ontologies.

4.2.1 Data Protection

The data protection ontology has been introduced

in (Bartolini and Muthuri, 2015; Bartolini et al.,

2015). The European Union is currently undergo-

ing a reform of the protection of personal data. The

main legislative document of the reform is the Gen-

eral Data Protection Regulation (GDPR), which will

introduce signiﬁcant changes in the duties of the con-

troller (Reding, 2010). The ontology has been deﬁned

to describe the upcoming reform; however, it does not

aim at modeling the whole domain of data protection

in the European Union, but only focuses on the re-

quirements of the data controller.

The ontology is preliminary and subject to change,

especially given that the reform is not ﬁnalized yet. It

is mainly made up of hierarchical relations, and con-

tains a number of object properties that relate the du-

ties of the controller with the corresponding rights of

the data subject.

Entities in the ontology are named using an auto-

generated IRI, and labels contain the human-readable

names.

4.2.2 Passenger Rights

The second ontology used as an experimental base has

been introduced in (Rodr

ıguez-Doncel et al., 2014a;

Rodr

ıguez-Doncel et al., 2014b) to describe the legal

framework for ﬂight incidents. In particular, the on-

tology addresses the perspective of the rights of the

passenger.

This ontology has a more complex structure, and

is split into three ﬁles. Since the import links were

actually broken, some changes had to be made to the

ontology to allow the OWL API to access local ﬁles.

Speciﬁcally, the ontology had to be converted from

Turtle syntax (World Wide Web Consortium (W3C),

2014b) to an XML serialization because of some lim-

itations of OWL API in parsing non-XML syntaxes.

The naming convention differs from the previous

ontology in that the IRIs are human-readable terms in

https://maven.apache.org/.

https://bitbucket.org/guerret/lu.uni.owl.mutatingowls.

AMARETTO 2016 - International Workshop on domAin speciﬁc Model-based AppRoaches to vEriﬁcaTion and validaTiOn

Table 2: Summary of the test ontologies.

Data protection

Passenger

rights

Pizza

Total number of axioms

680 541 940

Classes

87 89 100

Object properties

41 26 8

Data properties

4 31 0

Individuals

12 14 5

Subclass axioms

114 83 259

Table 3: Mutants by mutation operator.

Operator Data protection

Passenger

rights

Pizza

ERE 142 67 113

ERL 142 0 96

ECL 142 0 96

CRS 114 33 259

CSC 101 33 84

CRD 18 0 796

CRE 28 0 41

OND 39 10 6

ONR 34 8 7

ODR 39 10 6

ORD 34 8 7

ODP 29 8 6

ODC 239 54 254

ORP 29 5 7

ORC 119 22 257

ORI 0 0 0

DAP 2 29 0

DAC 5 3 0

DRT 3 13 0

IAP 12 0 0

IAC 30 0 0

IRT 12 0 10

English language, and no labels are used throughout

the ontology.

4.2.3 Pizza

Finally, the proposed methodology has been run

against the well-known pizza ontology

, which is the

one provided as a standard example for OWL and

Prot

e tutorials. The naming convention used in this

ontology is based on English-language identiﬁers for

the entities, but entities also feature label annotations

in Portuguese.

http://protege.stanford.edu/ontologies/pizza/pizza.owl.

4.2.4 Summary

Table 2 displays a summary of the features of the three

ontologies used.

4.3 Experimental Results

The mutation operators deﬁned in Section 3.2 have

been applied to the three test ontologies, generating

mutants for each. The total number of mutants per

mutation operator is displayed in Table 3.

Some considerations are offered by the very struc-

ture of the three ontologies. For example, the data

protection ontology, as mentioned earlier, uses auto-

generated IRIs as identiﬁers, and labels for descrip-

tive purposes. The pizza ontology uses English terms

as identiﬁers, but entities also have Portuguese la-

Mutating OWLs: Semantic Mutation Testing for Ontologies

bels. Finally, the passenger rights ontology does not

use label annotations. For this reason, the ERL and

ECL operators do not generate any mutant in the lat-

ter. Similarly, no mutant is generated by the IAP, IAC

and IRT operators in the passenger rights ontology be-

cause the individuals are not assigned to any class.

The data protection ontology makes a very limited

use of data properties, so very few mutants are gener-

ated from the data property entity; the same is not true

for the passenger rights entity, which has a signiﬁcant

number of data properties but less object properties.

The pizza ontology does not have any data properties

at all, and few object properties. However, the classes

that make up the domain and range of some of the

object properties have a large number of subclasses,

hence many mutants from the ODC and ORC opera-

tors.

4.4 Validation

The proposed approach was validated by testing an

ontology itself and not an application running on top

of it. For the SUT to be an ontology, the simplest

approach to test it is to have a set of SPARQL Protocol

and RDF Query Language (SPARQL) queries (World

Wide Web Consortium (W3C), 2008) which retrieve

data from the ontology.

Unfortunately, none of the ontologies used pro-

vide a SPARQL test suite. A set of queries for the

pizza ontology exists as the test suite for an alterna-

tive query language

. As minimal as this test suite is,

it has been used as a starting point to assess the valid-

ity of the approach. The queries in that test suite were

thus converted back to SPARQL. However, two more

queries were added to the test suite, because the ex-

isting queries only search for very small parts of the

ontology

The results of the validation is shown in Table 4,

and a summary of killed mutants is shown in Figure 1.

A brief analysis of the results elicits some inter-

esting considerations. First, it is clear that the test

suite mainly addresses classes, with little tests cover-

ing the properties. Thus, additional tests, especially

for the object properties, are required. Also, con-

cerning the classes, the tests mostly cover a particular

branch of the hierarchy, while almost no tests search

other branches of the ontology. Finally, some con-

siderations can be done on the ontology itself. For

example, by examining the live mutants in the ERE

operator, it emerges that some object properties are

https://code.google.com/p/twouse/wiki/SPARQLASExamp

les

The complete setup is available in the repository (see foot-

note 3).

Table 4: Results of the mutation testing.

Operator

Mutants

killed

Total

mutants

ERE 108 112

ERL 95 95

ECL 95 95

CRS 255 255

CSC 83 83

CRD 471 753

CRE 41 41

OND 0 6

ONR 0 7

ODR 0 6

ORD 0 7

ODP 0 6

ODC 1 250

ORP 0 7

ORC 1 253

IRT 0 10

Figure 1: Overview of mutants killed.

not used anywhere. Depending on the purposes of the

ontology, this might suggest that those properties are

irrelevant. Of course, such a small test suite does not

yield a lot of results, but a richer test suite would al-

low a more signiﬁcant analysis.

5 CONCLUSIONS AND FUTURE

WORK

The work presented in this paper extends and adapts

mutation testing techniques to ontologies deﬁned us-

ing the OWL language. The essentials of OWL on-

tologies are described, to introduce a methodology

and operators for mutation testing. The work then

presents an implementation of the mutation testing

technique and some basic experiments on previously-

deﬁned ontologies.

AMARETTO 2016 - International Workshop on domAin speciﬁc Model-based AppRoaches to vEriﬁcaTion and validaTiOn

The beneﬁts of mutation testing are manifold: by

analyzing the patterns of killed and alive mutants,

testers can detect errors in the SUT and in the test

suite. Equivalent mutants can help detect redundan-

cies in the ontology, which may not be errors but still

facilitate errors, for example when creating instances

of the ontology.

More in general, the extension of software engi-

neering and testing approaches to ontologies and se-

mantic knowledge bases can pave the way to the for-

malization of integrated design and testing patterns in

for semantics-based applications.

This work is at its initial stages, with many op-

portunities for future development. First off, the pro-

posed methodology needs to be expanded to support

a full test suite: a signiﬁcant set of SPARQL queries,

if the SUT is the ontology itself; or, if the SUT is an

ontology-based software, testing it with its own test

suite. The purpose would be to compare the outputs

of the test suite when executed against the original

ontology and against the mutants. In this phase, it is

possible that the complexity of the mutation testing

is excessive and causes performance problems, and

it might be necessary to apply or develop algorithms

designed to reduce the number of mutants.

Second, the mutation methodology can be im-

proved, by extending it with additional mutation op-

erators. For example, the mutation operators do not

currently address annotations other than labels, or the

value and cardinality constraints. Some of these fea-

tures of the OWL language can have a signiﬁcant ef-

fect in the ontology deﬁnition, and mutants thus cre-

ated might be useful in assessing the ontology.

Third, the mutation testing should take into ac-

count the peculiarities of ontology engineering. In

particular, while the domain certainly imposes some

constraints on the ontology developer, many decisions

are based on discretionary choices, balancing differ-

ent aspects such as human readability and efﬁciency

of the ontology. Traditional mutation testing tech-

niques might be extended to embrace these features,

for example by separating those mutant operators that

are likely to introduce errors in the domain (for exam-

ple swapping a class with its parent) from those that

simply change the ontology structure without making

it inconsistent with the domain. If such a partition

were possible, then mutation testing techniques could

be used not only to detect errors in the design, but also

to suggest different ontology architectures that the de-

signer might overlook.

Finally, stretching along the line of the previous

point, an extended mutation technique could be de-

signed which alters the structure of the ontology. For

example, there might be circumstances where using a

hierarchical relationship (subclass axiom) might be an

alternative to using an object property. An extended

mutation technique that generates mutants based on a

different structure of the ontology might offer a fast

way to compare a wide number of ontology designs.

REFERENCES

Ammann, P. and Offutt, A. J. (2008). Syntax-based testing.

In Introduction to Software Testing, chapter 5, pages

170–212. Cambridge University Press.

Antoniou, G. and van Harmelen, F. (2004). Web Ontol-

ogy Language: OWL. In Staab, S. and Studer, R.,

editors, Handbook on Ontologies, International Hand-

books on Information Systems, pages 67–92. Springer

Berlin Heidelberg.

Bartolini, C., Bertolino, A., Marchetti, E., and Parissis,

I. (2008). Data ﬂow-based validation of web ser-

vices compositions: Perspectives and examples. In

de Lemos, R., Di Giandomenico, F., Gacek, C., Muc-

cini, H., and Vieira, M., editors, Architecting De-

pendable Systems V, volume 5135 of Lecture Notes

in Computer Science, pages 298–325. Springer Berlin

/ Heidelberg.

Bartolini, C. and Muthuri, R. (2015). Reconciling data

protection rights and obligations: An ontology of the

forthcoming EU regulation. In Proceedings of the

Workshop on Language and Semantic Technology for

Legal Domain (LST4LD), Recent Advances in Natural

Language Processing (RANLP).

Bartolini, C., Muthuri, R., and Santos, C. (2015). Using

ontologies to model data protection requirements in

workﬂows. In Proceedings of the Ninth International

Workshop on Juris-informatics (JURISIN), pages 27–

40.

Blomqvist, E., Seil Sepour, A., and Presutti, V. (2012).

Ontology testing - methodology and tool. In ten

Teije, A., V

olker, J., Handschuh, S., Stuckenschmidt,

H., d’Acquin, M., Nikolov, A., Aussenac-Gilles, N.,

and Hernandez, N., editors, Knowledge Engineering

and Knowledge Management, volume 7603 of Lecture

Notes in Computer Science, pages 216–226. Springer

Berlin Heidelberg.

Burton-Jones, A., Storey, V. C., Sugumaran, V., and

Ahluwalia, P. (2005). A semiotic metrics suite for as-

sessing the quality of ontologies. Data & Knowledge

Engineering, 55(1):84–102.

Clark, J. A., Dan, H., and Hierons, R. M. (2010). Semantic

mutation testing. In Proceedings of the 3

IEEE In-

ternational Conference on Software Testing, Veriﬁca-

tion, and Validation Workshops (ICSTW), pages 100–

109. IEEE.

DeMillo, R. A., Lipton, R. J., and Sayward, F. G. (1978).

Hints on test data selection: Help for the practicing

programmer. Computer, 11(4):34–41.

Denny Vrande

c, A. G. (2006). Unit tests for ontologies.

In Meersman, R., Tari, Z., and Herrero, P., editors, On

the Move to Meaningful Internet Systems 2006: OTM

Mutating OWLs: Semantic Mutation Testing for Ontologies

2006 Workshops, volume 4278 of Lecture Notes in

Computer Science, pages 1012–1020. Springer Berlin

Heidelberg.

Gangemi, A., Catenacci, C., Ciaramita, M., and Lehmann,

J. (2006). Modelling ontology evaluation and valida-

tion. In Sure, Y. and Domingue, J., editors, The Se-

mantic Web: Research and Applications, volume 4011

of Lecture Notes in Computer Science, pages 140–

154. Springer Berlin Heidelberg.

Garc

ıa-Ramos, S., Otero, A., and Fern

andez-L

opez, M.

(2009). OntologyTest: A tool to evaluate ontologies

through tests deﬁned by the user. In Omatu, S., Rocha,

M. P., Bravo, J., Fern

andez, F., Corchado, E., Bustillo,

A., and Corchado, J. M., editors, Distributed Comput-

ing, Artiﬁcial Intelligence, Bioinformatics, Soft Com-

puting, and Ambient Assisted Living, volume 5518

of Lecture Notes in Computer Science, pages 91–98.

Springer Berlin Heidelberg.

Granitzer, M., Scharl, A., Weichselbraun, A., Neidhart, T.,

Jufﬁnger, A., and Wohlgenannt, G. (2007). Auto-

mated ontology learning and validation using hypoth-

esis testing. In Wegrzyn-Wolska, K. M. and Szczepa-

niak, P. S., editors, Advances in Intelligent Web Mas-

tering, volume 43 of Advances in Soft Computing,

pages 130–135. Springer Berlin Heidelberg.

Hamlet, R. G. (1977). Testing programs with the aid of a

compiler. IEEE Transactions on Software Engineer-

ing, SE-3(4):279–290.

Horridge, M., Drummond, N., Goodwin, J., Rector, A.,

Stevens, R., and Wang, H. H. (2006). The Manchester

OWL syntax. In OWL: Experiences and Directions

Workshop (OWLED).

Horrocks, I. (2002). DAML+OIL: a description logic for

the semantic web. Bulletin of the Technical Committee

on Data Engineering, 25(1):4–9.

Horrocks, I. (2013). What are ontologies good for? In

uppers, B.-O., Hahn, U., and Artmann, S., edi-

tors, Evolution of Semantic Systems, pages 175–188.

Springer Berlin Heidelberg.

Howden, W. E. (1982). Weak mutation testing and com-

pleteness of test sets. IEEE Transactions on Software

Engineering, SE-8(4):371–379.

Jia, Y. and Harman, M. (2011). An analysis and survey of

the development of mutation testing. IEEE Transac-

tions on Software Engineering, 37(5):649–678.

Kershenbaum, A., Fokoue, A., Patel, C., Welty, C., Schon-

berg, E., Cimino, J., Ma, L., Srinivas, K., Schloss, R.,

and Murdock, J. W. (2006). A view of OWL from the

ﬁeld: Use cases and experiences. In Cuenca Grau, B.,

Hitzler, P., Shankey, C., and Wallace, E., editors, Pro-

ceedings of the Second Workshop on OWL: Experi-

ences and Directions (OWLED), volume 216 of CEUR

Workshop Proceedings.

Lee, S., Bai, X., and Chen, Y. (2008). Automatic mutation

testing and simulation on OWL-S speciﬁed web ser-

vices. In Proceedings of the 41

Annual Simulation

Symposium (ANSS), pages 149–156. IEEE.

Lipton, R. (1971). Fault diagnosis of computer programs.

Technical report, Carnegie Mellon University.

Ma, L., Yang, Y., Qiu, Z., Xie, G., Pan, Y., and Liu, S.

(2006). Towards a complete OWL ontology bench-

mark. In Sure, Y. and Domingue, J., editors, The Se-

mantic Web: Research and Applications, volume 4011

of Lecture Notes in Computer Science, pages 125–

139. Springer Berlin Heidelberg.

Ma, Y.-S., Offutt, A. J., and Kwong, Y. R. (2005). Mujava:

An automated class mutation system. Software Test-

ing, Veriﬁcation and Reliability, 15(2):97–133.

McGuinness, D. L., Fikes, R., Rice, J., and Wilder, S.

(2000). An environment for merging and testing large

ontologies. In Proceedings of the Seventh Interna-

tional Conference on Principles of Knowledge Repre-

sentation and Reasoning (KR2000), pages 483–493.

Mottu, J.-M., Baudry, B., and Le Traon, Y. (2006). Mu-

tation analysis testing for model transformations. In

Rensink, A. and Warmer, J., editors, Model Driven

Architecture - Foundations and Applications, volume

4066 of Lecture Notes in Computer Science, pages

376–390. Springer Berlin Heidelberg.

Offutt, A. J. (1994). A practical system for mutation testing:

help for the common programmer. In Proceedings of

the International Test Conference (ITC), pages 824–

830. IEEE Computer Society.

Offutt, A. J. and Hayes, J. H. (1996). A semantic model

of program faults. SIGSOFT Software Engineering

Notes, 21(3):195–200.

Offutt, A. J., Lee, A., Rothermel, G., Untch, R. H., and

Zapf, C. (1996). An experimental determination of

sufﬁcient mutant operators. ACM Transactions on

Software Engineering and Methodology (TOSEM),

5(2):99–118.

Offutt, A. J. and Untch, R. H. (2001). Mutation 2000:

Uniting the orthogonal. In Wong, W. E., editor,

Mutation Testing for the New Century, volume 24

of The Springer International Series on Advances in

Database Systems, pages 34–44. Springer US.

Poveda-Villal

on, M., Su

arez-Figueroa, M. C., and G

omez-

erez, A. (2010). Common pitfalls in ontology devel-

opment. In Meseguer, P., Mandow, L., and Gasca,

R. M., editors, Current Topics in Artiﬁcial Intelli-

gence, volume 5988 of Lecture Notes in Computer

Science, pages 91–100. Springer Berlin Heidelberg.

Poveda-Villal

on, M., Su

arez-Figueroa, M. C., and G

omez-

erez, A. (2012). Validating ontologies with OOPS!

In ten Teije, A., V

olker, J., Handschuh, S., Stucken-

schmidt, H., d’Acquin, M., Nikolov, A., Aussenac-

Gilles, N., and Hernandez, N., editors, Knowledge En-

gineering and Knowledge Management, volume 7603

of Lecture Notes in Computer Science, pages 267–

281. Springer Berlin Heidelberg.

Quillian, M. R. (1967). Word concepts: A theory and simu-

lation of some basic semantic capabilities. Behavioral

Science, 12(5):410–430.

Reding, V. (2010). The upcoming data protection reform

for the European Union. International Data Privacy

Law.

Rodr

ıguez-Doncel, V., Santos, C., and Casanovas, P.

(2014a). A model of air transport passenger incidents

and rights. In Proceedings of the 27

International

AMARETTO 2016 - International Workshop on domAin speciﬁc Model-based AppRoaches to vEriﬁcaTion and validaTiOn

Conference on Legal Knowledge and Information Sys-

tems (JURIX), pages 55–60. IOS Press.

Rodr

ıguez-Doncel, V., Santos, C., and Casanovas, P.

(2014b). Ontology-driven legal support-system in the

air transport passenger domain. In Proceedings of the

International Workshop on Semantic Web for the Law

(SW4Law).

Rospocher, M. and Seraﬁni, L. (2013). An ontological

framework for decision support. In Takeda, H., Qu,

Y., Mizoguchi, R., and Kitamura, Y., editors, Semantic

Technology, volume 7774 of Lecture Notes in Com-

puter Science, pages 239–254. Springer Berlin Hei-

delberg.

Wang, H., Horridge, M., Rector, A., Drummond, N., and

Seidenberg, J. (2005). Debugging OWL-DL ontolo-

gies: A heuristic approach. In Gil, Y., Motta, E., Ben-

jamins, V. R., and Musen, M. A., editors, The Seman-

tic Web - ISWC 2005, volume 3729 of Lecture Notes

in Computer Science, pages 745–757. Springer Berlin

Heidelberg.

World Wide Web Consortium (W3C) (2004a). OWL-S: Se-

mantic markup for web services.

World Wide Web Consortium (W3C) (2004b). OWL Web

Ontology Language test cases.

World Wide Web Consortium (W3C) (2008). Sparql query

language for rdf.

World Wide Web Consortium (W3C) (2012). OWL 2 Web

Ontology Language document overview (second edi-

tion).

World Wide Web Consortium (W3C) (2014a). RDF 1.1

concepts and abstract syntax.

World Wide Web Consortium (W3C) (2014b). RDF 1.1

Turtle.

Mutating OWLs: Semantic Mutation Testing for Ontologies
