Converging Future Internet, “Things”, and Big Data: A Speciﬁcation

Following NovaGenesis Model

Antonio M. Alberti

, Eduardo S. dos Reis

, Rodrigo da R. Righi

, V´ıctor M. Mu˜noz

and Victor Chang

ICT Laboratory, Instituto Nacional de Telecomunicac¸˜oes - INATEL, Santa Rita do Sapuca´ı, Minas Gerais, Brazil

PIPCA, Universidade do Vale do Rio dos Sinos, S˜ao Leopoldo, Rio Grande do Sul, Brazil

Universitat Autonoma de Barcelona, UAB, Barcelona, Spain

School of Computing, Creative Tech. and Eng., Leeds Beckett University, Leeds, U.K.

Keywords:

Internet of Things, Big Data, Cloud Computing, Future Internet, NovaGenesis, FIWARE, Spark.

Abstract:

The convergence of Internet of “things” (IoT) with big data platforms and cloud computing is already happen-

ing. However, the vast majority, if not all the proposals are based on the current Internet technologies. The

convergence of IoT, big data and cloud in “clean slate” architectures is an unexplored topic. In this article,

we discuss this convergence considering the viewpoint of a “clean slate” proposal called NovaGenesis. We

specify a set of NovaGenesis services to publish sensor device’s data in distributed hash tables employing self-

verifying addresses and contract-based trust network formation. IoT devices capabilities and conﬁgurations

are exposed to software-controllers, which control their operational parameters. The speciﬁcation covers how

the “things” sensed information are subscribed by a big data service and injected in Spark big data platform,

allowing NovaGenesis services to subscribe data analytics from Spark. Future work include implementation

of the proposed speciﬁcations and further investigation of NovaGenesis services performance and scalability.

1 INTRODUCTION

Internet of “things” (IoT) (Conti, 2006) can be de-

ﬁned as to connect the ordinary things to the Inter-

net. In the last years, many initiatives appeared to

converge IoT with big data. Among them there are:

FIWARE (Ramparany et al., 2014), SmartSantander

(Sanchez et al., 2013) and SENSEI (Presser et al.,

2009). FIWARE provides a platform to integrate

services via next generation service interfaces (NG-

SIs). SmartSantander provides a platform for smart

city services integration using RESTful (Richardson

and Ruby, 2007) application programming interfaces.

SENSEI focus was on wireless sensor and actuator

networks interoperation, creating a market of sensed

information via RESTFul interfaces.

FIWARE integrates Cosmos big data platform ser-

vices, which are based on Hadoop (Hu et al., 2014).

SmartSantander employed a combination of Spark

(Zaharia et al., 2010) and Cassandra (Lakshman and

Malik, 2010). These approaches solidly depend on

current Internet support, since they use RESTFul

APIs. However, many IoT challenges, like security,

trust, privacy, software-control, to name a few, will

require more than incremental solutions or the appli-

cation of models already established. New architec-

ture models will be demanded, since the current cloud

and networking technologies and their protocols are

inherently limited for several expected scenarios (Pan

et al., 2011). “Clean slate” architectures for Internet

(and consequently for IoT) are being engineered un-

der the banner of future Internet design.

The convergence of IoT, big data, and cloud in

“clean slate” future Internet architectures is an unex-

plored topic and the main contribution of this paper is

on specifying an architecture to integrate them. In this

context, we are developing NovaGenesis (NG

) (Al-

berti et al., 2014; de Oliveira et al., 2015), a conver-

gent information model that covers information ex-

changing, processing, and storage. In this paper, we

address IoT, big data, cloud computing, and software-

deﬁned (McKeown et al., 2008) technologies’ con-

vergence under the perspective of NovaGenesis. In

addition, we specify a set of NovaGenesis services

to publish sensor device’s data in distributed hash ta-

bles (DHTs) employing self-verifying names (SVNs)

http://www.inatel.br/novagenesis/

Alberti, A., Reis, E., Righi, R., Muñoz, V. and Chang, V.

Converging Future Internet, “Things”, and Big Data: A Speciﬁcation Following NovaGenesis Model.

DOI: 10.5220/0005890600730081

In Proceedings of the International Conference on Internet of Things and Big Data (IoTBD 2016), pages 73-81

ISBN: 978-989-758-183-0

and contract-based trust network formation. In other

words, we specify the data path form devices to the

cloud, employing NovaGenesis emerging paradigms,

like SVNs and contract-based service composition.

IoT devices capabilities and conﬁgurations are ex-

posed to software-controllers, which control their op-

erational parameters following the model in (Alberti

et al., 2014). Finally, we specify how the “things”

sensed information are subscribed by a big data ser-

vice (BDS) and injected in Spark big data platform.

This allows NovaGenesis services to subscribe data

analytics generated by Spark.

The remaining of this paper is structured as fol-

lows. Section 2 provides an overview of FIWARE

IoT + big data + cloud computing integration pro-

posal. The section also covers the requirements for

“clean slate” FI architectures that can improve the

state-of-the-art while converging these aspects. Sec-

tion 3 presents NovaGenesis and its current imple-

mentation. Section 4 speciﬁes a set of new services

for converging IoT, big data, cloud computing, and

software-controllers. A sequence diagram is provided

to clarify new services joint functioning. The section

also provides a discussion on how these services in-

teract one another, ranging from “things” raw data

to big data analytics results. The main contribution

of the paper is on integrating future Internet services

with already established big data technologies and

software-controlled devices and gateways, advancing

IoT architectures towards SDN and SOA. Section 5

provides a discussion on how the proposed model can

help on addressing some open challenges in IoT and

big data integration. Section 6 ﬁnishes the paper.

2 RELATED WORK AND

REQUIREMENTS

The amount of future Internet (FI), IoT, cloud com-

puting, and big data convergent scenarios is immense.

The amount of technologies that support such sce-

narios is also impressive. One example of initiative

aimed at this convergence is the European project FI-

WARE (Ramparany et al., 2014). Figure 1 illustrates

a simpliﬁed overview of FIWARE architectural com-

ponents for IoT, which include: (i) IoT broker; (ii)

backend device management (BDM); (iii) context-

broker (CB); (iv) big data analysis (BDA); and (v)

complex event processing (CEP). Before describing

them, it is important to notice that three kinds of

“things” are supported: (a) devices that are compati-

ble with next generation service interface (NGSI) ver-

sion 9/10; (b) devices that are not compatible with

NGSI 9/10, however the gateways are; and (c) devices

and gateways that are not compatible with NGSI-

9/10. The IoT broker recovers, collects and pro-

cesses information from “things” exposing devices

as RESTful application programming interface (API)

resources. The BDM exposes legacy technologies

(standardized or proprietary) as resources to the CB

via NGSI-9/10. IoT agents are instantiated to handle,

conﬁgure and monitor non NGSI devices and gate-

ways. The CB provides a publish/subscribe context

broker service via NGSI-9/10 interface. Contexts can

be registered, updated, queried, notiﬁed, subscribed,

etc. For example, a native NGSI-9/10 device can

create a context that carries the current value of the

temperature in a certain room. BDA is an extended

version of hadoop (Hu et al., 2014) from Telefonica

(called Cosmos). Finally, CEP is an IBM generic en-

abler (as FIWARE names its components) to correlate

real time events according to programmed rules. The

data generated either by CEP or BDA is published on

CB. BDA is fed by CB and processed data from CEP.

Therefore, FIWARE allows near real time map/reduce

operations over large amounts of data from IoT.

“THINGS” DATA CENTER

IOT BROKER

BDA

BDM

ACCESS NETWORKS

CEP

APPLICATIONS

NATIVE NGSI-9/10

NON NGSI-9/10

NATIVE NGSI-9/10

NON NGSI-9/10

Figure 1: FIWARE scenario for converging future Internet,

Internet of “things”, big data, and cloud computing.

Considering the perspective of clean slate archi-

tectures for the future Internet (Pan et al., 2011), the

convergence provided by the FIWARE project — that

is supported by current Internet and web technologies

— could be improved in the following aspects

Security - The current Internet approach of us-

ing natural language names (NLNs) to name uniform

resource locators (URLs), hosts (IP addresses) and

transport layer ports (in sockets) is human-friendly,

but the intrinsic binding to physical world entities de-

pends on the correct and unambiguous understand-

ing of these names. Information centric networking

(ICN) proposes self-verifying names (SVNs) as an al-

ternative to NLNs (Ahlgren et al., 2012), so making

possible to check the relationship between the named

Many other aspects can be considered. However, due

to limited space we decided to concentrate on these three.

IoTBD 2016 - International Conference on Internet of Things and Big Data

entity and the name at any time. Furthermore, Gh-

odsi et al. (Ghodsi et al., 2011) argue that SVNs have

better security, scalability, and ﬂexibility than NLNs.

SVNs can also support provenance, non repudiation,

and integrity of IoT data and its sources. FIWARE ar-

chitecture is based on the current Internet/Web design

and therefore do not support SVNs.

Contract-based Composition - Web services can

support contract-based services composition, e.g. us-

ing constrained application protocol (CoAP) observ-

able resources. This enables services to form a

trust networks, increasing security and privacy. Who

would like to have your IoT services publishing pri-

vate data to low trust services you do not know? The

RESTFul interfaces (e.g. NGSI-9/10) are dynamic

and allow a service to establish service level agree-

ments (SLAs) with other instantiated services. How-

ever, contract-based operation is typically not oblig-

atory. For instance, in FIWARE generic enablers are

not required to establish SLAs one another. SLAs are

employed to deal with cloud infrastructure.

Software-Deﬁned Control - The role of software

is increasing in emerging information and commu-

nication technologies (ICT) architectures. Software-

deﬁned networking (SDN) consists on decoupling

control and data planes in networking equipment

(McKeown et al., 2008). Unfortunately, current

open SDN standards are concerned only with traf-

ﬁc forwarding, e.g. OpenFlow. There exists a huge

potential behind software-controlling IoT and cloud

devices/infrastructure. Controllers can be extended

to deal with many other functions, like proxying,

ﬁre-walling, interconnection, etc. FIWARE’s back-

end device management is an example of software-

controlling IoT devices. These software controllers

can be exposed as services to other applications. An-

other example is the FIWARE’s protocol translation

software that can be software-controlled. In short,

FIWARE project already perceived the potential of

software-controlling the IoT/cloud devices. However,

what is missing is contract-based dynamic composi-

tion with exposed controllers-as-a-service (CaaS).

FIWARE and SmartSantander meet the software-

deﬁned control requirement, but lack on supporting

SLAs among their services as well as on supporting

SVNs and its name resolution. SENSEI does not meet

any of these requirements. (Pan et al., 2011) surveys

many future Internet architectures, including “clean

slate” ones. Some of them individually support these

requirements, but they are not focused on IoT.

3 NovaGenesis

NovaGenesis (NG) project started in 2008 with this

question in mind: imagine there is no Internet archi-

tecture right now, how could we design it using the

best contemporary technologies? However, we real-

ized that emerging architectures should embrace not

only networking aspects, but also computing, stor-

age, and visualization. Thus, NG aims for redesign-

ing both communication mechanisms and protocols

for enabling a program running anywhere to address

messages to programs anywhere else with acceptable

performance and portability levels. Also, it looks

for the convergence of computing and communica-

tions, merging technologies like cloud and mobile

computing, Internet of things (IoT), service frame-

works, software-deﬁned networking (SDN), network

function virtualization (NFV) and distributed systems

(Alberti, 2012; Alberti, 2013).

3.1 Foundational Concepts

Figure 2 illustrates key ingredients we tried to con-

verge in NG. We started from naming, name resolu-

tion, and life-cycling of contents and services. There-

after, we included exposition, control and gateway for

“things”. The idea was to create a generic framework

that could deal with naming, life-cycling, persistent

identiﬁcation, location-independency, joint content,

services, and “things” coordination (orchestration).

3.1.1 Existences

The physical world in the Earth is full of physical en-

tities, e.g. cars, houses, etc. Furthermore, the human

mind is capable of creating virtual realities, full of vir-

tual entities, e.g. computer programs, ﬁles. Adopting

these deﬁnitions, a convergent information architec-

ture can be seen as the combination of physical and

virtual existences aimed at dealing with information

in a universal scale. An “individual” existence is any-

thing that can be classiﬁed as independent or sepa-

rated from others.

3.1.2 Binding Natural and

Hash-Function-Generated Names

Names are symbols used to denote one or more in-

dividual existences. In this case, to denote means to

represent something by signals. By deﬁnition, names

denote meaning and sense. However, there are names

that are almost randomly generated, having weak se-

mantics, e.g. the plate of your car. Consider the bi-

nary word obtained at the output of a hashing algo-

rithm. This binary word (also called hash code) can

Converging Future Internet, “Things”, and Big Data: A Speciﬁcation Following NovaGenesis Model

be used as a name a self-verifying name (SVN). In

this case, the binary input of the hash function can

be the existence itself (e.g. computer program ex-

ecutable, source code, or information ﬁles) or other

binary input related to the entity being named (e.g.

entities’ immutable attributes). In the ﬁrst case, the

name is said to be self-certiﬁable, because at any time

the existence’s binary words can be hashed again to

get exactly the same name. In the second case, the

perennial physical existence attributes can be digital-

ized again to certiﬁcate the name.

IoT means that any “thing” will be part of the

Internet, therefore architectures should accommo-

date/recognize “things” names. Our approach em-

ploys an unlimited number of namespaces, that are

linked by means of name bindings. A name binding is

a mapping among two or more names. A name bind-

ing (NB) can relate a name to an object or a name to

other names. NovaGenesis allows any naming struc-

ture and generalized name resolution as a service.

3.1.3 Names as Identiﬁers or Locators

There is no novelty on using names as identiﬁers or

locators. This is intrinsic to ICT technologies. How-

ever, the adoption of SCNs as identiﬁers is more re-

cent. NovaGenesis borrowed this idea from other

FIAs, specially NetInf (Dannewitz, 2009) and XIA

(Han et al., 2012). A locator should provide a notion

of distance among existences in some space. As one

can expect, it is not possible to derive such distance

notion from SVNs — they are ﬂat. Then, NG pro-

vides such distance notion by using SVN-bindings.

3.1.4 Contents, Services, and Contracts

A content can be deﬁned as a piece of information,

composed by chunks of binary data. For example, a

textual ﬁle. A service is a data (or information) pro-

cessor. Thus, a textual ﬁle can be the input or the

output of a word processor service. In addition, a net-

working information processor, such as a frame for-

warder, is a service like any other, since it receives

information at the input, adds some control data, and

forwards the processed information as an output. In

this context, a process that is instantiated in an op-

erating system provides in essence information pro-

cessing, which in turn can be deﬁned as a service.

Therefore, in this paper we propose the following def-

inition: a service is an existence aimed at process-

ing, exchanging, or storing information. Services ne-

gotiate their job using contracts, which are contents

that describe service requirements, clauses to be re-

spected, evaluation, and ﬁnalization criteria, among

other data. All the information required to describe

User-centric

Self-*, Context

Information-centric

Service-centric

Software-Defined

Security

Privacy

Naming

Name Resolution

Virtualization

Internet of Things

Exposition, Orchestration

Self-Certifying

Life-Cycling

Protocol Development

Mobility

ID/Loc Splitting

Mngt. and Control

Figure 2: Key ingredients for Future Internet.

and regulate a service offer can be included in a con-

tract. In service-oriented architecture (SOA) a con-

tract is usually called service-level agreement (SLA).

3.1.5 Distributed Publishing and Subscribing of

Name-bindings and Content

Names and NBs are central in NG. Thus, an impor-

tant design choice was to decide how they are going

to be stored and exchanged. Instead of a traditional

communication model, such as a “receiver accepts

all model”, it was selected a loosely coupled, asyn-

chronous, “receiver select” model — a pub/sub ap-

proach. In summary, services can publish name bind-

ings or content to other services. For example, the

binding of an operating system name to a host name

can be published by a service that represents the OS.

Another OS representative service can subscribe this

binding (assuming it is public) to discover that there

is a name relation between those two existences.

3.1.6 Name-based Life-cycling

The life-cycling of substrate resources, services, and

content (including names) is populated by a dense

entanglement of existential relationships. Operating

systems inhabit hosts. Services are instantiated, com-

bined in runtime, and removed from operating sys-

tems. Contents are created, exchanged, processed,

and removed from services. To deal with this hier-

archical life-cycling requirement, name bindings are

categorized. There are NBs exclusive for: (i) physical

world entities; (ii) software entities; (iii) contents; (iv)

other names, e.g. a process ID in a Linux OS. There

are also NBs to link names among physical-virtual,

virtual-physical, etc.

IoTBD 2016 - International Conference on Internet of Things and Big Data

HOST 2 HOST 1

PGS

PSS

HTS

App

PGS

GIRS

T 2

HOST 3

HTS

PGS

HOST 4

HTS

PGS

Figure 3: NovaGenesis current prototype.

3.2 Proof-of-concept Implementation

In 2012, we implemented a C++ prototype of No-

vaGenesis (NG) to run at user space of Linux Kernel

as illustrated on Figure 3. This 40k line codes proto-

type already runs without TCP/IP, using a raw socket

directly over Ethernet or Wi-Fi. In the ﬁgure, Host 1

is connected by Ethernet, while the remaining hosts

use Wi-Fi. A proxy/gateway service (PGS) encapsu-

lates NG messages over link layer technologies.

NovaGenesis web of names is build of distributed

stored name bindings. NBs are published and sub-

scribed by services. This is the most innovative aspect

of NovaGenesis— a distributed, highly scalable, pub-

lish/subscribe, name binding and content storage ser-

vice. NBs and content are published by any services

through sending a message to an instance of a pub-

lish/subscribe service (PSS). The PSS stores which

services are pre-authorized to access the published

data. Also, it records a time to live (TTL) for any

published data. There is also a notiﬁcation function-

ality that enables PSS to inform other services about

new publications or NB updating. However, the PSS

does not store the data published. It forwards them

to a generic indirection resolution service (GIRS),

which selects a hash table service (HTS) to store it.

Thus, published NBs and content are forwarded by

the GIRS to an HTS instance, where they are stored

behind a hash table data structure.

User services (or applications — App) can expose

its NBs and content to other services via PSS. Thus,

other services can subscribe a services’ NBs and con-

tent. The PSS does the rendezvous between publish-

ers and subscribers, enabling them to discover how

published names are related each other in a secure

way. Eventually, services can successively subscribe

NBs to identify and locate other existences, storing

these NBs in local data structures, and routing infor-

mation based on them.

GIRS and HTS instances form a distributed

hash table (DHT). This DHT was designed from

the scratch to support named-based and contract-

oriented operation. Current DHTs do not employ self-

certifying names to identify the DHT nodes. In addi-

tion, they relay on TCP/IP stack for communication.

Our GIRS/HTS approach relays on NovaGenesis ser-

vices to forward and route the data among DHT in-

stances. This explains why we decided on a “clean

slate” DHT design.

4 EXTENDING NG FOR IoT/BIG

DATA

In this section, we specify an extension to NovaGe-

nesis services that can provide similar support for

converging IoT, FI, big data and cloud as FIWARE

provides. However, our proposal meets the require-

ments presented in Section 2 to advance conver-

gence towards more secure, trustable, contract-based,

software-controlled architectures. Figure 4 illustrates

how these new services interact one other by us-

ing NovaGenesis PSS/GIRS/HTS, which can be seen

as a distributed name resolution system (NRS) with

cache capabilities. All these services use a pub-

lish/subscribe (pub/sub) application programming in-

terface (API), which has ﬁve primitives: (i) publishes

a NB (and a content, if any); (ii) subscribes a NB (and

content, if any); (iii) notiﬁes peer services about NB

(and content) published; (iv) revokes a publication;

and (v) delivers name bindings and related contents.

This interface is used alternatively to the NGSI-9/10

adopted on FI-WARE. In terms of components, the

proxy/gateway/controllerservice (PGCS) is similar to

the IoT broker, even tough it includes some of the

FI-WARE’s BDM functions, like resource exposition,

monitor, etc. NovaGenesis big data service (BDM)

role is different from FI-WARE’s BDA. It provides

an application level gateway to the big data solutions,

such as Spark, while the BDA implements the hadoop

distributed system. In addition, NG relays on a new

name resolution system (NRS), while FI-WARE is

“THINGS”

DATA CENTER

PGCS

BDS

EPGS

MCS

PGCS

EPGS

ACCESS NETWORKS

NRS

SPARK

Figure 4: New NovaGenesis services for converging future

Internet, Internet of “things”, big data, and cloud.

Converging Future Internet, “Things”, and Big Data: A Speciﬁcation Following NovaGenesis Model

NG Layer

802.15.4

NG Layer

802.15.4

Ethernet

App Layer

MCS

EPGS

NG Layer

PGCS PGCS

Ethernet

App Layer

NRS

BDS

TCP/IP

App Layer

PGCS

SPARK

Ethernet

SSHPUB/SUB

PUB/SUB

Figure 5: Layer stack for NG and Spark big data plus IoT.

based on DNS.

Figure 5 illustrates the protocol stack behind our

approach. The NG layer employs a blank page mes-

saging service implemented using SVNs. NG mes-

sages are encapsulated over IEEE 802.15.4 (to be im-

plemented) or Ethernet/Wi-Fi (already implemented).

The NovaGenesis pub/sub API can be seen as a ser-

vice access point (SAP) between NG Layer and NG

application layer. Observe that the original PGS pre-

sented in Figure 3 is modiﬁed not only to run em-

bedded (EPGS), but also to include software-control

capabilities (PGCS). To the best of our knowledge,

the EPGS is the ﬁrst future Internet gateway that:

(i) employs SVNs, instead of “human readable” ad-

dresses; (ii) exposes hardware resources to services

using a contract-based approach; and (iii) receives

control commands from a software-controller(PGCS)

using named-data paradigm.

4.1 Embedded Proxy/Gateway Service

This service is a minimal NG implementation to run

embedded. It generates nodes’ self-veriﬁable names

as well as a descriptor of the hardware features and

functionalities, storing them in a local hash table (HT)

component. Also, it sends a periodic “hello” mes-

sage that exposes its names as well as its MAC ad-

dress (proxy function)

to possible peers (Figure 6 il-

lustrates this procedure). The “hello” step is shown

as transaction a in this ﬁgure. Since a PGCS receives

this “hello”, it answers back with its names and PSS’s

names, enabling the EPGS to publish data on the NG

NRS (Transaction b). Then, the EPGS publishes its

name bindings, descriptors, and a service offer to the

NRS via the discovered PGCS (c). The NRS noti-

ﬁes the PGCS (d), which subscribes the service of-

fer (f,g). The service offer exposes device features,

names, and capabilities to the PGCS. The PGCS pub-

lishes a service contract acceptance object (h) to the

NRS. The NRS notiﬁes the EPGS about the accep-

tance (i), which subscribes it (not shown in ﬁgure).

After contracting a PGCS the hello message can be

suppressed to save energy

The EPGS is able to encapsulate NG messages

over a link layer technology (gateway function) that

is compatible with a PGCS (IEEE 802.15.4 as shown

in Figure 5). The EPGS publishes its status, conﬁgu-

ration, and raw data (measures) to the NRS (p), noti-

fying other services interested in the raw data (BDS)

or status/conﬁguration (PGCS).

4.2 Proxy/Gateway/Controller Service

The PGCS has gateway, proxy, and controller func-

tionalities. Similarly to the EPGS, it generates node’s

SVNs and descriptors and store them in a local HT. It

also sends a periodic “hello” message with its names

and MAC address

to other PGCS (a,b in Figure 6).

The PGCS is an IoT gateway for one or more sensors

and/or actuators nodes. The PGCS has the respon-

sibility to disclosure PSS names, so the EPGS(es)

can use NRS API (b). The PGCS is able to encap-

sulate message to the its contracted EPGS(es), using

their link layer technologies, e.g. IEEE 802.15.4. Fi-

nally, the PGCS acts as a software-controller of the

EPGS’s represented devices, i.e. the PGCS can pub-

lish control messages to the EPGSes in its trust net-

work, changing their conﬁgurations. For example, a

PGCS can publish a control message ordering a con-

trolled device to change its IEEE 802.15.4 channel.

4.3 Management and Control Service

This service is responsible to manage and control the

infrastructure and it is implemented as an applica-

tion that uses NG pub/sub API. It exposes its func-

tionalities, which can cover the classical ﬁve man-

agement areas: fault, conﬁguration, accounting, per-

formance, security (FCAPS). It maintains a trust net-

work (via SLAs) with many PGCSes. This model en-

ables to propagate policies and rules in a distributed

way to many software-controllers, keeping consis-

tency, since conﬁgurations/rules/policies are all pub-

lished in the NRS using SVNs. It addresses the

load balancing and controller consistency problems

of OpenFlow. In summary, the MCS performs gate-

way/proxy/controller management and control. De-

pending on the amount of ctrl. and manag. opera-

tions, this service can be fragmented.

4.4 Big Data Service

This service is a gateway to interoperate to Spark (Za-

haria et al., 2010) — a popular big data implementa-

tion. The BDS exposes big data platforms as a service

to other NG services/applications via pub/sub API.

IoTBD 2016 - International Conference on Internet of Things and Big Data

Its aim is similar to FIWARE’s Cosmos generic en-

abler — even though Cosmos is based on Hadoop

(Hu et al., 2014). NovaGenesis is a pub/sub envi-

ronment, therefore the BDS will need to translate this

communication model to request/reply, which is the

typical model to access current big data implemen-

tations. Also, NG is implemented in C++ language,

which makes interoperation with big data approaches

complex, since typically there is no native support for

injection/querying in C/C++. In this context, to in-

teroperate NG with Spark the BDS will keep a se-

cure socket shell (SSH) connection to the Spark con-

sole (Figure 5) using TCP/IP. Using this interface, the

BDS will be able to send Hive structured query lan-

guage (SQL) queries to the Spark cloud. Also, the

BDS will be able to: (i) inject data subscribed at No-

vaGenesis side on Spark; and (ii) publish the obtained

results on NovaGenesis NRS. Thus, data series from

NovaGenesis distributed hash service will be injected

into Spark, analyzed, and retrieved via BDS.

In Figure 6, the BDS searches for PGCSes that can

provide useful data for analytics. It subscribes rele-

vant NLN (e.g. “PGCS”, “gateway”, etc) from local

NRS (transaction i). The NRS returns knownPGCSes

(j). The BDS publishes a service offer to a PGCS (k)

that can provided the raw data for big data analysis.

The PGCS subscribes the service offer (l,m). After

analyzing the offer, the PGCS publishes a service of-

fer acceptance object to the BDS (n), which is notiﬁed

by the NRS. The BDS subscribes the acceptance ob-

ject (o). Finally, the raw data provided by the EPGS

is published to the BDS (p), which subscribes it (q).

The subscribed raw data is injected by BDS on Spark

via SSH. The BDS can now perform queries on Spark

(s) and publish resulting analytics on NG NRS (t).

5 DISCUSSION

Since there will be thousands of devices to be con-

nected (in ideal situations), it is a huge task is to mon-

itor, control and manage all network trafﬁcs and de-

vices (mobiles, routers, sensors etc). This is highly

important for all IoT and BD architectures. Factors

affecting such performance will include latency, size

of data and network speed (Chang and Wills, 2015).

The proposed N:1 device control/management model

based on software-controllers (PGCSes) is highly

scalable, since more PGCSes can be elastically al-

located when required. The proper selection of ser-

vices’ hosts can decrease latency.

Current security and privacy methods are lag-

ging behind sophisticated hacking techniques and

just one single solution is far not enough. A

EPGS

PGCS

NRS

BDS

PGCS

SPARK

Figure 6: Sequence diagram for NG and Spark big data,

including EPGS and laptop PGCS “hello” (a,b), exposition

and service offering (c,d,f,g), service contracting (h) and ac-

ceptance (i). A similar discovery, negotiation, and contract

establishment procedure is performed by the laptop PGCS

and BDS pair (i,j,k,l,m,n,o). Raw data is published by the

EPGS (p), notiﬁed and subscribed by NRS (q), and injected

on Spark (r). Results are published by BDS on NG NRS (t).

multi-layered security solution can reduce the risk

of unauthorized access and the use of back-end

non-SQL databases should be implemented in core

servers/clusters for IoT and BD architectures (Chang

et al., 2016). NovaGenesis self-verifying names,

pub/sub, and contract-based operation enhances secu-

rity, privacy, and trust. Name resolution is very impor-

tant to provide a multi-layered security solution.

Since a lot of data can be generated, smart means

to recover data at any instance with advanced tech-

niques to meet performance, accuracy and reliability

are required. All sites should have the facility to per-

form multi-purpose and multi-site recovery to ensure

business continuity (Chang, 2015). The distributed

nature of NG model can help on maintaining coher-

ence in case of disaster. Name resolution can be ex-

plored to ﬁnd out alternatives to access some data or

network. Name rebind is an important tool.

Converging Future Internet, “Things”, and Big Data: A Speciﬁcation Following NovaGenesis Model

6 CONCLUSION

This work has proposed the concept and reported the

speciﬁcation of a model to integrate big data, cloud

computing, IoT device-control-as-a-service, and IoT

services. The proposed model is based on NovaGe-

nesis, a “clean slate” FI proposal. A big data ser-

vice was proposed to interoperate NG name resolu-

tion service (based on pub/sub and distributed hash

tables) with Spark big data. The proposed speciﬁ-

cation also introduces embedded proxy/gateway ser-

vices that encapsulate IoT devices trafﬁc towards NG

pub/sub, as well as represent IoT device’s in the ser-

vice tier. Software-deﬁned IoT devices are controlled

by proxy/gateway/controller services (Alberti et al.,

2014). A domain level management and control ser-

vice (MCS) was also speciﬁed to implement in a logi-

cal centralized way the classical areas of management

and coordinate PGCSes activities. The architecture

advances state-of-the-art by converging data, control,

and management planes for FI with big data and IoT.

Future work includes: (i) implementation and per-

formance evaluation of the convergent architecture

speciﬁed in this paper; (ii) elasticity and scalability

tests of the proposed control/management model in-

cluding cloud computing resources; (iii) evaluated la-

tency and efﬁciency of proposed control/management

model; (iv) to monitor and evaluate service repu-

tation; (v) explore security advantages of proposed

model; (vi) implement and evaluate NG beneﬁts for

disaster recovery scenarios; and (vii) evaluate NG in-

tegration to other big data platforms besides Spark.

ACKNOWLEDGEMENT

This work was partially supported by Finep/Funttel

Grant No. 01.14.0231.00, under the Radiocommu-

nication Reference Center (Centro de Referˆencia em

Radicomunicac¸˜oes - CRR) project of the National In-

stitute of Telecommunications (Instituto Nacional de

Telecomunicac¸˜oes), Brazil.

REFERENCES

Ahlgren, B., Dannewitz, C., Imbrenda, C., Kutscher, D.,

and Ohlman, B. (2012). A survey of information-

centric networking. Communications Magazine,

IEEE, 50(7):26–36.

Alberti, A. (2013). A conceptual-driven survey on fu-

ture internet requirements, technologies, and chal-

lenges. Journal of the Brazilian Computer Society,

19(3):291–311.

Alberti, A., de O Fernandes, V., Casaroli, M., de Oliveira,

L., Pedroso, F., and Singh, D. (2014). A novagen-

esis proxy/gateway/controller for openﬂow software

deﬁned networks. In Network and Service Manage-

ment (CNSM), 2014 10th International Conference

on, pages 394–399.

Alberti, A. M. (2012). Searching for synergies among fu-

ture internet ingredients. In Lee, G., Howard, D.,

Slezak, D., and Hong, Y., editors, Convergence and

Hybrid Information Technology, volume 310 of Com-

munications in Computer and Information Science,

pages 61–68. Springer Berlin Heidelberg.

Chang, V. (2015). Towards a big data system disaster re-

covery in a private cloud. Ad Hoc Networks, 35:65 –

82. Special Issue on Big Data Inspired Data Sensing,

Processing and Networking Technologies.

Chang, V., Kuo, Y.-H., and Ramachandran, M. (2016).

Cloud computing adoption framework: A security

framework for business clouds. Future Generation

Computer Systems, 57:24 – 41.

Chang, V. and Wills, G. (2015). A model to compare cloud

and non-cloud storage of big data. Future Generation

Computer Systems, pages –.

Conti, J. P. (2006). The internet of things. Communications

Engineer, Vol 4, 2006.

Dannewitz, C. (2009). Netinf: An information-centric de-

sign for the future internet. In Proc. 3rd GI ITG KuVS

Workshop on The Future Internet.

de Oliveira, L., Alberti, A., Favoreto Casaroli, M.,

Raimundo-Neto, E., Feliciano da Costa, I., and

Cerqueira Sodre, A. (2015). Service-oriented, name-

based, and software-deﬁned spectrum sensing and dy-

namic resource allocation for wi-ﬁ networks using no-

vagenesis. In Telecommunications (IWT), 2015 Inter-

national Workshop on, pages 1–8.

Ghodsi, A., Koponen, T., Rajahalme, J., Sarolahti, P., and

Shenker, S. (2011). Naming in content-oriented ar-

chitectures. In Proceedings of the ACM SIGCOMM

Workshop on Information-centric Networking, ICN

’11, pages 1–6, New York, NY, USA. ACM.

Han, D., Anand, A., Dogar, F., Li, B., Lim, H., Machado,

M., Mukundan, A., Wu, W., Akella, A., Andersen,

D. G., Byers, J. W., Seshan, S., and Steenkiste, P.

(2012). XIA: Efﬁcient support for evolvable internet-

working. In Proc. 9th USENIX NSDI, San Jose, CA.

Hu, H., Wen, Y., Chua, T.-S., and Li, X. (2014). Toward

scalable systems for big data analytics: A technology

tutorial. Access, IEEE, 2:652–687.

Lakshman, A. and Malik, P. (2010). Cassandra: A de-

centralized structured storage system. SIGOPS Oper.

Syst. Rev., 44(2):35–40.

McKeown, N., Anderson, T., Balakrishnan, H., Parulkar,

G., Peterson, L., Rexford, J., Shenker, S., and Turner,

J. (2008). Openﬂow: enabling innovation in cam-

pus networks. SIGCOMM Comput. Commun. Rev.,

38(2):69–74.

Pan, J., Paul, S., and Jain, R. (2011). A survey of the re-

search on future internet architectures. Communica-

tions Magazine, IEEE, 49(7):26 –36.

IoTBD 2016 - International Conference on Internet of Things and Big Data

Presser, M., Barnaghi, P., Eurich, M., and Villalonga, C.

(2009). The sensei project: integrating the physical

world with the digital world of the network of the fu-

ture. Communications Magazine, IEEE, 47(4):1 –4.

Ramparany, F., Galan Marquez, F., Soriano, J., and Elsaleh,

T. (2014). Handling smart environment devices, data

and services at the semantic level with the ﬁ-ware core

platform. In Big Data (Big Data), 2014 IEEE Inter-

national Conference on, pages 14–20.

Richardson, L. and Ruby, S. (2007). Restful Web Services.

O’Reilly, ﬁrst edition.

Sanchez, L., Gutierrez, V., Galache, J., Sotres, P., Santana,

J., Casanueva, J., and Munoz, L. (2013). Smartsan-

tander: Experimentation and service provision in the

smart city. In Wireless Personal Multimedia Commu-

nications (WPMC), 2013 16th International Sympo-

sium on, pages 1–6.

Zaharia, M., Chowdhury, M., Franklin, M. J., Shenker,

S., and Stoica, I. (2010). Spark: Cluster comput-

ing with working sets. In Proceedings of the 2Nd

USENIX Conference on Hot Topics in Cloud Comput-

ing, HotCloud’10, pages 10–10, Berkeley, CA, USA.

USENIX Association.

Converging Future Internet, “Things”, and Big Data: A Speciﬁcation Following NovaGenesis Model
