MCM Analyzer: A Fuzzy Logic-based Offloading Decision Trade-off

for Mobile Cloud Computing

Gustavo Mascarenhas Kath and Daniel Antonio Callegari

FACIN - Faculdade de Informática, Pontifícia Universidade Católica do Rio Grande do Sul, Porto Alegre/RS, Brazil

Keywords: Fuzzy Logic, Mobile Cloud Computing, Offloading.

Abstract: Mobile cloud computing is an emerging solution for remote data processing and offloading. However,

simply sending all data to the cloud is sometimes inviable because of security, network and cost issues.

Consequently, there should be a trade-off between local and remote processing of data. Hence, an important

issue to mobile solutions relies on developing a way to determine which sets of information can be

processed locally by the device and which sets of information could be sent to the cloud for remote

processing. This paper presents a fuzzy logic-based decision module for mobile cloud computing that can be

added to an Android application. Our proposal analyses execution data in real time and helps resolving the

local-remote decision trade-off. Experimental results show our proposal offers a promising approach when

dealing with such scenarios.

1 INTRODUCTION

Mobile Cloud Computing is an emerging computing

paradigm that leverages cloud computing resources to

smart mobile devices. It uses cloud storage services for

providing online storage, and cloud processing services

for augmenting processing capabilities of such mobile

devices. Processing capabilities of mobile devices are

extended by outsourcing computational intensive

components of the mobile applications to cloud data

centers (Orsini, et. al., 2015).

Although executing heavy tasks on cloud

infrastructure could be beneficial, always delegating

execution to remote servers might not be

advantageous and, in some cases, more resources are

spent sending and receiving jobs over the network

(Shiraz et. al. 2013).

Nevertheless, we have seen that the batteries on

such devices currently do not withstand too long for

some real world scenarios (Cuervo et. al, 2010). For

this reason, the mobile device should be intelligent

enough to decide whether outsourcing computation

is beneficial or not for a particular scenario.

Because solving this tradeoff is often based on

previous experience or on a set of heuristics and it is

subject to the designer or programmer's judgment

(Orsini, et. al., 2015), we believe fuzzy logic offers a

promising point of departure.

The classical methodology on knowledge

representation uses conventional logic, which is

often inefficient when dealing with uncertainty and

vagueness – it does not provide an adequate model

for reasoning on approximate information. Fuzzy

Logic provides an efficient conceptual base for

dealing with the problem of knowledge

representation in uncertain and imprecise

environments. It also can be used as a decision

mechanism (Zadeh, 1965) (Cox, 1995).

Our solution is composed of two main parts: the

Mobile Cost Monitor (MCM) and the MCM

Analyzer modules.

The MCM module is added to an Android

application and it automatically collects several

variables for later decision. In this sense, MCM acts

as a software profiler or “context monitor”. Then,

the results are evaluated by the MCM Analyzer

module, which fuzzyfies the input variables – such

as execution time, CPU, memory usage, connectivity

and battery level – applies a set of fuzzy rules, and

then defuzzyfies a final variable indicating the

favored result. The following sections present our

proposal in more detail.

2 MOBILE COST MONITOR

The Mobile Cost Monitor (MCM) is a software

component designed to monitor a running Android

180

Kath, G. and Callegari, D.

MCM Analyzer: A Fuzzy Logic-based Ofﬂoading Decision Trade-off for Mobile Cloud Computing.

In Proceedings of the 18th International Conference on Enterprise Information Systems (ICEIS 2016) - Volume 2, pages 180-185

ISBN: 978-989-758-187-8

application and collect data such as CPU usage,

memory usage, networking status, processing time

and battery charge. MCM was developed as a

module that can be added as a library to Android

applications. Its purpose is to collect information

about the overall execution of both the device and

the application that it is integrated to. MCM requires

Android version 2.3.3 (Gingerbread) or later.

2.1 Data Collected by MCM

MCM collects 18 different variables and their

respective values about the device and the running

application, e.g. battery level, temperature and

status; network type, status, signal level, inbound

and outbound traffic; shared and private memory

amounts; low memory flag; and app and general

CPU usage. Some values are acquired directly from

the Android's API; others are internally computed

based on historical data.

In order to capture information, MCM must be

added to a host application as a class library. Then,

the app developer decides the monitoring scope and

creates an instance of the Monitor class. In the

beginning of the desired application scope, the

developer calls the Monitor's start method. MCM

then starts collecting data in a configurable regular

basis. The Monitor's stop method should be called at

the end of the desired monitoring scope. This

architecture encapsulates all functionality for the

final development team.

3 MCM ANALYZER MODULE

MCM Analyzer is a software component that can be

attached to the output of MCM in order to process

the monitored data. MCM Analyzer was built to help

evaluating whether processing should be executed

locally by the device or else by the cloud

infrastructure, i.e., in a remote environment.

The local processing environment in our

scenario is the smartphone or the tablet computer.

Such devices have greater limitations when

compared to general-purpose computers. The

hardware is often simpler and, most importantly,

they run on batteries (as opposed to regular

computers, which run plugged to a power outlet).

Batteries provide considerable less energy for

computational purposes and they do not stand long

periods without recharging. Processing a large data

set is a task that can draw a lot of energy from the

battery. Moreover, some types of processing can

also increase energy consumption because a higher

frequency CPU usage directly draws more energy

from the battery (Datta, 2013).

In certain scenarios, sending the data set to be

processed by the cloud infrastructure can diminish

this issue, as computational limitations would be

lower in comparison. However, this is only possible

when the smartphone is connected to the network. In

the other hand, there is the cost of sending the data

to the servers. The device's radio also consumes a

considerable amount of energy, so that some experts

recommend us to check whether the network

connection is already established before trying to

send data as well as to compress the data to be sent

by the network infrastructure (Sharkey, 2009).

3.1 MCM Analyzer Heuristics

The MCM Analyzer module uses embedded

heuristics in order to solve the offloading tradeoff. In

order to decide which variables from MCM are

useful to our decision process (and to that extent),

we analyzed them one by one when running

experiments. We found the following variables as

the most important for our case:

Battery Level: This variable is considered critical to

the decision process. A very low battery raises the

risk to start a process, requiring more resources, and

eventually not being able to complete processing.

The remote processing time of the same information

is many times expected to lessen the use of such

resources, but we should not ignore the effort of

sending and receiving the information back.

Battery Status: This variable is important to the

decision tradeoff since we can easily determine

whether the device is connected to some power

source even when the battery level is low. However,

because USB ports provide considerable less energy

than standard power outlets, the device may inform

it is charging even though the battery level is

decreasing. In order to account for this issue we

embedded specific rules to the decision heuristics.

Network is Connected: This is a critical variable

because if the device is not connected to a network

than it is obviously impossible to rely on the remote

processing of the data. On Android devices, though,

this variable only informs whether we are connected

to some sort of networking (e.g. Wi-Fi, 3G, 4G), but

it does not tell whether the connection itself is

working properly.

Network Signal Level: This is an important

variable in our scenario since the lower is the value,

the greater is the risk in data loss during the

transmission of data to a remote processing location.

MCM Analyzer: A Fuzzy Logic-based Ofﬂoading Decision Trade-off for Mobile Cloud Computing

181

This, in turn, will probably incur the need to resend

data, as well as demand more control by the

transmission protocol, consequently increasing

energy consumption (Jung et. al. 2012).

Network Type: This is another important variable

for our decision. Mobile networks such as 3G and

4G may compromise data transmission when

compared to a generally more stable Wi-Fi

connection. In addition, the smartphone’s user may

choose whether those types of connection are

allowed or not. Finally, there is the monetary cost of

using such connections, depending on the carrier.

Network is Roaming: The importance of this

variable in our case is moderate. It is usually subject

to additional charges from the carrier.

Network Wi-Fi TX and Network Wi-Fi RX: Both

variables are relevant in choosing the processing

environment. They inform the number of bytes that

the monitored application sent and received via the

network. The use of the network infrastructure has a

direct impact on battery consumption.

PSS, Shared and Private Memory:

Although those variables are highly interrelated, we

did not find enough and meaningful information

from them that can be used for our decision tradeoff.

The values for the variables do not find influence on

information on energy consumption or connection

data.

The drawback of using too much memory locally is

that it supposedly increases the frequency of calls to

the garbage collector, which according to (Li et. al,

2013) implies significantly on resource usage and

also increases the execution time. Sending data to be

processed by the cloud could help in reducing such

cost as well as it helps in freeing memory. This

heuristic can be provided by looking at the Low

Memory Flag variable.

Available Memory: This is an important variable

for the decision. However, it is not included in the

decision heuristics because the Android API

(Application Programming Interface) informs that its

value should not be considered as an absolute value.

Due to the nature of the operating system’s kernel, a

significant portion of this amount is required for the

proper OS’s performance.

Low Memory Flag: This is a very important

variable for us, since it tells whether the system

finds itself in a state of low available memory.

Sending data for processing by the cloud is an

alternative because it tends to use fewer resources

and free memory.

Table 1: Sample rules from MCM Analyzer.

Rule

MCM

variable

Favor

local

proc.

Favor

remote

proc.

Device is charging

Battery Status X

Device is discharging Battery Status X

Antenna has weak

signal

Network

Signal Level

Antenna has medium

signal

Network

Signal Level

Antenna has strong

signal

Network

Signal Level

Battery charge is high Battery Level X

Battery charge is

medium

Battery Level X

Battery charge is low Battery Level X

Device is connected

to mobile network

Network

Type

Device is connected

to a Wi-Fi router

Network

Type

Device is roaming

Network is

Roaming

4 SOLVING THE OFFLOADING

TRADEOFF

We developed a set of heuristic rules that act on the

values of the acquired variables. Table 1 presents a

sample of the rules. As we can see, some rules use

conditions with constant values, while others present

conditions with some uncertainty. Such points of

uncertainty are written in italics in Table 1.

Additionally, rules have different levels of

significance and distinct levels of interdependence.

As an example, the third rule states that “if the

device has a weak antenna signal, then we should

favor the local processing of data” (the MCM

variable Network Signal Level provides that

information).

Table 2 presents part of the decision heuristics

we developed when dealing with the inherent

uncertainty of such type of information. The

uncertainty measurements are placed in the first

column and in the first row of the table, and the

corresponding value for each rule is presented by

combining both values.

Table 3 lists sample fuzzy rules for the local and

remote execution time variables. We compare the

local and the remote processing time by evaluating

the rate between the total processing time as a

function of the volume of processed data.

ICEIS 2016 - 18th International Conference on Enterprise Information Systems

182

Table 2: Fuzzy input and output variables and terms.

Fuzzy Variable

Input Terms Output Terms

Battery Level

Low Remote ++

Medium Remote +

High Local ++

Network Level

Low Local ++

Medium Remote +

High Remote ++

Network Connection

False Local ++

True Remote ++

Network Type

Mobile Local +

Wi-Fi Remote +

Network is Roaming

False Remote +

True Local +

Battery Status

Not charging Remote +

Charging Local +

Memory is Low

False Local +

True Remote +

Figure 1: Interface of the testing application.

The output variables have the self-explanatory

terms Local-, Local--, Remote+ and Remote++.

Table 3: Fuzzy variables for the execution times.

Remote time

Local time

Short Medium Long

Short

Local + Local ++ Local ++

Medium

Remote + Remote + Local +

Long

Remote ++ Remote ++ Remote ++

In order to reassure our assumption that a fuzzy

logic-based solution is applicable to such cases, we

also developed a specific app that can be used to

experiment with the heuristics that compute the final

decision between processing the data locally or

remotely by the cloud infrastructure. The app

presents a user interface that allows the developer to

experiment with the input variables for the decision

system.

The application works on the input data, then

uses the fuzzy inference engine and outputs the

“Process Location” variable, which represents the

degree to which the system “favors” the local or the

remote processing of the data. By evaluating this

output value in the range 0 to 100, one could make

the final decision by applying some threshold

interval, for example. Figure 1 shows the main

interface of the app.

By experimenting with the testing app, the team

can perform tests in order to fine-tune their

heuristics for each particular case.

5 EXPERIMENTAL RESULTS

We ran our experiments in two distinct Android

smartphones: a Samsung Galaxy S3, 1.4 Ghz, 1 GiB

RAM, running Android 4.3 and a Motorola Moto X,

1.7 GHz, 2 GiB RAM, running Android 4.4.4.

In our experiments, we found some interesting

relations among the data collected by the MCM

module. Those relations are important because if we

find a correlation between two or more variables, it

means we can reduce the monitoring overhead by

leaving the dependent variables out of the sampling.

MCM Analyzer: A Fuzzy Logic-based Ofﬂoading Decision Trade-off for Mobile Cloud Computing

183

This is very important when profiling

applications in order to make decisions since all

profiling implies both a processing and a potential

memory overhead. Thus, by using less CPU cycles,

less memory and less battery resources, we can

minimize the computational footprint of the MCM

module.

As an example, if two variables are linearly

proportional, then it may be only necessary to collect

one of them in order to make a decision based on

their values. The testing application provides an easy

to use fuzzy inference engine that enables the

development team to try several combinations of

values for the input variables. It also provides a

convenient way to fine-tune the fuzzy inference

rules for the offloading decision to a particular case.

6 RELATED WORK

During the development of this research, we found

other works and applications already available with

similar functions and ideas of MCM. We observed,

however, that much of such initiatives were only

intended for application debugging purposes (before

the application was made available to the public)

and not for real time execution scenarios as in our

case. Two examples of such initiatives are

DevScope and the Android SDK’s Dalvik Debug

Monitor Service (DDMS) (Jung et. al, 2012)

(Google, 2015).

Some other initiatives are Qualcomm’s Trepn

Profiler (Qualcomm, 2015), and AppScope (Yoon,

2012). However, those profiling modules do not

focus on getting hardware specific information for

the running application but only for the device as a

whole. Such specific information cannot be obtained

via API calls because they are only available when

debugging is active.

AppScope and DevScope, in particular, focus on

the development of an energy model of the mobile

device. An energy model is a framework based on

mathematical calculations for estimating energy

expenditure of the main hardware components of a

device and therefore the total expenditure power of

the device. According to the authors, this technique

allows for a decision-making process based on

energy expenditure of certain components, as well as

the system altogether. In addition, it is also possible

to estimate the remaining battery time. Among all

related work, Qualcomm’s Trepn Profiler

application is the one that most resembles Mobile

Cost Monitor.

Nevertheless, as stated previously, because the

offloading decision in mobile cloud computing

environments is often based on expert judgment, we

suggest using approaches that better deal with

uncertainty and yet provide convenient and suitable

decision mechanisms for such scenarios.

7 CONCLUSIONS

As a model that enables ubiquitous network access

to a pool of computing and networking services,

Cloud Computing provides computational resources

in an on-demand, pay-as-you-go manner through

minimal interaction with the service provider. This

sort of utility computing infrastructure offers a

scalable environment to store and also process large

amounts of data. A solution to the offloading trade-

off may benefit from a fuzzy logic-based approach.

This paper presented MCM and MCM Analyzer

modules, as well as our investigation of variables

and potential fuzzy logic rules to address this

decision. This work offers new insights that build on

top of our previous research (Callegari et. at., 2013).

We developed different Android applications and

running scenarios, compared them and performed

several experiments in order to attest its practicality.

We verified that MCM and the decision mechanism

represent a new approach to mobile cloud computing

solutions. The next steps involve improving our

solution by adding learning capabilities. MCM runs

on Android devices and it enables the collection of

several types of information that allow the technical

team to evaluate proper scenarios where a mobile

could computing solution is feasible or even

necessary.

REFERENCES

Callegari, D. A., Jersak, L. C., da Costa, A. C., 2013.

Technical Trends and Challenges in Mobile Health - A

Systematic Review of Recent Available Literature. In

Proceedings of the 15th International Conference on

Enterprise Information Systems.

Cox, E. D., 1995. Fuzzy Logic for Business and Industry.

Charles River Media.

Cuervo, E., Balasubramanian, A., Cho, D., Wolman, A.,

Saroiu, R. Chandra, R., Bahl, P. 2010. MAUI: making

smartphones last longer with code offload. In 8th

International Conference on Mobile Systems,

Applications, and Services.

Datta, S. K., Bonnet, C., Nikaein, N., 2013. Minimizing

energy expenditure in smart devices. In IEEE

Conference on Information and Communication

Technologies.

ICEIS 2016 - 18th International Conference on Enterprise Information Systems

184

Google Inc.. Android., 2015. Debugging using DDMS.

Available: http://developer.android.com/tools/

debugging/ddms.html.

Jung, W., Kang, C., Yoon, C., Kim, D., Cha, H., 2012.

DevScope: a nonintrusive and online power analysis

tool for smartphone hardware components. In.

Proceedings of the 8

IEEE/ACM/IFIP international

conference on Hardware/software codesign and

system synthesis.

Orsini, G., Bade, D., Lamersdorf, W., 2015. Context-

Aware Computation Offloading for Mobile Cloud

Computing: Requirements Analysis, Survey and

Design Guideline. In 12

International Converence on

Mobile Systems and Pervasive Computing.

Qualcomm Inc., 2015. Trepn Profiler. Available

https://developer.qualcomm.com/mobile-

development/increase-app-performance/trepn-profiler.

Sharkey, J., 2009. Coding for Life - Battery Life, That Is,

Google I/O. Available: https://dl.google.com/io/2009/

pres/W_0300_CodingforLife-BatteryLifeThatIs.pdf.

Shiraz, M., Gani, A., Khokhar, R., Buyya, R., 2013. A

Review on Distributed Application Processing

Frameworks in Smart Mobile Devices for Mobile

Cloud Computing. In IEEE Communications Surveys

& Tutorials, vol. 15, no. 3.

Yoon, C., Kim, D., Jung, W., Kang, C., Cha, H., 2012.

AppScope: application energy metering framework for

android smartphones using kernel activity monitoring.

In Proceedings of the 2012 USENIX conference on

Annual Technical Conference.

Zadeh, L. A., 1965. Fuzzy sets. Information and Control.

8:338-53.

MCM Analyzer: A Fuzzy Logic-based Ofﬂoading Decision Trade-off for Mobile Cloud Computing

185
