Topological Functioning Model for Software Development within

MDA (Survey)

Arturs Solomencevs

Department of Applied Computer Science, Riga Technical University, Riga, Latvia

Keywords: Topological Functioning Model, Software Development, Formal Problem Domain Model, Model Driven

Architecture.

Abstract: The approach called Topological Functioning Modeling for Model Driven Architecture (TFM4MDA) uses

Topological Functioning Model (TFM) as a formal holistic problem domain model. The approach is

revolutionary, because it brings formalism to the earliest stages of software development – the analysis of

problem domain, and provides formal transformations to UML design models. A copious amount of effort

has been put into the development of TFM4MDA. Furthermore, TFM has not always been used in software

development. This paper represents a literature survey of 69 articles about TFM and its application. The

goal of this work is to trace the research of TFM and TFM4MDA approach, to throw light on the results of

the research, and to reveal some weaker areas of it. The goal is successfully achieved and the conclusions

are made.

1 INTRODUCTION

In (Osis, 2004), it is stated that object orientation has

become the dominate approach to the analysis and

design of computerized systems. The Unified

Modeling Language (UML) defines the industry-

standard modeling notation for object-oriented

software development. There are two fundamental

aspects to modeling: analysis, which defines what

the application has to do with the problem domain to

fit the customer’s requirements, and design, which

defines how the application will be built.

The problem domain is the part of the world in

which the software is required to bring about some

effect desired by the customer, as it is described in

(Osis, 2003b). The application domain is the

software we build and the computer system that

executes it. During the analysis and the design, both

domains are modeled.

In paper (Osis, 2003a), it is asserted that

modeling a problem domain brings essential

advantages into software development. A proper

problem domain model provides a powerful

language for expressing requirements for the system.

A precise problem domain model gives a precise

architectural (application domain) model. Author of

(Osis, 2001 b) claims that the stability of software

architecture depends on the adequacy of problem

domain model. In (Alksnis et al., 2005), it is proven

that it is beneficial to model a problem domain

formally. A formal model can be transformed into

another model if the transformation rules are

defined. For instance, a model which is a product of

system analysis can be transformed into a model of

system design. Also, formal design implies that the

correctness of operation of the entire system is

mathematically proven.

Unfortunately, as it is stated in (Osis, 2001e),

UML and its application have some relevant

drawbacks: 1) Use case driven object-oriented

methods give low priority to problem domain

modelling. Analyzing starts with application

domain. In this case, problem domain is considered

to be a “black box”. 2) Even when use cases are

applied for business modeling, relationship between

a business system and a planned computerized one

remain informal as well as identification of business

and system use cases themselves (Asnina, 2006). 3)

Diagrams (models) are constructed without a formal

basis (Osis, 2001e). 4) UML goes without

mathematics (Asnina and Osis, 2002).

Author of (Osis, 2003a) claims that the

improvement of the results of object-oriented system

analysis and modeling lies in using methods which

are oriented to deal with problem domain, because

the formalism must be involved on the very early

Solomencevs, A.

Topological Functioning Model for Software Development within MDA (Survey).

In Proceedings of the 11th International Conference on Evaluation of Novel Software Approaches to Software Engineering (ENASE 2016), pages 315-326

ISBN: 978-989-758-189-2

315

stage of software development. Until 2003, a more

or less formal way to map the knowledge about the

problem domain into software development process

did not exist.

Janis Osis from Riga Technical University

invented Topological Functioning Model (TFM). Its

theoretical fundamentals are published in (Osis,

1969). TFM is a formal model which describes the

functioning of a system. TFM has a solid

mathematical base. It is represented in a form of a

topological space (X, Θ), where X is a finite set of

functional features of the system under

consideration, and Θ is topology that satisfies

axioms of topological structures and is represented

in a form of a directed graph. The TFM’s functional

features describe the system’s physical or biological

characteristics that are relevant for the normal

functioning of the system. The TFM’s topology

consists of cause-effect relations between functional

features. Cause-effect relation exists between two

functional features, if appearance of one functional

feature is caused by appearance of the other without

participation of any intermediate functional feature.

Cause-effect relations form causal chains. Causal

chains must form at least one functioning cycle

within TFM. All the cycles and subcycles should be

carefully analyzed in order to completely identify

existing functionality of the system.

The idea of applying TFM in object-oriented

software engineering was published in (Osis,

2001b), and has been developed since then. It is the

first milestone in the development of TFM.

Researchers who made contributions to the TFM

approach are: J. Osis (the leader), E. Asnina, U.

Donins, A. Slihte, G. Alksnis, J. Silins and others.

Vast amount of work has been put into the research

of TFM and its application. The purpose of this

paper is to review the approach and its development

during the passage of time. This will throw light on

the results of the research, and will reveal weaker

areas which may need to be worked with. To

achieve the goal, 69 papers were studied.

2 THE BEGINNING OF

RESEARCH ON TFM

In papers (Osis, 2001a) and (Osis, 2001e), the

development of TFM’s theory is reviewed. In 1964,

associate professor J. Osis at Riga Technical

Universty begins the development of theoretical

basis for diagnostics of complex systems. He also

formed a scientific group. Since 1966, J Osis’s PhD

students have published oriented graph models in

their works. The final theoretical fundamentals of

TFM were published in (Osis, 1969).

In the beginning, TFM was not meant to be used

in software development. By studying papers (Osis,

1972), (Gelfandbain et al., 1990) and (Osis et al.,

1991) it becomes clear that topological modeling can

be used for diagnostics of complex systems. TFM

can also be applied in technical and medical

diagnostics, in image recognition and in expert

systems (Osis, 1991); in modeling of biological

systems (Osis and Beghi, 1997); and in business

process modeling and simulation (Osis et al., 1997).

In paper (Ivasiuta and Osis, 1999), methods for

comparing software design methodologies are

reviewed.

Paper (Osis et al., 1996) is the first article about

object-oriented approach that concerns TFM. In the

paper, object-oriented modeling and simulation are

discussed.

In paper (Osis, 1997), the development of object-

oriented methods for hybrid system analysis and

design is described.

The relation between domain modeling and

architectural design is discussed in paper (Osis, 2001

b). Precise domain model gives precise architectural

model. Stability of information system depends on

the structure of problem domain. Thus, full

knowledge about structure helps to minimize the risk

of losing the stability.

Paper (Osis, 2001c) represents a survey of

object-oriented approach. It was found that

historically the idea that the world could be viewed

either in terms of objects or processes comes from

ancient philosophy and cognitive science and was an

ancient Greek invention. In the seventeenth century

Descartes declared that humans naturally apply an

object-oriented view of the world. Analysis and

software development methods are reviewed in the

paper. Lack of formal basis for object-oriented

modeling is discussed. The tendency of giving low

priority to problem domain analysis in use case

driven methods is disputed. The way to improve

results of object-oriented system analysis and

modelling lies in using formal methods which are

oriented to deal with problem domain. In paper,

topological modeling is mentioned as an approach

for problem domain driven analysis. TFM supports

abstraction and decomposition – two fundamental

ways of dealing with system’s complexity. Thus, it

is possible to model complex systems with TFM.

In paper (Osis, 2001d), the development of

object-oriented analysis is reviewed. It is stated that

TFM’s theoretical fundamentals give the opportunity

MDI4SE 2016 - Special Session on Model-Driven Innovations for Software Engineering

316

to get a strictly formalized model (TFM) from

knowledge about a system. The obtained software

architecture is adequate to problem domain.

The drawbacks of UML and its application are

discussed in (Osis, 2001e). TFM is considered to

overcome the mentioned disadvantages.

In papers (Alksnis and Osis, 2001) and (Alksnis

and Osis, 2002), the research about how category

theory can be applied in software development is

carried out. The structure of topological space and

TFM is very similar to the definition of category.

Paper (Osis and Silins, 2002) represents the

analysis of modeling languages and methods which

can be applied in development of embedded systems

(real-time systems in particular). The paper can be

considered to be an introduction to applying TFM in

the development of embedded systems. However,

TFM is not mentioned in the article.

In paper (Asnina and Osis, 2002), UML

formalization possibilities using mechanisms of both

universal arrow logic and topological modeling are

described. Both approaches have strict mathematical

basis – category theory. Formalization possibilities

of the universal arrow logic and topological

modeling are compared. TFM has an advantage over

arrow logic, i.e., the operation of isolating the

system from its topological space is formally defined

– closure operation (Osis, 1969).

Paper (Nahimova and Osis, 2002) reviews the

methods of modeling the mechatronic systems. TFM

is mentioned as an approach that has advantage in

modeling complex systems.

In paper (Osis, 2003a), the approach of using

topological modeling for development of

mechatronic and embedded systems is introduced.

Paper (Osis, 2003b) introduces topological modeling

for software engineering (TFM4SE) approach. It is

stated that only a proper problem domain model

provides a powerful language for expressing

requirements to the system (Osis, 2003a), (Osis,

2003b). The construction of conceptual class

diagram from TFM is defined. At this point, this

model transformation is rather primitive, and is

developed in future research. The joining operation

of two TFMs is represented (Osis, 2003b).

3 TFM4MDA

Model Driven Architecture (MDA) is an approach to

system development, which increases the power of

models in this work. The purpose of MDA is to

separate the views and concerns. MDA has three

viewpoints and their corresponding models: a

computation independent model (CIM) contains

knowledge about the problem domain and the

requirements for software system; platform

independent model (PIM) focuses on the operation

of a system while hiding the details necessary for a

particular platform; and platform specific model

(PSM) (Miller and Mukerji, 2003). Model

transformation forms a key part of MDA. To get the

software source code we need to go by the path CIM

→ PIM → PSM → source code.

Paper (Osis, 2004) introduces topological

modeling for MDA. In the framework of MDA,

TFM is used as a formal CIM (computation

independent model). It is the first milestone in the

development of TFM4SE. TFM for MDA is

considered to be a subfield of TFM4SE.

The research about application of formal

methods in development of embedded systems

continues in (Alksnis et al., 2005). Topological

modeling is included in these methods.

The idea of connecting MDA with software

synthesis (code generation by applying artificial

intelligence) is published in (Birgelis and Osis,

2005).

Papers (Osis, 2006a) and (Osis, 2006b) introduce

novelties to TFM and MDA. TFM has systematic

approach for checking its completeness and non-

controversy (use case model, in its turn, does not

have such an approach). TFM topological

characteristics – connectedness, closure,

neighborhood and continuous mapping – form

mathematical background of TFM. TFM functional

characteristics – inputs, outputs, cycle structure and

cause-effect relations – form system theoretical

background of the model. Thanks to these

characteristics, TFM captures two aspects of the

system – structure and dynamics. Modified MDA

software development life cycle with a formal CIM

– TFM – is introduced. In this cycle, feedback from

the code deployment is not directed to the analysis

phase like in the traditional life cycle, but to the

TFM. Finally, the first metamodeling architecture is

published. In this architecture, TFM is on M0 layer

and UML Class diagram is on M1 layer.

In paper (Osis, 2006c), new metamodeling

architecture is defined. Author emphasizes the

importance of formalism in models, since formalized

transformation can be automated.

A formal method of TFM constructing from a

system’s verbal description is given in (Asnina and

Osis, 2006). This is an important milestone in the

development of TFM4SE. A form for expressing

TFM’s functional features is defined:

Topological Functioning Model for Software Development within MDA (Survey)

317

[to, into, in, by, of, from] a(n) <object>

e.g., Receiving the book from a reader.

The set of functional features should be written

down in the following form:

e.g., Registering a reader.

Paper (Asnina, 2006) introduces the mapping of

functional requirements (to planned information

system) onto TFM’s functional features. Mapping of

requirements makes it possible to validate them in

conformance to the business logic of the real world

system as early as possible. During the mapping,

TFM or (and) the list of requirements may need to

be modified. The modified TFM represents the

problem domain which is supported by the planned

information system. Between requirements and a

TFM the following mappings types exist: One to

One; Many to One; One to Many; One to Zero; Zero

to One; Zero to Many. Mapping types are explained

in the article’s text. For example, the existence of

Zero to Many mapping may indicate that some

requirement(s) is (are) missing. The paper also

describes the algorithm for getting a use case

diagram from TFM. By mapping requirements onto

TFM and by creating use cases from TFM, it is

possible to get an application domain model that

conforms to problem domain knowledge.

In papers (Osis et al., 2007a) and (Osis et al.,

2007b) TFM for MDA approach is called

TFMfMDA. Papers introduce the explicit separation

between problem domain and application domain.

This is an important milestone in the development of

TFM4SE. It is emphasized that functionality

determines the structure of the planned system. TFM

holistically represents complete functionality of the

system. In papers, the mapping of requirements onto

TFM and creation of use cases from TFM are

developed further. The transformation “TFM →

Graph of domain objects → Conceptual class

diagram” is defined. Elements precondition, the

responsible entity and subordination (“in” is inner,

“ex” is external) are added to the expressing form of

functional feature. Example:

Creating of a reader account, {unregistered person},

librarian, in.

Also, papers describe the requirements for a

software tool for TFMfMDA automation. Thus, a

new field of research – the development of tool

support for the approach – is opened.

Papers (Osis et al., 2007c) and (Osis and Asnina,

2008a) introduce more formal way for describing a

functional feature – a 5-tuple:

<A, R, O, PrCond, E>,

where A is an object action, R is a result of this

action, O is an object(s) that receives the result or

that is used in this action, PrCond is a set

preconditions or atomic business rules (optional

parameter), and E is an entity responsible for

performing actions. The fields – mapping of

requirements onto TFM; use case and conceptual

class diagram creation from TFM – find further

development in the papers. Also, a new

transformation is defined “TFM → UML Activity

diagram”. Later, this transformation will be

considered to be imprecise, and will be improved.

The MOF-based metamodel of TFMfMDA is

introduced. Also, the newest metamodeling

architecture for TFMfMDA is published. This is a

very important milestone in the development of

TFM4SE. The architecture is not included because

of space limits.

In papers (Asnina and Osis, 2008) and (Asnina et

al., 2008) analysis and modeling of multifractal

system properties in object-oriented software

development is described. However, the papers do

not specify the relation of this field with topological

modeling.

Articles (Osis et al., 2008 a) and (Osis et al.,

2008 b) give more detailed requirements for tool

support for TFMfMDA approach.

In paper (Osis and Asnina, 2008b), new

attributes are added to the tuple which describes a

functional feature of TFM:

<A, R, O, PrCond, PostCond, E, S>,

where PostCond is a set of post-conditions (an

optional element), and S is functional feature’s

belonging (subordination) to system’s functionality

(inner or external). Mapping of requirements onto

TFM is developed further – the description of

mapping type “One to Zero” is specified more

precisely. Terms “source TFM” and “target TFM”

are defined. Source TFM is a product of analyzing

the problem domain. Target TFM is an output of

mapping of requirements onto the functional

features of TFM. Mapping ensures that target TFM

is in compliance with source TFM.

4 TopUML

The intention to create an extension of UML named

“Topological Unified Modeling Language” is

expressed in paper (Osis, 2003a). The main motive

is to introduce mathematical formalism into UML

MDI4SE 2016 - Special Session on Model-Driven Innovations for Software Engineering

318

diagrams. On the other hand, further refinement of

TFM is required. It should be noted as the first

milestone in the development of TopUML. The aim

of “TopUML” research is to create a new version of

UML that can be applied in a formal way which

allows clearly tracing cause-and-effect relationships

between the problem and solution domains. Solution

domain is a system (e.g., business system) which is

supported by the planned information system. To

achieve this goal a new language is developed –

Topological Unified Modeling Language (TopUML)

– and its supporting software development method –

TopUML modeling. TopUML is considered to be a

research subfield of TFM4SE. In this subsection,

articles which relate to TopUML are reviewed. The

chief researcher is U. Donins, and his supervisor is J.

Osis.

The main goal of papers (Osis and Donins,

2009a), (Donins and Osis, 2009), (Osis and Donins,

2009b), (Donins, 2010) and (Osis and Donins,

2010a) is to bring formalism into UML Class

diagram, and to introduce a formal approach for

creating a UML Class diagram that conforms to the

“target” TFM. The creation of conceptual class

diagram from TFM, which is described in (Osis and

Asnina, 2008a), is disputed, because the topology

between the classes is not retained. Therefore,

topological relations between classes are defined.

Topological relations are not included in OMG

UML standard. Thus, topological (TopUML) class

diagram, which contains topological relations, is

defined. Transformation “TFM → Graph of domain

objects → Topological class diagram” is introduced

in the papers. New attributes are added to the

functional feature tuple:

<A, R, O, PrCond, PostCond, E, Cl, Op>,

where Cl is a class and Op is an operation. These

new attributes are used in the creation of graph of

domain objects from TFM. Also, S (subordination)

attribute of the tuple is not used in these papers.

Paper (Osis and Donins, 2010b) describes OMG

MOF-compatible metamodel of Topological class

diagram. This metamodel is needed to create the

UML profile for Topological class diagram, which is

proposed in the paper. This is a very important

milestone in the development of TFM4SE.

In paper (Donins et al., 2011), refinement

process of Topological class diagram is presented.

The goal of this process is to lower the abstraction

level of the initial Topological class diagram which

is obtained from the TFM. Formal and informal

guidelines for the refinement are given.

Paper (Donins and Osis, 2011) introduces

transformation “TFM → Graph of domain objects

→ UML Sequence diagram”. Separate sequence

diagram is obtained for each system goal and

requirement. Also, a case study of applying

topological modelling approach to information

system development is shown.

The research in (Donins, 2012a) introduces new

element to TFM – logical relations. The analysis of

logical relations helps to identify topological

relations in TFM. Also, it helps to verify the

consistency of TFM. Logical relations are needed

for transformation of TFM into other models. In

paper, an improved transformation “TFM → UML

Activity diagram” is defined. This transformation,

thanks to logical relations, gives a more precise

output than the one defined in (Osis et al., 2007c).

Formal definitions with tuples are given for the

following TFM elements: preconditions,

postconditions, topological and logical relationships.

The tuples and their descriptions are not included

because of limited space of this survey.

Transformation “TFM → UML Communication

diagram → Topological class diagram” is defined in

(Donins et al., 2012a) and (Donins et al., 2012b). So,

in the transformation from TFM to Topological class

diagram, communication diagram or graph of

domain objects can be used as intermediate model

(see article (Osis and Donins, 2009a)). Another

transformation – “TFM → set of State diagrams” –

is defined. One State diagram is obtained for each

class. State diagrams give opportunity to analyze

event-driven software systems. New attributes are

added to the functional feature tuple:

<A, R, O, PrCond, PostCond, E, S, Cl, Op, St, Es>,

where St – new state of object O after performing

action A (optional, needed for transformation to

State diagrams), Es - indicates if execution of action

A could be automated.

Paper (Osis et al., 2014) summarizes the research

results of TopUML and U. Donins’s PhD thesis

(Donins, 2012b). TopUML allows creating the most

popular UML design models from TFM. Some

models are obtained successively, i.e., using an

intermediate model. For example, at first one needs

to obtain a Communication diagram from TFM, and

only then – a Topological class diagram. All

transitions between TFM and TopUML diagrams

can be found in paper (Osis et al., 2014), in Section

IV.B. Also, the paper’s research explores traceability

of modeling artifacts - from functioning properties

and functional requirements of the problem domain

to the software design and development artifacts.

Topological Functioning Model for Software Development within MDA (Survey)

319

The trace links are set by the mentioned transitions

between diagrams.

TFM approach concentrates on formal analysis

of problem domain. The output of this analysis is a

“target” TFM. TopUML allows getting the most

needed design models that conform to TFM (Osis et

al., 2014). Thus, topological modeling together with

TopUML application covers both analysis and

design of the planned information system. Author of

the survey feels that TopUML could become more

useful if tool support was developed for it, i.e.,

formal transformations between models can and

should be automated for higher efficiency of the

approach. Also, no research has been done on the

application of TopUML for platform independent

viewpoint transformation into platform specific

viewpoint and generating software code.

5 IDM APPROACH

The Integrated Domain Modeling (IDM) is a

research subfield of TFM4SE. The aim of this

research is to find a way of formalizing the

knowledge about business system, and to get TFM

from this knowledge. In addition, tool support is

developed for IDM approach. In this subsection,

articles which relate to IDM approach are reviewed.

The chief researcher is A. Slihte, and his supervisor

is J. Osis.

Paper (Slihte, 2009) concentrates on

development of a software tool for TFM

construction. For this purpose, MOF-compatible

metamodel of TFM is introduced, and it is used by

the tool. Tool prototype is developed. It allows

manually creating a TFM. This is an important

milestone in the development of TFM4SE. In the

paper, for the first time TFM for MDA approach is

called “TFM4MDA”. This name is used nowadays.

In papers (Slihte, 2010) and (Osis and Slihte,

2010), an approach for automatic creation of TFM

from the knowledge about a system is proposed (not

yet developed). The knowledge is represented by

business use cases – a formal data structure that can

be processed automatically. A proposal to use

natural language processing to analyze sentences of

business use cases is made. This way, functional

features are obtained. Although, not all attributes of

functional feature tuple can be obtained

automatically – only action (A), object (O), result

(R) and preconditions (PrCond). By analyzing

business use cases, it is possible to obtain topology

of TFM. However, some cause-effect relations

(elements of TFM’s topology) need to be added

manually. To sum up, the process of getting TFM

from business use cases can be automated, but it

requires minor interaction with system analyst.

In order to make business use cases

“understandable” for computer, the step sentences

are defined using a controlled natural language. In

particular, Attempto Controlled English is used

(Slihte et al., 2011). However, there are some

problems with business use cases: 1) ambiguity, e.g.,

possibility to express the same meaning using

different words; 2) inconsistency of business use

cases, i.e., there might be steps defined that do not

make sense in the given business system. To solve

these problems, it is proposed to use ontology.

Ontologies provide logical statements that describe

what terms are and how they are related to each

other. Ontology allows validation of procedural

knowledge about a system which is represented by

business use cases. Ontology and use cases need to

be modified iteratively until they correspond. Then,

it is possible to construct a TFM. Nevertheless, TFM

also has to be validated. If any changes are

necessary, they will have to be done in the ontology

and business use cases, and then the TFM can be

regenerated.

Paper (Slihte et al., 2011) reviews declarative

and procedural knowledge. To represent declarative

knowledge ontology is used, and to represent

procedural knowledge – business use cases are

applied. Paper also reviews technical opportunities

of mapping the knowledge. Ontology can be

developed using OWL standard. Attempto Controlled

English for business use cases is mentioned in

(Slihte et al., 2011). Attempto Parsing Engine can be

used for natural language processing.

In paper (Osis et al., 2012), MOF-compatible

metamodel of business use cases is introduced. A

tool that uses this metamodel and allows

constructing business use case model is developed.

Paper (Slihte and Osis, 2014) gives a name for an

approach that is reviewed in this subsection: the

Integrated Domain Modeling (IDM). In paper, a case

of successful application of IDM approach in real

business project is studied. A tool for automatic

transformation “Business use cases → TFM” is

developed. IDM approach is published in A. Slihte’s

PhD thesis (Slihte, 2015). This is a very important

milestone in the development of TFM4SE.

To sum up, IDM approach concentrates on pre-

CIM analysis, and also introduces formalism to this

early stage of software development. The approach

provides theory and toolset for obtaining TFM

(which is a formal CIM in MDA framework) from

the formalized knowledge about a business system.

MDI4SE 2016 - Special Session on Model-Driven Innovations for Software Engineering

320

The toolset allows creating business use case model,

creating ontology, creating TFM (manually), and

automatically obtaining TFM from business use

cases. Nevertheless, author of this survey sees a gap

in functionality of the mentioned toolset –

correspondence between ontology and business use

cases is not validated automatically.

6 FURTHER DEVELOPMENT OF

TOPOLOGICAL MODELING

Paper (Osis and Silins, 2009) introduces an approach

for development of embedded systems. It combines

principles of co-design and MDA. Name of the

approach is “Topological Function – Architecture

Co-Design”.

Research in paper (Asnina and Osis, 2010)

concentrates on bridging problem and solution

domains. As before, TFM is used as a formal

bridging mechanism. Paper introduces new names

for TFM types: “as is” TFM – TFM of problem

domain; 2) “to be” TFM – TFM of solution domain;

3) TFM of information system. Information system

is a subsystem of solution domain. Hence, TFM of

information system can be separated from TFM of

solution domain with closure operation. Compliance

between a problem domain and a solution domain is

proved if continuous mapping between “as-is” TFM

and “to-be” TFM is in place. Likewise, continuous

mapping must be kept between “to-be” TFM and

TFM of information system. (Closure operation and

continuous mapping are fundamentals of TFM (Osis,

1969).)

In paper (Osis and Asnina, 2011a), authors

reason about the state of software development.

They share with some other experts, e.g., C. Jones,

the opinion that the way software is built is

primitive. To become better, software development

must turn into software engineering. The word

“engineering” intends a theory approved, completely

realized and reused many times in practice that gives

a qualitative and relatively inexpensive end product

in accurately predictable timeframes. In order to

satisfy high effectiveness and quality of the software

development we need Theory Driven Architecture

and Scientific Software Engineering. Paper’s title is

“Is Modeling a Treatment for the Weakness of

Software Engineering?” The answer is positive, but

if and only if modeling is based on mathematical

formalism from the very beginning of software

development process.

An engineering model should satisfy five key

characteristics: abstraction, understandability,

accuracy, predictability and inexpensiveness, as it is

stated in (Osis and Asnina, 2011b). TFM satisfies

them. Thus, it is concluded that TFM is an

engineering model. TFM is compared to Petri nets in

the paper. Both models are formal. TFM has an

advantage over Petri nets – TFM is applicable in

modeling complex systems, while Petri nets as self-

sufficient model is not quite convenient.

In paper (Asnina and Osis, 2011), it is concluded

that CIM may include three main parts: 1) CIM –

Knowledge Model (or pre-CIM); 2) CIM – Business

Model; 3) CIM – Business Requirements for the

System. Within TFM4MDA: CIM – Knowledge

Model is informal verbal description of a system, or,

if IDM is used, it is Ontology with Business use

cases; CIM – Business Model is TFM; CIM –

Business Requirements for the System are Use cases

obtained from TFM. Also, informal guidelines of

how to derive business processes from TFM are

introduced in the paper.

Paper (Osis and Asnina, 2011c) describes

benefits and limitations of use case techniques. New

formal guidelines for obtaining use cases from TFM

are introduced.

Paper (Asnina et al., 2011) demonstrates the

establishment of formal trace links to real world

functional units and entities from user requirements

and analysis artifacts. These links show element

interdependence make the impact analysis more

thorough. Thanks to the formalism of TFM and to

formal transformations from TFM to other models, it

is possible to automate the mentioned tracing.

In TFM, the combinations of causes might exist

that are sufficient or both necessary and sufficient to

cause an appearance of the effect. To specify these

combinations, logic is introduced to TFM in (Asnina

et al., 2012). This approach of representing logic in

TFM is different to the one described in (Donins,

2012a), and serves different purpose. A formal

specification of TFM’s cause-effect relation is

introduced – a 4-tuple:

<C, E, N, S>,

where C is a cause functional feature, E is an effect

functional feature, N is the necessity of the

functional feature C for generating the functional

feature E, and S is sufficiency of C

for generating E.

There was no formal specification for cause-effect

relation before. In addition, logical operators are

introduced: conjunction (AND), disjunction (OR,

XOR) and negation (

¬).

Topological Functioning Model for Software Development within MDA (Survey)

321

In paper (Asnina et al., 2013), an attribute is

added to the tuple that specifies cause-effect

relation:

<C, E, N, S, Refs>,

where Refs (references) is a set of unique tuples

<Ref_Ids, LOp>, where LOp is a logical operation

(e.g., AND, OR), and Ref_Ids is a set of tuples <C*,

E*> of cause-and-effect relations (<C, E> is not

equal to <C*, E*>) that participate in logical

operation LOp together. Also, paper introduces

transformation “TFM → UML Activity diagram”.

This transformation, thanks to integrated logic, is

more precise than the one defined in (Osis et al.,

2007c). This transformation is an alternative to the

one that is proposed in (Donins, 2012a), that uses

logical relations instead of cause-effect relations

specified by tuple <C, E, N, S, Refs>.

In paper (Asnina and Ovcinnikova, 2015), formal

specifications of TFM elements are refined. Refs

attribute is removed from the cause-and-effect

specification. New tuple that describes cause-effect

relation:

< ID, X

, X

, N, S>,

where ID is a unique identifier of a relation, X

is a

cause functional feature, and X

is an effect

functional feature. So it is quite the same as it was

defined in (Asnina et al., 2012). The exclusion of

Refs attribute leads to moving logical combination to

the definition of functional feature. New tuple that

describes functional feature:

< A, R, O, PrCond, PostCond, Pr, Ex, InRel,

OutRel>,

where InRel determines combinations of possible

logical relations among incoming cause-effect

relations, and OutRel – among outgoing cause-effect

relations. Pr and Ex are also new attributes, but are

not important in the context of logical combinations.

Pr is a set of responsible entities (systems or

subsystems) which provide or suggest the action

with the set of certain objects. Ex is a set of

responsible entities which enact the action. Finally,

the specification of logical relation is given (same as

in (Donins, 2012a)):

< ID, T, R

where ID is a unique identifier of a relation, T is a

set of cause-effect relations that participate in this

logical relation, and R

is a logical operator AND,

OR, or XOR over T. So paper (Asnina and

Ovcinnikova, 2015) contains all newest formal

definitions of TFM elements. In addition, the

research of the paper tries to find a mechanism for

specifying business rules that would be appropriate

for TFM. The conclusion is made that the best

option is Decision Model and Notation – a standard

proposed by the OMG for business process

modelling. Nevertheless, the result of the research

needs to be validated for cases where systems have

the complex behavior.

Paper (Osis and Asnina, 2015) supplements

paper (Osis and Asnina, 2011a). Software

Engineering Method and Theory (SEMAT) group is

described in more detail. This group supports a

principle to base software engineering on a solid

theory and best practices. The idea is to create a

solid theory that is a basis for the Kernel language

that formalizes different software development

methods. The Kernel language is being created as an

OMG standard.

7 CONCLUSION

In this paper, the development of topological

modeling for software development was reviewed.

Since 2004, TFM is used as a computation

independent model in the framework of MDA.

TFM4MDA approach – its theoretical basis, tool

support and cogency of usefulness for software

development – is a result of the reviewed research.

TFM4SE, including TopUML application and

IDM approach, covers both analysis and design of

the planned information system. IDM introduces

formalism to the pre-CIM analysis. TopUML

supports the obtaining of design models on PIM and

PSM levels that conform to the formal CIM – TFM.

Author derives the subfields of topological

modeling that were researched: Theoretical basis of

TFM; Theory to ensure compliance between

problem domain and solution domain; Mapping of

requirements onto TFM; Development of

mechatronic and embedded systems; Metamodeling;

Model Driven Architecture; Construction of problem

domain model from knowledge about the system;

Obtaining UML diagrams from TFM; Modeling of

business processes; Tool support for the approach.

For all mentioned subfields, author of the survey

does not see any significant lacks or contradictions

in the developed theory. The reviewed articles

successfully expose the theory. However, TFM4SE

lacks tool support. There are unimplemented

possibilities of automation: 1) validation of

correspondence between ontology and business use

cases in IDM; 2) formal transformations between

models in TopUML; 3) tracing from analysis

artifacts to real world functional units and entities.

MDI4SE 2016 - Special Session on Model-Driven Innovations for Software Engineering

322

The supporting tool would make the approach more

efficient. Thus, development of tool may be one of

the directions of future work.

TFM4MDA does not cover the transformation of

design models on PIM level to models on PSM

level. This also might be a direction for future

research.

Overall, author thinks that TFM4SE is ready to

be used in industry as an approach of software

development. Author believes that TFM is cogent.

REFERENCES

Alksnis, G., Asnina, E., Osis, J., Silins, J. 2005,

Formalization of Software Development: Problems

and Solutions. In: Applied computer systems. Volume

22, pp.204-216. ISSN 1407-7493.

Alksnis, G., Osis, J. 2002, Formalization of Software

Engineering by Means of the Theory of Categories. In:

Scientific Proceedings of Riga Technical University.

Series – Computer Science (5), Volume 13, Riga,

RTU, pp. 157-163.

Alksnis, G., Osis, Ya. 2001, Category Theory and

Computer Science. In: Computer Science, Applied

Computer Systems, Series – Computer Science (5),

Vol. 8, Scientific Proceedings of Riga Technical

University, Riga, pp. 59-67.

Asnina, E. 2006, The Formal Approach to Problem

Domain Modelling Within Model Driven

Architecture. In: Proceedings of the 9th International

Conference on Information Systems Implementation

and Modelling (ISIM’06), Czech Republic, Přerov, 25-

26 April, 2006. Ostrava: Jan Štefan MARQ, pp.97-

104. ISBN 80-86840-19-0.

Asnina, E., Gulbis, B., Osis, J., Alksnis, G., Donins, U.,

Slihte, A. 2011, Backward Requirements Traceability

within the Topology-based Model Driven Software

Development. In: Proceedings of the 3rd International

Workshop on Model-Driven Architecture and

Modeling-Driven Software Development (MDA &

MDSD 2011), China, Beijing, 7-11 June, 2011.

Lisbon: SciTePress, pp.36-45. ISBN 9789898425591.

Asnina, E., Osis, J. 2002, Formalization Problems and

Perspectives of the Program Development (in

Latvian). In: Scientific Proceedings of Riga Technical

University. Series – Computer Science (5), Volume

13, Riga, RTU, pp. 145-156.

Asnina, E., Osis, J. 2006, The Computation Independent

Viewpoint: a Formal Method of Topological

Functioning Model Constructing. In: Applied

computer systems. Vol.26, pp.21-32. ISSN 1407-7493.

Asnina, E., Osis, J. 2008, Analysis of Multifractal System

Properties in Object-Oriented Software Development.

In: Applied computer systems. Vol.34, pp.37-45. ISSN

1407-7493.

Asnina, E., Osis, J. 2010, Computation Independent

Models: Bridging Problem and Solution Domains. In:

Proceedings of the 2nd InternationalWorkshop on

Model-Driven Architecture and Modeling Theory-

Driven Development (MDA & MTDD 2010), in

conjunction with ENASE 2010, Greece, Athens, 22-24

July, 2010. Lisbon: SciTePress, pp.23-32. ISBN

9789898425164.

Asnina, E., Osis, J. 2011, Topological Functioning Model

as a CIM-Business Model. In: Model-Driven Domain

Analysis and Software Development: Architectures

and Functions. IGI Global, Hershey - New York, pp.

40 – 64. Available from: doi: 10.4018/978-1-61692-

874-2.ch003

Asnina, E., Osis, J., Jansone, A. 2012, System Thinking

for Formal Analysis of Domain Functioning in the

Computation Independent Model. In: Proceedings of

the 7th International Conference on Evaluation of

Novel Approaches to Software Engineering (ENASE

2012), Poland, Wrocław, 29-30 June, 2012. Lisbon:

SciTePress, pp.232-240. ISBN 9789898565136.

Asnina, E., Osis, J., Jansone, A. 2013, Formal

Specifications of Topological Relations. In: Databases

and Information Systems VII: Selected Papers from

the Tenth International Baltic Conference (DB&IS

2012), Lithuania, Vilnius, 8-11 July, 2012.

Amsterdam: IOS Press, pp.175-188. ISBN 978-1-

61499-160-1. e-ISBN 978-1-61499-161-8. Available

from: doi:10.3233/978-1-61499-161-8-175

Asnina, E., Osis, J., Kirikova, M. 2008, Design of Fractal-

Based Systems Within MDA: Platform Independent

Modelling. In: Proceedings of the Third AIS SIGSAND

European Symposium on Analysis, Design, Use and

Societal Impact of Information Systems (SIGSAND-

EUROPE 2008), Germany, Marburg, 12-13 June,

2008. Marburg: Koellen-Verlag, pp.39-53. ISBN 978-

3-88579-223-9. ISSN 1617-5468.

Asnina, E., Ovcinnikova, V. 2015, Specification of

Decision-making and Control Flow Branching in

Topological Functioning Models of Systems. In:

Proceedings of 10th International Conference on

Evaluaton of Novel Approaches to Software

Engineering, Spain, Barcelona, 29-30 April, 2015.

Portugal: SciTePress, pp.364-373. ISBN 978-989-758-

100-7.

Birgelis, J., Osis, J. 2005, Generalization of MDA and

Software Synthesis. In: Scientific Proceedings of Riga

Technical University. Series – Computer Science (5),

Volume 22, Riga, RTU, pp. 217-228.

Donins, U. 2010, Software Development with the

Emphasis on Topology. In: Advances in Databases

and Information Systems: Lecture Notes in Computer

Science. Volume 5968, Berlin: Springer Berlin

Heidelberg, pp. 220-228. ISBN 9783642120817.

Donins, U. 2012 a, Semantics of Logical Relations in

Topological Functioning Model. In: Proceedings of

the 7th International Conference on Evaluation of

Novel Approaches to Software Engineering (ENASE

2012), Poland, Wrocław, 29-30 June, 2012. Lisbon:

SciTePress, pp.217-223. ISBN 9789898565136.

Donins, U., Osis, J. 2009, Reconciling Software

Requirements and Architectures within MDA. In:

Topological Functioning Model for Software Development within MDA (Survey)

323

Applied computer systems. Volume 38, pp. 84-95.

ISSN 1407-7493.

Donins, U., Osis, J. 2011, Topological Modeling for

Enterprise Data Synchronization System: A Case

Study of Topological Model-Driven Software

Development. In: Proceedings of the 13th

International Conference on Enterprise Information

Systems. Vol.3, China, Beijing, 8-11 June, 2011.

Beijing: SciTePress, pp.87-96. ISBN 9789898425553.

Donins, U., Osis, J., Asnina, E., Jansone, A. 2012 a,

Formal Analysis of Objects State Changes and

Transitions. In: Proceedings of the 7th International

Conference on Evaluation of Novel Approaches to

Software Engineering (ENASE 2012), Poland,

Wrocław, 29-30 June, 2012. Lisbon: SciTePress,

pp.249-256. ISBN 9789898565136.

Donins, U., Osis, J., Asnina, E., Jansone, A. 2012 b, Using

Functional Characteristics to Analyze State Changes

of Objects. In: Databases and Information Systems.

Tenth International Baltic Conference on Databases

and Information Systems: Local Proceedings,

Materials of Doctoral Consortium, Lithuania, Vilnius,

8-11 July, 2012. Vilnius: Žara, pp.94-106. ISBN

9789986342748.

Donins, U., Osis, J., Slihte, A., Asnina, E., Gulbis, B.

2011, Towards the Refinement of Topological Class

Diagram as a Platform Independent Model. In:

Proceedings of the 3rd International Workshop on

Model-Driven Architecture and Modeling-Driven

Software Development (MDA & MDSD 2011), China,

Beijing, 8-11 June, 2011. Lisbon: SciTePress, pp.79-

88. ISBN 9789898425591.

Donins, Uldis. 2012 b, Topological Unified Modeling

Language: Development and Application. PhD Thesis.

Riga: [RTU]. 224 p.

Gelfandbain, J., Osis, J., Markovich, Z., Novozilova, N.

1990, Diagnostics on Graph Models (in Russian). In:

Proceedings of conference on gas turbine engines,

Moscow-Harkow, pp. 34 – 35.

Ivasiuta, O., Osis, J. 1999, Methodics to Comparing

Software Design Methodologies. In: Proc.of the 33rd

International Conference "Modelling and Simulation

of Systems" (MOSIS'99). Roznov pod Radhostem,

Czech Republi, V. ISM'99, pp. 67-74.

Miller, J., Mukerji, J. 2003, MDA Guide Version 1.0.1,

OMG, viewed 10 September 2015,

<http://www.omg.org/cgi-bin/doc?omg/03-06-01>

Nahimova, M., Osis, J. 2002, Specific Features of the

Modeling of Mechatronic Systems (in Latvian). In:

Scientific Proceedings of Riga Technical University.

Series – Computer Science (5), Volume 13, Riga,

RTU, pp. 181-189.

Osis, J. 1969, Topological Model of System Functioning

(in Russian). In: Automatics and Computer Science, J.

of Academia of Siences, Riga, Latvia, Nr. 6, pp. 44-50.

Osis, J. 1972, Diagnostics of Complex Systems (in

Russian). Summary of Habilitation Thesis, Latvian

Academy of Sciences, Riga, 56 p.

Osis, J. 1991, Topological Models in Technical and

Medical Diagnostics, in Image Recognition and in

Expert Systems in Latvia (in Latvian). In: World

Congress of Latvian Scientists, Vol. 5. Riga.

Osis, J. 1997, Development of Object-Oriented Methods

for Hybrid System Analysis and Design. In: Proceed.

of the 23rd Conference of the ASU. Stara Lesna,

Slovakia, pp. 162-170

Osis, J. 2001 a, RTU Scientific School of System

Modeling (in Latvian). In: Computer Science, Applied

Computer Systems, Series – Computer Science (5),

Vol. 8, Scientific Proceedings of Riga Technical

University, Riga, pp. 6-17.

Osis, J. 2001 b, What is the Precise Relationship between

Domain Modelling and Architectural Design and

Modelling? In: Proceedings of the 4th ECOOP

Workshop on Object-Oriented Architectural

Evolution, 15th ECOOP, Budapest, Hungary, 18–22

June, pp. 9-12.

Osis, J. 2001 c, Brief Survey of Object-Oriented

Approach. In: Computer Science, Applied Computer

Systems, Series – Computer Science (5), Vol. 8,

Scientific Proceedings of Riga Technical University,

Riga, pp. 23-32.

Osis, J. 2001 d, Object-Oriented System Analysis – Case

Processing or Construction of Formalism? (in

Latvian). In: Proceedings of Plenary session of the

2nd World Congress of Latvian Scientists, Riga, pp.

596.

Osis, J. 2001 e, RTU Scientific School of Modeling and

Studying of Complex Systems (in Latvian). In:

Proceedings of the 42nd International Conference of

Riga Technical University, Riga, RTU, pp. 38 – 40.

Osis, J. 2003 a, Extension of Software Development

Process for Mechatronic and Embedded Systems. In:

Proceedings of the 32nd International Conference on

Computers and Industrial Engineering, University of

Limerick, Ireland, 11 –13 August, pp. 305 – 310.

Osis, J. 2003 b, Topological Functioning Model Support

for Software Engineering. In: Scientific Proceedings of

Riga Technical University. Series – Computer Science

(5), Volume 17, Riga, RTU, pp. 31 – 42.

Osis, J. 2004, Software Development with Topological

Model in the Framework of MDA. In: Proceedings of

the 9

CAiSE/IFIP8.1/EUNO International Workshop

on Evaluation of Modeling Methods in Systems

Analysis and Design (EMMSAD’2004) in connection

with the CAiSE’2004. Volume 1, RTU, Riga, pp. 211-

220.

Osis, J. 2006 a, Problem Domain Modeling at the

Beginning of MDA Life Cycle By Means of

Topological Functioning Model. In: Proceedings of

the 7

International Baltic Conference on Databases

and Information Systems (DB&IS’06). Vilnius,

Lithuania, pp. 105-116.

Osis, J. 2006 b, Formal Computation Independent Model

within the MDA Life Cycle. In: International

Transactions on Systems Science and Applications.

ISSN 1751-1461 (Print), ISSN 1751-147X (CD-

ROM), V. 1, Nr. 2, Xiaglow Institute Ltd, Glasgow,

UK, pp. 159-166.

MDI4SE 2016 - Special Session on Model-Driven Innovations for Software Engineering

324

Osis, J. 2006 c, Topological Functioning Model within the

MDA Life Cycle. In: Scientific Proceedings of Riga

Technical University. Series – Computer Science (5),

Volume 26, Riga, RTU, pp. 9-20.

Osis, J., Asnina, E. 2008 a, Enterprise Modeling for

Information System Development within MDA. In:

Proceedings of the 41st Hawaii International

Conference on Systems Science (HICSS-41 2008),

United States of America, Waikoloa, 7-10 January,

2008. Waikoloa: IEEE Computer Society, pp.490-490.

ISSN 1530-1605. Available from:

doi:10.1109/HICSS.2008.150

Osis, J., Asnina, E. 2008 b, A Business Model to Make

Software Development Less Intuitive. In:

International Conference on Innovation in Sofware

Engineering (ISE 2008), Austria, Vienna, 10-12

December, 2008. Vienna: IEEE Computer Society,

pp.1240-1245. ISBN 9780769535142. Available from:

doi:10.1109/CIMCA.2008.52

Osis, J., Asnina, E. 2011 a, Is Modeling a Treatment for

the Weakness of Software Engineering? In: Model-

Driven Domain Analysis and Software Development:

Architectures and Functions. IGI Global, Hershey -

New York, pp. 1-14. Available from: doi:

10.4018/978-1-61692-874-2.ch001

Osis, J., Asnina, E. 2011 b, Topological Modeling for

Model-Driven Domain Analysis and Software

Development: Functions and Architectures. In: Model-

Driven Domain Analysis and Software Development:

Architectures and Functions. IGI Global, Hershey -

New York, pp. 15 – 39. Available from: doi:

10.4018/978-1-61692-874-2

Osis, J., Asnina, E. 2011 c, Derivation of Use Cases from

the Topological Computation Independent Business

Model. In: Model-Driven Domain Analysis and

Software Development: Architectures and Functions.

IGI Global, Hershey - New York, pp. 65 – 89.

Available from: doi: 10.4018/978-1-61692-874-

2.ch004

Osis, J., Asnina, E. 2015, Is Modeling a Treatment for the

Weakness of Software Engineering? In: V.Díaz,

J.Cueva Lovelle, B.García-Bustelo ed. Handbook of

Research on Innovations in Systems and Software

Engineering. Hershey, PA: IGI Global, pp.411-427.

ISBN 9781466663596. e-ISBN 9781466663602.

Available from: doi:10.4018/978-1-4666-6359-6

Osis, J., Asnina, E., Donins, U., Garcia-Diaz, V. 2014,

Dependencies among Architectural Views Got from

Software Requirements Based on a Formal Model. In:

Applied Computer Systems. Vol.16, pp.5-12. ISSN

2255-8683. e-ISSN 2255-8691. Available from:

doi:10.1515/acss-2014-0007

Osis, J., Asnina, E., Grave, A. 2007 a, Formal

Computation Independent Model of the Problem

Domain within the MDA. In: Proceedings of the 10th

International Conference on Information System

Implementation and Modeling (ISIM 2007), Czech

Republic, Hradec nad Moravici, 23-25 April, 2007.

Hradec and Moravici: Jan Štefan MARQ, pp.47-54.

Osis, J., Asnina, E., Grave, A. 2007 b, MDA Oriented

Computation Independent Modeling of the Problem

Domain. In: Proceedings of the 2nd International

Working Conference on Evaluation of Novel

Approaches to Software Engineering (ENASE 2007),

Spain, Barcelona, 23-25 July, 2007. Barcelona:

INSTICC Press, pp.66-71. ISBN 978-989-8111-10-4.

Osis, J., Asnina, E., Grave, A. 2007 c, Computation

Independent Modeling within the MDA. In:

Proceedings of IEEE International Conference on

Software, Science, Technology & Engineering

(SwSTE07), Israel, Herzlia, 30-31 October, 2007.

Herzlia: IEEE Computer Society, Conference

Publishing Services (CPS), pp.22-34. ISBN 978-0-

7695-3021-5. Available from:

doi:10.1109/SwSTE.2007.20

Osis, J., Asnina, E., Grave, A. 2008 a, Computation

Independent Representation of the Problem Domain in

MDA. In: e-Informatica Software Engineering

Journal, Vol.2, Iss.1, pp. 29.-46, ISSN 1897-7979.

Osis, J., Asnina, E., Grave, A. 2008 b, Formal Problem

Domain Modeling within MDA. In: Communications

in Computer and Information Science (CCIS).

Software and Data Technologies: Second

International Conference ICSOFT/ENASE 2007:

Revised Selected Papers, Germany, Berlin, 22-25 July,

2007. Berlin: Springer-Verlag Berlin Heidelberg,

pp.387-398. ISBN 9783540886549. e-ISBN

9783540886556. ISSN 1865-0929. Available from:

doi:10.1007/978-3-540-88655-6_29

Osis, J., Beghi, L. 1997, Topological Modelling of

Biological Systems. In: Proccedings of the third IFAC

Symposium on Modelling and Control in Biomedical

Systems (Including Biological Systems), D. A.

Linkens, E. R. Carson (editors), Pergamon-Elsevier

Science Publishing, Oxford, UK, pp. 337-342.

Osis, J., Donins, U. 2009 a, An Innovative Model Driven

Formalization of the Class Diagrams. In: Proceedings

of 4th International Conference on Evaluation of

Novel Approaches to Software Engineering (ENASE

2009), Italy, Milan, 9-10 May, 2009. Milan: INSTICC

Press, pp. 134-145.

Osis, J., Donins, U. 2009 b, Modeling Formalization of

MDA Software Development at the Very Beginning of

Life Cycle. In: Advances in Databases and

Information Systems: 13th East-European Conference

(ADBIS 2009) : Associated Workshops and Doctoral

Consortium : Local Proceedings, Latvia, Rīga, 7-10

September, 2009. Riga: RTU, pp.48-61. ISBN

9789984301631.

Osis, J., Donins, U. 2010 a, Formalization of the UML

Class Diagrams. In: Evaluation of Novel Approaches

to Software Engineering: 3rd and 4th International

Conferences ENASE 2008/2009: Revised Selected

Papers, Italy, Milan, 9-10 May, 2009. Berlin:

Springer-Verlag, pp.180-192. ISBN 9783642148187.

e-ISBN 9783642148194. ISSN 1865-0929. Available

from: doi:10.1007/978-3-642-14819-4_13

Osis, J., Donins, U. 2010 b, Platform Independent Model

Development by Means of Topological Class

Topological Functioning Model for Software Development within MDA (Survey)

325

Diagrams. In: Model-Driven Architecture and

Modeling Theory-Driven Development: Proceedings

of the 2nd International Workshop on Model-Driven

Architecture and Modeling Theory-Driven

Development (MDA & MTDD 2010), Greece, Athens,

22-24 July, 2010. Lisbon: SciTePress, pp.13-22. ISBN

9789898425164.

Osis, J., Gelfandbain, J., Markovich, Z., Novozilova, N.

1991, Diagnostics on Graph Models (on the Examples

of Aviation and Automobile Technology) (in Russian).

Moscow, Transport, 244 p.

Osis, J., Merkuryev, Y., Ginters, E., Teilans, A. 1996,

Object Oriented Modelling and Simulation Using

LATISS. In: Proceedings of the 22nd Conference of

the ASU, Clermont-Ferrand, France, July, pp.136-

145.

Osis, J., Silins, J. 2002, Specifics of Modelling of

Embedded Systems. In: Scientific Proceedings of Riga

Technical University. Series – Computer Science (5),

Volume 13, Riga, RTU, pp. 173-180.

Osis, J., Silins, J. 2009, Topological Function-Architecture

Co-Design of Embedded Systems. In: Advances in

Databases and Information Systems: 13th East-

European Conference (ADBIS 2009): Associated

Workshops and Doctoral Consortium : Local

Proceedings, Latvia, Rīga, 7-10 September, 2009.

Riga: RTU, pp.424-431. ISBN 9789984301631.

Osis, J., Slihte, A. 2010, Transforming Textual Use Cases

to a Computation Independent Model. In: Model-

Driven Architecture and Modeling Theory-Driven

Development: Proceedings of the 2nd International

Workshop (MDA & MTDD 2010), Greece, Athens, 22-

24 July, 2010. Lisbon: SciTePress, pp.33-42. ISBN

9789898425164.

Osis, J., Slihte, A., Jansone, A. 2012, Using Use Cases for

Domain Modeling. In: Proceedings of the 7th

International Conference on Evaluation of Novel

Approaches to Software Engineering (ENASE 2012),

Poland, Wrocław, 29-30 June, 2012. Lisbon:

SciTePress, pp.224-231. ISBN 9789898565136.

Osis, J., Sukovskis, U., Teilans, A. 1997, Business Process

Modeling and Simulation Based on Topological

Approach. In: Proceedings of the 9th European

Simulation Symposium and Exhibition, Passau,

Germany, pp. 496-501.

Slihte, A. 2009, The Concept of a Topological

Functioning Model Construction Tool. In: Advances in

Databases and Information Systems: 13th East-

European Conference (ADBIS 2009) : Associated

Workshops and Doctoral Consortium : Local

Proceedings, Latvia, Rīga, 7-10 September, 2009.

Rīga: RTU, pp.476-484. ISBN 9789984301631.

Slihte, A. 2010, The Specific Text Analysis Tasks at the

Beginning of MDA Life Cycle. In: Databases and

Information Systems Doctoral Consortium, Latvia,

Riga, 5-7 July, 2010. Riga: SIA "Latgales druka",

pp.11-22. ISBN 9789984451893.

Slihte, A., Osis, J. 2014, The Integrated Domain

Modeling: A Case Study. In: Databases and

Information Systems: Proceedings of the 11th

International Baltic Conference (DB&IS 2014),

Estonia, Tallinn, 8-11 June, 2014. Tallinn: Tallinn

University of Technology Press, pp.465-470. ISBN

978-9949-23-632-9. e-ISBN 978-9949-23-633-6.

Slihte, A., Osis, J., Donins, U. 2011, Knowledge

Integration for Domain Modeling. In: Proceedings of

the 3rd International Workshop on Model-Driven

Architecture and Modeling-Driven Software

Development (MDA & MDSD 2011), China, Beijing,

8-11 June, 2011. Lisbon: SciTePress, pp.46-56. ISBN

9789898425591.

Slihte, A., Osis, J., Donins, U., Asnina, E., Gulbis, B.

2011, Advancements of the Topological Functioning

Model for Model Driven Architecture Approach. In:

Proceedings of the 3rd International Workshop on

Model-Driven Architecture and Modeling-Driven

Software Development (MDA & MDSD 2011), China,

Beijing, 7-11 June, 2011. Lisbon: SciTePress, pp.91-

100. ISBN 9789898425591.

Slihte, Armands. 2015, The Integrated Domain Modeling:

an Approach & Toolset for Acquiring a Topological

Functioning Model. PhD Thesis. Riga: [RTU]. 224 p.

MDI4SE 2016 - Special Session on Model-Driven Innovations for Software Engineering

326
