Comparison of Distributed Computing Approaches to Complexity of

n-gram Extraction

Sanzhar Aubakirov

, Paulo Trigo

and Darhan Ahmed-Zaki

Department of Computer Science, al-Farabi Kazakh National University, Almaty, Kazakhstan

Instituto Superior de Engenharia de Lisboa, Biosystems and Integrative Sciences Institute / Agent and Systems Modeling,

Lisbon, Portugal

Keywords:

Distributed Computing, Text Processing, n-gram Extraction.

Abstract:

In this paper we compare different technologies that support distributed computing as a means to address

complex tasks. We address the task of n-gram text extraction which is a big computational given a large

amount of textual data to process. In order to deal with such complexity we have to adopt and implement

parallelization patterns. Nowadays there are several patterns, platforms and even languages that can be used

for the parallelization task. We implemented this task on three platforms: (1) MPJ Express, (2) Apache

Hadoop, and (3) Apache Spark. The experiments were implemented using two kinds of datasets composed

by: (A) a large number of small ﬁles, and (B) a small number of large ﬁles. Each experiment uses both

datasets and the experiment repeats for a set of different ﬁle sizes. We compared performance and efﬁciency

among MPJ Express, Apache Hadoop and Apache Spark. As a ﬁnal result we are able to provide guidelines

for choosing the platform that is best suited for each kind of data set regarding its overall size and granularity

of the input data.

1 INTRODUCTION

Applications of many algorithms and methods of text

analysis depends on statistical information about text

(Riedl and Biemann, 2012), statistics about n-grams

are an important building block in knowledge dis-

covery and information retrieval (Berberich and Be-

dathur, 2013). In this paper we compare different ap-

proaches that deal with n-gram extraction tasks via

the distribution of computation and data across clus-

ters of processing and storage resources. The eval-

uated approaches follow a model where the ”com-

putation moves to the data” (instead of the data be-

ing transferred to feed the computation). We follow

this model, of moving code to available resources, to

deal with the n-gram extraction task where the tem-

poral and space complexity grows with the number,

n, of grams to extract. We adopted the current pat-

terns of task parallelization, such as the map-reduce

paradigm, and implemented the n-gram extraction

task using three different platforms, namely the MPJ

Express, the Apache Hadoop and the Apache Spark.

We also describe application architecture developed

for MPJ Express implementation in order to provide

reliability and fault-tolerance. The contributions from

our work include:

• comprehensive experimental evaluation on En-

glish Wikipedia articles corpora

• time and space comparison between implemen-

tations on MPJ Express, Apache Hadoop and

Apache Spark

• detailed guidelines for choosing platform regard-

ing size and granularity of the input data

We will start from introduction to each platform

and assumptions made, then we will introduce n-gram

extraction method and show results of the experi-

ments. Finally we will provide pros and cons of each

platform regarding particular data set.

1.1 Apache Hadoop

Apache Hadoop is a Java Virtual Machine (JVM)

based framework that implements Map/Reduce

paradigm. It is dividing main task into many small

fragments of work, each of which may be executed

or re-executed on any node in the cluster. Map/Re-

duce paradigm is very well suited for the text pro-

cessing tasks because input data could be divided into

equal chunks and processed separately (Lin and Dyer,

Aubakirov, S., Trigo, P. and Ahmed-Zaki, D.

Comparison of Distributed Computing Approaches to Complexity of n-gram Extraction.

DOI: 10.5220/0005943000250030

In Proceedings of the 5th International Conference on Data Management Technologies and Applications (DATA 2016), pages 25-30

ISBN: 978-989-758-193-9

2010). One of the main features of Apache Hadoop

is transparently provided reliability, fault tolerance

and data motion. It sends same task to a different

nodes that provides ability to avoid downtime in case

of failure of one of the computing nodes, but at the

same time it decrease overall performance of the clus-

ter. Hadoop Distributed File System (HDFS) used for

nodes communication and as temporary data storage.

HDFS abstraction layer provides ability to process big

amount of data that do not ﬁts into fast random-access

memory. At the same time it is reducing performance,

seek times for random disk access are fundamentally

limited by the mechanical nature of the devices.

1.2 Apache Spark

Apache Spark is a JVM based framework that uses

abstraction layer for cluster communication named

Resilient Distributed Dataset (RDD). RDD provides

ability to store data as a certain collections distributed

in the cluster memory (Zaharia et al., 2012). Apache

Spark uses micro-batch task execution model based

on techonology called D-Streams. D-Streams tech-

nology streaming computation as a series of stateless

and deterministic batch computations on small time

intervals (Zaharia et al., 2013). Both RDD and D-

Streams provide reliability and fault-tolerance of task

execution, because the system can recover all inter-

mediate state and results on failure. Also Apache

Spark can be easily integrated with HDFS and Apache

Yarn.

1.3 MPJ Express

MPJ Express is Java implementation of Message

Passing Interface (MPI). The MPI has become a de

facto standard for writing High Performance Com-

puting (HPC) applications on clusters and Massively

Parallel Processors (MPP). It is inherits all advantages

and disadvantages of MPI. The main disadvantages is

the difﬁculty of writing and debugging distributed ap-

plications. The main advantages are ﬂexibility, cus-

tomizability and high performance of the application.

MPJ do not have built-in task manager that pro-

vides fault-tolerance and reliability, thus failure of one

of executors leads to task failure. We propose appli-

cation architecture in order to compete with applica-

tions based on Apache Spark and Apache Hadoop, it

is shown on the ﬁgure 1.

In order to minimize communication between

nodes and reduces network latency overhead each

cluster node processing one ﬁle at a time. We are

using HDFS to avoid data motion and transactional

queue synchronizing pattern to provide reliability.

Figure 1: Architecture of application based on MPJ Ex-

press.

2 METHOD

We are extracting n-gram statistical model from the

Wikipedia articles corpora. The data set description

is shown in table 1. The overall corpora size is 4 Gb

and consist of 209716 articles, each article’s size is

approximately 20 Kb. In order to cover most possible

data set types we divided all corpora into 6 volumes:

64 Mb, 256 Mb, 512 Mb, 1024 Mb, 2048 Mb and

4096 Mb. Each volume is divided into two sets: A) a

large number of small ﬁles, and B) a small number of

large ﬁles. For data set A we keep Wikipedia articles

as is, for B data set we concatenate articles into bigger

ﬁles.

Table 1: Description of the corpora.

size # articles # tokens

64 Mb 3277 6 ∗ 10

256 Mb 13108 25 ∗ 10

512 Mb 26215 51 ∗ 10

1024 Mb 52428 102 ∗ 10

2048 Mb 104858 206 ∗ 10

4096 Mb 209716 412 ∗ 10

Our goal is to extract statistical n-gram model

from all corpora and from each article separately. We

consider that full n-gram model is the all extracted n-

grams, where n ∈ [1, k] and k is the length of longest

sentence in the dataset. We are using method that

is described by Google in their paper (Brants et al.,

2007) and consider improvements suggested by work

(Berberich and Bedathur, 2013). Both algorithms

based on MapReduce paradigm. Method proposed

by (Berberich and Bedathur, 2013) optimized mem-

ory consumption overall performance, but at the same

time rejecting not frequent n-grams. For experiments

we are using Google’s algorithm because our goal is

to obtain full n-gram model.

We adopted algorithm for our goal of n-gram ex-

traction from the individual articles. Our method

operates with sentences, text of the articles is

represented as set of sentences S, where S =

, S

, . . . , S

), and each sentence S

is a list of

DATA 2016 - 5th International Conference on Data Management Technologies and Applications

words S

= (W

, . . . ,W

), where W

is a sin-

gle word.

Algorithm 1: Pseudo code for n-gram extraction.

1: function MAP(list sentence, int size)  map

2: return rangeClosed(1, size)

3: .map(n → sliding(sentence, n, size))

4: end function

5: function REDUCE(stream ngrams)  reduce

6: return ngrams.collect(groupByCount())

7: end function

8: function SLIDING(list sentence, int n, int size)

9: return rangeClosed(0, size - n)

10: .map(idx → join(” ”, list.subList(idx, idx +

n)))

11: end function

We implemented sliding(), map() and reduce()

functions, pseudo-code is shown in ﬁgure 1. Func-

tion map() takes list of sentences S and for each S

executes sliding() function with the parameter n =

(0, 1, 2, . . . , m), where n is size of slides (n-grams) that

function will produce and m is number of words W in

sentence S

. Function reduce() takes output of map()

function, which is the list of n-grams ( list of list of

words) and count similar ones. As a results it re-

turns list of objects (n-gram, v), that is usually called

Map, where v is the frequency of particular n-gram in

the text. This approach provide ability to execute in-

dependent map() and avoid communication between

nodes until reduce() stage.

2.1 MPJ Express Implementation

We are using transactional queue synchronization pat-

tern as a process task management for MPJ Express.

Transactions guarantees message delivery to a sin-

gle recipient. Thus in case of failure transaction can

be aborted and message will be delivered to another

worker. We ﬁll queue with the ﬁle names, each node

takes ﬁle name from queue, process it and takes an-

other one. This solution provides reliability, fault-

tolerance and scalability. And one more beneﬁt is that

workers can be implemented in any language or plat-

form, not only JVM based applications.

2.2 Apache Hadoop Implementation

Word count application is probably the most common

example of Apache Hadoop usage. We use algorithm

from the Apache Hadoop community ofﬁcial site as

basis for our task. The count part remaining almost

the same, with the adoptions to n-gram extraction

task. Pseudo-code of map() and reduce() functions

shown on Algorithm 2.

Algorithm 2: Pseudo-code of Apache Hadoop implementa-

tion.

1: function MAP(key, value, context)  map

2: list sentences = getSentences(value)

3: for (sentence : sentences) do

4: for (n← 1, sentence.size()) do

5: ngrams = sliding(sentence, n)

6: ngrams

7: .forEach(ngram → write(ngram, 1))

8: end for

9: end for

10: end function

11: function REDUCE(key, values, context)  reduce

12: sum = 0

13: for (value : values) do

14: sum += value.get()

15: end for

16: result.set(sum)

17: write(key, result)

18: end function

2.3 Apache Spark Implementation

Applications based on Apache Spark framework can

be implemented using one of three programming lan-

guages: Python, Scala and Java. Scala is a functional

programming language that fully executes in JVM.

It provide advantages such as immutable data struc-

tures, type safety and pure functions. This language

features simpliﬁes code parallelization by reducing

the biggest headache in distributed programming such

as race conditions, deadlocks, and other well-known

problems. As a results code written in Scala become

cleaner, shorter and easy to read. Apache Spark ap-

plication was implemented in Scala, pseudo-code of

implementation is described in Algorithm 3.

Algorithm 3: Pseudo-code of Apache Spark map and reduce

functions.

1: function MAP(sentence, N)  map

2: (1 to N).toStream.ﬂatMap(n ⇒ sen-

tence.sliding(n))

3: end function

4: function REDUCE(text)  reduce

5: text.ﬂatMap(sentence ⇒ sliding(sentence))

6: .map(ngram ⇒ (ngram,1))

7: .reduceByKey((a,b) ⇒ a+b)

8: .saveAsTextFile()

9: end function

2.4 Assumptions

We implemented n-gram extraction library that is

used by Hadoop and MPJ, while Spark use built-

in functions. All implementations use HDFS for

Comparison of Distributed Computing Approaches to Complexity of n-gram Extraction

input/output tasks and there is one separate ma-

chine that serves it. MPJ work with ﬁles splitted in

chunks, while both Spark and Hadoop works with

data streams.

Spark and Hadoop use built-in task management,

while MPJ implementation use messaging queue.

Messaging queue service was installed on separate

server and was not included into a cluster as a usual

node.

3 EXPERIMENTAL RESULTS

Technical characteristics of the cluster is shown in ta-

bles 2 and 3. There are 16 nodes, each node has the

same characteristics. Figure 2 shows overall picture

for results of the experiments, parallelization gives

good efﬁciency and speedup on all platforms.

Table 2: Cluster speciﬁcation.

CPU RAM HDD Net

Intel Core 500GB

i5-2500 16Gb 7200RPM 1Gbit/s

3.30GHz 6Gb/s

Table 3: Software speciﬁcation.

Name Version

MPJ Express 0.44

Apache Hadoop 2.6.0

Apache Spark 1.5.0

Java 1.8.0 60

Scala 2.11.7

Ubuntu OS 14.04

During our experiments Apache Hadoop shows

inefﬁcient processing time for data sets of type A (a

large number of little ﬁles). Processing time of even

the most smallest data set expressed in hours. Re-

searches (Andres and A, 2013), (Vorapongkitipun and

Nupairoj, 2014) and (Andrews and Binu, 2013) shows

that Apache Hadoop works faster if input data is rep-

resented as few big ﬁles instead of many little ﬁles.

This is because of HDFS design, which was devel-

oped for processing big data streams. Readings of

many little ﬁles leads to many communications be-

tween nodes, many disk head movements and as a

consequence leads to extremely inefﬁcient work of

HDFS.

Figure 3 shows results of experiments with dataset

of type A. As we mentioned before Apache Hadoop

is ineffective for such type of dataset, we exclude its

results from the graph. For this type of data Apache

Spark application processing time is higher than MPJ

Figure 2: Shows overall picture. Simple sequential process-

ing on the left side of the plot.

Express. The most effective time shows application

based on MPJ Express platform. Both implementa-

tions MPJ and MPJ+MR shows almost the same time,

but in an average MPJ+MR is 1.5 times faster. MPJ

Express application architecture was designed specif-

ically for such kind of data type where each node pro-

cessing one ﬁle at a time avoiding communication be-

tween nodes.

Figure 4 shows results of experiments with dataset

B. Results are varying depending on dataset volume

size. In an average Apache Hadoop is the slowest

platform, MPJ Express is the fastest. For data sizes

from 64 Mb to 1024 Mb MPJ Express is most effec-

tive, in an average it is 3 times faster than Apache

Spark and 5 times faster than Apache Hadoop. Start-

ing from 2048 Mb dataset sizes Apache Spark shows

better effectiveness, with size of 4096 Mb it is 2 times

faster than other platforms.

Figure 3: Experiments with dataset of type A.

4 SUMMARY

Figures 5 and 6 shows efﬁciency and speedup, it was

computed using the best suited data set type of each

platform. There is ideal line to simplify evaluation.

DATA 2016 - 5th International Conference on Data Management Technologies and Applications

Figure 4: Experiments with dataset of type B.

Figure 5: Shows speedup of each platform.

The graph shows that Hadoop speedup and efﬁciency

are far from ideal, while MPJ is very close, Spark is

always in the middle.

For the dataset type A we are dealing with a very

speciﬁc task - n-gram model extraction for every arti-

cle. It is requires to process large number of small

ﬁles. Application based on MPJ Express was de-

Figure 6: Shows efﬁciency of each platform.

signed speciﬁcally for such type of data set and thus

shows the highest performance. But challenges in

writing distributed software using MPJ Express are

great. Programmer must manage details across sev-

eral threads, processes, or machines. We have to

use low-level devices such as mutexes and to apply

high-level design patterns such as producer-consumer

queues to tackle these challenges. Concurrent pro-

grams are difﬁcult to reason about and even harder

to debug. Apache Hadoop is the platform that re-

quires high administrative skills during cluster setup

and detailed knowledge of documentation and best

practices. For small data set it is considerably slower

than other implementations. Apache Spark is fast and

easier to conﬁgure. Code written for Apache Spark

is cleaner and shorter. It is showing good efﬁciency

on both data types and for all data set sizes. Short

summary would be:

• MPJ Express can be adopted for almost any task

– Very ﬂexible

Comparison of Distributed Computing Approaches to Complexity of n-gram Extraction

– The highest performance

– Difﬁcult to implement and to debug code

• Apache Spark is fast and easy

– Performance is not far behind the MPJ Express

– Clean and short code

– Easy to conﬁgure

• Apache Hadoop

– Slow for little dataset

– Difﬁcult to conﬁgure

5 CONCLUSION

We experimented on the task of extracting n-gram sta-

tistical model from corpora of two different types: A)

a large number of small ﬁles, and B) a small number

of large ﬁles. Experimental result shows that type and

size of the data has a big inﬂuence on the performance

of a speciﬁc platform. We have concluded that:

• for dataset type A for all data sizes MPJ Express

shows the best speedup and efﬁciency

• for dataset type B

– for dataset sizes of 64 Mb to 2048 Mb MPJ

Express shows 3 times better speedup and ef-

ﬁciency

– for dataset sizes of 2048 Mb and more Apache

Spark shows 2 times better speedup and efﬁ-

ciency

6 COPYRIGHT FORM

The Author hereby grants to the publisher, i.e. Sci-

ence and Technology Publications, (SCITEPRESS)

Lda Consent to Publish and Transfer this Contribu-

tion.

REFERENCES

Andres, B. P. and A, B. (2013). Perusal on hadoop small ﬁle

problem. In Perusal on Hadoop small ﬁle problem.

IJCSEITR.

Andrews, B. P. and Binu, A. (2013). Perusal on hadoop

small ﬁle problem. In IJCSEITR. TJPRC.

Berberich, K. and Bedathur, S. (2013). Computing n-gram

statistics in mapreduce. In EDBT ’13 Proceedings

of the 16th International Conference on Extending

Database Technology. EDBT.

Brants, T., Popat, A. C., Xu, P., Och, F. J., and Dean, J.

(2007). Large language models in machine transla-

tion. In Proceedings of the 2007 Joint Conference

on Empirical Methods in Natural Language Process-

ing and Computational Natural Language Learning.

EMNLP-CoNLL.

Lin, J. and Dyer, C. (2010). An ontology-based approach to

text summarization. In Data-Intensive Text Processing

with MapReduce. Morgan and Claypool.

Riedl, M. and Biemann, C. (2012). Text segmentation with

topic models. In JLCL. JLCL.

Vorapongkitipun, C. and Nupairoj, N. (2014). Improving

performance of small-ﬁle accessing in hadoop. In JC-

SSE. JCSSE.

Zaharia, M., Das, T., Li, H., Shenker, S., and Stoica, I.

(2012). Discretized streams: An efﬁcient and fault-

tolerant model for stream processing on large clusters.

In HotCloud’12 Proceedings of the 4th USENIX con-

ference on Hot Topics in Cloud Computing. HotCloud.

Zaharia, M., Das, T., Li, H., Shenker, S., and Stoica, I.

(2013). Discretized streams: Fault-tolerant streaming

computation at scale. In Proceedings of the Twenty-

Fourth ACM Symposium on Operating Systems Prin-

ciples. SOSP.

DATA 2016 - 5th International Conference on Data Management Technologies and Applications
