Trust Management for Vehicular Cloud Computing

Marcela Roxana Farcasescu

West University of Timisoara, Department of Informatics and Mathematics, Bd. Vasile Parvan, Timisoara, Romania

1 RESEARCH PROBLEM

In the last years, the business model of cloud

computing has spread viral in several domains,

promising to change the way we think about

computing and data storage. One of the biggest

concerns in cloud adoption since 2009, is considered

to be the trust offered from both perspective – cloud-

end user and cloud provider. A new and challenging

field that highlights the need of defining the trust

management concept is vehicular cloud computing.

Stephen Olariu and his team have define the

vision of vehicular cloud computing as a pool of

resources which need to be carefully handled by a

trusted interested party.

This is why the current paper is going to

combine two of the main challenges in Vehicular

Cloud Computing by creating trust models: the

authentication of the owner of the car and the

geolocation data sharing. The infotaiment unit of a

vehicle will soon have installed an accesible

operating system which is already used for our

mobiles, tablets, gadgets, etc. In this way, all the

current applications that can be installed on our

gadgets will soon be adapted to the infotaiment unit,

which means that the vehicular cloud will become a

necesity. With this in mind, the authentication of the

owner of a car will become an important security

issue, while the geolocation data sharing will remain

a critical privacy concern.

The innovative approach is to build trust models

based on driver’s behavior as the owner of his

vehicle, using the geolocation as a strategical item in

validating the user’s actions and requests. The

attacks simulation will consider the scenario of

loosing ownership of the vehicle and providing fake

geolocation data.

2 OUTLINE OF OBJECTIVES

The main activities of the research will be to:

• Outline the security challenges in cloud

computing but also in vehicular cloud

environments

• Mitigate the importance of a trust

management in a cloud environment

• Build trust models for driver identification

and vehicle’s localization

• Apply the trust models and analyse the results

• Perform attack simulations: attacker as a

driver and fake geolocation received

• Interpretation of the results by providing a

final conclusion on the confirmed or infirmed

theory

The research will be conducted from two main

directions: how to trust the information provided by

the driver and how to trust the services used in

communication (the information requested by the

service will be used only for obtaining the needed

data and not for other purposes).

Before getting into the exact details, the main

concepts used, need to be defined.

3 STATE OF THE ART

Concepts review:

• Cloud Computing

Cloud computing combines in a successful recipe

the advantages of the grid computing with the

service-oriented. This introduces an elastic and rapid

provisioning service consumption model. Cloud

computing can overcome the running out of

capacity, capacity excess costs, tied-up capital. The

main characteristics of the cloud computing concept

are: on-demand self-service or pay-as-you-go, rapid

elasticity, resource pooling, measured service[Bernd

Grobauer]. In order to adopt cloud computing, a

cloud model should be chosen that will cover the

business needs (SaaS, PaaS, IaaS), the provider roles

and capabilities should be analysed, determine the

dependencies on the cloud provider, establish and

negotiate the SLA (Service Level Agreement), have

an exit strategy – in case the cloud provider will

disappear from the cloud ecosystem.

Cloud Security is a sub-domain of the computer

security that includes all the policies, controls,

Farcasescu, M.

Trust Management for Vehicular Cloud Computing.

In Doctoral Consortium (DCCLOSER 2016), pages 14-17

deployment techniques used in the infrastructure of

the cloud computing. Cloud based security refers to

the services present in the cloud environment. The

focus of this research paper relies on the sub-domain

of cloud based security.

• Vehicular Cloud Computing

Vehicular cloud computing represent an extension of

the cloud computing paradigm describing: “a group

of largely autonomous vehicles whose corporate

computing, sensing, communication and physical

resources can be coordinated and dynamically

allocated to authorized users”[ Md Whaiduzzaman].

A shorter definition redesigns the concept of a

vehicle in the cloud computing context, describing it

as driver’s dependent entities, service providers and

communication tools. The differences between cloud

computing and vehicular cloud computing are

The main challenges of both of the paradigms are

establishing a reliable trust context for each vehicle

involved in the communication, but also to trust the

information provided by those entities. This is why

the trust management concept is required when

discussing about the security and privacy concerns

of the vehicular cloud computing.

• Trust Management

Similar to the cloud computing, the trust concept has

multiple definitions, because it can be seen from

different perspectives: customer’s and cloud

vendor’s point of views. Trust is “the subjective

probability by which an individual, expects that

another individual, performs a given action on which

its welfare depends”[Talal H]. Trust represents

“more than the authorized nature of security

relations between human societies, from a stable and

healthy operation to a large extent thanks to the trust

relationship between the individuals, groups and

organizations.”[ R. K. L. Ko, P. Jagadpramana]

Marsh was one of the first researchers of the

computational trust. In the trust model that he

proposed as a direct interaction between agents, he

divided trust in three categories [Marsh S.]:

• Basic Trust - based on experiences from the

past

• General Trust - the trust that an agent has in

other agent

• Situational Trust - the amount of trust that an

agent has in other agent in a specific situation

The bidirectional relationship between two

agents can be described at any moment by using the

degree of trust represented by the three categories.

Trust management represents the trust analysis

between agents using trust metrics that rely on

reputation, deception, persuasion and the optimal

decisions taken according to the trust level found.

The trust management techniques can be classified

in four main categories: policy, recommendation,

reputation, prediction. For each category, specific

trust models can be created. A trust model can be

described by a set of rules that reflect the

relationship between the cloud provider and

customer.

4 METHODOLOGY

4.1 Building the Trust Models

The trust models will be created as sets of rules

established by the cloud provider or end-cloud user

using a Rule Based Engine (for example the

Business Rule Engine from WSO2). The set of rules

will reflect a specific policy or recommendation.

The trust models will be used later on at the

authentication and geographical location

identification phases. The geo-location can be also

used as a second authentication factor.

From the authentication perspective, we would

like to try to focus on personal gadget (owned

device) usage as an authentication method in order

to gain access to the infortaiment (the entertainment

unit from the vehicle) data. If the owner of the car is

not recognized, the current driver should have

limited access to the information presented on the

infotaiment unit. The recognition will be done using

the sensors of the owned device which will

interpretate the user behaviour in the vehicle. On the

other side, geo-location can be used to confirm that

the driver behaviour.

Geo-location is a concept used in “information

systems security cycles to extrapolate the

geographical location of a subject (person or

system)”. There are several Location-Based Service

(LBS) applications on different platforms that

currently challenge the user’s trust levels and

privacy. The LBS application use the geolocation

data to obtain other information for the user. Usually

are installed on personal devices and help in

researching for specific points of interest (eg.

restaurants, museums, etc). The main difference

between Geolocation Services and Location-Based

Services is that the first ones don’t require an

accurate user address and the primary objective is to

protect the user’s privacy.

For the Geolocation model, the GPS data will be

collected using driver’s gadgets and the infotaiment

unit. After establishing a set of rules for each cloud

provider, a trust score will be associated considering

Trust Management for Vehicular Cloud Computing

the number of touched rules per policy (a rule will

be considered “touched” if the condition or criteria

used in the rule was fully respected).

4.2 Collecting the Data

The data will be collected using mobile phones,

tablets, other gadgets sensors. Usually the devices

have built-in sensors that measure motion,

orientation, and various environmental conditions.

The sensors will provide raw data with high

precision and accuracy, monitoring three-

dimensional device movement or positioning, or

ambient environment changes. The sensors can be

classified as: environmental, motion and position

sensors.

The purpose of the collected data is to be used as

an input for the trust models created in order to

approve or decline further access through the cloud

ecosystem.

After collecting the data, an heuristic approach

will be used in identifying similarities and use the

input data as a further authentication schemas.

4.3 Attack Simulations

The next steps will be to prove by simulating attacks

that the heuristics chosen are actually providing the

expected results and try to improve those to address

possible attack scenarios.

A. Stolen Device

A possible scenario can be considered when the

drivers gadget or owned device it’s now in attacker’s

hands. An attack graph will be created looking at the

chances of the attacker to gain full access to the

infotaiment data using the stolen device.

B. Fake Geolocation Data

Another possible scenario is when the attacker

which already stolen the device from the driver is

sending fake geolocation data. An attach graph will

be created to analyse all the possible scenarios.

4.4 Preparing for Vehicular Cloud

Computing Outages

The outage concept refers to the unavailability of a

service that usually it is a consequence of a server

loss of electricity power or malware

blockages[Nicholas Car]. Outages could be a serious

security vulnerability for a cloud ecosystem. When

an outage occurs in cloud computing, there are two

key factors: the type of outage and the time needed

for service recovery.

Outages can be scheduled or unexpected. If the

cloud provider is scheduling an outage for

administration reasons each month at the same date

time, the service outage can be easily tracked and

used in malicious scopes. An unexpected outage can

occur due to a malware attack that takes down the

DNS servers. When an outage is analyzed, security

issues must be considered in order to detect the root

causes. After an outage in cloud computing, the

cloud vendor should present the problem and explain

the identified issue. If this is not possible, the

viability of the cloud services will be usually

questioned. The focus of the cloud provider is to

prepare for outages, not to avoid them. Prediction

might also be beneficial, but it implies processing a

lot of monitoring data and might result in too many

false-positive alarms.

In particular for vehicular cloud computing, an

outage is actual represented by a missed

communication between the vehicle and the cloud

which means that the data from the vehicle to the

cloud is not transferred anymore or the vehicle

doesn’t receive anymore data from the cloud. This

situation can occur while driving in the areas where

the communication is not possible (depending on the

channel used).

5 EXPECTED OUTCOME

The expected outcome is to confirm the advantages

and disadvantages of using the trust management in

vehicular cloud environments by analysing the

obstacles and proposed -solutions. The expected

results will highlight the need of implementing the

trust models for the vehicular cloud computing

environment.

6 STAGE OF THE RESEARCH

A few attempts for building the trust models were

already perform in order to extract the difference

between what the customer provided and what the

services collect with or without the end-user’s

approval.

Currently, I am in the process of collecting the

data from several owned devices like tablets, mobile

phones, fitness braces. After collecting the data the

next step will be to implement the trust models

DCCLOSER 2016 - Doctoral Consortium on Cloud Computing and Services Science

which will contribute to the driver identification.

ACKNOWLEDGEMENTS

This work was supported by a grant of the Romanian

National Authority for Scientific Research and

Innovation, CNCS-UEFISCDI, project number PN-

II-RU-TE-2014-4-1501(2015-2017).

REFERENCES

Stephan Olariu, Gongjun Yan, Ding Wen, Michele

C.Weigle, 2012, “Security Challenges in Vehicular

Cloud Computing” IEEE Transactions on intelligent

transportation systems.

Md Whaiduzzaman, Mehdi Sookhak, Adbullah Gani,

Rajkumar Buyya, 2014, “A survey on vehicular cloud

computing”,Journal Network and Computer

Applications.

Mario Gerla, 2012, “Vehicular Cloud

Computing”,Vehicular Communications and

Applications Workshop.

Talal H. Noor, Quan Z.Sheng, Sherali Zeadally, Jian Yu,

2013, “Trust Management of Services in Cloud

Environments: Obstacles and Solutions”, ACM

Computing Surveys, Vol 46, No1, Article 12,

Publication Date: October 2013.

Bernd Grobauer, Tobias Walloschek, Elmar Stocker,

2010,”Understanding Cloud-Computing

Vulnerabilities”, Proceedings of the 2010 IEEE

Security and Privacy,pp. 1-14.

Cloud Security Alliance, August 23, 2012, “Cloud

Computing Vulnerability Incidents: a statistical

overview”, Cloud Vulnerabilities Working Group.

Josang, A., Keser, C., and Dimitrakos, T. , 2005.

"Can We Manage Trust?" In: P. Herrmann et al. (Eds.):

iTrust, LNCS 3477, 2005, pp. 93-107.

S. Marsh, 1994 “Formalising trust as computational

concept”, PhD Thesis, Department of Computer

Science, University of Stirling, 1994, pp.56-59.

R. K. L. Ko, P. Jagadpramana, M. Mowbray, S. Pearson,

M. Kirchberg, Q. Liang, et al.,2011 "TrustCloud - A

Framework for Accountability and Trust in Cloud

Computing," in IEEE 2nd Cloud Forum for

Practitioners (IEEE ICFP 2011), Washington DC,

USA, pp. 1-5.

Nicholas Carr, 2008,“The Big Switch - Rewiring the

world, from Edison to Google”, Second Edition, W.W.

Norton & Company Inc, New York, Part 1, Chapter 1,

pp. 14-25.

Trust Management for Vehicular Cloud Computing
