An Approach to Add Multi-tenancy to Existing Applications

Uwe Hohenstein and Preeti Koka

Siemens AG, Corporate Technology, Otto-Hahn-Ring 6, D-81730 Muenchen, Germany

Keywords: Multi-tenancy, Cloud Migration, Aspect-Orientation, AspectJ, Industrial Application, Case Study.

Abstract: Multi-tenancy, i.e., sharing resources amongst several tenants, is a key element to make SaaS profitable by

saving resources and operational costs. This paper considers multi-tenancy in the context of Cloud migra-

tion and presents an approach to let existing applications become multi-tenant. The novelty of this approach

is that no reengineering and modification of the application’s source code is required. Adding some new

components is sufficient to achieve tenant management, authentication, tenant isolation, and also customiza-

tion. Using a case study, the paper demonstrates in detail how to benefit from aspect-orientation, particular-

ly the AspectJ language, in this respect and concludes with experiences.

1 INTRODUCTION

According to (Mell and Grance, 2011), Cloud com-

puting is a model for enabling convenient, on-

demand network access to a shared pool of configu-

rable computing resources that can rapidly be deliv-

ered with a minimal management effort or service

provider interaction.

Particularly, software is more and more becom-

ing an on-demand service drawn from the Cloud.

The so-called Software-as-a-Service (SaaS) is a

delivery model that enables customers, the so-called

tenants, to lease services without a local installation

(Lee and Choi, 2012). Tenants pay for what they use

to what extent without buying software licenses.

While a traditional application service provider

typically manages one dedicated application instance

per tenant, SaaS providers usually adopt a multi-

tenant architecture (Chong and Carraro, 2006). Mul-

ti-tenancy is a software architecture principle that

lets several tenants share a common infrastructure.

This saves operational cost due to an efficient utili-

zation of hardware and software resources and im-

proved ease of maintenance (Bezemer and Zaidman,

2010). A well-economical SaaS application has to

pursue a multi-tenant architecture.

In order to benefit from features such as elastici-

ty and pay-as-you-go, businesses want to move

applications into the cloud. One challenge for indus-

try is to convert legacy applications into multi-tenant

SaaS without major code changes and high effort

(Binz et al., 2011), thus preserving investments

while entering SaaS business.

This paper takes a practical view on Cloud mi-

gration and presents a low-effort approach for offer-

ing legacy applications as multi-tenant SaaS in a

Cloud – without refactoring the source code. To

explore our idea, we use an existing industrial appli-

cation that was originally not developed for a multi-

tenant environment and serves users of exactly one

tenant. Currently, each tenant has an application

deployed on a Tomcat server and an Oracle database

on premise.

Several authors such as (Walraven et al., 2011)

or (Guo et al., 2007) discuss multi-tenant architec-

tures with pros and cons according to what is shared

by the tenants: the topmost web frontend, middle tier

application servers, the underlying database. Others,

e.g., (Andrikopoulos et al., 2013) define further

degrees of sharing and categorize other migration

types to cloud-enable applications. Striving for mul-

ti-tenancy, the SaaS provider has to balance between

easy implementation and saving operational costs by

efficient resource utilization.

The simplest approach to make our application

multi-tenant with lowest development effort is cer-

tainly to let each tenant obtain a VM with Tomcat,

the application, and Oracle. (Krebs et al., 2012) call

this a virtualization approach. The ease of this ap-

proach is paid by well-known disadvantages such as

high consumption of resources and high costs espe-

cially in public clouds. Moreover, each tenant re-

quires an Oracle license or additional costs for using

Oracle as a Cloud service.

Hohenstein, U. and Koka, P.

An Approach to Add Multi-tenancy to Existing Applications.

DOI: 10.5220/0005973800390049

In Proceedings of the 11th International Joint Conference on Software Technologies (ICSOFT 2016) - Volume 2: ICSOFT-PT, pages 39-49

ISBN: 978-989-758-194-6

Fully efficient multi-tenancy (Chong and Carra-

ro, 2006), at the other edge of the scale, allows for

sharing all resources, one Tomcat, one application,

and one Oracle server among all tenants. Setting up

a fully multi-tenant application requires a significant

re-engineering of applications, and thus causes high

development costs (Momm and Krebs, 2011).

While serving several tenants by sharing one in-

stance, SaaS applications have to be customizable or

configurable to fulfill the varying functional re-

quirements of individual tenants (Krebs et al., 2012).

Tenant customization is recognized as one important

requirement and challenge by (Guo et al., 2007),

(Bezemer et al., 2010), and others. (Lee and Choi,

2012) state that it is not trivial to adapt the business

logic and data to the requirements of the different

tenants. Most work on customization focuses on

product-line approaches (Pohl et al., 2005) to offer

variability. Using aspect-oriented programming

(AOP) is sometimes proposed to achieve configura-

bility, e.g., by (Shahin et al., 2013) and (Wang and

Zheng, 2010).

In this paper, we also apply AOP, more precisely

the AspectJ language (Laddad, 2009), to migrate

existing applications into fully multi-tenant SaaS

applications. We elaborate upon how to benefit from

AspectJ in this context and show that it is possible to

have a simple and cheap mechanism by only adding

components to existing applications – without any

further reengineering. Using a real existing industrial

application, we demonstrate the major advantages of

our migration approach. In a nutshell, it is possible

to achieve tenant isolation, to modify existing be-

havior in a tenant-specific manner, to introduce new

services for specific tenants, and to monitor requests

per tenant for billing purposes.

Enabling such multi-tenancy facets is achieved

without explicitly touching source code or building a

new application; only a restart of Tomcat is required

after having deployed some additional components.

The motivation for our work is manifold. The

approach is a first step to let existing applications

become Cloud ready and to enable entering SaaS

business fast and easily. Such a first trial can explore

SaaS business opportunities and to expand business

to a larger customer base with low expenses. Being

easily applicable to other applications, our solution

reduces time-to-market and saves development ef-

fort. And finally, free demo versions of existing

applications can be made publicly available in a

Cloud as a teaser, maybe with reduced functionality.

Since no profit can be directly made in that case, we

benefit from small investments in development.

The remainder of this paper is structured as fol-

lows. Section 2 presents related research and deduc-

es the necessity for this work.

Before discussing the migration approach, we

give in Section 3 a short introduction into the aspect-

oriented AspectJ language, as far as it is necessary to

understand how we applied AspectJ.

We used a concrete industrial project to prove ef-

fectiveness. Section 4 introduces the application in

its original single-tenant form and presents our ap-

proach to migrate to a multi-tenant Cloud applica-

tion with low programming effort in detail. We dis-

cuss the components that implement important fac-

ets of multi-tenancy such as tenant isolation and

customization.

In Section 5, we evaluate the AspectJ approach

and discuss the lessons learned. Finally, the conclu-

sions summarize the discussion and presents future

ideas.

2 RELATED WORK

Several papers are related to our work in two sepa-

rate directions: Multi-tenancy and cloud migration.

The possible variants of multi-tenancy are de-

scribed, among others, by (Chong et al., 2006) and

(Kwok et al., 2008). (Momm and Krebs, 2011) con-

sider approaches to reduce resource consumption

and discuss some cost aspects of sharing. Based on

the number of tenants, the number of users per ten-

ant, and the amount of data per tenant, (Wang et al.,

2008) make recommendations on the best multi-

tenant variant to use.

(Guo et al., 2007) discuss implementation princi-

ples for application-level multi-tenancy, exploring

different approaches to improve isolation of security,

performance, availability, and administration.

(Fehling et al., 2010) come up with prospects for

the optimization of multi-tenancy by distributing the

tenants with respect to Quality of Service.

An architectural approach for reengineering appli-

cations to enable multi-tenancy in software services is

defined by (Bezemer et al., 2010). Their multi-

tenancy reengineering pattern requires a multi-tenant

database, tenant-specific authentication, and configu-

ration. The discussion takes into multi-tenancy reen-

gineering account workflow and UI configuration.

The reengineering pattern is applied to an existing

single-tenant application. Because of a well-designed

and layered architecture, the effort was relatively

little. Furthermore, (Bezemer and Zaidman, 2010)

manually transform the ScrewTurn wiki case to a

multi-tenant application and encounter performance

isolation of tenants, scalability issues for tenants from

ICSOFT-PT 2016 - 11th International Conference on Software Paradigm Trends

different continents, security, data protection, configu-

rability, and data isolation as the core challenges,

however, not solving all these issues. The paper also

stresses on another cost aspect for multi-tenant appli-

cations: The recurrence of maintenance tasks (e.g.,

patches or updates) raises operating cost too.

In contrast to this general work on strategies and

their impact on resource consumption, we tackle the

problem of adding multi-tenancy in a smart way.

A lot of research considers tenant-specific cus-

tomizations as an important requirement. Case stud-

ies such as (Kwok et al., 2008) stress on configura-

bility of multi-tenant applications. (Tsai et al., 2010)

discuss the elements of an application that need to be

customized: Graphical user interface, workflow

(business logic), service selection and configuration,

and data.

According to (Shahin et al., 2013), customization

could be performed in two ways. In a source-code

manner, SaaS applications are customized by inte-

grating new tenant-specific source code. (Zhou et

al., 2011) and (Kong et al., 2010) pursue such an

approach. Despite providing tenants with flexibility

in the customization process, this approach suffers

from several drawbacks. The tenant must be aware

of the implementation details of the SaaS applica-

tion. Next, allowing tenants to integrate source code

may violate the security regulations of the applica-

tion. And finally, the process of software upgrades

becomes more complicated for the SaaS provider,

since all the tenant-specific extensions have to be

retained.

In an alternative composition-based approach,

SaaS applications are customized by composing

variants, selected from a provided set of compo-

nents. The current state of practice in SaaS devel-

opment is that configuration of pre-defined exten-

sions is preferred over source code based approach-

es, which is considered too complex as pointed out

in (Walraven et al., 2011). One prominent approach

is providing an application template with unspeci-

fied parts, often called customization points (Lizhen

et al., 2010), which can be configured by selecting

predefined components from a provided set (Moens

et al., 2012); (Park et al., 2011); (Li et al., 2012).

(Pohl et al., 2005) point out four key concerns to

be addressed: modelling customization points and

variations, describing relationships among varia-

tions, validating customizations performed by ten-

ants, and dis-/associating variations to/from custom-

ization points during runtime.

(Shahin et al., 2013) deal with all these concerns.

Illustrated by a Travel Agency example, they pro-

pose the Orthogonal Variability Modeling (OVM) to

model customization points and variations and to

describe the relationships among variations. A

Metagraph-based algorithm validates tenants’ cus-

tomizations. An aspect-oriented extension of the

Business Process Execution Language (BPEL) is

used to associate and disassociate variations to/from

customization points at run-time.

(Lizhen et al., 2010) deal with three of the above

concerns by using Metagraphs to model customiza-

tion points, variants, and their relationships. They

also propose an algorithm to validate customizations

made by tenants.

(Tsai et al., 2010) and (Tsai and Sun, 2013) han-

dle only the modeling of customization points and

variants using an ontology-based customization

framework with OVM. To avoid unpredictable cus-

tomizations, tenants are guided through the customi-

zation process.

(Walraven et al., 2011) consider middleware

component models as inflexible for offering soft-

ware variations to different tenants. They use

Google AppEngine to build a multi-tenancy support

layer that combines dependency injection with mid-

dleware support. Using an online booking scenario,

they evaluate operational expenses and flexibility.

The application requires dedicated customization

points for applying customization.

(Wang and Zheng, 2010) apply the more general

AOP in a case study, but still have to prepare the

software architecture accordingly.

All this research starts from green-field or re-

quires at least a preparation of an existing applica-

tion with customization points, while our approach

leaves the original application as it is.

Another branch of related research considers mi-

grating legacy applications into the cloud as a chal-

lenge. There is a lot of work on checklists and meth-

odologies to perform such migrations. The project

ARTIST (Orue-Echevarria et al., 2014), e.g., pro-

vides methods, techniques, and tools to guide com-

panies to move applications into the cloud. A meth-

odology supports the complex, time-consuming, and

expensive transition with three phases: pre-

migration, migration, and post-migration.

Vendor lock-in is seen by (Binz et al., 2011) as a

major difficulty for migrating existing applications

into and between different clouds. The CMotion

framework models entities and their dependencies to

support migration, but requires the implementation

of adapters.

(Khajeh-Hosseini et al., 2012) present a frame-

work to support decision makers. Decisions to mi-

grate existing systems to the cloud can be compli-

cated as the benefits, risks, and costs of using the

An Approach to Add Multi-tenancy to Existing Applications

Cloud are complex and should also consider organi-

zational and socio-technical factors. Their Cloud

Adoption Toolkit offers a collection of tools for

decision support and helps to identify those concerns

and match them to appropriate technologies. A cost

modeling tool is presented in detail with a case

study; the tool can be used to compare the cost of

different cloud providers and deployment options.

To our knowledge, there is no work combining

an approach to migrate applications to the Cloud

with adding multi-tenancy for a real application by

avoiding major code changes.

3 ASPECT-ORIENTED

PROGRAMMING IN AspectJ

Aspect-orientation (AO) is a paradigm that helps to

develop software in a modular manner (Kiczales et

al., 1997). AO provides systematic means for effec-

tive modularization of crosscutting concerns

(CCCs), i.e., those functionalities that are typically

spread across several places in the source code.

CCCs often lead to lower programming productivity,

poor quality and traceability, and lower degree of

code reuse (Elrad, 2001).

AO has brought up new languages with special

concepts to modularize CCCs and to avoid the well-

known symptoms of non-modularization such as

code tangling and code scattering.

The AspectJ language (Laddad, 2009) essentially

extends Java with aspects. An aspect can change the

dynamic structure of a program by intercepting cer-

tain points of the program flow, called join points.

Examples of join points are method and constructor

calls or executions, field accesses, and exceptions.

Join points are syntactically specified by means of

pointcuts. Pointcuts identify join points in the flow

by means of a signature expression. Advices specify

certain actions to be taken before and/or after the

join points. The following is an example for a simple

AspectJ aspect:

@AspectclassMyAspect{

@Before(“execution(*MyClass*.get*(..))”)

publicvoidmyPc(){

do

something(Java)beforemyPcjoinpoints}

}

An annotation @Aspect lets the Java class MyAspect

become an aspect. A method annotated with

@Before, @After, @Around is an advice that is exe-

cuted before, after or around join points. Those an-

notations specify pointcuts as a string.

MyAspect

possesses a before advice that adds logic before

executing those methods that are captured by the

pointcut

myPc: Any execution of any method starting

with get, having any parameters and any return type,

belonging to a class starting with

MyClass. Wildcards

can be used to determine several methods of several

classes. A star “

*” in names denotes any character

sequence. “

*”as a type stands for any type. Parame-

ter types can be fixed or left open (..).

This is pure Java code that runs with any Java

compiler. So-called load-time weaving (LTW) let

the advices be woven into the code whenever a class

is loaded by the class loader. In addition to aspect

annotations, AspectJ offers a language of its own (in

fact, an extension of Java), however, requiring an

AspectJ compiler. But a compiler changes the build

process, which is often not desired, so for us. We do

not want to re-compile the existing application.

4 ADDING MULTI-TENANCY TO

EXISTING APPLICATIONS

4.1 Application Case

Our case study considers an existing Java applica-

tion, a REST service in the travel management do-

main with the following characteristics.

 The application is currently shipped as a single-

tenant application to customers and deployed in

Tomcat at the customer site.

 Each customer obtains a full application stack of

its own, consisting of Tomcat, the application,

and an Oracle database (DB) server at the

backend for storing data, all running on-premise.

The goal is to deploy this application in a public

cloud while sharing Tomcat, the application and the

database amongst several tenants.

Tomcat offers several forms of user authentica-

tion: form-based (for Web application), basic au-

thentication (for REST services) etc. If authentica-

tion is enabled, user and password are requested for

accessing an application. User, passwords, and user

roles are maintained in a configurable “user/roles

store” like in an XML file, a relational DB, a JDNI

store etc. During authentication, the Tomcat con-

tainer checks for access control privileges against

that store. In addition, the application can restrict

functionality to users with specific roles. Our appli-

cation uses the basic authentication of Tomcat.

An Oracle database possesses a dedicated sche-

Auth(entication) that contains the user/roles

tables. The connect string with a specific us-

er/password is part of the Tomcat configuration file.

Oracle has very specific terms that should be un-

ICSOFT-PT 2016 - 11th International Conference on Software Paradigm Trends

derstood. Any access to a database has to be granted

to users. Each user has a password to login and an

associated DB schema with the same name. To ac-

cess data of another user, tables can be prefixed by a

schema name. However, a user has to be explicitly

granted access by the owner, i.e., schemas are isolat-

ed from each other by default. Each user can create

the same set of tables with the same statement – in

his schema. Thus, the concept of a tenant “database”

maps to a user/schema within one Oracle server. In

the following, we use the notion

schema.table to

refer to a table in a specific schema.

A database instance is the Oracle notion of a DB

server with exactly one database being associated. A

JDBC driver connects to that database.

Details about the application are subject to con-

fidentiality and irrelevant for the message of this

paper.

4.2 Tenant and User Management

The major concern of this paper is to let an existing

Tomcat application become multi-tenant, thus shar-

ing a Tomcat and the Oracle database instance. As

pointed out in (Bezemer et al., 2010), the prerequi-

site for multi-tenancy is an appropriate tenant/user

management supporting the following workflow:

1. There must be a possibility to let tenants register

for using the application, if they are interested.

2. After having clarified the payment details be-

tween the SaaS provider and the tenant and set

up a contract, a SaaS administrator should be

able to acknowledge or deny the tenant for using

the application. To this end, we set up a new or-

ganizational Tomcat role

SaaS which allows the

administrator to manage SaaS. After acknowl-

edgement, each tenant obtains an Oracle user and

schema, i.e., a DB of its own thereby keeping the

tenant’s application data isolated.

3. The SaaS provider usually delegates the tasks of

creating and maintaining users to each tenant.

Any acknowledged tenant obtains a

TAdmin role

that allows registering his users for the applica-

tion by specifying credentials for authentication.

4. The tenant’s users obtain a role

User and can log

in to the application once they are authenticated.

This principle is called a centralized authentica-

tion system in (Chong and Carraro, 2006).

Thus, we have the following roles in Tomcat giving

privileges to the various types of users: the adminis-

trator for SaaS applications (

SaaS), the administrator

for a tenant who is enabled to register tenant’s users

(

TAdmin), and the user of the application (User); in-

deed, there may be several with specific privileges.

For the ease of discussion, we collapse them to one.

4.3 Initial DB Setup for Multi-tenancy

We assume a database schema Appl in the original

application to keep the application’s data (indeed,

there might be several). Another schema, referred to

Auth, contains the tables Users and User_Roles to

keep Tomcat users with their roles. Tomcat accesses

these tables for authentication to check the password

and roles. This means that only Tomcat users in the

Users table are allowed to access the application,

provided they have the requested role.

First, we extend the

Users table in the Auth

schema with a column tenant to keep the association

between a user and the tenant s/he belongs to.

We add a new Oracle user/schema

Admin exclu-

sively used by the SaaS admin to keep information

about tenants. A new table

Tenantsis created in this

schema to keep registered tenants with their admin-

istrators. We also add a

UserMonitoring table to the

schema for monitoring purposes (cf. 4.7).

A new Tomcat user

SaaS with a role SaaS is add-

ed to the

Users and User_Roles table. This allows

him to use the new tenant administration (cf. 4.4).

Finally, we need an SQL script

createApplica‐

tionTables.sql

that can be executed in any new

tenant schema to add the application’s tables.

These steps can be done by means of an SQL

script, without affecting the existing application.

Other Tomcat authentication schemes require similar

steps, e.g., operating on XML files.

4.4 Tenant Administration Service

We need new services for administration purposes,

especially for registering tenants and users, and new

functionality according to the workflow in Subsec-

tion 4.2. These services can simply be deployed as a

new application in Tomcat in order to become im-

mediately effective. There is again no impact on the

existing application source code. For instance, a

REST server can offer the following major services

supporting the workflow.

(1)

POSTTenantService allows tenants to register

for the application. The payload specifies a name

Tenanti, an administrator name, and a password,

both being used for Tomcat authentication. This

information is stored in the table

 Admin.Tenants

(name, admin, password, acknowledged, ...)

. Ac-

cess to this service is granted to everyone.

(2)

 PUT TenantService/Tenants/{Tenanti} with

a body

{“acknowledge”:Yes|No} can only be used by

An Approach to Add Multi-tenancy to Existing Applications

the SaaS administrator to enable or disable access

for Tenanti. If a TenantA is acknowledged by the

administrator, then

acknowledged=1 is set for

TenantA in the Admin.Tenants table. The record for

TenantA’s admin is taken from Admin.Tenants and

added to the

Auth.Users and Auth.User_Roles tables,

assigning a Tomcat role TAdmin. Next, a new schema

TenantA is created with all the application tables for

exclusively keeping application data for TenantA,

executing the SQL script

createApplication‐

Tables.sql

(3)

POST TenantService/Tenants/{Tenanti} cre-

ates a user for Tenanti to make the user known to

the application. Using the payload, a user name and

a password are added to the

Auth.Users table for

Tomcat authentication giving the users a User role;

the association of a user to his tenant is stored in the

tenant column of the Auth.Users table. This service

is only accessible by the registered tenant admin,

i.e., the role

TAdmin is checked by Tomcat authenti-

cation. If the administrator AdminA for TenantA

registers two users UserA1 and UserA2, the

Users

and

User_Roles tables finally contain the contents

shown in Table 1; an explanation describes when

each record has been added.

Table 1: Database contents for authentication.

Users user_name user_pass tenant

 …ex.users … NULL

 SaaS SaaS NULL

in 4.3

 AdminA PwA TenantA

Step 2

 UserA1 PwA1 TenantA

Step 3

 UserA2 PwA2 TenantA

Step 3

User_Roles user_name role_name

 …ex.users …ex.roles

 SaaS SaaS

in 4.3

 AdminA TAdmin

Step 2

 UserA1 User

Step 3

 UserA2 User

Step 3

(4) UserA1 and UserA2, registered for TenantA,

are now able to authenticate. They are allowed to

use the application with a Tomcat

User role.

4.5 Making an Existing Application

Become Tenant-aware

Tenants and their users are now known to the

Tomcat application. Indeed, all these users are al-

lowed to access the application since Tomcat au-

thenticates against the

Auth.User/UserRoles tables.

Moreover, the application still uses the existing

tables in the

Appl schema for all users. Hence, the

overall effect is as if the application has new users,

but without any effective data isolation for tenants.

However, the application must enforce measures

to ensure isolation between different tenants (Guo et

al., 2007). To achieve data isolation, a user’s data

must be stored in the tenant’s schema (i.e., data-

base). This requires determining the tenant for a

logged-in user to use the correct schema; any access

must be directed to that one. Here, AspectJ comes

into play to intercept every authentication: the user

is determined and the corresponding Tenanti for the

user is derived in such a way that the original appli-

cation is not explicitly modified, i.e., compiled

and/or rebuilt. This is the novelty in our approach.

The following code sketches an AspectJ

@Around

advice which changes the behavior accordingly:

@AspectpublicclassMTE{

@Around("execution(*

com.siemens.app.ExistingAppl.svc*(..)

&&!within(com.siemens.app.aspects.MTE)")

publicObjectinterceptServices

(finalProceedingJoinPointjp){

(1) determineuserfromHTTPRequestand

deriverole&tenant(fromUserstable);

(2) storeuser/tenant/roleforlaterusage;

returnjp.proceed(jp.getArgs());/*call

originallogicofsvc*method*/

}

}

We use Java with AspectJ annotations and LTW

instead of the AspectJ language and compiler. The

annotation

 @Aspect makes a Java class MTE (Mul‐

titenancyEnabler)

be an aspect. The annotation

@Around defines an advice to be executed at join

points. @Around includes a pointcut as a String to

determine the relevant join points: Any execution of

methods starting with

svc... belonging to the basic

REST service class

ExistingAppl returning a value

of any type (

*) with any parameters (..). Instead of

wildcards, we could also specify several method

signatures individually and combine them with ‘||’.

The

@Around method interceptServices imple-

ments the logic to be executed at each join point.

This advice traps the execution of

svc... methods

and replaces the behavior with its body. The parame-

ter

jp of type ProceedingJoinPoint serves two pur-

poses. First, it is used to execute the original logic at

the join points by means of

jp.proceed(). Further-

more, jp gives access to the context of invocation

such as the parameter values (

jp.getArgs()) and the

signature of the join point (jp.getSignature()), i.e.,

the concrete svc... method to be executed.

Since the method is implicitly invoked in our as-

pect inside by

jp.proceed(), we must exclude this

invocation in order to avoid an endless loop. That is

the reason why

!within(MTE) is added in the pointcut

ICSOFT-PT 2016 - 11th International Conference on Software Paradigm Trends

to not intercept any invocation that occurs within the

aspect itself.

Only the pointcut

"execution(*

com.siemens.app. ExistingAppl.svc*(..)"

interceptServices, which specifies what methods or

services to intercept, depends on the application

code, here the class

ExistingAppl that implements

the REST service.

All of this looks very straightforward, but with

one challenge: how to get the user name from

Tomcat authentication (cf. (1) in the code above)?

Usually, there is a

HttpServletRequest req,

which can be used to derive authentication infor-

mation, e.g., by

req.getUserPrincipal().getName().

Such a variable declaration can be annotated with

@Contextin a class; the value is then injected by the

Tomcat container. But there are also other ways that

could have been used in the original application,

e.g., passing an additional

@Context HttpS‐

ervletRequest

parameter to a service method. Un-

fortunately, it is unknown what mechanism has been

used, and moreover, even a global variable

req is

usually

private and not accessible from an external

aspect.

We noticed that Tomcat invokes for authentica-

tion in any case a _

handleRequest method of a class

WebApplicationImpl

. A @Before advice can pick up

this information in the MTE aspect, to give access to

the

ServletRequest and the user name:

@Before("execution

(*com.sun.jersey.server.impl.application

.WebApplicationImpl._handleRequest(..))

&&this(w)

&&!within(com.siemens.app.aspects.MTE)")

publicvoidgetUserInfo(JoinPointjp,

WebApplicationImplw){

Stringuser=w.getThreadLocalHttpContext()

.getRequest().getUserPrincipal().getName();

determineroleandtenantforuser;

}

Please note AspectJ intercepts JARs, even of 3

party tools; the unavailability of the source code

does not hinder AspectJ to intercept Tomcat!

The clause

this(w) binds the variable w to the

called object of type WebApplicationImpl. The meth-

od getThreadLocalHttpContext() is used to get the

user who has logged in. The tenant, the user belongs

to, can be determined by using the

Auth.Users table.

But now the next challenge (2) arises: How can

the advice

interceptServices access this infor-

mation? This is possible because the aspect can be

used for sharing information. The advice

getUserIn‐

can store the user information in a variable within

the MTE aspect. The advice interceptServices simply

uses this information. That is, the user information is

shared amongst several advices in the sense of Lad-

dad’s wormhole pattern (Laddad, 2009).

This advice does not depend on the application

but only on Tomcat. Any other application server

will require slight modifications of this advice.

Next, for the purpose of tenant isolation, any

connection to the database requested from the appli-

cation must be directed to the tenant schema. This is

achieved by another advice within

MTE, e.g.:

@Around("call(java.sql.Connection

java.sql.DriverManager.getConnection( ...))

&&!within(com.siemens.app.aspects.MTE)")

publicObjectinterceptGetConnection

(finalProceedingJoinPointjp){

Object[]args=jp.getArgs();

gettheuserandtenant(storedinMTE);

Objectconn=(Connection)jp.proceed(args);

//originallogicgetsconnection

Statementstmt=conn.createStatement();

//switchtotenant’sdatabase/schema:

stmt.execute("SETSCHEMA

'"+tenant+"'");

returnconn;

}

In case of Oracle, we have to set the tenant’s schema

for any successive DB operation. Indeed, an

@After

advice would have been sufficient here. However,

other databases have different concepts to use such

as an explicit database name in the URL. This par-

tially requires to modify the

getConnection parame-

ters (obtained by jp.getArgs()) in the advice accord-

ingly before calling the original logic.

We can also implement other strategies such as

sharing the original tables between several tenants in

this advice. Obviously, this advice depends on the

database system and the isolation strategy, but not

on the application.

4.6 Customization

According to (Shahin et al., 2013) and others, a

tenant-specific customization of an application is a

major challenge of multi-tenancy. Once the tenant is

known, AspectJ enables the SaaS provider to give an

application a tenant-specific behavior without

changing the existing source code.

From an implementation point of view, each ten-

ant-specific behavior requires one aspect class. Such

a class has to implement an interface

GenericModifi‐

which demands for a method getTenantName(). A

class

TenantAModifier implements Generic Modifier

could define an aspect for TenantA. Using the get‐

TenantName

method, an advice can compare the call-

ing tenant with the expected TenantA and modify

the logic only for that tenant:

if(nameOfCallingTenant.equals(getTenantName())

{…modifylogic…

An Approach to Add Multi-tenancy to Existing Applications

}else{//don’tmodifybehavior

returnjp.proceed(jp.getArgs());

//origlogic

}

We first show how to add new features to a specific

tenant, offering additional functionality that is not

part of the original application, e.g., adding new

REST services. Please note this is not possible by

simply adding the same

@Path to another class in a

new WAR; Tomcat will complain. However, static

introduction in AspectJ helps here.

@AspectpublicclassTenantAModifier

implementsGenericModifier{

@DeclareParents(defaultImpl=com.siemens.

newfunc.NewFunctionality.class,

value="com.siemens.app.ExistingAppl")

publiccom.siemens.nf.NewFunctionalityIFmix;

}

@DeclareParents

adds a new superclass NewFunction‐

ality

of interface NewFunctionalityIF on top of

those classes that are specified by the

value clause,

here the single class ExistingAppl, which imple-

ments the REST service. The new functionality, e.g.,

a new GET service

/newFunc, can then be imple-

mented in the class NewFunctionality. 

@Path("newFunc")

publicclassNewFunctionality

implementsNewFunctionalityIF{

@GETpublicResponsesvcNewGetOperation(...)

{

...}

}

The new service will be available in the Ex‐

istingAppl

although its definition is done in another

class. The interface

NewFunctionalityIF has only

syntactical reasons to enable a cast from Ex‐

istingAppl

to NewFunctionality, its “new” super-

class. The variable

mix is of no further importance. 

Existing features can be disabled by putting an

advice around a pointcut that catches the method,

then ignoring the original call by omitting

jp.proceed(). An empty result, a result masked out

with stars ‘*’, or an HTTP code 403 (FORBIDDEN)

in case of REST services can also be returned.

Similarly, an

@Around advice can modify the ex-

isting behavior, for example extending or changing

information to be returned, removing some records

or fields from a result etc. In any case, the original

logic and result can be used for modifications.

One important question is what has to be pre-

pared by the application in order to allow intercepted

code at the right place. The power of what can be

achieved depends on the pointcut syntax (specifying

what to intercept, i.e., where to replace logic) and

the context information available at those join

points. Intercepting methods is sufficient for REST

services and always feasible. Anyway, the applica-

tion code has to be known to find appropriate join

points (although the aspect itself is satisfied with

byte code and does not require the source code).

This is in contrast to other customization approaches

that require prepared customization points, where to

plug in tenant logic, thus violating our goal to leave

the original application untouched.

4.7 Monitoring

The next point is related to economical concerns of

SaaS providers. On the one hand, IaaS/PaaS provid-

ers define cost models; a SaaS provider has to pay

for running an application in a public cloud. On the

other hand, a SaaS provider has to define a billing

model to charge his tenants for using the application.

Both models have to be balanced in such a way that

a SaaS provider is able to make profit. The invest-

ment covers both the operational costs in a Cloud as

well as the costs for developing an application or

SaaS-enabling it (Momm and Krebs, 2011) and later

maintenance (Bezemer et al., 2010).

Most popular public cloud billing models are

post-paid models where the tenant receives a bill and

pays for usage periodically. This requires monitoring

and aggregating the consumption costs of each ten-

ant (Ruiz-Agundez et al., 2011). A SaaS provider

can also charge his tenants by a fixed rate, e.g., per

month or based upon other factors such as the num-

ber of users (registered or in parallel). Here, it is

important to predict the costs a tenant’s usage will

produce. Moreover, exhaustive usage by one tenant

could reduce the SaaS providers’ revenue.

No matter what billing model would be applied,

it is necessary to monitor and log the activities of all

tenants’ users and the costs they produce.

(Schwanengel and Hohenstein, 2013) discuss the

challenges of calculating the costs each tenant gen-

erates in a public cloud to establish a profitable bill-

ing model for a SaaS application. They show that

only rudimentary support is available by cloud pro-

viders. A user receives a monthly bill from a cloud

provider, not being detailed enough to determine the

costs for resources for each tenant individually.

To enable a tenant-specific monitoring, we added

a table

UserMonitoring(id, name, tenant, opera‐

tion, timestamp, elapsed)

to the Admin schema in

order to track tenants’ users activities.

We again use AspectJ to intercept any relevant

user actions. To this end, we extend the i

nter‐

ceptServices

advice in Subsection 4.5 to compute

the elapsed time around

jp.proceed() and to log it

together with the signature of the method, tenant,

user etc. at a central place. Dedicated pointcuts can

ICSOFT-PT 2016 - 11th International Conference on Software Paradigm Trends

define what has to be tracked; this might depend on

the application. The table now gives an overview

over all user activities. This forms the basis for

 a consumption-based model that charges back

tenants for their consumed resources;

 a tenant-specific profit-making check, i.e.,

whether the chosen business model for one/all

tenant(s) is appropriate to make profit;

 a timely reaction on frequent and massively

active tenants to throttle them before costs rise.

The presented approach is quite general and can

support further use cases. If a Service Level Agree-

ment (SLA) specifies a certain maximum number of

concurrent users, this SLA can be checked by a

@Before advice: Before executing a service request,

the number of concurrent users for the tenant is

checked in the

UserMonitoring table. Similarly, it is

possible to accumulate the (elapsed) execution times

or the number of service requests for each user or

tenant and to throttle or reject further access if

thresholds are exceeded. If an SLA states a threshold

for the number of registered users, the

Users table

can be used to supervise the limit in the user regis-

tration process. Finally, we can use the monitoring

information to implement auto-scaling features that

benefit from a Cloud’s elasticity.

5 EVALUATION

5.1 Advantages

We certainly achieve the general advantages of mul-

ti-tenancy such as cost saving by sharing resources

(hardware, application server, database etc.) among

tenants and reducing operational expenses (OPEX).

The additional advantage of our approach lies in

the fact that the source code of the existing applica-

tion does not need to be modified explicitly.

In order to add tenant management, we have to

deploy a new admin service (cf. 4.4) as a WAR file.

Adding

MTE.class to the deployed application WAR,

we achieve tenant isolation. Additional files Ten‐

antXModifier.class

in the WAR can provide a ten-

ant-specific behavior for each TenantX. This facili-

tates customization. Thanks to AspectJ load-time

weaving, only a restart of Tomcat is required to

make the multi-tenancy aspects apply.

All the multi-tenancy logic is concentrated in

classes to be added. These components rely on sim-

ple mechanisms that can easily be applied to other

legacy applications to make them multi-tenant.

Thus, development cost can be reduced.

The

MTE aspect mainly depends on tools, i.e., the

application server and the DB system, especially the

isolation strategy to apply. That is, a modification of

this aspect becomes necessary only if we, e.g.,

switch to JBoss and/or MySQL. The pointcuts to

intercept DB accesses are not DB-specific but rely

on JDBC. Any adoption and modification to other

tools can be made in central components anyway.

However, the pointcut

interceptServices in MTE

also specifies the application methods to be inter-

cepted. Other applications require different

pointcuts. To this end, an abstract aspect can imple-

ment an advice, but leave out the pointcut, while

application-specific sub-aspects specify the concrete

specific pointcuts, but reuse the general logic.

In general, REST services are easier to handle.

There are methods annotated with @GET, @PUT

etc., which are the entry points for functionality.

Moreover, it is just Java code.

Taking a look at the lines of code, it becomes

obvious how simple the approach is:

 The new tenant management service consists of

about 400 lines of Java code;

 The aspect

MTE has about 150 lines;

 Any

TenantXModifier certainly depends on what

should be modified. To give an impression for

REST services, an advice to disable functionality

has 10 lines, an advice introducing a new REST

service about 60, and an advice for a simple

modification of behavior has 23 lines.

To sum up, the approach offers a cost-efficient way

to migrate existing applications quickly and cheaply

into SaaS-offerings speeding up time-to-market.

Moreover, our approach also allows for a flexible

configuration, e.g., for tenant isolation (one DB

server or one DB for each tenant, single-table for all

tenants).

5.2 Lessons Learned

In case of AOP, comprehension and maintainability

are often cited. However, we did not detect any

problems. In fact, we only have a small number of

aspects. Moreover, the behavior of aspects is man-

ageable, especially since AO is not available to all

programmers.

One major contribution of AOP we benefit from

is the possibility to exchange information between

even unrelated classes by means of an aspect accord-

ing to the “Wormhole Pattern” (Laddad, 2009).

Anyway, we also detected some limitations: The

first idea to let newly registered users to authenticate

was to have a

Users table in each tenant schema.

An Approach to Add Multi-tenancy to Existing Applications

Authentication must then be intercepted to refer to

the correct database. We ran into the technical prob-

lem that authentication is part of the Tomcat con-

tainer, i.e., to intercept loading the application is not

sufficient. Our attempts to intercept loading Tomcat

failed (but maybe we overlooked a possibility).

6 CONCLUSIONS

This paper presented an approach for migrating

existing single-tenant to fully multi-tenant applica-

tions, which can afterwards be offered as SaaS.

While other approaches require a more or less

large reengineering of the existing source code in

order to bring in multi-tenancy, our approach con-

sists of simply adding components to the legacy

application – without explicitly touching the existing

application’s source code.

The additive components are implemented as as-

pects in AspectJ and depend only on technological

choices such as application server, database system,

and the data isolation strategy. The components can

easily be applied to other applications by just adjust-

ing some pointcuts.

Using an existing REST application that runs in

Tomcat and uses Oracle, the paper presented the

approach and discussed how to achieve two main

concerns in detail:

 tenant isolation (Chong and Carraro, 2006);

 tenant-specific customization of behavior.

We demonstrated the details of the approach and the

effort to be spent; the overall principle requires only

a few 100 lines of aspect code. We also elaborated

upon how to benefit from AspectJ in this respect and

concluded with some evaluation and lessons learnt.

In fact, REST services are simpler to handle as

demonstrated in this paper. There is just Java code

without any parts in HTML or Javascript. Future

work will go one step further and tackle other types

of applications, especially to determine the limits. So

far, we have first experiences that show the

MTE

aspect working well. Customization of logic is also

possible as far as no GUI is concerned. Further in-

vestigations will handle customizing the UI. Moreo-

ver, we want to combine our approach with feature

modeling tools to control the configuration in an

easy manner.

Certainly, migrating an application into the cloud

is much more than just adding multi-tenancy. In case

of too much load, e.g., several Tomcat instances

have to be started with a load balancer in front. Tak-

ing care of scalability issues and replacing software

components with Cloud services is also subject to

future work.

REFERENCES

Andrikopoulos, V., Binz, T., Leymann, F., Strauch, S.,

2013. How to adapt applications for the Cloud envi-

ronment - Challenges and solutions in migrating appli-

cations to the cloud. Computing 2013, 95(6): pp. 493-

535.

Bezemer, C., Zaidman, A. Platzbeecke, B. Hurkmans, T.,

Hart, A., 2010. Enabling multitenancy: An industrial

experience report. In: Technical Report of Delft Uni. of

Technology, TUD-SERG-2010-030, 2010.

Bezemer, C., Zaidman, A., 2010. Challenges of reengi-

neering into multitenant SaaS applications. In: Tech-

nical Report of Delft Uni. of Technology, TUD-SERG-

2010-012, 2010.

Binz, T., Leymann, F., Schumm, D., 2011: CMotion: A

framework for migration of applications into and be-

tween clouds. SOCA 2011, pp 1-4.

Chong, F., Carraro, G., 2006. Architecture strategies for

catching the long tail (2006), https://msdn

.microsoft.com/en-us/library /aa479069.aspx.

Chong, F., Carraro, G., Wolter, R., 2006. Multi-tenant data

architecture. http://msdn.microsoft.com/en-us/library

/aa479086.aspx (June 2006).

Elrad, T., Filman, R., Bader, A., 2001: Theme section on

aspect-oriented programming. CACM 44(10), 2001.

Fehling, C., Leymann, F., Mietzner, R., 2010: A frame-

work for optimized distribution of tenants in cloud ap-

plications. IEEE 3rd Int. Conference on, Cloud Com-

puting (CLOUD), 2010, pp. 252-259.

Guo, C., Sun, W., Huang, Y., Wang, Z., Gao, B., 2007: A

framework for native multi-tenancy application devel-

opment and management. In: CEC/EEE 2007: Int.

Conf. on Enterprise Computing, E-Commerce Tech-

nology and Int. Conf. On Enterprise Computing, E-

Commerce and E-Services, pp. 551-558 (2007).

Khajeh-Hosseini, A., Greenwood, D., Smith, J., Sommer-

ville, I., 2012. The cloud adoption toolkit: supporting

cloud adoption decisions in the enterprise. Software,

Practice Experiences 42(4): 447-465 (2012).

Kiczales, G., et al., 2007. Aspect-oriented programming.

In: Proc. of the European Conf. on Object-Oriented

Programming (ECOOP), pp. 230-242, Finland 1997.

Kong, L., Li, Q., Zheng, X., 2010. A novel model support-

ing customization sharing in SaaS applications,” in Int.

Conf. on Multimedia Information Networking and Se-

curity (MINES), 2010, pp. 225–229.

Krebs, R., Momm, C., Kounev, S., 2012. Architectural

concerns in multi-tenant SaaS applications. CLOSER

2012, pp. 426-431.

Kwok, T., Nguyen, T., Lam, L., 2008. A software as a

service with multi-tenancy support for an electronic

contract management application. In: Int. Conf. on

Services Computing (SCC) 2008. pp. 179-186.

Laddad, R., 2009: AspectJ in Action: Practical Aspect-

ICSOFT-PT 2016 - 11th International Conference on Software Paradigm Trends

Oriented Programming (2nd ed.) Manning, Greenwich

(2009).

Lee, W., Choi, M., 2012. A multi-tenant web application

framework for SaaS. In 2012 IEEE 5th Int. Conf. on

Cloud Computing (CLOUD), 2012, pp. 970–971.

Lee, J., Kang, S., Hur, S., 2012. Web-based development

framework for customizing java-based business logic

of SaaS application. In 14th Int. Conf. on Advanced

Communication Technology (ICACT), 2012, pp.

1310–1313.

Li, Q., Liu, S., Pan, Y., 2012. A cooperative construction

approach for SaaS applications. In 2012 IEEE 16th Int.

Conf. on Computer Supported Cooperative Work in

Design (CSCWD), 2012, pp. 398–403.

Lizhen, C., Haiyang, W., Lin, J., Pu, H., 2010. Customiza-

tion modeling based on metagraph for multi-tenant

applications. In 5th Int. Conf. on Pervasive Computing

and Applications (ICPCA), 2010, pp. 255–260.

Mell, P., Grance, T., 2011. The NIST definition of cloud

computing,” National Institute of Standards and Tech-

nology, Sept. 2011. http://csrc.nist.gov /publications/

nistpubs/800-145/SP800-145.pdf.

Moens, H., Truyen, E., Walraven, S., Joosen, W., Dhoedt,

B., De Turck, F., 2012. Developing and managing cus-

tomizable software as a service using feature model

conversion. In IEEE Network Operations and Man-

agement Symposium (NOMS), 2012, pp. 1295–1302.

Momm, C., Krebs, R., 2011. A qualitative discussion of

different approaches for implementing multi-tenant

SaaS offerings. Proc. Software Engineering 2011, pp.

139-150.

Orue-Echevarria et al., 2014. Cloudifying applications

with ARTIST: A global modernization approach to

move applications onto the cloud. CLOSER 2014, pp.

737-745.

Park, J., Moon, M., Yeom, K., 2011. Variability modeling

to develop flexible service-oriented applications.

Journal of Systems Science and Systems Engineering

2011, Vol. 20, no. 2, pp. 193–216.

Pohl, K., Böckle, G., v. d. Linden, F., 2005. Software

product line engineering: foundations, principles and

techniques. Secaucus, NJ, USA: Springer-Verlag New

York, Inc., 2005.

Ruiz-Agundez, I., Penya, Y., Bringas, P., 2011. A flexible

accounting model for cloud computing," SRII, 2011.

Schwanengel, A., Hohenstein, U., 2013. Challenges with

tenant-specific cost determination in multi-tenant ap-

plications. 4th Int. Conf. on Cloud Computing, Grids

and Virtualization 2013.

Shahin, A., Samir, A., Khamis, A., 2013. An aspect-

oriented approach for SaaS application customization.

48th Conf. on Statistics, Computer Science and Opera-

tions Research, Cairo University, Egypt, 2013.

Tsai, W., Shao, Q., Li, W., 2010. OIC: Ontology-based

intelligent customization framework for SaaS. In IEEE

Int. Conf. on Service-Oriented Computing and Appli-

cations (SOCA), 2010, pp. 1–8.

Tsai, W., Sun, X., 2013. SaaS multi-tenant application

customization. In IEEE 7th Int. Symposium on Service

Oriented System Engineering (SOSE), 2013, pp. 1–12.

Walraven, S., Truyen, E., W. Joosen, W., 2011. A mid-

dleware layer for flexible and cost-efficient multi-

tenant applications. Proc. on Middleware, 2011 (LNCS

7049), pp. 370-389.

Wang Z. et al, 2008: A study and performance evaluation

of the multi-tenant data tier design pattern for service

oriented computing. In IEEE Int. Conf. On eBusiness

Engineering, (ICEBE) 2008, 94-101.

Wang, H., Zheng, Z., 2010. Software Architecture Driven

Configurability of Multi-tenant Saas Applications.

LNCS Vol. 6318, 2010 pp. 418-424.

Zhou, X., Yi, L., Liu, Y., 2011. A collaborative require-

ment elicitation technique for SaaS applications. In

2011 IEEE Int. Conf. on Service Operations, Logistics,

and Informatics (SOLI), 2011, pp. 83–88.

An Approach to Add Multi-tenancy to Existing Applications
