An Approach to Off-talk Detection based on Text Classification
within an Automatic Spoken Dialogue System
Oleg Akhtiamov, Roman Sergienko and Wolfgang Minker
Institute of Communications Engineering, Ulm University, Albert Einstein Allee 43, Ulm, Germany
Keywords: Human-human-machine Interaction, Text Processing, Term Weighting, Feature Transformation.
Abstract: This paper describes the problem of the off-talk detection within an automatic spoken dialogue system. The
considered corpus contains realistic conversations between two users and an SDS. A two- (on-talk and off-
talk) and a three-class (on-talk, problem-related off-talk, and irrelevant off-talk) problem statement are
investigated using a speaker-independent approach to cross-validation. A novel off-talk detection approach
based on text classification is proposed. Seven different term weighting methods and two classification
algorithms are considered. As a dimensionality reduction method, a feature transformation based on term
belonging to classes is applied. The comparative analysis of the proposed approach and a baseline one is
performed; as a result, the best combinations of the text pre-processing methods and classification algorithms
are defined for both problem statements. The novel approach demonstrates significantly better classification
effectiveness in comparison with the baseline for the same task.
1 INTRODUCTION
As a rule, the interaction between a human and an
automatic spoken dialogue system (SDS) is
considered as a human-machine type of conversation.
However, this is an ideal case; real SDSs deal with a
mixed type of interaction, which may also include
human-human conversations, particularly in the
situations of collective problem solving, when one
user talks to the system directly and to other people at
the same time retelling and discussing the information
obtained from the system. Such a system is supposed
to be selective to react properly to each utterance: to
respond immediately, to analyse without a direct
response (for instance, for context definition or user
image creation), or to ignore. Considering this, we
specify three types of users’ talk: the first one is on-
talk; it comprises explicit problem-oriented requests
to the system. The second type is problem-related off-
talk, which includes phrases implicitly addressed to
the system, for example, retelling or discussing the
obtained information between users. Though such
utterances are not intended to be a direct system input,
they could be useful for the system adaptation to
users’ behaviour. The third type is irrelevant off-talk;
this class is useless for the particular task and should
be ignored in order not to confuse the system.
The obtained classification problem can be
transformed into a text categorization task directly
after speech recognition. In the vector space model
(Sebastiani, 2002), text categorization is considered
as a machine learning problem. The complexity of the
text categorization with the vector space model is
compounded by the need to extract numerical data
from text information before applying machine-
learning methods. Therefore, text pre-processing is
required and can be performed using term weighting.
At first sight, we obtain an ordinary text
classification task. However, off-talk detection faces
some special challenges, since off-talk is a complex
phenomenon, which is difficult to handle using only
lexical information. There are some works on off-talk
detection considering lexical (lexical n-gram
approach) (Shriberg et al., 2012), acoustic-prosodic
(prosodic n-gram approach), and visual (visual focus
of attention) features (Batliner et al., 2006). The Bag-
of-Words approach (lexical unigram) presented there
does not use any advanced term weighting
techniques, which could significantly improve
classification effectiveness. In this research, we use
only lexical information (Bag-of-Words model with
advanced term weighting) in order to conclude how
representative it can be for off-talk detection.
There exist different unsupervised and
288
Akhtiamov, O., Sergienko, R. and Minker, W.
An Approach to Off-talk Detection based on Text Classification within an Automatic Spoken Dialogue System.
DOI: 10.5220/0005977802880293
In Proceedings of the 13th International Conference on Informatics in Control, Automation and Robotics (ICINCO 2016) - Volume 2, pages 288-293
ISBN: 978-989-758-198-4
Copyright
c
 2016 by SCITEPRESS – Science and Technology Publications, Lda. All rights reserved

supervised term weighting methods. The most well-
known unsupervised term weighting method is TF-
IDF (Salton and Buckley, 1988). The following
supervised term weighting methods are also
considered in the paper: Gain Ratio (Debole and
Sebastiani, 2004), Confident Weights (Soucy and
Mineau, 2005), Second Moment of a Term (Xu and
Li, 2007), Relevance Frequency (Lan et al., 2009),
Term Relevance Ratio (Ko, 2012), and Novel Term
Weighting (Gasanova et al., 2014).
The considered text pre-processing techniques
usually lead to high dimensionality for a text
classification task. Therefore, we apply the Feature
Transformation Method Based on Term Belonging to
Classes for dimensionality reduction (Sergienko et
al., 2016).
As machine learning algorithms, we choose two
approaches, which have demonstrated good results
for the task of natural language call routing
(Sergienko et al., 2016): the method of k Nearest
Neighbours (KNN) (Zhou et al., 2009) and the
Support Vector Machine-based algorithm Fast Large
Margin (SVM-FLM) (Fan et al., 2008). This task and
the current one are quite close to each other in the
view of text classification.
This paper is organized as follows. In Section 2,
we describe two problem statements and a corpus.
Section 3 contains the description of term weighting
and the feature transformation method. In Section 4,
a baseline off-talk detection approach is compared
with the proposed one for the same corpus. Finally,
we provide concluding remarks and directions for
future investigations in Section 5.
2 CORPUS DESCRIPTION
The corpus we have used for our research was created
with a real SDS within the publicly funded German
Smart Web project and contains human-human-
machine interactions (audio and video) in the context
of a visit to the Football World Cup in 2006 (Batliner
et al., 2006). The recordings took place in situations,
which were as realistic as possible. No instructions
regarding off-talk were given. The user was carrying
a mobile phone and was interrupted by another
person. This way, a large amount of off-talk could be
evoked. The user was asking for transport
information, a competition program, which sights
were worth visiting, etc. 2218 segmented turns of 99
different German speakers were recorded. There are
2970 user utterances in total; one utterance includes
all successive sentences belonging to one class within
one turn.
The original corpus has the following labels: the
1
st
class – on-talk (a normal request), the 2
nd
one –
reading off-talk (a user reads the system response
from the display aloud), the 3
rd
class - paraphrasing
off-talk (a user retells others the information from the
display), the 4
th
one – spontaneous off-talk (other off-
talk, for instance, thinking aloud or interruptions).
We observe two different problem statements: the
first one contains three classes (classes 2 and 3 are
merged into one - problem-related off-talk), the
second statement is a simplified version of the first
one and contains two classes (classes 2-4 are merged
into one – off-talk). We perform a speaker-
independent validation, since it allows us to obtain
more representative results, especially when the real
system has a wide user audience.
We have split the corpus into 15 random subsets
for the cross-validation. After that, we establish a
training and a test set for each subset; different test
sets have no intersection. For each training set, we
have designed a vocabulary of unique words, which
appear in the set. The size of the vocabulary varies
from 1,355 to 1,421 words for different subsets.
3 TEXT PRE-PROCESSING
After the generation of training and test samples, we
performed term weighting. As a rule, term weighting
is a multiplication of two parts: the part based on term
frequency in a document (TF) and the part based on
term frequency in the whole database. The TF-part is
fixed for all considered term weighting methods and
calculated in the following way:
j
ij
ijijij
N
n
tftfTF  );1log(
,
where n
ij
is the number of times the i
th
word occurs in
the j
th
document, N
j
is the document size (number of
words in the document).
The second part of term weighting is calculated
once for each word from the vocabulary and does not
depend on an utterance for classification. We
consider seven different methods for the calculation
of the second part of term weighting.
3.1 Inverse Document Frequency (IDF)
IDF is a well-known unsupervised term weighting
method, which was proposed in (Salton and Buckley,
1988). There are some modifications of IDF, and we
use the most popular one:
An Approach to Off-talk Detection based on Text Classification within an Automatic Spoken Dialogue System
289

i
i
n
D
idf log
,
where |D| is the number of documents in the training
set, and n
i
is the number of documents that have the
i
th
word.
3.2 Gain Ratio (GR)
Gain Ratio (GR) is mainly used in term selection
(Yang and Pedersen, 1997). However, it was shown
in (Debole and Sebastiani, 2004) that it could also be
used for weighting terms, since its value reflects the
importance of a term. The definition of GR is as
follows:
  
 
,
)(log)(
)()(
),(
log),(
),(
,
, ,

 

 




jj
jj jj
ccc
ccc ttt
ji
cPcP
cPtP
ctP
ctP
ctGR
where P(t, c) is the probability estimation that a
document contains the term t and belongs to the
category c; P(t) is the probability estimation that a
document contains the term t, and P(c) is the
probability estimation that a document belongs to the
category c.
Then, the weight of the term t
i
is calculated as the
max value between all categories:
),(max)(
ji
Cc
i
ctGRtGR
j


,
where C is a set of all classes.
3.3 Confident Weights (CW)
The method uses the special value Maxstr as an
analogy of IDF.
First of all, the method estimates the probability P
that a document contains the term t with the
confidence interval for every category c
j
, to get
)|(
j
ctP
and
)|(
j
ctP
with a confidence interval. Let
M denote the lower bound of
)|(
j
ctP
and N denote
the upper bound of
)|(
j
ctP
. The strength of the term
t
i
considering c
j
is defined as follows:
 














otherwise
NMif
NM
M
ctstr
,0
,
2
log
),(
2
.
The maximum strength (Maxstr) of the term t is
calculated in the following way:
 
2
),(max)( ctstrtMaxstr
Cc

.
where C is a set of all classes.
3.4 Second Moment of a Term (TM2)
Let
)|( tcP
j
be the probability estimation that a
document belongs to the category c
j
with the
condition that the document contains the term t and
belongs to the category c; P(c
j
) is the probability
estimation that a document belongs to the category c
without any conditions. The idea is as follows: the
more
)|( tcP
j
is different from P(c
j
), the more
important the term t
i
is. Therefore, we can calculate
the term weight in the following way:
 



C
j
jji
cPtcPtTM
1
2
)()|()(
.
3.5 Relevance Frequency (RF)
The RF value is calculated as follows:
,
},1max{
2log),(
2









j
j
ji
a
a
ctrf
),(max)(
ji
Cc
i
ctrftrf
j


,
where a
j
is the number of documents of the category
c
j
which contain the term t
i
, and
j
a
is the number of
documents of all the remaining categories which also
contain this term.
3.6 Term Relevance Ratio (TRR)
The TRR method uses tf weights and is calculated as
follows:
,
)|(
)|(
2log),(
2









ji
ji
ji
ctP
ctP
ctTRR


 


V
l
T
k
lk
T
k
ik
i
c
c
tf
tf
ctP
1 1
1
)|(
,
),(max)(
ji
Cc
i
ctTRRtTRR
j


,
where c
j
is the class of a document,
j
c
is all the other
classes of c
j
, V is the vocabulary of the training data,
and T
c
is the document set of the class c.
ICINCO 2016 - 13th International Conference on Informatics in Control, Automation and Robotics
290

3.7 Novel Term Weighting (NTW)
This method was proposed in (Gasanova et al., 2014).
Let L be the number of classes; n
i
is the number of
documents which belong to the i
th
class; N
ij
is the
number of occurrences of the j
th
word in all articles
from the i
th
class. T
ij
= N
ij
/ n
i
is the relative frequency
of occurrences of the j
th
word in the i
th
class;
ij
i
j
TR max
;
)maxarg(
ij
i
j
TS 
is the class which
we assign to the j
th
word. The term relevance C
j
is
calculated in the following way:
).
1
1
(
1
1
1







L
Si
i
ijj
L
i
ij
j
j
T
L
R
T
C
3.8 Feature Transformation Method
We propose a feature transformation method based on
term belonging to classes (Sergienko et al., 2016).
The idea is to assign each term from the vocabulary
to the most appropriate class. Such an assignment is
performed during the calculation of GR, CW, RF,
TRR and NTW. With TF-IDF and TM2, we can also
assign one class for each term using the relative
frequency of the word in classes:
c
jc
Cc
j
N
n
S

 maxarg
,
where S
j
is the most appropriate class for the j
th
term,
c is the index of a class, C is a set of all classes, n
jc
is
the number of documents of the c
th
class which
contain the j
th
term, N
c
is the number of all documents
of the c
th
class.
After assigning each word to one class and term
weighting, we can calculate the sums of term weights
in a document for each class. We can put these sums
as new features of the text classification problem.
Therefore, such a method reduces the dimensionality
significantly; the dimensionality of the classification
problem equals the number of classes.
4 OFF-TALK DETECTION
APPROACHES
4.1 Baseline Off-talk Detection
Approach
The authors of the corpus performed their own
research on off-talk detection (Batliner et al., 2006).
They processed the audio data using an automatic
speech recogniser with manual proofreading and
extracted two groups of features: the first one is
prosodic features, which evaluate 95 different speech
characteristics such as speech rate, pause duration,
accents and many others. A detailed overview of
prosodic features is given in (Batliner et al., 2003).
The second group is part-of-speech features. There
are 5 different part-of-speech classes considered
(nouns, adjectives, verbs, etc.); one of them is
assigned to each word from the vocabulary (Batliner
et al., 1999). After that, an n-gram approach is
implemented for both groups of features with n=5.
As a classification method, the authors used
Linear Discriminant classification (LDA) and
estimated its performance as unweighted mean recall
(R). They obtained the same two- and three-class
problem statement and tested them using the speaker-
independent validation (Batliner et al., 2006).
The highest classification performance is reached
with all available features: R equals 0.681 and 0.600
for the two- and three-class task respectively.
4.2 Proposed Off-talk Detection
Approach
We implement the proposed approach based on text
classification using SVM-FLM (Fan et al., 2008) and
KNN (Zhou et al., 2009). These methods show
successful results for text classification tasks
(Sergienko et al., 2016), are able to solve high-
dimensionality problems, and possess moderate
resource consumption. There are effective
implementations of these algorithms built in the
RapidMiner free software package (Shafait et al.,
2010), which we use to solve our classification tasks.
As the main criterion of classification
effectiveness, we have to use the same estimation
based on unweighted mean recall (R) as the authors
did in their research, since it allows us to compare the
final results correctly. However, as the main criterion
of classification effectiveness during the process of
the parametric optimization for the parameter k in
KNN, we use the macro F-score (Baeza-Yates and
Ribeiro-Neto, 1999). It is a more representative
performance estimation than unweighted mean recall;
in some cases, the recall value can be equal to 1, but
in fact, the classifier effectiveness is not equal to
100%, since the precision value remains low. The
macro F-score does not possess this disadvantage; it
is calculated as the geometric mean of mean precision
and mean recall:
An Approach to Off-talk Detection based on Text Classification within an Automatic Spoken Dialogue System
291

ii
i
i
Dr Df
P
Df


,
ii
i
i
Dr Df
R
Dr


,
R
a
P
a
aF
1
)1(
1
1
)(


,
 
0,1a
,
where i is the number of a class, Dr
i
is the set of
objects in a test set, which belong to this class, Df
i
is
the set of objects in the test set classified by the
system to this class. We calculate the macro F
1
score
assuming a=0.5.
The optimal k value for KNN is specified from the
interval [1, 30] for each training set. It is natural that
we do not use any information from the test sets
during the process of parametric optimization in order
to keep the results as representative as possible.
Searching for k, we split each training set into a new
training and a validating set in order to perform
exhaustive search among all possible k using this pair
of sets.
We tested all possible combinations of the term
weighting methods (with and without the feature
transformation method) and the machine learning
algorithms for both classification tasks:
Table 1: Results of the classification algorithms with
different term weighting methods tested for the two-class
task with the speaker-independent validation.
KNN
SVM-FLM
TM2+FT
0.907
NTW
0.910
RF
0.896
RF
0.907
TRR
0.892
IDF
0.905
NTW+FT
0.892
TM2+FT
0.903
CW
0.887
TRR
0.901
IDF
0.881
NTW+FT
0.891
CW+FT
0.880
RF+FT
0.880
TRR+FT
0.879
CW+FT
0.876
RF+FT
0.879
TM2
0.871
NTW
0.879
TRR+FT
0.867
TM2
0.879
IDF+FT
0.859
GR
0.877
CW
0.836
IDF+FT
0.857
GR+FT
0.731
GR+FT
0.772
GR
0.638
Table 2: Results of the classification algorithms with
different term weighting methods tested for the three-class
task with the speaker-independent validation.
KNN
SVM-FLM
NTW
0.869
RF
0.893
NTW+FT
0.866
NTW
0.887
TRR
0.864
TRR
0.887
RF+FT
0.863
IDF
0.886
CW
0.863
TM2+FT
0.863
TM2+FT
0.863
TRR+FT
0.850
CW+FT
0.862
NTW+FT
0.849
RF
0.862
CW
0.849
TRR+FT
0.857
CW+FT
0.848
TM2
0.856
RF+FT
0.844
IDF
0.846
TM2
0.837
IDF+FT
0.843
IDF+FT
0.827
GR
0.843
GR
0.739
GR+FT
0.606
GR+FT
0.387
The tables contain unweighted mean recall values.
The mark ‘+FT’ means that the feature transformation
method is implemented. The best term weighting
methods are emphasized and have no statistically
significant difference between each other within one
column. The variable distributions are close to normal
that allows us to use t-test. The given results are
relevant with the confidential probability 0.95.
According to t-test, SVM-FLM works
significantly better than KNN for the task with three
classes. For the two-class task, there is no significant
difference between the classification algorithms.
5 CONCLUSIONS
The off-talk detection task has been solved with the
proposed approach based on text classification, which
shows effective results for both problem statements.
There is a set of the best term weighting methods with
no significant difference in their effectiveness within
each problem statement. The highest unweighted
mean recall for the two-class task equals 0.910 and is
reached with NTW and SVM-FLM, for the three-
class task - 0.893 (with RF and SVM-FLM).
The proposed approach outperforms the baseline
one: R equals 0.681 and 0.600 at the two- and three-
class task respectively for the baseline approach,
while the proposed approach demonstrates the values
0.910 and 0.893 at the same tasks. A possible reason
ICINCO 2016 - 13th International Conference on Informatics in Control, Automation and Robotics
292

of this is the assumption that the proposed approach
uses more effective data pre-processing methods and
machine learning algorithms for off-talk detection.
Another possible reason is a conceptual contradiction
in the baseline approach; the fact that it uses prosodic
features for off-talk detection means that users are
supposed to change their normal manner of speech
once they start talking to a computer. Such an
approach can work now, since modern dialogue
systems are still far from perfection, and users have
to adapt their behaviour talking to them. However, it
does not correspond to the main direction of
automatic dialogue system development – to make
the interaction between a user and a system as natural
as possible.
Any additional data processing (speech
recognition, text pre-processing, etc.) causes an
information loss. Deep learning neural networks
possess some features, which could improve
classification effectiveness: due to their ability to
work with entities of different abstraction levels, they
do not require additional data processing and are able
to make the system more effective and flexible.
Moreover, the works on off-talk detection (Shriberg
et al., 2012) and (Batliner et al., 2006) state that using
more than one group of features significantly
improves classification effectiveness. The choice of
relevant features can also be delegated to a system
based on deep learning neural networks. Therefore, as
a future direction, we propose the research of a deep
learning neural network-based approach to off-talk
detection.
REFERENCES
Sebastiani, F. 2002. Machine learning in automated text
categorization. ACM computing surveys (CSUR),
34(1):1-47.
Salton, G. and Buckley, C. 1988. Term-weighting
approaches in automatic text retrieval. Information
processing & management, 24(5):513-523.
Debole, F. and Sebastiani, F. 2004. Supervised term
weighting for automated text categorization. Text
mining and its applications:81-97. Springer Berlin
Heidelberg.
Soucy P. and Mineau G. W. 2005. Beyond TFIDF
Weighting for Text Categorization in the Vector Space
Model. Proceedings of the 19th International Joint
Conference on Artificial Intelligence (IJCAI
2005):1130-1135.
Xu, H. and Li, C. 2007. A Novel term weighting scheme for
automated text Categorization. Intelligent Systems
Design and Applications, 2007. ISDA 2007. Seventh
International Conference on:759-764. IEEE.
Lan, M., Tan, C. L., Su, J., and Lu, Y. 2009. Supervised and
traditional term weighting methods for automatic text
categorization. Pattern Analysis and Machine
Intelligence, IEEE Transactions on, 31(4):721-735.
Ko, Y. 2012. A study of term weighting schemes using class
information for text classification. Proceedings of the
35th international ACM SIGIR conference on Research
and development in information retrieval:1029-1030.
ACM.
Gasanova, T., Sergienko, R., Akhmedova, S., Semenkin,
E., and Minker, W. 2014. Opinion Mining and Topic
Categorization with Novel Term Weighting.
Proceedings of the 5th Workshop on Computational
Approaches to Subjectivity, Sentiment and Social
Media Analysis, Association for Computational
Linguistics, Baltimore, Maryland, USA, 84–89.
Fan, R. E., Chang, K. W., Hsieh C. J., Wang X. R., Lin C.
J. 2008. Liblinear: A library for large linear
classification. The Journal of Machine Learning
Research, 9, 1871–1874.
Yang, Y., and Pedersen, J. O. 1997. A comparative study
on feature selection in text categorization. ICML, vol.
9:412-420.
Batliner, A., Hacker, C., and Noth, E. 2006. To Talk or not
to Talk with a Computer: On-Talk vs. Off-Talk. How
People Talk to Computers, Robots, and Other Artificial
Communication Partners, 79-100.
Batliner, A., Fischer, K., Huber, R., Spilker, J., Noth, E.
2003. How to Find Trouble in Communication. Speech
Communication, 40, 117–143.
Batliner, A., Nutt, M., Warnke, V., Noth, E., Buckow, J.,
Huber, R., Niemann, H. 1999. Automatic Annotation
and Classification of Phrase Accents in Spontaneous
Speech. Proc. of Eurospeech99, 519–522.
Zhou, Y., Li, Y., and Xia, S. 2009. An improved KNN text
classification algorithm based on clustering. Journal of
computers, 4(3), 230-237.
Sergienko, R., Muhammad, S., and Minker, W. 2016. A
comparative study of text preprocessing approaches for
topic detection of user utterances. In Proceedings of the
10th edition of the Language Resources and Evaluation
Conference (LREC 2016).
Baeza-Yates, R; Ribeiro-Neto, B. 1999. Modern
Information Retrieval. New York, NY: ACM Press,
Addison-Wesley, 75.
Shriberg, E., Stolcke, A., Hakkani-Tur, D., Heck, L. 2012.
Learning When to Listen: Detecting System-Addressed
Speech in Human-Human-Computer Dialog.
Proceedings of Interspeech 2012, 334-337.
Shafait, F., Reif, M., Kofler, C., and Breuel, T. M. 2010.
Pattern recognition engineering. In: RapidMiner
Community Meeting and Conference, Citeseer, vol 9.
An Approach to Off-talk Detection based on Text Classification within an Automatic Spoken Dialogue System
293
