Automatic Fongbe Phoneme Recognition From Spoken Speech Signal

ejus A. A. Laleye

1,2

, Eug

ene C. Ezin

and Cina Motamed

Laboratoire d’Informatique Signal et Image de la C

ote d’Opale, Universit

e du Littoral C

ote d’Opale,

50 rue F. Buisson, BP 719, 62228 Calais Cedex, France

Unit

e de Recherche en Informatique et Sciences Appliqu

ees, Institut de Math

ematiques et de Sciences Physiques,

Universit

e d’Abomey-Calavi, BP 613 Porto-Novo, Benin

Keywords:

Formant Analysis, Fuzzy Logic, Deep Belief Networks, Phoneme Recognition, Continuous Speech Segmen-

tation, Fongbe Language.

Abstract:

This paper reports our efforts toward an automatic phoneme recognition for an under-resourced language,

Fongbe. We propose a complete recipe of algorithms from speech segmentation to phoneme recognition in

a continuous speech signal. We investigated a strictly fuzzy approach for simultaneous speech segmentation

and phoneme classiﬁcation. The implemented automatic phoneme recognition system integrates an acoustic

analysis based on calculation of the formants for vowel phonemes and calculation of pitch and intensity of

consonant phonemes. Vowel and consonant phonemes are obtained at classiﬁcation. Experiments were per-

formed on Fongbe language (an African tonal language spoken especially in Benin, Togo and Nigeria) and

results of phoneme error rate are reported.

1 INTRODUCTION

Phoneme recognition is an integrated process in an

Automatic Speech Recognition (ASR). Most large

vocabulary automatic speech recognition systems use

several interconnected layers of recognition for opti-

mum performance. Phonemes are perhaps the most

common sub-word modules used in ASR systems

(Baghdasaryan and Beex, 2011). Many methods ex-

ist for phoneme recognition which are introduced

for generating of phonetic symbols from the ex-

tracted feature vectors and calculated on speech sig-

nals. These are methods based on approaches such as

Artiﬁcial Neural Network (ANN) (Palaz et al., 2013;

Yousafzai et al., 2009; chwarz et al., 2006), Hidden

Markov Models (HMM) (Young, 2008; marani et al.,

2009), Support Vector Machine (SVM) (Solera-Urena

et al., 2007) or some hybrid methods (Trentin and

Gori, 2007; Anapathy et al., 2009).

This paper focuses on the development of an au-

tomatic phoneme recognition from continuous speech

using several interconnected layers starting from the

continuous speech segmentation to phoneme recogni-

tion. The overall system is the fusion of the recogni-

tion layer investigated in this work, the segmentation

and the classiﬁcation layers investigated respectively

in (Laleye et al., 2015b) and (Laleye et al., 2015a)

which were previous works on Fongbe language.

Figure 1 presents an overview of the phoneme

recognition system. It includes the segmentation (i),

classiﬁcation (ii) and recognition (iii) layers as ex-

plained above and the processing order. To real-

ize (i), we used the time domain approaches to gen-

erate features for detecting phoneme segments and

fuzzy logic approach for a matching phase performed

through supervised learning. Thus, (i) provides the

phoneme segments with an accurate in the deﬁnition

of boundaries. The Layer (ii) consists of a discrimina-

tory system of consonants and vowels using an intel-

ligent classiﬁer combination based on decision-level

fusion. It produces phonemes that are either con-

sonants or vowels whose phonetic identity is recog-

nized at (iii). Layer (iii) is based on acoustic anal-

ysis of Fongbe phonemes for identifying with more

precision the phonetic content of the phoneme to its

input. Time-domain features and frequency-domain

features are respectively extracted from the speech

signal to perform the segmentation and classiﬁcation

tasks. Frequency-domain features are computed on

phoneme segments in step 2 order to constitute the

classiﬁcation system inputs. In step 5, we calculated

the formant frequencies to facilitate the recognition of

consonants or vowels.

Experiments were performed on a read speech

corpus which contains 3117 utterances in Fongbe.

we calculated the phone error rate score according to

102

Laleye, F., Ezin, E. and Motamed, C.

Automatic Fongbe Phoneme Recognition From Spoken Speech Signal.

DOI: 10.5220/0006004101020109

In Proceedings of the 13th International Conference on Informatics in Control, Automation and Robotics (ICINCO 2016) - Volume 1, pages 102-109

ISBN: 978-989-758-198-4

#process

step

speech signal

segmentation

phoneme segments

classification

consonant or vowel

recognition

phoneme recognized

Figure 1: Overview of our automatic phoneme recognition.

the different DBN model used for recognizing each

phoneme in its subclass. Experiments have shown a

signiﬁcant improvement in the results given by phone

error rates (PER).

The remainder of this paper is organized as fol-

lows. The next section describes the automatic

text-independent segmentation of Fongbe continuous

speech. Section 3 describes how Fongbe phonemes

are classiﬁed into consonant or vowel classes. Section

4 focuses on phoneme recognition system. Section

5 presents and comments the experimental results of

PER that we obtained. Section 6 concludes this paper

with results.

2 AUTOMATIC

TEXT-INDEPENDENT

SEGMENTATION OF FONGBE

CONTINUOUS SPEECH

In this section, We present the phoneme segmen-

tation method (preliminary work on Fongbe) used

in this phoneme recognition work. we summarize

this method in (Laleye et al., 2015b) to perform

a text-independent segmentation of Fongbe continu-

ous speech. The segmentation task was performed

from non-linear speech analysis using fuzzy logic ap-

proach. It is based on the calculation of time domain

features such as short-term energy, zero crossing rate

Figure 2: Flow diagram of the segmentation algorithm.

and the singularity exponents in each point of signal.

As part of our work, we modiﬁed the calculation of

singularity exponents by reducing the frame sizes in

the scale-dependent functional h(t) in order to detect

only the boundaries between the phoneme segments

in speech signal. For more details please refer to (Lal-

eye et al., 2015b). The used algorithm for automatic

text-independent segmentation is summarized in Fig-

ure 2 and includes the following tasks:

a - Removal the silence from speech signal: a

method based on the signal energy and the spec-

tral centroid is used to remove the silence areas in

the audio signal.

b - Singularity exponents Computation: local distri-

bution of singularity exponents has been exploited

for analyzing the temporal dynamics of speech

segments previously obtained. This leads to the

segment candidates.

c - Short-time energy and zero crossing rate calcu-

Automatic Fongbe Phoneme Recognition From Spoken Speech Signal

103

(a) Classiﬁcation and normalization.

(b) Decision fusion using fuzzy logic.

Figure 3: Paradigm of our classiﬁcation system.

lation: the features are computed in each candi-

date segment generated by the local analysis of

singularity exponents.

d - Fuzzy rules application: fuzzy rules have been

generated for the matching phase to improve the

accuracy in the phoneme or syllable segments de-

tection and the boundaries of beginning and the

end.

The phoneme segments are properly detected at the

matching phase. The matching phase is performed by

using fuzzy logic model which consists of a number

of conditional “if-then” rules. The matching phase

inputs are singularity exponents (SE), short-term en-

ergy (STE) and zero crossing rate (ZRC) and the out-

put is the membership degree of silence and phoneme.

The input variables are fuzziﬁed into three comple-

mentary sets namely: low, medium, high and the

output variable is fuzziﬁed into two sets: silent and

phoneme. The authors obtained for the different co-

efﬁcients considering the features values:

• STE: low - medium - high

• ZCR: low - medium - high

• SE: low - medium - high

The fuzzy rules generated through supervised learn-

ing are presented in Table2. In this table, x is a vari-

able that can take the value low, medium or high.

The different membership functions were ob-

tained by examining the local distribution of each cal-

culated feature. Local distribution has induced three

subsets according to the variation of input data and

output is obtained depending on the nature of data.

Table 1: Generated fuzzy rules.

Rules

Input Output

STE ZCR SE

1 low x x silent

2 x low x silent

3 x x low silent

4 medium medium medium phoneme

5 medium medium high phoneme

6 x high x silent

7 high medium medium phoneme

8 high medium high phoneme

Because of the linearity of values in the subsets, a

simple triangle curve (trimf ) is used for the member-

ship functions.

3 FONGBE PHONEME

CLASSIFICATION

The phoneme classiﬁcation system (Laleye et al.,

2015a) consist of three modules which are each sub-

divided into submodules. The ﬁrst module performs

classiﬁcation with Naive Bayes and Learning Vec-

tor Quantization (LVQ) classiﬁer and produces out-

puts with the coefﬁcients applied as input. It con-

tains the submodules which are (i) feature extraction

(MFCC, PLP, and Rasta-PLP), (ii) classiﬁcation with

Naive Bayes and LVQ. The second module performs

weighted mean calculation of classiﬁers outputs and

contains the submodule which is (iii) normalization

ICINCO 2016 - 13th International Conference on Informatics in Control, Automation and Robotics

104

for classiﬁers decisions database. The last module

performs the decision fusion with fuzzy approach.

Figure 3 shows the various steps of classiﬁcation.

Nature of the results obtained in the ﬁrst step al-

lows to apply fuzzy logic on four membership func-

tions. The inputs to fuzzy logic system are MFCC,

PLP and Rasta-PLP and the output obtained is the

membership degree of a phoneme to consonant or

vowel class. The input variables are fuzziﬁed into

four complementary sets namely: low, medium, high

and very high and the output variable is fuzziﬁed into

two sets namely: consonant and vowel. Table 2 shows

the fuzzy rules which were generated after fuzziﬁca-

tion. First, the input data is arranged in an interval

as [Xmin .. Xmax]. The different membership func-

tions were obtained by examining the local distribu-

tion of samples of both classes. Local distribution has

induced four subsets according to the variation of the

input data and the output is obtained depending on the

nature of the data. For example, if we give MFCC,

PLP and Rasta as input to the system, the consonant

or vowel output is obtained according to the subsets

of the input data. Because of the linearity of values in

the subsets, a simple triangle curve (trimf ) is used for

low and medium membership functions and a trapeze

curve (trapmf ) is used for high and very high mem-

bership functions.

This layer described in this section provides a

classiﬁcation in consonant or vowel of phoneme seg-

ments obtained in the ﬁrst layer. The following sec-

tion explain how our system recognize deﬁnitively the

phonemes contained in a spoken speech.

4 PHONEME RECOGNITION

This section describes the process of the third layer,

which is to recognize each phoneme included in the

speech on the basis of the formant frequencies. We es-

tablished an acoustic analysis of the phonemes by cal-

culating the formant F1, F2 and F3 from vowels and

the fundamental frequency and intensity from conso-

nants. The recognizer was therefore trained with a

Deep Belief Network (DBN) and a fuzzy logic sys-

tem with the features calculated for recognizing each

of the consonants and vowels. The acoustic analysis

by calculating the frequencies allowed us to represent

the phonemes in a tree according to the values of the

formant, pitch and intensity. Figure 4 shows the tree

of the categorization of consonants and vowels

4.1 Formant Analysis of Vowels

Articulatory conﬁguration of each vowel lead to spe-

Table 2: Generated fuzzy rules. x is a variable that can take

the value low, medium or high.

Rules

Input Output

mfcc rasta plp

1 low low low consonant

2 low low medium vowel

3 x x high consonant

3 x x very high vowel

4 low medium low vowel

5 low high low consonant

6 low very high low vowel

7 medium low low vowel

8 medium very high low vowel

9 high low low consonant

11 high high low consonant

12 very high low low vowel

13 very high low medium vowel

14 very high medium low vowel

15 very high very high low vowel

16 very high very high medium vowel

ciﬁc formant values corresponding to the shape taken

by the vocal tract for each vowel. The shape will in-

duce a resonant frequency in production of vowels:

higher its size is, lower its frequency is. The ﬁrst

three formant have a wide variation in the acoustic

conﬁguration of each vowel. The mandible aperture

(F1) varies from 311Hz (front. / i/) to 681Hz (cent.

/ a/) for oral vowels and from 315Hz (front. /

i/) to

610Hz (cent. /˜a/) for nasal vowels. The second for-

mant (F2) which indicates the tongue movement in

front or rear position takes values from 697Hz (back.

/ u/) to 2238Hz (front. / i/) for oral vowels and from

406Hz (back. /˜u/) to 1630Hz (back. /

i/). The third for-

mant inﬂuenced by the rounding of the lips has values

that vary between 2696Hz (back. / O/) and 3174Hz

(front. / O/) for oral vowels and between 711Hz (back.

/˜O/) and 2870Hz (front. /˜E/).

In F1-level, oral vowels (back. and front.) / i/,

/ u/, / e/ and / o/ have lower values while oral vowels

(back. and front.) / E/, / O/ and the central oral vowels

/ a/ have the highest values. In each aperture level,

a front vowel has a greater F1 than a back vowel.

Vowels / i/ and / a/ are respectively the low and high

extremities in the frequency range of the mandible

aperture (F1). These remarks are also observed with

nasalized vowels. This indicates that front vowels are

/ i e E i

/ and the listed back vowels are / u o O u

/. In F2-level, front vowels have higher frequencies

compared to back vowels that are realized with low

frequencies. The only difference between the vowels

from the same class (front and back) is the value of

the third formant F3. F3 of / u/ (F3 = 3083Hz) and

/ (F3 = 2720Hz) has a lower value than the value of

the vowels / i/ (F3 = 3174Hz) and /i

/ (F3 = 2738Hz),

thereby justifying the rounding of the lips during the

production of vowels / u u

/. Table 3 summarizes

Automatic Fongbe Phoneme Recognition From Spoken Speech Signal

105

Figure 4: Tree of consonants and vowels.

Table 3: Mean values of formants F1, F2 et F3 for each

phoneme of Fongbe vowel system.

F1-

average

F2-

average

F3-

average

front

311 2238 3174

353 2042 3096

530 1255 3081

back

326 697 3083

380 822 2727

555 1051 2696

cent.

681 1404 2789

sal

front

315 1630 2738

405 1362 2870

back

325 406 2720

501 705 2711

cent. a

610 1015 2769

the averages of formant frequencies calculated on all

phonemes in the data corpus.

4.2 Fongbe Consonant System

Fongbe consonant system is composed of twenty-two

(22) phonemes grouped into two (2) classes (oral and

nasal consonants). Unlike the acoustic conﬁguration

of vowels that is characterized by the presence of for-

mant frequencies, the acoustic analysis of consonants

consisted in calculating of two acoustic markers: fun-

damental frequency (pitch) that materializes the pe-

riodic vibration of the vocal cords and intensity that

materializes the sub-glottis pressure. Usually, there

are three main classes for acoustic analysis of con-

sonants: plosives, fricatives and sonorants. The con-

sonants from French are investigated in the next plo-

sives, fricatives and consonant vocalic. In Fongbe, in

addition to occlusive, fricative and consonant vocalic,

there are two other classes that are nasal consonants

and semi-consonants.

• The Occlusives from Fongbe have the same con-

ﬁguration than most other languages, including

French. We distinguish sound and voiceless stops,

which are mainly composed of voiced (/ d g gb

j/) and unvoiced (/ b d/) oral consonants. They are

characterized by the fundamental frequency (f0)

which vary averagely between the voiced conso-

nants (263Hz for / j/ and 279Hz for / gb/). The

unvoiced consonants are realized with lower pitch

than voiced consonants except / d/ and / j/. The

fundamental frequencies (pitch) calculated over

all speakers in data corpus are shown in Figure 5.

The smallest average voice intensity (6) during the

isolated pronunciation of voiced stops is obtained

with the voiced consonant / d/ (56db) while the

higher is obtained with the unvoiced / b/ (60db)

voiceless Occlusives of Fongbe are composed of

some voiceless oral consonants such as / c k kp

t/ and also / p/ which is not considered a phone-

mic consonant but only found in some words bor-

rowed from other languages. The voice intensity

during the pronunciation of voiceless stop varies

between 53db (for / c/) and 59db (for / p/).

• Articulatory conﬁguration fricatives indicates the

presence of noise throughout their pronunciation.

As occlusives, there are sound fricatives (peri-

ICINCO 2016 - 13th International Conference on Informatics in Control, Automation and Robotics

106

odic) and the voiceless fricatives (aperiodic) in

Fongbe. The sound fricatives are composed of

sound oral consonants / h v z/ and the voiceless

fricatives are composed of voiceless oral conso-

nants / f s x/. The fundamental frequency of / h/

(250 Hz) is lower than periodic fricatives / z/ (293

Hz) and / v/ (286 Hz). Voiceless fricatives are re-

alized with low intensity values compared to the

sound fricatives whose peaks are observed respec-

tively with the consonants / x/ (54 db) and / z/ (58

db).

• There are three nasals consonants in Fongbe such

as / m/, / n/ and / N/. They are comparable to

voiced stops in an articulatory viewpoint. They

are realized with the lowest fundamental frequen-

cies compared to voiced stops. Compared to other

consonants from Fongbe, the nasal consonants are

produced with the lowest intensity of voice and

form, with the semi-consonants (/ w/ and / y/)

the briefest in the pronunciation. The realiza-

tion of semi-consonants are performed with al-

most the same periodic vibration rhythms of the

vocal cords (pitch values) and the same pressure

subglottic (intensity) than the voiced stops.

Figure 5: Pitch per consonfront.

Figure 6: Intensity of each consonfront.

4.3 Baseline Phoneme Recognition

System

We used two different approaches to perform the

process of the last layer of our recognition system:

fuzzy logic and DBN approaches. The Computation

of the vowel formants, the fundamental frequency

and intensity of consonants provide additional ex-

pert knowledge which can allow us to apply a fuzzy

logic system to effectively recognize consonant or

vowel phonemes (the inputs of this layer). Then,

we used several DBNs in a hierarchical architecture

based on the phoneme classiﬁcation (Figure 4) to

achieve recognition. Our recognition system con-

sists of a mixture of fuzzy rules applied for recog-

nizing subclasses of phonemes and DBN structures

for recognizing the phonemes contained in each sub-

class. Thus, initially we used the fuzzy logic model

which consist of a number of conditional ”if-then”

rules. When the classiﬁcation layer provides a con-

sonant to the recognition layer, the inputs of the fuzzy

logic system are fundamental frequency and intensity

and the output is the membership degree of voiceless,

voiced, sonorant and nasal. In the case of a vowel

as input to the third layer, the inputs are the formants

F1, F2 and F3 and the output is the membership de-

gree of oral front, oral central, oral back, nasal front,

nasal central and nasal back. For a consonant as an

input, the fundamental frequency (f0) is fuzziﬁed into

four complementary sets namely: low, medium, high,

very high and intensity is fuzziﬁed into three com-

plementary sets namely: low, medium, high. For a

vowel, each formant is fuzziﬁed into three comple-

mentary sets namely: low, medium, high. The linear-

ity of computed features induced the use of a simple

triangle curve (trimf ) for low, medium, high and very

high membership functions. The fuzzy rules gen-

erated through supervised learning are presented in

Table4 and Table5.

Table 4: The generated fuzzy rules applied to vowel for

identifying its subclass.

Rules

Input Output

F1 F2 F3

1 low low low oral front

2 low low medium nasal front

3 low low high oral front

4 low high medium nasal back

5 low high high oral back

6 medium low low nasal front

7 medium medium high nasal back

8 high low low oral front

9 high low medium nasal central

10 high medium medium oral central

11 high medium high oral back

After having detected the subclasses, we perform

a learning step based on the use of Deep Belief Net-

work. We trained 10 DBN models whose the neu-

ron number in the output layer varies according on

Automatic Fongbe Phoneme Recognition From Spoken Speech Signal

107

Table 5: The generated fuzzy rules applied to consonant for

identifying its subclass.

Rules

Input Output

f0 intensity

1 low medium sonorant

2 low high nasal

3 medium medium voiced

4 medium high sonorant

5 high low voiced

6 high medium voiced

7 very high low voiceless

8 very high medium voiced

Table 6: DBN parameters.

Model-256 units Model-512 units Model-1024 units

RBM Layer 1 256 units 512 units 1024 units

RBM Layer 2 256 units 512 units 1024 units

RBM Layer 3 256 units 512 units 1024 units

RBM Layer 4 256 units 512 units 1024 units

Learning rate 0.01 0.01 0.01

Training Epochs 160 160 160

Batch size 8 8 8

the number of elements in a subclass. We used three

different architectures to compare the recognition per-

formance and impact of the layer number of DBN

models on the performance of our recognition system.

This is also motivated by differences in the change of

phoneme subclasses. Table 6 summarizes the param-

eters used for each DBN model;

4.4 Experiments Results

Experiments were performed with Matlab in an en-

vironment which is Intel Core i7 CPU L 640 @

2.13GHz × 4 processor with 4GB memory.

4.5 Experimental Data

The complete recipe of algorithms proposed in this

work has been built for an automatic recognition of

Fongbe phonemes contained in a continuous speech.

Fongbe language is the majority language of Benin,

which is spoken by more than 50% of Benin’s popu-

lation, including 8 million speakers and also spoken

in Nigeria and Togo. Fongbe is an under-resourced

language which is characterized by a series of vow-

els (oral and nasal) and consonants (unvoiced, frica-

tives). By excluding compound words and derived

words, the words of Fongbe language can be grouped

into monosyllabic (V and CV), into bisyllabic (VCV;

CVV; CVCV and VV) and trisyllable (VCVCV and

CVCVCV). It is written ofﬁcially in Benin with an

alphabet derived from the Latin writting since 1975.

It has a complex tonal system, with two lexical tones,

high and low, which may be modiﬁed by means of

tonal processes to drive three further phonetic tones:

rising low-high, falling high-low and mid (Lefebvre

and Brousseau., 2001). The Fongbe’s vowel system

is well suited to the vocalic timbre as it was designed

by the ﬁrst Phoneticians. It includes twelve timbres:

7 oral vowels with 4 degrees of aperture and 5 nasal

vowels with 3 degrees of aperture. Its consonant sys-

tem includes 22 phonemes in 7 orders and 4 series.

The Fongbe speech corpus is divided into a train and

test sets which respectively contain 2307 and 810 sen-

tences uttered by 56 speakers whose ages are between

9 and 45 years. It contains for the full database ap-

proximately 12 thousand words and more than 96

thousand phonemes.

4.6 RESULTS

The best performing setting of DBN models (four

hidden layer architectures) was used to compute the

phone error rate (PER) for the core test set. PER is

the standard evaluation metric for phoneme recogni-

tion systems. It measures the difference between the

phoneme string returned by the recognizer and the

correct reference transcription. The distance between

the two phoneme strings is computed by the classi-

cal minimum edit distance algorithm (Huang et al.,

2001). Its formula (Equation 1) is based on the num-

ber of phoneme substitutions (SD), insertions (IE) and

deletions (DE) which are necessary to map between

the correct and hypothesized strings.

PER = 100.

SD + IE + DE

(1)

where N represents the number of phonemes in the

correct transcription.

After calculating the PER metric, we also calcu-

late Acc (recognition accuracy) by using:

Acc = 100 − PER (2)

PER for four-layer architectures with different

hidden layer sizes are presented in table 7.

Table 7: Performance metrics per model.

Models DE IE SD PER Acc

256 units 7.15% 4.60% 16.30% 28.05% 71.95%

512 units 9.02% 3.04% 12.5% 24.56% 75.44%

1024 units 10.03% 1.30% 13.4% 24.73% 75.27%

The best PER is obtained with 512 units as hidden

layer sizes and is around 24%. This shows that by

adding more hidden layer sizes, from 256 units to 512

units, the recognition system performance has signif-

icantly improved and has given the best PER.

ICINCO 2016 - 13th International Conference on Informatics in Control, Automation and Robotics

108

5 CONCLUSION

In this work, we have achieved a ﬁrst automatic recog-

nition system of Fongbe phonemes starting from the

continuous speech segmentation to the phonetic iden-

tity recognition of the units contained in the speech

signal. We offer a complete recipe algorithms using

fuzzy logic for segmentation, classiﬁcation, identity

recognition. The output of this complete recipe is a

set of DBN models trained individually on 2307 sen-

tences of the training set and according to the con-

ﬁguration of each subclass. Unlike most phoneme

recognition systems, we ﬁrst performed a recognition

of plosives, fricatives and nasal consonants for con-

sonant phonemes and recognition of oral and nasal

for vowel phonemes. This yields a better recogni-

tion accuracy, decreasing especially the phone error

rate. In this way working with the subclasses by re-

ducing phoneme set increased approximately with 4%

the recognition accuracy. Another important ﬁnding

of this work is that we achieved very good Fongbe

phoneme recognition accuracy with 512 units as hid-

den layer sizes in our DBN models.

REFERENCES

Anapathy, S., Thomas, S., and Hermansky, H. (2009). Mod-

ulation frequency features for phoneme recognition in

noisy speech. J. Acoust. Soc. Am, 125(1):EL8–EL1.

Baghdasaryan, A. G. and Beex, A. A. (2011). Automatic

phoneme recognition with segmental hidden markov

models. In Signals, Systems and Computers (ASILO-

MAR), 2011 Conference Record of the Forty Fifth

Asilomar Conference on, pages 569–574.

chwarz, P., Matejka, P., and Cernocky, J. (2006). Hierarchi-

cal structures of neural networks for phoneme recog-

nition. In 2006 IEEE International Conference on

Acoustics Speech and Signal Processing Proceedings.

Huang, X., Acero, A., and Hon, H.-W. (2001). Spoken

language processing, a guide to theory, algorithm and

system development. Prentice Hall.

Laleye, F. A. A., Ezin, E. C., and Motamed, C. (2015a).

Adaptive decision-level fusion for fongbe phoneme

classiﬁcation using fuzzy logic and deep belief net-

works. In Proceedings of the 12th International Con-

ference on Informatics in Control, Automation and

Robotics, Volume 1, Colmar, Alsace, France, 21-23

July, pages 15–24.

Laleye, F. A. A., Ezin, E. C., and Motamed, C. (2015b). An

algorithm based on fuzzy logic for text-independent

fongbe speech segmentation. In 11th International

Conference on Signal-Image Technology & Internet-

Based Systems, SITIS 2015, Bangkok, Thailand,

November 23-27, pages 1–6.

Lefebvre, C. and Brousseau., A. (2001). A grammar of

fonge, de gruyter mouton. page 608.

marani, S., Raviram, P., and Wahidabanu, R. (2009). Im-

plementation of hmm and radial basis function for

speech recognition. In Int. Conf. on Intelligent Agent

and Multi-Agent Systems, 2009 (IAMA 2009), Chen-

nai, pages 1–4.

Palaz, D., Collobert, R., and Magimai.-Doss, M. (2013).

End-to-end phoneme sequence recognition using con-

volutional neural networks. Idiap-RR.

Solera-Urena, R., Martin-Iglesias, D., Gallardo-Antolin, A.,

Pelaez-Moreno, C., and Diaz-de Maria, F. (2007). Ro-

bust asr using support vector machines. Speech Com-

munication, 49(4):253–267.

Trentin, E. and Gori, M. (2007). A survey of hybrid

ann/hmm models for automatic speech recognition.

Neurocomputing, 37(1):91–126.

Young, S. (2008). Hmms and related speech recognition

technologies. Springer Handbook of Speech Process-

ing, Springer-Verlag Berlin Heidelberg, pages 539–

557.

Yousafzai, J., Cvetkovic, Z., and Sollich, P. (2009). Tun-

ing support vector machines for robust phoneme clas-

siﬁcation with acoustic waveforms. In 10th Annual

conference of the International Speech communica-

tion association, pages 2359 – 2362, England. ISCA-

INST SPEECH COMMUNICATION ASSOC.

Automatic Fongbe Phoneme Recognition From Spoken Speech Signal

109
