Evaluation of Local 3-D Point Cloud Descriptors in Terms of Suitability

for Object Classiﬁcation

Jens Garstka and Gabriele Peters

Human-Computer Interaction, Faculty of Mathematics and Computer Science,

University of Hagen, D-58084 Hagen, Germany

Keywords:

Local 3-D Feature Descriptors, Performance Evaluation, Object Classiﬁcation.

Abstract:

This paper investigates existing methods for local 3-D feature description with special regards to their suitabil-

ity for object classiﬁcation based on 3-D point cloud data. We choose ﬁve approved descriptors, namely Spin

Images, Point Feature Histogram, Fast Point Feature Histogram, Signature of Histograms of Orientations, and

Unique Shape Context and evaluate them with a commonly used classiﬁcation pipeline on a large scale 3-D

object dataset comprising more than 200000 different point clouds. Of particular interest are the details of the

choice of all parameters associated with the classiﬁcation pipeline. The point clouds are classiﬁed by using

support vector machines. Fast Point Feature Histogram proves to be the best descriptor for the method of

object classiﬁcation used in this evaluation.

1 INTRODUCTION

Latest advances in image based object recognition,

e. g., deep convolutional neural networks may sug-

gest that the problem of object classiﬁcation is solved.

However, it is still possible to list many situations in

which deep learning approaches based on image data

fail. This happens mainly if the objects are translucent

or if they have no or an arbitrary texture, respectively.

This is often the case for non-natural human-made ob-

jects. Figure 1 illustrates one of these cases.

Figure 1: This patchwork sofa illustrates one of the situa-

tions where an image based object recognition or classiﬁca-

tion is difﬁcult due to arbitrary textures — image by Dolores

Develde, 2012, Creative Commons Attribution 3.0 License.

To address these problems, it is helpful to re-

gard the 3rd dimension for object classiﬁcation. It

allows to reduce the mentioned problems at least in

some cases. The sofa shown in Figure 1, for ex-

ample, could certainly be recognized using a three-

dimensional representation.

A description of 3-D objects can be divided into

two broad categories: global and local. Global de-

scriptors deﬁne a representation of an object which

effectively and concisely describes the entire 3-D ob-

ject. In most cases, these methods require an a priori

segmentation of the scene into object an background

and are not suitable for partially visible objects from

cluttered scenes. Furthermore, it has to be consid-

ered that objects might have different poses or might

be deformed. Local descriptors allow robust and ef-

ﬁcient recognition approaches that can operate under

partial occlusion and are invariant to different poses

and deformation.

Beginning with the introduction of Microsoft Ki-

nect in 2010, even research groups with a small bud-

get were enabled to easily generate 3-D data on their

own. As a consequence a lot of research regarding lo-

cal 3-D feature descriptors was done in recent years.

This paper investigates ﬁve approved local 3-D fea-

ture descriptors of 3-D point clouds with a focus on

their suitability for object classiﬁcation. The text is

structured as follows. In Section 2, existing evalua-

tions and the evaluated local 3-D feature descriptors

are presented. In Section 3 the used classiﬁcation

pipeline is introduced in detail. In Section 4 the ﬁve

local 3-D feature descriptors are applied and evalu-

ated in context of the classiﬁcation pipeline. Finally,

Section 5 and Section 6 discuss the results and give a

short conclusion.

540

Garstka, J. and Peters, G.

Evaluation of Local 3-D Point Cloud Descriptors in Terms of Suitability for Object Classiﬁcation.

DOI: 10.5220/0006011505400547

In Proceedings of the 13th International Conference on Informatics in Control, Automation and Robotics (ICINCO 2016) - Volume 2, pages 540-547

ISBN: 978-989-758-198-4

2 RELATED WORK

Subsequently, already published evaluations of local

3-D feature descriptors and the local 3-D feature de-

scriptions considered in this paper are introduced.

2.1 Existing Evaluations

There is a number of publications that deal with evalu-

ations of 3-D feature descriptors in the last ﬁve years.

A survey and evaluation of local shape descriptors

(Heider et al., 2011) divides existing local descriptors

into three classes. Focus of the evaluation are 3-D

meshes and only local shape descriptors for meshes

are examined.

The evaluation of local shape descriptors for 3-D

shape retrieval (Tang and Godil, 2012) is similar to

the work of (Heider et al., 2011), with the difference

that they perform the tests of 6 simple mesh descrip-

tors on the SHREC 2011 Shape Retrieval Contest of

Non-rigid 3D Watertight Meshes dataset (Lian et al.,

2011).

An evaluation from Alexandre with focus on local

3-D descriptors for object and category recognition

(Alexandre, 2012) is the publication that is themati-

cally most similar to our work. The tested algorithms

are the same ones as those examined in this paper.

However, the pipeline proposed by Alexandre is un-

suitable for a larger amount of data.

The evaluation of local 3-D feature descriptors for

a classiﬁcation of surface geometries in point clouds

(Arbeiter et al., 2012) investigates how local 3-D fea-

ture descriptions can be used to classify primitive lo-

cal surfaces such as cylinders, edges, or corners in

point clouds. Arbeiter et al. compare a small selec-

tion of three local 3-D feature descriptors.

The goal of the evaluation of 3-D feature descrip-

tors in the work of (Kim and Hilton, 2013) is a multi-

modal registration of 3-D point clouds, meshes, and

images. Although the descriptors used in this work

are the same as in this paper, conclusions regarding

a classiﬁcation of 3-D point clouds can hardly be de-

rived from their results.

Finally, a survey on 3-D object recognition in clut-

tered scenes with local surface features (Guo et al.,

2014) provides a good overview of the available de-

scriptors and divides them with a taxonomy into dif-

ferent descriptor types. In addition, there is an infor-

mal comparison of the performance of each descrip-

tor, which, however, is based on the statements given

in each individual publication and not on an own eval-

uation.

2.2 Local 3-D Feature Descriptors

The goal of local 3-D feature descriptors is the de-

scription of particularly “interesting” local areas of a

3-D object. The advantages of local representations

consist in their robustness with respect to noise, and

their variability concerning object shape and partial

occlusions. A wide variety of methods exists (Guo

et al., 2014), but not all are suitable for 3-D point

clouds, but rather meshes or depth images. The fol-

lowing ﬁve local 3-D feature descriptors are suitable

for the local description of 3-D point clouds and are

evaluated in this paper.

The Spin Image (SI) descriptor (Johnson and

Hebert, 1998; Johnson and Hebert, 1999) is arguably

the most cited and approved local 3-D descriptor. It

is a histogram based method that requires a normal

vector as a rotation axis. In a nutshell, all 3-D points

of the local environment are collected while the 2-D

histogram is rotated around the normal vector.

The Point Feature Histogram (PFH) (Rusu et al.,

2008a) is a histogram based approach as well. Rusu

et al. compute Darboux frames (Rusu et al., 2008a)

for each 3-D point of a local spherical environment.

The three angles of each Darboux frame are subdi-

vided into 5 intervals and ﬁlled in a histogram with

125 bins.

Since the computational complexity for the deter-

mination of Darboux frames at each point within a

k-neighborhood is O(k

), the computation of PFH is

relatively slow. For this reason, Rusu et al. proposed

a simpliﬁed version of PFH named Fast Point Fea-

ture Histogram (FPFH) (Rusu et al., 2009). They pre-

served the basic characteristics of the descriptor, but

replaced the computation of the Darboux frame with

an approximation of it.

Tombari et al. propose a descriptor called Signa-

tures of Histograms of Orientations (SHOT) (Tombari

et al., 2010b; Salti et al., 2014). A spherical neigh-

borhood is divided into several segments. For each

segment a histogram is ﬁlled with the cosine values

of the angles between the z-axis of the local reference

frame and the normal vectors of all points that are part

of the currently considered segment.

Another local 3-D feature descriptor introduced

by Tombari et al. is Unique Shape Context (USC)

(Tombari et al., 2010a). It is an extension of the 3-D

Shape Context (3DSC) (Frome et al., 2004), which

essentially consists of a spherical histogram divided

into radial, elevation, and azimuth divisions. Tombari

et al. determine a unique local reference frame to en-

sure that the histogram has unique orientation.

Evaluation of Local 3-D Point Cloud Descriptors in Terms of Suitability for Object Classiﬁcation

541

Keypoint

Selection

Feature

Description

Point Cloud Bag of Words Classiﬁcation

Figure 2: The classiﬁcation pipeline used for the evaluation of local 3-D feature descriptors. It consists of four main steps:

keypoint selection, feature descriptions, a bag-of-words model, and the classiﬁcation.

3 CLASSIFICATION PIPELINE

At a conceptual level, a 3-D classiﬁcation pipeline is

based on four main steps. These are the keypoint se-

lection (Salti et al., 2011; Dutagaci et al., 2012; Filipe

and Alexandre, 2013), the extraction of local feature

descriptions (Alexandre, 2012; Guo et al., 2014), a

bag-of-words model (Wu and Lin, 2011; Cholewa and

Sporysz, 2014), and a machine learning method for

the classiﬁcation task for which support vector ma-

chines (Toldo et al., 2010) are widely used. Figure 2

depicts these steps with a conceptual illustration of

such a pipeline. The individual steps and their param-

eters are discussed in detail in the next subsections.

3.1 Point Clouds

The dataset used in the context of this work is the

RGB-D Object Dataset (Lai et al., 2011). The dataset

contains 51 object classes, e. g., banana, calculator,

glue stick, or sponge. Each object class comprises

several different objects of the same object class. The

object class coffee mug, for example, contains 8 dif-

ferent types of coffee cups. In summary, the datasets

contains 300 different objects where each object was

captured in different poses. This results in 207841

distinct point clouds. The mean point cloud resolu-

tion (pcr) of these point clouds is ≈ 0.001295.

As not only the complete set of object classes, but

also a part of it will be used in context of this evalua-

tion, a subset is speciﬁed in the following. It consists

of 10 randomly selected object classes, namely cap,

coffee mug, food bag, greens, hand towel, keyboard,

kleenex, notebook, pitcher, and shampoo. These 10

object classes contain approx. 36500 3-D point clouds

from 53 distinct objects (cf. Figure 3).

Figure 3: A picture of one object from each of the 10 se-

lected object classes, which are left to right, top to bottom:

cap, coffee mug, food bag, greens, hand towel, keyboard,

kleenex, notebook, pitcher, and shampoo.

3.2 Keypoint Selection

Keypoints, also referred to as interest points, are

points in images or 3-D point clouds that distinctively

describe an interesting region. They are supposed to

be stable under varying conditions. To ensure that our

evaluation results are independent of the choice of a

keypoint selection algorithm, two different keypoint

selection algorithms are used throughout this paper.

The ﬁrst method is the keypoint algorithm in-

troduced in context of the Intrinsic Shape Signature

(ISS) (Zhong, 2009). According to (Salti et al., 2011)

and (Filipe and Alexandre, 2013) the ISS keypoint al-

gorithm yields the best scores in terms of repeatability

and is the fastest of the tested algorithms. All rele-

vant parameter values for the Intrinsic Shape Signa-

ture keypoint algorithm have been determined in the

evaluation of (Salti et al., 2011). Based on their re-

sults we use a radius of 6 · pcr for our evaluation.

Considering the fact that there are still many cur-

rent pipelines that rely on sparse sampling (Guo et al.,

2014), sparse sampling is used as a second option.

The distance of points using sparse sampling varies

signiﬁcantly depending on the approach (Johnson and

Hebert, 1998; Frome et al., 2004; Drost et al., 2010;

Aldoma et al., 2012b). Thus, we use a radius of 6 · pcr

for sparse sampling, as well.

3.3 Feature Description

In this subsection we discuss the individual parame-

ters of the ﬁve local 3-D feature descriptors (cf. Sub-

section 2.2) we compare in our evaluation.

3.3.1 Spin Image

There are three main parameters to conﬁgure Spin Im-

age (SI): the height, the width, and the radius used for

the determination of the normal vector. The height

and the width of SI histograms described in (John-

son and Hebert, 1998) is 20 × 10. In a later work

they propose a size of 15 × 15 (Johnson and Hebert,

1999), while (Aldoma et al., 2012a) prefer a size of

17 × 9. In contrast to Johnson and Hebert, who use

meshes in their experiments, Aldoma et al. use point

clouds. Furthermore, they use an uneven number of

square bins with an edge length equal to the point

ICINCO 2016 - 13th International Conference on Informatics in Control, Automation and Robotics

542

cloud resolution to take account of the sparse distri-

bution of point clouds. Therefore, we decided to fol-

low Aldoma et al. and use spin images with a size of

17×9 = 153 bins for our evaluation. The normal vec-

tor will be calculated based on the same radius used

to compute the histogram: 9 · pcr.

3.3.2 Point Feature Histogram

PFH requires two radii, the spherical support area and

a radius to approximate the normal vectors of the Dar-

boux frames. The size of the spherical support ar-

eas, i. e., the k-neighborhoods, are given by (Rusu

et al., 2008a) in meters and centimeters within an in-

terval of [2.0cm, 3.5 cm] for an indoor kitchen scene

and [50 cm, 150 cm] for an outdoor urban scene. Our

test data mainly includes household objects with a

size of at most 30 cm. Thus, we can assume that lo-

cal features can be limited to a size of 5cm or a k-

neighborhood with a radius of 2.5 cm, which ﬁts to

the radii that are used by Rusu et al. for the kitchen

scene and is approximately equivalent to 19.3 · pcr.

An indication of the size of the area used for

the approximation of the normal vectors is given by

(Alexandre, 2012). He proposes a radius of 1cm

which is ≈ 7.7 · pcr in our dataset. Therefore, we use

a radius of 20 · pcr for the spherical support area, and

a radius of 8 · pcr to approximate the normal vector.

3.3.3 Fast Point Feature Histogram

As the Fast Point Feature Histogram (Rusu et al.,

2009) is based on the Point Feature Histogram and

follows the same mechanism, we use the same radii

as for the Point Feature Histogram.

3.3.4 Signatures of Histograms of Orientations

(Tombari et al., 2010b) recommend histograms with

11 bins and a segmentation of the spherical environ-

ment with 8 azimuth divisions, 2 elevation divisions,

and 2 radial divisions. Additionally, Tombari et al.

specify the size of the support area with 15 · pcr. We

will use all these parameter values for our evaluation,

too.

3.3.5 Unique Shape Context

All required parameter values for USC are given by

(Tombari et al., 2010a): 10 radial divisions, 14 az-

imuth divisions, and 14 elevation divisions. The outer

radius of the spherical histogram is 20 · pcr, the inner

radius of the spherical histogram is 2 · pcr, the radius

to approximate the normal vector is 20 · pcr, and the

density radius is 2 · pcr. We use these values in our

evaluations as well.

3.4 Bag-of-words

A bag-of-words model is used to count the occur-

rences of words of a text in a histogram. In the same

way a bag-of-words model can be used to count the

occurrences of local feature descriptions. In this con-

text it is often called a bag-of-features.

The only parameter required in advance is the

number of bins of the histogram. For each bin, a rep-

resentative local 3-D feature description is required.

These descriptions are taken from the centers of each

cluster determined by k-means clustering on precom-

puted local 3-D feature descriptions. The initial cen-

ters of the clusters are chosen at random by using a

k-means variant named k-means++ (Arthur and Vas-

silvitskii, 2007). The distance measure used is the

Euclidean distance.

Depending on the referred source, the selected

number of clusters k differs by orders of magnitude.

Toldo et al. use values of k between 20 and 80 (Toldo

et al., 2009) and values from 50 to 150 (Toldo et al.,

2010), Knopp et al. use 10% of all feature descriptions

extracted from a training set as a value of k (Knopp

et al., 2010). Madry et al. use between 7 and 300

clusters (Madry et al., 2012; Madry et al., 2013) and

Yi et al. use 20% of the average number of features

they extracted for each patch of all objects in their

training set (Yi et al., 2014). For this reason, 7 dif-

ferent histogram sizes, i. e., 10, 20, 50, 100, 200, 500,

and 1000 will be compared in this evaluation.

3.5 Classiﬁcation

Most of the classiﬁcation approaches in (Toldo et al.,

2009; Toldo et al., 2010; Knopp et al., 2010; Madry

et al., 2012; Madry et al., 2013; Seib et al., 2013; Yi

et al., 2014) use support vector machines as underly-

ing technique. Only the approach proposed by Yi is

based on a different concept using a language model.

Rusu et al. state, that support vector machines

have already been used for a classiﬁcation based on

a bag-of-features model for color images with great

success (Rusu et al., 2008b; Rusu, 2010). In the refer-

enced works, Rusu et al. test support vector machines,

k-nearest neighbor searches, and k-means clustering

in different conﬁgurations against each other. The

best results are achieved using an SVM with a ra-

dial basis function (RBF) as kernel. There are some

other approaches, e. g., the work presented by (Lai

et al., 2011), where in some cases an alternative ma-

chine learning approach leads to slightly better re-

sults. However, since SVMs are the most widely

used classiﬁcation method in this problem domain,

the evaluation presented here will also use SVMs as

Evaluation of Local 3-D Point Cloud Descriptors in Terms of Suitability for Object Classiﬁcation

543

binary classiﬁer for each object class. Accordingly, a

Gaussian radial basis function is used as kernel.

3.6 Summary

In summary, for a given 3-D point cloud we ex-

tract a set of keypoints with ISS and sparse sam-

pling. For each keypoint we compute a local 3-D fea-

ture description based on one of the ﬁve selected al-

gorithms and determine the nearest representative to

count the feature description in the corresponding bin

of the bag-of-features histogram. Finally, the bag-of-

features histogram is used as input vector for the SVM

of each object class and the best matching object class

is selected based on the SVM responses.

4 EVALUATION

In this section the evaluation of local 3-D feature de-

scriptors is presented in detail. Initially, the most ap-

propriate keypoint algorithm, the optimal size of a

bag-of-features histogram, and the best SVM training

parameters are determined. This is done in Subsec-

tion 4.1, 4.2, and 4.3. In these subsections, all pipeline

parameters are optimized to maximize the correct as-

signment of an object corresponding to object class C

to C. Subsequently, Subsection 4.4 merges these opti-

mizations to an overall classiﬁcation. Subsection 4.5

examines the computation times required to classify

3-D point clouds this way.

4.1 SVM-parameters

A Gaussian radial basis function

K(x

, x

) = e

−γkx

−x

, γ > 0

requires the speciﬁcation of a single parameter γ

which has to be determined depending on the data

which is used to train the support vector machine. Ad-

ditionally, the support vector machine requires a pa-

rameter C > 0, which is the penalty parameter of the

error term, i. e., a multiplier of the distance of mis-

classiﬁed samples to their region.

A Note on SVM Training Histograms:

The following subsections contain small SVM train-

ing histograms with the size of 4 × 4 bins. All these

histograms have the same axes and labels. To retain

readability, the axes and labels are not included for

each histogram. Instead, the labels and axes of all

histograms are shown only once in Figure 4. The val-

ues of C increase from left to right, while the values

of γ increase from top to bottom.

Figure 4: Axes and labels of all SVM training histograms

in this paper. C is the penalty parameter for misclassiﬁed

samples, γ is the parameter of the radial basis function.

4.2 Sparse Sampling vs. ISS

To select the more appropriate keypoint algorithm, the

achieved classiﬁcation rates for both methods, sparse

sampling and ISS, are compared.

10 20 50 100 200 500 1000

ISS keyp.sparse sam.

Figure 5: Mean binary classiﬁcation rates of FPFH – com-

parison of ISS keypoints and sparse sampling (labels shown

in Figure 4). The color scale below the histograms indicates

the mean binary classiﬁcation rates.

Figure 5 illustrates the mean binary classiﬁcation

rates in excerpts for FPFH. Each column represents a

bag-of-features size. The upper row illustrates results

that can be achieved with keypoints determined by the

ISS algorithm, while the lower row contains the re-

sults based on sparse sampling. The mean binary clas-

siﬁcation rates for both methods have nearly the same

values shifted by one γ-step. In order to complement

the visual interpretation, Table 1 contains the values

for ISS with gamma = 0.008 (second row of each ISS

histogram) and sparse sampling with gamma = 0.001

(ﬁrst row of each sparse sampling histogram).

Table 1: Binary classiﬁcation results for FPFH that can be

achieved with ISS keypoints for γ = 0.0008 and sparse sam-

pling for γ = 0.0001. (Blue cells: max. value).

ISS keypoints sparse sampling

BoF C : 1 5 25 125 C : 1 5 25 125

10 94.66 95.09 95.34 95.47 94.88 95.38 95.68 95.84

20 95.22 95.75 96.04 96.15 95.51 96.06 96.37 96.56

50 95.45 96.12 96.48 96.58 95.67 96.33 96.74 96.90

100 95.46 96.18 96.57 96.65 95.65 96.44 96.92 97.14

200 95.29 96.11 96.56 96.62 95.54 96.33 96.82 97.04

500 94.97 95.91 96.30 96.30 95.32 96.21 96.56 96.66

1000 94.63 95.69 96.02 95.79 95.04 96.13 96.48 96.32

ICINCO 2016 - 13th International Conference on Informatics in Control, Automation and Robotics

544

The differences in classiﬁcation rates between ISS

and sparse sampling are always less than 0.5%. This

cannot be denoted as signiﬁcant. For this reason, the

number of keypoints should be considered with re-

spect to the computation time. The average number

of approx. 355 keypoints per point cloud identiﬁed

by sparse sampling is more than two and a half times

higher, than the average number of approx. 132 key-

points determined by ISS. Accordingly, sparse sam-

pling will not be used due to the larger number of fea-

tures to be calculated.

4.3 Local 3-D Feature Descriptors

10 20 50 100 200 500 1000

PFHFPFH

SHOTUSC

Figure 6: Mean binary classiﬁcation rates of all evaluated

local 3-D feature descriptors (labels shown in Figure 4).

The color scale below the histograms indicates the mean

binary classiﬁcation rates.

Figure 6 illustrates the binary classiﬁcation results

for different local 3-D feature descriptors. The low

classiﬁcation results of SI are immediately apparent.

Additionally, the darkest shade of red indicating the

best classiﬁcation results can be found for C = 125

(right column) and γ = 0.0008 (second row) of each

histogram. Table 2 summarizes the best conﬁgura-

tion of parameters for each of the evaluated local 3-D

feature descriptors, as well as the corresponding clas-

siﬁcation rates.

Table 2: Classiﬁcation rate of the considered descriptors

with ﬁnal set of pipeline parameters. (KP: keypoint algo-

rithm, BoF: size of bag-of-features).

KP BoF C γ rate

SI ISS 50 125 0.008 92.80%

PFH ISS 100 125 0.008 96.56%

FPFH ISS 100 125 0.008 96.65%

SHOT ISS 100 125 0.008 96.27%

USC ISS 200 125 0.008 97.62%

4.4 Overall Classiﬁcation Results

The mean binary classiﬁcation rates shown so far,

consider only how well an object corresponding to

object class C is correctly assigned to C. In prac-

tice, however, it is decisive how often an object cor-

responding to object class C is incorrectly assigned to

another objects class C

. This value is relatively high

due to the fact that the shapes of many objects are very

similar. Thus, the overall classiﬁcation rate is by far

lagging behind the mean binary classiﬁcation rate of

approx. 96%. In fact, an exact assignment (a point

cloud is only assigned to the correct object class and

all other SVMs reject the point cloud) can neither be

achieved considered all 51 object classes, nor while

using the subset of 10 object classes (see Section 3.1).

However, when choosing only that object class

where the corresponding SVM returns the highest

distance between the input vector (i. e., the bag-of-

features histogram) with respect to the separating hy-

perplane, the classiﬁcation rates shown in Table 3 can

be achieved. Above that, the classiﬁcation rates that

can be achieved for 10 object classes are only slightly

lower than those that were achieved by (Alexandre,

2012).

Table 3: Overall classiﬁcation rates that can be achieved

considering the highest distance between the input vector

and the separating hyperplane for each SVM.

51 classes 10 classes

SI 7.4% 23.8%

PFH 6.0% 62.9%

FPFH 9.4% 65.0%

SHOT 3.6% 22.8%

USC 8.5% 59.7%

4.5 Computation Times

The computation times of the ﬁve local 3-D feature

descriptors may be of particular interest to select one

of these algorithms depending on the requirements.

Table 4 gives a brief overview of the system used for

all computations.

Table 4: System used for evaluation.

Conﬁguration

CPU Intel Xeon E5630 @2.53GHz

Memory 12GB DDR3 @1066MHz

OS Debian 8.0 GNU/Linux 64bit

The average computation times to classify a 3-D

point cloud with one of the ﬁve local 3-D feature de-

scriptors are shown in Table 5. The values reﬂect the

Evaluation of Local 3-D Point Cloud Descriptors in Terms of Suitability for Object Classiﬁcation

545

computation times that are required for classiﬁcation.

The computation of keypoints, local 3-D feature vec-

tors, and bag-of-feature are not taken into account.

Table 5: Average classiﬁcation times. The values indicate

the time to classify the bag-of-features histogram within

each SVM.

10 classes all 51 classes

SI ≈ 2.13ms ≈ 10.9ms

PFH ≈ 7.40ms ≈ 37.8ms

FPFH ≈ 2.29ms ≈ 11.7ms

SHOT ≈ 5.85ms ≈ 29.8ms

USC ≈ 3.40ms ≈ 17.3ms

Table 6 shows the mean computation times of a

single local 3-D feature description and a factor that

enables a quick comparison of the computation times

with respect to the fastest algorithm SI.

Table 6: Computation times of 3-D feature description al-

gorithms used within the experiments in ascending order.

The last column shows the factor with respect to the fastest

algorithm SI.

Time Factor

SI ≈ 0.045ms 1

SHOT ≈ 0.28ms ≈ 6

FPFH ≈ 6.69ms ≈ 150

USC ≈ 9.95ms ≈ 220

PFH ≈ 64.51ms ≈ 1430

5 DISCUSSION

Our evaluation of ﬁve local 3-D feature descriptors

with a focus on 3-D object classiﬁcation shows, that

it is possible to achieve approx. 60% to 65% correct

class assignments with PFH, FPFH, and USC (cf. Ta-

ble 3). The two other algorithms, SI and the SHOT

achieve classiﬁcation rates of only 22% and 23%.

In case of SI the mean binary classiﬁcation rate of

92.80% is considerably lower compared to the other

algorithms. The reason for the bad results of SHOT

remains unclear. Considering the algorithms with re-

spect to the computation and classiﬁcation times, SI

and SHOT are by far the fastest methods (cf. Table 5

and 6). However, the classiﬁcation rates of these two

algorithms are so low that the two algorithms should

not be used in this context. Of the remaining three al-

gorithms FPFH is the fastest and best method, i. e., the

method with the highest classiﬁcation rate at the same

time. However, considering the classiﬁcation results

of all local 3-D feature descriptors in context of the

full test dataset using all 51 object classes (cf. Table 3)

it turns out that a classiﬁcation of 3-D objects, that are

almost indistinguishable in terms of shape, is in fact

not possible. For this reason, the use of local 3-D

features can only be seen as a complement to color-

based object classiﬁcation. This is in particular the

case when ambiguous textures or bad lighting condi-

tions complicate a color image based method.

6 CONCLUSION

Summarizing, the Fast Point Feature Histogram pro-

vides the best results in terms of computation time and

classiﬁcation rate. However, it has to be taken into ac-

count that an object classiﬁcation on the sole basis of

3-D representations only works when the classes are

sufﬁciently different.

REFERENCES

Aldoma, A., Marton, Z.-C., Tombari, F., Wohlkinger, W.,

Potthast, C., Zeisl, B., Rusu, R., Gedikli, S., and

Vincze, M. (2012a). Tutorial: Point cloud library:

Three-dimensional object recognition and 6 dof pose

estimation. Robotics Automation Magazine, IEEE,

19(3):80–91.

Aldoma, A., Tombari, F., Rusu, R. B., and Vincze, M.

(2012b). Our-cvfh–oriented, unique and repeat-

able clustered viewpoint feature histogram for ob-

ject recognition and 6dof pose estimation. In Pattern

Recognition, pages 113–122. Springer.

Alexandre, L. A. (2012). 3d descriptors for object and cate-

gory recognition: a comparative evaluation. In Work-

shop on Color-Depth Camera Fusion in Robotics at

the IEEE/RSJ International Conference on Intelligent

Robots and Systems (IROS), Vilamoura, Portugal.

Arbeiter, G., Fuchs, S., Bormann, R., Fischer, J., and Verl,

A. (2012). Evaluation of 3d feature descriptors for

classiﬁcation of surface geometries in point clouds.

In 2012 IEEE/RSJ International Conference on In-

telligent Robots and Systems, IROS 2012, Vilamoura,

Algarve, Portugal, October 7-12, 2012, pages 1644–

1650.

Arthur, D. and Vassilvitskii, S. (2007). k-means++: The

advantages of careful seeding. In Proceedings of the

eighteenth annual ACM-SIAM symposium on Discrete

algorithms, pages 1027–1035. Society for Industrial

and Applied Mathematics.

Cholewa, M. and Sporysz, P. (2014). Classiﬁcation of dy-

namic sequences of 3d point clouds. In Artiﬁcial Intel-

ligence and Soft Computing, pages 672–683. Springer.

Drost, B., Ulrich, M., Navab, N., and Ilic, S. (2010). Model

globally, match locally: Efﬁcient and robust 3d object

recognition. In Computer Vision and Pattern Recogni-

tion (CVPR), 2010 IEEE Conference on, pages 998–

1005. IEEE.

Dutagaci, H., Cheung, C. P., and Godil, A. (2012). Eval-

uation of 3d interest point detection techniques via

ICINCO 2016 - 13th International Conference on Informatics in Control, Automation and Robotics

546

human-generated ground truth. The Visual Computer,

28(9):901–917.

Filipe, S. and Alexandre, L. A. (2013). A comparative eval-

uation of 3d keypoint detectors. In 9th Conference on

Telecommunications, Conftele 2013, pages 145–148,

Castelo Branco, Portugal.

Frome, A., Huber, D., Kolluri, R., Bulow, T., and Malik,

J. (2004). Recognizing objects in range data using

regional point descriptors. In Proceedings of the Eu-

ropean Conference on Computer Vision (ECCV).

Guo, Y., Bennamoun, M., Sohel, F., Lu, M., and Wan,

J. (2014). 3d object recognition in cluttered scenes

with local surface features: A survey. Pattern Analy-

sis and Machine Intelligence, IEEE Transactions on,

36(11):2270–2287.

Heider, P., Pierre-Pierre, A., Li, R., and Grimm, C. (2011).

Local shape descriptors, a survey and evaluation. In

Proceedings of the 4th Eurographics conference on

3D Object Retrieval, pages 49–56. Eurographics As-

sociation.

Johnson, A. and Hebert, M. (1999). Using spin images for

efﬁcient object recognition in cluttered 3d scenes. Pat-

tern Analysis and Machine Intelligence, IEEE Trans-

actions on, 21(5):433–449.

Johnson, A. E. and Hebert, M. (1998). Surface matching

for object recognition in complex three-dimensional

scenes. Image and Vision Computing, 16(9):635–651.

Kim, H. and Hilton, A. (2013). Evaluation of 3d feature de-

scriptors for multi-modal data registration. In 2013 In-

ternational Conference on 3D Vision, 3DV 2013, Seat-

tle, Washington, USA, June 29 - July 1, 2013, pages

119–126.

Knopp, J., Prasad, M., Willems, G., Timofte, R., and

Van Gool, L. (2010). Hough transform and 3d surf for

robust three dimensional classiﬁcation. In Computer

Vision–ECCV 2010, pages 589–602. Springer.

Lai, K., Bo, L., Ren, X., and Fox, D. (2011). A large-

scale hierarchical multi-view rgb-d object dataset. In

Robotics and Automation (ICRA), 2011 IEEE Interna-

tional Conference on, pages 1817–1824. IEEE.

Lian, Z., Godil, A., Bustos, B., Daoudi, M., Hermans, J.,

Kawamura, S., Kurita, Y., Lavou

e, G., Van Nguyen,

H., Ohbuchi, R., et al. (2011). Shrec’11 track: Shape

retrieval on non-rigid 3d watertight meshes. 3DOR,

11:79–88.

Madry, M., Afkham, H. M., Ek, C. H., Carlsson, S., and

Kragic, D. (2013). Extracting essential local object

characteristics for 3d object categorization. In Intelli-

gent Robots and Systems (IROS), 2013 IEEE/RSJ In-

ternational Conference on, pages 2240–2247. IEEE.

Madry, M., Ek, C. H., Detry, R., Hang, K., and Kragic, D.

(2012). Improving generalization for 3d object cate-

gorization with global structure histograms. In Intelli-

gent Robots and Systems (IROS), 2012 IEEE/RSJ In-

ternational Conference on, pages 1379–1386. IEEE.

Rusu, R., Blodow, N., and Beetz, M. (2009). Fast point fea-

ture histograms (fpfh) for 3d registration. In Robotics

and Automation, 2009. ICRA ’09. IEEE International

Conference on, pages 3212–3217.

Rusu, R. B. (2010). Semantic 3d object maps for every-

day manipulation in human living environments. KI-

unstliche Intelligenz, 24(4):345–348.

Rusu, R. B., Blodow, N., Marton, Z. C., and Beetz, M.

(2008a). Aligning point cloud views using persistent

feature histograms. In Intelligent Robots and Systems,

2008. IROS 2008. IEEE/RSJ International Conference

on, pages 3384–3391. IEEE.

Rusu, R. B., Marton, Z. C., Blodow, N., and Beetz, M.

(2008b). Learning informative point classes for the

acquisition of object model maps. In Control, Automa-

tion, Robotics and Vision, 2008. ICARCV 2008. 10th

International Conference on, pages 643–650. IEEE.

Salti, S., Tombari, F., and Stefano, L. D. (2011). A per-

formance evaluation of 3d keypoint detectors. In

3D Imaging, Modeling, Processing, Visualization and

Transmission (3DIMPVT), 2011 International Con-

ference on, pages 236–243. IEEE.

Salti, S., Tombari, F., and Stefano, L. D. (2014). Shot:

Unique signatures of histograms for surface and tex-

ture description. Computer Vision and Image Under-

standing, 125(0):251 – 264.

Seib, V., Christ-Friedmann, S., Thierfelder, S., and Paulus,

D. (2013). Object class and instance recognition on

rgb-d data. In Sixth International Conference on Ma-

chine Vision (ICMV 13), pages 90670J–90670J. Inter-

national Society for Optics and Photonics.

Tang, S. and Godil, A. (2012). An evaluation of lo-

cal shape descriptors for 3d shape retrieval. CoRR,

abs/1202.2368.

Toldo, R., Castellani, U., and Fusiello, A. (2009). A bag of

words approach for 3d object categorization. In Com-

puter Vision/Computer Graphics CollaborationTech-

niques, pages 116–127. Springer.

Toldo, R., Castellani, U., and Fusiello, A. (2010). The bag

of words approach for retrieval and categorization of

3d objects. The Visual Computer, 26(10):1257–1268.

Tombari, F., Salti, S., and Di Stefano, L. (2010a). Unique

shape context for 3d data description. In Proceedings

of the ACM workshop on 3D object retrieval, pages

57–62. ACM.

Tombari, F., Salti, S., and Di Stefano, L. (2010b). Unique

signatures of histograms for local surface descrip-

tion. In Computer Vision–ECCV 2010, pages 356–

369. Springer.

Wu, C.-C. and Lin, S.-F. (2011). Efﬁcient model detection

in point cloud data based on bag of words classiﬁca-

tion. Journal of Computational Information Systems,

7(12):4170–4177.

Yi, Y., Guang, Y., Hao, Z., Meng-Yin, F., and Mei-ling,

W. (2014). Object segmentation and recognition in 3d

point cloud with language model. In Multisensor Fu-

sion and Information Integration for Intelligent Sys-

tems (MFI), 2014 International Conference on, pages

1–6. IEEE.

Zhong, Y. (2009). Intrinsic shape signatures: A shape de-

scriptor for 3d object recognition. In Computer Vision

Workshops (ICCV Workshops), 2009 IEEE 12th Inter-

national Conference on, pages 689–696. IEEE.

Evaluation of Local 3-D Point Cloud Descriptors in Terms of Suitability for Object Classiﬁcation

547
