Towards Context-aware Border Security Control

Boris Shishkov

1,2

and Dimitris Mitrakos

Institute of Mathematics and Informatics, Bulgarian Academy of Sciences, 1113 Sofia, Bulgaria

IICREST, 53 Ivan Susanin Street, 1618 Sofia, Bulgaria

Department of Electrical Engineering, Aristotle University of Thessaloniki, 54124 Thessaloniki, Greece

b.b.shishkov@iicrest.org, mitrakos@eng.auth.gr

Keywords: Enterprise Modeling, Model-driven Engineering, Context-awareness, Border Security, SDBC.

Abstract: Context-aware systems allow for adapting the system behaviour to the context situation at hand and we have

seen good applicability of context-aware systems in domains, such as Mobile Health. Even though this could

also be useful for the Border Security domain, applying context-awareness in this domain is not trivial since

the possible context situations are numerous and difficult to predict. Still, context-aware Border Security

systems are needed as a possible way to overcome the inevitable shortage of resources along the borders.

Smooth and fast border crossing for travellers, in combination with adequate level of security, can be achieved

if: (i) at any moment, the context situation is properly captured; (ii) there is potential for behaviour and

resources (from the Authorities’ side) corresponding to each possible context situation. The context situation

capturing is about sensors, data streaming, and so on. Establishing the right behaviour / resources is about

enterprise modeling and business rules, and it is also about automation that assumes in turn integration of

software applications in the overall Border Security system. In this position paper, we address all that, inspired

by the SDBC Approach, Enterprise Ontology, Semiotic Norms, and the principles of Context-aware Systems.

Reporting research-in-progress, we only present our way of modeling and we identify several domain-specific

concerns that are related to the application of the built models. We also provide a list of recommendations

that are expected to be useful with regard to possible Border Security system developments.

1 INTRODUCTION

Most software systems need to be adequately

integrated in their enterprise environment comprising

enterprise modules, human agents, and even already

running software applications. Hence, traceability

and possible mappings are often needed between a

piece of software and an enterprise module and vice

versa (Shishkov, 2016); this we call enterprise-

software alignment (Shishkov and Janssen, 2016).

The SDBC Approach allows for realizing such an

alignment in a component-based way (Shishkov,

2005), justifying that software specification should be

based on corresponding enterprise models. This can

be achieved when we have sufficient knowledge of

the enterprise environment and this environment is

more or less stable. Nevertheless, if we have a

constantly changing enterprise environment, we

would face a new challenge – the challenge of

handling adaptability. This means adapting to the

surrounding situation in two directions: firstly, if the

enterprise environment is changing, then the

enterprise modules “inside” should be changing in

turn; secondly, if the enterprise environment is

changing, then the “behaviour” of the software

applications running inside the enterprise should be

adapted as well. Said otherwise, we should be able to

adequately establish the situation at hand and provide

the right enterprise / software behaviour accordingly.

This was called context-awareness in research

addressing such adaptability-related challenges in the

domain of Mobile Health (AWARENESS, 2006). An

example is Tele-Monitoring: a patient is being

monitored from distance, using mobile technology;

there are several possible-to-occur situations, each of

them being easy-to-capture distantly; then action is

triggered, corresponding to the captured context

situation. Thus, we argue that context-awareness is a

solution and is easy-to-apply only if we have a limited

number of possible-to-occur situations. However, in

the current position paper, we address a domain

characterized by MANY possible-to-occur situations:

this is the Border Security domain. In

particular, we are interested in the monitoring of

illegal migration and in combatting related crime

207

Shishkov B. and Mitrakos D.

Towards Context-aware Border Security Control.

DOI: 10.5220/0006223802070212

In Proceedings of the Sixth International Symposium on Business Modeling and Software Design (BMSD 2016), pages 207-212

ISBN: 978-989-758-190-8

(and goods smuggling). Guarding along country

borders by electronic means, using various channels:

infrared images, visible images, proximity sensors,

and so on, followed by some kind of intelligent data

fusion algorithms, has been addressed in several

European Projects, such as the European FP7 Project:

“Protection of European Seas and Borders through

the Intelligent Use of Surveillance” (PERSEUS,

2015) and the European EBF Project: “Land Border

Surveillance – Strengthening of Reaction Capacity”

(LandBorderSurveillance, 2012). Still, those efforts

appear to be insufficient as it can be seen from the

severe border problems in Greece and Italy, in 2015-

2016 (FRONTEX, 2016). We recognize the need for

better interoperability with regard to the existing

national border security platforms and systems. We

do agree that innovative capabilities are needed,

including trans-national exchange of available and

useful information, as it has been discussed in the

above-mentioned projects. Nevertheless, we argue

that those would only be part of the solution related

to the challenge of improving Border Security,

supported by (software) technology. We claim that

context-awareness is not applied of full value at the

borders and we claim that context-aware Border

Security systems would make a difference in the

direction of improvement. At the same time, we go

back to our previous conclusion, already mentioned,

that it is not straightforward applying context-aware

solutions in the Border Security domain. Hence,

research is needed on Context-Aware Border Security

(CABS) control, as a possible way to overcome the

inevitable shortage of resources along the borders (it

would be difficult for a country to supply persons and

equipment at every potentially risky border point). A

CABS system would guarantee adaptability with

regard to the situation at hand – persons and

equipment would only be supplied at the spot where

they are needed and in the moment when they are

needed. Of course, if total “tension” appears at all

risky border points at the same time, such an approach

would “crash” but this is similar to the situation of all

customers of a bank claiming back their deposits at

the same time. Such situations are considered to be of

low probability to occur and are thus left beyond the

scope of this paper.

Hence, we claim that smooth and fast border

crossing for travellers in combination with adequate

level of security can only be achieved if:

(i) at any moment, the context situation is properly

captured;

(ii) there is potential for behaviour and resources

(from the Authorities’ side) corresponding to each

possible context situation.

The context situation capturing is about sensors, data

streaming, and so on. Establishing the right behaviour

/ resources is about enterprise modeling and business

rules, and it is also about automation that assumes in

turn integration of software applications in the overall

Border Security system.

Further, because of the increased complexity with

regard to Border Security situations and occurrence

probabilities, we need to address data aspects (going

beyond just interoperability and information

exchange, see above). Ways to capture data, quality

of data and the probability that the captured data is

correct, reliability, versioning, privacy, and so on, are

of importance as well. Hence data analytics is to be

integrated in the enterprise modeling and also in the

software development in order to facilitate context-

awareness, especially in the Border Security domain.

In this position paper, we address all this, inspired

by the SDBC Approach (Shishkov, 2005), Enterprise

Ontology (Dietz, 2006), Semiotic Norms (Liu, 2000;

Shishkov et al., 2006), and the principles of Context-

aware Systems (AWARENESS, 2006).

Reporting research-in-progress, we only present

our way of modeling (Section 2) and we identify

several domain-specific concerns that are related to

the application of the built models (Section 3). We

also provide (as part of the conclusions) a list of

recommendations that are expected to be useful with

regard to possible Border Security system

developments.

2 WAY OF MODELING

As mentioned above, we address the challenges of

deriving software and integrating it in its enterprise

environment, inspired by the SDBC Approach

(Shishkov, 2005). This in turn assumes reference to

the theories of LAP – Enterprise Ontology (Dietz,

2006) and Organizational Semiotics (Liu, 2000);

those are briefly outlined in another paper published

in the current proceedings (Shishkov & Janssen,

2016). The idea behind SDBC is that (re-usable)

enterprise modeling constructs (called “Business

CoMponents”) are identified and reflected in

corresponding software specification models to be in

turn decomposed in terms of models of software

components. SDBC is consistent with the principles

of Model-Driven Engineering – MDE (Schmidt,

2006): building a technology-independent model

goes first, then it is to be decided what would be

automated, and in the end is the software derivation.

This is the “basis”, no matter if we go for developing

a context-aware system or a system that is not

Sixth International Symposium on Business Modeling and Software Design

208

context-aware – in order to contribute especially in

the direction of context-awareness and particularly in

the Border Security domain, we need to have a

“valid” basis to start to build upon. For that we take

SDBC not only because developing this approach is

part of our previous work but also because SDBC has

been validated by means of case studies carried out in

the domains of Finance and Healthcare.

Further, the SDBC Approach and the principles of

MDE were successfully applied in specifying

context-aware systems in domains, such as Mobile

Health.

Nevertheless, as mentioned already, the Border

Security domain assumes greater complexity because

of numerous possible situations and prediction

difficulties. Further, what is observed at the border is

a “mixture” of personnel and devices, subject to

numerous rules and functionalities (FRONTEX,

2016), and it is not trivial approaching this in terms of

technology-independent models, automation, and so

on. This is because some (intuitive) tasks can only be

realized by humans while other (surveillance) tasks

can only be realized by devices, to give just an

example. Hence, we need to “adapt” SDBC to the

peculiarities of the Border Security domain. SDBC

goes “top-down”, from a “bird-view” enterprise

model through delimitation with regard to the

software system –to-be, to implementation.

Nevertheless, for specifying a CABS system, we

propose to go “middle-out”, as exhibited on Figure 1,

and we adapt the application of SDBC accordingly.

Figure 1: CABS – Way of Modeling.

On the Figure: “GM” stands for “general model”,

“CM” stands for “conceptual model”, “ITM” stands

for “IT model”, “HM” stands for “humans model”,

“AM” stands for “aspect model”, and “DA” stands for

“data analytics”.

We propose to go “middle-out” because in the

Border Security domain, it seems most pragmatic to

start with modeling “what is there” (a mixture of

person-tasks, device functionalities, and so on to be

seen at the border) – such a model we call a general

model (GM). No other model that would inevitably be

abstract, would allow for grasping everything

correctly and also communicating it adequately with

all relevant stakeholders – this is claimed to be of

great importance particularly for the Border Security

domain. Just as an example of GM, we consider a

typical point at an external EU border, the border

between Bulgaria and Turkey (FRONTEX, 2016),

and we take an “imaginary” view on things that may

be seen at a border point – see Figure 2.

Figure 2: GM Example.

As seen from the Figure: there is a border fence

and border police officers patrolling along the fence;

there are cameras attached to the fence, which realize

crowd monitoring and there are mobile cameras

attached to drones; there are finger-print devices that

can be used by police officers for personal

identification; there are (networked) computers

running and streaming all sensor raw data, and also

processing it by applying data fusion algorithms (for

example), allowing “higher-level” reasoning, and so

on. Hence, we claim that such a model should be the

starting point in specifying a CABS system.

We use the GM as basis for deriving a CABS-

related classification of concepts – this we call a

conceptual model (CM) – see Figure 1. This way of

“arriving” at the CM guarantees that our further

system development activities would be “grounded”.

The human agent concept and the device

concept appear to be essential within the CABS

conceptual model (Figure 3). That is because the

CABS general model suggests that anything that can

be observed at the border either relates to a personal

(human) role or to a functionality delivered by a

device (equipment). Further, among the human

agents at the border (besides the persons who are

crossing the border and are thus left outside the scope

of the CABS system) are customs officers and

police officers, while among the devices one

could observe at the border are sensors,

Towards Context-aware Border Security Control

209

computers, and vehicles. Sensors in turn could

be audio sensors and video sensors, while

computers could be servers and personal

computers, and vehicles could be cars and

drones. And so on. This is just as an example on

how a CM can be derived, based on a GM.

human agent

entit

device

customs

officer

police

officer

... vehicle

computer

...

sensor

video

sensor

audio

sensor

drone

car

personal

computer

server

Figure 3: Deriving a Conceptual Model.

Such a conceptual model is the necessary starting

point in an SDBC software development but also if

one would just need to build an enterprise model.

What goes next, as it can be seen from Figure 1,

is splitting in two, namely: humans model and IT

model. Said otherwise, all that concerns persons at the

border is put on one side and all that concerns devices

at the border is put on another side. We do not mix

this up even though in enterprise modeling we often

mix up activities that are realized by humans and

activities that are automated, realizing that it is

possible to further automate activities currently

realized by humans. For example, the SDBC

Approach was used to specify the automation of what

a human actor (in particular: Insurance Broker) was

doing, for the sake of “replacing” humans by software

(Shishkov, 2005). In such cases, it is straightforward

putting together in the model issues that concern

human actors and issues that concern non-human

actors. This is claimed to be nevertheless

inappropriate with regard to the Border Security

domain and that is why the CABS conceptual model

strongly distinguishes between human agents and

devices (see Figure 3). Hence, as according to Fig. 1,

we model the human entities and processes (HM), and

in parallel, we model the devices-related entities and

processes (ITM).

That is because devices at the border (on one

hand) capture raw data, stream data, run algorithms,

and so on, and all those issues concern the electronics

features of the devices, not even so much the software

in some cases; further, those societally elementary but

computation-intensive tasks assume nothing like real-

life communication, intuitive behaviour, pro-activity,

and so on. Persons at the border (on the other hand),

such as border police officers, for example, are often

valued especially for their intuitive behaviour,

enriched by many years of experience. It is the person

(not the device) who can “smell in the air” anything

wrong and possibly trigger a check without even

being able to explain why. This is in contrast to other

domains where sometimes a task can equally be

completed by a human actor or by a non-human actor.

We claim that at the border, what persons do and what

devices do are “two different Worlds”.

What is next (see Figure 1) is the modeling

elaboration – each of the two models (HM and ITM)

is to be elaborated; having provided just a

classification of concepts is not enough - statics

(entities and their relationships), dynamics (processes

and states), and so on, need also to be provided as

elaboration. Such elaboration models are called

aspect models (AM). We build those models, inspired

by the four modeling perspectives of the SDBC

Approach: Structural Perspective that reflects entities

and their relationships (Dietz, 2006); Dynamic

Perspective that reflects the overall business process

and the states of each entity (evolving accordingly)

(Van der Aalst, 2011); Data Perspective that reflects

the information flows across entities within the

system and flows reaching beyond the system’s

boundary (Shishkov, 2005); Language-Action

Perspective that reflects real-life human

communication and expression of promises,

commitments, and so on (Shishkov et al., 2006).

Hence, as elaboration, we build structural models,

dynamic models, data models, and language-action

models – those are four aspect models. We proceed

as follows:

• With regard to the HM we do all four elaborations,

but

• With regard to the ITM, we do all except the last

one – the language-action model, because devices

cannot express commitments, do promises, and so

on, using language.

Then, after having elaborated the HM and the

ITM in terms of aspect models, we need to

“synchronize” between the two, as depicted in Figure

1. By bringing together the two structural models, we

establish all relationships between human entities and

device entities, by bringing together the two dynamic

models, we establish if any human action requires as

pre-condition a corresponding device action to be

completed (and vice versa), and so on. A question

could be asked why was it necessary to firstly split

and then synchronize. By firstly splitting in two

(persons and devices) and then bringing them

together, we guarantee for:

Sixth International Symposium on Business Modeling and Software Design

210

• Adequate modeling, because each model is being

generated based on the right background (when

modeling humans, we consider humans and when

modeling devices, we consider devices);

• Exhaustive modeling, because in the end the “two

parts” are brought together.

Then comes the data analytics (DA) – see Fig. 1

and it is important not to confuse this with the “data

perspective” of SDBC, reflected in deriving the

aspect models. This perspective has a purely

functional drive – we consider the data flows as part

of the delivered functionality (for example, a balance

needs to be checked, before allowing a person to

withdraw money from his/her account). The DA, on

the contrary, has a non-functional drive and is

crosscutting. For example: (i) Extracting a face image

of a person, allows for realizing activities on that

basis but is it legally correct to do so and if not, is this

information an “input” or not? (ii) If what we get as

sensor raw data has, say 80% trustworthyness, what

we do forward? Those are just two examples and we

would also mention data versioning, obsolete data,

wrong approximations, and so on. Nevertheless, just

staying aware of those issues is not helpful – we need

to address them functionally (even though in essence

they may be non-functional). A possible way to do

this is by applying Semiotic Norms – see another

paper in the current proceedings (Shishkov &

Janssen, 2016), for example (on considering crowd

monitoring):

Whenever the System has established a situation

if the level of trust is less than 75%

then the System

is obliged to check also another source.

And in the end comes re-engineering – Figure 1,

and the line there is dashed, to indicate that it is not

always needed to re-engineer the system. Still, if the

built models help in identifying inconsistencies, re-

engineering could follow straightforwardly.

This is our proposed way of modeling CABS

systems, in line with the SDBC Approach and as

already mentioned, in the next section, we reason

about the application of the CABS models, by

identifying several concerns related to such an

application.

3 DOMAIN-SPECIFIC

CONCERNS

Being successful in the modeling phase is crucially

important, no question about this, but it is equally

important to be successful in reflecting the models in

architectures that are an adequate basis for

implementation. In this regard, we have identified

several domain-specific concerns, not claiming

exhaustiveness nevertheless, which are presented in

the current section; those concerns are intuitive

behaviour, devices’ technical restrictions, security,

and privacy.

3.1 Intuitive Behaviour

As mentioned before, a border police officer is

sometimes especially valued for his/her capability to

be intuitive with regard to a situation, applying a

“sixth feeling” in deciding what to do. In our view,

this is nearly impossible to capture and reflect in

models. This means in turn that an important Border-

Security-related “asset” would inevitably remain

outside the “scope” of a CABS system.

3.2 Devices’ Technical Restrictions

Often a device at the border is a piece of hardware and

its electronics would often be restrictive with regard

to the ways in which it could be used. If a software

application would have to “bridge” the device to the

system, then in-depth knowledge on the electronics of

the device would be a must – this complicates the job

of enterprise modelers and software designers. Those

restrictions are nevertheless not only electronics-

related – a drone, for example cannot “carry” more

than half a kilo and cannot stay in the air more than a

certain amount of time – such restrictions should be

taken into account as well.

3.3 Security

A CABS system should follow highest security

standards, “higher” than even in Banking because a

Border Security failure may lead to dramatic

consequences for hundreds and thousands of people.

This assumes not only establishing advanced

computer networking but also “guaranteeing” what

human actors would do (or not do). This is to be taken

into account and in our view, it is very difficult to

actually establish and maintain so high security

standards in two perspectives - personal and

technical.

3.4 Privacy

A CABS system should be a privacy-sensitive system

because of a number of privacy-related risks at the

border, concerning both border police officers and

Towards Context-aware Border Security Control

211

persons crossing the border. For example, it should

not be possible that terrorists whose crossing the

border was obstacled by a border police officer, are

able to later on identify the police officer. Another

example: it should not be possible that crowd

monitoring information is used later on in another

context, with regard to the monitored person(s).

Those issues are “burdened” with many legal aspects

and what makes things even more complicated is that

legislation differs from country to country, even

inside the EU.

Those are four important concerns, related to the

application of the CABS models and they indicate

that there are issues beyond enterprise modeling and

software design, that need to be taken into account

and have great potential impact on the CABS system

–to-be.

4 CONCLUSIONS

There is room for improving both the effectiveness

and efficiency of the control at the external EU

borders, and context awareness is a desired feature in

this regard. Nevertheless, the development of

context-aware Border Security systems is not trivial

because of numerous possible-to-occur situations and

prediction difficulties, and because of person-specific

(intuitive) and device-specific (algorithmic)

behaviour patterns. A “middle-out” realization of the

SDBC Approach is proposed to tackle this, coming

through the derivation of a general model, a

conceptual model (split in two – a humans model

(HM) and an IT model (ITM)), modeling

elaborations, a synchronization between HM and

ITM, and enrichment in terms of data analytics.

Persons’ intuitive behaviour, the technical restrictions

of devices, security, and privacy are among the

concerns related to the application of those models.

Inspired by the aim of furthering this research, we

would stick to the following recommendations that

we identified accordingly:

• A CABS system should be modeled as a human-

centric system because the intuitive behaviour of

border police officers is and will be of great

importance at the border.

• In using devices, the quality-of-data is to be of

great importance for a CABS system, and this

issue is to be also handled functionally.

• A CABS system is to be modeled as a context-

aware system where the delivered system

behaviour depends on the context situation at

hand.

• A CABS system is to be based on an enterprise

model that is split in two – one part featuring

persons and another part featuring devices; a

synchronization between the two is essential.

• Security and privacy are issues that are to be taken

into account additionally, in order to have a CABS

system of real value.

REFERENCES

AWARENESS, 2006, the website on the Freeband

AWARENESS Project: https://www.utwente.nl

/ctit/research/research_projects/concluded/bsik/

freeband/projects/awareness

Dietz, J.L.G., 2006. Enterprise Ontology, Theory and

Methodology. Springer-Verlag, Berlin Heidelberg.

FRONTEX, 2016, the website on the European Agency

FRONTEX: http://frontex.europa.eu.

LandBorderSurveillance, 2012, the website on the EBF

LandBorderSurveillance Project: http://ec.europa.eu/

dgs/homeaffairs/financing/fundings/projects/

project_example_048_en.htm

Liu, K., 2000. Semiotics in Information Systems

Engineering. Cambridge University Press, Cambridge.

PERSEUS, 2015, the website on the European FP7

PERSEUS Project: http://cordis.europa.eu/

project/rcn/97515_en.html

Schmidt, D.C., 2006. Model-Driven Engineering. IEEE

Computer Society.

Shishkov, B., 2016. Foreword. In BMSD’16, 6th

International Symposium on Business Modeling and

Software Design. SCITEPRESS.

Shishkov, B., 2005. Software Specification Based on Re-

usable Business Components (PhD Thesis), TU Delft –

SIKS Publishing. Delft.

Shishkov, B., Dietz, J.L.G., Liu, K., 2006. Bridging the

Language-Action Perspective and Organizational

Semiotics in SDBC. In ICEIS’06, 8th International

Conference on Enterprise Information Systems.

SCITEPRESS.

Shishkov, B. and Janssen, M., 2016. Towards a Service-

Oriented Architecture for eVoting. In BMSD’16, 6th

International Symposium on Business Modeling and

Software Design. SCITEPRESS.

Van der Aalst, W., 2011. Process Mining - Discovery,

Conformance and Enhancement of Business Processes.

Springer-Verlag, Berlin Heidelberg.

Sixth International Symposium on Business Modeling and Software Design

212
