Green Data Science

Using Big Data in an “Environmentally Friendly” Manner

Wil M. P. van der Aalst

Eindhoven University of Technology, Department of Mathematics and Computer Science,

PO Box 513, NL-5600 MB Eindhoven, The Netherlands

Keywords:

Data Science, Big Data, Fairness, Conﬁdentiality, Accuracy, Transparency, Process Mining.

Abstract:

The widespread use of “Big Data” is heavily impacting organizations and individuals for which these data are

collected. Sophisticated data science techniques aim to extract as much value from data as possible. Powerful

mixtures of Big Data and analytics are rapidly changing the way we do business, socialize, conduct research,

and govern society. Big Data is considered as the “new oil” and data science aims to transform this into new

forms of “energy”: insights, diagnostics, predictions, and automated decisions. However, the process of trans-

forming “new oil” (data) into “new energy” (analytics) may negatively impact citizens, patients, customers,

and employees. Systematic discrimination based on data, invasions of privacy, non-transparent life-changing

decisions, and inaccurate conclusions illustrate that data science techniques may lead to new forms of “pollu-

tion”. We use the term “Green Data Science” for technological solutions that enable individuals, organizations

and society to reap the beneﬁts from the widespread availability of data while ensuring fairness, conﬁden-

tiality, accuracy, and transparency. To illustrate the scientiﬁc challenges related to “Green Data Science”, we

focus on process mining as a concrete example. Recent breakthroughs in process mining resulted in powerful

techniques to discover the real processes, to detect deviations from normative process models, and to analyze

bottlenecks and waste. Therefore, this paper poses the question: How to beneﬁt from process mining while

avoiding “pollutions” related to unfairness, undesired disclosures, inaccuracies, and non-transparency?

1 INTRODUCTION

In recent years, data science emerged as a new and

important discipline. It can be viewed as an amal-

gamation of classical disciplines like statistics, data

mining, databases, and distributed systems. We use

the following deﬁnition: “Data science is an inter-

disciplinary ﬁeld aiming to turn data into real value.

Data may be structured or unstructured, big or small,

static or streaming. Value may be provided in the form

of predictions, models learned from data, or any type

of data visualization delivering insights. Data science

includes data extraction, data preparation, data ex-

ploration, data transformation, storage and retrieval,

computing infrastructures, various types of mining

and learning, presentation of explanations and pre-

dictions, and the exploitation of results taking into

account ethical, social, legal, and business aspects.”

(Aalst, 2016).

Related to data science is the overhyped term “Big

Data” that is used to refer to the massive amounts

of data collected. Organizations are heavily invest-

ing in Big Data technologies, but at the same time

citizens, patients, customers, and employees are con-

cerned about the use of their data. We live in an

era characterized by unprecedented opportunities to

sense, store, and analyze data related to human ac-

tivities in great detail and resolution. This introduces

new risks and intended or unintended abuse enabled

by powerful analysis techniques. Data may be sensi-

tive and personal, and should not be revealed or used

for proposes different from what was agreed upon.

Moreover, analysis techniques may discriminate mi-

norities even when attributes like gender and race are

removed. Using data science technology as a “black

box” making life-changing decisions (e.g., medical

prioritization or mortgage approvals) triggers a vari-

ety of ethical dilemmas.

Sustainable data science is only possible when

citizens, patients, customers, and employees are pro-

tected against irresponsible uses of data (big or

small). Therefore, we need to separate the “good”

and “bad” of data science. Compare this with envi-

ronmentally friendly forms of green energy (e.g. so-

lar power) that overcome problems related to tradi-

tional forms of energy. Data science may result in

Van Der Aalst W.

Green Data Science - Using Big Data in an â

AIJEnvironmentally Friendlyâ

I Manner.

DOI: 10.5220/0006806900010001

In Proceedings of the 18th International Conference on Enterprise Information Systems (ICEIS 2016), pages 9-21

ISBN: 978-989-758-187-8

unfair decision making, undesired disclosures, inac-

curacies, and non-transparency. These irresponsible

uses of data can be viewed as “pollution”. Abandon-

ing the systematic use of data may help to overcome

these problems. However, this would be comparable

to abandoning the use of energy altogether. Data sci-

ence is used to make products and services more reli-

able, convenient, efﬁcient, and cost effective. More-

over, most new products and services depend on the

collection and use of data. Therefore, we argue that

the “prohibition of data (science)” is not a viable so-

lution.

In this paper, we coin the term “Green Data Sci-

ence” (GDS) to refer to the collection of techniques

and approaches trying to reap the beneﬁts of data sci-

ence and Big Data while ensuring fairness, conﬁden-

tiality, accuracy, and transparency. We believe that

technological solutions can be used to avoid pollution

and protect the environment in which data is collected

and used. Section 2 elaborates on the following four

challenges:

• Fairness – Data Science without prejudice: How

to avoid unfair conclusions even if they are true?

• Conﬁdentiality – Data Science that ensures con-

ﬁdentiality: How to answer questions without re-

vealing secrets?

• Accuracy – Data Science without guesswork:

How to answer questions with a guaranteed level

of accuracy?

• Transparency – Data Science that provides trans-

parency: How to clarify answers such that they

become indisputable?

Concerns related to privacy and personal data protec-

tion triggered legislation like the EU’s Data Protec-

tion Directive. Directive 95/46/EC (“on the protection

of individuals with regard to the processing of per-

sonal data and on the free movement of such data”) of

the European Parliament and the Council was adopted

on 24 October 1995 (European Commission, 1995).

The General Data Protection Regulation (GDPR) is

currently under development and aims to strengthen

and unify data protection for individuals within the

EU (European Commission, 2015). GDPR will re-

place Directive 95/46/EC and is expected to be ﬁnal-

ized in Spring 2016 and will be much more restrictive

than earlier legislation. Sanctions include ﬁnes of up

to 4% of the annual worldwide turnover. GDPR and

other forms of legislation limiting the use of data, may

prevent the use of data science also in situations where

data is used in a positive manner. Prohibiting the col-

lection and systematic use of data is like turning back

the clock. Next to legislation, positive technological

solutions are needed to ensure fairness, conﬁdential-

ity, accuracy, and transparency. By just imposing re-

strictions, individuals, organizations and society can-

not exploit data (science) in a positive way.

The four challenges discussed in Section 2 are

quite general. Therefore, we focus on a concrete

subdiscipline in data science in Section 3: Process

Mining (Aalst, 2011). Process mining seeks the con-

frontation between event data (i.e., observed behav-

ior) and process models (hand-made or discovered au-

tomatically). Event data are related to explicit process

models, e.g., Petri nets or BPMN models. For exam-

ple, process models are discovered from event data or

event data are replayed on models to analyze com-

pliance and performance. Process mining provides

a bridge between data-driven approaches (data min-

ing, machine learning and business intelligence) and

process-centric approaches (business process model-

ing, model-based analysis, and business process man-

agement/reengineering). Process mining results may

drive redesigns, show the need for new controls, trig-

ger interventions, and enable automated decision sup-

port. Individuals inside (e.g., end-users and workers)

and outside (e.g., customers, citizens, or patients) the

organization may be impacted by process mining re-

sults. Therefore, Section 3 lists process mining chal-

lenges related to fairness, conﬁdentiality, accuracy,

and transparency.

In the long run, data science is only sustainable

if we are willing to address the problems discussed

in this paper. Rather than abandoning the use of data

altogether, we should ﬁnd positive technological ways

to protect individuals.

2 FOUR CHALLENGES

Figure 1 sketches the “data science pipeline”. Individ-

uals interact with a range of hardware/software sys-

tems (information systems, smartphones, websites,

wearables, etc.) Ê. Data related to machine and in-

teraction events are collected Ë and preprocessed

for analysis Ì. During preprocessing data may be

transformed, cleaned, anonymized, de-identiﬁed, etc.

Models may be learned from data or made/modiﬁed

by hand Í. For compliance checking, models are of-

ten normative and made by hand rather than discov-

ered from data. Analysis results based on data (and

possibly also models) are presented to analysts, man-

agers, etc. Î or used to inﬂuence the behavior of in-

formation systems and devices Ï. Based on the data,

decisions are made or recommendations are provided.

Analysis results may also be used to change systems,

laws, procedures, guidelines, responsibilities, etc. Ð.

Figure 1 also lists the four challenges discussed

data in a

variety of

systems

data used as

input for

analytics

information

systems,

devices, etc.

results

models

extract, load,

transform, clean,

anonymize, de-

identify, etc.

report, discover,

mine, learn, check,

predict, recommend, etc.

interaction with individuals

interpretation by analysts, managers, etc.

Figure 1: The “data science pipeline” facing four challenges.

in the remainder of this section. Each of the chal-

lenges requires an understanding of the whole data

pipeline. Flawed analysis results or bad decisions

may be caused by different factors such as a sampling

bias, careless preprocessing, inadequate analysis, or

an opinionated presentation.

2.1 Fairness - Data Science without

Prejudice: How to Avoid Unfair

Conclusions Even if they are True?

Data science techniques need to ensure fairness: Au-

tomated decisions and insights should not be used to

discriminate in ways that are unacceptable from a le-

gal or ethical point of view. Discrimination can be de-

ﬁned as “the harmful treatment of an individual based

on their membership of a speciﬁc group or category

(race, gender, nationality, disability, marital status, or

age)”. However, most analysis techniques aim to dis-

criminate among groups. Banks handing out loans

and credit cards try to discriminate between groups

that will pay their debts and groups that will run into

ﬁnancial problems. Insurance companies try to dis-

criminate between groups that are likely to claim and

groups that are less likely to claim insurance. Hos-

pitals try to discriminate between groups for which

a particular treatment is likely to be effective and

groups for which this is less likely. Hiring employ-

ees, providing scholarships, screening suspects, etc.

can all be seen as classiﬁcation problems: The goal

is to explain a response variable (e.g., person will pay

back the loan) in terms of predictor variables (e.g.,

credit history, employment status, age, etc.). Ideally,

the learned model explains the response variable as

good as possible without discriminating on the basis

of sensitive attributes (race, gender, etc.).

To explain discrimination discovery and discrimi-

nation prevention, let us consider the set of all (poten-

tial) customers of some insurance company specializ-

ing in car insurance. For each customer we have the

following variables:

• name,

• birthdate,

• gender (male or female),

• nationality,

• car brand (Alfa, BMW, etc.),

• years of driving experience,

• number of claims in the last year,

• number of claims in the last ﬁve years, and

• status (insured, refused, or left).

The status ﬁeld is used to distinguish current cus-

tomers (status=insured) from customers that were re-

fused (status=refused) or that left the insurance com-

pany during the last year (status=left). Customers that

were refused or that left more than a year ago are re-

moved from the data set.

Techniques for discrimination discovery aim to

identify groups that are discriminated based on sen-

sitive variables, i.e., variables that should not matter.

For example, we may ﬁnd that “males have a higher

likelihood to be rejected than females” or that “for-

eigners driving a BMW have a higher likelihood to be

rejected than Dutch BMW drivers”. Discrimination

may be caused by human judgment or by automated

decision algorithms using a predictive model. The

decision algorithms may discriminate due to a sam-

pling bias, incomplete data, or incorrect labels. If ear-

lier rejections are used to learn new rejections, then

prejudices may be reinforced. Similar “self-fulﬁlling

prophecies” can be caused by sampling or missing

values.

Even when there is no intent to discriminate, dis-

crimination may still occur. Even when the auto-

mated decision algorithm does not use gender and

uses only non-sensitive variables, the actual decisions

may still be such that (fe)males or foreigners have a

much higher probability to be rejected. The decision

algorithm may also favor more frequent values for a

variable. As a result, minority groups may be treated

unfairly.

fairness

accuracy

low accuracy

highest accuracy

possible using all data

without constraints

analysis results

and model are

non-discriminating

analysis results and

model are created

without considering

discrimination

possible compromise

between fairness and

accuracy

ideal

situation

(impossible)

Figure 2: Tradeoff between fairness and accuracy.

Discrimination prevention aims to create auto-

mated decision algorithms that do not discriminate us-

ing sensitive variables. It is not sufﬁcient to remove

these sensitive variables: Due to correlations and the

handling of outliers, unintentional discrimination may

still take place. One can add constraints to the deci-

sion algorithm to ensure fairness using a predeﬁned

criterion. For example, the constraint “males and fe-

males should have approximately the same probabil-

ity to be rejected” can be added to a decision-tree

learning algorithm. Next to adding algorithm-speciﬁc

constraints used during analysis one can also use pre-

processing (modify the input data by resampling or

relabeling) or postprocessing (modify models, e.g.,

relabel mixed leaf nodes in a decision tree). In gen-

eral there is often a trade-off between maximizing ac-

curacy and minimizing discrimination (see Figure 2).

By rejecting fewer males (better fairness), the insur-

ance company may need to pay more claims.

Discrimination prevention often needs to use sen-

sitive variables (gender, age, nationality, etc.) to en-

sure fairness. This creates a paradox, e.g., informa-

tion on gender needs to be used to avoid discrimina-

tion based on gender.

The ﬁrst paper on discrimination-aware data min-

ing appeared in 2008 (Pedreshi et al., 2008). Since

then, several papers mostly focusing on fair classiﬁca-

tion appeared: (Calders and Verwer, 2010; Kamiran

et al., 2010; Ruggieri et al., 2010). These examples

show that unfairness during analysis can be actively

prevented. However, unfairness is not limited to clas-

siﬁcation and more advanced forms of analytics also

need to ensure fairness.

2.2 Conﬁdentiality - Data Science that

Ensures Conﬁdentiality: How to

Answer Questions without

Revealing Secrets?

The application of data science techniques should not

reveal certain types of personal or otherwise sensi-

tive information. Often personal data need to be kept

conﬁdential. The General Data Protection Regula-

tion (GDPR) currently under development (European

Commission, 2015) focuses on personal information:

“The principles of data protection should apply to any

information concerning an identiﬁed or identiﬁable natural

person. Data including pseudonymized data, which could

be attributed to a natural person by the use of additional in-

formation, should be considered as information on an iden-

tiﬁable natural person. To determine whether a person is

identiﬁable, account should be taken of all the means rea-

sonably likely to be used either by the controller or by any

other person to identify the individual directly or indirectly.

To ascertain whether means are reasonably likely to be used

to identify the individual, account should be taken of all ob-

jective factors, such as the costs of and the amount of time

required for identiﬁcation, taking into consideration both

available technology at the time of the processing and tech-

nological development. The principles of data protection

should therefore not apply to anonymous information, that

is information which does not relate to an identiﬁed or iden-

tiﬁable natural person or to data rendered anonymous in

such a way that the data subject is not or no longer identiﬁ-

able.”

Conﬁdentiality is not limited to personal data.

Companies may want to hide sales volumes or pro-

duction times when presenting results to certain stake-

holders. One also needs to bear in mind that few infor-

mation systems hold information that can be shared

or analyzed without limits (e.g., the existence of per-

sonal data cannot be avoided). The “data science

pipeline” depicted in Figure 1 shows that there are dif-

ferent types of data having different audiences. Here

we focus on: (1) the “raw data” stored in the informa-

tion system Ë, (2) the data used as input for analysis

Ì, and (3) the analysis results interpreted by analysts

and managers Î. Whereas the raw data may refer to

individuals, the data used for analysis is often (partly)

de-identiﬁed, and analysis results may refer to aggre-

gate data only. It is important to note that conﬁden-

tiality may be endangered along the whole pipeline

and includes analysis results.

Consider a data set that contains sensitive infor-

mation. Records in such a data set may have three

types of variables:

• Direct Identiﬁers: Variables that uniquely identify

a person, house, car, company, or other entity. For

example, a social security number identiﬁes a per-

son.

• Key Variables: Subsets of variables that together

can be used to identify some entity. For example,

it may be possible to identify a person based on

gender, age, and employer. A car may be uniquely

identiﬁed based on registration date, model, and

color. Key variables are also referred to as implicit

identiﬁers or quasi identiﬁers.

• Non-identifying Variables: Variables that cannot

be used to identify some entity (direct or indirect).

Conﬁdentiality is impaired by unintended or mali-

cious disclosures. We consider three types of such

disclosures:

• Identity Disclosure: Information about an entity

(person, house, etc.) is revealed. This can be done

through direct or implicit identiﬁers. For exam-

ple, the salaries of employees are disclosed unin-

tentionally or an intruder is able to retrieve patient

data.

• Attribute Disclosure: Information about an entity

can be derived indirectly. If there is only one male

surgeon in the age group 40-45, then aggregate

data for this category reveals information about

this person.

• Partial Disclosure: Information about a group of

entities can be inferred. Aggregate information

on male surgeons in the age group 40-45 may dis-

close an unusual number of medical errors. These

cannot be linked to a particular surgeon. Never-

theless, one may conclude that surgeons in this

group are more likely to make errors.

De-identiﬁcation of data refers to the process of re-

moving or obscuring variables with the goal to min-

imize unintended disclosures. In many cases re-

identiﬁcation is possible by linking different data

sources. For example, the combination of wedding

date and birth date may allow for the re-identiﬁcation

of a particular person. Anonymization of data refers to

de-identiﬁcation that is irreversible: re-identiﬁcation

is impossible. A range of de-identiﬁcation methods is

available: removing variables, randomization, hash-

ing, shufﬂing, sub-sampling, aggregation, truncation,

generalization, adding noise, etc. Adding some noise

to a continuous variable or the coarsening of values

may have a limited impact on the quality of analysis

results while ensuring conﬁdentiality.

confidentiality

data utility

no meaningful

analysis possible

full use of data

potential possible

full disclosure

of sensitive

data

no sensitive

data disclosed

possible compromise

between confidentiality

and utility

ideal

situation

(impossible)

Figure 3: Tradeoff between conﬁdentiality and utility.

There is a trade-off between minimizing the dis-

closure of sensitive information and the usefulness of

analysis results (see Figure 3). Removing variables,

aggregation, and adding noise can make it hard to pro-

duce any meaningful analysis results. Emphasis on

conﬁdentiality (like security) may also reduce conve-

nience. Note that personalization often conﬂicts with

fairness and conﬁdentiality. Disclosing all data, sup-

ports analysis, but jeopardizes conﬁdentiality.

Access rights to the different types of data and

analysis results in the “data science pipeline” (Fig-

ure 1) vary per group. For example, very few peo-

ple will have access to the “raw data” stored in the

information system Ë. More people will have access

to the data used for analysis and the actual analysis

results. Poor cybersecurity may endanger conﬁden-

tiality. Good policies ensuring proper authentication

(Are you who you say you are?) and authorization

(What are you allowed to do?) are needed to protect

access to the pipeline in Figure 1. Cybersecurity mea-

sures should not complicate access, data preparation,

and analysis; otherwise people may start using illegal

copies and replicate data.

See (Monreale et al., 2014; Nelson, 2015; Presi-

dent’s Council, 2014) for approaches to ensure conﬁ-

dentiality.

2.3 Accuracy - Data Science without

Guesswork: How to Answer

Questions with a Guaranteed Level

of Accuracy?

Increasingly decisions are made using a combina-

tion of algorithms and data rather than human judge-

ment. Hence, analysis results need to be accurate

and should not deceive end-users and decision mak-

ers. Yet, there are several factors endangering accu-

racy.

First of all, there is the problem of overﬁtting the

data leading to “bogus conclusions”. There are nu-

merous examples of so-called spurious correlations

illustrating the problem. Some examples (taken from

(Vigen, 2015)):

• The per capita cheese consumption strongly cor-

relates with the number of people who died by be-

coming tangled in their bedsheets.

• The number of Japanese passenger cars sold in

the US strongly correlates with the number of sui-

cides by crashing of motor vehicle.

• US spending on science, space and technol-

ogy strongly correlates with suicides by hanging,

strangulation and suffocation.

• The total revenue generated by arcades strongly

correlates with the number of computer science

doctorates awarded in the US.

When using many variables relative to the number of

instances, classiﬁcation may result in complex rules

overﬁtting the data. This is often referred to as the

curse of dimensionality: As dimensionality increases,

the number of combinations grows so fast that the

available data become sparse. With a ﬁxed number

of instances, the predictive power reduces as the di-

mensionality increases. Using cross-validation most

ﬁndings (e.g., classiﬁcation rules) will get rejected.

However, if there are many ﬁndings, some may sur-

vive cross-validation by sheer luck.

In statistics, Bonferroni’s correction is a method

(named after the Italian mathematician Carlo Emilio

Bonferroni) to compensate for the problem of multi-

ple comparisons. Normally, one rejects the null hy-

pothesis if the likelihood of the observed data under

the null hypothesis is low (Casella and Berger, 2002).

If we test many hypotheses, we also increase the like-

lihood of a rare event. Hence, the likelihood of in-

correctly rejecting a null hypothesis increases (Miller,

1981). If the desired signiﬁcance level for the whole

collection of null hypotheses is α, then the Bonfer-

roni correction suggests that one should test each in-

dividual hypothesis at a signiﬁcance level of

where

k is the number of null hypotheses. For example, if

α = 0.05 and k = 20, then

= 0.0025 is the required

signiﬁcance level for testing the individual hypothe-

ses.

Next to overﬁtting the data and testing multiple

hypotheses, there is the problem of uncertainty in the

input data and the problem of not showing uncer-

tainty in the results.

Uncertainty in the input data is related to the

fourth “V” in the four “V’s of Big Data” (Volume,

Velocity, Variety, and Veracity). Veracity refers to the

trustworthiness of the input data. Sensor data may be

uncertain, multiple users may use the same account,

tweets may be generated by software rather than peo-

ple, etc. These uncertainties are often not taken into

account during analysis assuming that things “even

out” in larger data sets. This does not need to be the

case and the reliability of analysis results is affected

by unreliable or probabilistic input data.

When we say, “we are 95% conﬁdent that the

true value of parameter x is in our conﬁdence inter-

val [a,b]”, we mean that 95% of the hypothetically

observed conﬁdence intervals will hold the true value

of parameter x. Averages, sums, standard deviations,

etc. are often based on sample data. Therefore, it is

important to provide a conﬁdence interval. For exam-

ple, given a mean of 35.4 the 95% conﬁdence interval

may be [35.3,35.6], but the 95% conﬁdence interval

may also be [15.3,55.6]. In the latter case, we will

interpret the mean of 35.4 as a “wild guess” rather

than a representative value for true average value. Al-

though we are used to conﬁdence intervals for numer-

ical values, decision makers have problems interpret-

ing the expected accuracy of more complex analysis

results like decision trees, association rules, process

models, etc. Cross-validation techniques like k-fold

checking and confusion matrices give some insights.

However, models and decisions tend to be too “crisp”

(hiding uncertainties). Explicit vagueness or more ex-

plicit conﬁdence diagnostics may help to better inter-

pret analysis results. Parts of models should be kept

deliberately “vague” if analysis is not conclusive.

2.4 Transparency - Data Science that

Provides Transparency: How to

Clarify Answers Such that they

become Indisputable?

Data science techniques are used to make a variety of

decisions. Some of these decisions are made automat-

ically based on rules learned from historic data. For

example, a mortgage application may be rejected au-

tomatically based on a decision tree. Other decisions

According to Bonferroni’s principle we need to avoid treating random observations as if they are real and sig-

niﬁcant (Rajaraman and Ullman, 2011). The following example, inspired by a similar example in (Rajaraman

and Ullman, 2011), illustrates the risk of treating completely random events as patterns.

A Dutch government agency is searching for terrorists by examining hotel visits of all of its 18 million citizens

(18 × 10

). The hypothesis is that terrorists meet multiple times at some hotel to plan an attack. Hence, the

agency looks for suspicious “events” {p

, p

} † {d

} where persons p

and p

meet on days d

and d

How many of such suspicious events will the agency ﬁnd if the behavior of people is completely random? To

estimate this number we need to make some additional assumptions. On average, Dutch people go to a hotel

every 100 days and a hotel can accommodate 100 people at the same time. We further assume that there are

18×10

100×100

= 1800 Dutch hotels where potential terrorists can meet.

The probability that two persons (p

and p

) visit a hotel on a given day d is

100

= 10

−4

. The probability

that p

and p

visit the same hotel on day d is 10

−4

1800

= 5.55 ×10

−8

. The probability that p

and p

visit

the same hotel on two different days d

and d

is (5.55 × 10

−8

)

= 3.086 × 10

−15

. Note that different hotels

may be used on both days. Hence, the probability of suspicious event {p

, p

} † {d

} is 3.086 ×10

−15

How many candidate events are there? Assume an observation period of 1000 days. Hence, there are 1000 ×

(1000 − 1)/2 = 499,500 combinations of days d

and d

. Note that the order of days does not matter, but the

days need to be different. There are (18 × 10

) × (18 × 10

− 1)/2 = 1.62 × 10

combinations of persons p

and p

. Again the ordering of p

and p

does not matter, but p

6= p

. Hence, there are 499,500×1.62×10

8.09 × 10

candidate events {p

, p

} † {d

The expected number of suspicious events is equal to the product of the number of candidate events {p

, p

} †

} and the probability of such events (assuming independence): 8.09 ×10

× 3.086 × 10

−15

= 249, 749.

Hence, there will be around a quarter million observed suspicious events {p

, p

} † {d

} in a 1000 day

period!

Suppose that there are only a handful of terrorists and related meetings in hotels. The Dutch government agency

will need to investigate around a quarter million suspicious events involving hundreds of thousands innocent

citizens. Using Bonferroni’s principle, we know beforehand that this is not wise: there will be too many false

positives.

Example: Bonferroni’s principle explained using an example taken from (Aalst, 2016). To apply the principle, compute the

number of observations of some phenomena one is interested in under the assumption that things occur at random. If this

number is signiﬁcantly larger than the real number of instances one expects, then most of the ﬁndings will be false positives.

are based on analysis results (e.g., process models or

frequent patterns). For example, when analysis re-

veals previously unknown bottlenecks, then this may

have consequences for the organization of work and

changes in stafﬁng (or even layoffs). Automated de-

cision rules (Ï in Figure 1) need to be as accurate

as possible (e.g., to reduce costs and delays). Anal-

ysis results (Î in Figure 1) also need to be accurate.

However, accuracy is not sufﬁcient to ensure accep-

tance and proper use of data science techniques. Both

decisions Ï and analysis results Î also need to be

transparent.

Figure 4 illustrates the notion of transparency.

Consider an application submitted by John evaluated

using three data-driven decision systems. The ﬁrst

system is a black box: It is unclear why John’s appli-

cation is rejected. The second system reveals it’s deci-

sion logic in the form of a decision tree. Applications

from females and younger males are always accepted.

Only applications from older males get rejected. The

third system uses the same decision tree, but also ex-

plains the rejection (“because male and above 50”).

gender

age

reject

gender

age

reject

gender

age

reject

black box

data-driven

decision system 2

data-driven

decision system 3

data-driven

decision system 1

Your cla im is

rejected

because you

are male

and abo ve 50

...

Figure 4: Different levels of transparency.

Clearly, the third system is most transparent. When

governments make decisions for citizens it is often

mandatory to explain the basis for such decisions.

Deep learning techniques (like many-layered neu-

ral networks) use multiple processing layers with

complex structures or multiple non-linear transforma-

tions. These techniques have been successfully ap-

plied to automatic speech recognition, image recogni-

tion, and various other complex decision tasks. Deep

learning methods are often looked at as a “black box”,

with performance measured empirically and no for-

mal guarantees or explanations. A many-layered neu-

ral network is not as transparent as for example a deci-

sion tree. Such a neural network may make good deci-

sions, but it cannot explain a rule or criterion. There-

fore, such black box approaches are non-transparent

and may be unacceptable in some domains.

Transparency is not restricted to automated deci-

sion making and explaining individual decisions, it

also involves the intelligibility, clearness, and com-

prehensibility of analysis results (e.g., a process

model, decision tree, regression formula). For exam-

ple, a model may reveal bottlenecks in a process, pos-

sible fraudulent behavior, deviations by a small group

of individuals, etc. It needs to be clear for the user

of such models (e.g., a manager) how these ﬁndings

where obtained. The link to the data and the analysis

technique used should be clear. For example, ﬁltering

the input data (e.g., removing outliers) or adjusting

parameters of the algorithm may have a dramatic ef-

fect on the model returned.

Storytelling is sometimes referred to as “the last

mile in data science”. The key question is: How to

communicate analysis results with end-users? Story-

telling is about communicating actionable insights to

the right person, at the right time, in the right way.

One needs to know the gist of the story one wants

to tell to successfully communicate analysis results

(rather than presenting the whole model and all data).

One can use natural language generation to transform

selected analysis results into concise, easy-to-read, in-

dividualized reports.

To provide transparency there should be a clear

link between data and analysis results/stories. One

needs to be able to drill-down and inspect the data

from the model’s perspective. Given a bottleneck one

needs to be able to drill down to the instances that

are delayed due to the bottleneck. This related to data

provenance: it should always be possible to reproduce

analysis results from the original data.

The four challenges depicted in Figure 1 are

clearly interrelated. There may be trade-offs between

fairness, conﬁdentiality, accuracy and transparency.

For example, to ensure conﬁdentiality we may add

noise and de-identify data thus possibly compromis-

ing accuracy and transparency.

3 EXAMPLE: GREEN PROCESS

MINING

The goal of process mining is to turn event data into

insights and actions (Aalst, 2016). Process mining is

an integral part of data science, fueled by the avail-

ability of data and the desire to improve processes.

Process mining can be seen as a means to bridge

the gap between data science and process science.

Data science approaches tend to be process agonistic

whereas process science approaches tend to be model-

driven without considering the “evidence” hidden in

the data. This section discusses challenges related to

fairness, conﬁdentiality, accuracy, and transparency in

the context of process mining. The goal is not to pro-

vide solutions, but to illustrate that the more general

challenges discussed before trigger concrete research

questions when considering processes and event data.

3.1 What is Process Mining?

Figure 5 shows the “process mining pipeline” and can

be viewed as a specialization of the Figure 1. Pro-

cess mining focuses on the analysis of event data

and analysis results are often related to process mod-

els. Process mining is a rapidly growing subdiscipline

within both Business Process Management (BPM)

(Aalst, 2013a) and data science (Aalst, 2014). Main-

stream Business Intelligence (BI), data mining and

machine learning tools are not tailored towards the

analysis of event data and the improvement of pro-

cesses. Fortunately, there are dedicated process min-

ing tools able to transform event data into action-

able process-related insights. For example, ProM

(www.processmining.org) is an open-source pro-

cess mining tool supporting process discovery, con-

formance checking, social network analysis, organi-

zational mining, clustering, decision mining, predic-

tion, and recommendation (see Figure 6). Moreover,

in recent years, several vendors released commercial

process mining tools. Examples include: Celonis

Process Mining by Celonis GmbH (www.celonis.

de), Disco by Fluxicon (www.fluxicon.com), Inter-

stage Business Process Manager Analytics by Fu-

jitsu Ltd (www.fujitsu.com), Minit by Gradient

ECM (www.minitlabs.com), myInvenio by Cogni-

tive Technology (www.my-invenio.com), Perceptive

Process Mining by Lexmark (www.lexmark.com),

QPR ProcessAnalyzer by QPR (www.qpr.com), Ri-

alto Process by Exeura (www.exeura.eu), SNP Busi-

ness Process Analysis by SNP Schneider-Neureither

& Partner AG (www.snp-bpa.com), and PPM web-

Methods Process Performance Manager by Software

AG (www.softwareag.com).

data in a

variety of

systems

data used as

input for

analytics

information

systems,

devices, etc.

results

models

extract, load,

transform, clean,

anonymize, de-

identify, etc.

report, discover,

mine, learn, check,

predict, recommend, etc.

interaction with individuals

interpretation by analysts, managers, etc.

event data

(e.g., in XES

format)

data in databases,

files, logs, etc.

having a temporal

dimension

process models (e.g.,

BPMN, UML AD/SDs, Petri

nets, workflow models)

techniques for process discovery,

conformance checking, and

performance analysis

results include process models

annotated with frequencies,

times, and deviations

operational support,

e.g., predictions,

recommendations,

decisions, and alerts

people and devices

generating a

variety of events

Figure 5: The “process mining pipeline” relates observed and modeled behavior.

3.1.1 Creating and Managing Event Data

Process mining is impossible without proper event

logs (Aalst, 2011). An event log contains event data

related to a particular process. Each event in an event

log refers to one process instance, called case. Events

related to a case are ordered. Events can have at-

tributes. Examples of typical attribute names are ac-

tivity, time, costs, and resource. Not all events need

to have the same set of attributes. However, typically,

events referring to the same activity have the same set

of attributes. Figure 6(a) shows the conversion of an

CSV ﬁle with four columns (case, activity, resource,

and timestamp) into an event log.

Most process mining tools support XES (eXten-

sible Event Stream) (IEEE Task Force on Process

Mining, 2013). In September 2010, the format was

adopted by the IEEE Task Force on Process Mining

and became the de facto exchange format for pro-

cess mining. The IEEE Standards Organization is cur-

rently evaluating XES with the aim to turn XES into

an ofﬁcial IEEE standard.

To create event logs we need to extract, load,

transform, anonymize, and de-identify data in a va-

riety of systems (see Ì in Figure 5). Consider for

example the hundreds of tables in a typical HIS (Hos-

pital Information System) like ChipSoft, McKesson

and EPIC or in an ERP (Enterprise Resource Plan-

ning) system like SAP, Oracle, and Microsoft Dynam-

ics. Non-trivial mappings are needed to extract events

and to relate events to cases. Event data needs to be

scoped to focus on a particular process. Moreover, the

data also needs to be scoped with respect to conﬁden-

tiality issues.

3.1.2 Process Discovery

Process discovery is one of the most challenging pro-

cess mining tasks (Aalst, 2011). Based on an event

log, a process model is constructed thus capturing the

behavior seen in the log. Dozens of process discov-

ery algorithms are available. Figure 6(c) shows a pro-

cess model discovered using ProM’s inductive visual

miner (Leemans et al., 2015). Techniques use Petri

nets, WF-nets, C-nets, process trees, or transition sys-

tems as a representational bias (Aalst, 2016). These

results can always be converted to the desired nota-

tion, for example BPMN (Business Process Model

and Notation), YAWL, or UML activity diagrams.

3.1.3 Conformance Checking

Using conformance checking discrepancies between

the log and the model can be detected and quantiﬁed

by replaying the log (Aalst et al., 2012). For exam-

ple, Figure 6(c) shows an activity that was skipped

16 times. Some of the discrepancies found may ex-

pose undesirable deviations, i.e., conformance check-

ing signals the need for a better control of the process.

Other discrepancies may reveal desirable deviations

and can be used for better process support. Input for

conformance checking is a process model having ex-

ecutable semantics and an event log.

3.1.4 Performance Analysis

By replaying event logs on process model, we can

compute frequencies and waiting/service times. Us-

ing alignments (Aalst et al., 2012) we can relate cases

to paths in the model. Since events have timestamps,

case activity resource timestamp

each row

corresponds

to an event

each dot

corresponds

to an event

208 cases

time

process model

discovered for the most

frequent activities

conformance

checking view

performance

analysis view

activity was

skipped 16 times

average waiting

time is 18 days

queue length is

currently 22

(a) (b)

(c)

(d)

(e)

(f)

5987

events

tokens refer to

real cases

Figure 6: Six screenshots of ProM while analyzing an event log with 208 cases, 5987 events, and 74 different activities. First,

a CSV ﬁle is converted into an event log (a). Then, the event data can be explored using a dotted chart (b). A process model

is discovered for the 11 most frequent activities (c). The event log can be replayed on the discovered model. This is used to

show deviations (d), average waiting times (e), and queue lengths (f).

we can associate the times in-between events along

such a path to delays in the process model. If the

event log records both start and complete events for

activities, we can also monitor activity durations. Fig-

ure 6(d) shows an activity that has an average waiting

time of 18 days and 16 hours. Note that such bottle-

necks are discovered without any modeling.

3.1.5 Operational Support

Figure 6(e) shows the queue length at a particular

point in time. This illustrates that process mining can

be used in an online setting to provide operational

support. Process mining techniques exist to predict

the remaining ﬂow time for a case or the outcome of

a process. This requires the combination of a discov-

ered process model, historic event data, and informa-

tion about running cases. There are also techniques to

recommend the next step in a process, to check con-

formance at run-time, and to provide alerts when cer-

tain Service Level Agreements (SLAs) are violated.

3.2 Challenges in Process Mining

Table 1 maps the four generic challenges identiﬁed in

Section 2 onto the six key ingredients of process min-

ing brieﬂy introduced in Section 3.1. Note that both

cases (i.e., process instances) and the resources used

to execute activities may refer to individuals (cus-

tomers, citizens, patients, workers, etc.). Event data

are difﬁcult to fully anonymize. In larger processes,

most cases follow a unique path. In the event log

used in Figure 6, 198 of the 208 cases follow a unique

path (focusing only on the order of activities). Hence,

knowing the order of a few selected activities may

be used to de-anonymize or re-identify cases. The

same holds for (precise) timestamps. For the event

tiﬁed based on the day the registration activity (ﬁrst

activity in process) was executed. If one knows the

timestamps of these initial activities with the preci-

sion of an hour, then almost all cases can be uniquely

identiﬁed. This shows that the ordering and times-

tamp data in event logs may reveal conﬁdential infor-

mation unintentionally. Therefore, it is interesting to

investigate what can be done by adding noise (or other

transformations) to event data such that the analysis

results do not change too much. For example, we can

shift all timestamps such that all cases start in “week

0”. Most process discovery techniques will still re-

turn the same process model. Moreover, the average

ﬂow/waiting/service times are not affected by this.

Conformance checking (Aalst et al., 2012) can be

viewed as a classiﬁcation problem. What kind of

cases deviate at a particular point? Bottleneck analy-

sis can also be formulated as a classiﬁcation problem.

Which cases get delayed more than 5 days? We may

ﬁnd out that conformance or performance problems

are caused by characteristics of the case itself or the

people that worked on it. This allows us to discover

patterns such as:

• Doctor Jones often performs an operation without

making a scan and this results in more incidents

later in the process.

• Insurance claims from older customers often get

rejected because they are incomplete.

• Citizens that submit their tax declaration too late

often get rejected by teams having a higher work-

load.

Techniques for discrimination discovery can be used

to ﬁnd distinctions that are not desirable/acceptable.

Subsequently, techniques for discrimination preven-

tion can be used to avoid such situations. It is impor-

tant to note that discrimination is not just related to

static variables, but also relates to the way cases are

handled.

It is also interesting to use techniques from de-

composed process mining or streaming process min-

ing (see Chapter 12 in (Aalst, 2016)) to make process

mining “greener”.

For streaming process mining one cannot keep

track of all events and all cases due to memory con-

straints and the need to provide answers in real-time

(Burattin et al., 2014; Aalst, 2016; Zelst et al., 2015).

Hence, event data need to be stored in aggregated

form. Aging data structures, queues, time windows,

sampling, hashing, etc. can be used to keep only the

information necessary to instantly provide answers to

selected questions. Such approaches can also be used

to ensure conﬁdentiality, often without a signiﬁcant

loss of accuracy.

For decomposed/distributed process mining event

data need to be split based on a grouping activities in

the process (Aalst, 2013b; Aalst, 2016). After split-

ting the event log, it is still possible to discover pro-

cess models and to check conformance. Interestingly,

the sublogs can be analyzed separately. This may be

used to break potential harmful correlations. Rather

than storing complete cases, one can also store shorter

episodes of anonymized case fragments. Sometimes

it may even be sufﬁcient to store only direct succes-

sions, i.e., facts of the form “for some unknown case

activity a was followed by activity b with a delay of 8

hours”. Some discovery algorithms only use data on

direct successions and do not require additional, pos-

sibly sensitive, information. Of course certain ques-

tions can no longer be answered in a reliable manner

Table 1: Relating the four challenges to process mining speciﬁc tasks.

creating and

managing

event data

process

discovery

conformance

checking

performance

analysis

operational

support

fairness

Data Science with-

out prejudice: How to

avoid unfair conclusions

even if they are true?

The input data may

be biased, incomplete

or incorrect such

that the analysis

reconﬁrms prejudices.

By resampling or

relabeling the data,

undesirable forms of

discrimination can

be avoided. Note

that both cases and

resources (used to

execute activities)

may refer to individ-

uals having sensitive

attributes such as

race, gender, age, etc.

The discovered model

may abstract from

paths followed by cer-

tain under-represented

groups of cases.

Discrimination-aware

process-discovery

algorithms can be

used to avoid this. For

example, if cases are

handled differently

based on gender, we

may want to ensure

that both are equally

represented in the

model.

Conformance

checking can be

used to “blame”

individuals, groups,

or organizations for

deviating from some

normative model.

Discrimination-aware

conformance check-

ing (e.g., alignments)

needs to separate

(1) likelihood, (2)

severity and (3)

blame. Deviations

may need to be

interpreted differently

for different groups of

cases and resources.

Straightforward

performance measure-

ments may be unfair

for certain classes of

cases and resources

(e.g., not taking into

account the context).

Discrimination-aware

performance analysis

detects unfairness

and supports process

improvements taking

into account trade-

offs between internal

fairness (worker’s

perspective) and

external fairness (citi-

zen/patient/customer’s

perspective).

Process-related

predictions, rec-

ommendations

and decisions

may discriminate

(un)intentionally.

This problem can

be tackled using

techniques from

discrimination-aware

data mining.

conﬁdentiality

Data Science that

ensures conﬁdentiality:

How to answer questions

without revealing secrets?

Event data (e.g., XES

ﬁles) may reveal

sensitive information.

Anonymization and

de-identiﬁcation can

be used to avoid

disclosure. Note

that timestamps and

paths may be unique

and a source for

re-identiﬁcation (e.g.,

all paths are unique).

The discovered model

may reveal sensitive

information, espe-

cially with respect

to infrequent paths

or small event logs.

Drilling-down from

the model may need

to be blocked when

numbers get too small

(cf. k-anonymity).

Conformance check-

ing shows diagnostics

for deviating cases

and resources.

Access-control

is important and

diagnostics need to be

aggregated to avoid

revealing compliance

problems at the level

of individuals.

Performance analysis

shows bottlenecks and
