Native Cloud Applications

Why Virtual Machines, Images and Containers Miss the Point!

Frank Leymann, Christoph Fehling, Sebastian Wagner and Johannes Wettinger

Institute of Architecture of Application Systems, Universität Stuttgart, Universitätsstraße 38, Stuttgart, Germany

Keywords: Cloud Computing, Virtualization, Cloud Migration, Soa, Microservices, Continuous Delivery.

Abstract: Due to the current hype around cloud computing, the term “native cloud application” becomes increasingly

popular. It suggests an application to fully benefit from all the advantages of cloud computing. Many users

tend to consider their applications as cloud native if the application is just bundled in a virtual machine

image or a container. Even though virtualization is fundamental for implementing the cloud computing

paradigm, a virtualized application does not automatically cover all properties of a native cloud application.

In this work, we propose a definition of a native cloud application by specifying the set of characteristic

architectural properties, which a native cloud application has to provide. We demonstrate the importance of

these properties by introducing a typical scenario from current practice that moves an application to the

cloud. The identified properties and the scenario especially show why virtualization alone is insufficient to

build native cloud applications. Finally, we outline how native cloud applications respect the core principles

of service-oriented architectures, which are currently hyped a lot in the form of microservice architectures.

1 INTRODUCTION

Cloud service providers of the early days, such as

Amazon, started their Infrastructure as a Service

(IaaS) cloud business by enabling customers to run

virtual machines (VM) on their datacenter

infrastructure. Customers were able to create VM

images that bundled their application stack along

with an operating system and instantiate those

images as VMs. In numerous industry collaborations

we investigated the migration of existing

applications to the cloud and the development of

new cloud applications (Fehling et al., 2013; Fehling

et al., 2011; Brandic et al., 2010). In the investigated

use cases we found that virtualization alone is not

sufficient for fully taking advantage of the cloud

computing paradigm.

In this article we show that although

virtualization lays the groundwork for cloud

computing, additional alterations to the application’s

architecture are required to make up a “cloud native

application”. We discuss five essential architectural

properties we identified during our industry

collaborations that have to be implemented by a

native cloud application (Fehling et al., 2014).

Based on those properties we explain why an

application that was simply migrated to the cloud in

the form of a VM image does not comply with these

properties and how the application has to be adapted

to transform it into a native cloud application. These

properties have to be enabled in any application that

is built for the cloud. Note that we provide a

definition of native cloud applications by specifying

their properties; we do not aim to establish a

migration guide for moving applications to the

cloud. Guidelines and best practices on this topic can

be found in our previous work (Andrikopoulos et al.,

2013; Fehling et al., 2013).

Section 2 introduces a reference application that

reflects the core of the architectures of our industry

use cases. Based on the reference application,

Section 3 focuses on its transformation from a VM-

bundled to a native cloud application. We also

discuss why virtualization or containerization alone

is not sufficient to fully benefit from cloud

environments. Therefore, a set of architectural

properties are introduced, which a native cloud

application has to implement. Section 4 discusses

how native cloud applications are related to

microservice architectures, SOA, and continuous

delivery. Furthermore, Section 5 discusses how the

reference application itself can be offered as a cloud

service. Finally, Section 6 concludes the article.

Leymann F., Wagner S., Fehling C. and Wettinger J.

Native Cloud Applications - Why Virtual Machines, Images and Containers Miss the Point!.

DOI: 10.5220/0006811300010001

In Proceedings of the 6th International Conference on Cloud Computing and Services Science (CLOSER 2016), pages 7-15

ISBN: 978-989-758-182-3

2 REFERENCE APPLICATION

Throughout the article, the application shown in

Figure 1 is used as running example for transforming

an existing application into a cloud native

application. It offers functionality for accounting,

marketing, and other business concerns. The

architecture specification of this application and the

following transformation uses the concept of layers

and tiers (Fowler, 2002): the functionality of an

application is provided by separate components that

are associated with logical layers. Application

components may only interact with other

components on the same layer or one layer below.

Logical layers are later assigned to physical tiers for

application provisioning. In our case, these tiers are

constituted by VMs, which may be hosted by a

cloud provider.

Presentation

Layer

Web Server

Account

Management

(EJBs)

Account DBMS

GUI Rendering

(Browser)

Marketing

Campaigns

(Assemblies)

…

Marketing CMS … DBMS

Account DB Marketing DB … DB

JEE Server .Net App Server … App Server

GUI Handling

(Servlets)

Data Access

Layer

Business Logic

Layer

Figure 1: Reference Application to be Moved to the

Cloud.

The reference application is comprised of three

layers. Each layer has been built on different

technology stacks. The accounting functions are

implemented as Enterprise Java Beans

(EJB) on a

Java Enterprise Edition (JEE) server making use of a

Database Management Systems (DBMS); the

marketing functions are built in a .Net environment

using a Content Management System (CMS). All

application functions are integrated into a graphical

https://jcp.org/aboutJava/communityprocess/final/jsr318

http://www.microsoft.com/net

user interface (GUI), which is realized by servlets

hosted on a Web server.

The servlet, EJB and .Net components are

stateless. In this scope, we differentiate: (i) session

state – information about the interaction of users

with the application. This data is provided with each

request to the application and (ii) application state –

data handled by the application, such as a customer

account, billing address, etc. This data is persisted in

the databases.

3 TRANSFORMING THE

REFERENCE APPLICATION

TO A CLOUD NATIVE

APPLICATION

When moving the reference application to a cloud

environment, the generic properties of this

environment can be used to deduct required cloud

application properties. The properties of the cloud

environment have been defined by the NIST (2011):

On-demand self-service – the cloud customer can

independently sign up to the service and configure it

to his demands. Broad network access – the cloud is

connected to the customer network via a high-speed

network. Resource pooling – resources required to

provide the cloud service are shared among

customers. Rapid elasticity – resources can be

dynamically assigned to customers to handle

currently occurring workload. Measured service –

the use of the cloud by customers is monitored,

often, to enable pay-per-use billing models.

To make an application suitable for such a cloud

environment, i.e. to utilize the NIST properties, we

identified the IDEAL cloud application properties

(Fehling et al., 2014): Isolation of state,

Distribution, Elasticity, Automated Management

and Loose coupling. In this section, we discuss why

VM-based application virtualization and

containerization alone is rather obstructive for

realizing them. Based on this discussion, the steps

for enabling these properties are described in order

to transform a VM-based application towards a

native cloud application. As we start our discussion

on the level of VMs, we first focus on the

Infrastructure as a Service (IaaS) service model.

Then we show how it can be extended to use

Platform as a Service (PaaS) offerings of a cloud

provider.

3.1 Complete Application per Virtual

Machine

To provide an application to customers within a

cloud environment as quickly as possible,

enterprises typically bundle their application into a

single virtual machine image (VMI)

. Such VMIs

are usually self-contained and include all

components necessary for running the application.

Considering the reference application, the data

access layer, the business logic layer, and the

presentation layer would be included in that VMI.

Figure 2 shows an overview of that package.

Virtual Machine

Web Server

Account

Management

(EJBs)

Account DBMS

Marketing

Campaigns

(Assemblies)

…

Marketing CMS … DBMS

Account DB Marketing DB … DB

JEE Server .Net App Server … App Server

GUI Handling

(Servlets)

GUI Rendering

(Browser)

GUI Rendering

(Browser)

GUI Rendering

(Browser)

GUI Rendering

(Browser)

Figure 2: Packaging the Application into one VM.

Customers now start using the application

through their Web browsers. As shown in Figure 2,

all requests are handled by the same VM.

Consequently, the more customers are using the

application, the more resources are required. At

some point in time, considering an increasing

amount of customer requests, the available resources

will not be able to serve all customer requests any

more. Thus, the application needs to be scaled in

order to serve all customers adequately.

The first approach to achieve scalability is to

instantiate another VM containing a copy of your

application stack as shown in Figure 3. This allows

you to serve more customers without running into

From here on we do not mention containerization

explicitly by considering them as similar to virtual

machine images – well recognizing the differences. But

for the purpose of our discussion they are very similar.

any bottleneck. However, the operation of multiple

VMs also has significant downsides. You typically

have to pay for licenses, e.g. for the database server,

the application server, and the content management

system, on a per VM basis. If customers use the

account management features mostly, why should

you also replicate the marketing campaigns stack

and pay for the corresponding licenses? Next, what

about your databases that are getting out of sync

because separate databases are maintained in each of

the VMs? This may happen because storage is

associated to a single VM but updates need to be

synchronized across those VM to result in consistent

data.

Therefore, it should be possible to scale the

application at a finer granular, to ensure that its

individual functions can be scaled independently

instead of scaling the application as a whole. This

can be achieved by following the distribution

property in the application architecture. This property

requires the application functionality to be distributed

among different components to exploit the measured

service property and the associated pay-per-use

pricing models more efficiently. Due to its

modularized architecture comprising of logical layers

and components, the distribution property is met by

the reference application. However, by summarizing

the components into one single VM, i.e. in one tier,

the modularized architecture of the application gets

lost.

Moreover, this leads to the violation of the

isolated state property, which is relevant for the

application to benefit from the resource pooling and

elasticity property. This property demands that

session and application state must be confined to a

small set of well-known stateful components, ideally,

the storage offerings and communication offerings of

the cloud providers. It ensures that stateless

components can be scaled more easily, as during the

addition and removal of application component

instances, no state information has to be

synchronized or migrated, respectively.

Another IDEAL property that is just partly

supported in case the application is bundled as a

single VM is the elasticity property. The property

requires that instances of application components can

be added and removed flexibly and quickly in order

to adjust the performance to the currently

experienced workload. If the load on the components

increases, new resources are provisioned to handle

the increased load. If, in turn, the load on the

resources decreases, under-utilized components are

decommissioned. This scaling out (increasing the

number of resources to adapt to workload) as

opposed to scaling up (increasing the capabilities of a

single cloud resource) is predominantly used by

cloud applications as it is also required to react to

component failures by replacing failed components

with fresh ones. Since the distribution is lost, scaling

up the application by assigning more resources to the

VM (e.g. CPU, memory, etc.) is fully supported, but

not scaling out individual components. Hence, the

elasticity property is just partly met if the application

is bundled as a single VM. The incomplete support of

the elasticity property also hinders the full

exploitation of the cloud resource pooling property,

as the elasticity property enables unused application

resources to be decommissioned and returned to the

resource pool of the cloud if they are not needed

anymore. These resources can then be used by other

customers or applications.

VM1

VM2

VM3

Figure 3: Scaling based on complete Virtual Machines.

3.2 Stack-based Virtual Machines with

Storage Offerings

Because of the drawbacks of a single VM image

containing the complete application, a suitable next

step is to extract the different application stacks to

separate virtual machines. Moreover, data can be

externalized to storage offerings in the cloud (“Data

as a Service”), which are often associated to the IaaS

service model. Such services are used similar to hard

drives by the VMs, but they are stored in a provider-

managed scalable storage offering. Especially the

stored data can be shared among multiple VMs when

they are being scaled out, thus, avoiding the

consistency problems indicated before and hence

fostering the isolated state property. Figure 4 shows

the resulting deployment topology of the application,

where each stack and the Web GUI is placed into a

different virtual machine that accesses a Data as a

Service cloud offering.

When a particular stack is under high request

load, it can be scaled out by starting multiple

instances of the corresponding VM. For example, in

Figure 5 another VM instance of the accounting stack

is created to handle higher load. However, when

another instance of a VM is created the DBMS is still

replicated which results in increased license costs.

Data as a Service (Aspect of IaaS)

Web Server

Account

Management

(EJBs)

Account DBMS

GUI Rendering

(Browser)

Marketing

Campaigns

(Assemblies)

…

Marketing CMS … DBMS

Account DB Marketing DB … DB

JEE Server .Net App Server … App Server

GUI Handling

(Servlets)

GUI Rendering

(Browser)

GUI Rendering

(Browser)

GUI Rendering

(Browser)

Figure 4: Packaging Stacks into VMs.

Data as a Service (Aspect of IaaS)

Web Server

Account

Management

(EJBs)

Account DBMS

GUI Rendering

(Browser)

Marketing

Campaigns

(Assemblies)

…

Marketing CMS … DBMS

Account DB Marketing DB … DB

JEE Server .Net App Server … App Server

GUI Handling

(Servlets)

GUI Rendering

(Browser)

GUI Rendering

(Browser)

GUI Rendering

(Browser)

Account

Management

(EJBs)

Account DBMS

JEE Server

VM Scale Out

Figure 5: Packaging Stacks into VMs.

3.3 Using Middleware Virtual

Machines for Scaling

The replication of middleware components such as a

DBMS can be avoided by placing these components

again into separate VMs that can be scaled out

independently from the rest of the application stack

on demand. The middleware component is then able

to serve multiple other components. In case of the

reference application the DBMS associated with the

account management is moved to a new VM (Figure

6), which can be accessed by different instances of

the JEE Server. Of course, also the JEE server or the

.Net server could be moved into separate VMs. By

doing so, the distribution property is increased and

elasticity can be realized at a finer granular.

Data as a Service (Aspect of IaaS)

Web Server

Account

Management

(EJBs)

Account DBMS

GUI Rendering

(Browser)

Marketing

Campaigns

(Assemblies)

…

Marketing CMS … DBMS

Account DB Marketing DB … DB

JEE Server .Net App Server … App Server

GUI Handling

(Servlets)

GUI Rendering

(Browser)

GUI Rendering

(Browser)

GUI Rendering

(Browser)

Account

Management

(EJBs)

JEE Server

Figure 6: Middleware-VMs for Scaling.

Even though the single components are now able to

scale independently from each other, the problem of

updating the application components and especially

the middleware installed on VMs still remains.

Especially, in large applications involving a variety

of heterogeneous interdependent components this can

become a very time- and resource-intensive task. For

example, a new release of the JEE application server

may also require your DBMS to be updated. But the

new versions of the DBMS may not be compatible

with the utilized .Net application server. This, in turn,

makes it necessary to run two different versions of

the same DBMS. However, this violates an aspect of

the automated management property demanding that

required human interactions to handle management

tasks are reduced as much as possible in order to

increase the availability and reactiveness of the

application.

3.4 Resolving Maintenance Problems

To reduce management efforts, we can substitute

components and middleware with IaaS, PaaS, or

SaaS offerings from cloud providers. In Figure 7, the

VMs providing the Web server and application

server middleware are replaced with corresponding

PaaS offerings. Now, it is the cloud provider’s

responsibility to keep the components updated and to

rollout new releases that contain the latest fixes, e.g.

to avoid security vulnerabilities.

In case of the reference application, most

components can be replaced by cloud offerings. The

first step already replaced physical machines, hosting

the application components with VMs that may be

hosted on IaaS cloud environments. Instead of

application servers, one may use PaaS offerings to

host the application components of the business logic

layer. The DBMS could be substituted by PaaS

offerings such as Amazon SimpleDB; marketing

campaign .Net assemblies could be hosted on

Microsoft Azure, as an example.

Data as a Service (Aspect of IaaS)

Account

Management

(EJBs)

GUI Rendering

(Browser)

Marketing

Campaigns

(Assemblies)

…

Marketing CMS

… DBMS

Marketing DB … DB

.Net App Server

GUI Handling

(Servlets)

GUI Rendering

(Browser)

GUI Rendering

(Browser)

GUI Rendering

(Browser)

Account

Management

(EJBs)

Account DBMS

Account DB

PaaS – Web Server

PaaS – App Server

PaaS – JEE App Server

Figure 7: Making Use of Cloud Resources and Features.

To offload the management (and even

development) of your .Net assemblies one could even

decide to substitute the whole marketing stack by a

SaaS offering that provides the required marketing

functionality. In this case, the Web GUI is integrated

with the SaaS offering by using the APIs provided by

the offering.

Of course, before replacing a component with an

*aaS offering, it should be carefully considered how

the dependent components are affected

(Andrikopoulos et al., 2013): adjustments to

components may be required to respect the runtime

environment and APIs of the used *aaS offering.

3.5 The Final Steps Towards a Cloud

Native Application

The reference application is now decomposed into

multiple VMs that can be scaled individually to

fulfill the distribution and elasticity property.

Isolation of state has been enabled by relying on

cloud provider storage offerings. The software update

management has been addressed partially.

However, the addition and removal of virtual

machine instances can still be hindered by

dependencies among application components: if a

VM is decommissioned while an application

component hosted on it interacts with another

component, errors may occur. The dependencies

between application components meaning the

assumptions that communicating components make

about each other can be reduced by following the

loose coupling property. This property is

implemented by using cloud communication

offerings enabling asynchronous communication

between components through a messaging

intermediate as shown in Figure 8. This separation of

concerns ensures that communication complexity

regarding routing, data formats, communication

speed etc. is handled in the messaging middleware

and not in components, effectively reducing the

dependencies among communication partners. Now,

the application can scale individual components

easier as components do not have to be notified in

case other components are provisioned and

decommissioned.

To make elastic scaling more efficient, it should

be automated. Thus, again the automated

management property is respected. This enables the

application to add and remove resources without

human intervention. It can cope with failures more

quickly and exploits pay-per-use pricing schemes

more efficiently: resources that are no longer needed

should be automatically decommissioned.

Consequently, the resource demand has to be

constantly monitored and corresponding actions have

to be triggered without human interactions. This is

done by a separate watchdog component (Ornstein et

al., 1975; Fowler, 2002) and elasticity management

components (Freemantle, 2010). After this step, the

reference application became cloud native, thus,

supporting the IDEAL cloud application properties:

Isolation of state, Distribution, Elasticity,

Automated Management and Loose coupling

(Fehling et al., 2014).

In terms of virtualization techniques and

technologies, fully fledged VMs with their dedicated

guest operation system could also be replaced by

more lightweight virtualization approaches such as

containers, which recently became popular with

Docker (Mouat, 2015). However, such approaches

may not provide the same degree of isolation, so

depending on the specific requirements of an

application, the one or the other virtualization

approach fits better.

Data as a Service (Aspect of IaaS)

Account

Management

(EJBs)

GUI Rendering

(Browser)

Marketing

Campaigns

(Assemblies)

…

Marketing CMS

… DBMS

Marketing DB … DB

.Net App Server

GUI Handling

(Servlets)

GUI Rendering

(Browser)

GUI Rendering

(Browser)

GUI Rendering

(Browser)

Account

Management

(EJBs)

Account DBMS

Account DB

PaaS – Web Server

PaaS – App Server

PaaS – JEE App Server

Queing

PaaS – Messaging Middleware

Figure 8: Making use of Cloud Communication Features.

4 MICROSERVICES &

CONTINUOUS DELIVERY

Microservice architectures provide an emerging

software architecture style, which is currently

discussed and hyped a lot. While there is no clear

definition of what a microservice actually is, some

common characteristics have been established

(Fowler, 2016; Newman, 2015). Microservice

architectures are contrary to monolithic

architectures. Consequently, a specific application

such as a Web application (e.g. the reference

application presented in this paper) or a back-end

system for mobile apps is not developed and

maintained as a huge single building block, but as a

set of 'small' and independent services, i.e.

microservices. As of today, there is no common

sense how 'small' a microservice should be. To make

them meaningful, these services are typically built

around business capabilities such as account

management and marketing campaigns as outlined

by the reference application. Their independence is

implemented by running each service in its own

process or container (Mouat, 2015). This is a key

difference to other component-based architecture

styles, where the entire application shares a process,

but is internally modularized, for instance, using

Java libraries.

The higher degree of independence in case of

microservices enables them to be independently

deployable from each other, i.e. specific parts of an

application can be updated and redeployed without

touching other parts. For non-trivial and more

complex applications, the number of services

involved quickly increases. Consequently, manual

deployment processes definitely do not scale

anymore for such architectures, because deployment

happens much more often and independently.

Therefore, fully automated deployment machinery

such as continuous delivery pipelines are required

(Humble and Farley, 2015).

As a side effect of the services' independence,

the underlying technologies and utilized

programming languages can be extremely diverse.

While one service may be implemented using Java

EE, another one could be implemented using .Net,

Ruby, or Node.js. This enables the usage of 'the best

tool for the job', because different technology stacks

and programming languages are optimized for

different sets of problems. The interface, however,

which is exposed by a particular service must be

technology-agnostic, e.g. based on REST over

HTTP, so different services can be integrated

without considering their specific implementation

details. Consequently, the underlying storage

technologies can also differ, because 'decentralized

data management' (Fowler, 2016) is another core

principle of microservice architectures. As outlined

by the reference application, each service has its

own data storage, so the data storage technology

(relational, key-value, document-oriented, graph-

based, etc.) can be chosen according to the specific

storage requirements of a particular service

implementation.

In addition, microservice architectures follow the

principle of 'smart endpoints and dumb pipes'

(Fowler, 2016), implying the usage of lightweight

and minimal middleware components such as

messaging systems ('dumb pipes'), while moving the

intelligence to the services themselves ('smart

endpoints'). This is confirmed by reports and surveys

such as carried out by Schermann et al.: REST in

conjunction with HTTP as transport protocol is used

by many companies today. JSON and XML are both

common data exchange formats. There is a trend to

minimize the usage of complex middleware towards

a more choreography-style coordination of services

(Schermann et al., 2015). Finally, the architectural

paradigm of self-contained systems (SCS, 2016) can

help to treat an application, which is made of a set of

microservices, in a self-contained manner.

In this context, an important fact needs to be

emphasized: most of the core principles of

microservice architectures are not new at all.

Service-oriented architectures (SOA) are established

in practice for some time already, sharing many of

the previously discussed core principles with

microservice architectures. Thus, we see

microservice architectures as one possible

opinionated approach to realize SOA, while making

each service independently deployable. This idea of

establishing independently deployable units is a

focus of microservice architectures, which was not

explicitly a core principle in most SOA-related

works and efforts. Therefore, continuous delivery

(Humble and Farley, 2015) can now be implemented

individually per service to completely decouple their

deployment.

Our previously presented approach to transition

the references application's architecture towards a

native cloud application is based on applying the

IDEAL properties. The resulting architecture owns

the previously discussed characteristics of

microservice architectures and SOA. Each part of

the reference application (account management,

marketing campaigns, etc.) now represents an

independently (re-)deployable unit. Consequently, if

an existing application is transitioned towards a

native cloud application architecture by applying the

IDEAL properties, the result typically is a

microservice architecture. To go even further and

also consider development as part of the entire

DevOps lifecycle, a separate continuous delivery

pipeline (Humble and Farley, 2015) can be

implemented for each service to perform their

automated deployment when a bug fix or new

feature is committed by a developer. Such pipelines

combined with Cloud-based development

environments such as Cloud9 (Cloud9, 2016) also

make the associated application development

processes cloud-native in addition to deploying and

running the application in a cloud-native way.

5 MOVING TOWARDS A SAAS

APPLICATION

While the IDEAL properties enable an application to

benefit from cloud environments and (micro)service-

oriented architectures, additional properties have to

be considered in case the application shall be offered

as a Service to a large number of customers

(Freemantle, 2010; Badger et al., 2011): Such

applications should own the properties clusterability,

elasticity, multi-tenancy, pay-per-use and self-

service. Clusterability summarizes the above-

mentioned isolation of state, distribution, and loose

coupling. The elasticity discussed by Freemantle and

Badger et al. is identical to the elasticity mentioned

above. The remaining properties have to be enabled

in an application-specific manner as follows.

5.1 Multi-tenancy

The application should be able to support multiple

tenants, i.e. defined groups of users, where each

group is isolated from the others. Multi-tenancy does

not mean isolation by associating each tenant with a

separate copy of the application stack in one or more

dedicated VMs. Instead, the application is adapted to

have a notion of tenants to ensure isolation. The

application could also exploit multi-tenant aware

middleware (Azeez et al., 2010) as this type of

middleware is able to assign tenant requests to the

corresponding instance of a component.

In scope of the reference application, the

decomposition of the application into loosely coupled

components enables the identification of components

that can easily be shared among multiple tenants.

Other components, which are more critical, for

example, those sharing customer data likely have to

be adjusted in order to ensure tenant isolation. In

previous work, we discussed how such shared

components and tenant-isolated components may be

implemented (Fehling et al., 2014). Whether an

application component may be shared among

customers or not may also affect the distribution of

application components to VMs.

5.2 Pay-per-Use

Pay-per-use is a property that fundamentally

distinguishes cloud applications from applications

hosted in traditional datacenters. It ensures that

tenants do only pay when they are actually using an

application function, but not for the provisioning or

reservation of application resources. Pay-per-use is

enabled by fine-grained metering and billing of the

components of an application stack. Consequently,

the actual usage of each individual component within

the application stack must be able to be monitored,

tracked, and metered. Depending on the metered

amount of resource usage, the tenant is billed. What

kind of resources are metered and billed depends on

the specific application and the underlying business

model. Monitoring and metering can also be

supported by the underlying middleware if it is

capable to relate the requests made to the application

components with concrete tenants.

In scope of the reference application, sharing

application component instances ensures that the

overall workload experienced by all instances is

leveled out as workload peaks of one customer

happen at the same time where another customer

experiences a workload low. This sharing, thus,

enables flexible pricing models, i.e. charging on a

per-access basis rather than on a monthly basis. For

instance, the reference application may meter and bill

a tenant for the number of marketing campaigns he

persists in the CMS. Other applications may meter a

tenant based on the number requests or the number of

CPUs he is using. Amazon, for instance, provides a

highly sophisticated billing model for their EC2

instances (Amazon, 2016).

5.3 Self-service

The application has to ensure that each tenant can

provision and manage his subscription to the

application on his own, whenever he decides to do

so. Especially, no separate administrative staff is

needed for provisioning, configuring, and managing

the application. Self-service capability applies to

each component of the application (including

platform, infrastructure, etc.). Otherwise, there would

not be real improvements in time-to-market. The

self-service functionality can be provided by user

interfaces, command line interfaces, and APIs to

facilitate the automated management of the cloud

application (Freemantle, 2010).

In scope of the reference application, automated

provisioning and decommissioning of application

component instances is enabled by the used cloud

environment. Therefore, customers may be

empowered to sign up and adjust subscriptions to the

cloud-native application in a self-service manner, as

no human management tasks are required on the

application provider side anymore.

6 SUMMARY

Based on the IDEAL cloud application properties we

have shown how an existing application can be

transformed to a cloud native application. Moreover,

we discussed the relation of cloud native application

to (micro)service-oriented architectures and

continuous delivery. Additional properties defined by

Freemantle and Badger et al. – multi-tenancy, pay-

per-use, and self-service – enabling a cloud-native

application to be offered as a Service requiring

significant adjustments of the application

functionality. Multi-tenancy commonly requires

adaptation of application interfaces and storage

structures to ensure the isolation of tenants.

Functionality to support pay-per-use billing and self-

service commonly has to be newly created with

application-specific knowledge.

Based on the transformation of the reference

application we have shown that virtualization is a

mandatory prerequisite for building a native cloud

application, but just virtualizing an application does

not satisfy all cloud application properties. Hence, it

is insufficient to simply move an application into a

VM and call it a cloud native application.

REFERENCES

Freemantle, P., 2010. Cloud Native. http://

pzf.fremantle.org/2010/05/cloud-native.html

Fehling, C., Leymann F., Retter, R., Schupeck, W.,

Arbitter, P., 2014. Cloud Computing Patterns:

Fundamentals to Design, Build, and Manage Cloud

Applications. Springer.

Moore, G., 2011. Systems of Engagement and The Future

of Enterprise IT A Sea Change in Enterprise IT. Aim.

white paper.

Mell, P., Grace, T., 2011. The NIST Definition of Cloud

Computing. National Institute of Standards and

Technology NIST, Gaithersburg, MD.

Badger, L., Grance, T., Patt-Corner, P., Voas, J., 2011.

DRAFT: Cloud Computing Synopsis and

Recommendation, NIST. http://csrc.nist.gov/

publications/drafts/800-146/Draft-NIST-SP800-

146.pdf

Ornstein, S. M., Crowther W. R., Kraley, M. F., Bressler,

R. D., Michel, A., Heart, F. E., 1975. Pluribus: a

reliable multiprocessor. In Proceedings of the 1975

American Federation of Information Processing

Societies National Computer Conference (AFIPS).

Fowler, M., 2002. Patterns of Enterprise Application

Architecture. Addison-Wesley Longman Publishing

Co., Inc., Boston, MA, USA.

Azeez, A., Perera, S., Gamage, D., Linton, R.,

Siriwardana, P., Leelaratne, D., Weerawarana, S.,

Fremantle, P., 2010. Multi-tenant SOA Middleware for

Cloud Computing. In Proceedings of the 2010 IEEE

International Conference on Cloud Computing

(CLOUD).

Andrikopoulos, V., Binz, T., Leymann, F., Strauch, S.,

2013. How to Adapt Applications for the Cloud

Environment Challenges and Solutions in Migrating

Applications to the Cloud. In Computing. Vol. 95(6),

Springer.

Andrikopoulos, V., Song, Z., Leymann, F., 2013.

Supporting the Migration of Applications to the Cloud

through a Decision Support System. In Proceedings of

the 6th IEEE International Conference on Cloud

Computing (CLOUD).

Fehling, C., Leymann, F., Ruehl, S. T., Rudek, M.,

Verclas, S., 2013. Service Migration Patterns -

Decision Support and Best Practices for the Migration

of Existing Service-based Applications to Cloud

Environments. In Proceedings of the 6th IEEE

International Conference on Service Oriented

Computing and Applications (SOCA).

Fehling, C., Konrad, R., Leymann, F., Mietzner, R., Pauly,

M., Schumm, D., 2011. Flexible Process-based

Applications in Hybrid Clouds. In Proceedings of the

2011 IEEE International Conference on Cloud

Computing (CLOUD).

Brandic, I., Anstett, T., Schumm, D., Leymann, F.,

Dustdar, S., Konrad, R., 2010. Compliant Cloud

Computing (C3): Architecture and Language Support

for User-driven Compliance Management in Clouds.

In Proceedings of the 3rd International Conference on

Cloud Computing (Cloud).

Amazon, 2016. Amazon Elastic Compute Cloud (EC2)

Pricing. http://aws.amazon.com/ec2/pricing

Fowler, M., 2016. Microservices Resource Guide. http://

martinfowler.com/microservices

Newman, S., 2015. Building Microservices. O'Reilly

Media.

Humble, J., Farley, D., 2010. Continuous Delivery.

Addison-Wesley Professional.

Mouat, A., 2015. Using Docker. O'Reilly Media.

Schermann, G.; Cito, J., Leitner, P., 2015. All the services

large and micro: Revisiting industrial practices in

services computing. PeerJ.

SCS, 2016. Self-contained System (SCS) – Assembling

Software from Independent Systems. http://

scs-architecture.org

Cloud9 IDE, Inc., 2016. Cloud9 website. https://c9.io

All links were last followed on 9

of February, 2016.
