Rest in Protection

A Kernel-level Approach to Mitigate RIP Tampering

Vincent Haupert and Tilo Müller

Department of Computer Science, Friedrich-Alexander University Erlangen-Nürnberg (FAU),

Martensstraße 3, Erlangen, Germany

{vincent.haupert, tilo.mueller}@cs.fau.de

Keywords:

RIP Protection, ROP Prevention, Instruction-level Monitoring, Linux Kernel.

Abstract:

We present RIProtection (Rest In Protection), a novel Linux kernel-based approach that mitigates the tamper-

ing of return instruction pointers. RIProtection uses single stepping on branches for instruction-level monitor-

ing to guarantee the integrity of the ret-based control-ﬂow of user-mode programs. Our modular design of

RIProtection allows an easy adoption of several security approaches relying on instruction-level monitoring.

For this paper, we implemented two exclusive approaches to protect RIPs: XOR-based encryption as well as

a shadow stack. Both approaches provide reliable protection of RIPs, while the shadow stack additionally

prevents return-oriented programming and withstands information leakages of the user-mode stack. While

the performance of RIProtection is a severe drawback, its compatibility with regard to hardware and software

requirements is outstanding because it supports virtually all 64-bit programs without recompilation or binary

rewriting.

1 INTRODUCTION

Numerous exploit techniques for memory-safety vul-

nerabilities are known and have been widely applied

for years. Exploiting these mistakes was easy from

the beginning but many of the approaches available

today limit or even prevent the damage. The most

widely applied safeguards in use at present are Ad-

dress Space Layout Randomization (ASLR), which

randomizes the base address of segments, the No eX-

ecute (NX) bit, which marks a page as either ex-

ecutable or not, and stack canaries, which place a

unique random value in front of the RIP. All three

countermeasures signiﬁcantly increase the effort an

attacker needs to undertake, especially if ASLR, NX

and canaries are combined.

When it comes to creating exploits that subvert a

great number of countermeasures, however, return-

oriented programming (ROP) (Shacham, 2007) has

become the method of choice. ROP can circumvent

NX because it uses chained addresses (so-called gad-

gets) of segments that do not have the NX bit set. All

these gadgets eventually execute a ret. ASLR can

be subverted by the prior exploitation of an informa-

tion leakage vulnerability (Sotirov and Dowd, 2008).

If the latter is the case, canaries can be trivially dis-

abled, too (Bulba and Kil3r, 2000). Especially ROP

distorts the original intent of a ret because it does

not read an address that was previously written by its

corresponding call.

1.1 Contributions

Our work yields the following contributions:

(a) We propose RIProtection, a novel kernel-based

protection mechanism that uses single steps on

branches to synchronously monitor any branch in-

struction. RIProtection currently only monitors

call and ret instructions but is able to monitor

any branch. Our approach is developed to run

on commodity hardware and facilitates the branch

trap ﬂag and the last branch record of the Intel x86

CPU. Both features have been available for years

now and, therefore, allow high compatibility.

(b) Different types of security models are supported

on a per-process basis. This work presents two

approaches: One relying on the XOR encryption

of return addresses, the other using a shadow stack

to provide enhanced security.

can safely prevent RIP tampering as well as ROP

and information leakage attacks in the shadow

stack operation mode. Furthermore, our empiric

evaluation of the shadow stack security module

proves that all ret-based attacks are prevented

Haupert, V. and Müller, T.

Rest in Protection - A Kernel-level Approach to Mitigate RIP Tampering.

DOI: 10.5220/0006083800250037

In Proceedings of the 3rd International Conference on Information Systems Security and Privacy (ICISSP 2017), pages 25-37

ISBN: 978-989-758-209-7

CFIMon

ROPecker

RIProtection

ILR

STIR

IPCR

ROPGuard

CCFIR

StackGuard

Pointguard

G-Free

CFLocking

Compile Time Binary Instrumentation

Kernel-/Hardware-based

ROPDefender

Binary rewriting

kBouncer

control-ﬂow integrity

gadget-oriented

RIP-protective

DROP

Figure 1: The Landscape of Related Work: Each circle represents the technical approach that a defense mechanism uses.

While the compiler, binary rewriting and instrumentation are rather precise and self-explanatory, the kernel- and hardware-

aided category is more generalized and sums up techniques that try to facilitate hardware features. Additionally, the circles

are subdivided to illustrate the concept that an approach is using. They might aim to assert control-ﬂow integrity, concentrate

to eliminate gadgets, focus on protecting the RIP or use multiple concepts.

and an effective gain in security is achieved. Ad-

ditionally, we evaluated performance and com-

patibility. While run-time performance is a big

issue, RIProtection has high compatibility with

any x86_64 legacy binary without requiring any

side information, source code, binary rewriting or

user-level binary instrumentation.

1.2 Outline

The outline of this paper is as follows. Section 2

covers related work on exploit mitigation that uses

compile-time approaches, binary rewriting, binary in-

strumentation or a kernel-based approach. Section 3

describes the design and implementation of RIProtec-

tion. Section 4 is dedicated to the evaluation of RIPro-

tection in terms of security, performance and compat-

ibility. Finally, Section 5 provides a conclusion and

possibilities for future work.

2 LANDSCAPE OF RELATED

WORK

All defense techniques presented in this section can

be categorized to some extent to use compiler-based

solutions, binary rewriting, instrumentation or a hard-

ware-aided kernel-level approach as a technical strat-

egy. In addition to these techniques, they have a con-

cept that may enforce control-ﬂow integrity, has the

goal of making ROP gadgets unavailable to an at-

tacker or focuses on mitigation of the RIP. In con-

trast to all related work, RIProtection operates only in

kernel-mode without modiﬁcation of hardware or user

mode software. 1 illustrates the landscape of the dif-

ferent technical approaches described in the following

sections.

2.1 Compile-time Approaches

This section is dedicated to compiler-level extensions

that aim to improve the security of programs by stat-

ically adding security logic to the source code. Many

works use this approach as it is rather convenient to

add checks for improved security. However, a natural

feature of all these approaches is that they need the

source code to be available.

StackGuard (Cowan et al., 1998) is a patch

for the GCC compiler that is available using the

-fstack-protector option. It inserts a random

cookie (also called canary) in front of the RIP that

is checked during a function’s epilogue. StackGuard

is a potent mitigation technique that signiﬁcantly in-

creases the effort that an attacker needs to take and

introduces only a slight performance overhead. Espe-

ICISSP 2017 - 3rd International Conference on Information Systems Security and Privacy

cially the fact that only one secret is used for the en-

tire process, however, renders canaries vulnerable to

information leakage attacks (Bulba and Kil3r, 2000).

Pointguard (Cowan et al., 2003) is yet another

patch for the GCC that encrypts any pointers and de-

crypts them only if they are about to get loaded into a

CPU register. It uses XORencryption with a key that

is acquired at program start using /dev/urandom. In

general, Pointguard can provide security not only for

the RIP but for every pointer in the program. Yet, it

uses only one secret for the entire process and, conse-

quently, becomes especially vulnerable against infor-

mation leakage attacks.

An approach that wants to eliminate useful gad-

gets is G-Free (Onarlioglu et al., 2010). To achieve

this, two techniques are used. First, any unintended

code sequences are transformed that could be read as

ret or jmp. To prevent the usage of these instructions

created by the compiler, G-Free additionally enforces

control-ﬂow integrity by ensuring that a function is

called only from its entry point. The fact that G-Free

ﬁrst removes unaligned gadgets and later adds code

that is required for its approach may introduce new

gadgets (Cheng et al., 2014). Furthermore, the pol-

icy to only allow functions to be called from their en-

try point cannot always prevent ROP attacks (Gökta¸s

et al., 2014).

Another compiler extension that uses control-ﬂow

integrity in conjunction with the elimination of unin-

tended gadgets is CFLocking (Bletsch et al., 2011).

First, non-intended gadgets are eliminated. To ac-

count for the name of the tool, a lock that is immedi-

ately unlocked when the control ﬂow is transferred to

a legal target in the control-ﬂow graph is introduced.

If a branch occurs, the lock is checked again and if it

is still locked, the program is terminated. In general,

CFLocking suffers from similar drawbacks as G-Free.

2.2 Binary Rewriting

The technique of binary rewriting aims to modify an

existing program without recompilation.

A gadget-oriented tool that does not aim to re-

move useful gadgets but uses a randomization ap-

proach to make gadgets unavailable is ILR (Hiser

et al., 2012). In contrast to ASLR, which random-

izes only the base of a segment, ILR randomizes

the address of every instruction. This cannot be

achieved with x86 native code, which is why ILR uses

a process-level virtual machine (PVM). The princi-

ple of operation consists of an ofﬂine and a run-time

phase. In the ofﬂine phase, ILR analyzes the binary

and creates a randomized binary and a fall-through

map for the PVM to guide execution in the run-time

phase. Even though ILR can randomize up to 99.7%

of the instructions in a binary, research has proven that

even very small programs can provide enough gad-

gets for a successful exploit (Schwartz et al., 2011).

Furthermore, shared libraries are not affected by ILR.

They are solely protected by ASLR and, thus, provide

a potential attack surface.

Another instruction randomization approach is

STIR (Wartell et al., 2012). Similar to ILR – but with-

out the need of a virtual machine – it does not rely on

any side information and, therefore, requires only the

binary. However, STIR randomizes only the binary

at a basic block granularity and uses x86 native code

to dynamically determine the address of each basic

block. The level of randomization is relatively high

but a leaked basic block can again provide enough

gadgets to break this defense (Schwartz et al., 2011).

The x86 architecture is generally an attractive tar-

get for code-reuse attacks (Roemer et al., 2010). Its

instruction encoding is of variable length and must

not be unaligned, which allows interpreting data as

instructions. IPR (Pappas et al., 2012) is a sophis-

ticated solution for IA-32 that aims to eliminate un-

intended gadgets. In general, IPR uses three binary

rewrite techniques that do not change the semantics

of the program but provide equivalent substitution of

some binary patterns.

CCFIR (Zhang et al., 2013) aims to combine a

gadget-oriented approach with control-ﬂow integrity

mechanisms. On the control-ﬂow side, CCFIR re-

stricts indirect call and jump instructions such that

they may only transfer the control ﬂow to the function

entry point or are entirely prohibited (e.g. sensitive

API calls may only be accessed using a direct call).

To achieve this, CCFIR disassembles the binary and

creates an entry for each indirect branch in a so-called

springboard. As this approach uses control-ﬂow in-

tegrity, ROP can be successfully prevented. How-

ever, an attacker might still jump to valid targets in

the control-ﬂow graph.

2.3 Binary Instrumentation

The approach of binary instrumentation is similar to

binary rewriting. However, instrumentation does not

only rewrite existing code but also adds additional

checks – several instructions are, therefore, instru-

mented. In contrast to RIProtection, all these ap-

proaches instrument the binary in user-mode rather

than in kernel-mode.

DROP (Chen et al., 2009) employs instrumenta-

tion to realize a gadget-oriented technique. Their de-

fense tool relies on two parameters: the size of each

potential gadget (G_size) and the length of contiguous

Rest in Protection - A Kernel-level Approach to Mitigate RIP Tampering

gadget sequences (S_length). If a speciﬁc threshold

for G_size and max(S_length) is reached, it is identi-

ﬁed as malicious ROP code. According to its DROP

does not yield false positive or false negatives. Recent

work, however, has shown that approaches which rely

on gadget size and length cannot reliably protect pro-

grams and, thus, are still vulnerable (Gökta¸s et al.,

2014).

Another instrumentation-based approach that

tries to enforce control-ﬂow integrity is ROPDe-

fender (Davi et al., 2011). It uses the dynamic binary

instrumentation framework Pin (Luk et al., 2005) to

instrument any binary without having access to any

side information. ROPDefender ensures that every

ret reads only the RIP placed by its corresponding

call, and utilizes a shadow stack to achieve this. The

implementation is rather compact as the Pin frame-

work provides most of the features that ROPDefender

requires. In contrast to RIProtection, ROPDefender

uses only a shadow stack of return addresses and does

not save the value of the stack pointer. In our opinion,

this could lead to malfunctioning, e.g. in some cases

of exception handling, if the same return address ex-

ists more than once in the (shadow) stack.

ROPGuard (Fratri

c, 2012) is another state-of-the-

art defense technique that is part of the Enhanced Mit-

igation Experience Toolkit (EMET) (Defense, 2012).

It tries to enforce a coarse-grained control-ﬂow pol-

icy by using binary instrumentation to hook several

critical Windows API functions on IA-32. When one

of these functions is executed, ROPGuard performs

two checks. At ﬁrst it probes whether the RIP of the

API function call is call-preceded. ROPGuard per-

forms this call-preceded check not only on the RIP

but also emulates a few steps in the control ﬂow to

catch a future non-call-preceded return. The second

check is committed to the stack. ROPGuard detects

attempts to modify stack pointers in such a way that

they point into the heap or another attacker-controlled

memory region. Additionally, the stack may not be

set to executable. Nevertheless, also ROPGuard can

be bypassed as shown in the literature (Davi et al.,

2014).

The kBouncer (Pappas et al., 2013) approach not

only relies on binary instrumentation but also uses

the last branch record (LBR) of modern processors.

As a top-level concept, it enforces a coarse-grained

control-ﬂow integrity policy that hooks all Windows

API calls. The remarkable difference to ROPGuard

is that it not only checks if the procedure is call-

preceded but also probes previously adopted branches

with the facilities that the LBR offers. Like other ap-

proaches that utilize coarse-grained control-ﬂow in-

tegrity, kBouncer can also be bypassed (Carlini and

Wagner, 2014). The basic steps to exploit a program

if kBouncer is in use are the following: 1) place the

ROP payload as usual but do not invoke the syscall

yet, 2) ﬂush history, 3) restore the state of registers

that might have changed due to the history ﬂushing,

and 4) execute the syscall.

2.4 Kernel- and Hardware-based

Approaches

This section describes approaches which have in com-

mon that they all attempt to use hardware features

and/or are implemented in kernel mode.

Address Space Layout Randomization (ASLR) is a

standard mitigation technique that every modern op-

erating system has integrated today. The OS maps

program sections during the load-time of a process.

Most notably, the sections for the stack and heap are

randomized and, therefore, an attacker cannot over-

write the RIP with an address that points into any seg-

ment that is covered by ASLR. Besides being vulner-

able to brute-force attacks (Shacham et al., 2004), it

is constantly being bypassed using information leak-

age attacks (Sotirov and Dowd, 2008) and, as a result,

has the same attack surface as canaries. This is a ma-

jor issue, because even though ASLR and canaries are

widely used nowadays, they can be disabled using the

same vulnerability.

The No eXecute (NX) bit is a page entry bit that

marks an entire page as either executable or not. To-

gether with ASLR, it is one of the default defense

techniques (van der Veen et al., 2012). When an

instruction is scheduled for execution, the memory

management unit (MMU) probes the page that the

address belongs to and if the NX bit is set, the pro-

cessor yields an exception causing the process to be

terminated. With NX enabled, it is no longer pos-

sible to execute payload injected via a buffer over-

run, because the stack is not marked as executable.

The method of choice to circumvent NX these days

is ROP (Shacham, 2007). This technique does not

call functions but only a short sequence of instruc-

tions preceding a ret. As a consequence, the program

counter is always loaded with an address of an exe-

cutable section. Thus, the NX bit cannot prevent the

execution of malicious code because the PC is only

loaded with addresses from executable segments.

CFIMon (Xia et al., 2012) uses hardware perfor-

mance counters and the Linux kernel subsystem perf

events to detect control-ﬂow violations. Therefore,

they use the branch trace store (BTS) of recent pro-

cessors. When BTS is used, all taken branches are

recorded in memory. The protection that CFIMon of-

fers is to run whenever the protected application calls

ICISSP 2017 - 3rd International Conference on Information Systems Security and Privacy

execve(2). At this point, CFIMon reads the BTS and

each branch is qualiﬁed as legal, illegal or suspicious.

In contrast to the LBR, using the BTS has a notable

performance impact as branches are traced to memory

rather than to speciﬁc registers. Furthermore, the as-

sumption that every exploit ultimately leads to a call

to execve(2) a weakness because malicious code can

obviously deal damage without issuing an execve(2)

system call.

ROPecker (Cheng et al., 2014) is a state-of-the-art

ROP prevention tool that performs various checks to

enforce some sort of coarse-grained control-ﬂow in-

tegrity. ROPecker is triggered on some “risky system

calls” like mmap(2) and, additionally, if code is ex-

ecuted that resides on another page as the previous

page. Whenever ROPecker is triggered during the

run-time phase, it ﬁrst consults the database created

in the ofﬂine phase and the LBR to check whether

the address points to a gadget. If a speciﬁc gadget

chain threshold is exceeded, ROPecker terminates the

process. To ﬁll the gap until the next critical sys-

tem call or page fault, ROPecker also implements fu-

ture instruction emulation. Even though the authors

admit that their approach could especially struggle

with short gadget chains, they do not acknowledge

this as a realistic threat. However, it has been proven

that ROPecker can indeed be defeated using history

ﬂushing and gadget lengths below the threshold in

a similar fashion as the exploitation of kBouncer re-

quires (Gökta¸s et al., 2014).

3 DESIGN AND

IMPLEMENTATION

In this section, we present RIProtection, a novel ap-

proach that does not require recompilation, binary

rewriting or any other side information such as de-

bug symbols. First, we describe the general idea be-

hind RIProtection and, subsequently, present our de-

sign decisions for instruction-level monitoring along

with some implementation details of our approach.

Finally, the technical implementation is outlined and

a typical RIProtection life cycle is shown.

3.1 Basic Idea and Concept

The high-level concept of RIProtection is rather

generic. As illustrated in Figure 2, it consists of

two parts. One part is responsible for instruction-

level monitoring (ILM). ILM determines the kind of

branch and invokes the second part, one of the under-

lying security modules SecMod

to SecMod

. The

selected security module SecMod

then is aware of

Protected

Process

Branch

ILM

SecMod

...

SecMod

RIProtection

Figure 2: The concept of RIProtection consists of a compo-

nent that is used for instruction-level monitoring (ILM) and

of several possible security modules (SecMod

which branch was executed and can enforce a pol-

icy of choice. RIProtection allows different security

mechanisms on a per-process basis. Even though, for

our work, only call and ret instruction are of inter-

est, RIProtection is capable of monitoring any branch

instruction. Therefore, the monitoring of e.g. jmp

instructions could be realized to implement a mech-

anism to prevent jump-oriented programming in the

future (Checkoway et al., 2010).

3.2 Single Step on Branches

To realize ILM, RIProtection makes use of the Intel

x86 debug capabilities like the hardware supported

feature for single stepping. If the TF ﬂag in the

EFLAGS register is set, the processor generates an

exception on every instruction. Since single step-

ping allows monitoring all instructions, it is slow in

terms of performance because each instruction causes

a context switch to the kernel. A rather unknown

ﬂag in the IA32_DEBUGCTL MSR, the branch trap ﬂag

(BTF), causes the processor to treat the TF ﬂag in the

EFLAGS register only as a single step on branches

rather than a single step on each instruction (Corpora-

tion, 2014).

A branch is actually every instruction that does not

incrementally raise the PC such that noticeable over-

head is especially accounted by instructions of the

jmp family. Every time the PC is explicitly loaded

with an address rather than being implicitly incre-

mented, a debug exception is generated. A debug ex-

ception caused by the BTF ﬂag is a synchronous inter-

rupt and is categorized as a trap (Corporation, 2014).

This means that the processor generates an interrupt

after an instruction was executed. This information is

important as it affects the steps needed to access and

modify the RIP.

The handling of call and ret is as follows. When

a call is executed, the RIP is already on the stack

and can directly be processed by one of the security

modules. The ret case, however, is more complex

Rest in Protection - A Kernel-level Approach to Mitigate RIP Tampering

because the ret instruction occasionally reads ille-

gal addresses, e.g. if the RIP on the program stack

is modiﬁed by the security module. But even though

the program counter is already loaded with the RIP,

the processor has not yet begun with the instruction

fetch. Consequently, the PC can be processed with-

out touching the RIP on the stack. It becomes chal-

lenging to determine the branch type if the interrupt

is triggered after instruction execution. In a bare soft-

ware approach, this task would involve reading the

RIP from the stack and disassembling it to ﬁnd the

instruction that caused the branch. This is tricky be-

cause of the variable length of CISC instructions.

However, modern processors offer the possibil-

ity to monitor the source and destination of taken

branches, interrupts and exceptions in a set of reg-

isters called the last branch record (LBR). As these

entries are captured using bare hardware and regis-

ters instead of memory, it has near-zero performance

impact. Although not widely used in the past, LBR

registers are available since the Pentium 4 architec-

ture (Corporation, 2014) and initially offered four

model-speciﬁc registers that record the from and to

address of a taken branch. Furthermore, the LBR can

be conﬁgured to record only taken branches in the

user-level. Therefore, any architecture that supports

the LBR is suitable for RIProtection.

3.3 XOR Security Module

We implemented two security modules, one based

on XOR encryption and another based on a shadow

stack, both of which rely on monitoring call and ret

instructions.

. . .

RIP

. . .

call

. . .

RIP⊕secret

. . .

ret

. . .

RIP

. . .

Figure 3: The XOR security module.

The XOR module acquires a unique random key

when the process is protected. During execution of

the program, call and ret can be treated in the

same fashion because XOR is used to encrypt and de-

crypt the RIP with the process secret. This approach

does not have any logic probing whether a RIP was

modiﬁed because the XOR encryption on each call

and ret already establishes an implicit program ter-

mination if an attacker tampered a RIP. Overwriting

the RIP with plaintext addresses results in illegal ad-

dresses and consequently in process termination due

to segmentation violation as the RIP on the stack is

XOR-processed on each ret. 3 illustrates these steps.

3.4 Shadow Stack Security Module

. . .

RIP

. . .

ret

. . . . . .

SP RIP

. . . . . .

shadow stack

add

call

found?

kill

yes

match?

yes

resume

Figure 4: The shadow stack security module.

As visualized in 4, the shadow stack approach does

not modify the RIP on the program stack. In contrast

to the XOR module, the shadow stack requires addi-

tional bookkeeping structures for the RIPs. On call,

a new mapping on the shadow stack is created using

the SP as key and the RIP as value. On ret, the SP

is used to retrieve the shadow RIP. Our implementa-

tion of the shadow stack uses a map of key-value pairs

rather than only saving the return address. Related

work such as the ROPDefender only saves the RIP

on a call and, therefore, needs separate handling for

functions or exceptions that jump over several stack

frames. If the SP value is saved as a key, no special

treatment is required and the list is traversed in re-

verse order to ﬁnd the matching entry. The correct

entry, according to the stack data structure, is usually

the last entry added. If, however, no entry is found or

the PC and the shadow RIP do not match, the program

is killed. Otherwise, the program is resumed.

3.5 Implementation

This section explains the technical implementation of

the design described in the previous section. The im-

plementation of RIProtection is carried out as a Linux

v3.13 kernel patch for Ubuntu 14.04.1 LTS in about

1,000 lines of code. Overall, the patch modiﬁes 12

existing ﬁles and adds four new ﬁles.

5 shows the architecture and execution ﬂow of

RIProtection. To indicate whether a program is to

be protected by RIProtection, we modiﬁed the ker-

nel code of the ELF binary handler. RIProtection

introduces EI_RIProtection at byte 8 of the ELF

header, which is labeled as R in 5. If R is set to a

value greater than zero, RIProtection invokes ripro-

tection_protect just before the new process is ex-

ecuted. In this step, RIProtection adds the task to

its internal list of protected tasks and sets the TF

ﬂag in the EFLAGS register as well as the LBR and

ICISSP 2017 - 3rd International Conference on Information Systems Security and Privacy

protect

L F7f 2 1 1

binary program

Kernel Mode User Mode

handle_branch

execve

set

program counter

do_debug

return instr ptr

abandon

exit

Processor

call func

func:

ret

non call/ret

process

R > 0

security modules

shadow stack

R = 2

xor

R = 1

execve

EFLAGS

IA32_DEBUGCTL

1 1

LBR BTF

TOS

from

LBR

Figure 5: The architecture of RIProtection: The execution ﬂow and interaction of user-mode, kernel-mode and processor

features. Functions and features introduced by RIProtection are ﬁlled with a yellow background.

BTF bit in the IA32_DEBUGCTL MSR. From this point

on, the CPU records all branches, interrupts and ex-

ceptions taken in user space. Furthermore, an inter-

rupt is generated on each branch. Additionally, the

protect function determines which security module

(XOR or shadow stack) is used and invokes the ini-

tialization handler of the selected module. For the

XOR method, the initialization involves only acquir-

ing a task-speciﬁc 48- or 32-bit random key using

get_random_bytes for x86_64 and IA-32 binaries

respectively. If the shadow stack module is used, it

allocates and initializes the head of the shadow stack

list structure.

When the kernel receives an interrupt due to

a branch instruction in the protected program,

do_debug is called. In this function, handle_branch

is executed if the task is in the list of protected tasks.

In this case, handle_branch retrieves the most re-

cent from-entry of the LBR to ﬁnd out the address

of the instruction that caused the interrupt. The

handle_branch function also increments the task-

speciﬁc counters for ret, call and the total amount

of branches depending on the type of branch. These

statistics are available through the /proc ﬁlesystem

for all running tasks which are protected by RIProtec-

tion and are also available for the protected task that

terminated most recently.

Both security modules need to read the RIP. If the

debug trap occurred due to a call instruction, the ad-

dress of the following address (i.e. the RIP) was al-

ready pushed on the stack. Hence, the call handler

needs to copy the RIP to the kernel space. In the fol-

lowing, the XOR approach encrypts the RIP with the

process secret and write it back. The shadow stack

creates a new entry in the shadow list, which consists

of key-value pairs while the current value of the SP

acts as a key and RIP as a value.

As soon as a ret is executed, the program counter

is already loaded with the entry found on the pro-

cess stack as depicted by the current value of the SP.

Therefore, the user space stack of the process is not

accessed for retrieving the RIP. Instead, the ret han-

Rest in Protection - A Kernel-level Approach to Mitigate RIP Tampering

dler routine of the security module directly reads the

task’s program counter. Not even the XOR module

needs to access the process memory after decrypting

the address because the value of the SP was already

increased and entries with a lower value than the cur-

rent SP are free by deﬁnition. The detection of RIP

tampering is implicit for the XOR module. There is

no explicit logic in the code that marks code as ma-

licious and causes RIProtection to terminate the pro-

cess. Nevertheless, the process is indirectly killed due

to a segmentation violation.

The ret handler of the shadow stack approach

must ﬁrst look for the correct entry in its internal

list by comparing the SP key of entries with the cur-

rent SP value incremented by one. Later, the shadow

RIP is compared to the RIP loaded into the program

counter. If both do not match, the RIP was tampered

with and the process is terminated. In the case that no

entry matches the incremented SP value, the program

counter is loaded with an address that was not placed

using a call instruction and the program is killed. In

this situation, an attacker likely tried to launch a ROP

attack and the normal control ﬂow of the program was

tampered. If an entry in the shadow stack is found

and matches, the entry is removed from the list and

the program is resumed.

If handle_branch could neither detect a call nor

a ret, the control is immediately transferred back to

the application. This is not a rare case as a trap is also

generated for all jmp instructions that are common in

every program. Unfortunately, it is impossible to ﬁlter

out jmps in hardware leading to a severe performance

drawback of our approach as explained in 4.2.

For every process, do_exit is eventually called.

This is also true if the program is killed instead of ex-

plicitly calling exit(2). When this point is reached,

abandon is called and disables TF and BTF, and re-

leases the perf events kernel counter to stop cap-

turing branches for that task. Ultimately, the task is

removed from the list of protected tasks.

4 EVALUATION

In this section, we evaluate RIProtection and the XOR

and shadow stack modules in terms of security, per-

formance and compatibility. All three categories were

examined running Ubuntu 14.04.1 LTS using a hyper-

threaded, dual-core Intel Core i5-650.

4.1 Security

This section is dedicated to the security evaluation

and discussion of RIProtection. The underlying XOR

and shadow stack security modules are examined in-

dividually and in contrast to each other.

First, we will consider if it is possible to entirely

disable the instruction-level monitoring facilities of

RIProtection. The single step on branches method de-

pends on two values. The TF ﬂag in the EFLAGS reg-

ister and the BTF ﬂag in the IA32_DEBUGCTL MSR.

Model-speciﬁc registers can only be accessed from

the kernel-level and, therefore, are usually not acces-

sible from the user space (Corporation, 2014). Con-

sequently, the IA32_DEBUGCTL is well-protected and

tampering with it is not easy. The EFLAGS regis-

ter, however, can be modiﬁed using the pushf and

popf instructions. This is not a security ﬂaw, even

though clearing the TF ﬂag in the EFLAGS register

disables single stepping completely because attackers

must ﬁrst gain control over the execution ﬂow to ex-

ecute these instructions. As covered in detail in the

following section about the compatibility of RIProtec-

tion, the TF ﬂag in the EFLAGS register may not be

modiﬁed by the application itself. Otherwise, RIPro-

tection cannot protect the program.

4.1.1 XOR Module

Although RIProtection’s instruction-monitoring facil-

ities cannot be disabled, it might be possible to get

around its underlying security modules while they are

in use. In many aspects, the protection and the attack

surface of RIProtection operating in XOR mode can

be compared to stack canaries as used by StackGuard.

As explained in 2, canaries place a unique and ran-

dom value beside the RIP. This value is checked in the

function epilogue just before a ret is executed. If the

check fails, the program is terminated. The XOR se-

curity module does not require an individual check af-

ter ret execution because the XOR with the process-

speciﬁc secret creates an invalid address as long as the

attacker does not know the process-speciﬁc secret. As

already stated, however, stack canaries also rely on

such a secret and it also has been proved that they can

be bypassed (Bulba and Kil3r, 2000). Usually, this is

achieved by exploiting an information leakage vulner-

ability that reveals the value of the canary. Afterward

a buffer overﬂow vulnerability is exploited, for exam-

ple, and the canary value is simply rewritten.

In a similar way, the XOR security module of

RIProtection cannot withstand an information leak-

age vulnerability that allows the attacker to read the

value of the RIP. The RIP is encrypted using a sim-

ple XOR of the secret and the original RIP. It comes

in handy for the implementation of the approach that

the inverse function of the XOR function is the XOR

function again. However, if an adversary has knowl-

edge of an encrypted RIP and knows the original ad-

ICISSP 2017 - 3rd International Conference on Information Systems Security and Privacy

dress, he or she can deduce the secret easily. As far

as Linux is concerned, the address of the original RIP

is often statically known because the .text section

is sometimes unaffected by ASLR because of perfor-

mance reasons.

Even with full ASLR enabled, the key space of the

XOR module can be reduced due to the nature of the

XOR function. The offsets between instructions are

still known and if an adversary is able to leak more

than one XOR encrypted RIP he or she can leak at

most as many bits as the highest offset between two

XOR encrypted RIPs. In general, the process secret of

a 64-bit executable protected by RIProtection in the

XOR operation mode has as an entropy of 48-bit as

the remaining most signiﬁcant bits are currently sign-

extended with bit 47. The offset between the RIPs

is statically known and the following expression is

true: RIP

⊕RIP

= (RIP

⊕secret)⊕(RIP

⊕secret).

With those two conditions the key space is potentially

reduced with every leaked address and an adversary

might be able to compute the secret within a reason-

able period. Nevertheless, this remains to be a rather

theoretical vulnerability as the key can be easily com-

puted if an attacker is able to leak memory.

At ﬁrst glance, full ASLR cannot provide en-

hanced security, as ASLR is also vulnerable to in-

formation leakage attacks. Nevertheless, consider an

example of a program with an information leakage

vulnerability for which an attacker wants to execute

ROP gadgets that reside in the program’s .text sec-

tion. Additionally, assume that the program is exe-

cuted in an environment where full ASLR and NX

are enabled. The ﬁrst approach that an adversary

would usually take to create the ROP payload is to

read the RIP because it provides a perfect address for

the .text section. If RIProtection with XOR encryp-

tion is in charge, this would fail due to the encryption

of the RIP with a so far unknown secret. On the other

hand, the adversary cannot compute the secret, even

though he or she is able to read the encrypted RIP.

To achieve this, the attacker needs to determine the

real, unencrypted RIP, which is protected by ASLR.

Nevertheless, even such a scenario cannot disable this

kind of attack entirely. An attacker might leak a func-

tion pointer or any other data pointing to .text and,

thus, be able to compute the process secret.

4.1.2 Shadow Stack Module

The shadow stack security module pursues a differ-

ent approach than the XOR-based encryption and is

slightly more complicated. When a ret instruction

is executed after an attack begins, there are two cases

where the shadow stack provides protection. If the

RIP is modiﬁed directly, the handler function ﬁnds

a shadow RIP that differs from the address that is

loaded into the PC. Consequently, the process is ter-

minated. The other case assumes that an attacker

could start an exploit that does not take over the con-

trol ﬂow by modifying the RIP. This can be achieved

by GOT hijacking, for example. To execute further

malicious instructions, a code-reuse attack like ROP

can be used. If RIProtection is used in its shadow

stack mode, this fails because ROP will execute a se-

ries of gadgets ending in a ret instruction without a

corresponding call. As a result, the shadow list of

the shadow stack security module cannot ﬁnd an entry

for the SP value and accounts for this by terminating

the program. The attack surface of the shadow stack

approach is substantially different from that of the

XOR mode because it does not reveal any of the data

it operates on to the process. Therefore, the shadow

stack does not provide any points to attack for infor-

mation leakage because its data resides entirely in the

kernel space.

The shadow stack can not only protect the pro-

gram from classic RIP modiﬁcation and ROP, but is

also not disabled easily. The fact that the XOR se-

curity module is vulnerable to information leakage

makes it especially inferior because two widely used

safeguards, ASLR and canaries, provide the same at-

tack surface. Therefore, an attacker might circumvent

ASLR, canaries and RIProtection in its XOR mode

using the same vulnerability.

4.2 Performance

We acquired our performance data using the

nbench2 (Mayer, 2011) CPU benchmark which mea-

sures the operations per second for various algo-

rithms. Note that the benchmark offers three more

tests but those were omitted to improve the readabil-

ity of the results as even their native test performance

scores below 10 operations per second.

Our evaluation compares the performance without

and with RIProtection running in either the XOR or

shadow stack operation mode. The results are de-

picted in 6 and visualize the run-time multiplier of

RIProtection. Furthermore, we also evaluated how

often RIProtection was invoked due to a call/ret

instruction or due to any other branch. The bench-

marking result for the run-time multiplier yields a no-

ticeable performance overhead introduced by RIPro-

tection ranging from 93 for the FP Emulation test to

827 for the LU Decomposition test. The average op-

erations per second is almost equal, being 46.39 for

XOR and 46.10 for the shadow stack. For tests with a

high call-ret amount, e.g. the Fourier test, the XOR

tends to perform slightly better than the shadow stack

operation mode.

Rest in Protection - A Kernel-level Approach to Mitigate RIP Tampering

Num. sort

Str. sort FP Emulation Fourier Idea Huffman

LU Decomp.

100

1000

10000

100000

2134,4

891,35

341,57

41689

8937,1

3168,7

2368,6

7,46

1,84

3,45

202,39

96,57

10,15

2,87

7,37

1,82

3,43

200,9

96,13

10,2

2,87

Iterations per second

unprotected XOR shadow stack

200

400

600

800

Run-time multiplier / No. branches ·10

multiplier calls/rets all branches

Figure 6: Benchmarking results for various tests of the nbench2 CPU benchmark. The green bar shows the iterations per

second using nbench2 without protection while the blue and red bars indicate a run using the XOR and shadow stack operation

modes respectively. The other graphs display the average run-time multiplier of both security modules while the dashed and

dash-dotted graphs indicate the number of branches due to a call or ret and the total amount of branches.

In general, one would expect the XOR-based en-

cryption to perform notably better than the shadow

stack because it does not require any additional struc-

tures on each call or ret and provides constant op-

eration time for every invocation of its logic. The re-

sults, however, indicate that the advantage of XOR is

minimal and that most of the average run-time per-

formance differences stem from measuring inaccu-

racy. This suggests that the overall bottleneck is not

the underlying security module but the BTF-based

instruction-monitoring approach of the ILM unit.

Furthermore, one would assume that the run-time

multiplier is linearly dependent on the total count of

branches because each one causes an interrupt. The

LU Decomposition test result, however, has the high-

est run-time multiplier but a branch count that is 22%

below the average number of branches. This suggests

that the LU Decomposition test suffers from the con-

text switch which also has an effect on the contents of

the CPU cache.

The performance overhead introduced by RIPro-

tection has primarily two reasons. The ﬁrst one is

that the BTF ﬂag triggers a debug trap whenever a

branch occurs. This is especially an issue for jmp

instructions that occur often. The second reason is

that an interrupt is per se a time-consuming operation

that involves an expensive context switch to kernel-

mode that also confuses hardware components like

the CPU cache. Nevertheless, the performance evalu-

ation shows that global statements on the performance

of programs cannot be made because it is highly de-

pendent on the structure of the program.

4.3 Compatibility

RIProtection can protect any 64-bit ELF program that

runs in user-mode if the following requirements are

met. In any case, RIProtection must be explicitly en-

abled , as explained in 3.5.

First, the hardware requirements of RIProtection

must be met. As already stated in 3, the CPU needs

to support single stepping on branches and the last

branch record. The number of branches that the LBR

can record has increased with processor generations

but for RIProtection only one entry is required. As

any Intel CPU that features the LBR also supports

BTF, only a CPU with LBR is required.

Another primary requirement of RIProtection is

that a program does not modify the TF ﬂag in the

EFLAGS register. The EFLAGS are indirectly mod-

iﬁed by the pushf and popf instructions and, hence,

protected applications are not allowed to use these in-

structions. Due to this limitation, single step debug-

ging is neither allowed, because the debugger modi-

ﬁes the EFLAGS, nor possible, as the debugger does

not receive any signals due to RIProtection. More-

over, the backtrace feature that many debuggers usu-

ally offer cannot be used if RIProtection protects the

debugged process in XOR mode, because all the RIPs

are encrypted.

Furthermore, the compiler that was used or is used

to build the program needs to follow the convention

ICISSP 2017 - 3rd International Conference on Information Systems Security and Privacy

that a ret is a return from a procedure previously

called using a call instruction (Corporation, 2014).

This is certainly true for popular compilers like GCC

and LLVM but may not be the case for some obfus-

cated binaries. The same applies to the use of (in-

line) assembler and therefore must not tamper with

any RIP and must not introduce ret instructions that

read a RIP not placed by its corresponding call.

Multi-threaded applications follow the same line.

RIProtection supports multi-threading as long as

threads are managed in kernel-mode. It is important

that the scheduling of threads is carried out in the ker-

nel as the scheduler needs to execute a ret without

a corresponding call. This violates the fundamental

assumption of RIProtection. However, this operation

is not a problem inside the kernel because RIProtec-

tion applies its defense mechanisms only to user-level

programs and, therefore, is only triggered there.

5 FUTURE WORK

The XOR security module could be hardened against

information leakage by increasing the number of task-

speciﬁc secrets to n. As a consequence, the log

(n)

least signiﬁcant or most signiﬁcant bits could indicate

the key to use. This has the drawback that log

(n)

bits of entropy are lost. One needs to take care that

the entropy does not drop too low. In general, the

concept would require slightly more space but main-

tains an easy approach. Moreover, additional security

could be introduced by implementing the concept of

call-preceded rets as is also found in related work.

In a case where an adversary was able to leak the se-

cret and, consequently, is able to generate a valid ROP

payload, he or she is at least forced to use gadgets that

are call-preceded.

Even though the security modules already rely on

a modular design and can be easily implemented, they

are still part of the Linux kernel. The development

of additional security modules would be easier and

more convenient if each security approach is a sepa-

rate loadable kernel module (LKM).

The security evaluation of the XOR approach re-

veals that the shadow stack module is superior in

terms of protection. However, the XOR approach is

still of interest because it could be easily realized in

hardware by introducing a register that holds the task-

speciﬁc secret. The ⊕ encryption on call and ret

could be achieved in a similar fashion to RIProtec-

tion. If implemented in hardware, the attack surface

would remain the same but probably with a near-zero

performance impact. In fact, AMD has a patent on

Hardware Based Return Pointer Encryption (Kaplan,

2014) that was published in June 2014 and has a sim-

ilar concept to the proposed idea.

The implementation of the shadow stack approach

in hardware is a more challenging task as a logic must

be implemented to ﬁnd the appropriate entry in the

shadow stack. The concept of a shadow stack would

necessarily lead to a slow down because it involves

memory access on every call and ret. To increase

the performance, a cache that holds the most recent

branches could be used.

Both of the presented security modules address

only ret-based exploitation techniques like ROP.

Therefore, they cannot protect programs that can

launch an attack that e.g. relies on jump-oriented

programming (Checkoway et al., 2010). As a conse-

quence, a security module that protects against ret-

and jmp-based exploitation is of interest. RIPro-

tection is capable of monitoring arbitrary branches

but program protection against jmp-based exploita-

tion is a more challenging task because, in contrast to

ret-based techniques, no corresponding instruction

as call for ROP exists to determine if control is going

to a legal branch target. Compared to the XOR and

shadow stack security modules, an approach to miti-

gate jump-oriented programming would likely result

in a similar performance evaluation because the over-

head is for the most part caused by the instruction-

level monitoring of RIProtection.

6 CONCLUSION

We presented RIProtection, a novel approach that

utilizes the single step on branches hardware de-

bug feature to provide instruction-level monitoring of

branches. For its modular system, we developed a

XOR and a shadow stack security approach where

both operate whenever a call or ret instruction oc-

curs. The chapter on the design and implementation

of RIProtection showed that our generic concept can

be adopted quite well by single modules. The fol-

lowing chapter evaluated RIProtection in terms of se-

curity, performance and compatibility. This conclud-

ing chapter summarizes the limitations of RIProtec-

tion has and proposes some ideas for how the imple-

mentation could be further improved.

As far as security is concerned, RIProtection can,

in both operation modes, reliably prevent the exploita-

tion of a buffer overﬂow that tries to overwrite the

RIP with the raw value of an address found in an ex-

ecutable program section. As already discussed, the

XOR approach might be circumvented by informa-

tion leakage vulnerability. The shadow stack, how-

ever, is immune against memory disclosure and pro-

Rest in Protection - A Kernel-level Approach to Mitigate RIP Tampering

vides overall solid protection against ret-based ex-

ploitation.

The performance evaluation of RIProtection re-

veals that its usage in the ﬁeld is highly dependent on

the structure of the program and makes global state-

ments on the expected performance of protected pro-

grams difﬁcult. In any case, RIProtection introduces

a signiﬁcant performance impact.

In means of compatibility RIProtection provides

excellent support for every x86_64 binary created

from standard C with a compiler that respects con-

ventions. The security module that should be used

can conveniently be chosen by only altering the re-

spective byte in the program ELF header.

ACKNOWLEDGEMENTS

This work was supported by DATEV eG as part of

the research project “Software-based Hardening for

Mobile Applications”.

REFERENCES

Bletsch, T., Jiang, X., and Freeh, V. (2011). Mitigating

code-reuse attacks with control-ﬂow locking. In Pro-

ceedings of the 27th Annual Computer Security Ap-

plications Conference, ACSAC ’11, pages 353–362,

New York, NY, USA. ACM.

Bulba and Kil3r (2000). Bypassing stackguard and stack-

shield.

Carlini, N. and Wagner, D. (2014). Rop is still dangerous:

Breaking modern defenses. In Proceedings of the 23rd

USENIX Conference on Security Symposium, SEC’14,

pages 385–399, Berkeley, CA, USA. USENIX Asso-

ciation.

Checkoway, S., Davi, L., Dmitrienko, A., Sadeghi, A.-

R., Shacham, H., and Winandy, M. (2010). Return-

oriented programming without returns. In Proceed-

ings of the 17th ACM Conference on Computer and

Communications Security, CCS ’10, New York, NY,

USA. ACM.

Chen, P., Xiao, H., Shen, X., Yin, X., Mao, B., and Xie, L.

(2009). Drop: Detecting return-oriented programming

malicious code. In Prakash, A. and Sen Gupta, I., ed-

itors, Information Systems Security, volume 5905 of

Lecture Notes in Computer Science, pages 163–177.

Springer Berlin Heidelberg.

Cheng, Y., Zhou, Z., Yu, M., Ding, X., and Deng, R. H.

(2014). Ropecker: A generic and practical approach

for defending against rop attacks. In Proceedings of

the 21th Annual Network and Distributed System Se-

curity Symposium, NDSS’14. NDSS Association.

Corporation, I. (2014). Intel

 64 and ia-32 architectures

software developer’s manual, volume 3 (3a, 3b & 3c):

System programming guide.

Cowan, C., Beattie, S., Johansen, J., and Wagle, P. (2003).

Pointguard: Protecting pointers from buffer overﬂow

vulnerabilities. In Proceedings of the 12th Confer-

ence on USENIX Security Symposium - Volume 12,

SSYM’03, pages 7–7, Berkeley, CA, USA. USENIX

Association.

Cowan, C., Pu, C., Maier, D., Hintony, H., Walpole, J.,

Bakke, P., Beattie, S., Grier, A., Wagle, P., and Zhang,

Q. (1998). Stackguard: Automatic adaptive detection

and prevention of buffer-overﬂow attacks. In Proceed-

ings of the 7th Conference on USENIX Security Sym-

posium - Volume 7, SSYM’98, pages 5–5, Berkeley,

CA, USA. USENIX Association.

Davi, L., Sadeghi, A.-R., Lehmann, D., and Monrose, F.

(2014). Stitching the gadgets: On the ineffectiveness

of coarse-grained control-ﬂow integrity protection. In

Proceedings of the 23rd USENIX Conference on Se-

curity Symposium, SEC’14, pages 401–416, Berkeley,

CA, USA. USENIX Association.

Davi, L., Sadeghi, A.-R., and Winandy, M. (2011). Ropde-

fender: A detection tool to defend against return-

oriented programming attacks. In Proceedings of the

6th ACM Symposium on Information, Computer and

Communications Security, ASIACCS ’11, pages 40–

51, New York, NY, USA. ACM.

Defense, M. S. R. . (2012). Introducing enhanced mitigation

experience toolkit (emet).

Fratri

c, I. (2012). Ropguard: Runtime prevention of return-

oriented programming attacks.

Gökta¸s, E., Athanasopoulos, E., Polychronakis, M., Bos,

H., and Portokalidis, G. (2014). Size does matter:

Why using gadget-chain length to prevent code-reuse

attacks is hard. In Proceedings of the 23rd USENIX

Conference on Security Symposium , SEC’14, pages

417–432, San Diego, CA. USENIX Association.

Hiser, J., Nguyen-Tuong, A., Co, M., Hall, M., and David-

son, J. (2012). Ilr: Where’d my gadgets go? In Se-

curity and Privacy (SP), 2012 IEEE Symposium on,

pages 571–585.

Kaplan, D. (2014). Hardware based return pointer encryp-

tion. US Patent App. 13/717,315.

Luk, C.-K., Cohn, R., Muth, R., Patil, H., Klauser, A.,

Lowney, G., Wallace, S., Reddi, V. J., and Hazelwood,

K. (2005). Pin: Building customized program analysis

tools with dynamic instrumentation. In Proceedings

of the 2005 ACM SIGPLAN Conference on Program-

ming Language Design and Implementation, PLDI

’05, pages 190–200, New York, NY, USA. ACM.

Mayer, U. F. (2011). Linux/unix nbench.

Onarlioglu, K., Bilge, L., Lanzi, A., Balzarotti, D., and

Kirda, E. (2010). G-free: Defeating return-oriented

programming through gadget-less binaries. In Pro-

ceedings of the 26th Annual Computer Security Appli-

cations Conference, ACSAC ’10, pages 49–58, New

York, NY, USA. ACM.

Pappas, V., Polychronakis, M., and Keromytis, A. D.

(2012). Smashing the gadgets: Hindering return-

oriented programming using in-place code random-

ization. In Proceedings of the 2012 IEEE Sympo-

sium on Security and Privacy, SP ’12, pages 601–615,

Washington, DC, USA. IEEE Computer Society.

ICISSP 2017 - 3rd International Conference on Information Systems Security and Privacy

Pappas, V., Polychronakis, M., and Keromytis, A. D.

(2013). Transparent rop exploit mitigation using in-

direct branch tracing. In Proceedings of the 22Nd

USENIX Conference on Security, SEC’13, pages 447–

462, Berkeley, CA, USA. USENIX Association.

Roemer, R., Buchanan, E., Shacham, H., and Savage, S.

(2010). Return-oriented programming: Systems, lan-

guages, and applications.

Schwartz, E. J., Avgerinos, T., and Brumley, D. (2011). Q:

Exploit hardening made easy. In Proceedings of the

20th USENIX Conference on Security, SEC’11, pages

25–25, Berkeley, CA, USA. USENIX Association.

Shacham, H. (2007). The geometry of innocent ﬂesh on

the bone: Return-into-libc without function calls (on

the x86). In Proceedings of the 14th ACM Conference

on Computer and Communications Security, CCS ’07,

pages 552–561, New York, NY, USA. ACM.

Shacham, H., Page, M., Pfaff, B., Goh, E.-J., Modadugu,

N., and Boneh, D. (2004). On the effectiveness of

address-space randomization. In Proceedings of the

11th ACM Conference on Computer and Communica-

tions Security, CCS ’04, pages 298–307, New York,

NY, USA. ACM.

Sotirov, A. and Dowd, M. (2008). Bypassing browser mem-

ory protections: Setting back browser security by 10

years.

van der Veen, V., dutt Sharma, N., Cavallaro, L., and Bos,

H. (2012). Memory errors: The past, the present, and

the future. In Balzarotti, D., Stolfo, S., and Cova, M.,

editors, Research in Attacks, Intrusions, and Defenses,

volume 7462 of Lecture Notes in Computer Science,

pages 86–106. Springer Berlin Heidelberg.

Wartell, R., Mohan, V., Hamlen, K. W., and Lin, Z.

(2012). Binary stirring: Self-randomizing instruction

addresses of legacy x86 binary code. In Proceedings

of the 2012 ACM Conference on Computer and Com-

munications Security, CCS ’12, pages 157–168, New

York, NY, USA. ACM.

Xia, Y., Liu, Y., Chen, H., and Zang, B. (2012). Cﬁmon:

Detecting violation of control ﬂow integrity using per-

formance counters. In Dependable Systems and Net-

works (DSN), 2012 42nd Annual IEEE/IFIP Interna-

tional Conference on, pages 1–12.

Zhang, C., Wei, T., Chen, Z., Duan, L., Szekeres, L., Mc-

Camant, S., Song, D., and Zou, W. (2013). Practi-

cal control ﬂow integrity and randomization for binary

executables. In Proceedings of the 2013 IEEE Sympo-

sium on Security and Privacy, SP ’13, pages 559–573,

Washington, DC, USA. IEEE Computer Society.

Rest in Protection - A Kernel-level Approach to Mitigate RIP Tampering
