Collaborative Contributions for Better Annotations

Priyam Bakliwal

, Guruprasad M. Hegde

and C. V. Jawahar

International Institute of Information Technology, Hyderabad, India

Bosch Research and Technology Centre, Bengaluru, India

Keywords:

Video-processing, Active-leaning, Surveillance Video Annotations, Tracking.

Abstract:

We propose an active learning based solution for efﬁcient, scalable and accurate annotations of objects in

video sequences. Recent computer vision solutions use machine learning. Effectiveness of these solutions

relies on the amount of available annotated data which again depends on the generation of huge amount of

accurately annotated data. In this paper, we focus on reducing the human annotation efforts with simultaneous

increase in tracking accuracy to get precise, tight bounding boxes around an object of interest. We use a novel

combination of two different tracking algorithms to track an object in the whole video sequence. We propose

a sampling strategy to sample the most informative frame which is given for human annotation. This newly

annotated frame is used to update the previous annotations. Thus, by collaborative efforts of both human and

the system we obtain accurate annotations with minimal effort. Using the proposed method, user efforts can

be reduced to half without compromising on the annotation accuracy. We have quantitatively and qualitatively

validated the results on eight different datasets.

1 INTRODUCTION

With increase in use of surveillance cameras and de-

crease in cost of storage and processing of surveil-

lance videos, there is a huge availability of unlabeled

video data. This data can be utilized in many high

level computer vision tasks such as motion analy-

sis, event detection and activity understanding. Com-

puter vision models that do video analysis (Zhong

and Chang, 2001; Zhong et al., 2004) require accu-

rately annotated data for both training and evaluation.

However, annotating massive video sequences is ex-

tremely expensive and may not be feasible.

The use of tracking algorithms to generate anno-

tated data lack in terms of detection accuracy and re-

liability making them unsuitable for critical applica-

tions like surveillance systems, transport, sports anal-

ysis, medical imaging, etc. Most of the recent algo-

rithms (Gray et al., 2007; Zhou et al., 2009; Thomas

et al., 2010) use the appearance model as a prereq-

uisite for the success of a tracking system. It is ex-

tremely challenging to design a robust appearance

model which can be adaptive to all the working condi-

tions like partial/full occlusion, illumination changes,

motion blur, shape changes, etc.. These methods do

give us a signiﬁcant improvement in tracking output

but they are still not reliable enough to be used for

generation of annotated data.

There have been many attempts in the past to gen-

erate annotated data from videos. However, these

methods are not often used for large industrial scale

annotations because they usually lack annotation con-

sistency and accuracy. In most cases (Kavasidis et al.,

2012), human annotators mark the object of interest

in a video sequence. As pointed out in (Vondrick

et al., 2013), manual annotations, involve a huge cog-

nition load, and is subjected to inefﬁciency and in-

accuracies. Some efforts that use crowd sourcing to

increase the number of annotations, mainly for build-

ing large corpora (Deng et al., 2009; Oh and et. al.,

2011; Russell et al., 2008), suffer from inconsistent

annotations as most workers are poor annotators. In

video annotation, the marking consistency of an anno-

tator is extremely important as it becomes difﬁcult to

capture the marking variation in shape and extent of

object within neighboring frames. Thus, crowd sourc-

ing mandates robust quality control protocols.

Due to extremely high cost of human annotation

for large video datasets, much of the research efforts

have been dedicated towards leveraging the use of un-

labeled data. Many algorithms developed recently are

using semi-supervised learning (Fergus et al., 2009;

Lee et al., 2011), or weakly-labeled data (Thomas

et al., 2010), which is faster to annotate. All of these

algorithms aim at reducing the number of annotations

needed.

The video annotation framework proposed by

Vondrick and Ramanan (Vondrick and Ramanan,

Bakliwal P., M. Hegde G. and Jawahar C.

Collaborative Contributions for Better Annotations.

DOI: 10.5220/0006098103530360

In Proceedings of the 12th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2017), pages 353-360

ISBN: 978-989-758-227-1

353

Figure 1: Use of Active Learning for object tracking in

video sequences. Top row shows the tracking output on

3 frames of TUD-Crossing(4) sequence. The tracker fails

to track the person in white jacket accurately. Our sam-

pling technique selects the most informative frame (shown

in red rectangle) for user annotation. The proposed algo-

rithm ensures more accurate tracking with minimal user ef-

forts. Bottom row shows better predictions for entire se-

quence with only one user annotation.

2011) is based on the video annotations using active

learning. In this system annotations are derived by

tracking results and active learning is used to intelli-

gently query the human annotator for corrections on

the tracks. Angela et. al. (Angela et al., 2012), uses

an incremental learning approach which continuously

updates an object detector and detection thresholds,

as an user interactively corrects annotations proposed

by the system. In their work, the learning approach is

paired with an active learning element which predicts

the most difﬁcult images. Their solution is purely

based on detection and does not consider the tracking.

However, our approach incorporated tracking into de-

tection, making it more robust while ensuring mini-

mal annotation effort.

Works in similar lines includes (Chatterjee and

Leuski, 2015; Zha et al., 2012; H

oferlin et al., 2012)

which utilize active learning for video indexing and

annotation. However, they do not incorporate the

power of existing efﬁcient tracking algorithms to cre-

ate a robust and accurate framework for real time ob-

ject detection in video sequences.

Contributions. In this work, we use tracking algo-

rithms to detect the objects in multiple frames and ac-

tive learning is used to improve the correctness of the

tracks. We propose (i) an effective tracking algorithm

and (ii) an adaptive key-frame strategy that use ac-

tive learning to intelligently query the annotator to la-

bel the objects at only certain frames which are most

likely to improve the performance. The proposed ac-

tive learning strategy can also be used in other com-

puter vision tasks. We propose a framework that can

easily incorporate various tracking algorithms, mak-

ing it more generalized. Multiple tracking algorithms

(2 in our case) are combined efﬁciently to produce a

reliable and accurate track for the object.

One of the major contributions of this method

is consideration of neighborhood in selection of key

frames. Also, we have used ‘Query by Commit-

tee’ strategy for key frame selection. Consideration

of temporal neighborhood makes sure that with each

user annotation, the tracking is best updated for neigh-

boring frames as well. The advantages of our method

includes easy incorporation of tracking algorithms,

automatic detection of key frames thereby drastically

reducing human efforts and scalable annotation pro-

cess. This makes our approach suitable for annota-

tions of large video datasets.

We performed experiments on objects of multiple

datasets and show that the user efforts for doing

annotation can be reduced up to 50% when using the

proposed active learning strategy without compro-

mising on tracking accuracy. We also show that with

the same amount of user efforts the proposed method

achieves an improvement of up to 200% for tracking

task. We report experimental results on 8 different

datasets consisting of more than 2500 frames and 17

objects. The consistent improvement in all scenarios

demonstrate the utility of our approach.

2 TRACKING ALGORITHMS

We employ three tracking algorithms in this work.

The most simple uses bi-linear interpolation which

does not consider object characteristics and predicts

tracks using initialization only. The other two al-

gorithms are the modiﬁcation of two state of the art

tracking methods, Weighted Multiple Instance Learn-

ing Tracker (WMILT) (Zhang and Song, 2013) and

Discriminative Scale Space Tracker (DSST) (Danell-

jan et al., 2014). WMILT uses weighted instance prob-

abilities to detect object of same size in other frames.

On the other hand, DSST uses discriminative corre-

lation ﬁlters based on a scale pyramid representation

to track the object. DSST algorithm is scale invariant

while the WMILT algorithm works for objects with not

much scale change.

2.1 Bi-linear Interpolation

Interpolation is the basic approach to the problem of

object tracking. In simple terms, the linear interpo-

lation of two known points given by the coordinates

VISAPP 2017 - International Conference on Computer Vision Theory and Applications

354

) and (x

) is the straight line between these

points. In the problem of video annotation, the main

criteria is how to decide the key frames. In this ap-

proach the user is asked to annotate every n

frame

and rest of the frames are simply tracked using inter-

polation. There is a trade-off between tracking accu-

racy and annotation cost. Smaller value of n leads to

better track but higher annotation cost.

2.2 Bidirectional WMILT

Weighted Multiple Instance Learning Tracker

(WMILT) (Zhang and Song, 2013) integrates the

sample importance into the learning procedure. A

bag probability function is used to combine the

weighted instance probability. The algorithm weighs

the positive instances according to their importance

to the bag probability, it assumes that the weight for

the instance near the target location is larger than that

far from the target location.

The algorithm relies on positive and negative sam-

ples. The positive samples and negative samples are

separated into two bags. The initialized target is la-

beled as positive. The contribution of each positive

sample is calculated using a monotone decreasing

function with respect to the Euclidean distance be-

tween the locations of sample and target. In this way

the tracker integrates the sample importance into the

learning procedure.

Intuitively, all the instances in the negative bag

are very far and completely dissimilar to the target.

Therefore, the algorithm treats all negative instances

to contribute equally to the negative bag. Finally, a

bag log-likelihood function is used to ﬁnd the instance

for which the probability is maximized. The algo-

rithm efﬁciently integrates the sample importance into

the learning procedure to detect the similar sized tar-

get in rest of the image sequence. We have used the

algorithm to detect the object location both in back-

ward as well as forward image sequence resulting in

higher tracking accuracy.

2.3 Bidirectional DSST

The DSST algorithm (Danelljan et al., 2014) extends

discriminative correlation ﬁlters (Bolme et al., 2010)

to multi-dimensional features for visual object track-

ing. We utilize this method to predict the target lo-

cations in both the temporal directions of the video

sequences, so as to improve the prediction.

The algorithm uses HOG features along with im-

age intensity features. An image is represented as

d-dimensional feature map from which a rectangular

target patch is extracted. An optimum correlation ﬁl-

ter is found by minimizing the cost function. We build

a 3-dimensional scale space correlation ﬁlter for scale

invariant visual object tracking. The ﬁlter size is ﬁxed

to M × N × S, where M and N are height and width of

the ﬁlter and S is the number of scales. A feature pyra-

mid is constructed from a rectangular area around the

target and the pyramid is centered at the target’s loca-

tion and scale. A 3-dimensional Gaussian function is

then used to get the desired correlation output.

This correlation ﬁlter is used to track the target

both in previous and next frames of the image se-

quence. Given a new frame, a rectangular cuboid of

size M × N × S is extracted from the feature pyramid.

Similar to above, the cuboid is centered at the pre-

dicted location and scale of the target. We compute

the correlation scores and the new target location and

scale is obtained by ﬁnding the maximum score.

3 ACTIVE LEARNING

BASELINES

Generally, annotating massive videos is extremely ex-

pensive. There are hundreds of hours of surveillance

video footage of cars and pedestrians which will re-

quire a lot of human effort to annotate. Currently

video annotations are done typically by having paid

users on Mechanical Turk labeling a set of key frames

followed by linear interpolation (Yuen et al., 2009).

3.1 Interpolation with Key Frame

Selection

We extend the interpolation based tracking by adding

dynamic key frame selection strategy. As discussed

earlier, the interpolation method is highly dependent

on key frame selection interval n. The optimum value

of n vary from object to object. For example, con-

sider an object moving at a constant pace for few

frames and then change speed during later frames.

Such cases makes it hard to ﬁnd a single optimum

value of n for even one object.

A slight modiﬁcation in naive linear interpolation

approach can signiﬁcantly reduce the human efforts.

We have designed a tool that initially asks the user

to annotate ﬁrst and last frame of the video sequence.

the tool calculates the object track using linear inter-

polation. It also gives ﬂexibility to the user to de-

cide which frame to annotate next so as to improve

the tracking accuracy. This avoids the problem that

occurs due to ﬁxing the n for a given object.

Collaborative Contributions for Better Annotations

355

Figure 2: The behavior of proposed method ‘Collaborative Neighborhood Tracker’ in case of occlusion. First frame is the

initialization frame and red bounding boxes are the initial tracking output. The algorithm selects middle frame as the key

frame. After user annotation, the track updates (shown in green). Clearly, the tracking algorithm is handling occlusion well

and the key frame selection is improving the overall track.

3.2 Uncertainty based Active Learning

One of the simplest and most intuitive key frame

selection strategy is uncertainty sampling. In this

method, the algorithm queries the frames about which

the tracker is least certain. in this approach we use

both the tracking algorithms, viz., WMILT and DSST,

separately. For WMILT, we use classiﬁer probabil-

ity as the measure to deﬁne uncertainty. Whereas,

to calculate uncertainty for DSST, we consider both

tracker’s translation and scale correlation conﬁdence

scores. The frame with minimum tracker’s score /

conﬁdence, is considered as the next frame for user

annotation. The tracker’s output is updated after ev-

ery user annotation.

4 COLLABORATIVE TRACKING

We propose a new collaborative approach to improve

tracking accuracy while ensuring minimal user ef-

forts. We use the tracking algorithms described in

section 2 and combine them in a novel way to get an

enhanced hybrid tracking algorithm. The DSST being

scale invariant algorithm is complimentary to WMILT

algorithm which detects similar sized objects. Hence,

a combination of both gives a higher tracking accu-

racy.

4.1 Collaborative Tracker

We have collaborated the two trackers (WMILT and

DSST) into a new tracker named ‘Collaborative

Tracker’. We represent the target as a bounding box

enclosing its spatial extent within a video frame. The

bounding box is represented as a 4-dimensional vec-

tor representing top-left and bottom-right corner co-

ordinates of the target. Let the predicted bounding

boxes of above two trackers be P

and P

. Then the

collaborated output is given by:

= εP

+ (1 − ε)P

(1)

where ε (0 ≤ ε ≤ 1) is the weight assigned to the in-

dividual tracker outputs. The value of ε is ﬁxed at the

start of the annotation. If the size of object across the

whole track is constant and does not vary much, the

value of ε is greater than 0.5 else it is less than 0.5.

We also propose an adaptive frame sampling

scheme which uses active learning to intelligently

asks the human annotator to annotate the target only

in few speciﬁc frames that are likely to improve the

performance. This approach is based on the fact that

for any tracking algorithm, not all the objects/videos

can be treated equally.

The performance of any tracking algorithm can

vary signiﬁcantly depending upon the scenario in the

video. Some objects are comparatively easier to anno-

tate automatically. For example, the frames in which

a person is standing. In such cases, only one frame

initialization might give required track. However, the

more complex scenarios require a lot more annotation

efforts to get the desired track. Thus, the proposed key

frame sampling scheme helps to utilize the annota-

tion efforts on more complex objects (or frames) that

are visually ambiguous, such as occlusions or sudden

change of appearance (see Fig 2).

Suppose at time t, the task is to ﬁgure out the

frame that the user should annotate next. We utilize

the difference in opinion principle to determine the

next frame. The center (C) of the predicted bounding

box (P) is given by:

C =

+ P

(2)

where P

and P

are coordinates of top left corner of

the bounding box and P

and P

are coordinates of

bottom right corner. For a frame i, we determine the

difference in center predictions D

for all three algo-

rithms at time t − 1 using:

= C

t−1

⊕C

t−1

⊕C

t−1

(3)

where,

a ⊕ b ⊕ c = dist(a, b) + dist(b,c) + dist(c, a) (4)

VISAPP 2017 - International Conference on Computer Vision Theory and Applications

356

dist(x,y) is the Euclidean distance between x and y.

Next, we determine the frame that best helps in im-

proving the tracker output for all other frames. We

select the most useful key frame as the frame with

largest center difference as per ‘Query by Commit-

tee’ strategy. The key frame f

at any time t is found

using:

= argmax

) (5)

These key frame annotations are used to track the ob-

ject using different tracking algorithms and ultimately

each track adds up to the accuracy of the ﬁnal output.

Intuitively, the track of an object at a particular frame

is more accurate when the initialization is done in the

near by frame. Therefore, for every frame we use the

tracking output for the iteration where (initialization)

key frame is closest. The tracker output for frame i at

time t (P

) is calculated using Eq1 as:

j =

t−1

argmin

k=1

| f

− i| (6a)

= εP

+ (1 − ε)P

(6b)

The algorithm ﬁnds out most uncertain frame and

asks the user for its annotation. The correction of this

frame results in overall improvement of the tracking

accuracy. Therefore, with every iteration the tracker

improves and the algorithm updates the object posi-

tions, thereby making the prediction more accurate.

4.2 Collaborative Neighborhood

Tracker

In this approach, we consider the uncertainty of tem-

poral neighboring frames to determine the next key

frame. The intuition behind this is that every user

annotation should improve the object location in the

whole video sequence and not just the current frame

(See Fig 3). Thus, we consider the temporal neighbor-

hood center difference along with the current frame’s

center difference to decide the next key frame to be

given for user annotation. This makes our sampling

scheme robust. In this approach, the key frame selec-

tion is done using:

= argmax

(

∑

j=1

ηe

−| j−i|

) (7)

where η is a normalization constant and T is the total

number of frames in the sequence. All the frames in

the sequence are considered in the neighborhood of

every key frame, more closer the neighboring frame

to the key frame the greater is the impact of its cen-

ter difference. Similar to Collaborative Tracker, the

Collaborative Neighborhood Tracker is expected to

(a)

(b)

Figure 3: Importance of consideration of neighborhood

frames while key frame selection. The output of two dif-

ferent trackers are shown in separate color bonding boxes.

To decide next key frame to annotate there are two ways:

(a) Based on tracker disagreement of candidate frame. (b)

Based on tracker disagreement of candidate neighborhood.

Clearly, second scenario is better to be given to user for an-

notation. User annotation of its third frame will update the

tracking output of neighbors as well resulting in better track

and more reduction in error.

become more accurate with each user annotation. In

this case, the improvements are expected to be more

because the selection of key frame is based on col-

lective uncertainty of temporal neighborhood making

the selection process more informative. Finally, Eq 6

is used to give the ﬁnal track of the object.

5 EXPERIMENTS

We have performed multiple experiments on eight dif-

ferent publicly available datasets and show the effec-

tiveness of the proposed algorithm in various scenar-

ios.

5.1 Datasets and Evaluation Measures

We have used 17 sequences from standard track-

ing datasets like ETH-Bahnhof, ETH-Jelmoli,

ETH-Sunnyday, TUD-Campus, TUD-Crossing, TUD-

Stadmitte, David, Couple, etc. to evaluate the

performance of the proposed technique. The video

sequences pose several challenges such as illumina-

tion changes, size and pose changes, motion blurs,

partial and full occlusions etc. to tracking algorithms.

We have selected the following criteria to measure

the performance and provide comparisons among dif-

ferent tracking algorithms.

Average Error. Average Error is the mean of differ-

ence between each side of the bounding box gener-

ated by the tracker {(x

),(x

)} and the ground

truth {(x

),(x

)}.

Collaborative Contributions for Better Annotations

357

Figure 4: Change in Average Error with the number of user

annotations for Liner Interpolation and Key Frame Selec-

tion(M1) for TUD-Campus(2) and TUD-Crossing(8).

AvgError = (|x

− x

| + |x

− x

| + |y

− y

| + |y

−

|)/4.

Edge Error. An edge error occurs if the difference

between an edge of the bounding box generated by

the tracker and the ground truth is more than 5 pixels,

i.e., if |e

Tracker

− e

| ≥ 5 then edge error is 1 else 0

(where, e

Tracker

are edges of tracker and ground

truth). The edge error is then summed up for all 4

edges of the bounding box.

Centroid Error: Centroid Error is the Euclidean dis-

tance between centroids of bounding boxes of the

tracker and the ground truth. Centroid error is cal-

culated as

( ¯c

− c

)

+ ( ¯c

− c

)

, where, ( ¯c

, ¯c

)

are ground truth centroid coordinates and (c

, c

) are

tracker centroid coordinates.

5.2 Comparison of various Active

Learning Strategies

The main aim of video annotation framework is to

generate the track for different objects with minimal

user interaction. In this section we describe several

experiments to show the effectiveness of the proposed

algorithm. We have referred Key Frame Selection as

M1, Uncertainty (WMILT) as M2, Uncertainty (DSST)

as M3, Collaborative Tracker (proposed approach) as

M4 and Collaborative Neighborhood Tracker (pro-

posed approach) as M5. Also for datasets we have

used notations, TC for TUD-Campus, TCr for TUD-

Crossing, EJ for ETH-Jelmoli, ES for ETH-Sunnyday

and EB for ETH-Banhof. As mentioned earlier the

value of ε depends on the variations in the size of ob-

ject across the whole track. We have used different

values of ε for each object in the dataset. For objects

such as ETH-Banhof(2,3) where the variation in object

size is much we have used lower values (0.20, 0.22),

where as, for objects like Couple and David the value

of ε is higher (0.75,0.80).

In this experiment we compare the traditional an-

notation technique with the active based method. Ex-

isting video annotation framework (Yuen et al., 2009)

typically have users labeling frames at regular inter-

vals followed by linear interpolation. Fig 4 shows

the decrease in average error with increase in number

of user annotations for Linear Interpolation and Key

Frame Selection(M1). Clearly, the decrease in error

shows that the active learning based solution is better

than traditional annotation technique.

In this experiment, we show that the proposed

tracker is suitable for mission critical applications like

automotive surveillance. For such applications limb

precision is very important. The limb precision of an

algorithm can be captured accurately using the edge

error. Thus, the aim is to calculate the number of

user annotations required by different algorithms to

get an ‘Edge Error’ less than 1 per frame. A better

algorithm should achieve this error rate with mini-

mum possible user annotations. Table 1 shows the

number of user annotations required to get an edge

error less than 1 per frame for different active learn-

ing algorithms. We observe that our proposed method

‘Collaborative Neighborhood Tracker’ (M5) consis-

tently outperforms all other approaches. This is due

to the incorporation of temporal neighborhood infor-

mation into key frame sampling scheme. Notice that,

‘Collaborative Tracker’ (M4) which lacks neighbor-

hood information performs better than M1, M2 and

M3 conﬁrming that our hybrid tracker is more accu-

rate than individual trackers.

Fig 2 shows the behavior of proposed method

(M5) in case of occlusion. The algorithm intelligently

selects the key frame so as to improve the overall

track. Clearly, the tracking algorithm is improving

after every user annotation.

Another important measure to decide the effec-

tiveness of any object detection framework is the ‘Av-

erage Error’. The annotation algorithm having least

average error after a certain number of user annota-

tions is the better one. Table 2 shows the average er-

ror achieved by different annotation algorithms with

same number of user interactions. Clearly, the pro-

posed method (M5) is performing better than other

annotation algorithms. We are able to achieve nearly

half error with same user efforts then the other ap-

proaches.

Centroid Error measures the precision of the cen-

ter of the bounding box. For every good annotation

algorithm the centroid of trackers output should be

as close as possible to the center of the ground truth.

In this experiment we have measured the centroid er-

ror precision for different active learning strategies

on three datasets namely TUD-Crossing, ETH-Jelmoli

and ETH-Sunnyday. We have aggregated the centroid

errors for all the object after each user annotation to

check the convergence of these algorithms. Fig 5

shows the change in ‘Centroid Error’ with increasing

VISAPP 2017 - International Conference on Computer Vision Theory and Applications

358

(a) (b) (c)

Figure 5: Change in ‘Centroid Error’ with increasing user annotations for (a) TUD-Crossing, (b) ETH-Jelmoli and (c) ETH-

Sunnyday datasets. Clearly, error for our proposed algorithms ‘Collaborative Tracker’ and ‘Collaborative Neighborhood

Tracker’ is decreasing faster than other annotation algorithms.

Table 1: The number of user annotations required to get an

edge error less than 1 per frame. The value in the parenthe-

sis indicates the object ID. The best results are reported in

bold.

Objects

Active Learning Approaches

M1 M2 M3 M4 M5

TC(2) 12 15 10 6 7

TCr(1) 7 13 5 3 2

TCr(5) 10 20 15 13 12

TCr(8) 16 22 19 15 12

EB(2) 12 18 8 11 7

EB(3) 12 20 7 7 5

EJ(1) 9 14 3 2 2

EJ(2) 8 12 4 2 2

EJ(5) 9 17 5 6 4

ES(2) 9 14 6 5 4

ES(5) 24 20 18 16 15

ES(12) 8 15 9 7 5

ES(34) 7 10 8 7 6

Couple 41 28 11 9 7

David 12 15 11 9 8

Total 196 253 139 118 98

user annotations for different datasets. Clearly, error

for our proposed algorithms ‘Collaborative Tracker’

and ‘Collaborative Neighborhood Tracker’ is decreas-

ing faster than other annotation algorithms.

Another major concern while doing large scale

video annotation is the scalability of the annotation

algorithm. The annotation cost increases signiﬁcantly

for videos with larger duration. For these experiments

Table 2: Average error(rounded to nearest integer) achieved

by different annotation algorithms after 5 user annotations.

The value in the parenthesis indicates the object ID. The

better algorithm should achieve less error in same number

of user annotations.

Objects

Active Learning Approaches

M1 M2 M3 M4 M5

TC(2) 205 206 175 159 157

TCr(1) 176 224 147 148 105

TCr(5) 485 815 525 398 426

TCr(8) 908 937 816 713 701

EB(2) 485 887 427 398 381

EB(3) 288 305 209 164 128

EJ(1) 85 224 77 70 56

EJ(2) 104 314 99 88 80

EJ(5) 206 447 266 193 187

ES(2) 222 487 286 199 184

ES(5) 3277 1889 1756 1487 1401

ES(12) 418 725 300 263 233

ES(34) 195 400 153 171 146

Couple 2099 1204 1644 1140 934

David 3962 1742 921 1258 880

Total 13122 10811 7807 6852 6005

we have taken objects (multiple datasets) of varied

length and calculated the number of user annotations

required to get a satisfactory track (Average error less

than 5 pixels per frame). From ﬁg 6, the perfor-

mance difference is high for objects that are present

for larger number of frames which shows that the pro-

posed method is effective for both short as well as

Collaborative Contributions for Better Annotations

359

Figure 6: The number of user annotations required by ob-

jects of different length to achieve average error less than 5

pixel per frame. Clearly, M4 and M5 (proposed methods)

requires signiﬁcantly less user efforts especially for objects

with longer video sequences.

long video sequences. This shows that the proposed

approach is highly scalable.

Thus, from above experiments it is clear that using

the proposed approach user efforts required for video

annotations can be reduced to 50%. Also, the method

is scalable and robust to challenges like occlusion.

6 CONCLUSION

In this paper, we propose an efﬁcient and accurate

method to effectively annotate huge video sequences

with minimal user efforts. The approach is suitable

for generating large annotated datasets for mission

critical applications like surveillance and autonomous

driving. We effectively utilize the active learning ap-

proach to decide the best selection of key frames.

This makes our approach scalable to generate huge

annotations for large scale surveillance and automo-

tive related videos with substantial reduction in hu-

man efforts. We have veriﬁed that using the proposed

approach, annotation efforts can be reduced to half

while maintaining the track quality.

REFERENCES

Angela, Y., Juergen, G., Christian, L., and Luc, Van, G.

(2012). Interactive object detection. CVPR.

Bolme, a. S., Beveridge, J. R., Draper, B. A., and Lui, Y. M.

(2010). Visual object tracking using adaptive correla-

tion ﬁlters. CVPR.

Chatterjee, M. and Leuski, A. (2015). CRMActive: An ac-

tive learning based approach for effective Video anno-

tation and retrieval. ICMR.

Danelljan, M., Haumlger, G., Shahbaz Khan, F., and Fels-

berg, M. (2014). Accurate scale estimation for robust

visual tracking. BMVC.

Deng, J., Dong, W., Socher, R., Li, L.-J., Li, K., and Fei-

Fei, L. (2009). Imagenet: A large-scale hierarchical

image database. CVPR.

Fergus, R., Weiss, Y., and Torralba, A. (2009). Semi-

supervised learning in gigantic image collections.

NIPS.

Gray, D., Brennan, S., and Tao, H. (2007). Evaluating ap-

pearance models for recognition, reacquisition, and

tracking. PETSW.

oferlin, B., Netzel, R., H

oferlin, M., Weiskopf, D., and

Heidemann, G. (2012). Inter-active learning of ad-hoc

classiﬁers for video visual analytics. VAST.

Kavasidis, I., Palazzo, S., Di Salvo, R., Giordano, D., and

Spampinato, C. (2012). A semi-automatic tool for de-

tection and tracking ground truth generation in videos.

VIGTAW.

Lee, Jae, Y., and Grauman, K. (2011). Learning the

easy things ﬁrst: Self-paced visual category discov-

ery. CVPR.

Oh, S. and et. al. (2011). A large-scale benchmark dataset

for event recognition in surveillance video. CVPR.

Russell, B. C., Torralba, A., Murphy, K. P., and Freeman,

W. T. (2008). Labelme: A database and web-based

tool for image annotation. IJCV.

Thomas, D., Bogdan, A., and Ferrari, V. (2010). Localizing

objects while learning their appearance. ECCV.

Vondrick, C., Patterson, D., and Ramanan, D. (2013). Ef-

ﬁciently scaling up crowdsourced video annotation.

IJCV.

Vondrick, C. and Ramanan, D. (2011). Video annotation

and tracking with active learning. NIPS.

Yuen, J., Russell, B., Liu, C., and Torralba, A. (2009). La-

belme video: Building a video database with human

annotations.

Zha, Z. J., Wang, M., Zheng, Y. T., Yang, Y., Hong, R., and

Chua, T. S. (2012). Interactive video indexing with

statistical active learning. Transactions on Multime-

dia.

Zhang, K. and Song, H. (2013). Real-time visual tracking

via online weighted multiple instance learning. Pat-

tern Recognition.

Zhong, D. and Chang, S.-F. (2001). Structure analysis of

sports video using domain models. International Con-

ference on Multimedia and Expo.

Zhong, H., Shi, J., and Visontai, M. (2004). Detecting un-

usual activity in video. CVPR.

Zhou, H., Yuan, Y., and Shi, C. (2009). Object tracking

using sift features and mean shift. Computer vision

and image understanding.

VISAPP 2017 - International Conference on Computer Vision Theory and Applications

360
