On using Sarkar Metrics to Evaluate the Modularity of Metamodels

Georg Hinkel

and Misha Strittmatter

Software Engineering Division, FZI Research Center of Information Technologies, Karlsruhe, Germany

Software Design & Quality Group, Karlsruhe Institute of Technology, Karlsruhe, Germany

Keywords:

Metamodel, Modularity, Metric.

Abstract:

As model-driven engineering (MDE) gets applied for the development of larger systems, the quality assurance

of model-driven artifacts gets more important. Here, metamodels are particularly important as many other

artifacts depend on them. Existing approaches to measure the modularity of metamodels have not been vali-

dated for metamodels thoroughly. In this paper, we evaluate the usage of the metrics suggested by Sarkar et

al. to automatically measure the modularity of metamodels with the goal of automated quality improvements.

For this, we analyze the data from a previous controlled experiment on the perception of metamodel quality

with 24 participants, including both students and academic professionals. From the results, we were able to

statistically disprove even a slight correlation with perceived metamodel quality.

1 INTRODUCTION

Metamodels are a central artifact of model-driven en-

gineering as many other artifacts depend on them. If

a metamodel contains design ﬂaws, then presumably

all other artifacts have to compensate for them. It is

therefore very important to detect such design ﬂaws

as early as possible.

In object-oriented programming, several ap-

proaches exist to detect design ﬂaws and can be cate-

gorized into (anti-)patterns and metrics. Antipatterns

are commonly used, for example as code smells. If

an antipattern can be found in the code, there is a

high defect probability and the smell may be avoid-

able through better design. On the other hand, met-

rics have been established to monitor the complexity

of object-oriented design not captured by smells such

as the depth of inheritance or lines of code.

In prior work (Hinkel et al., 2016b), we have iden-

tiﬁed modularity as a quality attribute of metamod-

els that has a signiﬁcant inﬂuence on the perception

of metamodel quality alongside correctness and com-

pleteness. While the latter are hard to measure, met-

rics exist in object-oriented design to measure modu-

larity.

Metamodels essentially describe type systems just

as object-oriented designs do using UML models. In

fact, the differences between usual class diagrams and

formal metamodels lies mostly in the degree of for-

malization and how the resulting models are used.

Whereas UML models of object-oriented design are

often used only for documentation or to generate code

skeletons, metamodels are usually used to generate

a multitude of artifacts such as serialization and ed-

itors. But like class diagrams, metamodels can be

structured in packages, which makes it appealing to

apply the same metrics to measure metamodel modu-

larity as also used for class diagrams.

Metrics make it viable to automate ﬁxing design

ﬂaws through design space exploration of possible

semantics-preserving operations. Such an optimiza-

tion system repeatedly alters the metamodel randomly

in several places and outputs the version that scores

best according to the metrics (or outputs all versions

along the Pareto-front if multiple metrics are used).

For modularity, this is practical as e.g. the module

structure can be easily altered without changing the

metamodels’ semantics. For such an auto-tuner to

produce meaningful results, the underlying metrics

must have a clear and validated correlation to modu-

larity. Otherwise, it is not clear that the outcome of the

auto-tuner is better than the previous one. However,

such a validation of correlations of metrics to quality

attributes is hard as one has to consider consequences

of metamodel design on all dependent artifacts. To

the best of our knowledge, this rarely has been done

before.

In the Neurorobotics-platform developed in the

scope of the Human Brain Project (HBP), these de-

pendent artifacts include not only editors, but also

Hinkel G. and Strittmatter M.

On using Sarkar Metrics to Evaluate the Modularity of Metamodels.

DOI: 10.5220/0006105502530260

In Proceedings of the 5th International Conference on Model-Driven Engineering and Software Development (MODELSWARD 2017), pages 253-260

ISBN: 978-989-758-210-3

253

an entire simulation platform where the connection

between robots and neural networks is described in

models (Hinkel et al., 2015; Hinkel et al., 2016a). As

the HBP is designed for a total duration of ten years,

it is likely that the metamodel will degrade unless ex-

tra effort is spent for its refactorings (Lehman, 1974;

Lehman et al., 1997). For such refactorings, we aim to

measure their success and potentially automate them.

Given the similarity of metamodels to object-

oriented design, we think that metrics for object-

oriented design are good starting points when trying

to measure the quality of metamodels. In particular,

the set of metrics developed by Sarkar (Sarkar et al.,

2008) have been established to measure the quality of

modularization. All of the metrics are scaled to have

values between 0 and 1, where 0 always is the worst

and 1 the best value. This handyness has given these

metrics some popularity.

In this paper, we have picked the metrics by Sarkar

and analyze whether they can be applied to metamod-

els. We analyze how the values for these metrics cor-

relate with perceived metamodel quality and/or meta-

model modularity.

The remainder of this paper is structured as

follows: Section 2 analyzes the Sarkar metrics

and presents adoptions for metamodels. Section 3

presents the setup of the empirical experiment that we

use to validate these metrics to measure metamodel

modularity. Section 4 presents the results from this

experiment. Section 5 discusses threats to validity of

the results. Finally, Section 6 discusses related work

before Section 7 concludes the paper.

2 SARKAR METRICS TO

MEASURE METAMODEL

QUALITY

In this section, we analyze which Sarkar metrics

can be used to measure metamodel modularity, but

only from an applicability point of view. That is,

many of the metrics need adjustments to be applied

to metamodels or cannot be applied at all. We base

this discussion on the Essential Meta Object Facility

(EMOF) standard, especially on its implementation in

Ecore, to describe the structure of metamodels.

An adaptation is necessary because the Sarkar

metrics require an implementation of the object-

oriented system under observation. They operate on

an executable method speciﬁcation that allows them

to retrace how classes in the object-oriented design

are used. Furthermore, they rely on interface concepts

such as APIs that exist in many object-oriented pro-

gramming languages but are omitted in many meta-

metamodels. Our goal is to provide metrics to support

the metamodel design process where no implementa-

tion in the form of transformations, analyses or other

artifacts are available.

In the remainder of this section, we discuss the

inheritance-based coupling metric IC in Section 2.1,

the association-based coupling metrics AC in different

variants in Section 2.2 and the size uniformity metrics

MU and CU in Section 2.3. In Section 2.4, we discuss

the (in-)applicability of the other metrics and present

a new proposed metric to measure the degree of mod-

ularization.

2.1 Inheritance-based Coupling

One of the metrics by Sarkar et al. is the

Inheritance-Based Intermodule Coupling IC. It mea-

sures inheritance-based coupling between packages

based on three different rationales, represented by

sub-metrics IC

− IC

. The ﬁrst metric IC

measures

for a package p the fraction of other packages p

who

are coupled to p by including a class that inherits from

a class in p. Conversely, IC

measures the fraction of

classes outside the package p that inherit from a class

in p. The third component IC

measures the fraction

of classes of p that have base classes in another pack-

age. The components are combined by simply taking

the minimum value for each of the components for

each package. A formal deﬁnition is given in Fig-

ure 1.

There, C deﬁnes the set of all classes, P de-

ﬁnes the set of all packages and the predicates

C, Module, Par and Chlds depict the classes of a

package, the package of a class, the parent classes and

the derived classes of a class. IC

and IC

are set to 1

if the metamodel only consists of a single package.

While all of the components for IC can be eval-

uated for metamodels as well, especially the compo-

nent IC

yields a large problem. Many metamodels

use a single base class to extract common functional-

ity. An example for this is the support for stereotypes

that can be implemented using a common base class

EStereotypeableObject (Kramer et al., 2012), sep-

arated in its own module. However, using such an

approach means immediately that the component IC

constantly equals zero. Therefore, we excluded the

component IC

from the composite metric IC.

IC(p) = min{IC

(p), IC

(p)}.

As in the proposal of Sarkar et al., inheritance-

based coupling for an entire metamodel simply is the

average inheritance-based intermodule coupling of its

packages.

MODELSWARD 2017 - 5th International Conference on Model-Driven Engineering and Software Development

254

(p) = 1 −

|{p

∈ P |∃

d∈C(p

)

∃

c∈C(p)

(c ∈ Chlds(d) ∧ p 6= p

)}|

|P | − 1

(p) = 1 −

|{d ∈ C |∃

c∈C(p)

(c ∈ Chlds(d) ∧ p 6= Module(d))}|

|C |− |C(p)|

(p) = 1 −

|{c ∈ C |∃

d∈Par(c)

(Module(d) 6= p)}|

|C(p)|

IC(p) = min{IC

(p), IC

(p)}

Figure 1: Formal deﬁnition of inheritance-based coupling.

2.2 Association-based Coupling

Similar to the inheritance-based coupling, Sarkar also

deﬁnes the association-based intermodule coupling

AC based on the usage of classes from a different

module in the public API of a class. Translating

the public API to the set of features of a class, this

can be applied to metamodels as well where a us-

age is deﬁned as including a reference to the used

class. Here, metamodels offer to distinguish between

multiple types of associations. Unlike usual object-

oriented platforms, metamodels draw a big differ-

ence between regular associations and composite ref-

erences, in Ecore called containments. Thus, we com-

pute three association-based coupling indices, one for

associations only, one for composite references and

lastly one for both of them together.

Like IC, the composite metric AC as deﬁned by

Sarkar et al. consists of three components AC

, AC

and AC

. Their deﬁnition is equivalent to the deﬁni-

tion of IC

, IC

and IC

except that they are using the

predicate Uses instead of Chlds and Par that yields

the set of used classes for a given class.

We adjust the metrics by altering the semantics of

the usage predicate. The closest adoption of AC is

to use the types of references as usages, but we also

obtain the metric AC

cmp

by limiting the usage to com-

posite and container references and omitting all re-

maining non-composite cross-references.

This distinction is useful as composite refer-

ences have a very different characteristics than cross-

references in many meta-metamodels such as Ecore,

which is widely used in the model-driven community.

The largest difference probably is that composite ref-

erences determine the lifecycle of referenced model

elements. Container references are just the opposites

of composite references and thus AC

cmp

also takes

these into account automatically.

Opposite references introduce a strong coupling

between their declaring classes not only if they are

containment references. If a reference is set for one of

these classes, this implies that the opposite reference

is set for the target value as well. Therefore, we have

separated a third variant of the AC metric that only

measures the association-based coupling introduced

by opposite references AC

2.3 Size Uniformity

The size-uniformity metrics MU and CU relate the

mean size of modules and classes to the standard de-

viation and are deﬁned as follows:

{MU,CU} =

{p,c}

+ σ

{p,c}

Here, µ

{p,c}

and σ

{p,c}

denote the mean value and

standard deviation for the size of packages in terms

of number of classes contained in a package (MU:

, σ

) or the size of classes in terms of number of

methods or lines of code (CU: µ

, σ

). While the

number of classes of a package can be measured for

metamodels as well, the number of methods for a

metamodel is usually meaningless since metamodels

rather concentrate on the structural features, i.e. at-

tributes and references. Also the lines of code for a

class is not applicable since metamodels are often not

deﬁned in textual syntaxes.

Therefore, we adapt the uniformity for classes in

that we take the number of structural features as they

make up the essential parts of a model class, in our

opinion.

2.4 Other Metrics

The remaining metrics deﬁned by Sarkar et al. are

not applicable for metamodels, at least not in an early

stage of development when no subsequent artifact is

available. They may be applicable if e.g. analyses

or transformations based on this metamodel are taken

into account. An overview of these metrics and an

analysis whether they are applicable for metamodels

is depicted in Table 1.

As we do not have an implementation to analyze,

the metrics MII, NC, NPII, SAV I, PPI and APIU are

On using Sarkar Metrics to Evaluate the Modularity of Metamodels

255

Table 1: Summary of the Sarkar metrics with original rationale (Sarkar et al., 2008) and analysis whether they are suited to

measure metamodel modularity.

Metric Rationale Suited

MII Is the intermodule method call trafﬁc routed through APIs? No

NC To what extent are the non-API methods accessed by other mod-

ules?

BCFI Does the fragile base class problem exist across the modules? No

IC To what extend are the modules coupled through inheritance? Yes

NPII To what extend does the implementation code in each class pro-

gram to the public interfaces of the other classes?

AC To what extend are modules coupled through association? Yes

SAV I To what extend do the classes directly access the state in other

classes?

MU To what extend are the modules different in size? Yes

CU To what extend are the classes different in size? Yes

PPI How much superﬂuous code exists in a plugin module? No

APIU Are the APIs of a module cohesive from the standpoint of sim-

ilarity of purpose and to what extend are the clients of an API

segmented?

CReuM To what extend are the classes that are used together also

grouped together in the same module?

not applicable for metamodels. Furthermore, BCFI is

not applicable as the underlying problematic "Fragile

Base Class Problem" is not possible if method con-

tents are not considered. Likewise, we do not have

any information what classes are used together as we

want to apply the metrics already during the meta-

model development. This makes the metric CReuM

also not applicable.

3 EXPERIMENT SETUP

To evaluate the goodness-of-ﬁt of the presented

Sarkar metrics to measure metamodel modularity, we

used the data collected from a previous controlled

experiment on metamodel quality perception (Hinkel

et al., 2016b). In this experiment, participants were

asked to manually asses the quality of metamodels

created by peers. The material – domain descriptions,

assessments and created metamodels – are publicly

available online

. Due to space limitations, we there-

fore only replicate a very short description of the ex-

periment.

The 24 participants created metamodels for two

domains. Each domain was described in a text and

the participants were asked to design a metamodel

according to it. The participants consisted of profes-

sional researchers as well as students from a practical

course on MDE. They were randomly assigned to the

domains, ensuring a balance between the domains.

https://sdqweb.ipd.kit.edu/wiki/Metamodel_Quality

The ﬁrst domain concerned user interfaces of mo-

bile applications. Participants were asked to create

a metamodel that would be able to capture designs

of the user interface of mobile applications so that

these user interface descriptions could later be used

platform-independently. The participants created the

metamodel according to a domain description in nat-

ural language from scratch. We refer to creating the

metamodel of this mobile applications domain as the

Mobiles scenario.

The second domain was business process model-

ing. Here, the participants were given a truncated

metamodel of the Business Process Modeling Lan-

guage and Notation (BPMN) (The Object Manage-

ment Group, 2011) where the packages containing

conversations and collaborations had been removed.

The task for the participants was to reproduce the

missing part of the metamodel according to a textual

description of the requirements for the collaborations

and conversations. We refer to this evolution task as

the BPMN scenario in the remainder of this paper.

To evaluate our adoptions of the Sarkar metrics to

measure the quality of metamodel modularity, we cor-

related the metric results with the manual modularity

assessments and applied an analysis of variance. That

is, we try to statistically prove that metric results and

metamodel modularity are connected.

MODELSWARD 2017 - 5th International Conference on Model-Driven Engineering and Software Development

256

4 RESULTS

We correlated the manual quality assessments with

the metric results for the metamodels created by the

experiment participants. The discussion of the results

is split into three sections, one for each of the scenar-

ios and a third for discussion.

4.1 Mobiles

The results correlating the metric results against man-

ually assessed metamodel quality perceptions are de-

picted in Table 2. To get a quicker overview, we have

printed strong correlations (|ρ| > 0.5) in bold. For the

metric AC

, no correlations are shown as the metric

values do not have a variance, i.e. no metamodel con-

tained opposite references across package boundaries.

Table 2: Correlations of metric results to quality attribute

assessments in the Mobiles and BPMN scenario. Strong

correlations (|ρ| > 0.5) are printed in bold.

Mobiles BPMN

Quality

Modularity

Quality

Modularity

IC -0.28 -0.43 0.08 0.45

AC -0.21 -0.46 0.12 0.48

cmp

-0.20 -0.45 0.06 0.59

AC(op) – – 0.23 0.64

MU -0.24 -0.76 0.38 -0.32

CU 0.73 0.35 0.16 0.35

A surprising result is that all of the coupling-based

Sarkar metrics have a negative correlation with mod-

ularity, among many other negative correlations to

other quality attributes. This is due to the fact that

these metrics only measure the quality of a modular-

ization, but not its degree. In particular, metamod-

els with only one package get the maximum score of

1 for inheritance- and association-based coupling in-

dices as there are no inheritance or association rela-

tions to other packages. However, such a metamodel

is perceived as not modular as there is no modulariza-

tion involved.

Using the Fisher transformation based on 14 ob-

servations and applying the Bonferroni method to

control the family-wise error-rate, we can reject the

null-hypothesis that the true correlation of a given

metric with modularity is at least 0.3 on a 95% conﬁ-

dence level when the correlation is lower than -0.39.

Besides CU, this is the case for all Sarkar metrics. For

MU, we can even reject this hypothesis at a 99.9%

conﬁdence level.

The module uniformity metric MU shows the

strongest negative correlations not only to modular-

ity but also to changeability and transformation cre-

ation. The reason for this is the same as for the

coupling-based metrics: Those participants that were

not aware of the beneﬁts of a good modularization of-

ten also failed in other aspects and therefore created

metamodels that are hard to read. But unlike the cou-

pling metrics where a value of 1 can also be achieved

through a high quality modularization, it is highly un-

likely for metamodel developers to create perfectly

balanced modules, in particular because many meta-

models contain modules that are only used to give a

structure but do not contain any classes.

Despite it only being a corner case, the case of

lacking modularization is very important. The reason

is the automated refactoring, we envisioned in the in-

troduction. Such an approach requires the underlying

metrics to be robust against lacking modularization.

Otherwise, the obtained results will always be mono-

lithic metamodels, i.e. all classes put into a single

package.

Interestingly, the class uniformity metric CU has

strong correlations to a range of quality attributes,

but not to modularity as one might have expected.

A uniform class design correlated strongly with con-

sistency, completeness, correctness, instance creation

and ultimately also overall quality. A potential rea-

son is that in object-oriented code, many bad smells

such as god classes manifest in single classes having

far more members than others, so one may suspect

causality here. While we agree that CU can be a suit-

able metric for consistency, we think that the correla-

tions to completeness and correctness are rather intro-

duced by the fact that the most complete and correct

metamodels were created presumably by the most ex-

perienced participants that also had an eye on consis-

tency.

4.2 BPMN

In this section, we validate the applicability of the

metrics in the BPMN scenario. Despite the fact that

the participants have only evaluated manual exten-

sions, the metric results were taken from the complete

metamodels, also taking into account the larger part

of the metamodel that had not been changed. While

this means that the metric values may not be com-

pared across scenarios, the inﬂuence on correlations

is limited. Furthermore, we do think that this better

represents an evolution scenario which is more com-

mon than creating a metamodel from scratch.

Besides, it is also not trivial to identify the relevant

subset of a metamodel that should be evaluated. Even

On using Sarkar Metrics to Evaluate the Modularity of Metamodels

257

though a major part of the metamodel was not modi-

ﬁed by the participants of the experiment, the created

extension had references and inheritance relations to

the rest of the metamodel such that this could not be

ignored easily by the metrics.

●

●●

0.885 0.895

−4 −2 0 2 4

Modularity

(a) Inheritance-based coupling

●

●●

0.855 0.865 0.875 0.885

AC(cmp)

−4 −2 0 2 4

Modularity

(b) Association-based coupling

Figure 2: Coupling metrics plotted against the perceived

modularity.

We can see that the inheritance- and association-

based coupling metrics correlate with modularity, but

this correlation is not so strong and for both IC and

AC, the correlation coefﬁcient is below 0.5. Espe-

cially the association-based coupling has a stronger

correlation to consistency than to modularity, al-

though we get a stronger correlation to modularity

if we limit the coupling to containment references.

However, this still gives worse results than restricting

the association to opposite references. The correlation

of AC

cmp

to modularity is signiﬁcant with p = 0.045

in an ANOVA, but does not withstand a correction. A

similar ANOVA for IC yields a p-value of p = 0.14

so that this correlation is not even signiﬁcant on the

10%-level.

The results for inheritance-based and

containment-based coupling are depicted in Fig-

ure 2. As one can see, most metamodels were in

a small range of metric values achieved for the

inheritance-based coupling. However, the one meta-

model that received a much higher score was also

perceived as most modular.

The best results have been achieved by restrict-

ing the association-based coupling to opposite refer-

ences with a correlation coefﬁcient of ρ = 0.64 and a

p-value of p = 0.024. However, the samples showed

only a very small variance as only two metamodels

had introduced new opposite references, so the sam-

ple size is too small to produce reliable results.

The class size uniformity correlates strongly with

conciseness but in the BPMN scenario had a nega-

tive correlation with consistency. This means that this

metric apparently cannot be used to measure consis-

tency, as suggested from the Mobiles scenario. Like-

wise, the correlation to conciseness is not conﬁrmed

by the Mobiles scenario.

4.3 Discussion

The metrics by Sarkar et al. are only meant to mea-

sure the quality of modularization but not the degree

to which a system is modularized. In particular, many

of the metrics, in particular the ones that we adopted

for metamodels as well, yield best results when no

modularization is applied at all. The metrics IC and

AC are set to the maximum and presumably best value

1 in case no package structure has been applied to the

system or in our case the metamodel.

A possible conclusion for metamodel developers

could be that the best modularization can be achieved

simply by putting all classes of a metamodel into a

single package and thus forgetting about packages at

all. There are several examples of larger metamodels

used in both industry and academia that seem to have

adopted this idea as they consist of exactly one pack-

age but this way, developers have to know the entire

metamodel before they can do anything. These ex-

amples include the UML metamodel used by Eclipse

and many component models such as Kevoree (Fou-

quet et al., 2014) or SOFA 2 (Bureš et al., 2006).

On the other hand, if a metamodel consists only

of a single package, developers are aware that they

have to understand the entire metamodel before they

can do anything. This may be better than a poor mod-

ularization where developers may get the impression

that they can neglect some packages which in the end

turns out as wrong, because of complex dependencies

between packages. Therefore, the goal of developers

must be a balance between the degree of modulariza-

tion and its quality.

5 THREATS TO VALIDITY

The internal threats to validity described in the origi-

nal experiment description (Hinkel et al., 2016b) also

apply when using the collected data to validate meta-

model metrics. We do not repeat them here due to

space limitations.

However, a threat to validity arises as we com-

puted the metric values in the BPMN scenario based

on the entire metamodels whereas the participants

were asked to assess the quality speciﬁcally of the

user extensions. Additionally to the problems of al-

ternative approaches we mentioned before, we think

that the threat to the validity is acceptable since corre-

lations coefﬁcients do not change under linear trans-

formations.

We are correlating the metrics results with per-

ceived modularity in order to utilize the wisdom of

our study participants. However, metrics are most

MODELSWARD 2017 - 5th International Conference on Model-Driven Engineering and Software Development

258

valuable if they ﬁnd the subtle ﬂaws that humans do

not perceive in order to raise awareness that there

might be something wrong. Furthermore, the expe-

rience of our experiment participants, especially the

students, may be insufﬁcient.

6 RELATED WORK

The Sarkar metrics have been already validated in

large-scale software systems (Sarkar et al., 2008).

This validation showed that randomly introduced de-

sign ﬂaws could be detected by decreasing metric val-

ues. The goal in our validation, however, is to com-

pare entirely different design alternatives.

Related work in the context of metamodel quality

consists mostly of adoptions of metrics for UML class

diagrams and object-oriented design. However, to the

best of our knowledge, the characterization of meta-

model quality has not yet been approached through

the perception of modeling experts.

Bertoa et al. (Bertoa and Vallecillo, 2010) present

a rich collection of quality attributes for metamodels.

However, as it is not the scope of their work, they

do not give any information how to quantify the at-

tributes.

Ma et al. (Ma et al., 2013) present a quality

model for metamodels. By transferring metrics from

object-oriented models and weighting them, they pro-

vide composite metrics to quantify quality properties.

They calculate these metrics for several versions of

the UML metamodel. However, they do not provide a

correlation between their metrics and quality.

López et al. propose a tool and language to check

for properties of metamodels (López-Fernández et al.,

2014). In their paper, they also provide a catalog

of negative properties, categorized in design ﬂaws,

best practices, naming conventions and metrics. They

check for breaches of ﬁxed thresholds for the same

metrics, but both their catalog and also these thresh-

olds stem from conventions and experience and are

not empirically validated.

Williams et al. applied a variety of size metrics

onto a big collection of metamodels (Williams et al.,

2013). However, they did not draw any conclusions

with regards to quality.

Di Rocco et al. also applied metrics onto a large

set of metamodels (Di Rocco et al., 2014). Besides

size metrics, they also feature the number of isolated

metaclasses and the number of concrete immediately

featureless metaclasses. Based on the characteristics

they draw conclusions about general characteristics of

metamodels. However, to the best of our knowledge,

they did not correlate the metric results to any quality

attributes.

Leitner et al. propose complexity metrics for do-

main models of the software product line ﬁeld as well

as feature models (Leitner et al., 2012). However,

domain models are not as constrained by their meta-

models as it is the case with feature models. The

authors argue, that the complexity of both, feature

and domain models, inﬂuences the overall quality of

the model, but especially usability and maintainabil-

ity. They show the applicability of their metrics, but

do not validate the inﬂuence between the metrics and

quality.

Vanderfeesten et al. investigated quality and de-

signed metrics for business process models (Vander-

feesten et al., 2007). Some of them can be applied to

metamodels or even graphs in general. The metrics

are validated by assessing the relation between metric

results and error occurrences and manual quality as-

sessments (Mendling and Neumann, 2007; Mendling

et al., 2007; Sánchez-González et al., 2010; Vander-

feesten et al., 2008). However, it is subject of fur-

ther research to investigate how these metrics can be

adapted to metamodels.

7 CONCLUSION AND OUTLOOK

The results of this paper suggest that the metrics es-

tablished to measure the quality of modularization in

software systems alone may be misleading. From the

few metrics suggested by Sarkar et al., many were not

applicable to metamodels as they require an existing

implementation and the remaining metrics partially

favor monolithic metamodels over properly modular-

ized ones. As a consequence, no signiﬁcant corre-

lations between these metrics and the manually as-

sessed modularity of metamodels could be observed.

Particularly in the Mobiles scenario, we were even

able to statistically disprove even a slight correlation

of 0.3 between the metric values and the perceived

metamodel, which makes the metrics practically use-

less for the purpose of predicting how the modularity

of a given metamodel is perceived.

This insight raises the question whether there are

there other metrics that correlate with the perception

of metamodel quality. An answer to this question will

improve the understanding on how the modularity of

metamodels is perceived.

ACKNOWLEDGEMENTS

This research has received funding from the European

Union Horizon 2020 Future and Emerging Technolo-

On using Sarkar Metrics to Evaluate the Modularity of Metamodels

259

gies Programme (H2020-EU.1.2.FET) under grant

agreement no. 720270 (Human Brain Project SGA-I)

and the Helmholtz Association of German Research

Centers.

REFERENCES

Bertoa, M. F. and Vallecillo, A. (2010). Quality attributes

for software metamodels. In Proceedings of the

13th TOOLS Workshop on Quantitative Approaches

in Object-Oriented Software Engineering (QAOOSE

2010).

Bureš, T., Hnetynka, P., and Plášil, F. (2006). Sofa 2.0:

Balancing advanced features in a hierarchical compo-

nent model. In Proceedings of the fourth International

Conference on Software Engineering Research, Man-

agement and Applications, pages 40–48. IEEE.

Di Rocco, J., Di Ruscio, D., Iovino, L., and Pierantonio,

A. (2014). Mining metrics for understanding meta-

model characteristics. In Proceedings of the 6th In-

ternational Workshop on Modeling in Software Engi-

neering, MiSE 2014, pages 55–60, New York, NY,

USA. ACM.

Fouquet, F., Nain, G., Morin, B., Daubert, E., Barais, O.,

Plouzeau, N., and Jézéquel, J.-M. (2014). Kevoree

Modeling Framework (KMF): Efﬁcient modeling

techniques for runtime use. Technical report, SnT-

University of Luxembourg.

Hinkel, G., Groenda, H., Krach, S., Vannucci, L., Den-

ninger, O., Cauli, N., Ulbrich, S., Roennau, A.,

Falotico, E., Gewaltig, M.-O., Knoll, A., Dillmann,

R., Laschi, C., and Reussner, R. (2016a). A Frame-

work for Coupled Simulations of Robots and Spiking

Neuronal Networks. Journal of Intelligent & Robotics

Systems.

Hinkel, G., Groenda, H., Vannucci, L., Denninger, O.,

Cauli, N., and Ulbrich, S. (2015). A Domain-Speciﬁc

Language (DSL) for Integrating Neuronal Networks

in Robot Control. In 2015 Joint MORSE/VAO Work-

shop on Model-Driven Robot Software Engineering

and View-based Software-Engineering.

Hinkel, G., Kramer, M., Burger, E., Strittmatter, M., and

Happe, L. (2016b). An Empirical Study on the Per-

ception of Metamodel Quality. In Proceedings of

the 4th International Conference on Model-driven

Engineering and Software Development (MODEL-

SWARD). Scitepress.

Kramer, M. E., Durdik, Z., Hauck, M., Henss, J., Küster,

M., Merkle, P., and Rentschler, A. (2012). Extend-

ing the Palladio Component Model using Proﬁles and

Stereotypes. In Becker, S., Happe, J., Koziolek, A.,

and Reussner, R., editors, Palladio Days 2012 Pro-

ceedings (appeared as technical report), Karlsruhe

Reports in Informatics ; 2012,21, pages 7–15, Karl-

sruhe. KIT, Faculty of Informatics.

Lehman, M., Ramil, J., Wernick, P., Perry, D., and Turski,

W. (1997). Metrics and laws of software evolution-the

nineties view. In Software Metrics Symposium, 1997.

Proceedings., Fourth International, pages 20–32.

Lehman, M. M. (1974). Programs, cities, students: Limits

to growth? (Inaugural lecture - Imperial College of

Science and Technology ; 1974). Imperial College of

Science and Technology, University of London.

Leitner, A., Weiß, R., and Kreiner, C. (2012). Analyzing

the complexity of domain model representations. In

Proceedings of the 19th International Conference and

Workshops on Engineering of Computer Based Sys-

tems (ECBS), pages 242–248.

López-Fernández, J. J., Guerra, E., and de Lara, J. (2014).

Assessing the quality of meta-models. In Proceedings

of the 11th Workshop on Model Driven Engineering,

Veriﬁcation and Validation (MoDeVVa), page 3.

Ma, Z., He, X., and Liu, C. (2013). Assessing the qual-

ity of metamodels. Frontiers of Computer Science,

7(4):558–570.

Mendling, J. and Neumann, G. (2007). Error metrics for

business process models. In Proceedings of the 19th

International Conference on Advanced Information

Systems Engineering, pages 53–56.

Mendling, J., Neumann, G., and Van Der Aalst, W. (2007).

Understanding the occurrence of errors in process

models based on metrics. In On the Move to Meaning-

ful Internet Systems 2007: CoopIS, DOA, ODBASE,

GADA, and IS, pages 113–130. Springer.

Sánchez-González, L., García, F., Mendling, J., Ruiz, F.,

and Piattini, M. (2010). Prediction of business process

model quality based on structural metrics. In Concep-

tual Modeling–ER 2010, pages 458–463. Springer.

Sarkar, S., Kak, A. C., and Rama, G. M. (2008). Metrics

for measuring the quality of modularization of large-

scale object-oriented software. Software Engineering,

IEEE Transactions on, 34(5):700–720.

The Object Management Group (2011). Business process

model and notation 2.0. http://www.bpmn.org/.

Vanderfeesten, I., Cardoso, J., Mendling, J., Reijers, H. A.,

and van der Aalst, W. (2007). Quality metrics for busi-

ness process models. BPM and Workﬂow handbook,

144.

Vanderfeesten, I., Reijers, H. A., Mendling, J., van der

Aalst, W. M., and Cardoso, J. (2008). On a quest for

good process models: the cross-connectivity metric.

In Advanced Information Systems Engineering, pages

480–494. Springer.

Williams, J. R., Zolotas, A., Matragkas, N. D., Rose, L. M.,

Kolovos, D. S., Paige, R. F., and Polack, F. A. (2013).

What do metamodels really look like? In Proceedings

of the ﬁrst international Workshop on Experiences and

Empirical Studies in Software Modelling (EESSMod),

pages 55–60.

MODELSWARD 2017 - 5th International Conference on Model-Driven Engineering and Software Development

260
