Generating a Distilled N-Gram Set

Effective Lexical Multiword Building in the SPECIALIST Lexicon

Chris J. Lu

1,2

, Destinee Tormey

1,2

, Lynn McCreedy

1,2

and Allen C. Browne

National Library of Medicine, Bethesda, MD, U.S.A.

Medical Science & Computing, LLC, Rockville, MD, U.S.A.

Keywords: MEDLINE N-Gram Set, Multiwords, Medical Language Processing, Natural Language Processing, the

SPECIALIST Lexicon.

Abstract: Multiwords are vital to better Natural Language Processing (NLP) systems for more effective and efficient

parsers, refining information retrieval searches, enhancing precision and recall in Medical Language

Processing (MLP) applications, etc. The Lexical Systems Group has enhanced the coverage of multiwords in

the Lexicon to provide a more comprehensive resource for such applications. This paper describes a new

systematic approach to lexical multiword acquisition from MEDLINE through filters and matchers based on

empirical models. The design goal, function description, various tests and applications of filters, matchers,

and data are discussed. Results include: 1) Generating a smaller (38%) distilled MEDLINE n-gram set with

better precision and similar recall to the MEDLINE n-gram set; 2) Establishing a system for generating high

precision multiword candidates for effective Lexicon building. We believe the MLP/NLP community can

benefit from access to these big data (MEDLINE n-gram) sets. We also anticipate an accelerated growth of

multiwords in the Lexicon with this system. Ultimately, improvement in recall or precision can be anticipated

in NLP projects using the MEDLINE distilled n-gram set, SPECIALIST Lexicon and its applications.

1 INTRODUCTION

This section introduces: first, the SPECIALIST

Lexicon; second, the importance of multiwords in

NLP; third, the background and purpose of

developing a new n-gram-based system for building

lexical multiwords.

1.1 The SPECIALIST Lexicon

The SPECIALIST Lexicon, distributed in the Unified

Medical Language System (UMLS) Knowledge

Sources by the National Library of Medicine (NLM),

is a large syntactic lexicon of biomedical and general

English, designed and developed to provide the

lexical information needed for the SPECIALIST

Natural Language Processing System (McCray et al.,

1993). Lexical records are used for part-of-speech

(POS) tagging, indexing, information retrieval,

concept mapping, etc. in many NLP projects, such as

Lexical Tools (McCray et al., 1994), MetaMap

(Aronson, 2001; Aronson and Lang, 2010), cTAKES

(Savova, 2010), Sophia (Divita et al., 2014), gSpell

(Divita et al., 2000), STMT (Lu and Browne, 2012),

SemRep, UMLS Metathesaurus, ClinicalTrials.gov,

etc. It has been one of the richest and most robust NLP

resources for the NLP/MLP community since its first

release in 1994. It is important to keep the Lexicon up

to date with broad coverage to ensure the success of

NLP applications that use it.

Each lexical entry in the Lexicon records the

syntactic, morphological, and orthographic

information needed by the SPECIALIST NLP

System. Terms must meet 3 requirements to qualify

as lexical entries: 1) part-of-speech, 2) inflections,

and 3) a special unit of lexical meaning by

themselves. Linguists in the Lexical Systems Group

(LSG) look at the usage of candidate terms from

various sources to add terms into the Lexicon if the

above three requirements are met. Terms (base forms

and inflectional variants) may be single words or

multiwords - namely words that contain space(s). If it

is a multiword, such as “ice cream” or “hot dog”, it is

called a lexical multiword (LexMultiword or LMW).

Single words in the Lexicon have increased 2.6 times

from 180,468 in 2002 to 468,655 in 2016. These

Lexicon single words cover only about 10.62% of

unigrams (single words) from titles and abstracts in

Lu C., Tormey D., McCreedy L. and Browne A.

Generating a Distilled N-Gram Set - Effective Lexical Multiword Building in the SPECIALIST Lexicon.

DOI: 10.5220/0006142000770087

In Proceedings of the 10th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2017), pages 77-87

ISBN: 978-989-758-213-4

MEDLINE.2016. However, single-word Lexicon

terms comprise 98.42% of MEDLINE unigrams if the

word count (WC) is taken into consideration. In other

words, the current Lexicon has a very high recall rate

of single words in MEDLINE, because most

frequently used single words in MEDLINE are

covered. As for LMWs, we observe a continuous

growth in the Lexicon from 88,324 (32.86%) in 2002

to 446,928 (48.81%) in 2016. Both the high coverage

of existing single words and the trend of increasing

growth of LMWs in the Lexicon lead to our position

that multiword acquisition is key for future Lexicon

building.

1.2 Multiwords in NLP

Multiwords are vital to the success of high quality

NLP applications (Sag et al., 2002; Fraser, 2009).

First, multiwords are ubiquitous. Technical

terminologies in many specialized knowledge

domains, particularly in areas like medicine,

computer science and engineering, are often created

as Multiword Expressions (MWEs) (Frantzi et al.,

2000; Green et al., 2013; Ramisch, 2014). Second,

MWEs are hard to deal with in NLP tasks, such as

identification, parsing, translation, and

disambiguation, not only because MWEs have a large

amount of distinct phenomena, but also due to the

absence of major syntactic theories and semantic

formalisms. Our Lexicon with multiwords remedies

these issues. For example, most NLP applications on

word segmentations are word-oriented

(tokenization), relying on POS taggers, stemmers,

and chunkers to segment each MWE as a phrasal unit

from the sentence. This process can be improved if

multiwords can be identified as a phrasal unit directly

(such as through a Lexicon lookup) and not processed

further by taggers, e.g. phrasal preposition (“because

of”, “due to”), and adverbs (“on time”). Thus, POS

ambiguity can be reduced through identifying the

POS of these MWEs. Third, non-decomposable

MWEs, such as fixed phrases (“kingdom come”, “by

and large”) and idioms (“kick the bucket”, “shoot the

breeze”), are very challenging tasks for NLP

syntactically as well as semantically. While syntactic

aspects of idiom usage necessitates a beyond-Lexical-

level solution to those non-decomposable MWEs,

fixed phrases are handled well as LMWs in our

Lexicon. NLP techniques, such as Query Expansion,

do not work well on fixed-phrase MWEs for concept

mapping, unless they are seen as LMWs. For

example, “hot dog” should not be expanded as “high

temperature canine” to find its concept. Instead, a

direct Lexicon look up of “hot dog” (E0233017)

without further query expansion resolves issues

caused by fixed-phrase MWEs. Furthermore, the

Metathesaurus concept associated with a sentence

often coincides with the longest multiword in the

sentence. This idea is implemented in MetaMap by

identifying the longest LMWs in sentences for

mapped concept ranking. Accordingly, a

comprehensive lexicon with a rich resource of MWEs

is an essential component to a more precise, effective,

and efficient NLP system.

1.3 MWEs and LMWs

Research on Multiword Expressions (MWEs) has

been growing since the late 1990s. State of the art

methods including statistical association measures

(Silva and Lopes, 1999; Fazly et al., 2009; Pecina,

2010), machine learning (Boukobza and Rappoport,

2009; Tsvetkov and Wintner, 2011; Green et al.,

2011), syntactic patterns (Seretan and Wehrli, 2009;

Kim and Baldwin, 2010; Green et al., 2013), web

queries (Takahashi and Morimoto, 2013), semantic

analysis (Pearce, 2001; Baldwin et al., 2003), and a

combination of the above methods (Calzolari et al.,

2002; Bejček et al., 2013; Sangati and Cranenburgh,

2015) are used in MWE research for acquisition,

identification, interpretation, disambiguation and

other applications. Despite a great deal of research on

MWEs, there is no approach that fits perfectly for

building LMWs in the SPECIALIST Lexicon. LMWs

are a subset of MWEs due to our requirements that a

legitimate Lexical entry must have a POS, inflections,

and be a unit of meaning. In short, the broader notion

of MWEs are distinguished from LWMs in four ways.

First, a collocation (an arbitrary statistically

significant association between co-occurring items) is

not necessarily a LMW because it is not necessarily

qualified as a Lexical entry. For example,

“undergoing cardiac surgery” occurs frequently

(3,770 hits in 3,062 documents) in the 2016

MEDLINE n-gram set, but it is not a LMW because

it is not functioning as a special unit of meaning by

itself. Moreover, this collocation is sometimes, but

not always, a single POS. On the other hand, its

subterm, “cardiac surgery”, which occurs frequently

(37,171 hits in 22,404 documents) in MEDLINE, is a

LMW. In other words, frequency alone is not

sufficient to determine if a term is a LMW. For the

same reason, some phrases are not LMWs. For

example, “in the house” is not a LMW while “in

house” is. Second, verb particle constructions are

handled by complementation types (Browne et al.,

2000) in Lexical records to coordinate lexical

meaning with syntactic characteristics of the verb.

HEALTHINF 2017 - 10th International Conference on Health Informatics

For example, “beat someone up” can be constructed

from the Lexical record of “beat”, as shown in Figure

1. Similarly, light verbs that are covered within

Lexical records, such as “make love” and “give birth”,

are included in the Lexical records of “make”

(E0038623) and “give” (E0029785), respectively.

The information on these types of MWEs is stored

inside the Lexical records and they are not considered

LMWs (not a base form or inflectional variants of a

Lexical entry). However, they can be

retrieved/identified by a parser based on the Lexicon.

Third, non-decomposable idioms are beyond the

scope of the Lexicon, such as “kick the bucket” and

“shoot the breeze”. Aligning the syntactic analysis of

idiomatic phrases with their semantic interpretations

is beyond the scope of what a lexicon can accomplish.

Thus, they are not under consideration here. Fourth,

due to the complicated nature of multiwords, much

previous MWE research only focuses on bi-grams or

tri-grams, which do not meet the requirement of

including up to five-grams to reach an estimated

recall value of 99.47% of multiwords (Lu et al.,

2015).

{base=beat

entry=E0012175

cat=verb

intran

intran;part(about)

tran=np

tran=np;part(back)

tran=np;part(up)

tran=np;part(down)

tran=np;part(in)

link=advbl

cplxtran=np,advbl

nominalization=beating|noun|E0219216

}

Figure 1: Lexical record of the verb “beat”.

2 MOTIVATION

Previously, an element word approach (Lu et al.,

2014) was used to build the Lexicon by linguists

through a web-based computer-aided tool, LexBuild

(Lu et al., 2012). Unigrams with high frequency (WC)

from the MEDLINE n-gram set that are not in the

Lexicon were used as element words for finding new

LMW candidates through the Essie search engine (Ide

et al., 2007). There are several issues with this

approach: 1) it is time consuming; 2) multiwords

associated with high frequency element words do not

necessarily have high frequency; 3) new multiwords

associated with processed element words are missed.

If we use the mean value, 65%, as an estimated

multiword ratio based on the empirical measurement

(Ramisch, 2014), it will take more than 21 years for

current LSG staff to add all multiwords to the Lexicon

by this approach (on average, 20,000 terms are added

by LSG staff annually). And this estimate does not

account for the fact that many new multiwords are

continuously being created by biomedical researchers

and English users in general. Thus, we decided to

develop a new system to effectively build LMWs to

the Lexicon by using an n-gram approach. MEDLINE

was chosen as the corpus because it is the biggest and

most commonly used resource in the biomedical

domain. The MEDLINE n-gram set (MNS) was

generated by the following steps: 1) English titles and

abstracts from MEDLINE documents are collected

and then tokenized to sentences and words (tokens);

2) by requirements, the MNS includes up to 5-grams

with information of associated document count (DC)

and word count (WC); 3) n-gram and DC|WC are

used as key and values in Java HashMap class for n-

gram retrieval; 4) due to the large scale, the computer

program for retrieving n-grams exceeds the

maximum keys in the Java HashMap class (2

-1)

when n > 3. Thus, a new model is developed to

resolve this issue. This model involves processes of

splitting, grouping, filtering, combining and sorting

(Lu et al., 2015). The MNS is generated by above

processes and has been distributed annually to the

public since 2014. The MNS provides comprehensive

raw n-gram data from titles and abstracts of

MEDLINE. Due to its large-scale size (> 19M n-

grams), it is difficult to be handled by computer

programs with complicated algorithms. So, a distilled

MEDLINE n-gram set (DMNS), with reduced size,

higher precision and similar recall in terms of LMWs,

is required for the multiword acquisition task and

useful for NLP applications.

3 APPROACH - FILTERS

Filters (exclusive filters) are designed to be applied

on the MNS to generate the DMNS by trapping

invalid LMWs. The design goal of these filters is set

to keep the similar (high) recall rate by not trapping

valid LMWs. Ideally, all valid multiwords should

pass through these filters. The precision of the filtered

n-gram set can be improved significantly by applying

a series of filters with high recall rate. Exclusive

filters are developed based on empirical models with

heuristic rules in this task. They are categorized into

three types as described below. Patterns and trapped

Generating a Distilled N-Gram Set - Effective Lexical Multiword Building in the SPECIALIST Lexicon

examples are illustrated for each filter in the format

of [pattern] and “example” in this paper, respectively.

3.1 General Exclusive Filters

This type of filter is intuitive and based on surface

features of terms. Terms composed merely of certain

characters/words, such as punctuation, digits,

numbers, spaces and stopwords do not meet the

requirement of having a special unit of lexical

meaning to themselves. They are used for the general

purpose of filtering out invalid LMWs:

 Pipe Filter: A term that contains pipe(s) is

trapped because a pipe is used as a field

separator in most NLP systems. Trapped

examples include: “(|r|”, “Ag|AgCl”, etc.

 Punctuation or Space Filter: A term that

contains nothing but punctuation or space(s) is

trapped. Trapped examples include: “=”, “+/-“,

“<”, “(%)” and “-->”.

 Digit Filter: A term that contains nothing but

digit(s), punctuation, and space(s) is trapped.

Trapped examples include: “2000”, “95%”, “3-

5”, “$1,500”, “(+/10.05)”, “192.168.1.1” and

“[192, 168]”.

 Number Filter: A term that contains nothing but

number(s) is trapped. This filter can be

considered as a domain filter because all

numbers are already recorded in the Lexicon.

Trapped examples include: “two”, “first and

second”, “one third”, “twenty-eight”, “Four

hundred and forty-seven” and “half”.

 Digit and Stopword Filter: A term that contains

nothing but digit(s) or stopword(s) is trapped.

Trapped examples include: “50% of”, “of the”,

“1, 2, and”, “2003 to 2007”, “for >=50%” and

“OR-462”.

3.2 Pattern Exclusive Filters

This type of filter looks for certain matching patterns

in a term for trapping. Computer programs are

implemented based on observed empirical patterns.

Some filters require sophisticated algorithms.

 Parenthetic Acronym Pattern (PAP) Filter: A

parenthetic acronym is a conventional way of

representing an acronym expansion with the

associated acronym. The pattern is an acronym

expansion followed by an acronym within a

closed parenthesis, e.g., [acronym-expansion

(ACRONYM)]. The expansions of acronyms

are usually valid multiwords. A term that

contains this pattern is trapped because it

contains a potential multiword plus the

associated acronym and thus cannot be a valid

LMW. Trapped examples include: “magnetic

resonance imaging (MRI)”, “imaging (MRI)”,

“magnetic resonance (MR) imaging” and

“(CREB)-binding protein (CBP)”.

 Indefinite Article Filter: A lowercased term that

starts with an indefinite article and a space, [a ],

without other n-grams that match as its spelling

variants (spVar) pattern in the corpus (n-gram

set) is trapped. Patterns of [a-XXX] and [aXXX]

are used as the spVar pattern of indefinite

articles of [a XXX], where XXX represents any

term. Trapped examples include: “a

significant”, “a case”, “a case of”, “a dose-

dependent” and “a delivery rate per”.

 UPPERCASE Colon Filter: A term that contains

the pattern of [UPPERCASE:] is trapped. In

MEDLINE, this is a conventional usage for this

pattern, such as [CONCLUSION:],

[RESULTS:], [OBJECTIVE:], [METHODS:],

[MATERIALS AND METHODS:], and

[BACKGROUND:]. Trapped examples include

“MATERIALS AND METHODS: The”, “95%

CI:” and “PHPT:”

 Disallowed Punctuation Filter: A term that

contains disallowed punctuation is trapped.

Disallowed punctuation includes:

{}_!@#*\;"?~=|<>$`^. Trapped examples

include: “(n =”, “(P < 0.05)”, “N^N”, “group

(n=6) received” and “CYP3A7*1C”.

 Measurement Pattern Filter: A term that

contains a measurement pattern is trapped. A

measurement pattern is [number + unit],

including age (“4-year-old”, “4 year-old”, “four

year-old”, “4 year-olds” and “4 years or older

with”), time (“four months

”, “1 January 1991”,

“from May 2002” and “6 hours plus”), range

(“2-3 days” and “1-2 tablets”), temperature (“at

-5 degrees”), dosage (“10 cigarettes per day”

and “0.1-2.3 mg/day”) and others (“60 inches”,

“0.5 mg”, “3 mg/EE”, “10 mg/kg” and “50

mg/kg/day”).

 Incomplete Pattern Filter: A term that contains

an incomplete pattern is trapped. A valid

multiword should have completed parentheses

or brackets. Incomplete patterns are terms that

do not have an even number of left and right

parentheses or square brackets or they are not

closed. Trapped examples include: “II (Hunter

syndrome”, “0.05) higher”, “bond]C-C[triple”,

“(chi(2)” and “interval [95%”.

HEALTHINF 2017 - 10th International Conference on Health Informatics

3.3 Lead-End-Term Exclusive Filters

LMWs do not start with certain terms, such as

auxiliaries (“be”, “do”, etc.), complementizers

(“that”), conjunctions (“and”, “or”, “but”, etc.),

determiners (“a”, “the”, “some”, etc.), modals

(“may”, “must”, “can”, etc.), pronouns (“it”, “he”,

“they”, etc.), and prepositions (“to”, “on”, “by”, etc.).

They are called invalid lead-terms. Similarly,

multiwords do not end with words in the above-listed

categories. N-grams ending in them are invalid

LMWs. They are used in exclusive filters to exclude

invalid multiwords. Terms from the Lexicon with any

of the above seven categories are used as invalid lead-

end-term (ILET) candidates. ILETs only comprise

0.05% (488) of total forms in Lexicon.2016

(915,583). Notably, ILET candidates are considered

static because no new terms in the above 7 categories

have been added since 2010. Please refer to LSG web

documents on Lead-End-Term filter models for

details (National Library of Medicine, Lexicon: Lead-

End-Terms Model, 2015).

 Absolute Invalid Lead-Term Filter: A term that

leads with an absolute invalid lead-term (AILT)

is trapped. There are 382 AILTs derived from

the Lexicon, such as [the], [from], [is] and [of].

Trapped examples include: “The results”, “from

the”, “is a” and “of a”.

 Absolute Invalid End-Term Filter: A term that

ends with an absolute invalid end-term (AIET)

is trapped. There are 407 AIETs derived from

the Lexicon, such as [with], [the] and [that].

Trapped examples include: “patients with”, “at

the” and “suggest that”.

 Lead-End-Term Filter: A term that leads with an

ILET and also ends with an ILET is trapped.

Trapped examples include: “in a”, “to be”, “with

a” and “as a”.

 Lead-Term No SpVar Filter: A term that leads

with a valid lead-term (VLT) without any other

term matching its spVar pattern in the same

corpus is trapped. There are 52 VLTs derived

from the Lexicon, such as [to], [as], [for] and

[plus]. Trapped examples include: “to

determine”, “as a result”, “for example” and

“plus LHRH-A”.

 End-Term No SpVar Filter: A term that ends

with a valid end-term (VET) without any other

term matching its spVar pattern in the same

corpus is trapped. There are 27 VETs derived

from the Lexicon, such as [of], [to], [in] and

[more]. Trapped examples include: “effects of”,

“was used to”, “(HPV) in” and “loss of two or

more”.

4 TESTS AND RESULTS

The evaluation of each individual filter, the

combination of all filters, and the distilled MEDLINE

n-gram set are discussed in this section. The 2016

release of the Lexicon and MEDLINE n-gram set are

used in this paper, unless specified otherwise.

4.1 Recall Test of Filters

A recall test model has been established for testing

each developed filter individually. Recall is defined

as: TP / (TP + FN), where T is true, F is false, P is

positive, N is negative. Terms (915,583) in the

Lexicon are used to test exclusive filters. All Lexicon

terms are valid (relevant) and should pass through

filters for preserving high recall rate. In this test, the

pass-through terms are counted as TP (retrieved,

relevant) while the trapped terms are FN (not

retrieved, relevant) for the filtered set.

Columns 4 and 5 in Table 1 list the recall rate and

number of trapped terms (FN) for this recall test. The

results show that all filters meet the design goal to

have very high recall rates. The lowest recall rate

(99.9913%) is at filter 15, Lead-Term No SpVar

Filter.

4.2 The Distilled N-gram Set

The distilled MEDLINE n-gram set is generated by

applying these high recall filters to the MEDLINE n-

gram set in the same sequential order of the first

column (ID) in Table 1. Let’s say X filters are applied

to all MEDLINE n-grams. The number of valid

LMWs (TP) and number of invalid LMWs (FP) of the

filtered MEDLINE n-gram set after ith filter are TP

and FP

, respectively, where i = 0, 1, 2, … X. The

number of valid LMWs are about the same (TP

≅

TP

≅ TP

≅… ≅ TP

) if high recall filters are used.

The number of invalid LMWs is reduced (FP

> FP

> … > FP

) from the original MEDLINE n-

gram set to the final distilled MEDLINE n-gram set

after applying filters. Accordingly, the distilled

MEDLINE n-gram set (X) has higher precision P

and similar recall R

to the MEDLINE n-gram set (0),

as shown in equations 1 and 2, respectively, where the

number of FN

(not retrieved, relevant) is a constant.

= TP

/ (TP

+ FP

)≅ TP

/ (TP

+ FP

)

> TP

/ (TP

+ FP

) (1)

= TP

/ (TP

+ FN

) = TP

/ (TP

+ FN

)

≅ TP

/ (TP

+ FN

) (2)

Generating a Distilled N-Gram Set - Effective Lexical Multiword Building in the SPECIALIST Lexicon

Sixteen high recall rate filters are applied to the

MEDLINE n-gram set in the same sequential order as

the first column in Table 1 to filter out invalid LMWs.

Columns 6, 7 and 8 in Table 1 list the number of

trapped terms, the passing rate (PR) and cumulative

passing rate (cum. PR) for all filters applied on the

MEDLINE n-gram set. The passing rate of the ith

filter is the pass through terms/total terms when

applying the ith filter on the MNS individually. The

pass through terms equals the total terms minus the

trapped terms. The cum. PR of ith filter is the

cumulative passing rate after applying i filters in the

sequential order of the first column in Table 1 to the

MNS. In other words, the trapped number is the sum

of trapped terms by filters that apply before the ith

filter. As a result (i = 16), the distilled MEDLINE n-

gram set, after filtering out the majority (11,922,490)

of invalid LMWs by these 16 filters, contains about

38.31% (7,402,848) n-grams of the MEDLINE n-

gram set (19,325,338). Figure 2 shows a schematic

diagram for generating the distilled MNS by applying

these filters on the MNS. These filters are designed

to independently trap invalid lexMultiwords, so the

order of filter application does not affect the final

results. These filters are generic and can be used by

different NLP projects if they meet the project

requirements. The Lead-End-Term filters (ID: 12-16)

have higher efficiency (trapped terms/total terms) by

trapping more n-grams in this process while the recall

rate is above 99.99%. Theoretically, the distilled

MEDLINE n-gram set, preserves valid terms in the

MNS and thus has higher precision and similar recall

compared to the MNS. The size of DMNS is reduced

to 38% of MNS, making it possible for complicated

computer programs to work in a reasonable time

frame in practice, such as the SpVar Pattern matcher

(please see section 5.1).

Table 1: Results of applying exclusive filters on Lexicon recall test and the MEDLINE n-gram set.

ID Filter Type Filter Name

Lexicon Recall Test Applied on the MEDLINE N-gram Set

Recall Trapped Trapped PR Cum. PR

General

Filters

Pipe 100.0000% 0 7 100.0000% 100.0000%

2 Punctuation or Space 100.0000% 0 425 99.9978% 99.9978%

3 Digit 99.9999% 1 132,650 99.3136% 99.3114%

4 Number 99.9953% 43 4,326 99.9775% 99.2890%

5 Digit and Stopword 99.9991% 8 157,786 99.1777% 98.4725%

Pattern

Filters

Parenthetic Acronym -

(ACR)

100.0000% 0 197,022 98.9647% 97.4530%

7 Indefinite Article 99.9986% 13 344,403 98.1713% 95.6709%

8 UPPERCASE Colon 99.9999% 1 113,936 99.3838% 95.0813%

9 Disallowed Punctuation 99.9986% 13 135,508 99.2625% 94.3801%

10 Measurement 99.9920% 73 336,112 98.1572% 92.6409%

11 Incomplete 100.0000% 0 166,356 99.0708% 91.7801%

Lead-End-

Term

Filters

Absolute Invalid Lead-

Term

99.9943% 52 4,712,162 73.4329% 67.3967%

Absolute Invalid End-

Term

99.9997% 3 2,710,470 79.1897% 53.3713%

14 Lead-End-Term 99.9992% 7 2,687 99.9739% 53.3573%

15 Lead-Term No SpVar 99.9913% 80 1,450,394 85.9342% 45.8522%

16 End-Term No SpVar 99.9968% 29 1,458,246 83.5433% 38.3064%

Figure 2: Schematic diagram of the MNS, filters and the distilled MNS.

HEALTHINF 2017 - 10th International Conference on Health Informatics

4.3 Evaluation of DMNS

We further verify the DMNS by comparing the

performance of the MNS and the DMNS. A smaller

test set is set up by retrieving LMW candidates from

the Parenthetic Acronym Pattern (PAP) matcher.

Matchers (inclusive filters) are designed to retrieve

LMWs from MEDLINE n-grams by trapping valid

multiwords that match valid LMW patterns. In other

words, terms trapped by matchers should be valid

LMWs. The design goal of matchers is set to generate

high precision LMW candidates. On the other hand,

the recall of matchers might decrease because not all

valid LMWs are trapped.

Acronym expansions are good patterns for a

matcher because they have a high possibility of

generating valid LMWs. The PAP matcher model is

implemented as follows. First, apply Parenthetic

Acronym Pattern Filter on the MEDLINE n-gram set

to retrieve terms matching the pattern of [acronym

expansion (ACRONYM)]. For example, “computed

tomography (CT)”, “magnetic resonance imaging

(MRI)”, “Unified Health System (SUS)”, etc. are

retrieved from the n-gram set. Second, retrieve

expansions if they match the associated acronym.

Heuristic rules are implemented, such as checking the

initial characters of first and last words of the

expansion to match the first and last characters of the

associated acronym. For example, the expansion of

“Unified Health System (SUS)” is identified as an

invalid LMW because the first initial of the expansion

(U) does not match the first character of acronym (S).

Third, remove terms if the expansion is a subterm of

other expansions in the list. For example, both n-

grams of “cell sarcoma (CCA)“ and “clear cell

sarcoma (CCA)” pass the first two steps. The invalid

LMW of “cell sarcoma” is removed in this step

because it is a subterm of the valid LMW “clear cell

sarcoma”.

We applied the PAP matcher to the MNS to

retrieve LMW candidates. The lowercased core-terms

of these candidates are collected as the test set. Core-

term normalization is to normalize an n-gram to its

core form by stripping the leading and ending

punctuation. For example, “in details,”, “- in details”

and “- in details,” have the same core-term form of

“in details”. Core-terms might have punctuation

internally, such as "in (5) details". It is a useful

normalization to cluster terms with the same core

together from the n-gram set in multiword

acquisition. As a result, 17,707 LMW candidates are

retrieved by this process. They are tagged by LSG

linguists and are added to the Lexicon if they are valid

LMWs. 15,850 candidates in this set are tagged as

valid LMWs to reach 89.51% precision for this PAP

matcher, where precision is defined as: TP/(TP+FP),

as shown in case 1 in Table 2. The recall cannot be

found because all LMWs from MEDLINE cannot be

identified in real practice. The result of this PAP

matcher is used as the baseline for performance test

to compare the results of other filters and matchers.

Accordingly, recall in case 1 is set to 1.00 for the

purpose of comparison. F1 score is defined as: (2 x

precision x recall) / (precision + recall), is calculated

and shown in the last column in Table 2.

We repeat the same process by applying the PAP

matcher to the DMNS to retrieve LMWs. The results

(case 2) show an improvement on F1 score with better

precision and almost the same recall. This confirms

the theoretic conclusion and the result of the recall

test on these filters, that the distilled MEDLINE n-

gram contains almost the same amount of valid

multiwords as the MEDLINE n-gram set while its

size is reduced to 38%. Furthermore, the cumulative

recall rates of these 16 filters on the recall test

(0.9996, multiple product of recall column in table 1)

and the recall rate of case 2 in Table 2 (0.9994) are

almost identical. This confirms that the approach of

applying these filters results in a similarly high recall

rate for both the Lexicon and the test set from PAP

matcher. Similar results of the Lexicon recall test and

DMNS in Table 1 and the performance test of the

PAP matcher on the MNS and the DMNS in Table 2

for 3 releases (2014 to 2016) of the Lexicon and

MEDLINE are found to confirm the consistency of

this approach.

Table 2: Performance comparison of MNS, DMNS and SVP matchers on a test set with 17,707 terms.

Case Test Case - Model TP FP FN TN Precision Recall F1

1 PAP matcher on MNS (baseline) 15,850 1,857 0 0 0.8951 (1.0000) 0.9447

2 PAP matcher on DMNS (16 filters) 15,840 1,299 10 558 0.9242 0.9994 0.9603

3 SVP matcher on case 2 8,094 499 7,756 1,358 0.9419 0.5107 0.6623

Generating a Distilled N-Gram Set - Effective Lexical Multiword Building in the SPECIALIST Lexicon

5 APPLICATIONS ON DMNS

Despite the high precision of the PAP matcher, it only

retrieves a small amount of LMW candidates. Other

matchers have been developed to retrieve more LMW

candidates for Lexicon building.

5.1 Spelling Variant Pattern Matcher

The Spelling Variant Pattern (SVP) matcher model

with a complicated algorithm was developed to

retrieve large amount of LMW candidates. As we

observed, an n-gram is a good LMW candidate if it

has spelling variants existing in the same corpus (n-

gram set). A sophisticated computer algorithm was

developed to identify all n-grams that have potential

spVars. First, a special normalization program was

developed to normalize spVars into their canonical

forms by converting non-ASCII Unicode to ASCII

(e.g. “Labbé” to “Labbe”), synonym substitution (e.g.

“St. Anthony's fire” to “Saint Anthony's fire”), rank

substitution (e.g. “Vth nerve” to “5th nerve”), number

substitution (e.g. “12-lead” to “twelve-lead”), Roman

numeral substitution (e.g. “BoHV-I” to “BoHV-1”),

strip punctuation (e.g. “lamin-A” to “lamin A”),

stripping genitive (e.g. “Laufe's forceps” to “Laufe

forceps”), converting to lowercase, and removing any

space(s). All terms that have the same normalized

spVar canonical form are identified as spVars to each

other. The Lexicon.2015 has 379,269 spVars

(including inflectional spelling variants) in 867,728

(unique) inflectional variants, and was used to test

this model. As shown in the recall column in Table 3,

80.50% of all spVars in the Lexicon are identified by

spVar normalization (step 1). All identified spVars

are grouped in spVar classes for further NLP

processing. Second, a MES (Metaphone, Edit

distance, and Sorted distance) model is developed to

improve recall. The MES model is composed of an

algorithm of Metaphone phonetic code (Philips,

1990), edit distance (the minimum number of

operations required to transform one term into the

other), and minimum sorted distance. Sorted distance

is the distance between two terms in an alphabetic

sorted list of a set of terms. It is used to measure the

similarity of two terms compared to other terms in the

set. All terms having the same phonetic code and an

edit distance (ED) less than a specified value are

collected and sorted. The pair with the minimum

sorted distance (the closest pair) is identified as

spVars to each other. For example, “yuppie flu” and

“yuppy flu” have different spVar canonical forms of

“yuppieflu” and “yuppyflu”, respectively, and thus are

not identified as spVars in the step 1, normalization.

They are identified as spVars in step 2 (MES model),

because they have the same Metaphone code of

[YPFL], edit distance of 2, and the minimum sorted

distance. This step identifies more spVars that cannot

be identified by normalization in step 1. The recall is

increased to 97.92% (Table 3). Third, an ES (Edit

distance and Sorted distance) model is developed for

further improvement of recall. Terms with an edited

distance less than a specified value are collected and

sorted. The pair with the minimum sorted distance is

identified as being spVars. For example, “zincemia”

and “zincaemia” are identified as spVars by the ES

model with an edit distance of 1, while they were not

identified as spVars in the previous steps, because

they have different spVar canonical forms of

“zincemia” and “zincaemia” and also have different

Metaphone codes of [SNSM] and [SNKM],

respectively. By relaxing the value of edit distance in

both models repeatedly, our program reaches 99.72%

recall on spVar identification in six steps in this test,

as shown in Table 3. Precision (Prec.), recall, F1,

accuracy, and running time (RT) of each step in this

SVP matcher model are shown in Table 3, where

accuracy is defined as: (TP + TN) / (TP + FP + FN +

TN).

For testing purposes, we applied this SVP matcher

model to the test set from the PAP matcher (case 2 in

Table 2). The results indicate improvement in

precision while recall dropped, as shown in case 3 in

Table 2. This confirms the design characteristics of

matchers.

Table 3: Performance analysis of the SVP matcher model.

Step Algorithm ED TP FP FN TN Prec. Recall F1 Accuracy RT

1 SpVarNorm N/A 305,309 3,495 73,960 484,964 0.9887 0.8050 0.8874 0.9107 1 min

2 MES 2 371,385 156,648 7,884 331,811 0.7033 0.9792 0.8187 0.8104 7 hr

3 ES 1 376,646 270,881 2,623 217,578 0.5817 0.9931 0.7336 0.6848 23 hr

4 MES 3 377,004 285,046 2,265 203,413 0.5694 0.9940 0.7241 0.6689 8 min

5 ES 2 378,134 337,461 1,135 150,998 0.5284 0.9970 0.6907 0.6098 26 hr

6 MES 4 378,211 340,105 1,058 148,354 0.5265 0.9972 0.6892 0.6068 2 min

HEALTHINF 2017 - 10th International Conference on Health Informatics

The next step is to apply this SVP matcher model

to the MNS to generate LMW candidates from

MEDLINE. The running time of this model on the

Lexicon took over 56 hours (sum of the RT column

in Table 3) even with a powerful computer with 192

GB memory. The running time will be exponentially

increased when applying the SVP model on the MNS,

which is over 22 times the size of the Lexicon. This

is impractical and not feasible in real practice. Thus,

the smaller size (38%) DMNS is chosen as input to

replace the MNS for reducing the processing time

without sacrificing recall. Further purification

processes of core-term normalization and frequency

threshold restriction (WC > 150) are also applied to

reduce the size of the n-gram set for better

performance. As a result, 752,920 spVars in 269,871

spVar classes are identified by running this computer

program for 20 days and are used for LMWs building

in the SPECIALIST Lexicon.

5.2 More Filters and Matchers

Other filters and matchers have also been developed

to apply to the DMNS to further improve LMW

building. For example, domain filters exclude terms

that are in a certain domain, such as single word,

frequency, and existing in the current Lexicon.

By requirement, a valid LMW must have a

meaning. Thus, a term with valid concept(s) has a

better possibility of being a valid LMW. We utilized

UMLS Metathesaurus concepts to create one such

matcher, the Metathesaurus CUI Pattern (MCP)

matcher. The Synonym Mapping Tool (SMT) in

STMT (Lu and Browne, 2012) is used to retrieve

Metathesaurus concepts (CUIs) in this model to

generate LMW candidates. The SMT is set up to find

concepts within 2 subterm substitutions by their

synonyms. The default synonym list in SMT is used.

In addition, an End-Word Pattern (EWP) matcher was

also developed. In the biomedical domain,

multiwords often end with certain words (End-

Words), such as [syndrome] (e.g. “migraine

syndrome”, “contiguous gene syndrome”), [disease]

(e.g. “Fabry disease”, “Devic disease”), and so on.

An End-Word candidate list composed of the top 20

frequency End-Words for LMWs has been derived

from the Lexicon. These End-Words are used in the

EWP matcher to retrieve LMW candidates.

The combining of filters and matchers improves

precision. This work focuses on generating high

precision LMW candidates for effective LMW

building. On the other hand, the recall of the matchers

is not emphasized because there are too many

multiwords yet to be found.

6 CONCLUSIONS

A set of high recall rate filters has been developed.

These filters are used to derive the distilled

MEDLINE n-gram set, resulting in reducing its size

to 38%, with better precision and similar recall to that

of the MEDLINE n-gram set. These filters and the

distilled n-gram set have been tested against the

Lexicon and a test set of terms retrieved from MNS

by PAP matchers. The distilled MEDLINE n-gram

set is needed for further NLP processes with

complicated algorithms, such as the SVP matcher

model, to reduce the running time for retrieving more

LMW candidates for Lexicon building.

Other matchers have also been developed and

evaluated. Combinations of filters and matchers have

been used to generate high precision LMW

candidates for effectively building the Lexicon. The

LSG plans to continuously enhance and develop

filters and matchers for further improvement. The

filters and matchers we have developed are generic

and can be used independently or in combination for

different research purposes. The approach of

generating the distilled MEDLINE n-gram set is also

generic and can be applied to other n-gram sets for

reducing size and better precision without sacrificing

recall. Most importantly, this approach provides a

modular and extendable framework for more and

better filters and matchers for LMW acquisition and

NLP research.

Multiwords are pervasive, challenging and vital in

NLP. The LSG aims to provide a lexicon with high

coverage of multiwords matching that of single

words. We believe the impact of enriched multiword

acquisition will enhance the precision, recall, and

naturalness of NLP applications. The SPECIALIST

Lexicon, the MEDLINE n-gram set and the distilled

MEDLINE n-gram set (National Library of Medicine,

Lexicon: The MEDLINE n-gram set, 2016) are

distributed by the National Library of Medicine

(NLM) annually via an Open Source License

agreement.

ACKNOWLEDGEMENTS

This research was supported by the Intramural

Research Program of the NIH, National Library of

Medicine. The authors would like to thank Mr. Guy

Divita for his valuable discussions and suggestions.

Generating a Distilled N-Gram Set - Effective Lexical Multiword Building in the SPECIALIST Lexicon

REFERENCES

Aronson, A.R., 2001. Effective mapping of biomedical text

to the UMLS Metathesaurus: the MetaMap program. In

proceedings of AMIA 2001 Annual Symposium,

Wash., DC, USA, Nov. 3-7, pages 17-21.

Aronson, A.R. and Lang, F.M., 2010. An Overview of

MetaMap: Historical Perspective and Recent

Advances. JAMIA, vol. 17, pages 229-236.

Baldwin, T., Bannard, C., Tanaka, T., Widdows, D., 2003.

An Empirical Model of Multiword Expression

Decomposability. In proceedings of the ACL 2003

Workshop on Multiword Expressions: Analysis,

Acquisition and Treatment, Sapporo, Japan, July 12,

pages 89-96.

Bejček, E., Straňák, P., Pecina, P., 2013. Syntactic

Identification of Occurrences of Multiword

Expressions in Text using a Lexicon with Dependency

Structures. In proceedings of the 9th Workshop on

Multiword Expressions, Atlanta, Georgia, USA, June

13-14, pages 106–115.

Boukobza, R., Rappoport, A., 2009. Multi-Word

Expression Identification Using Sentence Surface

Features. In proceedings of the 2009 Conference on

Empirical Methods in Natural Language Processing,

Singapore, August 6-7, pages 468–477.

Browne, A.C., McCray, A.T., Srinivasan, S., 2000. The

SPECIALIST LEXICON. Lister Hill National Center

for Biomedical Communications, National Library of

Medicine, Bethesda, Maryland, USA, June, pages 30-

49.

Calzolari, N., Fillmore, C.J., Grishman, R., Ide, N., Lenci,

A., MacLeod, C., Zampolli, A., 2002. Towards Best

Practice for Multiword Expressions in Computational

Lexicon. In proceedings of the Third International

Conference on Language Resources and Evaluation

(LREC), Las Palmas, Canary Islands, Spain, May 29-

31, pages 1934-1940.

Divita, G., Browne, A.C., Tse, T., Cheh, M.L., Loane, R.F.,

Abramson, M., 2000. A Spelling Suggestion Technique

for Terminology Servers. In proceedings of AMIA

2000 Annual Symposium, Los Angeles, CA, USA,

Nov. 4-8, page 994.

Divita, G., Zeng, Q.T., Gundlapalli, A.V., Duvall, S.,

Nebeker, J., and Samore, M.H., 2014. Sophia: An

Expedient UMLS Concept Extraction Annotator. In

proceedings of AMIA 2014 Annual Symposium,

Wash., DC, USA, Nov. 15-19, pages 467-476.

Fazly, A., Cook, P., Stevenson, S., 2009. Unsupervised

Type and Token Identification of Idiomatic

Expressions. Computational Linguistics, vol. 35, no. 1,

pages 61-103.

Frantzi, K., Ananiadou, S., Mima, H., 2000. Automatic

Recognition of Multi-Word Terms: the C-value/NC-

value Method. International Journal on Digital

Libraries, vol. 3, no. 2, pages 115-130.

Fraser, S., 2009. Technical vocabulary and collocational

behaviour in a specialised corpus. In proceedings of the

British Association for Applied Linguistics (BAAL),

Newcastle University, Sep. 3-5, pages 43-48.

Green, S., de Marneffe, M.C., Bauer, J., and Manning,

C.D., 2011. Multiword Expression Identification with

Tree Substitution Grammars: A Parsing tour deforce

with French. In proceedings of EMNLP, Edinburgh,

Scotland, UK, July 27-31, pages 725–735.

Green, S., de Marneffe, M.C., Manning, C.D., 2013.

Parsing models for identifying multiword expressions.

Computational Linguistics. vol. 39, no. 1, pages 195–

227.

Ide, N.C., Loane, R.F., Fushman, D.D., 2007. Essie: A

Concept-based Search Engine for Structured

Biomedical Text. JAMIA, vol. 14, no. 3, May/June,

pages 253-263.

Kim, S.N. and Baldwin, T., 2010. How to pick out token

instances of English verb-particle constructions.

Language Resources and Evaluation, April, vol. 44, no.

1, pages 97-113.

Lu, C.J. and Browne, A.C., 2012. Development of Sub-

Term Mapping Tools (STMT). In proceedings of

AMIA 2012 Annual Symposium, Chicago, IL, USA,

Nov. 3-7, page 1845.

Lu, C.J., McCreedy, L., Tormey, D., and Browne, A.C.,

2012. A Systematic Approach for Automatically

Generating Derivational Variants in Lexical Tools

Based on the SPECIALIST Lexicon. IEEE IT

Professional Magazine, May/June, pages 36-42.

Lu, C.J., Tormey, D., McCreedy, L., Browne, A.C., 2014.

Using Element Words to Generate (Multi)Words for the

SPECIALIST Lexicon. In proceedings of AMIA 2014

Annual Symposium, Wash., DC, USA, Nov. 15-19,

page 1499.

Lu, C.J., Tormey, D., McCreedy, L., Browne, A.C., 2015.

Generating the MEDLINE N-Gram Set, In proceedings

of AMIA 2015 Annual Symposium, San Francisco,

CA, USA, Nov. 14-18, page 1569.

McCray, A.T., Aronson, A.R., Browne, A.C., Rindflesch,

T.C., Razi, A., Srinivasan, S., 1993. UMLS Knowledge

for Biomedical Language Processing. Bull. Medical

Library Assoc., vol. 81, no. 2, pages 184-194.

McCray, A.T., Srinivasan, S., Browne, A.C., 1994. Lexical

Methods for Managing Variation in Biomedical

Terminologies. In proceedings of the 18th Annual

Symposium on Computer Applications in Medical

Care, pages 235-239.

National Library of Medicine, Lexicon, 2016. Lead-End-

Terms Model. Available from:

<https://lsg3.nlm.nih.gov/LexSysGroup/Projects/lexic

on/current/docs/designDoc/UDF/multiwords/leadEnd

Terms/index.html>.

National Library of Medicine. Lexicon, 2016. The

MEDLINE n-gram set. Available from:

<https://lsg3.nlm.nih.gov/LexSysGroup/Projects/nGra

m/index.html>.

Pearce, D., 2001. Using Conceptual Similarity for

Collocation Extraction. In proceedings of the 4

Special Interest Group for Computational Linguistics

(CLUK4), University of Sheffield, Sheffield, UK,

January 10-11, pages 34–42.

HEALTHINF 2017 - 10th International Conference on Health Informatics

Pecina, P., 2010. Lexical association measures collocation

extraction. Language Resources and Evaluation, vol.

44, pages 137-158.

Philips, L., 1990. Hanging on the Metaphone. Computer

Language, December, vol. 17, no. 12, pages 39-43.

Ramisch, C., 2014. Multiword Expressions Acquisition: A

Generic and Open Framework (Theory and

Applications of Natural Language Processing).

Springer, 2015

Edition, pages 4, 9, 37.

Sag, I., Baldwin, T., Bond, F., Copestake, A., and

Flickinger, D., 2002. Multiword expressions: A pain in

the neck for NLP. In proceedings of the 3rd

International Conference on Intelligent Text Processing

and Computational Linguistics (CICLING 2002),

Mexico City, Mexico, pages 1-15.

Sangati, F., Cranenburgh, A.V., 2015. Multiword

Expression Identification with Recurring Tree

Fragments and Association Measures. In proceedings

of Annual conference of North American Chapter of the

Association for Computational Linguistics: Human

Language Technologies (NAACL-HLT), Denver,

Colorado, May 31-June 5, pages 10-8.

Savova, G.K., Masanz, J.J., Ogren, P.V., Zheng, J., Sohn,

S., Kipper-Schuler, K.C., Chute, C.G., 2010. Mayo

clinical Text Analysis and Knowledge Extraction

System (cTAKES): architecture, component evaluation

and applications. JAMIA, vol. 17, no. 5, pages 507-513.

Seretan, V. and Wehrli, E., 2009. Multilingual collocation

extraction with a syntactic parser. Language Resources

and Evaluation, March, vol. 43, no. 1, pages 71-85.

Silva, J.F. and Lopes, G.P., 1999. A Local Maxima method

and a Fair Dispersion Normalization for extracting

multi-word units from corpora. In proceedings of the

Sixth Meeting on Mathematics of Language (MOL6),

Orlando, FL, USA, pages 369-381.

Takahashi, S. and Morimoto, T., 2013. Selection of Multi-

Word Expressions from Web N-gram Corpus for

Speech Recognition. In proceedings of International

Symposium on Natural Language Processing (SNLP),

Phuket, Thailand, Oct. 28-30, pages 6-11.

Tsvetkov, Y. and Wintner, S., 2011. Identification of Multi-

word Expressions by Combining Multiple Linguistic

Information Sources. In proceedings of the Conference

on Empirical Methods in Natural Language Processing,

Edinburgh, Scotland, UK, July 27-31, pages 836–845.

Generating a Distilled N-Gram Set - Effective Lexical Multiword Building in the SPECIALIST Lexicon
