Comparative Study on Data Mining Techniques Applied to Breast

Cancer Gene Expression Profiles

Sérgio Mosquim Júnior

1,2

and Juliana de Oliveira

School of Sciences, Humanities and Languages, São Paulo State University, Av. Dom Antonio, 2100, Assis - SP, Brazil

Uppsala University, Uppsala, Sweden

Keywords: Data Mining, Breast Cancer, Decision Trees, Artificial Neural Networks.

Abstract: Breast cancer has the second highest incidence among all cancer types and is the fifth cause of cancer

related death among women. In Brazil, breast cancer mortality rates have been rising. Cancer classification

is intricate, mainly when differentiating subtypes. In this context, data mining becomes a fundamental tool

to analyze genotypic data, improving diagnostics, treatment and patient care. As the data dimensionality is

problematic, methods to reduce it must be applied. Hence, the present study aims at the analysis of two data

mining methods (i.e., decision trees and artificial neural networks). Weka® and MATLAB® were used to

implement these two methodologies. Decision trees appointed important genes for the classification.

Optimal artificial neural network architecture consists of two layers, one with 99 neurons and the other with

5. Both data mining techniques were able to classify data with high accuracy.

1 INTRODUCTION

According to the Brazilian National Cancer Institute

(INCA), cancer is the name given to more than 100

diseases that have a disorderly growth of cells

(malign) that penetrate tissues and organs, being

able to spread to other regions of the body in a

process called metastasis (Brasil, 2016).

According to estimates from the World Health

Organization (WHO) from 2011, cancer now is

responsible for more deaths than any other coronary

diseases. The constant changes in global

demographics and epidemiology lead to an increase

of the disease in the next decades, estimating 20

million new cases annually in 2025. In 2012, it was

estimated that 14.1 million new cases and 8.2

million deaths occurred globally (Ferlay et al.,

2015).

Breast cancer is the type of cancer which

presents the second highest incidence in the world

and is the most frequent in women, with 1.67

million new cases diagnosed in 2012. This value

corresponds to 25% of the total cancer diagnoses in

that year. Breast cancer still is the fifth cause of

death among several cancer types (Ferlay et al.,

2015).

In an analysis made by Desantis et al., (2015)

with data from GLOBOCAN, i.e. a project

developed by the International Agency for Research

on Cancer whose objective is to provide recent

incidence, mortality and prevalence estimates for the

most important types of cancer, it is discussed that

the highest incidences of breast cancer around the

world continue to be observed in the less developed

countries. It is estimated that nearly 1.7 million new

cases and 521,900 deaths were attributed to breast

cancer in the world in 2012.

Both in developed countries and in low to

medium income countries there has been an increase

in breast cancer incidence. This may be a result of

several factors, like changes in eating habits,

increase in obesity, hormone replacement therapy,

physical inactivity, among others (DeSantis et al.,

2015).

Despite this increase in breast cancer incidence,

mortality rates have decreased with time, especially

in developed countries. This tendency is a result of

more frequent mammographs and improvements in

treatment for example (DeSantis et al., 2015).

However, in countries like Brazil, Colombia,

Ecuador, Egypt, Guatemala, Japan, Kuwait, Mexico

and others, mortality rates increases, which reflects

and increase in incidence and, in some cases, the

limited access to treatment (DeSantis et al., 2015).

According to INCA, 57,960 new cases of breast

cancer are expected in 2016, with an estimate risk of

168

Mosquim JÃžnior S. and de Oliveira J.

Comparative Study on Data Mining Techniques Applied to Breast Cancer Gene Expression Proﬁles.

DOI: 10.5220/0006170201680175

In Proceedings of the 10th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2017), pages 168-175

ISBN: 978-989-758-214-1

56.20 cases in every 100 thousand women. Without

taking into account non melanoma skin tumors,

breast cancer ranks first and most frequent in the

South, Southeast, Northeast and Center of Brazil.

Cancer classification has been a central topic in

treatment research. The most classical approach is

based on tumor morphology, which presents

limitations such as a strongly biased identification

by specialists and also difficulties in distinguishing

between subtypes (Liu et al., 2004). In this context

data mining appears as a means of facilitating

decision making processes by health professionals

when it comes to diagnosis, treatment and patient

care (Tseng et al., 2015).

Data mining belongs to a stage in the Knowledge

Discovery in Database (KDD) process (Tseng et al.,

2015). It is defined as the process of discovering

hidden patterns in data, which can take place

automatic or semi automatically (Witten et al.,

2011).

The vast applications of cDNA and

oligonucleotide microarrays, with complete genomic

expression, scanning more than 40,000 clones in a

single experiment, made possible the development

of a new era of molecular genomics. At the same

time, they’re generating vast amounts of data.

Molecular expression based classification continues

to be a challenge partly due to the different

microarray platforms, identification methods,

scanners, image analysis tools but also currently

available classification algorithms. Moreover,

there’s a growing number of algorithms that are

being developed for analysis of high quality

microarray data (Greer and Khan, 2004).

Due to the high cost, genetic data are usually

collected from a limited number of patients.

Therefore, there’s a need for choosing the most

relevant information among the available data.

Irrelevant gene removal can contribute to the

reduction of noise, confusion and complexity.

Besides, it increases the chances of identifying

important genes, classifying diseases and predicting

several outcomes (e.g., type of cancer). Several

computacional strategies have been applied to gene

expression classification problems (Shah and

Kusiak, 2007).

Learning methods constitute an automatic and

intelligent technique, which has been used widely

for solving different real and complex situations.

Since its introduction in bioinformatics, learning

approaches have helped to speed up diverse

researches. Since they are inexpensive and efficient,

its applications have become more popular and

constantly growing (Liu et al., 2004).

Usually, there are two different learning

schemes, supervised and unsupervised learning. In

the first one, the output is given, or there is some

type of previous knowledge about the data. On the

second one, however, there is no previous

knowledge about the data. General tasks performed

are classification, characterization and clustering.

The supervised approach is the most used in

biological problems where two sets of samples are

presented. The program, then, must generate a

classifier which is able to distinguish between these

two datasets. Then, it can be used as a base for the

classification of unseen data (Liu et al., 2004).

In an article published by Ahmad et al. (2015), it

was mentioned that when analyzing data mining in

healthcare, classification is one of the most popular

methods. The authors then follow by giving a list of

the most commonly used classification algorithms in

healthcare, such as K Nearest Neighbor (KNN),

Decision Trees, Support Vector Machines, Artificial

Neural Networks and Bayesian Methods (Ahmad et

al., 2015).

Decision Trees (DT) are considered to be one of

the most popular approaches when it comes to

classifiers. They can be built from data which is

already available in several fields. Every non leaf

node denotes a test to be performed, while branches

are outcomes. The tree ends in a leaf node, which

represents a class label. The most common use of

DTs is to calculate conditional probabilities. They

allow for class separation based on information gain.

The main advantages presented by this method are

the fact that DTs are self-explanatory, easy to

follow, the ability to handle nominal and numeric

attributes, ability to handle missing values.

However, they also present several disadvantages.

Most algorithms require the trees to have discrete

values, for they use the divide and conquer method.

Their performance gets lower the more complex is

the interaction among attributes. In that way, other

classifiers can describe the relationship among

variables in a way DTs would make it really

challenging (Ahmad et al., 2015).

Artificial Neural Networks (ANN), on the other

hand, were considered to be the best classification

algorithm before the introduction of methods such as

DTs and Support Vector Machines. This allowed

them to be one of the most widely used in several

different fields. They have widely used in supporting

diagnosis of diseases such as cancers and in

predicting outcomes. Their basic elements are

neurons (also called nodes), which are

interconnected and work in parallel to produce

outcome functions. The main ability behind ANNs is

Comparative Study on Data Mining Techniques Applied to Breast Cancer Gene Expression Proﬁles

169

that they are able to minimize error by adjusting the

connection weights and by making changes in its

structure. One of their main advantages is that they

can properly handle noisy data and classify data

different from the one used for training. However,

they require many parameters, including the number

of hidden layer nodes (empirically determined), the

learning process is computationally intense and time

consuming, and they do not provide any details

about the phenomenon being investigated.

Especially when it comes to the determination of

parameters, the performance is entirely dependent on

these factors (Ahmad et al., 2015).

The process of knowledge discovery can be

defined in five different steps, i.e., selection,

preprocessing, transformation, data mining and

interpretation. The preprocessing stage refers to the

removal of information which is not necessary for

the process and also cleans the data (Ahmad et al.,

2015). Shah and Kusiak (2007) mentioned that the

removal of irrelevant genes may contribute to noise

and complexity reduction while it also increases the

chances of identifying relevant genes. In most cases,

before using any data mining technique, a

dimensionality reduction approach is applied. It aims

at improving the performance of the method,

preventing overtraining and data is more easily

comprehended (Aguiar-Pulido et al., 2013).

On the above, the present work aims to compare

different data mining techniques (i.e., DT and ANN)

with respect to gathering high quality information on

breast cancer gene expression data.

2 METHODOLOGY

The data used in the present study consist of

publicly available breast cancer gene expression

data. Considering the KDD process described above,

a preprocessing and cleaning stages had to take

place before data mining itself. This consisted of

compiling the data, removing empty cells and using

a couple of filters in order to reduce dimensionality.

These filters were based on variance and entropy.

After this stage, the two different methods (DTs and

ANNs) were applied to the data and the results

analyzed and compared.

2.1 Data Acquisition

The invasive breast cancer gene expression (BRCA)

data were obtained from The Cancer Genome Atlas

(TCGA), which aims at accelerating the

comprehension of the molecular bases behind cancer

through the application of genomic analysis

techniques. The TCGA is a collaboration between

The National Cancer Institute and The Nacional

Human Genome Research Institute (EUA, 2016).

The present data corresponds to level 3 gene

expression data (i.e., expression values). These

values have already been normalized through

Lowess methodology when the data were acquired.

Typically, the first transformation applied to

expression data adjusts the individual hybridization

intensities to balance them, so meaningful biological

comparisons can be made. In addition to this

normalization, the expression rations must also be

normalized using Log2 values.

2.2 Preprocessing

The downloaded data were presented in text files,

one for each patient. These genes and their

expression values in these files were read and copied

into a spreadsheet by using a program written in

MATLAB®. This spreadsheet was then subjected to

different filters to remove irrelevant genes. The first

one detected empty values and removed the

corresponding genes, so there would be no errors

when reading the table. A second set of filters aimed

at removing genes with low variance and low

entropy values, which corresponds to noise in the

data.

2.3 Data Mining

The above mentioned data mining techniques (i.e.

DTs and ANNs) were performed on two different

pieces of software, Weka® and MATLAB®. The

DT were performed on both, while ANN was only

performed on MATLAB®.

2.3.1 Decision Trees

Oncologists classify different tumors based on

biopsy and other criteria. DT predict the class to

which a certain instance belongs. It is a simple

classifier, which is an advantage to this method

(Kingsford and Salzberg, 2008).

These trees are built splitting the data in two

parts, a training set that is used for the induction of

the tree, and a test set, which is used to check the

precision of the provided solution. After induction

the trees are used to classify unseen samples. It is a

hierarchical structure consisted of nodes (root,

internal node and terminal node) and directed lines.

Precise predictions can be achieved given adequate

training (Podgorelec et al., 2002; Kingsford and

BIOINFORMATICS 2017 - 8th International Conference on Bioinformatics Models, Methods and Algorithms

170

Salzberg, 2008; Aguiar-Pulido et al., 2013). The

classification task is quite simple. Starting at the

root, the testing condition is applied on the instances

and they follow the branches according to the

results. This will lead to an internal node, where the

same procedure is repeated, or to a leaf, where class

attribution is defined (Aguiar-Pulido et al., 2013).

On Weka® there are different tree algorithms. In

these case, two algorithms performed better, J48 and

REPTree. J48 uses the concept of entropy with a

training set, and every feature is used to make a

decision, which takes place by splitting the data into

smaller data sets. It is a pruned or unpruned tree

derived from the C4.5 tree. It uses information gain

to determine how much a property can separate the

training data according to the classification (Hall et

al., 2009 and Sa'di et al., 2015). REPTree uses the

regression tree logic and creates multiple trees in

different iterations. The best one is then selected to

be considered representative. The tree is pruned

using mean square error. It is a fast algorithm which

uses information gain as the splitting criterion.

Missing attributes are dealt with using C4.5’s

fractional instances (Kalmegh, 2015).

On MATLAB®, however, the fit tree function

uses the Classification And Regression Tree

(CART) algorithm, which creates a large tree and

then prunes it to a certain size based on cross-

validation estimate of error (Loh, 2014).

2.3.2 Artificial Neural Networks

The brain is basically constituted of neurons

interconnected with axons and dendrites. It learns by

adjusting these connections (Aguiar-Pulido et al.,

2013). Since it is a complex, nonlinear and parallel

processing system, it is interesting to simulate this

capacity (Greer and Khan, 2004).

ANNs resemble the brain in two aspects. First,

knowledge is acquired through learning. Second,

strong interneural connections (synaptic weights) are

used to store knowledge (Greer and Khan, 2004).

These ANNs are made of nodes called neurons,

and directed links which measure signal importance

using a weight factor. These values adapt based on

information processed during learning (Aguiar-

Pulido et al., 2013). A ANN is developed in three

stages, design, training and validation. Designing

involves network architecture selection (number of

neurons and layers). The optimal selection is usually

subjective and requires trial and error (Gamito and

Crawford, 2004).

Input data are analogous to independent variable

(x) and output data to dependent variable (y). When

training starts, connection weights are small. Hence,

the output values are arbitrary and errors are high. In

supervised learning, the output given by the network

is compared to the expected output. A training

algorithm adjusts the weights based on the

calculated error from the two outputs (Gamito and

Crawford, 2004).

During training, instances with known output are

presented to the ANN sequential and repeatedly,

constituting epochs or iterations. The algorithm

adjusts the weights and, with time, a matrix is

generated, which presents the training values that

minimize error (Gamito and Crawford, 2004).

In the present study, the ANNs were

programmed on MATLAB® using the pattern

recognition function. The data were divided for

training (70%) and for testing (30%). Then, ANNs

with different architectures were trained, analyzing

the number of layers (one or two) and the number of

neurons in each layer (from one to 100 for the first

layer and one to 15 in the second one), as well as the

number of trainings an ANN should perform. From

all the generated ANNs, the one which presented the

lowest error in classification was saved.

2.4 Data Analysis

In order to analyze the results, 10 fold cross

validation, ROC curve and confusion matrices were

used in the present study.

3 RESULTS AND DISCUSSION

3.1 Decision Trees

On Weka®, the J48 algorithm was used with all

native configurations. Figure 1 shows the tree

generated by J48, it’s worth noting that ’t’ and ’n’

stand for tumoral and normal, respectively. It used

four different genes to classify the instances (TSLP,

FYN, PSENEN and RABIF). Observing the

numbers at the end of each node, it is possible to

notice that TSLP and FYN together were able to

classify most part of the instances.

TSLP (Thymic Stromal Lymphopoietin) is a

member of the cytokine IL-2 family and a distant

paralogue of IL-7. The murine gene was discovered

in thymic stromal cell lineages that supported B cell

development. Just like IL-7, this gene can stimulate

thymocytes to promote B cell lymphopoiesis (Roan

et al., 2012). A homologue of this protein was

identified in humans through computational

methods. In a similar way, it was possible to isolate

Comparative Study on Data Mining Techniques Applied to Breast Cancer Gene Expression Proﬁles

171

Figure 1: Decision tree created on Weka through J48

algorithm.

a receptor for the TSLP. Besides, several cell types

respond to this protein, including innate immune

system cells, which is evidenced by the possibility

of cytokine production in mast cells, NK and

eosinophils. Interestingly, the role of TSLP is quite

complicated. Some studies found a promoting role in

tumor development. Others, on the other hand, a

suppressing role. Therefore, the importance of this

gene as a possible target for cancer therapy is

evidenced (LoKuan and Ziegler, 2014).

The FYN gene, on the other hand, is located in

chromosome 6q21. It is a member of the SRC

family, originally identified in 1986 as SYN or SLK.

It is located primarily in the plasma membrane,

where if phosphorylates tyrosine residues in targets

involved in different signaling paths. Its biological

roles are quite diverse. In the past, a lot was focused

on its immunologic and neurologic functions.

However, this gene is also mitogenic signaling

mediator and regulator of the cell cycle, growing and

proliferation, integrin mediated interactions and cell

adhesion. High expression levels have been linked to

morphological transformations in normal cells. For

example, high expression of this gene in NIH 3T3

fibroblasts showed a phenotype similar to that of

cancer, with increased anchorage independent

growth and prominent morphological alterations.

This gene is over expressed in several cancer types,

including glioblastomas, neck and head squamous

cell carcinoma, and melanoma. However, the role

behind this increased expression has not been well

defined yet (Saito et al., 2010).

Kinases of the SRC family (SFKs) were among

the first kinases to be discovered. The family is

constituted of 11 members, 8 of which have already

been studied. Some, like c-Src has been intensely

studied when it comes to it relationship with cancer

biology, particularly as a molecule of vital

importance in tumor development, progression and

resistance to therapeutic agents. For the last decade,

the involvement of other members of the family, like

Fyn, in several aspects of cancer biology has become

more apparent (Elias and Ditzel, 2015).

Fyn is located in the most internal layer of the

plasma membrane, attached to myristic and palmitic

acids. The activity of this protein is regulated by

intermolecular interactions influenced by tyrosine

phosphorylation and dephosphorylation. Fyn

activation leads to tyrosine phosphorylation in

different targets, like focal activation kinase (FAK)

and anti estrogen resistance protein 1 (BCAR1)

(Elias and Ditzel, 2015).

This gene has several molecular functions,

including cell growth regulation, survival, adhesion,

cytoskeleton remodeling, motility, axon direction,

synaptic function, myelination in the central nervous

system, placket activation and T cell receptor

signaling (Elias and Ditzel, 2015).

Fyn is also involved in several pathogenic

aspects of different types of cancers, with tumor

promoting effects, proliferation promotion,

migration and prostate tumor cell invasion, cell

death inhibition and mesenchymal epithelial

transition. Again, the importance of studying this

gene as a possible target for cancer therapy get

highlighted (Elias and Ditzel, 2015).

However, neither PSENEN or RABIF could be

specifically found linked to cancer development.

Figure 2, on the other hand, shows the decision

tree built by REPTree. On this tree, only one gene

was used to classify the instances, MMP11.

The matrix metalloproteinases (MMP) are

important components of the tumor stroma. They

regulate and shape the tumor microenvironment, its

expression, and activation, all of which are increased

in most human cancers when compared to levels

found in normal tissues. The MMP11 was isolated

as a gene associated to breast cancer, and it is

expressed in most primary invasive carcinomas, in

several of its metastasis and, although more rarely,

in sarcomas and other epithelial malignancies. It is

worth noting that it is a protein that is barely even

expressed in normal adult tissues (Peruzzi et al.,

2009).

Figure 2: Decision tree created on Weka through the

REPTree algorithm.

Peruzzi and coworkers (2009) analyzed if

MMP11 was a relevant target for human cancer

BIOINFORMATICS 2017 - 8th International Conference on Bioinformatics Models, Methods and Algorithms

172

through analysis of microarray data of stomach,

kidney, colon, lung and breast cancers. The

abundance of this protein in these tissues was

compared to normal tissue values from the same

type, which aimed at analyzing the differential

expression of this particular protein. The authors

found out that MMP11 is more expressed in all

types of tumor when compared to normal tissue,

which highlights the role of this particular gene as a

target for cancer therapy.

Although on MATLAB® DT of different

complexities were testes, the simplest one was

already able to classify the instances with a good

percentage (98%) of correct classifications.

The genes identified on MATLAB® are different

from those found on Weka® (MMP11, IPO9,

ADAMTS5, DUS3L) except for MMP11. This tree

can be observed in Figure 3.

Figure 3: Decision tree created on MATLAB®.

Members of the ADAMTS family can be

classified in different groups, which are based on its

functions. Interestingly, it is worth mentioning that

on recent years several studies have arisen about the

role of this family in angiogenesis and cancer.

Several members were linked to angiogenic

regulation, which were placed on the list of

angiogenesis inhibitors. However, this mechanism is

not shared by all members of this family (Kumar et

al., 2012).

ADAMTS5, is one of the most studied

metalloproeinases from this family due to its role in

cartilage degradation in arthritis. The human gene is

located in chromosome 21q21.3. Small chemical

inhibitors of this metalloproteinase were identified

based on its catalytic domain structure. Recent

studies evidenced another role of this protein,

involved in the development of other conditions

such as cancer. There is a crescent number of

publications about the regulation of this gene

expression levels in the progression of malignant

tumors, suggesting that it may act as a suppressor in

some types of cancer. A decrease in the mRNA

levels for this gene was identified in prostate cancer

besides head and neck squamous cell carcinoma

when compared to normal levels. Moreover, in

breast cancer tissue, this protein levels are low when

compared to non-neoplastic tissue (Kumar et al.,

2012).

In a study conducted by Porter and coworkers

(2004), this gene was shown as being repressed in

breast cancer. The authors compared the mRNA

level of all ADAMTS genes in malignant breast

tumors and non neoplastic breast tissue. They were

able to show that ADAMTS5 was repressed in this

type of cancer. Furthermore, although there is a low

ADAMTS5 expression in prostate cancer cell

lineages, normal cells from the prostate estroma

present high levels of ADMATS5 expression. It was

also documented that this gene would be

hypermethylated in colorectal cancer. Therefore, a

pattern arises which suggest a supressor role for this

gene (Kumar et al., 2012).

Nevertheless, other publications suggest that

ADAMTS5 would be over expressed in

glioblastoma, and that it could contribute to glial cell

invasion. Hence, ADAMTS5 has different roles in

different types of cancer which depend on substrate

availability and its antiangiogenic activity (Kumar et

al., 2012).

The gene IPO9 could not be directly associated

with the development of breast cancer.

Figure 4: Confusion matrix generated on MATLAB® for

the corresponding decision tree. 98% of the samples were

correctly classified by the tree (sum of the diagonals). 12

out of 593 samples were misclassified.

The confusion matrix shows the predicted class

versus the real class to which a certain patient

belongs. In this matrix, it is possible to observe the

Comparative Study on Data Mining Techniques Applied to Breast Cancer Gene Expression Proﬁles

173

percentage of correctly classified instances. On the

matrix obtained on MATLAB®, the classifier was

able to correctly classify 98% of the instances

(Figure 4).

As it was mentioned previously, the quality of a

certain classifier can be expressed in terms of a ROC

curve, as can be seen in Figure 5. Two aspects can

be seen in this curve, the position of the current

classifier and the area under the curve. These values

are better the closer they get to 1. In this case, the

area under the curve was 0.947574 and the classifier

can be found in a point of coordinates (0.0113208

0.904762).

Figure 5: ROC curve for the decision tree on MATLAB®.

The point represents the efficiency of the classifier, which

is calculated from the division of the false positive rate

and the true positive rate.

3.2 Artificial Neural Networks

Among the several ANNs generated on MATLAB®,

the one selected as the best was the one which

presented the lowest global error in the classification

process. This structure of this particular ANN can be

seen in Figure 6.

An error histogram plot was created for this

particular ANN (Figure 7) on which it can be seen

that from all the patients used for testing, only 2 had

an error different from -0.00525.

Figure 7: Error histogram with the error values for the

best.

Moreover, the classification made by the ANN

was also evaluated by means of a confusion matrix

(Figure 8). In the picture, it can be seen that 98,9%

of the samples were correctly classified. Only one

patient from each group was misclassify.

Figure 8: Confusion matrix calculated for the ANN which

presented the lowest global error.

Figure 6: Structure of the ANN which presented the lowest global error among all the different networks created on

MATLAB®.

BIOINFORMATICS 2017 - 8th International Conference on Bioinformatics Models, Methods and Algorithms

174

4 CONCLUSIONS

The use of both programs for implementation of

DTs showed diversity in the genes selected by the

same method, with at least TSLP, FYN and MMP11

being directly linked to cancer. Moreover, the ANNs

presented good classification capabilities, with the

one selected presenting very low errors (-0.00525).

For both methods, confusion matrices showed

correct classification of at least 98% of instances.

Although there are some divergent results especially

when it comes to the DT created in the two different

pieces of software, the results are coherent to what

was set as objective on the present study (i.e., using

of data mining techniques for discovery of genes

associated with breast cancer development).

REFERENCES

Aguiar-Pulido, V., et al. 2013. Exploring patterns of

epigenetic information with data mining techniques.

Curr Pharm Des, 19, 779-89.

Ahmad, P., et al. 2015. Techniques of Data Mining In

Healthcare: A Review. International Journal of

Computer Applications, 120, 38-50.

BRASIL. Instituto Nacional do Cancer (INCA). 2016. O

que é o cancer? Available at

http://www1.inca.gov.br/conteudo_view.asp?id=322.

Accessed: 27 March 2016.

Desantis, C.E., et al. 2015. International Variation in

Female Breast Cancer Incidence and Mortality Rates.

Cancer Epidemiol Biomarkers Prev, 24, 1495-506.

Elias, D., Ditzel, H.J. 2015. Fyn is an important molecule

in cancer pathogenesis and drug resistance.

Pharmacological Research, 100, 250-254.

EUA. The Cancer Genome Atlas. National Institute of

Health. 2016. About TCGA. Available at

<http://cancergenome.nih.gov/abouttcga>. Accessed

27 March 2016.

Ferlay, J., et al. 2015. Cancer incidence and mortality

worldwide: sources, methods and major patterns in

GLOBOCAN 2012. Int J Cancer, 136, E359-86.

Gamito, E.J., Crawford, E.D. 2004. Artificial neural

networks for predictive modeling in prostate cancer.

Curr Oncol Rep, 6, 216-21.

Greer, B.T., Khan, J. 2004. Diagnostic classification of

cancer using DNA microarrays and artificial

intelligence. Ann N Y Acad Sci, 1020, 49-66.

Hall, M.A., et al. 2009. The WEKA Data Mining

Software: An Update. SIGKDD Explorations 11, 1.

Kalmegh, S. 2015. Analysis of WEKA Data Mining

Algorithm REPTree, Simple Cart and RandomTree for

Classification of Indian News. IJISET - International

Journal of Innovative Science, Engineering &

Technology, 2.

Kingsford, C., Salzberg, S. L. 2008. What are decision

trees? Nat Biotechnol, 26, 1011-3.

Kumar, S., et al. 2012. Emerging Roles of ADAMTSs in

Angiogenesis and Cancer. Cancers, 4, 1252-1299.

Liu, B., et al. 2004. A combinational feature selection and

ensemble neural network method for classification of

gene expression data. BMC Bioinformatics, 5, 136.

Loh, W.-Y. 2014. Fifty Years of Classification and

Regression Trees. International Statistical Review, 82,

329-348.

Lokuan, E., Ziegler, S.F. 2014. Thymic Stromal

Lymphopoietin (TSLP) and Cancer. Journal of

immunology (Baltimore, Md. : 1950), 193, 4283-4288.

Peruzzi, D., et al. 2009. MMP11: A Novel Target Antigen

for Cancer Immunotherapy. Clinical Cancer Research,

15, 4104-4113.

Podgorelec, V., et al. 2002. Decision trees: an overview

and their use in medicine. J Med Syst, 26, 445-63.

Porter, S., et al. 2004. Dysregulated Expression of

Adamalysin-Thrombospondin Genes in Human Breast

Carcinoma. Clinical Cancer Research, 10, 2429-2440.

Roan, F., et al. 2012. The multiple facets of thymic

stromal lymphopoietin (TSLP) during allergic

inflammation and beyond. Journal of Leukocyte

Biology, 91, 877-886.

Sa'di, S., et al. 2015. Comparison of Data Mining

Algorithms in the Diagnosis of Type Ii Diabetes.

International Journal on Computational Science &

Applications, 5, 1-12.

Saito, Y.D., et al. 2010. Fyn: a novel molecular target in

prostate cancer. Cancer, 116, 1629-1637.

Shah, S., Kusiak, A. 2007. Cancer gene search with data-

mining and genetic algorithms. Comput Biol Med, 37,

251-61.

Tseng, W.T., et al. 2015. The application of data mining

techniques to oral cancer prognosis. J Med Syst, 39,

59.

Witten, I.H., et al., 2011. Data Mining Practical Machine

Learning Tools and Techniques, 3rd ed. Morgan

Kaufmann Publishers, USA.

Comparative Study on Data Mining Techniques Applied to Breast Cancer Gene Expression Proﬁles

175
