Enhancing Accuracy of Android Malware Detection using Intent

Instrumentation

Shahrooz Pooryousef and Morteza Amini

Department of Computer Engineering, Sharif University of Technology, Tehran, Iran

pooryousef@ce.sharif.edu, amini@sharif.edu

Keywords:

Android Security, Malware Detection, Code Instrumentation, Static and Dynamic Analysis.

Abstract:

Event-driven actions in Android malwares and complexity of extracted proﬁles of applications’ behaviors are

two challenges in dynamic malware analysis tools to ﬁnd malicious behaviors. Thanks to ability of event-

driven actions in Android applications, malwares can trigger their malicious behaviors at speciﬁc conditions

and evade from detection. In this paper, we propose a framework for instrumenting Intents in Android appli-

cations’ source code in a way that different parts of the application be triggered automatically at runtime. Our

instrumented codes force the application to exhibit its behaviors and so we can have a more complete proﬁle of

the application’s behaviors. Our framework, which is implemented as a tool, ﬁrst uses static analysis to extract

an application’s structure and components and then, instruments Intents inside the application’s Smali codes.

Experimental results show that applying our code instrumentation framework on applications help exhibiting

more data leakage behaviors such as disclosing Android ID in 79 more applications in a data set containing

6,187 malwares in comparison to using traditional malware analysis tools.

1 INTRODUCTION

Smart Phones play an essential role in many concepts

of our daily life such as entertainment, socialization

and business (Corporation, 2014). Users of these de-

vices can download diverse applications from third

party markets and install them on their devices. As

well as these devices be common, they have become

the primary target of many attackers (Report, 2014).

Android, as the most popular platform in the smart

phone market share(IDC, 2014), has huge malware

surface (Zhou et al., 2012a; Rastogi et al., 2014).

According to the McAfee reports in 2013, Android

has 2.47 million new malware samples, which indi-

cate a 197% increase over 2012 (Report, 2014). Most

of these malwares spread through the online markets

such as Google Play (Zhou et al., 2012a) and these

malwares perform activities such as collecting user in-

formation, sending premium-rate SMS messages, or

stealing credentials (Felt et al., 2011b).

Many different static and dynamic methods have

been proposed in the industry and academic world for

detecting Android malwares. Static analysis meth-

ods (Bartel et al., 2014; Yang et al., 2015; Grace

et al., 2012; Chin et al., 2011) search malicious

signatures inside the application’s source code. In

contrast, dynamic malware analysis methods (Zheng

et al., 2012a; Enck et al., 2014; Gilbert et al., 2011;

Zhou et al., 2012a) run applications inside a sand-

box environment and analyze applications’ behaviors.

Even though dynamic malware analysis tools exhibit

many undesirable behaviors of malwares, they cannot

capture all of the applications’ suspicious behaviors

completely. Android malwares use different tricks to

evade from detection by malware analysis tools. Un-

fortunately, in Android, traditional dynamic malware

analysis methods cannot yield a good accuracy in de-

tecting suspicious behaviors due to the following rea-

sons:

Existing Event-driven Actions. Due to the An-

droid architecture, applications can register some of

their functionalities to be triggered whenever an event

is received or happened in the system. Android mal-

wares use this feature to hide their suspicious be-

haviors in the presence of dynamic malware analy-

sis methods. For example, a malicious action in the

application can be triggered whenever the device is

connected to the charger.

Complexity of Extracted Proﬁles of Applications’

Behaviors. Second problem in Android malware

analysis is the complexity of extracted proﬁles of ap-

plications’ behaviors. In malware detection, getting a

ﬁne grained proﬁles of applications’ internal behav-

380

Pooryousef, S. and Amini, M.

Enhancing Accuracy of Android Malware Detection using Intent Instrumentation.

DOI: 10.5220/0006195803800388

In Proceedings of the 3rd International Conference on Information Systems Security and Privacy (ICISSP 2017), pages 380-388

ISBN: 978-989-758-209-7

iors is critical for obtaining a good accuracy (Zhang

et al., 2013). Some features of Android applications

such as using Binder mechanism prevalently, or inter-

acting with OS services (directly or indirectly) make

extracting the proﬁle of applications a very complex

process. For example, using Binder mechanism leads

generating so many system calls in the application

so that extracting suspicious trace of system calls be-

tween these so many system calls is a challenging task

(Zhang et al., 2013). In addition, after extracting ap-

plication behaviors, we need to consider some other

concepts such as the contexts of actions for differen-

tiating them from the benign behaviors (Yang et al.,

2015).

Evading from detection in Android malwares

along with the complexity of generated proﬁles could

impact on the accuracy of dynamic analysis methods.

With our experiments on a data set containing 6,187

Android malwares, we found that many of the appli-

cations Security Sensitive APIs (SS-APIs) are invok-

ing inside the speciﬁc components such as broadcast

receivers. These components help malwares to trigger

their malicious actions at the speciﬁc conditions. In

this paper, in order to help dynamic malware analysis

methods gathering more complete and exact proﬁles

of applications’ behaviors, we propose a framework

for automatic code instrumentation in Android appli-

cations. With code instrumentation at an application’s

speciﬁc points, we can trigger the application’s hid-

den behaviors and get a straight proﬁle of the appli-

cation’s critical parts. After the instrumentation, our

tool automatically builds and generates an executable

application package and signs it.

In our framework, we enjoy Intents messages

(Chin et al., 2011) to invoke and trigger different parts

of Android applications automatically at runtime. In

our proposed method, in contrast to fuzzing methods,

for analyzing an application, by considering the ap-

plication’s structure and attributes, we do not need

to generate too many input values (Fuzz, 2014). In

fact, our proposed framework, ﬁrst extracts the appli-

cation’s call graph and then, instruments Intents in the

application’s Smali codes and generates a new APK

ﬁle of the application. As we directly work on the

application’s Smali codes and do not need to get the

application’s Java source code, neither decompilation

of the Dalvik byte codes to Java source code nor ob-

fuscation techniques have negative effect on our in-

strumentation process.

The rest of this paper is organized as follows. In

Section 2, some background information about An-

droid applications structure, Intent mechanism, and

Smali format is presented. Section 3, presents the

components of our Intent instrumentation framework,

and describes these components’ functionality, sepa-

rately. After that, we present our evaluation results in

Section 4. Section 5 presents the related work, and

ﬁnally Section 6 concludes the paper and draws the

future work.

2 BACKGROUND

Before describing the proposed method for code in-

strumentation in Android applications, we require

to survey the components of Android applications,

brieﬂy describing the Android Intent mechanism, and

introducing the Smali format of Android applications

source code.

2.1 Components of Android

Applications

Android is a mobile operating system that runs on the

millions of devices in the world. One of the key suc-

cess of the Android huge market share is existence of

diverse applications for this platform; because of the

open nature of its applications market place (Xu et al.,

2012). Android applications usually are developed

in Java language and packaged in APK ﬁles, which

are ZIP compressed ﬁles. Android applications con-

sist of four different components in order to perform

their tasks. These components are activity, service,

broadcast receiver, and content provider. Activities

include applications’ interfaces which users interact

with them. Services are components that are used

for background processing and do not have any inter-

face for interacting with users. Anytime that an action

needs to perform some long operations which do not

need user interactions, developers use such compo-

nents. Broadcast receivers are triggered with broad-

cast messages which are broadcasted by the operat-

ing system or other components of applications. The

content providers can store and retrieve data in many

types such as ﬁle system and SQL Lite data bases.

In addition to these components, Android appli-

cations have an XML ﬁle (Manifest.xml ﬁle) which

includes some important information about an appli-

cation such as the required permissions of the applica-

tion, the names of its components, and the version of

the OS compatible with the application. In Fig. 1, we

have shown a manifest ﬁle where a broadcast receiver

component and a service have been deﬁned.

2.2 Android Intent Mechanism

Android uses Binder and Intent messages for provid-

ing Inter Process Communication. Binder mechanism

Enhancing Accuracy of Android Malware Detection using Intent Instrumentation

381

<intent-filter>

<action

android:name="android.intent.action.BOOT_COMPLETED"

</intent-filter>

</receiver>

</service>

Figure 1: An example of an Android Manifest.xml ﬁle that

deﬁnes a service and a broadcast receiver.

is used when an application requires to interact with

system privileged services (Chen et al., 2015). In or-

der to provide a mechanism for interacting an applica-

tion’s components with each other and also with other

applications’ components, Android uses Intents (Chin

et al., 2011). An Intent object, is a passive data struc-

ture that has an abstract description of an operation

to be performed. In addition to the applications, the

operating system can use Intents for triggering differ-

ent components of applications. Intent invocation is

done through some APIs such as startActivityForRe-

sult, and startActivity. In Android, Intents can be sent

explicitly or implicitly. In explicit sending, sender

speciﬁes the receiver in the Intent deﬁnition. In im-

plicit sending, sender does not specify the receiver

and the operating system based on the Intent descrip-

tion chooses the target application or component for

handling the received Intent.

2.3 Smali Format

Smali format is a representation of dex format (op-

codes) used by Android Dalvik machine (Zheng et al.,

2012a). Smali codes of Android applications can be

obtained using tools such as Apktool (Google, 2014).

To give a small example of the Smali format, in Fig. 2,

the Smali code of a Java method is represented. This

method writes custom log messages.

3 PROPOSED

INSTRUMENTATION

FRAMEWORK

The main idea of our Intent instrumentation frame-

work is to place some speciﬁc Intents at the speciﬁc

points of the application’s source code. The goal is

to trigger the components of the application automat-

ically in order to activate all parts of the application

at runtime. Furthermore, we can choose which com-

.method public log()V

.locals 2

.prologue

.line 13

const-string v0, "remote"

const-string v1, "This is a Log method"

invoke-static {v0, v1}, Landroid/util/Log;->v(Ljava/

lang/String;Ljava/lang/String;)I

.line 14

return-void

.end method

Figure 2: Smali format of a method.

ponents of the application be run respectively with

regards to the application’s function call graph. As

we do not have access to the application’s Java code,

we use Smali codes for Intent instrumentation. The

overall architecture of our framework has been de-

picted in Fig. 3. Our tool is based on static analy-

sis, and thus we disassemble Android applications to

the Smali ﬁles ﬁrst. Then, we specify the structure

of the application, for example the application’s call

graph and type of the components and their input val-

ues which are passed to them at runtime. After the in-

strumentation, we decompile the application’s Smali

ﬁles to generate a new APK ﬁle. In below, each of

these steps are explained.

3.1 Disassembling Application

In the ﬁrst phase, our tool takes an APK ﬁle, disas-

sembles its dex ﬁle, and generates Smali ﬁles for all

application’s components, for example broadcast re-

ceivers and services. We disassemble applications’

APK ﬁles using Apktool (Google, 2014). In this step,

each Smali ﬁle is mapped to a single Java class, and

its path corresponds to the path of the Java class in

the application’s source code. Working directly on

the Smali codes helps us to overcome the obfuscation

techniques which make most static analysis tools in-

efﬁcient.

3.2 Extracting Application Structure

The tool then, parses the application manifest and

Smali ﬁles for extracting the application’s structure,

i.e., the application’s call graph. We used Androguard

toolset (Desnos, 2014) to construct the application’s

function call graph in this step. Thereafter, we parse

the application’s manifest ﬁle to extract the names of

ICISSP 2017 - 3rd International Conference on Information Systems Security and Privacy

382

Apk

file

Disassemble

apk

Manifest

Smali

Files

Extract Application

Structur, Services and

Broadcast Receivers

Instrument

Fake Intents

Sign

apk

Apk

file

Figure 3: The steps of our Intent instrumentation framework.

A B

Figure 4: Dependency in component invocation.

its components. For generating Intents in the next

step, we need some information about each compo-

nent, such as components’ expected values, whenever

they are invoked from other components at runtime.

In this step, these values are identiﬁed and extracted.

3.3 Instrumenting Intents

Manipulating an application’s Smali codes and

adding some new codes between Smali instructions

can inﬂuence the application’s main execution ﬂow

and so leads to change the application’s original be-

haviors. In addition, we cannot guarantee that merg-

ing our Intent codes into the target application, does

not affect the manipulated application to crash after

installation. Also, we need to make sure that our in-

strumented Intents will invoke the application’s dif-

ferent components at runtime. Speciﬁcally, for instru-

menting Smali codes inside Android applications we

need to consider the following issues.

Application Functionality: The order and depen-

dency of invoking the application’s components must

be considered in triggering the application’s compo-

nents. For example, as depicted in Fig. 4, ﬁrst, com-

ponent A calls component B and then, component C

is triggered by component B. So, we must consider

this sequence and dependency in generating our In-

tents for the application. In addition, for some compo-

nents, namely SMS receivers, if the target component

expects some speciﬁc inputs, we must include these

inputs in our Intent deﬁnition.

Executing Instrumented Codes: Another issue

in instrumenting Intents, is assurance of executing the

injected codes. If the application execution reaches

with low probability to where our Intents have been

instrumented, the place of instrumentation is not ap-

propriate. This is a crucial issue; because our Intents

must surely invoke the application different compo-

nents.

In order to overcome the above constraints, we

instrument our Intents at a speciﬁc point of the ap-

plication. The best point is the application’s main

activity. Each application in Android, has an activ-

ity which is the application’s main entry point. This

activity is speciﬁed with ”LUANCHER” tag in the

manifest ﬁle. As oncreate method exists in all ac-

tivities, we chose this method for placing our Smali

codes. We found experimentally that the function’s

beginning is the most appropriate place for placing

our codes and instrumenting in other places leads ap-

plications to crash at runtime.

Another challenge is the registers of the oncreate

method. If they are manipulated carelessly, it can re-

sult in crashing the application at runtime. In Dalvik

bytecode, registers are always 32 bits, and can hold

any type of values; however there is a limitation on

the number of registers for each method. As we re-

quire to use registers in deﬁning our Intents and in-

voking them, changing the values of the registers that

are used in another points of the application is risky.

In our proposed framework, we need only three reg-

isters for Intent deﬁnition. However, for some com-

ponents, if we require to pass some values to a target

component, we need more registers.

In instrumentation, we consider components that

have at least one SS-API. SS-APIs are APIs in An-

droid system which handle a security sensitive action

in the system (for example, connection to the Internet)

(Yang et al., 2015). These APIs trigger the Android

access control mechanism whenever they are invoked.

We have used Felt et al. (Felt et al., 2011a) proposed

method for identifying SS-APIs in applications.

Algorithm 1 depicts the steps of our Intent instru-

mentation approach. After the instrumentation, our

tool automatically generates an executable APK and

Enhancing Accuracy of Android Malware Detection using Intent Instrumentation

383

signs it, which can be installed on the device. Our

framework sign each instrumented APK using a ran-

domly generated key.

Algorithm 1: Intent Instrumentation Flow chart.

Input: Application

s Smali Files, Application

Call Graph

Output: Instrumented APK f ile

1: Find the Application’s main activity and oncreate

function

2: for Each application Component: do

3: if Component is an end point in the call graph

and have SS-API then

4: Extract components’ attributes

5: Generate Intents with considering com-

ponents structure

6: Instrument Intents in Oncreate

7: end if

8: end for

9: return Instrumented APK f ile

4 IMPLEMENTATION AND

EXPERIMENTAL RESULTS

We implemented the proposed framework to show

the applicability of the proposed approach and eval-

uate it. In our implementation, we used Andro-

Guard (Desnos, 2014) modules for constructing ap-

plications’ function call graphs. For identifying the

Android privileged APIs, we used the results of Felt

et al. (Felt et al., 2011a) research. In order to dis-

assemble APK ﬁles to Smali ﬁles, we employed Apk-

tool (Google, 2014). Apktool allows us to take an An-

droid APK ﬁle, convert it into a Smali source repre-

sentation, and then recompile it back into a new APK

ﬁle. We used Python scripts for static analysis and

integrating the mentioned tool set and modules.

Using the implemented framework we can evalu-

ate the feasibility and the beneﬁcial of our code in-

strumentation approach on malware detection. First,

we show the impact of proﬁling the speciﬁc parts (or

components) of applications on analyzing application

behaviors. Afterward, we evaluate the impact of our

Intent instrumentation on illustrating more suspicious

behaviors of Android malwares using traditional mal-

ware analysis frameworks such as AppsPlayground

(Rastogi et al., 2013). We analyze how the accu-

racy of malware analysis tools can be enhanced af-

ter Intent instrumentation. The following subsections,

demonstrate the practical advantages of our Intent in-

strumentation framework.

4.1 Malware Collection

To evaluate our framework, we collected 6,187 An-

droid malwares, which are publicly available for re-

searchers, in June 2016. Among these malwares,

4,367 Android malwares were downloaded from

Virus share repository (VirusShare, 2014) and 1,820

malwares from ISBX center (ISBX, 2014). Our mal-

ware data set consists both old and new malware sam-

ples, and contains samples of the most known mal-

ware families.

4.2 Extracting Proﬁles of Applications

As explained in 1, the complexity of extracted pro-

ﬁles of applications can produce challenges for tradi-

tional proposed solutions in extracting and analyzing

suspicious behaviors. In this section, we show that

how separate analyzing the different components of

an application can simplify the identiﬁcation of the

suspicious behaviors of the application. Note that our

goal is not identifying the malicious behaviors and we

just illustrate that extracting and separate analyzing an

application’s different components can show up clues

about suspicious behaviors quickly. We consider a

trace of function call graph which reach an SS-API

as a sign of a suspicious behavior in our analysis pro-

cess. Distinguishing malicious behaviors from the be-

nign ones in the extracted behaviors requires further

analysis using mechanism, such as machine learning

techniques, which is out of the scope of this paper.

We analyzed the whole data set for characteriz-

ing how much Android components namely broadcast

receivers and services are used in Android malwares

and how many of applications’ overall SS-APIs in-

clude in each component. As indicated in Fig. 5,

5,870 of the collected malwares (94.8%) contain at

least one service and, 5,265 of the collected malwares

(85%) include at least one broadcast receiver. Also,

3,633 of the malwares have at least 7 services and

2,400 of the malwares have at least 7 broadcast re-

ceivers. Almost 54 percent of applications’ SS-APIs

are invoked in broadcast receiver and service compo-

nents as depicted in Fig. 6. This indicates that most

of the malwares use SS-APIs in broadcast receivers

and services permanently. In this way, malwares can

trigger their malicious behaviors at the speciﬁc condi-

tions and can evade from detection in malware analy-

sis tools.

Considering behaviors of components separately

can be helpful in ﬁnding malicious behaviors using

traditional analysis methods, especially the ones an-

alyzing applications’ behaviors at system call level.

We did a simple experiment on our data set for sup-

ICISSP 2017 - 3rd International Conference on Information Systems Security and Privacy

384

1 2 3 4 5 6 7

Services 5870 5290 5402 5116 3902 3658 3633

Broadcast Receiver 5265 4847 4389 4009 3760 2801 2400

1000

2000

3000

4000

5000

6000

7000

1 2 3 4 5 6 7

Services Broadcast Receiver

Figure 5: Number of components used in the malwares.

Activity Service Broadcast Receiver

Content Provider

Java Class

20% 29% 25% 5% 21%

20%

29%

25%

21%

10%

15%

20%

25%

30%

35%

Activity Service Broadcast

Receiver

Content

Provider

Java Class

Figure 6: Percent of used SS-APIs in the components of

malwares.

porting this claim. We disassembled some of col-

lected malwares using Apktool and analyzed Smali

ﬁles of these malwares. Precisely, we tracked appli-

cations’ function call graph in order to ﬁnd a trace of

API calls which results in invoking an SS-API as a

sign of suspicious behavior. We found that for ﬁnd-

ing a suspicious behavior in an application (a trace

of APIs), we need to analyze in average six traces of

function calls as depicted in Fig. 7. However, if we

analyze different parts of applications’ proﬁles sepa-

rately, we need to analyze only ﬁve traces in average.

Of course, for ﬁnding some malicious behaviors, we

may need more comprehensive analysis on the whole

application’s proﬁle.

Specific Profile

Complete Profile

0 0

6 8

5 6

9 5

4 8

8 6

3 12

6 9

7 10

4 7

2 14

9 9

4 6

7 10

1 2 3 4 5 6 7 8 9 10 11 12 13 14

Number of analyzed traces

Number of tries fo finding a malicious trace

Complete Profile

Specific Profile

Figure 7: Extracting malicious behavior per trace.

Table 1: Overall detection of more leaked private informa-

tion in our dataset.

Information type Number of applications

Android ID 79

IMEI 67

Phone number 11

Contact number 9

Location data 10

4.3 Malware Analysis in Presence of

Intent Instrumentation

Here, the advantages of our code instrumentation on

exposing malware suspicious behaviors using one of

the most comprehensive dynamic malware analysis

tools, named AppsPlayground (Rastogi et al., 2013),

is evaluated. Although our instrumentation approach

can be employed in any dynamic malware analysis

framework such as CopperDroid (Tam et al., 2015)

or VetDroid (Zhang et al., 2013), we employed it in

AppsPlayground, due to the fact that its source code is

available online and has a very friendly interface. We

compared the reports of AppsPlayground on our in-

strumented APKs with reports generated on the orig-

inal APKs.

AppsPlayground is a framework for automated

dynamic security analysis of Android applications. It

integrates a number of detection, exploration, and dis-

guise techniques to come up with an effective analysis

environment. AppsPlayground can detect malicious

activities inside malwares and also activities that are

not malicious but can be annoying.

AppsPlayground tracks some data such as An-

droid ID and IMSI in applications. Android ID is used

to identify a user device and is a unique ID for each

device. It is used usually in speciﬁc applications such

as games or applications which need to identify the

user’s device. IMSI identiﬁes a GSM subscriber on

the cellular network. Other types of data that might

be leaked include contact numbers and location data.

In order to evaluate the AppsPlayground accuracy af-

ter Intent instrumentation, we compared the reported

data leakage in two runs of it on our data set.

After applying our framework on the data set

including 6,187 malwares, we identiﬁed exposures

of private sensitive information in 79 instrumented

applications which did not identiﬁed by AppsPlay-

ground employing original APKs. Even though ap-

plying our framework on our data set did not make

AppsPlayground to identify new uncaptured mal-

wares, our instrumentation leads to exposing more

suspicious behaviors in analyzed applications. The

results of the detection of more leaked private infor-

Enhancing Accuracy of Android Malware Detection using Intent Instrumentation

385

mation are presented in Table 1. The found expo-

sures include 79 leakage of Android ID and 67 leak-

age of IMEI. In the identiﬁed malwares, which leak

user information, we found that related components

need speciﬁc inputs. In fact, our instrumented codes

force the components to be triggered and exhibit their

behaviors. In addition, in 16 malwares, we saw that

instrumented codes trigger some components of the

applications which invoke native codes developed in

C and C++ language. Although native codes may be

used by benign Android applications for performance

reasons, since the native code can have system call

directly, malwares can use this capability to exploit

vulnerabilities in OS kernel level.

5 RELATED WORK

There are several studies on the analysis of Android

applications and characterizing the behaviors of An-

droid malwares. In this section, we categorize the re-

lated studies into static code instrumentation, and dy-

namic analysis methods.

5.1 Code Instrumentation and Static

Analysis

Code instrumentation in Android applications and

generating new APK from modiﬁed Smali ﬁles can

be used for benign or malicious purposes. Some work

use code instrumentation at runtime or statically, as

what we do for analyzing Android applications, for

detecting application vulnerabilities. Karami et al.

(Karami et al., 2013) proposed a framework for au-

tomatic code instrumentation in Android applications

using behaviors of applications at runtime and also

I/O system calls of applications. Aurasium (Xu et al.,

2012) enforces user security policies in Android ap-

plications which enables dynamic and ﬁne-grained

policy enforcement. Aurasium, In contrast to work

such as (Bugiel et al., 2013), (Jeon et al., 2012), and

(Pooryousef and Amini, 2016), which modify An-

droid source code for preparing a ﬁne grained access

control in applications, automatically repackages ar-

bitrary applications to attach user-level sandboxing

and policy enforcement code (Xu et al., 2012). In-

telliDroid (Wong and Lie, 2016) is a generic Android

input generator to produce inputs speciﬁc to dynamic

analysis tools, in order to achieve higher code cover-

age in malware analysis process. ApkCombiner (Li

et al., 2015) combines multiple Android applications

using applications’ Smali codes to analyze inter app

vulnerabilities. ADAM (Zheng et al., 2012b) uses

Smali code instrumentation for evaluating Android

antivirus softwares. In comparison to the existing

code instrumentation frameworks, our framework, by

considering application structure and attributes of ap-

plications’ components, can trigger applications’ hid-

den behaviors and get a straight proﬁle of the appli-

cations’ critical parts. Using our framework, we can

consider invoking some speciﬁc components. This

is a good idea for analyzing the behaviors of some

speciﬁc components separately. In addition, for ma-

licious purposes, attackers can instrument malicious

Smali codes into benign and popular Android appli-

cations (Zhou et al., 2012b; Zhou et al., 2013).

Analyzing source code of Android applications

have been widely covered in many works which focus

on static analysis methods. Appcontext (Yang et al.,

2015) uses context of actions in Android applications

to identify and differentiate malicious and benign ac-

tions. AppContext uses static analysis to extract the

application function call graph and related actions and

then correlates application contexts with the actions.

SAAF (Hoffmann et al., 2013) analyzes application

Smali codes and creates program slices for perform-

ing data-ﬂow analysis. Bartel et al. (Bartel et al.,

2014) use static analysis for extracting permissions

in Android applications. ANDROGUARD (Desnos,

2014) is a tool set that decompiles and analyzes An-

droid applications in order to detect malicious appli-

cations using their signatures. Stowaway (Felt et al.,

2011a) statically analyzes that how an application

uses Android APIs to detect whether an application’s

requests overpass its privileges or not. Woodpecker

(Grace et al., 2012) analyzes Smali codes of appli-

cations statically to uncover capability leaks. Intent’s

vulnerabilities in components of Android applications

have been analyzed with ComDroid framework pro-

posed in (Chin et al., 2011).

5.2 Dynamic Analysis

Dynamic analysis of Android applications’ behaviors

is considered in many researches. We brieﬂy intro-

duce these works but do not elaborate them in details,

because their overlap with our work is rather small.

TaintDroid (Enck et al., 2014) uses data tainting for

tracking data ﬂows inside applications for preserv-

ing user privacy. AppInspector (Gilbert et al., 2011)

can automatically generate input and log during pro-

gram executions, and can detect privacy leakage be-

haviors by the analysis of log information. AppsPlay-

ground (Rastogi et al., 2013) tries to drive applica-

tions along multiple paths in order to reveal their sus-

picious behaviors. SmartDroid (Zheng et al., 2012a)

focuses on Android applications’ behaviors which

trigger with user interactions and uses Smali code

ICISSP 2017 - 3rd International Conference on Information Systems Security and Privacy

386

analysis for revealing application’s structures. Vet-

Droid (Zhang et al., 2013) identiﬁes explicit and im-

plicit permission use points inside applications and

generates proﬁles of the applications based of these

points. DROIDRANGER (Zhou et al., 2012a) imple-

ments a combination of a permission-based behav-

ioral foot printing scheme to detect samples of al-

ready known malware families and a heuristic-based

ﬁltering scheme to detect unknown malicious appli-

cations. Some other methods such as (Peiravian and

Zhu, 2013; Sahs and Khan, 2012) and (Burguera

et al., 2011) use machine learning for analyzing dif-

ferent features of applications for malware detection.

6 CONCLUSION AND FUTURE

WORK

Dynamic analysis tools usually cannot extract a com-

plete and precise proﬁle of applications’ behaviors or

cannot trigger or extract behaviors of speciﬁc compo-

nents of applications separately. In this paper, we pro-

posed a framework for instrumenting Intents in An-

droid applications’ Smali codes. Our instrumented

Intents, trigger different components of applications

automatically at runtime. We ﬁrst showed that ex-

tracting proﬁles belong to some speciﬁc components

of applications can simplify the analysis of applica-

tions’ behaviors, and consequently facilitates ﬁnding

suspicious behaviors. Then, further investigation us-

ing a dynamic malware analysis tool, named App-

sPlayground, showed that code instrumentation (for

forcing some components to be invoked) can facili-

tate detecting more malicious or suspicious behaviors

in applications. We successfully applied our instru-

mentation framework to a data set of 6,187 malware

applications. Experimental results showed that apply-

ing our code instrumentation framework on the ap-

plications, help exhibiting more data leakage such as

Android ID in 79 more applications in comparison to

using traditional malware analysis tools with no In-

tent instrumentation. However, our framework can-

not trigger the native codes that are directly used in

applications. In addition, some of the applications in

our collected malwares do not produce manifest ﬁle

in disassembling process of our framework.

REFERENCES

Bartel, A., Klein, J., Monperrus, M., and Le Traon, Y.

(2014). Static analysis for extracting permission

checks of a large scale framework: The challenges and

solutions for analyzing android. In IEEE Transactions

on Software Engineering, volume 40, pages 617–632.

IEEE.

Bugiel, S., Heuser, S., and Sadeghi, A.-R. (2013). Flexi-

ble and ﬁne-grained mandatory access control on an-

droid for diverse security and privacy policies. In Pre-

sented as part of the 22nd USENIX Security Sympo-

sium (USENIX Security 13), pages 131–146.

Burguera, I., Zurutuza, U., and Nadjm-Tehrani, S. (2011).

Crowdroid: behavior-based malware detection system

for android. In Proceedings of the 1st ACM workshop

on Security and privacy in smartphones and mobile

devices, pages 15–26. ACM.

Chen, J., Chen, H., Bauman, E., Lin, Z., Zang, B., and

Guan, H. (2015). You shouldn’t collect my se-

crets: Thwarting sensitive keystroke leakage in mo-

bile ime apps. In Proceedings of 24th USENIX Se-

curity Symposium (USENIX Security 15), pages 657–

690. USENIX Association.

Chin, E., Felt, A. P., Greenwood, K., and Wagner, D.

(2011). Analyzing inter-application communication in

android. In Proceedings of the 9th international con-

ference on Mobile systems, applications, and services,

pages 239–252. ACM.

Corporation, I. D. (2014). Android mar-

ket share reached 75% worldwide in q3

2012. http://techcrunch.com/2012/11/02/idc-

androidmarket-share-reached-75-worldwidein-q3-

2012 Access time: May 7,2013.

Desnos, A. (2014). Androguard-reverse engineering, mal-

ware and goodware analysis of android applications.

https:

code.google.com/p/androguard Access time: 2013,

May.

Enck, W., Gilbert, P., Han, S., Tendulkar, V., Chun, B.-G.,

Cox, L. P., Jung, J., McDaniel, P., and Sheth, A. N.

(2014). Taintdroid: An information-ﬂow tracking sys-

tem for realtime privacy monitoring on smartphones.

In ACM Transactions on Computer Systems (TOCS),

volume 32, pages 5:1–5:29. ACM.

Felt, A. P., Chin, E., Hanna, S., Song, D., and Wagner, D.

(2011a). Android permissions demystiﬁed. In Pro-

ceedings of the 18th ACM conference on Computer

and communications security, pages 627–638. ACM.

Felt, A. P., Finifter, M., Chin, E., Hanna, S., and Wagner,

D. (2011b). A survey of mobile malware in the wild.

In Proceedings of the 1st ACM workshop on Security

and privacy in smartphones and mobile devices, pages

3–14. ACM.

Fuzz (2014). Fuzz. http://pages.cs.wisc.edu/bart/fuzz/ Ac-

cess time: 2008, May.

Gilbert, P., Chun, B.-G., Cox, L. P., and Jung, J. (2011).

Vision: automated security validation of mobile apps

at app markets. In Proceedings of the second interna-

tional workshop on Mobile cloud computing and ser-

vices, pages 21–26. ACM.

Enhancing Accuracy of Android Malware Detection using Intent Instrumentation

387

Google (2014). Apktool. https:code.google.compandroid-

apktool Access time: 2016, May.

Grace, M. C., Zhou, Y., Wang, Z., and Jiang, X. (2012).

Systematic detection of capability leaks in stock an-

droid smartphones. In Proceedings of the Network

and Distributed System Security Symposium (NDSS),

volume 14, page 19. Internet Society.

Hoffmann, J., Ussath, M., Holz, T., and Spreitzenbarth,

M. (2013). Slicing droids: program slicing for smali

code. In Proceedings of the 28th Annual ACM Sympo-

sium on Applied Computing, pages 1844–1851. ACM.

IDC (2014). Android and ios continue to domi-

nate the worldwide smartphone market with an-

droid shipments just shy of 800 million in 2013.

http://www.idc.com/getdoc.jsp Access time: February

2014.

ISBX (2014). An online data set of malwares.

http://www.unb.ca/research/iscx/dataset/ Access time:

2015, May.

Jeon, J., Micinski, K. K., Vaughan, J. A., Fogel, A., Reddy,

N., Foster, J. S., and Millstein, T. (2012). Dr. android

and mr. hide: ﬁne-grained permissions in android ap-

plications. In Proceedings of the second ACM work-

shop on Security and privacy in smartphones and mo-

bile devices, pages 3–14. ACM.

Karami, M., Elsabagh, M., Najaﬁborazjani, P., and Stavrou,

A. (2013). Behavioral analysis of android applications

using automated instrumentation. In Proceedings of

the IEEE 7th International Conference on Software

Security and Reliability-Companion (SERE-C), pages

182–187. IEEE.

Li, L., Bartel, A., Bissyand

e, T. F., Klein, J., and Le Traon,

Y. (2015). Apkcombiner: Combining multiple an-

droid apps to support inter-app analysis. In Proceed-

ings of the IFIP International Information Security

Conference, pages 513–527. Springer.

Peiravian, N. and Zhu, X. (2013). Machine learning for

android malware detection using permission and api

calls. In Proceedings of the IEEE 25th International

Conference on Tools with Artiﬁcial Intelligence, pages

300–305. IEEE.

Pooryousef, S. and Amini, M. (2016). Fine-grained ac-

cess control for hybrid mobile applications in android

using restricted paths. In Information Security and

Cryptology (ISCISC), 2016 13th International Iranian

Society of Cryptology Conference on, pages 85–90.

IEEE.

Rastogi, V., Chen, Y., and Enck, W. (2013). Appsplay-

ground: automatic security analysis of smartphone ap-

plications. In Proceedings of the 3rd ACM conference

on Data and application security and privacy, pages

209–220. ACM.

Rastogi, V., Chen, Y., and Jiang, X. (2014). Catch me if you

can: Evaluating android anti-malware against trans-

formation attacks. In IEEE Transactions on Informa-

tion Forensics and Security, volume 9, pages 99–108.

IEEE.

Report, M. T. (2014). Third quarter 2012.

http://www.mcafee.com/ca/resources/reports/rp-

quarterly-threat-q3-2012.pdf Access time: May 7,

2013.

Sahs, J. and Khan, L. (2012). A machine learning ap-

proach to android malware detection. In Proceedings

of the Intelligence and Security Informatics Confer-

ence (EISIC), 2012 European, pages 141–147. IEEE.

Tam, K., Khan, S. J., Fattori, A., and Cavallaro, L. (2015).

Copperdroid: Automatic reconstruction of android

malware behaviors. In Proceedings of the Network

and Distributed System Security Symposium (NDSS).

Internet Society.

VirusShare (2014). An online data set of malwares.

https:virusshare.com Access time: 2015, May.

Wong, M. Y. and Lie, D. (2016). Intellidroid: A targeted

input generator for the dynamic analysis of android

malware. In Proceedings of the Annual Symposium

on Network and Distributed System Security (NDSS),

pages 1–15. The Internet Society.

Xu, R., Sa

ıdi, H., and Anderson, R. (2012). Aurasium:

Practical policy enforcement for android applications.

In Proceedings of the 21st USENIX Security Sympo-

sium (USENIX Security 12), pages 539–552. USENIX

Association.

Yang, W., Xiao, X., Andow, B., Li, S., Xie, T., and Enck,

W. (2015). Appcontext: Differentiating malicious and

benign mobile app behaviors using context. In 37th

IEEE International Conference on Software Engineer-

ing, volume 1, pages 303–313. IEEE.

Zhang, Y., Yang, M., Xu, B., Yang, Z., Gu, G., Ning, P.,

Wang, X. S., and Zang, B. (2013). Vetting undesir-

able behaviors in android apps with permission use

analysis. In Proceedings of the ACM SIGSAC confer-

ence on Computer & communications security, pages

611–622. ACM.

Zheng, C., Zhu, S., Dai, S., Gu, G., Gong, X., Han, X., and

Zou, W. (2012a). Smartdroid: an automatic system for

revealing ui-based trigger conditions in android appli-

cations. In Proceedings of the 2nd ACM workshop on

Security and privacy in smartphones and mobile de-

vices, pages 93–104. ACM.

Zheng, M., Lee, P. P., and Lui, J. C. (2012b). Adam: an

automatic and extensible platform to stress test an-

droid anti-virus systems. In International Conference

on Detection of Intrusions and Malware, and Vulner-

ability Assessment, pages 82–101. Springer.

Zhou, W., Zhang, X., and Jiang, X. (2013). Appink: water-

marking android apps for repackaging deterrence. In

Proceedings of the 8th ACM SIGSAC symposium on

Information, computer and communications security,

pages 1–12. ACM.

Zhou, Y., Wang, Z., Zhou, W., and Jiang, X. (2012a). Hey,

you, get off of my market: Detecting malicious apps in

ofﬁcial and alternative android markets. In Proceed-

ings of the Network and Distributed System Security

Symposium (NDSS), volume 25, pages 50–52.

Zhou, Y., Wang, Z., Zhou, W., and Jiang, X. (2012b). Hey,

you, get off of my market: Detecting malicious apps in

ofﬁcial and alternative android markets. In Proceed-

ings of the Network and Distributed System Security

Symposium (NDSS), volume 25, pages 50–52.

ICISSP 2017 - 3rd International Conference on Information Systems Security and Privacy

388
