Cluster Analysis of Twitter Data: A Review of Algorithms

Noufa Alnajran, Keeley Crockett, David McLean and Annabel Latham

School of Computing, Math and Digital Technology, Manchester Metropolitan University,

John Dalton Building, All Saints, Manchester, M1 5GD, U.K.

Keywords: Clustering, Social Network Analysis, Twitter, Data Mining, Machine Learning.

Abstract: Twitter, a microblogging online social network (OSN), has quickly gained prominence as it provides people

with the opportunity to communicate and share posts and topics. Tremendous value lies in automated

analysing and reasoning about such data in order to derive meaningful insights, which carries potential

opportunities for businesses, users, and consumers. However, the sheer volume, noise, and dynamism of

Twitter, imposes challenges that hinder the efficacy of observing clusters with high intra-cluster (i.e.

minimum variance) and low inter-cluster similarities. This review focuses on research that has used various

clustering algorithms to analyse Twitter data streams and identify hidden patterns in tweets where text is

highly unstructured. This paper performs a comparative analysis on approaches of unsupervised learning in

order to determine whether empirical findings support the enhancement of decision support and pattern

recognition applications. A review of the literature identified 13 studies that implemented different clustering

methods. A comparison including clustering methods, algorithms, number of clusters, dataset(s) size, distance

measure, clustering features, evaluation methods, and results was conducted. The conclusion reports that the

use of unsupervised learning in mining social media data has several weaknesses. Success criteria and future

directions for research and practice to the research community are discussed.

1 INTRODUCTION

The rapid evolution of web 2.0 technologies such as

OSN applications, has led to the continuous

generation of an enormous volume of digital

heterogeneous data being published at an

unprecedented rate. These technologies have

significantly changed the way people communicate

and share information among each other in various

domains. Millions of people have shifted from the

traditional media channels such as newspapers, to

online social media. In this context, Twitter has

gained massive popularity as it provides an informal

platform where people can easily publish and

broadcast messages on different areas across the

world. It had a prominent role in spreading awareness

of natural disasters such as Hurricane Sandy and

socio-political events such as the Arab Spring (Kumar

et al., 2014). This has made Twitter an important

source of information for synthesizing evidence in

argumentation, and a goldmine of potential cross-

domain opportunities for both businesses and

decision makers. However, the exponential amount of

user generated content on this site is too vast for

manual analysis. More than 500 million short-text

messages, referred to as “tweets”, are published every

day (Krestel et al., 2015). This requires an automated

and scalable mining process to discover patterns in

the unstructured data.

Cluster analysis is the unsupervised process of

grouping data instances into relatively similar

categories, without prior understanding of the groups

structure or class labels (Han et al., 2011). It is a

prominent component of exploratory data analysis. A

subfield of clustering includes text mining, where

large volumes of text are analysed to find patterns

between documents (Godfrey et al., 2014). The

growth of these unstructured data collections,

advances in technology and computer power, and

enhanced software capabilities, has made text mining

an independent academic field. Moreover, the

emergence of OSNs has yielded new frontiers for

academic research, where researchers in the broad

area of Natural Language Processing consider text

analysis one of the most important research areas.

Recent studies in various disciplines have shown

increasing interest in micro-blogging services,

particularly Twitter (Sheela, 2016). The applications

of text mining tools for studying features of content

Alnajran N., Crockett K., McLean D. and Latham A.

Cluster Analysis of Twitter Data: A Review of Algorithms.

DOI: 10.5220/0006202802390249

In Proceedings of the 9th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2017), pages 239-249

ISBN: 978-989-758-220-2

239

and semantics in tweets propagating through the

network has been widely studied (Kumar et al., 2014).

Several studies have aimed at analysing social data

from Twitter through performing data mining

techniques such as classification (Castillo et al.,

2011). However, these techniques could be

considered to have limited capabilities due to the

unpredictable nature of the dataset. Cluster analysis

of tweets has been reported to be particularly suitable

for this kind of data for two reasons (Go et al., 2009):

(1) the amount of data for training is too vast for

manual labelling. (2) The nature of the data implies

the existence of unforeseen groups that may carry

important nuggets of information which can only be

revealed by unsupervised learning.

Among the research conducted around clustering

tweets’ short-text and other text mining applications

on Twitter, researchers aim to find relevant

information such as inferring users’ interests and

identifying emergent topics. However, several natural

challenges of the data prevent standard clustering

algorithms being applied with their full potentials:

 Sparseness –unlike traditional clustering of

documents which are rich in context, tweets are

restricted to 140 characters.

 Non-standardization –people invented many ways

to expand the semantics that are carried out by the

tweet. This implies the usage of slangs,

misspelled, and connected words. Users also use

self-defined hashtags to identify topics or events.

 Volume –the rapid generation of tweets results in

high volumes of data.

Therefore, due to the textual length restriction of the

text, the content in tweets is limited, however it still

may contain rich meanings. Therefore, tweets require

intelligent techniques, such as incorporating semantic

technologies that can analyse datasets with such

complex characteristics and convey meanings and

correlations.

The main purpose of this paper is to:

 Review various clustering algorithms that are

implemented on different features of Twitter

datasets.

 Review various domains of applications and

success criteria that are used for measuring and

evaluating the accuracy of the algorithm.

 Compare relevant approaches in terms of

clustering methods, algorithms, number of

clusters, dataset(s) size, distance measure,

clustering features, evaluation methods, and

results.

 Recommend future directions for research and

practice to the research community.

To the best of our knowledge, there does not exist

research that reviews the prominent clustering

algorithms available to use on challenging, large, and

unstructured data such as Twitter. Thus, this shall

provide a thorough literature review and a valuable

source of information on the state of the art for

relevant research in this field.

The rest of this paper is organized as follows:

section 2 describes the methods that are used in this

review. Section 3 includes the techniques of mining

Twitter datasets that use four clustering methods: (1)

partition-based, (2) hierarchical-based, (3) hybrid-

based, and (4) density-based. Section 4 contains the

discussion and section 5 has the conclusion and future

work. A table providing a summary of the studies

featured in this review is located at the end of the

paper.

2 METHODS

2.1 Literature Search Procedures

In this review, multiple research databases were

investigated, such as Google Scholar and DeepDyve,

to conduct online searches. This process includes

searching for the following terms: ‘mining Twitter

short-text’, ‘clustering tweets’, ‘unsupervised

learning on Twitter’, and ‘categorization of tweets’.

2.2 Inclusion Criteria

The inclusion criteria for this paper includes research

that involve:

 An implementation of one of the following

clustering methods: partition, hierarchical, hybrid,

and density, on Twitter short-text messages. The

reason for choosing these methods is that these

generally cover the major clustering algorithms

and have not been reviewed previously in the

context of Twitter data.

 An approach to find hidden patterns and similar

groups of information in tweets using models of

unsupervised learning.

A total of 13 articles from 2011 to present have met

the inclusion criteria as Twitter text mining

applications using unsupervised learning.

3 CLUSTER-BASED TWITTER

MINING

Many clustering methods exist in the literature, and it

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

240

is difficult to provide a crisp categorization of these

methods as they may overlap and share features.

Nevertheless, the major clustering methods are

included in this review (Han et al., 2011).

Clustering has been widely studied in the context

of Twitter mining. It has been applied to analyse

social behaviours in a variety of domains to achieve

different tasks, such as tailoring advertisements for

groups with similar interests (Friedemann, 2015),

event detection (De Boom et al., 2015), and trending

issues extraction (Purwitasari et al., 2015). This

review focuses on the major clustering methods:

partition, hierarchical, hybrid, and density, which

have been used in the context of Twitter data.

3.1 Partition-based Clustering

Partitioning algorithms attempt to organize the data

objects into k partitions (k ≤ n), each representing a

cluster, where n is the number of objects in a dataset.

Based on a distance function, clusters are formed such

that objects within the cluster are similar (intra-

similarity), whereas dissimilar objects lie in different

clusters (inter-similarity). Partitioning algorithms can

be further divided into hard and fuzzy (soft)

clustering. In this section, six articles are summarized

in which partitioning-based clustering algorithms has

been applied in the exploratory analysis of Twitter.

3.1.1 Hard Clustering

Methods of hard partitioning of data assign discrete

value label 0, 1, in order to describe the belonging

relationship of objects to clusters. These conventional

clustering methods provide crisp membership

assignments of the data to clusters. K-means and k-

medoids are the most popular hard clustering

algorithms (Preeti Arora, 2016).

K-means is a centroid-based iterative technique

which takes the number of representative instances,

around which the clusters are built. Data instances are

assigned to these clusters based on a dissimilarity

function (i.e. distance measure). In each iteration, the

mean of the assigned points to the cluster is calculated

and used to replace the centroid of the last iteration

until some criteria of convergence is met.

K-means has been adapted in numerous ways to

suit different datasets including numerical, binary,

and categorical features. In the context of Twitter

mining applications, k-means approach for clustering

customers of a company using social media data from

Twitter was proposed (Friedemann, 2015). The

technique constructs features from a massive Twitter

dataset and clusters them using a similarity measure

to produce groupings of users. The study performed

k-means clustering and produced satisfactory

experimental results. It is considered to be relatively

computational efficient. In (Soni and Mathai, 2015),

a ‘cluster-then-predict’ model was proposed to

improve the accuracy of predicting Twitter sentiment

through a composition of both supervised and

unsupervised learning. After building the dataset, k-

Means was performed such that tweets with similar

words are clustered together. This unsupervised phase

was performed after a feature extraction process.

After the clustering phase, classification was done on

the same data. The data was divided into training and

testing sets, with 70% and 30% of the data

respectively. Finally, the Random Forest learning

algorithm was used for building the learning model,

which was applied to each of the training datasets

individually (Breiman, 2001).

This algorithm has

been chosen as it provides satisfactory trade-off

between accuracy, interpretability, and execution

time. Empirical evaluation shows that combining

both supervised and unsupervised learning (k-Means

then Random Forest) performed better than various

stand-alone learning algorithms.

K-medoids is an object-based representative

technique that deals with discrete data. It is an

improvement to k-means in relation to its sensitivity

to outliers. Instead of referring to the mean value of

cluster objects, k-medoids picks the nearest point to

the center of data points as the representative of the

corresponding cluster. Thus, minimizing the sum of

distances between each object, o, and its

corresponding center point. That is, the sum of the

error for all objects in each cluster is calculated as

(Han et al., 2011),







∈





(1)

Where k is the number of clusters, p is an object in the

cluster C

, while o

is the representative objects of C

The lower the value of E, the higher clustering

quality.

A recent study focused on the usage of k-medoids

algorithm for tweets clustering due to its simplicity

and low computational time (Purwitasari et al., 2015).

In this study, the author applied this algorithm to

extract issues related to news that is posted on Twitter

such as “flight passengers asking for refund” in

Indonesia. Their proposed methodology for Twitter

trending issues extraction consists of clustering tweets

with k-medoids, in which they divided the tweets

dataset into groups and used a representative tweet as

the cluster center. Issue terms are then selected from

the clusters result and assigned higher weight values.

Cluster Analysis of Twitter Data: A Review of Algorithms

241

The terms that weigh over a certain threshold are

extracted as trending issues. Weight score is

calculated as the frequency of word occurrences in the

dataset. Average Silhouette Width (Rousseeuw,

1987), a method for validating clusters’ consistency,

was used to measure and evaluate the clustering

performance (Ramaswamy, [no date]). In the work,

the experiments demonstrated good results of using k-

medoids for this purpose, however, re-tweets (i.e.

duplicates) had influenced the clustering results.

Another study used k-means and k-medoids

respectively to cluster a single Twitter dataset and

compare the results of each algorithm (Zhao, 2011).

Initially, k-means was applied, which took the values

in the matrix as numeric, and set the number of

clusters, k, to eight. After that, the term-document

matrix was transformed to a document-term one and

the clustering was performed. Then, the frequent

words in each cluster and the cluster centers were

computed in order to find what they are about. The

first experiment showed that the clusters were of

different topics. The second experiment was

conducted using k-medoids, which used

representative objects instead of means to represent

the cluster center.

K-medoids has the advantage of robustness over

k-means as it is less influenced by noise and outliers.

However, this comes at the cost of efficiency. This is

due to the high processing time that is required by k-

medoids compared to k-means. Both methods require

the number of clusters, k, to be fixed. In terms of

clustering sparse data such as tweets, k-medoids may

not be the best choice as these do not have many

words in common and the similarities between them

are small and noisy (Aggarwal and Zhai, 2012). Thus,

a representative sentence does not often contain the

required concepts in order to effectively build a

cluster around it.

3.1.2 Fuzzy Clustering

This partition-based method is particularly suitable in

the case of no clear groupings in the data set. Unlike

hard clustering, fuzzy algorithms assign a continuous

value [0, 1] to provide reasonable clustering. Multiple

fuzzy clustering algorithms exist in the literature,

however fuzzy c-means (FCM) is the most prominent.

FCM provides a criteria on grouping data points

into different clusters to varying degrees that are

specified by a membership grade. It incorporates a

membership function that represents the fuzziness of

its behaviour. The data are bound to each cluster by

means of this function.

In the context of Twitter analysis, a recent study

presented a simple approach using fuzzy clustering

for pre-processing and analysis of hashtags (Zadeh et

al., 2015). The resulting fuzzy clusters are used to

gain insights related to patterns of hashtags popularity

and temporal trends. To analyse hashtags’ dynamics,

the authors identified groups of hashtags that have

similar temporal patterns and looked at their linguistic

characteristics. They recognised the most and least

representative hashtags of these groups. The adopted

methodology is fuzzy clustering based and multiple

conclusions were drawn on the resulting clusters with

regards to variations of hashtags throughout a period

of time. Their clustering was based on the fact that

categorization of hashtags is not crisp, rather, most

data points belong to several clusters according to

certain degrees of membership. Another study

compared the performance of supervised learning

against unsupervised learning in discriminating the

gender of a Twitter user (Vicente et al., 2015). Given

only the unstructured information available for each

tweet in the user’s profile, the aim is to predict the

gender of the user. The unsupervised learning

involved the usage of soft in conjunction with hard

clustering algorithms. K-means and FCM were

applied on a 242K Twitter users’ dataset. The

unsupervised approach based on FCM proved to be

highly suitable for detecting the user’s gender,

achieving a performance of about 96%. It also has the

privilege of not requiring a labelled training set and

the possibility of scaling up to large datasets with

improved accuracy.

Experiments have shown that fuzzy-based

clustering is more complex than clustering with crisp

boundaries. This is because the former requires more

computation time for the involved kernel (Bora et al.,

2014). Fuzzy methods provide relatively high

clustering accuracy and more realistic probability of

belonging. Therefore, they can be considered an

effective method that excludes the need of a labelled

dataset. This is particularly useful for sheer volumes

of tweets, where human annotations can be highly

expensive. However, these methods generally have

low scalability and results can be sensitive to the

initial parameter values. In terms of optimization,

fuzzy clustering methods can be easily drawn into

local optimal.

3.2 Hierarchical-based Clustering

In hierarchical clustering algorithms, data objects are

grouped into a tree like (i.e. hierarchy) of clusters.

These algorithms can be further classified depending

on whether their composition is formed in a top-down

(divisive) or bottom-up (agglomerative) manner. This

section reviews three studies that performed

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

242

hierarchical-based clustering algorithms in

applications of Twitter mining.

Hierarchical clustering was used for topic

detection in Twitter streams, based on aggressive

tweets/terms filtering (Ifrim et al., 2014). The

clustering process was performed in two phases, first

the tweets and second the resulting headlines from the

first clustering step. Their methodology is composed

of initially computing tweets pair-wise distances

using the cosine metric. Then computing a

hierarchical clustering so that tweets belonging to the

same topic shall cluster together, and thus each cluster

is considered as a detected topic. Afterwards, they

controlled the tightness of clusters by cutting the

resulting dendrogram at 0.5 distance threshold. In this

way they will not have to provide the number of

required clusters a-priori as in k-Means. The

threshold was set to 0.5 in order to avoid having loose

or tight clusters, rather, a value of 0.5 worked well for

their method. Each resulting cluster is then assigned

a score and ranked according to that score. The top-

20 clusters are then assigned headlines, which are the

first tweet in each of them (with respect to publication

time). The final step involved re-clustering the

headlines to avoid topic fragmentation, also using

hierarchical clustering, the resulting headlines are

then ranked by the one with the highest score inside a

cluster. The headlines with the earliest publication

time are selected and their tweet text is presented as a

final topic headline. Another research implemented a

hierarchical approach for the purpose of helping users

parse tweets results better by grouping them into

clusters (Ramaswamy, [no date]). The aim was for

fewer clusters that are tightly packed, rather than too

many large clusters. The work involved using a

dataset of tweets to see how the choice of the distance

function affects the behaviour of hierarchical

clustering algorithms. Ramaswamy conducted a

survey of two clustering algorithms that are both

hierarchical in nature but different in their core

implementation of the distance function has been

conducted. A total of 925 tweets comprising of

various topics with common keyword have been used

in the experiments. In the first algorithm, the author

considered each of the given objects to be in different

clusters. Then determining if the object o is close

enough to cluster c, and if so, add o to c. This process

continues until the maximum size of the desired

clusters is reached or no more new clusters can be

formed. In this first algorithm, the notion of the

distance between an object and a cluster has been

defined using concepts from association rule

problems –support and confidence. The second

algorithm maintained the average distance of an

object from each element in the cluster as the

similarity measure. If the average is small enough, the

object is added to the cluster. Both clustering

algorithms were implemented using C# and involve

reading the tweets, tokenizing them, clustering them

and returning the clustered output. Although the

overall behaviour was found to be similar for both

algorithms, the second one seemed to fare better for

each of the confidence and support level value. An

integrated hierarchical approach of agglomerative

and divisive clustering was proposed to dynamically

create broad categories of similar tweets based on the

appearance of nouns (Kuar, 2015).

The bottom-up

approach merges similar clusters together to reduce

their redundancy. The technique adopted a recursive

and incremental process of dividing and combining

clusters in order to produce more meaningful sorted

clusters. It has shown an increase in clustering

effectiveness and quality compared to standard

hierarchical algorithms.

In this context, empirical evaluations provided

that hierarchical methods performed slower than hard

partition-based clustering, particularly k-means

(Manpreet Kaur, 2013). Therefore, for massive social

media datasets, hard partitioning methods are

considered to be relatively computationally efficient

as well as producing acceptable experimental results.

3.3 Hybrid-based Clustering

Because hierarchical clustering algorithms tend to

compare all pairs of data, their robustness is relatively

high. However, this makes them not very efficient

due to their tendency to require at least O(n

)

computation time. On the other hand, partitioning

algorithms may not be the optimal choice despite

being more efficient than hierarchical algorithms.

This is because the former may not be very effective

as they tend to rely on small number of initial cluster

representatives. This trade-off has led researchers to

propose several clustering algorithms that combined

the features of hierarchical and partitioning methods

in order to improve their performance and efficiency.

These hybrid algorithms include any aggregations

between clustering algorithms. In general, they

initially partition the input dataset into sub clusters

and then construct a new hierarchical cluster based on

these sub clusters.

There is not much research conducted using a

hybrid clustering approach in the area of Twitter

mining. Nevertheless, one approach implemented

clustering of keywords that are presented in the tweets

using agglomerative hierarchical clustering and crisp

c-means (Miyamoto et al., 2012). The clustering

Cluster Analysis of Twitter Data: A Review of Algorithms

243

features was based on a series of tweets as one long

sequence of keywords. The approach involved

building two datasets, each composed of 50 tweets in

different timeframes. Several observations of

agglomerative clusters obtained by cutting the

dendrogram and c-means clusters, with and without

pair-wise constrains were analysed. Better clustering

results are provided using pair-wise constrains,

however, the size of datasets is relatively small for a

generalization.

3.4 Density-based Clustering

This method groups data located in the region with

high density of the data space to belong to the same

cluster. Therefore, it is capable of discovering clusters

with arbitrary shape. DBSCAN (Density-Based

Spatial Clustering of Applications with Noise) is the

prominent density-based algorithm. It grows regions

with sufficiently high density into clusters (Ester et

al., 1996). In this section, three articles are

summarized in which density-based algorithms has

been applied in the exploratory analysis of Twitter.

A density-based clustering has been adopted in

the context of Twitter textual data analysis to discover

cohesively the information posted by users about an

event as well as the user’s perception about it (Baralis

et al., 2013). The provided framework adopts a

multiple-level clustering strategy, which focuses on

disjoint dataset portions iteratively and identifies

clusters locally. DBSCAN has been exploited for the

cluster analysis as it allows discovering arbitrarily

shaped clusters, and increases cluster homogeneity by

filtering out noise and outliers. Additionally, it does

not require prior specification of the number of

expected clusters in the data. In this approach,

DBSCAN has been applied iteratively on disjoint

dataset portions and all the original dataset is

clustered at the first level. Then, tweets labelled as

outliers in the previous level are re-clustered at each

subsequent level. To discover representative clusters

for their Twitter dataset, they attempt to avoid clusters

containing few tweets. They also attempt to limit the

number of tweets labelled as outliers and thus un-

clustered, in order to consider all different posted

information. Through addressing these issues,

DBSCAN parameters were properly set at each level.

A recent study employed DBSCAN as part of its

novel method for creating an event detection ground

truth through utilizing tweets hashtags (De Boom et

al., 2015). The authors clustered co-occurring

hashtags using DBSCAN. The method required

setting two thresholds: the minimum number of

hashtags per cluster and a minimum similarity

measure between two hashtags, above which the two

hashtags belong to the same neighbourhood. A

collection of clusters of sufficiently co-occurring

hashtags on the same day were obtained by running

DBSCAN for every day in the dataset. A recent study

has introduced the application of DBSCAN for

representing meaningful segments of tweets in batch

mode (Anumol Babu, 2016). The segmentation was

done based on calculations of the stickiness score.

This score considers the probability of a segment

being a phrase within the batch of tweets (i.e. local

context) and the probability of it being a phrase in

English (i.e. global context) (Weng et al., 2015).

Sentimental variations in tweets were then analysed

based on these segments. Each word in the text is

assigned a sentiment score according to a

predetermined sentiment lexicon. The sentiment of a

tweet is then denoted as the summation of the most

positive score and the most negative score among

individual words in the tweet. In this approach, the

core of the clustering consisted of integrating

DBSCAN with Jaccard Coefficient similarity

function. Empirical evaluations indicated an

enhancement of the existing system as a result of

using DBSCAN for clustering,

It can be observed from the literature surrounding

Density-based algorithms in Twitter mining, that they

are highly efficient and can be particularly suitable for

clustering unstructured data, such as tweets, as it

allows the identification of clusters with arbitrary

shape. Moreover, it is less prone to outliers and noise,

and does not require initial identification of the

required number of clusters. However, clustering high

data volumes requires big memory size.

4 DISCUSSION

Several approaches of unsupervised learning

applications for mining unstructured social media

data have been reviewed and presented in table 1. The

table provides a comparison on the features that are

used in the studies including: research approach,

clustering method, algorithm, number of clusters,

dataset size, distance measure, clustering features,

evaluation methods, and results. The review

comprises 13 studies spanning from 2011 to the

present. These studies have different approaches, in

which the clustering of Twitter data was performed in

various settings and domains to achieve different

business values or satisfy certain requirements. These

approaches range from pure clustering perspectives,

such as determining the impact of a distance function

choice on clustering behaviour, to a more general

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

244

pattern recognition application, such as targeting

advertisements and events detection. The majority of

the studies performed clustering in order to detect

news, topics, events, and facts and to predict

sentiments. Different clustering methods and

algorithms were implemented in these studies, each

of different dataset and number of clusters. From the

13 reviewed datasets, it can be observed that the

average dataset size is 162,550 for tweets textual data,

ranging from 50 to 1,084,200 and average of 126,329

for Twitter user accounts, ranging from 10,000 to

242,658 distinct user accounts. The majority of the

dataset sizes observed in the surveys are relatively

small, which means that the high volume challenge of

Twitter data has not been taken into consideration.

Therefore, in order for these algorithms to be

effective, they should be able to scale well to the

massive amounts of Twitter data. In this matter, the

scalability (in terms of clustering performance) of

most of the algorithms implemented in the surveys is

questionable as these algorithms have not been tested

on considerably large datasets.

As partitioning algorithms require the number of

clusters, c, to be pre-set, c has been included in the

review to provide an indication on the number of

clusters that might be appropriate for similar tasks.

From the provided comparisons, the average number

of clusters maintained can be derived, which is 7, with

2 as the minimum clusters and 10 as the maximum.

The table additionally compared the different

distance measures used. It can be observed that

Euclidean distance is the prominent for partitioning

algorithms, whereas hierarchical algorithms

commonly implemented the cosine similarity

measure. In terms of clustering features, different sets

were used depending on the implemented approach.

The features observed from the review include some

or all of the following:

 Hashtags –31% of the reviewed surveys included

hashtags in the features set and considered their

impact, 23% treated hashtags as normal words in

the text, and 31% removed hashtags before

analysis (excluding the 15% studies that are

clustering upon user accounts).

 Account metadata –username, date, status,

latitude, longitude, followers, and account

followings.

 Tweet metadata –tweet id, published date, and

language.

 Maintaining a BOW of the unique words

contained in each textual data of a tweet and their

frequencies as the feature vector. Some included

hashtags in the BOW while others ignored them.

None of the surveys studied the impact of retweets

nor “@mentions”. Rather, some datasets did not

remove the retweeted tweets which affected the

resulting clustering credibility. Because tweets

commonly get large number of retweets, keeping

them in the dataset will produce large clusters

containing redundant tweets rather than tweets with

similar features. This will consequently reinforce

false patterns and increase run time.

Evaluation methods vary from robust measures,

such as ASW to manual observations, such as

manually comparing an algorithm’s detected topics

with Google news headlines. ASW has been utilised

by most of the studies to measure the clustering

performance. Some of the evaluation methods are

derived from other data mining techniques such as

association rules and classification. These methods

include clustering based on confidence and support

levels, and calculating precision, recall and the F

measure from a confusion matrix.

5 CONCLUSION

The review contributes to the literature in several

significant ways. First, it provides a comparative

analysis on applications that utilized and tuned text

mining methods, particularly clustering, to the

characteristics of Twitter unstructured data. Second,

the review concentrated on algorithms of the general

clustering methods: (1) partition-based, (2)

hierarchical-based, (3) hybrid-based, and (4) density-

based, in Twitter mining. Third, unlike existing

reviews which provides high level and abstract

specification of surveys, this review was

comprehensive in that it provided comparative

information and discussion across the dataset size,

approach, clustering methods, algorithm, number of

clusters, distance measure, clustering feature,

evaluation methods, and results.

Thirteen articles were reviewed in this paper, and

the results indicated that there is a sufficient

improvement in the exploratory analysis of social

media data. However, many of the existing

methodologies have limited capabilities in their

performance and thus limited potential abilities in

recognising patterns in the data:

 Most of the dataset sizes are relatively small

which is not indicative of the patterns in social

behaviours and therefore generalised conclusions

cannot be drawn. Because of the sparsity of

Twitter textual data, it is difficult to discover

representative information in small datasets.

Cluster Analysis of Twitter Data: A Review of Algorithms

245

Therefore, future studies should aim to increase

the size of the dataset.

 Some of the algorithms implemented may have

provided effective results in terms of efficiency

and accuracy. However, this may be attributed to

the small size of dataset as the scalability has not

been evaluated.

 Some of the reviewed datasets included redundant

tweets (i.e. retweets) which yields inaccurate

clustering. Therefore future studies should

perform a comprehensive pre-processing phase in

which retweets and other noise, such as URLs, are

removed from the dataset prior to clustering.

 Most of the studies implemented keyword-based

techniques, such as term frequencies and BOW

which ignores the respective order of appearance

of the words and does not account for correlations

between text segments. Therefore, future research

should incorporate and measure the underlying

semantic similarities in the dataset.

In conclusion, after conducting this review it can be

clearly noticed that clustering is an important element

of exploratory text analysis in which unstructured

data can be useful for pattern recognition as well as

identification of user potentials and interests.

However, future research must demonstrate the

effectiveness of such approaches through acquiring

larger datasets in order for the algorithms to be useful

in discovering knowledge and applicable in several

contexts and domains. A meta-analysis review is

recommended as a future work, which will provide a

quantitative estimate for the impact and usefulness of

clustering methods in providing insights from social

media data.

Table 1: Summary of the studies featured in this review.

Author

& Year

Approach Method

Algorithm &

Number of

Clusters (C)

Dataset

Size

Distance

Measure

Clustering

Features

Evaluation

Methods

Results

(Friedem

ann,

2015)

Targeting

advertise-

ments

Partitioning-Based Clustering

Hard Partitioning

k-Means

C: 5

10,000

Twitter

user

account

Euclidean

distance

posted status,

number of

followers and

account followings,

latitude, longitude,

whether a popular

Twitter account

(influencer) is

followed

Computing a

metric of

clustering quality

q. The lower the

value of q, the

better clustering

performance

Achieved

clustering is

midway between

ideal and

randomized data.

Experiments

emphasized the

credibility of

Twitter data for

market analysis

(Soni

and

Mathai,

2015)

Sentiment

prediction

k-Means

C: 2

1200

“Apple

” tweets

Squared

Euclidean

distance

Bag-of-Words

(BOW) from

twitter corpus

(frequency of

word

occurrences)

Confusion

matrix and ROC

(Receiver

Operator

Characteristic)

graph

Model

integration of

supervised and

unsupervised k-

Means learning

improved twitter

sentiment

prediction

(Purwita

sari et

al., 2015)

News

summary

k-Medoids

C: 10

200

tweets

(geo-

location:

Indonesi

Cosine

similarity

Term

frequencies and

weight in tweet

text.

Hashtags

omitted

The larger

ASW value,

the more

homogeneous

the cluster

result

Inclusion of

retweets

affected cluster

result quality

(Zhao,

2011)

R Data

Mining

k-Means

C: 8

200

tweets

from

@rdata

mining

account

Euclidean

distance

Term

frequencies in

tweet text

(document-term

matrix).

Hashtags

omitted

Checked the

top 3 terms in

every cluster

Clusters of

different topics

k-Medoids

C: 9

Manhattan

distance

ASW

Clusters overlap

and not well

separated

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

246

Table 1: Summary of the studies featured in this review. (cont.)

Author

& Year

Approach Method

Algorithm &

Number of

Clusters (C)

Dataset

Size

Distance

Measure

Clustering

Features

Evaluation

Methods

Results

(Vicente

et al.,

2015)

Gender

detection

k-Means

C: 2

242,658

unique

Twitter

users

Euclidean

distance

Screen name

and user name

Two

experiments: 1

used labelled

data for building

clusters and

evaluating

performance. 2

used unlabelled

data for

clustering and

labelled for

evaluation

C-Means

provided better

clustering

performance

than k-Means.

More usage of

unlabelled data

significantly

enhanced c-

means but got k-

Means worse

Fuzzy Partitioning

c-Means

C: 2

(Zadeh

et al.,

2015)

Events and

facts

detection

FANNY

(Kaufman

and

Rousseeuw,

2009)

C: 6

distinct

hashtag

Manhattan

Distance

Temporal

aspects of

hashtags

Defined a misfit

measure to

identify

elements’ degree

of “not fitting”

into a cluster.

Clustering

performance

measured using

ASW

Insights into

patterns

associated with

each cluster for

hashtags

changing

popularities

over time

(Ifrim et

al., 2014)

Topic

detection

Hierarchical-Based Clustering

Agglomerative

(dendrogram cut

at 0.5)

dataset:

1,084,200

tweets. 2

943,175

JSON

format

English

tweets

Cosine

similarity

Date, tweet

id, text, user

mentions,

hashtags,

URLs,

media

URLs, and

retweet or

not

(1) a subset of ground

truth topics, (2)

google for the

automatically

detected topic

headline, in the

manual assessment o

how many detected

topics are actually

published news in

traditional media

Application of

agglomerative

clustering can detect

topics with 80%

accuracy. However,

not efficient for real-

time data analysis.

(Ramas

wamy,

[no

date])

Impact of

distance

function

choice on

clustering

behaviour

Two Ward

(Jr., 1963)

algorithms

C: 5

925 tweets

Ratio of

tweets

appearing in

different

clusters

Tokenization

of tweets’

texts

Several experiments

conducted to

determine

appropriate values

of confidence and

support levels

which determine

further clustering

Generally similar

behaviour of the 2

algorithms. In terms

of fewer, tightly

packed clusters, 2

algorithm fared

better for confidence

and support values

Avg.

distance

between

tokens and

clusters

(Kaur,

2015)

Noun-

ased

categorizatio

Agglomerative

15062

“Stem

Cell”

tweets

Inter-

cosine

similarity

Frequency

occurrences

for nouns

in tweets.

Hashtags

omitted

Experimental

comparisons of

clustering quality

against: k-means,

Ward, and DBSCAN

clustering.

Combinatorial

approach provided

higher accuracy

compared to existing

methodologies,

however, at the cost

of performance.

Clustering runtime:

1hour

Divisive

Intra-

cosine

similarity

(Miyamo

to et al.,

2012)

Keyword

clustering

Hybrid-based

Clustering

Hard c-Means

(partitioning)

C: 2

dataset:

50 tweets

(35 terms

occur > 8

times)

: 50

tweets (38

terms occur

> 5 times)

Squared

Euclidean

distance

Sequence of

word

occurrences

in a set of

tweets

Several observations

of: clusters with and

without pair-wise

constraints

clusters obtained by

cutting the

dendrogram with and

without pair-wise

constraints

Application of

pair-wise

constraints

improved

clustering quality.

However, dataset

size is arguably

small

Agglomerative

(hierarchical)

C: 2

Cluster Analysis of Twitter Data: A Review of Algorithms

247

Table 1: Summary of the studies featured in this review. (cont.)

Author

& Year

Approach Method

Algorithm &

Number of

Clusters (C)

Dataset

Size

Distance

Measure

Clustering

Features

Evaluation

Methods

Results

(Baralis

et al.,

2013)

Cohesive

information

discovery

Density-Based Clustering

DBSCAN “Paralymp

ics”

dataset:

1969

tweets

Cosine

similarity

BOW of tweets

including

hashtags

ASW Effective in

discovering

knowledge.

Performance

relatively low for

not very large

dataset.

Clustering

runtime: 2min

9sec

May not scale

well to massive

datasets

“Concert”

dataset:

2960

tweets

(De

Boom et

al., 2015)

Event

detection

DBSCAN 63,067

tweets

(geolocati

on:

Belgium)

Sum of avg.

occurrences

of both

hashtags per

day/2

Hashtags co-

occurrence

matrix

Precision,

recall, and F

measures

Improvement in

event detection and

clustering through

high-level semantic

information

(Anumol

Babu,

2016)

Sentiment

Analysis

DBSCAN 100

synthetic

tweets

Jaccard

similarity

Tweet text and

publication time.

Hashtags

omitted

Evaluating

tweets

segmentation

and its

accuracy

through an

experiment

Enhancement of

the present

system as

DBSCAN was

integrated

REFERENCES

Aggarwal, C. C. & Zhai, C. 2012. Mining Text Data,

Springer Science & Business Media.

Anumol Babu, R. V. P. 2016. Efficient Density Based

Clustering of Tweets and Sentimental Analysis Based

on Segmentation. International Journal of Computer

Techniques, 3, 53-57.

Baralis, E., Cerquitelli, T., Chiusano, S., Grimaudo, L. &

Xiao, X. Analysis of Twitter Data Using A Multiple-

Level Clustering Strategy. International Conference on

Model and Data Engineering, 2013. Springer, 13-24.

Bora, D. J., Gupta, D. & Kumar, A. 2014. A Comparative

Study Between Fuzzy Clustering Algorithm and Hard

Clustering Algorithm. Arxiv Preprint Arxiv:1404.6059.

Breiman, L. 2001. Random Forests. Machine Learning, 45,

5-32.

Castillo, C., Mendoza, M. & Poblete, B. Information

Credibility On Twitter. Proceedings Of The 20th

International Conference On World Wide Web, 2011.

ACM, 675-684.

De Boom, C., Van Canneyt, S. & Dhoedt, B. Semantics-

Driven Event Clustering In Twitter Feeds. Making

Sense Of Microposts, 2015. Ceur, 2-9.

Ester, M., Kriegel, H.-P., Sander, J. & Xu, X. A Density-

Based Algorithm for Discovering Clusters in Large

Spatial Databases with Noise. KDD, 1996. 226-231.

Friedemann, V. 2015. Clustering A Customer Base Using

Twitter Data.

Go, A., Bhayani, R. & Huang, L. 2009. Twitter Sentiment

Classification Using Distant Supervision. Cs224n

Project Report, Stanford, 1, 12.

Godfrey, D., Johns, C., Meyer, C., Race, S. & Sadek, C.

2014. A Case Study in Text Mining: Interpreting

Twitter Data from World Cup Tweets. Arxiv Preprint

Arxiv:1408.5427.

Han, J., Pei, J. & Kamber, M. 2011. Data Mining: Concepts

And Techniques, Elsevier.

Ifrim, G., Shi, B. & Brigadir, I. Event Detection in Twitter

Using Aggressive Filtering and Hierarchical Tweet

Clustering. Second Workshop on Social News on the

Web (Snow), Seoul, Korea, 8 April 2014, 2014. ACM.

Jr., J. H. W. 1963. Hierarchical Grouping to Optimize an

Objective Function. Journal of the American Statistical

Association, 58, 236-244.

Kaufman, L. & Rousseeuw, P. J. 2009. Finding Groups in

Data: An Introduction to Cluster Analysis, John Wiley

& Sons.

Kaur, N., 2015. A Combinatorial Tweet Clustering

Methodology Utilizing Inter and Intra Cosine

Similarity (Doctoral Dissertation, Faculty Of Graduate

Studies And Research, University Of Regina).

Krestel, R., Werkmeister, T., Wiradarma, T. P. & Kasneci,

G. Tweet-Recommender: Finding Relevant Tweets for

News Articles. Proceedings of the 24th International

Conference on World Wide Web, 2015. ACM, 53-54.

Kumar, S., Morstatter, F. & Liu, H. 2014. Twitter Data

Analytics, Springer.

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

248

Manpreet Kaur, U. K. 2013. Comparison Between K-Mean

And Hierarchical Algorithm Using Query Redirection.

International Journal of Advanced Research in

Computer Science and Software Engineering 3, 54-59.

Miyamoto, S., Suzuki, S. & Takumi, S. Clustering In

Tweets Using A Fuzzy Neighborhood Model. Fuzzy

Systems (Fuzz-Ieee), 2012 IEEE International

Conference On, 2012. IEEE, 1-6.

Preeti Arora, D. D., Shipra Varshney. Analysis of k-Means

and k-Medoids Algorithm for Big Data. 2016 India.

Procedia Computer Science, 507-512.

Purwitasari, D., Fatichah, C., Arieshanti, I. & Hayatin, N.

k-Medoids Algorithm on Indonesian Twitter Feeds for

Clustering Trending Issue as Important Terms in News

Summarization. Information & Communication

Technology And Systems (ICTS), 2015 International

Conference On, 2015. IEEE, 95-98.

Ramaswamy, S. Comparing The Efficiency of Two

Clustering Techniques.

Rousseeuw, P. J. 1987. Silhouettes: A Graphical Aid to the

Interpretation and Validation of Cluster Analysis.

Journal of Computational and Applied Mathematics,

20, 53-65.

Sheela, L. 2016. A Review of Sentiment Analysis in Twitter

Data Using Hadoop. International Journal of Database

Theory And Application, 9, 77-86.

Soni, R. & Mathai, K. J. 2015. Improved Twitter Sentiment

Prediction Through Cluster-Then-Predict Model. Arxiv

Preprint Arxiv:1509.02437.

Vicente, M., Batista, F. & Carvalho, J. P. Twitter Gender

Classification Using User Unstructured Information.

Fuzzy Systems (Fuzz-IEEE), 2015 IEEE International

Conference On, 2015. IEEE, 1-7.

Weng, J., Li, C., Sun, A. And He, Q., 2015. Tweet

Segmentation and Its Application to Named Entity

Recognition.

Zadeh, L. A., Abbasov, A. M. & Shahbazova, S. N.

Analysis Of Twitter Hashtags: Fuzzy Clustering

Approach. Fuzzy Information Processing Society

(Nafips) Held Jointly With 2015 5th World Conference

On Soft Computing (WCONSC), 2015 Annual

Conference of the North American, 2015. IEEE, 1-6.

Zhao, Y. 2011. R and Data Mining: Examples and Case

Studies.

Cluster Analysis of Twitter Data: A Review of Algorithms

249
