Agent-based Reconfigurable Natural Language Interface to Robots

Human-Agent Interaction using Task-specific Controlled Natural Languages

Tamás Mészáros and Tadeusz Dobrowiecki

Department of Measurement and Information System,

Budapest University of Technology and Economics, Budapest, Hungary

Keywords: Human-Machine Interaction (HMI), Human-Robot Interface (HRI), Human/Robot-Communication (HCL),

Controlled Natural Language (CNL), Robot Operating System (ROS).

Abstract: We present the architecture of a flexible natural language based interface to robots involved in tasks in a

mixed-initiative human-robot environment. The designed interface uses a bidirectional natural language

communication pertinent to the user, the robot and the tasks at hand. Tasks are executed via agents that can

communicate and engage in conversation with the user using task-specific controlled natural languages. The

final interface language is dynamically composed and reconfigured at the interface level according to the tasks

and skills of the robotic system. The multi-agent infrastructure is fused with the ROS robotic middleware to

provide seamless communication to all system components at various level of abstraction.

1 INTRODUCTION

The evolution of robots from strict manufacturing to

various service domains widened the spectrum of the

potential human collaborators to humans not versed

in the details of the robotic systems.

In such mixed robot-human teams (let it be an

ailing elderly and the household robot, robotic

museum guide and its visitors, shopping mall guide

and customers, etc.), the principal communication

modality is the natural human language (NL), getting

in addition around the reading and typing by

assuming speech modality (Burgard 1999, Rousseau

2013, Khayrallah 2015). Such level of interaction

does not demand from the human agent any

additional professional knowledge and skills beside

the natural knowledge of the task and goals.

Using natural language (i.e. speech) alone was

already considered and serious reviews are available

(Bastianelli 2014, Schiffer 2012). The natural

language interactions were also discussed in the

context of service robotics, ranging from simple

canned commands, via speech act protocols to the full

natural language conversation without any

constraints and limitations (Fong 2003).

Plenty of research has already been done in

translating human NL demands into commands

interpretable by the robot, even to the low level of the

ROS commands (Lauria 2002, MacMahon 2006,

Kemke 2007, Tellex 2011, Schiffer 2012, Howard

2014, Bastianelli 2014, Ferland 2014, Stenmark

2015). These approaches however addressed

applications where the robot had a number of well-

defined configuration and fixed set of tasks for which

natural languages were designed, and only a few

considered the option (and the potential) of the robot

feed-back in natural language (Green 2009) or more

complex dialogues with humans (Huber 2002).

A fully bi-directional and adaptive NL-based

human-robot interface (HRI) requires an architecture

that is more advanced. The grammar and the

vocabulary of the human-to-robot NL interaction

should dynamically adapt to the specifics of the robot

design and the changing set of tasks and situations

that the robot encounters. In order to achieve this our

approach was to design a system that can dynamically

change the natural language used on the HRI by

seamlessly integrating task-specific sublanguages

used by individual components (agents) in the robotic

system.

It is almost impossible to tackle this task in a

uniform, generic and formal way. Some components

admitting an informal, ad hoc design must also be

included in the HRI architecture and design. In the

present paper we propose an architecture constraining

the communication to the level of so called controlled

natural language (Wyner 2009). Our aim here is to

keep the format of the conversation well acceptable

632

MÃl’szÃ ˛aros T. and Dobrowiecki T.

Agent-based Reconﬁgurable Natural Language Interface to Robots - Human-Agent Interaction using Task-speciﬁc Controlled Natural Languages.

DOI: 10.5220/0006205306320639

In Proceedings of the 9th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2017), pages 632-639

ISBN: 978-989-758-220-2

to the human, yet formally treatable by the robotic

system to be used also internally between the

distributed system components.

The context of the development is an interesting

mixed-initiative application domain (described in

detail in Section 3), where the robot acts as a guide to

the human, and where the human acts as the helper to

the robot, essentially acting for its costly gripping and

sensing. It makes the design of the robot simpler (and

permits to move more intelligence and resources to

other system components), and extends the spectrum

of the manageable objects (as a gripper human arm

and hand outperforms the robotic technology in the

variety of objects it can handle with gentleness and

precision, in size, weight, shape, texture, etc.,

grasping, stacking, turning, placing, ... all with the

same "gripper").

Our contribution here aims at the principled

development of a bidirectional and flexible

conversation interface spanning the full robotic

system, from the hand held devices to the ROS nodes

in the robot middleware.

2 ROS-BASED ROBOTS

2.1 Robot Operating System

ROS based system implementation means a

collection of loosely coupled, independent computing

entities (nodes) exchanging information via

asynchronous messages. The ROS Master is that part

of ROS, which is responsible for providing topical

connectivity ("yellow pages") among the nodes.

ROS system can be deployed across multiple

machines, with one of them designated to host the

master. A node is a running instance of a ROS

program. (Well-designed) ROS nodes are loosely

coupled, with (generally) no programmed-in

knowledge about other nodes in the architecture.

ROS nodes communicate with each other using a

publisher-subscriber model: they send messages to a

declared topic (publishing) and receive on demanded

topic (subscribing). A node that wants to share

information will publish messages on the appropriate

ROS topic and a node that wants to receive

information will subscribe to that topic. The ROS

Master ensures that nodes will find each other. The

messages themselves are sent directly from publisher

to subscriber.

2.2 Reconfigurable Robots

One of the essential so called core robotic system

abilities (beside adaptability, interaction, motion,

manipulation, perception, cognitive ability,

dependability, and decisional autonomy) is the

configurability. It means the ability of the robot to be

configured to perform a task or reconfigured to

perform different tasks (H2020). Configuration may

range from a simple change of parameter values,

through re-programming the system, up to being able

to alter the physical structure of the system

(especially its body of sensors and actuators).

The configuration ability can be the prerogative of

the system designer, but can be moved into the hands

of the user, or even the robot itself. Among many

possible mechanisms of configuration (configuration

files, skilled operator interaction, unskilled operator

interaction, automatic arrangement, remote

communication of configuration, see (H2020)) the

unskilled operator case is for us of special

importance, as such operator (plain user) required

usually an unprofessional and natural interface to

interact with the robotic system, where the speech

modality offers itself at once.

In the next section we will see that the intelligent

trolley (our prototype) is configured from the buying

user to the buying user, being effectively re-

programmed by the user’s shopping list and in the

real-time by the course of conversation with the

customer. The developed natural language interface

(configurable linguistically in itself) is thus a tool in

the hands of the user to configure the general purpose

intelligent robot to become his or her personalized

service robot, at least for the timespan of buying.

3 THE PILOT SCENARIO

Our prototype robot called iTrolley works in a self-

service warehouse environment where its main task is

to help customers to collect (large) boxes of selected

wares. A typical application is a furniture store where

the user selects goods in the display area and picks

them up in the self-service storage area.

The iTrolley provides intelligent, automated and

easy-to-use transport support. It helps the user to

traverse the storage area along an optimal path while

collecting goods. It answers questions and queries

about the shopping and the goods, resolves problems

and warns about mistakes during the entire process.

The robot may also provide additional services like

payment preparation, customer support related to the

wares, marketing, etc.

Agent-based Reconﬁgurable Natural Language Interface to Robots - Human-Agent Interaction using Task-speciﬁc Controlled Natural

Languages

633

3.1 Roles in the Pilot Scenario

The human Customer selects the wares in the display

area (creating the shopping list) then s/he picks up the

selected goods boxed for delivery in the storage area.

Finally, the Customer pays at the checkout area and

puts the boxes into a car waiting in the shipping area.

The Shopping App runs on the Customer's

mobile phone and helps browsing and selecting wares

in the display area. It maintains the shopping list and

helps the Customer to communicate with the robot.

The iTrolley Robot is a self-moving autonomous

transport robot that helps the Customer to carry

goods. It guides the Customer to the appropriate

shelves in the storage area and gives instructions

which boxes should be collected. It helps in detecting

and resolving problems, provides payment

information at checkout and brings the goods to the

appropriate shipping location.

The Warehouse Management System provides

inventory, payment, advertisement and other services

and information to the Robot and the Customer.

3.2 The Shopping Scenario

The Customer enters the Warehouse, installs the

Shopping App software on her/his phone or picks up

a warehouse hand device with the application already

installed, starts browsing the displayed goods

(furniture, household appliances etc.) in the display

area.

To buy an item s/he scans its code with the

Shopping App (adding the item to the shopping list).

After having finished the browsing s/he enters the

Storage area and selects an available iTrolley Robot,

and connects the Shopping App to the selected robot.

The iTrolley Robot talks with the Customer in

natural language using speech recognition and

synthesis. It plans the preliminary route along the

Storage Area to pick the goods and executes it. It

directs the Customer to the appropriate shelf where

the item on the shopping list can be found, instructs

the Customer to pick items (boxes) from the shelf and

to put them on the robot’s transport platform,

identifies and verifies the picked items (by weighting

them or detecting barcodes present on the boxes) and

warns the Customer about wrongly picked items. It

also communicates with other iTrolley agents to

resolve route conflicts, continuously modifies its

route according to the global information about other

iTrolley routes, traffic jams, etc. (cooperative

planning).

When all goods are collected the iTrolley Robot

provides pre-payment information to the cashiers at

the checkout area, takes its load to an available

cashier to proceed with the payment.

After the customer paid for the goods the cashier

accepts the transaction and allows the Robot to

proceed to the shipping area, collecting the

warehouse's hand device from the Customer (if

applicable). The iTrolley finally transports the goods

to the shipping area.

3.3 Natural Language Communication

The iTrolley Robot communicates with the Customer

in the spoken natural language. This makes it possible

for the Customer to formulate queries and commands

easily and to understand well the information

provided by the robot. Situations presented in the

shopping scenario may require many kinds of

communication between the system and the Customer

ranging from instructions given to or by the robot,

through information sharing activities till a general

chat. The reconfigurable nature of the robot, the

various shopping list items and the varying needs of

the Customer yield also many possible (and

changing) conversation scenarios.

To take all these into account we designed a

flexible and modular framework for natural language

human-robot communication.

4 ARCHITECTURE

Our solution is designed as a ROS-based system

meaning that the ROS platform provides the basic

organization and communication capabilities

throughout the entire system. It connects the human-

machine interface to the robotic components as well

as to other application specific modules.

4.1 Interface Components

The interface's internal architecture contains the

following components (

Figure 1).

The Voice Agent runs on a mobile device and

contains a speech recognition module for detecting

the user's input, a speech synthesis module for passing

messages from the system to the user, a ROS

communication module that connects the agent to the

ROS-based system, and a dispatcher component that

analyzes the user's input in order to determine the

appropriate target agent that can process that input. In

the pilot system this component is called the

Shopping App, and it also contains a camera with

barcode scanner as an input device.

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

634

Robotic Modules run on the robot and provide

services like physical movement and the navigation

of the robot, handling sensor inputs and other

hardware- and robot-specific modules. In the pilot

scenario, these modules provide movement and

navigation functions in the warehouse environment.

Local Application Agents run in close relation

with the robotic modules. These agents provide

higher level services like map discovery, route

planning, error detection and recovery, etc. They may

also possess natural language processing and

understanding components, state management of

human-robot conversations and application-specific

functions. In the pilot scenario, these modules handle

the shopping list, retrieve information (e.g. location)

about the goods, plan the route in the storage area,

coordinate item pick-up and perform task-specific

natural language communication with the Customer.

Finally, Global Application Agents run

independently from the robot and provide services

like synchronizing the operation of multiple robots

and resolving conflicts, logging and monitoring, etc.

In our application, these agents provide warehouse

inventory information and an administrator interface

for monitoring the entire system.

4.2 Communication

All mentioned components communicate with each

other using the ROS infrastructure, although they also

encapsulate higher-level protocols in their messages.

We differentiate the following three levels of

communication.

At ROS level Robotic Modules communicate

using standard ROS messages and semantics. These

messages are delivered via well-defined topics and

follow the standard semantics of the robotic

components. For example, the navigation module

communicates with the robot motor subsystem to

reach the desired location in the storage area.

The Voice Agent, Local and Global Application

Agents communicate among themselves using Agent

Communication Languages (ACL) embedded in the

ROS messages. This is the ROS-ACL level, which

will be discussed in more detail in Section 5.3.

The Voice Agent communicates with the user

using spoken natural language. In order to represent

these messages internally the agent transforms them

to ROS-ACL-NL messages. At this level natural

language sentences are embedded in the ROS-ACL

messages. These sentences are parsed and understood

by Local and Global Application Agents that use

task-specific controlled natural languages detailed

later on in Section 6.

5 HOW DOES IT WORK

5.1 The Voice Agent

The main task of the Voice Agent is to communicate

with the user using spoken natural language dialogues

and transform them to ROS-ACL-NL messages. It

provides no application-specific services or interface

in general; it is merely the man-machine

communication component of the system. In this

respect it plays two roles: the Speaker and the

Listener, for speaking and for speech recognizing. It

can be placed on the robot itself or it can be deployed

independently on a (mobile) device.

After starting up the Voice Agent implements two

ROS topics (channels). The Speaker topic is used to

receive requests for speech synthesis, while the

Listener topic accepts subscription messages from

other agents for notification about recognized input

sentences from the Customer.

The Voice Agent's Speaker receives ROS-ACL-

NL messages in which agents can request that natural

language text present in the message should be

spoken to the user. The Voice Agent queues the

Figure 1: The high-level architecture of the system with various communication methods.

Agent-based Reconﬁgurable Natural Language Interface to Robots - Human-Agent Interaction using Task-speciﬁc Controlled Natural

Languages

635

requests, and speaks them one-by-one using the

output device. In our prototype implementation a

simple FIFO scheduler is used for ordering the

messages in the queue. If a given application would

require it, other scheduling methods can also be used.

It is even possible to use pre-emptive algorithms for

urgent alert messages that notify the user of some

imminent danger.

The Voice Agent working in Listener mode

receives user input and routes it to the appropriate

agent for processing. In order to do it, it accepts

subscriptions for certain language patterns. These

subscriptions are specified in ROS-ACL subscribe

messages that include their ROS topic (to which the

input should be delivered), the filter pattern for the

input and a priority value for the given pattern.

Such patterns can be considered as language

detection rules for task-specific controlled natural

languages. An agent that wishes to communicate with

the user provides these rules for the Voice Agent to

select those input messages that it is interested in.

Agents can specify or delete such rules dynamically

as their operation (or life cycle) requires it. The Voice

Agent always maintains a complete set of language

rules according to the actual needs of other agents.

5.2 Task-specific Agents

Task-specific global and local application agents are

responsible for services and functions required by the

application. They communicate as ROS nodes in the

system: they may create their own topics or subscribe

to other topics as well. In addition to the standard

ROS semantics they may also use ROS-ACL

messages when communicating with other agents,

and the ROS-ACL-NL protocol for natural language

communication.

Application agents may also use the Voice

Agent’s previously mentioned Listener and Speaker

topics to communicate with the user. In this case they

send their own language detection rules to the

Listener and subscribe for the incoming messages.

They receive them from the Voice Agent in ROS-

ACL-NL format and they also send such messages to

the Voice Agent's Speaker to be spoken to the user.

Examples for such agents can be found in Section 7.3.

5.3 ROS-ACL Messages

Agents communicate with each other using Agent

Communication Language (ACL). The underlying

communication framework is provided by the Robot

Operating System, therefore ACL communication is

embedded in ROS messages. This developed

communication method is called ROS-ACL.

Any kind of ACL speech acts and semantics can

be used as needed by the given application. For

application-independent functions we have selected a

limited set of ACL messages. Application agents may

communicate with other agents using the ACL

semantics: they request a service from another agent

(e.g. text to speech messages can be sent as a request

to the Voice Agent), subscribe to events (e.g. user

input at the Voice Agent), inform other agents about

events (e.g. recognized input text is sent from the

Voice Agent to subscriber), and so on.

6 CONTROLLED NATURAL

LANGUAGE

COMMUNICATION

In a traditional software system user interface

elements created and handled by various application

components are assembled into a single graphical

user interface by a compositing display manager.

The developed natural language interface

implements a similar method. Every agent can

communicate with the user using its own task-specific

controlled natural language and a compositing

interface (the Voice Agent) unifies these languages.

6.1 Natural Language Messages

When the user communicates with the system in

spoken natural language the Voice Agent analyzes

speech input and transforms it into ROS-ACL-NL

messages where natural language sentences are

embedded at the content level. These sentences are

then received, parsed and understood by application

agents.

Agents communicate with the user using task-

specific controlled natural languages. These

languages are created solely for the functions

provided by the agents. E.g. in our pilot application

we have created languages for shopping list

assembly, item pick-up, etc. Since the system

communicates with the user using a single voice input

interface (the Voice Agent), it should be able to

separate different languages, and it should determine

a target agent for a given sentence from the human

user. This is done by language detection rules

provided by the application agents. The rules are used

by the Voice Agent to determine the controlled

natural language which is the best match for a given

sentence and which agent is the target of that

communication.

The rules have the following attributes: priority

(importance), the ROS topic, and the language

detection pattern.

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

636

Based on such rules the Voice Agent determines

which patterns match a given input sentence, selects

the topic with the highest priority, and assembles a

ROS-ACL message to be sent to that topic.

In addition to the language detection, the Voice

Agent is also able to maintain conversation between

the user and the agents. Discourse detection is done

using a similar rule-based scheme.

6.2 Conversation Management

To handle conversation between the user and the

application agents we have applied finite state

machines. These machines describe the possible

states of the human-agent conversations and the

possible state transitions defined by the application

and the rules of the controlled languages.

The states of the finite state machine represent

stages of the conversation with the user. A state can

be changed by the user input (defined by the

transitions for each state) or by the application logic

of the agent (e.g. the agent can change its state when

a message is received from another agent or ROS

node). State transitions also specify the output to be

sent to the user when the transition happens.

Every agent maintains its own state of

conversation and provides information about allowed

state transitions (possible user inputs specified via

filter masks) to the Voice Agent. This interface agent

collects all state transition filter masks and uses them

in a similar way as language detection rules work.

There are also other mechanisms to ease the

development of complex state machines (like

“shortcut” transitions, initialization messages at

states, etc.) that are not described in this paper.

7 PROTOTYPE TESTING

The demo application is implemented as a ROS-Java-

Android hybrid system following the previously

detailed system design and the pilot application

scenario.

The ROS core of the pilot application runs in a

simulated environment using Gazebo graphical robot

simulator (gazebosim.org). It uses Jackal ROS

package for navigation. We have developed several

application-specific agents in Java to perform various

tasks in pilot application. The Voice Agent is

implemented in the Android ecosystem.

The software demonstration is based on open

source tools and can be installed on Ubuntu using a

Docker-based automated installation utility. The

source code of our prototype application can be found

at our project Web page (R5-COP 2016).

7.1 The ROS Simulator

We used the Gazebo simulator for testing and

demonstration purposes.

It is a universal robotic simulation toolbox with

advanced graphics and physics engine. Figure 2

shows the simulated robot and the storage area of the

warehouse. For the sake of simplicity, Jackal robot

model is used. The products (boxes) in the warehouse

are located on standard shelves.

In addition to the visual interface the ROS

simulator provides also several robotic components

for sensor input, robot movement, route planning and

navigation etc. These are used by application agents

to perform various tasks in the pilot scenario.

Figure 2: The simulated storage area with the robot.

7.2 The Voice Agent Android App

We developed the Voice Agent as an Android

application using the Google Speech Synthesis and

Speech Recognition APIs to implement the necessary

input and output function for the Listener and Speaker

roles. The application has a simple configuration

interface to specify the address of the ROS core.

After the configuration is finished the Voice

Agent connects to the ROS core. When other agents

in the system are connected to the Voice Agent, their

detection rules are displayed for debugging purposes.

The application also contains a camera module to

scan and recognize QR codes that are used to

assemble the shopping list in the display area of the

warehouse. We also used them to simulate the robot's

camera that checks the collected wares during the

pick-up phase in the storage area. In the simulation

the robot asks the customer to scan the code of the

selected box using the hand device, and it warns the

user if a wrong box is picked.

Agent-based Reconﬁgurable Natural Language Interface to Robots - Human-Agent Interaction using Task-speciﬁc Controlled Natural

Languages

637

Figure 3: The Voice Agent as an Android application.

7.3 Application Agents

We have developed several application agents for the

pilot scenario.

The simplest is HowAreYou Agent that performs

general chat like greeting, goodbye and the like. It

also has a wild-card rule with low priority that allows

the system to respond to messages not recognized by

any other agent.

The ShoppingList Agent is responsible for

maintaining the state of the shopping list shown to the

user on Android device. It also maintains the states of

the wares, whether they are collected or not in the

Storage Area, or if the robot is waiting directly in

front of the shelf where the box can be found. It

communicates with the ItemCollector Agent and with

Pickup Agent.

The ItemCollector Agent is responsible for

navigating the robot to items found on the shopping

list, while the Pickup Agent instructs the user to pick

up the box when the robot arrives to the appropriate

place. This agent also validates the user's action by

checking the QR code of the box.

There are other agents that communicate with the

user in controlled natural language. For example, the

Sales Agent advertises items on sale. All these agents

have their simple controlled natural language rules,

conversational states and state transitions.

In addition to these application agents the system

also possesses a main agent, responsible for starting

and stopping the execution of the demo application,

the and the ROSDisplay Agent with a graphical user

interface that provides monitoring of the system.

8 CONCLUSIONS

The developed system provides a natural language

voice interface for a robotic system that provides a

complex functionality to the human user. The internal

complexity of the robotic system is tackled using

several application-specific agents. These agents use

task-specific controlled natural languages. The

system uses a common natural language interface to

communicate with the user using speech recognition

and voice generation. This interface (the Voice Agent)

uses language and discourse detection rules to

identify the agent to which a given user message

should be delivered.

The system is developed using the industrial

standard ROS framework. Messages between agents

and other ROS components are embedded into ROS-

messages with different level of abstraction. The

speech input and generation interfaces are

implemented on the Android platform that provides

readily available functionality for these purposes. The

software running on the Android device is also

connected to the ROS-based robotic system.

Although the system was developed for the

iTrolley pilot scenario, it can be easily adapted to

other applications as well. The communication

framework and the Voice Agent are application

independent thus need no customizations. This also

implies that a developed system can also be

reconfigured if the robotic hardware changes. In this

case new ROS modules and modifications in

Application Agents might be required depending on

the nature of the change.

The developed solution not only accepts spoken

commands from the users but it is also able to initiate

and engage in conversations with the user in many

different topics at the same time. This is an important

feature for robots in application fields like health care,

ambient assisted living. In these areas they not only

perform, fulfil user commands (demands), but must

direct, command, influence the users towards goals

set by the staff controlling the user environment.

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

638

Furthermore, by replacing the ROS framework

with other means for communication our approach

may also be applied to other application areas where

a multi-agent system should use a common human-

machine interface to communicate with its users.

Other modalities could also be developed in

addition to the speech interface. By extending the

functionality of the Voice Agent other input methods

like text input with autosuggest function, gesture

recognition or simple menu-based interfaces could

also be implemented. Such additional modalities can

amplify the disambiguation capabilities and improve

the efficiency of the communication (Green 2009,

Breuer 2012, Fardana 2013).

ACKNOWLEDGEMENTS

This work was supported in part by ARTEMIS Joint

Undertaking and in part by the Hungarian National

Research, Development and Innovation Fund within

the framework of the Reconfigurable ROS-based

Resilient Reasoning Robotic Cooperating Systems

(R5-COP) Project.

The prototype application was developed by a

group of researchers including István Engedy, Péter

Eredics and Péter Györke at our department.

REFERENCES

Bastianelli E., G. Castellucci, D. Croce, R. Basili, D. Nardi,

2014. Effective and Robust Natural Language

Understanding for Human obot Interaction, ECAI 2014,

T. Schaub et al. (Eds.).

Breuer, Thomas, et al. 2012. Johnny: An autonomous

service robot for domestic environments. Journal of

intelligent & robotic systems 66.1-2 (2012): 245-272.

Burgard W., A.B. Cremers, D. Fox, D. Hähnel, G.

Lakemeyer, D. Schulz, W. Steiner, S. Thrun, 1999.

Experiences with an interactive museum tour-guide

robot, Artificial Intelligence 114 (1999) 3–55.

Fardana A.R., S. Jain, I. Jovancevic, Y. Suri, C. Morand and

N.M. Robertson, 2013. Controlling a Mobile Robot

with Natural Commands based on Voice and Gesture,

Workshop on Human Robot Interaction (HRI) for

Assistance and Industrial Robots, VisionLab, Heriot-

Watt University, 2013.

Ferland F., R. Chauvin, D. Létourneau, F. Michaud, 2014.

Hello Robot, Can You Come Here? Using ROS4iOS to

Provide Remote Perceptual Capabilities for Visual

Location, Speech and Speaker Recognition, Proc. HRI

'14 the 2014 ACM/IEEE Int. Conf. on Human-Robot

Interaction, Pages 101-101.

Fong T., I. Nourbakhsh, K. Dautenhahn, 2003. A survey of

socially interactive robots, Robotics and Autonomous

Systems 42 (2003) 143–166.

Green A., 2009. Design and Evaluating Human-Robot

Communication, PhD, KTH, 2009.

H2020 – Robotics 2020 – Multi-Annual Roadmap For

Robotics in Europe - http://www.eu-robotics.net/

Howard T.M., I. Chung, O. Propp, M.R. Walter, and N. Roy,

2014. Efficient Natural Language Interfaces for

Assistive Robots, IROS 2014 Workshop on

Rehabilitation and Assistive Robotics, Sept 14-18,

2014, Chicago.

Huber A., Bernd L. 2002. Users Talk to their Model Trains:

Interaction with a Speech-based Multi-Agent System.

Proceedings of the First International Joint Conference

on Autonomous Agents and Multi-Agent Systems,

AAMAS 2002, July 15-19, Bologna, Italy,

Kemke C., 2007. “From Saying to Doing” – Natural

Language Interaction with Artificial Agents and

Robots, Ch 9, Human-Robot Interaction, (ed.) N.

Sarkar, Sept 2007, Itech Education and Publishing,

Vienna, Austria.

Khayrallah H., S. Trott, J. Feldman, 2015. Natural

Language For Human Robot Interaction, Proc. of the

Workshop on Human-Robot Teaming at the 10th

ACM/IEEE Int. Conf. on Human-Robot Interaction,

Portland, Oregon.

Lauria S., T. Kyriacou, G. Bugmann, J. Bos, E. Klein, 2002.

Converting Natural Language Route Instructions into

Robot Executable Procedures, Proc. 11th IEEE Int.

Work-shop on Robot and Human Interactive

Communication, pp. 223-228.

MacMahon M., B. Stankiewicz, B. Kuipers, 2006. Walk the

Talk: Connecting Language, Knowledge, and Action in

Route Instructions, Proc. AAAI'06 the 21st Nat. Conf.

on Artificial Intelli. - Vol 2, pp. 1475-1482.

R5COP 2016, http://r5cop.mit.bme.hu/

Rousseau V., F. Ferland, D. Letourneau, F. Michaud, 2013.

Sorry to Interrupt, But May I Have Your Attention?

Preliminary Design and Evaluation of Autonomous

Engagement in HRI, J. of Human-Robot Interaction,

Vol. 2, No. 3, 2013, pp. 41–61.

Schiffer S., N. Hoppe, and G. Lakemeyer, 2012. Natural

Language Interpretation for an Interactive Service

Robot in Domestic Domains, J. Filipe and A. Fred

(Eds.): ICAART 2012, CCIS 358, pp. 39–53, 2012.

Stenmark M., J. Malec, 2015. Connecting natural language

to task demonstrations and low-level control of

industrial robots, Workshop on Multimodal Semantics

for Robotic Systems (MuSRobS) IEEE/RSJ Int. Conf. on

Intelligent Robots and Systems 2015.

Tellex S., T. Kollar, S. Dickerson, M.R.Walter, A. Gopal

Banerjee, S. Teller, N. Roy, 2011. Understanding

Natural Language Commands for Robotic Navigation

and Mobile Manipulation, Proc. of the Nat. Conf. on

Artificial Intelli. (AAAI 2011).

Wyner, Adam, et al. 2009. On controlled natural languages:

Properties and prospects. International Workshop on

Controlled Natural Language. Springer Berlin

Heidelberg, 2009.

Agent-based Reconﬁgurable Natural Language Interface to Robots - Human-Agent Interaction using Task-speciﬁc Controlled Natural

Languages

639
