Enabling Focused Software Quality Assurance in Agile Software

Development Processes for Mobile Applications using Text and Usage

Mining Methods

Michael Bauer

, Kateryna Sergieieva

, Gerrit Meixner

, Konstantin Holl

and Frank Elberzhager

Usability and Interaction Technology Laboratory (UniTyLab), Heilbronn University,

Max-Planck-Straße 39, 74081 Heilbronn, Germany

Fraunhofer Institute for Experimental Software Engineering (IESE), Information Systems Quality Assurance,

Fraunhofer-Platz 1, 67663 Kaiserslautern, Germany

Keywords:

Software Maintenance Tools, Agile Software Development, Data Mining, Data Analytics, Mobile Computing.

Abstract:

The acceptance of mobile applications that support services, such as navigation guidance or travel manage-

ment, is highly dependent on the set of features implemented and the application quality. Information about

the acceptance can be gained quickly by collecting user feedback like explicit textual reviews given by the

application users or their implicitly given usage data. Considering an approach that bases on developing a

minimal set of functions in order to realize a minimal viable product (MVP), it is possible to place a product

with a short time to market. In this paper the Opti4Apps approach is presented. It aims at a focused quality

assurance as part of the MVP development, which enables and expands the beneﬁts of MVP by providing a

semi-automated feedback elicitation, analysis and processing framework. The Opti4Apps process adjusts to

mobile development habits including an additional automated feedback and usage data processing infrastruc-

ture.

1 INTRODUCTION

Mobile applications have attained an increasing im-

portance in daily use. In 2015, about 1640 million

smart phones and tablets as opposed to about 276

million notebooks and desktop computers were sold

(Yahoo, 2016). Among all smart phone users e.g. in

the U.S. in 2013, 62 percent used mobile application

and among them 74 percent used productivity appli-

cations (Nielsen, 2013). The sales numbers of mobile

devices and the possibility to reach many users lead to

more software development service providers enter-

ing the mobile application market. Scrum

is widely

adopted as an agile software development process but

there has been a noticeable shift in attention toward

lean software development although these methods

have much in common, including short iterative life

cycles, quick and frequent feedback from customers,

and constant learning (Wang et al., 2012). In lean

software development the use of a MVP is propa-

gated. A MVP is a product with just enough features

and minimal characteristics to gather validated learn-

https://www.scrum.org

ing in continued development (Robinson, 2016).

The posing challenges are how to collect and pro-

cess costumer respectively user feedback inside a con-

tinuous delivery (CD) environment and how to gain

knowledge to enhance the quality of mobile appli-

cations including usability issues of future develop-

ments without the enlargement of delivery times. To

address this, a focused quality assurance approach

is needed which supports the MVP-based develop-

ment of mobile applications, e.g. budget restric-

tions and short development periods. Hence, we aim

to establish an optimization for mobile application

(short: Opti4Apps) tailored to MVP-development us-

ing a semi-automated framework. The framework

consists of feedback and usage elicitation, followed

by analysing the data and load processing the analy-

sis outcome.

2 STATE OF THE ART

CD deﬁnes a deployment pipeline which enables

lean inadvertent error prevention (Fitzgerald and Stol,

2014) (Humble et al., 2006). This deployment

128

Bauer M., Sergieieva K. and Meixner G.

Enabling Focused Software Quality Assurance in Agile Software Development Processes for Mobile Applications using Text and Usage Mining Methods.

DOI: 10.5220/0006224801280132

In Proceedings of the 12th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2017), pages 128-132

ISBN: 978-989-758-229-5

pipeline comprises visibility including all aspects of

the delivery system like building, deploying, test-

ing, and releasing which are visible to every mem-

ber of the team to promote collaboration. This sup-

plies feedback as team members learn of problems

when they occur so that they are able to ﬁx them as

quickly as possible. It includes permanent deploy-

ment through a fully automated process to install and

release any version of the software to any environ-

ment (Duvall, 2012). Beyond CD, the principle of de-

velopment and operations (DevOps) is a development

methodology that bridges the gap between software

development and IT operations, emphasizes collabo-

ration, also emphasizes continuous delivery and qual-

ity assurance (Jabbari et al., 2016). Lean software de-

velopment deﬁnes seven principles (Poppendieck and

Poppendieck, 2003):

• Eliminate waste: Everything not adding value to

the customer is waste and has to be eliminated.

• Amplify learning: Software development based

on iterations empowers a continuous learning pro-

cess.

• Decide as late as possible: Delaying decisions as

much as possible until they can be made based on

facts.

• Deliver as fast as possible: A sooner delivery of

the product without major defects enables imme-

diate feedback which can be incorporated into the

next iteration.

• Empower the team: The development team takes

care of what actions might be taken and suggests

improvements.

• Build integrity in: The product must not look like

a collection of small solutions, but as one integral

system.

• See the whole: Not sub-optimizing to get the de-

tails right, but considering the system as a whole

empowers to adapt to project changes.

The paradigms of lean development, DevOps and CD

depend on fast deployment to gain knowledge about

the product. Therefore automation and constant mon-

itoring of the deployment pipeline is required (Hassel-

bring, 2015). Regarding automating the deployment

pipeline many tools already exist. Jenkins

can be

used for automated builds, unit- and acceptance tests,

static and dynamic code analysis by using a common

code basis from a version control system (VCS) like

Git

. JMeter

can be used for load and performance

https://jenkins.io

https://git-scm.com

http://jmeter.apache.org

tests. Puppet

is a DevOps tool, that treats infras-

tructure as code (IaC), collaboration between devel-

opment, operation, information security and network-

ing. Beside this, web analytic tools like Google An-

alytics

and Piwik

are also used in mobile applica-

tions.

Despite of all those automation tools, some tasks

are still accomplished manually, especially in the area

of usability. The ISO 9241-210 deﬁnes a human-

centred design (HCD) process where the user is in-

volved in every step of the process and provides feed-

back constantly (ISO, 2011). Common methods are

used during this process, e.g. interviews, heuristic

evaluation, usability tests, and are deﬁned in ISO/TR

16982 and are executed by usability experts manually

(ISO, 2002). Feedback can be elicited with applica-

tions like iRequire (Seyff et al., 2010) and ConTexter

artner and Schneider, 2012) where large groups of

users are able to describe requirements and requests.

Providers like UserVoice

combine the feedback of

an application with a bug tracker. These solutions as-

sume that stakeholders have the intrinsic motivation

to contribute their problem descriptions. Appsee’s

mobile analytics platform provides in-depth analysis

of users’ behavior. It provides dwell times on screens,

as well as touch heat maps, recordings of the us-

age, navigation diagrams and tracking of clicks and

other events. This usage data can be acquired in a

similar way to classify usability and failure patterns.

Based on the classiﬁcation, a focused quality assur-

ance method for mobile applications increases the ef-

fectiveness of ﬁnding failures of mobile applications

during testing (Holl and Vieira, 2015).

3 VISION

The Opti4Apps approach is based on a semi-

/automated elicitation and analysis of mobile appli-

cation data. On the one hand data is collected within

the mobile device, e.g. from sensors, user interac-

tions, or device-resident sources like log ﬁles. On

the other hand data is collected from software stores,

e.g. Google Play Store

or App Store

, and user fo-

rums where explicit feedback is given. The idea is to

identify failure patterns using data mining and natural

language processing methods in a mobile application.

https://puppet.com

https://www.google.de/analytics/index.html

https://piwik.org

https://www.uservoice.com/

https://www.appsee.com/

https://play.google.com/store

https://itunes.apple.com

Enabling Focused Software Quality Assurance in Agile Software Development Processes for Mobile Applications using Text and Usage

Mining Methods

129

Figure 1: Overview of the Opti4Apps approach.

Analysing these patterns is intended to speed the de-

velopment process, allowing problems to be identiﬁed

and rectiﬁed quicker. Thus, it can provide a baseline

for the effective further development as well as the

focused quality assurance. This can mean using the

new knowledge to guide the test manager during the

inspection of the requirements speciﬁcation as well as

the testing of the mobile application. It can also mean

identifying user groups that have problems with a spe-

ciﬁc task within the application. This can be useful in-

formation for a usability engineer. Figure 1 shows an

overview of the Opti4Apps approach. In the ﬁrst iter-

ation the mobile application is delivered to the users

as a MVP. An agent collects feedback and sends it

to the Opti4Apps backend. The frontend presents the

processed information. The test manager uses this in-

formation to plan and execute quality assurance tasks.

After that an optimized version of the mobile applica-

tion is delivered to the users again.

The recognition of the Opti4Apps depends on the de-

gree it is encouraging mobile development habits. It

is also important not to enlarge the tasks of the de-

velopment teams with additional conﬁguration over-

head. That is why the knowledge discovery has to be

automated. As already mentioned in the introduction,

agile development is widely adopted. Figure 2 de-

scribes a process that encapsulates an automated feed-

back cycle and knowledge discovery infrastructure for

mobile applications. Following the DevOps method-

ology it should be provided as IaC. It is based on

a CD approach presented in the research of Krusche

and Alperowitz (Krusche and Alperowitz, 2014). In

software development, requirements are stored in an

issue tracker like JIRA

. The developers who are re-

sponsible for the requirements write code and commit

it to a VCS like Git. A continuous integration server

performs checkouts of the latest version and runs au-

tomated builds, tests, and generates reports. A prod-

https://de.atlassian.com/software/jira/agile

Figure 2: Overview of the Opti4Apps process.

uct owner releases a version to a delivery server. This

can either be software repositories like the Google

Play Store, the App Store or self-hosted reposito-

ries. Sometimes services like TestFlight

and Hock-

eyApp

are used for beta testing purposes. The user

downloads the mobile application to his device from

the delivery server. The usage data is collected by an

agent attached to the mobile application. It is spa-

tiotemporal time series data containing a set of mea-

sured points. The measurements can be divided in

device speciﬁc data like the android version, sensor

data like GPS location, and application speciﬁc data

like event names. All that data is stored in a data

warehouse. Clickstreams are extracted from the usage

data and used for classiﬁcation and clustering of tasks

and user groups. Data from the development tools is

also captured in the data warehouse to ensure trace-

ability of a failure pattern to issues, versions, or even

development branches. A combination of data min-

ing methods like outlier analysis, clustering, and clas-

siﬁcation are used to identify failure and usage pat-

terns. In addition to that explicit feedback from users

is scraped from the delivery server respectively the

Google Play Store, the App Store, and user forums.

Natural language processing methods like topic mod-

els are used to identify additional failure patterns. If

e.g. a group of words like failure, problem, etc. oc-

curs often with words like network a resulting topic

may indicate network problems. The frontend of the

approach is an analytics tool which is observed by the

product owner. Based on the analytics, the product

owner takes action for the next iteration. The ana-

lytics tool helps the product owner to make decisions

based on data and consult the right expert, e.g. a us-

ability engineer or a test manager. Findings can also

be stored to the issue tracker for improvements in the

next iteration of the development.

https://developer.apple.com/testﬂight

https://hockeyapp.net/

HUCAPP 2017 - International Conference on Human Computer Interaction Theory and Applications

130

4 CONCLUSIONS

Opti4Apps implements and extends the beneﬁts of an

MVP development by developing and using a frame-

work based on the automatic elicitation and analysis

of feedback as well as using an effective and efﬁcient

quality assurance methodology. In contrast to classi-

cal development this enables quicker delivery times

and early feedback from users. With Opti4Apps this

feedback is automatically processed in a systematic

way to identify failure patterns. Those patterns deﬁne

connections of typical failure causes with their com-

mon impacts. In addition to that using cluster analysis

of failure patterns the approach is capable of ﬁnding

user groups with similar problems. In future work

ﬁnding user groups and segmentation of user tasks by

analyzing clickstream data will be done. One chal-

lenge here is to label and to distinguish tasks. To solve

this it is planned to use data fusion between develop-

ment tools and clickstream data to interconnect e.g.

issue, class, and function names with user interaction

event data collected from an agent inside the mobile.

Insights about efﬁciency and effectiveness on tasks

also allow conclusions about the usability of the mo-

bile application. Another challenge is to identify user

groups based on the clickstream data when no other

user data is available. A promising idea is to group

users based on behavioral pattens within the applica-

tion. In parallel developing a concept to protect the

privacy of end users is mandatory. With Opti4Apps,

lean principles can be applied to the software devel-

opment of mobile applications. The framework sup-

ports ampliﬁed learning by iterations including imme-

diate and structured feedback. The outlined process

makes fast deliveries possible and enables late deci-

sions based on reasonable data. Concerning this, the

elicitation of relevant information with respect to the

user’s behavior should be automated as much as pos-

sible. Further more, the feedback and insights from

one development can be reused in parallel or subse-

quent development.

ACKNOWLEDGEMENTS

The research described in this paper was performed

in the project Opti4Apps

- Optimization for mobile

applications (grant no. 01FJ15133) of the German

Federal Ministry of Education and Research.

http://www.opti4apps.de

REFERENCES

Duvall (2012). Continuous delivery.

http://www.dccia.ua.es/dccia/inf/asignaturas/MADS/

lecturas/10 Continuous Delivery Dzone Refcardz.pdf.

Accessed on 2016-11-7.

Fitzgerald, B. and Stol, K.-J. (2014). Continuous soft-

ware engineering and beyond: Trends and challenges.

In Proceedings of the 1st International Workshop

on Rapid Continuous Software Engineering, RCoSE

2014, pages 1–9, New York, NY, USA. ACM.

artner, S. and Schneider, K. (2012). A Method for Priori-

tizing End-user Feedback for Requirements Engineer-

ing. In Proceedings of the 5th International Workshop

on Co-operative and Human Aspects of Software En-

gineering, CHASE ’12, pages 47–49, Piscataway, NJ,

USA. IEEE Press.

Hasselbring (2015). Devops: Softwarearchitektur an der

schnittstelle zwischen entwicklung und betrieb. In GI-

Fachtagung Architekturen 2015.

Holl, K. and Vieira, V. (2015). Focused quality assur-

ance of mobile applications: Evaluation of a failure

pattern classiﬁcation. In 41st Euromicro Conference

on Software Engineering and Advanced Applications,

EUROMICRO-SEAA 2015, Madeira, Portugal, Au-

gust 26-28, 2015, pages 349–356.

Humble, J., Read, C., and North, D. (2006). The deploy-

ment production line. In Proceedings of the Confer-

ence on AGILE 2006, AGILE ’06, pages 113–118,

Washington, DC, USA. IEEE Computer Society.

ISO (2002). Ergonomics of human-system interaction -

Usability methods supporting human-centred design;

ISO/TR 16982:2002. ISO International Organization

for Standardization.

ISO (2011). Ergonomics of human-system interaction - Part

210: Human-centred design for interactive systems;

ISO 9241-210:2010. ISO International Organization

for Standardization.

Jabbari, R., bin Ali, N., Petersen, K., and Tanveer, B.

(2016). What is devops?: A systematic mapping study

on deﬁnitions and practices. In Proceedings of the

Scientiﬁc Workshop Proceedings of XP2016, XP ’16

Workshops, pages 12:1–12:11, New York, NY, USA.

ACM.

Krusche, S. and Alperowitz, L. (2014). Introduction of con-

tinuous delivery in multi-customer project courses.

In Companion Proceedings of the 36th International

Conference on Software Engineering, ICSE Compan-

ion 2014, pages 335–343, New York, NY, USA. ACM.

Nielsen (2013). The mobile consumer: A global snapshot.

http://www.nielsen.com/content/dam/corporate/uk/en/

documents/Mobile-Consumer-Report-2013.pdf. Ac-

cessed on 2016-11-02.

Poppendieck, M. and Poppendieck, T. (2003). Lean

Software Development: An Agile Toolkit: An Agile

Toolkit. Addison-Wesley.

Robinson, F. (2016). Minimum viable product.

http://www.syncdev.com/minimum-viable-product/.

Accessed on 2016-11-02.

Seyff, N., Graf, F., and Maiden, N. (2010). Using mo-

bile RE tools to give end-users their own voice. In

Enabling Focused Software Quality Assurance in Agile Software Development Processes for Mobile Applications using Text and Usage

Mining Methods

131

Proceedings of the 2010 18th IEEE International Re-

quirements Engineering Conference, RE2010, pages

37–46, Sydney, Australia.

Wang, X., Conboy, K., and Cawley, O. (2012). Leagile

software development: An experience report analy-

sis of the application of lean approaches in agile soft-

ware development. Journal of Systems and Software,

85(6):1287–1299.

Yahoo (2016). Statista - Das Statistik-Portal: Prog-

nose zum absatz von tablets, pcs und smartphones

weltweit von 2010 bis 2020 (in millionen st

uck).

https://de.statista.com/statistik/daten/studie/256337/

umfrage/prognose-zum-weltweiten-absatz-von-

tablets-pcs-und-smartphones. Accessed on 2016-11-

02.

HUCAPP 2017 - International Conference on Human Computer Interaction Theory and Applications

132
