Towards a Multi-level Approach for the Maintenance of Semantic

Annotations

Silvio Domingos Cardoso

1,2

, Chantal Reynaud-Dela

ıtre

, Marcos Da Silveira

, Ying-Chi Lin

Anika Groß

, Erhard Rahm

and C

edric Pruski

LIST, Luxembourg Institute of Science and Technology, 5, avenue des Hauts-Fourneaux,

L-4362 Esch-sur-Alzette, Luxembourg

LRI, University of Paris-Sud XI, Orsay, France

Institute of Computer Science, Universit

at Leipzig, P.O. Box 100920, 04009 Leipzig, Germany

Keywords:

Semantic Annotation, Annotation Maintenance, Ontology Evolution, Life Sciences.

Abstract:

Semantic annotations are often used to enrich documents as clinical trials and electronic health records. How-

ever, the usability of these annotations tends to decrease over time due to the evolution of the domain on-

tologies. The maintenance of these annotations is critical for tools that exploit them (e.g., search engines and

decision support systems) in order to assure an acceptable level of performance. Despite the recent advances

in ontology evolution systems, the maintenance of semantic annotations remains an open problem. In this pa-

per, we introduce, based on previous experiments, the main components of a multi-level approach towards the

automatic maintenance of semantic annotations. We further provide examples for strengthening our proposal.

1 INTRODUCTION

The use of Knowledge Organization Systems (KOS)

(Hodge, 2000), such as classiﬁcation schemes, con-

trolled terminologies, thesauri or ontologies in the

medical ﬁeld to annotate medical data is gaining in-

terest over the last years (Gimenez et al., 2012; Funk

et al., 2014; Yimam et al., 2016). Usually, KOS

elements are used to annotate documents such as

clinical reports or medical images in order to make

their semantics explicit for humans and software ap-

plications. The KOS entities (concepts, properties,

relationships, etc.) are associated with documents

producing semantic annotations (Da Silveira et al.,

2015). This process is commonly made by humans or

automatic annotators and brings many beneﬁts for end

users such as, enhancing the retrieval of relevant in-

formation for decision support or improving semantic

interoperability between systems (Uren et al., 2006).

However, the dynamic nature of medical knowl-

edge forces to continuously revise KOS content.

Thus, semantic annotations based on previous ver-

sions of the KOS can be impacted and loose their

validity. Therefore, mechanisms to adapt these im-

pacted annotations to the new version of KOS are re-

quired. In our previous work (Groß et al., 2012; Car-

doso et al., 2016), we have shown a strong correlation

between the modiﬁcation of KOS elements and the

modiﬁcation of semantic annotations. We also man-

age to categorize the various evolution that can affect

KOS and associate these changes with modiﬁcations

of elements deﬁning annotations.

In the literature, three families of approaches deal-

ing with annotation maintenance can be found. The

ﬁrst one addresses the problem of automatic detection

of inconsistent annotations (Eilbeck et al., 2009; Qin

and Atluri, 2009; K

opke and Eder, 2011; Zavalina

et al., 2015). However, mechanisms to support the

correction of impacted annotations are not proposed.

The second family of approach put the focus on the

automatic detection and manual correction of invalid

annotations (Maynard et al., 2007; Auer and Herre,

2007; Burger et al., 2010; Abgaz, 2013). How-

ever, these approaches only consider basic ontology

changes, e.g., deletion and addition of concepts in

ontology while more complex changes are important

to consider and requires human intervention to per-

form the maintenance which is hardly applicable in

the medical domain by virtue of the huge amount of

annotations to adapt. Last, the most advance works

implement an automatic correction of the annotation

(Luong and Dieng-Kuntz, 2006; Tissaoui et al., 2011;

Cardoso S., Reynaud-DelaÃ

otre C., Da Silveira M., Lin Y., GroÃ§ A., Rahm E. and Pruski C.

Towards a Multi-level Approach for the Maintenance of Semantic Annotations.

DOI: 10.5220/0006230104010406

In Proceedings of the 10th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2017), pages 401-406

ISBN: 978-989-758-213-4

401

Park et al., 2011; Frost and Moore, 2014). This is

mostly done based on reasoning techniques which

rely of the logic formalism of the KOS. However,

as medical KOS are expressed using lightweight de-

scription logic, these technique must be adapted.

The literature review highlights that there is no

annotation maintenance/adaptation framework able

to cope with the speciﬁcity of the medical domain

e.g., size of the KOS, amount of annotations. In

this paper we discuss the foundation of a (semi-

)automatic approach to manage semantic annotations

when their underlying KOS evolve over time without

re-annotating the documents. We further justify our

ideas based on previous experiments and examples.

We structure the remainder of this paper as fol-

lows: In Section 2 we deﬁne the annotation model

used throughout this paper. Section 3 introduces our

ideas towards the (semi-)automatic maintenance of

semantic annotations. In Section 4 we conclude the

paper by outlining future work.

2 ANNOTATION MODEL

The development of novel annotation maintenance

approaches requires an appropriate annotation model

covering evolution and quality aspects for annota-

tions. We refer to our previously described annota-

tion model (Groß et al., 2012; Cardoso et al., 2016)

and give a brief overview of the main aspects.

A single annotation is deﬁned as a = (i, c, {q})

where an instance item i ∈ I

is annotated with an on-

tology concept c ∈ ON

, and a set of quality indicators

{q} ∈ Q. An instance might be an electronic health

record (EHR) or a question item from a case report

form (CRFs) as used within clinical trials. In general,

a concept can be used to annotate many items and an

item might be annotated with several concepts. Dif-

ferent quality indicators can be used to retain qual-

ity, reliability and provenance information for each

annotation, e.g. by attaching numerical conﬁdence

values, categorical ratings or evidence codes (Groß

et al., 2009). Note that the quality of automatically

generated annotations can vary signiﬁcantly depend-

ing on the used methods, tools and their conﬁgura-

tions (Funk et al., 2014).

Both, instance data and ontologies, underlie con-

tinuous changes. Hence, we denote I

as an instance

in the version u and ON

is an ontology in the ver-

sion v. In this proposition paper, we focus on main-

taining annotations due to evolution of ontology. We

include further elements in the annotation model to

better trace KOS changes and to correctly update the

annotations. For instance, we retain the position of

an annotation within an instance item (o f f set) since

items can cover several concepts. The o f f set can be

useful, e.g. to link concepts from different versions

with the same part of an item. We further consider the

semantic relationship between a KOS concept and an

item or the annotated part of an item. For instance,

one item can be annotated as equivalent to a concept,

more/less speciﬁc, partial match, etc. The semantic

type of an annotation is useful to update outdated an-

notations. For instance, instead of removing an im-

pacted annotation after concept deletion, one could

preserve the annotated item by linking it to the super-

class of the removed concept and changing its seman-

tic type to “less speciﬁc”. As additional provenance

information, our annotation model includes an ele-

ment to indicate which concept attribute (e.g., title,

synonym, preferred terms, etc.) has mainly been used

to produce an annotation. This can be valuable dur-

ing the maintenance process, for example, to decide

whether a basic attribute change is relevant and might

entail an annotation modiﬁcation.

3 FOUNDATION FOR SEMANTIC

ANNOTATION MAINTENANCE

As discussed in Section 1, our long term objective

is to design a (semi-)automatic approach for main-

taining semantic annotations valid over time if the

underlying KOS is evolving without a complete re-

annotation of the document and by guaranteeing a

high quality in the annotation after maintenance. We

have analyzed the evolution of several KOS of the

medical domain and we identiﬁed the behavior of an-

notations under different scenarios. We rely on these

ﬁndings to derive different aspects to take into con-

sideration for the maintaining semantic annotations.

It can be seen as a multi-level approach that can be

split according to inputs, process and outputs. It al-

lows us to optimize the annotation maintenance task

by considering at each step more information of dif-

ferent nature to maintain annotation that remain in-

valid after the previous step.

3.1 Maintenance Process

The different maintenance processes we have identi-

ﬁed consist in: i) Automatically detecting inconsistent

annotations caused by the evolution of the underlying

KOS; ii) Using information gained from the evolution

of the KOS only to adapt impacted annotations; iii)

Using information of external KOS to maintain anno-

tations that could not be maintained by considering

local resource; iv) Using change patterns to ﬁnalize

HEALTHINF 2017 - 10th International Conference on Health Informatics

402

Input

Set of annotations,

set of ontology

changes

Set of classes,

rules, set of

ontology changes

Rules and

Resources

Rules and change

patterns

Process Output

Correlate

ontology changes +

annotation changes

Apply rules in local

resource

Load new rules

to process

external resource

Load new rules

for ontology

resource

Apply rules

and correct

annotations

Apply rules

and correct

annotations

Set of impacted

Annotation

Identification of

invalid annotations

Corrected

annotations

Annotations for

refinement

Annotation correction:

Ontology change rules

Corrected

annotations

Annotations for

refinement

Annotation correction:

External resource

knowledge

Corrected

annotations

Set of ranked

annotations

Annotation correction:

Change patterns

Stable

annotations

Figure 1: A multi-level framework for supporting annotation maintenance.

Identification of

invalid annotations

Ontology change rules

External resource

knowledge

Change patterns

 Ontology change rules

Annotation:          because a split

 Rules:  



 



  



 



  



 



 

Action: 



 





784.9

784.99

307.51 307.51

 External resource knowledge

Annotation:          because a ChgAttValue

 Result in ontology change rules: The annotations were not corrected by rules

 Search in external sources:

      

i.e.: bulimia was found in other ontology and it has a sameAs correlation with the changed concept

Action: 



 





 

Change Patterns:

ChangePattern (



 

Partial Match  



D055705

 Physiological Processes

 Level 4

 When previous levels have not worked!

 Annotation:  

   

   because a ChgAttValue

superClass 



  

Rules  

D055705 SubClassOf 

Action:





 





D010829

D055705

Find annotations that

might be impacted by

the KOS evolution

Apply formal heuristics

to maintain the

annotations using KOS

changes

Access external resources

to retrieve additional

information to maintain the

annotations. These

information are validated

using formal heuristics

Use of change patterns to

identify the correlation

between concepts over time

and maintain the

annotations

Figure 2: Examples illustrating the behaviour of the framework at each level.

the maintenance and optimize the quality of the set of

adapted annotations.

• Identiﬁcation of invalid annotations: It consists

in identifying invalid annotations by analyzing the

evolution of the associated KOS. To this end, it

takes as input a set of annotations and two suc-

cessive versions of the used KOS namely K

and

n+1

. The identiﬁcation of concepts that have

Towards a Multi-level Approach for the Maintenance of Semantic Annotations

403

changed between K

and K

n+1

can be obtained

using an ontology Diff tool (Hartung et al., 2013;

Noy et al., 2002) as well as additional information

specifying the type of changes that have affected

these concepts. As it is the case for ontology map-

ping adaptation (Groß et al., 2013), such informa-

tion plays a key role in the maintenance task be-

cause it will determine the type of correction to

apply to the annotations in the next levels. For in-

stance, the deletion of a concept attribute can lead

to the deletion of annotations but the deletion of

the same attribute value in the context of a split

of concept can lead to the migration of the anno-

tation to the evolved version of the concept (i.e.

the result of the split). It is therefore crucial to

consider not only basic ontological changes (i.e.

addition/deletion of concept) as it is the case in ex-

isting approaches for annotation maintenance but

complex changes (i.e. split/merge of concepts)

to optimize both the maintenance process and the

quality of the adapted annotations.

• Annotation correction using ontology change

rules: It consists in using information derived

from the set of annotations itself as well as the

data of the Diff between the two KOS versions K

and K

n+1

coming from the previous level to adapt

the identiﬁed invalid annotations. At this level, the

correction of annotations can be speciﬁed in rules

that combine the context of evolution of the KOS

and the status of the annotations. Under these con-

ditions, the rules must specify the maintenance ac-

tion to perform. For instance, we observed cases

where an annotation was impacted because in its

new version the label of concept associated with

this particular annotation adopted the plural form.

Therefore the corresponding rule can look like:

“If the label of concept is set to its plural form

then do not change the annotation”

The type of ontological change contained in the

Diff allows to propose more elaborated correction

rules acting directly on the element of the anno-

tation model like the o f f set. For instance, if the

attribute used to annotate the text contained in an

EHR is modiﬁed (e.g., a new word was added at

the end of the label), then we check if we can ﬁnd

this modiﬁcation in the text of the document to

annotate (e.g., if the new word is also adjacent to

the old text) by checking the information located

at the o f f set position. The corresponding rule is:

“If the label of concept increase and the data lo-

cated beside the offset of the annotation is equal

to the added word then increase the offset”

Another example is depicted in Figure 2. The an-

notation sneezing associated with the concept hav-

ing as code 784.09 in ICD-9-CM version 2006 is

no more valid in 2007. It is the direct consequence

of the split of concept 784.9 between 2006 and

2007.

In the example of Figure 2 the depicted rule

checks if a concept was split. Basically, it speci-

ﬁes if the concept 784.99 from the new version of

ICD-9-CM was engendered by a split of concept

and whether it has a label (or an attribute value)

which is equal to the same text of the annotation.

It also veriﬁes that the new version of the concept

784.9 (if it still exists) has no label of concept that

fully match the text of the annotation. As a result,

the action to maintain this annotation is to change

the source concept of the annotation to 784.99.

• Annotation correction using external resource

knowledge: It consists in using information in-

ferred from external knowledge sources to main-

tain the annotations that could not be corrected

using local resources of the previous level. Ac-

tually, in many cases the drift of ontological con-

cepts can be characterized only by considering the

semantic relationships provided by other ontolo-

gies (Pruski et al., 2016). Often labels of con-

cept are completely different, from the syntactic

point of view, before and after evolution. There-

fore, considering local resources only does not al-

low to characterize their evolution and, in turn,

cannot be reused for annotation maintenance pur-

pose. The example depicted in Figure 2 about the

evolution of the label of concept 307.51 of ICD-

9-CM “Bulimia” in 2004 to “Bulimia nervosa” in

2005 shows another use case that requires external

knowledge source. Applying existing approaches

on annotation associated with this concept would

simply lead to the deletion of the annotations. But

the consideration of external resource (here map-

pings between ICD-9-CM and SNOMED CT pro-

vided by Bioportal) tells that these two terms are

synonyms therefore the annotation can be kept.

Nevertheless, the nature of the external knowl-

edge resources can vary. Whether RDF datasets

like BIO2RDF (Belleau et al., 2008) or expres-

sive OWL ontologies contained in Bioportal (Noy

et al., 2009) are considered, the inferred informa-

tion can be of different quality and can affect the

quality of the maintenance process.

• Annotation correction using change patterns:

At this stage, information provided by the Diff

and the use of external resources are not sufﬁ-

cient to maintain invalid annotations. The anal-

ysis of the morphosyntactic form of concept la-

bels can reveal information to take decision about

the maintenance of annotation. This technique has

HEALTHINF 2017 - 10th International Conference on Health Informatics

404

already been explored in the context of ontology

mapping adaptation (Dos Reis et al., 2015) but re-

mains less relevant in terms of quality in the re-

sulting maintenance decisions. Change Patterns

are modiﬁcations observed in attribute values of

a concept using linguistic-based features to iden-

tify the correlation between concepts over time.

For instance, a Partial Copy between concepts is

computed if and only if there exists a partial over-

lap between words from an attribute present in the

KOS version K

and an attribute in the new KOS

version K

n+1

(i.e., the attribute a

becomes a

For instance, the annotation “Physiologic pro-

cesses”, shown at the bottom of Figure 2 pro-

duced using MeSH in period 2008/2009 was re-

moved. This is due to a change in the attribute

value in the deﬁnition of the concept D010829

leading to “Physiological Phenomena”. Assum-

ing the following conditions: i) we do not have in-

formation inside the ontology to handle with this

change, ii) the super class from concept D010829

is Thing iii) external resources do not provide the

necessary information to make decision, the ap-

plication of four change patterns (total copy, total

transfer, partial copy, partial transfer) consider-

ing only the attributes in the same sub-ontology

e.g., the sub classes from concept D010829 allow

to change the concept associated to this annotation

from D010829 to D055705.

3.2 Output

Our approach was designed to process the annota-

tions according to different levels of granularity, but

the outputs only contain three kinds of data.

The ﬁrst one refers to the nature of the annota-

tions. It makes the distinction between annotations

impacted by the evolution of the underlying KOS and

non impacted annotations. We described in details

these annotations in (Cardoso et al., 2016).

At the levels dealing with the correction of the

annotations, the outputs are: i) the corrected anno-

tations and ii) the set of annotations that need fur-

ther investigation. Once corrected, the annotations are

also enriched with evolution information making fu-

ture modiﬁcations easier and enhancing their quality.

If invalid annotations remain, the deﬁnition of an-

other levels exploiting different kind of information

for maintenance purpose need to be implemented.

The complexity of the evolution affecting KOS, the

nature of the annotation, the speciﬁcities of the kind

of object to annotate need to be taken into account in

the deﬁnition of the additional levels. The rules that

are used at each level also need to be deﬁned by con-

sidering the quality of the adapted annotations.

4 CONCLUSION

We have presented a multi-level approach towards

the (semi-)automatic maintenance of the annotations

turned invalid after the evolution of their associated

KOS. Our proposal is based on literature review as

well as experimentations and consists in the progres-

sive integration of complex information of different

nature and various sources for correcting invalid se-

mantic annotations without re-annotating documents.

As future work, we will put the stress in the deﬁnition

and validation of such a framework. Since our anno-

tation framework will be used to (semi-)automatically

correct outdated annotations, the used methods will

need careful evaluation according to the quality of the

produced results. For future work, we also plan to

evaluate the different maintenance approaches using

several annotation datasets from the biomedical do-

main such as annotated CRFs or EHR.

ACKNOWLEDGEMENTS

The National Research Fund (FNR) of Luxembourg

and Deutsche Forschungsgemeinschaft (DFG) sup-

port this work under the ELISA research project.

REFERENCES

Abgaz, Y. M. (2013). Change impact analysis for evolv-

ing ontology-based content management. PhD thesis,

Dublin City University.

Auer, S. and Herre, H. (2007). A Versioning and Evolution

Framework for RDF Knowledge Bases, pages 55–69.

Springer Berlin Heidelberg, Berlin, Heidelberg.

Belleau, F., Nolin, M.-A., Tourigny, N., Rigault, P., and

Morissette, J. (2008). Bio2rdf: towards a mashup to

build bioinformatics knowledge systems. Journal of

biomedical informatics, 41(5):706–716.

Burger, T., Morozova, O., Zaihrayeu, I., Andrews, P., and

Pane, J. (2010). Report on methods and algorithms

for linking user-generated semantic annotations to se-

mantic web and supporting their evolution in time.

Cardoso, S. D., Pruski, C., Silveira, M. D., Lin, Y.,

Groß, A., Rahm, E., and Reynaud-Dela

ıtre, C. (2016).

Leveraging the impact of ontology evolution on se-

mantic annotations. In Knowledge Engineering and

Knowledge Management - 20th International Confer-

ence, EKAW 2016, Bologna, Italy, November 19-23,

2016, Proceedings, pages 68–82.

Da Silveira, M., Dos Reis, J. C., and Pruski, C. (2015).

Management of dynamic biomedical terminologies:

Towards a Multi-level Approach for the Maintenance of Semantic Annotations

405

Current status and future challenges. Yearbook of

Medical informatics, 10(1):125–133.

Dos Reis, J. C., Dinh, D., Da Silveira, M., Pruski, C., and

Reynaud-Dela

ıtre, C. (2015). Recognizing lexical and

semantic change patterns in evolving life science on-

tologies to inform mapping adaptation. Artiﬁcial in-

telligence in medicine, 63(3):153–170.

Eilbeck, K., Moore, B., Holt, C., and Yandell, M. (2009).

Quantitative measures for the management and com-

parison of annotated genomes. BMC Bioinformatics,

10(1):67.

Frost, H. R. and Moore, J. H. (2014). Optimization of gene

set annotations via entropy minimization over variable

clusters (emvc). Bioinformatics (Oxford, England),

30(12):1698–1706.

Funk, C., Baumgartner, W., Garcia, B., Roeder, C., Bada,

M., Cohen, K. B., Hunter, L. E., and Verspoor, K.

(2014). Large-scale biomedical concept recognition:

an evaluation of current automatic annotators and their

parameters. BMC Bioinformatics, 15(1):1–29.

Gimenez, F., Xu, J., Liu, Y., Liu, T. T., Beaulieu, C. F.,

Rubin, D. L., and Napel, S. (2012). Automatic anno-

tation of radiological observations in liver CT images.

In AMIA 2012, American Medical Informatics Asso-

ciation Annual Symposium, Chicago, Illinois, USA,

November 3-7, 2012.

Groß, A., Dos Reis, J. C., Hartung, M., Pruski, C., and

Rahm, E. (2013). Semi-automatic adaptation of map-

pings between life science ontologies. In International

Conference on Data Integration in the Life Sciences,

pages 90–104. Springer.

Groß, A., Hartung, M., Kirsten, T., and Rahm, E. (2009).

Estimating the quality of ontology-based annotations

by considering evolutionary changes. In International

Workshop on Data Integration in the Life Sciences,

pages 71–87. Springer.

Groß, A., Hartung, M., Prufer, K., Kelso, J., and Rahm, E.

(2012). Impact of ontology evolution on functional

analyses. Bioinformatics, 28(20):2671–2677.

Hartung, M., Groß, A., and Rahm, E. (2013). Conto–diff:

generation of complex evolution mappings for life sci-

ence ontologies. Journal of biomedical informatics,

46(1):15–32.

Hodge, G. (2000). Systems of knowledge organization

for digital libraries: Beyond traditional authority ﬁles.

Reports - Descriptive.

opke, J. and Eder, J. (2011). Semantic invalidation of an-

notations due to ontology evolution. In Meersman, R.,

Dillon, T., Herrero, P., Kumar, A., Reichert, M., Qing,

L., Ooi, B.-C., Damiani, E., Schmidt, D., White, J.,

Hauswirth, M., Hitzler, P., and Mohania, M., editors,

On the Move to Meaningful Internet Systems: OTM

2011, volume 7045 of Lecture Notes in Computer Sci-

ence, pages 763–780. Springer Berlin Heidelberg.

Luong, P.-H. and Dieng-Kuntz, R. (2006). A rule-based

approach for semantic annotation evolution in the

coswem system. In Canadian Semantic Web, vol-

ume 2 of Semantic Web and Beyond, pages 103–120.

Springer US.

Maynard, D., Peters, W., and Sabou, M. (2007). Change

management for metadata evolution.

Noy, N. F., Musen, M. A., et al. (2002). Promptdiff:

A ﬁxed-point algorithm for comparing ontology ver-

sions. AAAI/IAAI, 2002:744–750.

Noy, N. F., Shah, N. H., Whetzel, P. L., Dai, B., Dorf, M.,

Grifﬁth, N., Jonquet, C., Rubin, D. L., Storey, M.-A.,

Chute, C. G., et al. (2009). Bioportal: ontologies and

integrated data resources at the click of a mouse. Nu-

cleic acids research, page gkp440.

Park, Y. R., Kim, J., Lee, H. W., Yoon, Y. J., and Kim, J. H.

(2011). Gochase-ii: correcting semantic inconsisten-

cies from gene ontology-based annotations for gene

products. BMC Bioinformatics, 12(1):1–7.

Pruski, C., Dos Reis, J. C., and Da Silveira, M. (2016). Cap-

turing the relationship between evolving biomedical

concepts via background knowledge. In the 9th Se-

mantic Web Applications and Tools for Life Sciences

International Conference.

Qin, L. and Atluri, V. (2009). Evaluating the validity of data

instances against ontology evolution over the semantic

web. Information and Software Technology, 51(1):83

– 97.

Tissaoui, A., Aussenac-Gilles, N., Hernandez, N., and

Laublet, P. (2011). Evonto - joint evolution of on-

tologies and semantic annotations. In Dietz, J., ed-

itor, International Conference on Knowledge Engi-

neering and Ontology Development (KEOD), Paris,

26/10/2011-29/10/2011, pages 226–231.

Uren, V., Cimiano, P., Iria, J., Handschuh, S., Vargas-Vera,

M., Motta, E., and Ciravegna, F. (2006). Semantic an-

notation for knowledge management: Requirements

and a survey of the state of the art. Web Semantics:

Science, Services and Agents on the World Wide Web,

4(1):14 – 28.

Yimam, S. M., Biemann, C., Majnaric, L.,

Sabanovi

S.,

and Holzinger, A. (2016). An adaptive annotation ap-

proach for biomedical entity and relation recognition.

Brain Informatics, 3(3):157–168.

Zavalina, O. L., Kizhakkethil, P., Alemneh, D. G., Phillips,

M. E., and Tarver, H. (2015). Building a framework of

metadata change to support knowledge management.

Journal of Information & Knowledge Manage-

ment, 14(01):1550005.

HEALTHINF 2017 - 10th International Conference on Health Informatics

406
