Animal Sound Classification using Sequential Classifiers

Javier Romero, Amalia Luque

and Alejandro Carrasco

Escuela Politécnica Superior, Universidad de Sevilla, Sevilla, Spain

Keywords: Sound Classification, Data Mining, Sequential Classifiers, Habitat Monitoring.

Abstract: Several authors have shown that the sounds of anurans can be used as an indicator of climate change. But

the recording, storage and further processing of a huge number of anuran’s sounds, distributed in time and

space, are required to obtain this indicator. It is therefore highly desirable to have algorithms and tools for

the automatic classification of the different classes of sounds. In this paper five different classification

methods are proposed, all of them based on the data mining domain, which try to take advantage of the

sound sequential behaviour. Its definition and comparison is undertaken using several approaches. The

sequential classifiers have revealed that they can obtain a better performance than their non-sequential

counterpart. The sliding window with an underlying decision tree has reached the best results in our tests,

even overwhelming the Hidden Markov Models usually employed in similar applications. A quite

remarkable overall classification performance has been obtained, a result even more relevant considering

the low quality of the analysed sounds.

1 INTRODUCTION

Climate change is becoming one of the most

demanding concerns for the whole humanity. For

this reason, many indicators are being defined and

used trying to monitor the global warming evolution.

Some of these indicators have to do with the

warming impact in the biosphere, measuring the

change in some animal species population.

Indeed, sound production in ectotherms animals

is strongly influenced by the ambient temperature

(Márquez and Bosch, 1995) which can affect various

features of their acoustic communication system. In

fact the ambient temperature, once exceeded a

certain threshold, can restrict the physiological

processes associated to the sound production even

inhibiting behaviour call. As a result, the

temperature may significantly affect the patterns of

calling songs modifying the beginning, duration and

intensity of calling episodes and, consequently, the

anuran reproductive activity.

Therefore, the analysis and classification of the

sounds produced by certain animal species have

revealed as a strong indicator of temperature chan-

ges and therefore the possible existence of climate

Corresponding author

change. Particularly interesting are the results

provided by anuran sounds analysis (Llusia et al.,

2013).

In previous works (Luque et al., 2016) it has

been proposed a non-sequential method for sound

classification. According to this procedure, the

sound is split up in 10 msec. frames. Next, every

frame is featured using 18 MPEG-7 parameters: a

vector in

ℝ



(ISO, 2001). Then the frame features

are compared to some frame patterns belonging to

known species, assigning a class label to each frame.

Eventually the sound is classified by frame voting,

i.e., the most frequent frame class is assigned to the

whole sound.

Comparing frame features to frame patterns is

called a supervised classification in the data mining

realm. Up to 9 different algorithms have been

proposed in (Romero et al., 2016) to make this

classification.

However, sounds are inherently made up of

sequential data. So, if the frame sequence

information is added to the classification process,

better classification results should be expected.

242

Romero J., Luque A. and Carrasco A.

Animal Sound Classiﬁcation using Sequential Classiﬁers.

DOI: 10.5220/0006246002420247

In Proceedings of the 10th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2017), pages 242-247

ISBN: 978-989-758-212-7

2 METHODS

To introduce the sequential information several

methods are proposed.

 Temporal parameters construction (TP)

(Schaidnagel et al., 2014). For every frame, a

“segment” is considered using the closest

neighbour frames. And for every parameter, a

new parameter is constructed: the interquartile

range in the segment. In this way, up to 36

parameters (a vector in

ℝ



) are now

identifying a frame, 18 of them including

some kind of sequence information. A 10

frame segment is proposed in this study.

 Sliding windows (SW) (Aggarwal, 2007). A

short window (e.g. with 5 frames), centred in

each frame, is considered. Now the parameters

featuring each frame (e.g. 5 parameters) are

those corresponding to all the frames under

the window. In the example, each frame is

featured using 5x5 parameters (a vector in

ℝ



 Recursive sliding windows (RSW) (Dietterich,

2002). It is a method similar to the previous

one, but now the classifier considers not only

the parameters of the frame under the window,

but also their classification results.

 Hidden Markov Models (HMM) (Rabiner,

1989). It is a genuine sequential classifier. The

sequence of frame parameters is considered to

be obtained as the result of an HMM made up

of hidden states emitting observed data. This

is the classifier recommended in the MPEG-7

standard.

 Autoregressive integrated moving average

models (ARIMA) (Box et al., 2011). It is also

a genuine sequential classifier. The sequence

of frame parameters is considered the result of

an ARIMA time series. For a certain sound,

the coefficients of the time series are

computed and, in a second step, these

coefficients are classified using non-sequential

classifiers.

Most of this sequential classifier (all except the

HMM) are relying on an underlying non-sequential

classifier. A broad and representative selection of

them has been used through this paper:

 Minimum distance (Wacker and Landgrebe,

1971);

 Maximum likelihood (Le Cam, 1979);

 Decision trees (Rokach et al., 2008);

 k-nearest neighbour (Cover and Hart, 1967);

 Support vector machine (SVM) (Cristianini

and Shawe-Taylor, 2000);

 Logistic regression (Dobson and Barnett,

2008);

 Neural networks (Du and Swamy, 2013);

 Discriminant function (Härdle and Simar,

2012);

 Bayesian classifiers (Hastie et al., 2005).

Sequential classifiers significantly increases the

number of parameters required. To cope with this

drawback, a reduction on the number of original

MPEG-7 parameters is proposed, considering the 5

most significant features (leading to a vector in

ℝ



Feature selection procedures are employed to

determine this reduced set.

For comparison reasons, 2 non-sequential

methods are also considered:

 Non-sequential classification based on 18

MPEG-7 parameters (NS-18).

 Non-sequential classification based on the 5

most relevant MPEG-7 parameters (NS-5).

To compare the results obtained for every

classifier, several metrics for the performance of a

classifier can be defined (Sokolova and Lapalme,

2009), all of them based on the confusion matrix.

The most relevant indicators and their definitions are

the following:

 Accuracy: Overall effectiveness of a classifier;

 Error rate: Classification error;

 Precision: Class agreement of the data labels

with the positive labels given by the classifier;

 Sensitivity: Effectiveness of a classifier to

identify positive labels;

 Specificity: How effectively a classifier

identifies negative labels.

Additionally, a graphical way to compare

classifiers will be used, representing their

performance in the Receiver Operating

Characteristic (ROC) space (Powers, 2011), where

the True Positive Rate (sensitivitiy) of a classifier is

plotted versus its False Positive Rate (defined as one

minus the specificity).

3 RESULTS

For testing purposes, sound files provided by the

Zoological Sound Library (Fonozoo, 2016) have

been used, corresponding to 2 species, the epidalea

calamita (natterjack toad) and alytes obstetricans

(common midwife toad), with a total of 63

recordings containing 3 classes of sounds:

 Epidalea calamita; mating call (23 records)

 Epidalea calamita; release call (10 records)

Animal Sound Classiﬁcation using Sequential Classiﬁers

243

 Alytes obstetricans (30 records)

In total 6,053 seconds (1h:40':53") of recording

have been analysed, with a 96 seconds (1':36")

average file length, and a 53 seconds median.

A common feature of all recordings is that they

have been made in the natural habitat, with very

significant surrounding noise (wind, water, rain,

traffic, voice...), which means an additional

challenge in the signal processing.

The results obtained by the non-sequential

classifiers based on 18 MPEG-7 parameters are

compared using the ROC analysis which is depicted

in Figure 1. The best result corresponds to the

decision tree classifier with an accuracy of 91.53%.

Figure 1: ROC analysis for non-sequential classifiers

based on 18 MPEG-7 parameters.

The results obtained by the non-sequential

classifiers based on the 5 most relevant MPEG-7

parameters are also compared using the ROC

analysis which is depicted in Figure 2. The best

result corresponds to the decision tree classifier with

an accuracy of 89.42%.

The results obtained by the temporal parameter

construction approach are now considered. The

corresponding ROC analysis is depicted in Figure 3.

The best result corresponds to the decision tree

classifier with an accuracy of 91.53%.

Focusing now on the sliding window method, its

results are compared through the ROC analysis and

presented in Figure 4. The best result corresponds to

the decision tree classifier with an accuracy of

90.48%.

Once more, the results obtained by the recursive

sliding window method are compared using the

ROC analysis which is portrayed in Figure 5. The

best result corresponds to the decision tree classifier

with an accuracy of 73.54%.

Figure 2: ROC analysis for non-sequential classifiers

based on the 5 most relevant MPEG-7 parameters.

Figure 3: ROC analysis for sequential classifiers using

temporal parameter construction.

Figure 4: ROC analysis for sequential classifiers using

sliding windows.

0 10 20 30 40 50 60 70 80 90 100

100

False Positive Rate (%)

True Positive Rate (%)

MinDis

MaxLik

DecTr

kNN

SVM

LogReg

Neur

Discr

Bayes

0 10 20 30 40 50 60 70 80 90 100

100

False Positive Rate (%)

True Positive Rate (%)

MinDis

MaxLik

DecTr

kNN

SVM

LogReg

Neur

Discr

Bayes

0 10 20 30 40 50 60 70 80 90 100

100

False Positive Rate (%)

True Positive Rate (%)

MinDis

MaxLik

DecTr

kNN

SVM

LogReg

Neur

Discr

Bayes

BIOSIGNALS 2017 - 10th International Conference on Bio-inspired Systems and Signal Processing

244

Table 1: Performance metrics.

Method

Number of

features

ACC PRC SNS SPC

Non-sequential

18 91.53% 87.05% 83.43% 93.01%

5 89.42% 85.40% 83.77% 91.52%

Temporal parameters 36 91.53% 91.40% 84.44% 93.33%

Sliding windows 5x5 90.48% 87.23% 87.44% 92.53%

Recursive sliding windows 5x5 73.54% 51.57% 62.22% 74.92%

HMM

Over the file 5 84.13% 70.24% 61.64% 85.58%

Over ROI length segments 5 59.79% - 40.00% 68.54%

Over 5 sliding windows 5 69.31% 56.42% 52.75% 78.13%

ARIMA 5 70.37% 63.17% 52.66% 77.48%

Figure 5: ROC analysis for sequential classifiers using

recursive sliding windows.

Figure 6: ROC analysis for sequential classifiers using

ARIMA models.

The HMM is the only of the proposed methods

not relaying in other classifiers. Therefore, it is not a

ROC analysis to compare the non-existent

classifiers. The HMM takes a sound segment and try

to classify it as a whole, not framing it. When a

sound file has to be classified 3 alternatives have

been explored to determine the segment length:

 The full file (HMM-F). This approach obtains

an accuracy of 84.13%.

 A segment with the same length that the ROI

mean length (HMM-ROI). The Regions Of

Interest (ROIs) are the segments of the sound

patterns containing a valid sound (no silence

or noise). This approach obtains an accuracy

of 59.79%.

 A segment defined by a sliding window of a

certain length (HMM-SW). It is proposed to

use 5 frames in the analysis. This approach

obtains an accuracy of 69.31%.

Eventually, the results obtained by the ARIMA

method are also compared using the ROC analysis

which is illustrated in Figure 6. The best result

corresponds to the decision tree classifier with an

accuracy of 70.37%.

Until now, partial results have been presented for

every sequential method. To obtain an overall

perspective, a comparison of the different methods

proposed for sequential classifiers is presented in

Table 1, where the non-sequential classifiers are also

considered for contrasting reasons. Additionally, a

ROC analysis has also been accomplished for every

method and its results are depicted in Figure 7.

Considering now the best sequential method

(sliding window) and the underlying best classifier

(decision tree) the overall results can be examined.

The confusion matrix is presented in Table 2.

Additionally the classification profile is depicted

in Figure 8. It can be seen that an overall success

rate of 85.71% is obtained, with quite balanced

values for every class. These results are considered a

good performance, furthermore when considering

the low quality of the sound records.

0 10 20 30 40 50 60 70 80 90 100

100

False Positive Rate (%)

True Positive Rate (%)

MinDis

MaxLik

DecTr

kNN

SVM

LogReg

Neur

Discr

Bayes

0 10 20 30 40 50 60 70 80 90 100

100

False Positive Rate (%)

True Positive Rate (%)

DisMin

MaxVer

ArDec

kNN

SVM

RegLog

Neur

Discr

Bayes

Animal Sound Classiﬁcation using Sequential Classiﬁers

245

Figure 7: ROC analysis for sequential methods.

Table 2: Confusion matrix for the sliding window method

with decision tree classifier.

Classification obtained

1 2 3

Data class

20 0 3

3 7 0

1 1 28

Figure 8: Classification profile for the sliding window

method with decision tree classifier.

4 CONCLUSIONS

From the above results several conclusions can be

reached. Firstly, they have shown that at least 2

sequential methods, the temporal parameter

construction and the sliding window, slightly

enhance the non-sequential classification, at least in

terms of ROC analysis.

The sliding window appears as the most efficient

approach and show the best metrics among the

classifiers based on the same number of parameters

(5 parameters).

When the sequential method relies on another

classifier, the decision tree algorithm stands out in

almost every case. The only exception is the

recursive sliding window method, where decision

tree is the second best classifier (after the k-nearest

neighbour).

The sliding window with an underlying decision

tree classifier reaches a remarkable overall success

rate (85.71%), a figure even more relevant

considering the low quality of the analysed sounds.

Its results clearly overcome the performance

obtained, in any of the studied variants, through the

Hidden Markov Models, the MPEG-7 proposed

technique.

ACKNOWLEDGEMENTS

This work has been supported by the Consejería de

Innovación, Ciencia y Empresa, Junta de Andalucía,

Spain, through the excellence eSAPIENS (reference

number TIC-5705). The authors would like to thank

Rafael Ignacio Marquez Martinez de Orense (Museo

Nacional de Ciencias Naturales) and Juan Francisco

Beltrán Gala (Faculty of Biology, University of

Seville) for their collaboration and support.

REFERENCES

Aggarwal, C. C. (2007). Data streams: models and

algorithms (Vol. 31). Springer Science and Business

Media.

Box, G. E., Jenkins, G. M., Reinsel, G. C. (2011). Time

series analysis: forecasting and control (Vol. 734).

John Wiley and Sons.

Cover, T. M., Hart, P. E. (1967). Nearest neighbor pattern

classification. Information Theory, IEEE Transactions

on, 13(1), 21-27.

Cristianini, N., Shawe-Taylor, J. (2000). An introduction

to support vector machines and other kernel-based

learning methods. Cambridge University Press.

Dietterich, T. G. (2002). Machine learning for sequential

data: A review. In Structural, syntactic, and statistical

pattern recognition (pp. 15-30). Springer Berlin

Heidelberg.

Dobson, A. J., Barnett, A. (2008). An introduction to

generalized linear models. CRC press.

Du, K. L., Swamy, M. N. S. (2013). Neural Networks and

Statistical Learning. Springer Science and Business

Media.

Fonozoo.com (2016). Retrieved from http://www.fonozoo.

com/

Härdle, W. K., Simar, L. (2012). Applied multivariate

statistical analysis. Springer Science and Business

Media.

Hastie, T., Tibshirani, R., Friedman, J. (2005). The

elements of statistical learning: data mining, inference

and prediction. Springer-Verlag.

ISO (2001). ISO 15938-4:2001 (MPEG-7: Multimedia

Content Description Interface), Part 4: Audio. ISO.

Le Cam, L. M. (1979). Maximum likelihood: an

introduction. Statistics Branch, Department of

0 10 20 30 40 50 60 70 80 90 100

100

False Positive Rate (%)

True Positive Rate (%)

NS-18

NS-5

RSW

HMM-F

HMM-ROI

HMM-SW

ARIMA

Overall success rate: 85.71%

Calamita: mating (96%)

Calamita: release (90%)

Alytes obstetricans (77%)

BIOSIGNALS 2017 - 10th International Conference on Bio-inspired Systems and Signal Processing

246

Mathematics, University of Maryland.

Llusia, D., Márquez, R., Beltrán, J. F., Benitez, M., Do

Amaral, J. P. (2013). Calling be-haviour under climate

change: geographical and seasonal variation of calling

temperatures in ectotherms. Global change biology,

19(9), 2655-2674.

Luque, J., Larios, D. F., Personal, E., Barbancho, J., León,

C. (2016). Evaluation of MPEG-7-Based Audio

Descriptors for Animal Voice Recognition over

Wireless Acoustic Sensor Networks. Sensors, 16(5),

717.

Márquez, R., Bosch, J. (1995). Advertisement calls of the

midwife toads Alytes (Amphibia, Anura,

Discoglossidae) in continental Spain. Journal of

Zoological Systematics and Evolutionary Research,

33(3-4), 185-192.

Powers, D. M. (2011). Evaluation: from precision, recall

and F-measure to ROC, informedness, markedness

and correlation. Journal of Machine Learning

Technologies, 2(1), 37-63.

Rabiner, L. R. (1989). A tutorial on hidden Markov

models and selected applications in speech

recognition. Proceedings of the IEEE, 77(2), 257-286.

Rokach, Lior, Maimon, O. (2008). Data mining with

decision trees: theory and applications. World

Scientific Pub Co Inc.

Romero, J., Luque, A., Carrasco, A. (2016). Anuran sound

classification using MPEG-7 frame descriptors. XVII

Conferencia de la Asociación Española para la

Inteligencia Artificial (CAEPIA), 801-810.

Schaidnagel, M., Connolly, T., Laux, F. (2014).

Automated feature construction for classification of

time ordered data sequences. International Journal on

Advances in Software, 7(3 and 4), 632-641.

Sokolova, M., Lapalme, G. (2009). A systematic analysis

of performance measures for classification tasks.

Information Processing and Management, 45(4), 427-

437.

Wacker, A. G., Landgrebe, D. A. (1971). The minimum

distance approach to classification. Purdue University.

Information Note 100771.

Animal Sound Classiﬁcation using Sequential Classiﬁers

247
