A Generic Agent Architecture for Cooperative Multi-agent Games

ao Marinheiro

and Henrique Lopes Cardoso

1,2

DEI/FEUP, Faculdade de Engenharia, Universidade do Porto, Porto, Portugal

LIACC – Laborat

orio de Intelig

encia Artiﬁcial e Ci

encia de Computadores, Porto, Portugal

Keywords:

Multi-agent Systems, Cooperative Games, Negotiation, Opponent Modeling, Trust Reasoning.

Abstract:

Traditional search techniques are difﬁcult to apply to cooperative negotiation games, due to the often enormous

search trees and the difﬁculty in calculating the value of a players position or move. We propose a generic

agent architecture that ensembles negotiation, trust and opponent modeling, simplifying the development of

agents capable of playing these games effectively by introducing modules to handle these challenges. We

demonstrate the application of this modular architecture by instantiating it in two different games and testing

the designed agents in a variety of scenarios; we also assess the role of the negotiation, trust and opponent

modeling modules in each of the games. Results show that the architecture is generic enough to be applied in

a wide variety of games. Furthermore, we conclude that the inclusion of the three modules allows for more

effective agents to be built.

1 INTRODUCTION

Games have always been an important testbed to

develop new and interesting ideas in AI research.

There has been extensive research using games like

Chess (Drogoul, 1995) or Go (Silver et al., 2016).

However, most research in this area relates to tradi-

tional adversarial games and makes use of extensive

searching and game speciﬁc heuristics in order to ﬁnd

the best move

One interesting category of games is that of co-

operative negotiation games, where players are en-

couraged to barter and create or break deals between

themselves in order to win. In the ﬁeld of game the-

ory, a game is considered a cooperative game if play-

ers are able to form binding commitments with each-

other. Games in which players can not create binding

agreements are usually considered non-cooperative

games (Nash, 1951). It is usually assumed that com-

munication between players is allowed in cooperative

games but not in non-cooperative games.

For the purposes of this work, however, we con-

sider a different, more general, deﬁnition of coop-

erative games – games in which cooperation be-

tween players is possible and encouraged but which

is not necessarily based on binding agreements. More

The DeepMind approach (Silver et al., 2016) is a late

deviation to this status quo, and has recently been applied to

imperfect information games (Heinrich and Silver, 2016).

speciﬁcally, we will focus on cooperative negotia-

tion games with a mix of cooperation and competi-

tion. Some characteristics that are frequently present

in these games are:

• Very large search spaces, which makes the appli-

cation of traditional search techniques impracti-

cal.

• Difﬁculty in evaluating moves and player posi-

tions due to how the values for these often depend

on the social context of the game.

• The possibility of betrayals and desertions due to

the existence of non-binding agreements.

Two examples of cooperative negotiation games

are Diplomacy (Calhamer, 2000) and Werewolves

of Miller’s Hollow (des Palli

eres and Marly, 2009).

Diplomacy is a strategy game for 7 players where

each player takes control of a nation. By submitting

orders to their armies and navies, which are executed

simultaneously with those of other nations, players

must try to capture territories and supply centers in

a map of Europe. The ﬁrst player to capture 18 or

more supply centers wins the game. Because players

can issue orders to support their opponents, the game

encourages players to negotiate and cooperate among

themselves in order to win the game.

Werewolves of Miller’s Hollow, on the other hand,

is a team based game where two teams, the villagers

and the werewolves, attempt to eliminate each other.

Marinheiro J. and Lopes Cardoso H.

A Generic Agent Architecture for Cooperative Multi-agent Games.

DOI: 10.5220/0006253101070118

In Proceedings of the 9th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2017), pages 107-118

ISBN: 978-989-758-219-6

107

The twist is that the players on the villager team

do not know who their team mates are and who the

werewolves are, encouraging players to communi-

cate, share information and decide who to trust. The

game is played in two phases: the day phase, where

players communicate freely, ending with a vote to

eliminate one player thought to be a werewolf by the

remaining players; and the night phase, where play-

ers cannot communicate but can choose to use some

special abilities depending on their role in the game.

Due to the characteristics of cooperative negotia-

tion games it is possible to obtain much better results

in these games if one is able to negotiate and coor-

dinate with other players effectively. Unfortunately,

while humans are very good at negotiation and intu-

itively distinguish who to trust, it is much harder for

a computer to do so. In order to develop effective and

believable software agents for these sorts of games,

and cope with the large size of the search spaces, new

strategies that can effectively tackle the concepts of

negotiation, opponent modeling and trust reasoning

need to be employed. We propose a generic agent ar-

chitecture that tackles these concepts and facilitates

the development of agents with these capabilities to

play cooperative negotiation games.

The rest of this paper is structured as follows. In

Section 2 we brieﬂy describe some of the existing ap-

proaches in this area. Section 3 introduces the pro-

posed architecture and its different modules. Then,

in Section 4 we describe some agents implemented

using the proposed architecture. In Section 5 we de-

scribe the tests and experiments executed using the

developed agents, together with some results. Finally,

in Section 6, we discuss the implications and conclu-

sions taken from the results obtained as well as some

possible future work towards the improvement of the

proposed architecture and developed agents.

2 RELATED WORK

Cooperative negotiation games have not received too

much attention in the ﬁeld of artiﬁcial intelligence, the

game of Diplomacy being a notable exception. We

here discuss some of the many agents created to play

Diplomacy, since to the best of our knowledge no sig-

niﬁcant research has been applied to other cooperative

games.

One of the simplest agents implemented for

Diplomacy – DumbBot – was developed by David

Norman (Norman, 2013). This bot has no negotia-

tion capabilities and uses a simple heuristic to decide

its actions by preferring to choose moves that weaken

its strongest opponents. DumbBot assigns a value

to each territory that depends on who controls it and

what units are around it, and then it assigns actions to

every unit depending on those score values. While the

method used is very simple, DumbBot obtains fairly

good results and is frequently used as a benchmark

for other Diplomacy agents.

One of the most important and inﬂuential nego-

tiating agents is the Israeli Diplomat (Kraus et al.,

1989; Kraus et al., 1995). This agent was designed

with a general negotiation architecture to be applied

in a variety of situations. The Israeli Diplomat tries to

mimic the structure of a war-time nation. It consists

of several components working together to choose the

best course of action. The diplomat keeps a knowl-

edge base of the relations it believes each nation has

with each other, as well as any agreements it has and

its intention to keep them, together with its trust that

others will keep them as well. This knowledge base

is updated by the different modules as the game pro-

gresses, and affects every decision the diplomat takes.

Another interesting approach in this area is that

of D-Brane (de Jonge, 2015), an agent developed by

Dave de Jonge that makes use of the NB

algorithm as

well as a complex strategical module to ﬁnd the best

sets of moves to negotiate and play. This agent uses

a basic form of opponent modeling by using the util-

ity values of deals previously proposed and accepted

by its opponents as a way to direct the search for bet-

ter solutions; however, it does not make an attempt

to explicitly predict an opponent’s goals or strategies.

Another aspect that this agent lacks is the ability to

negotiate coalitions with other agents as well as joint

moves for future phases of the game, having no nego-

tiation strategy for these kinds of deals.

Finally, DipBlue (Ferreira et al., 2015) is a ne-

gotiating agent for Diplomacy inspired by the Israeli

Diplomat architecture. The agent is split into sev-

eral modules called Advisers, that together decide the

actions the agent takes. Each adviser receives move

scores evaluated by previous advisers and alters them

according to its role. The base adviser is inspired

by DumbBot and uses the same scoring heuristic.

This score is then changed by other advisers to pro-

mote support actions for the units, promote actions

that keep agreements with its allies and encourage the

agent to attack players that it distrusts. In order to

model the trust value of each player, DipBlue keeps a

trust matrix that is updated as the game is played. If a

player performs hostile actions against DipBlue, such

as attacking or breaking an agreement, its trust value

diminishes. If a player performs friendly actions, or

refrains from doing hostile actions, its trust value in-

creases. DipBlue is more likely to accept agreements

and help players with which it has a high trust value,

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

108

and attack players with a low trust value. DipBlue

does not have full negotiation capabilities, lacking the

ability to ask and give information or threaten players.

3 ALPHA

This section introduces the proposed Alpha architec-

ture and its modules, which intends to approach sev-

eral of the challenges present in cooperative negoti-

ation games and facilitate the development of agents

for these games.

3.1 Alpha Architecture

We propose a generic architecture that tackles sev-

eral of the issues present in cooperative negotiation

games, allowing for the creation of agents capable of

negotiation, trust reasoning and opponent modeling in

a simple way. In order to be used in a variety of games

and environments this architecture is required to be as

generic as possible, making no assumptions about ne-

gotiation protocol, negotiation strategy, player goals,

and search strategy. As such, the proposed archi-

tecture, which we dubbed the Alpha architecture, is

modular and based on the architecture of the Israeli

Diplomat and DipBlue. Figure 1 shows a simpliﬁed

overview of the Alpha architecture.

Like the Israeli Diplomat, it is based on the struc-

ture of a wartime nation, with four different indepen-

dent modules

• The President: in charge of coordinating other

modules and taking the ﬁnal decisions.

• The Strategy Ofﬁce: in charge of suggesting

good strategies to the President.

• The Foreign Ofﬁce: in charge of negotiation.

• The Intelligence Ofﬁce: in charge of predicting

what opponents are likely to do.

This structure allows the architecture to have a

clean separation between the different independent

modules for the different subjects of negotiation, op-

ponent modeling, the strategic and tactical evaluation

of the game and the high level agent personality and

overall strategy. As a result, the user can easily and

effortlessly swap out the modules at will and decide

what capabilities the agent should have, allowing for

great freedom in designing agents. By creating a rela-

tively small quantity of these modules and combining

them in different ways the developer can create a large

These modules can also be seen as agents, making the

Alpha architecture a multi-agent system, as in (Johansson

and H

ard, 2005; Johansson and Olsson, 2005).

Figure 1: High-level diagram of the Alpha architecture and

its modules.

variety of agents with different behaviors and capabil-

ities in a short time.

3.1.1 The President

The President (PR) acts as the central module for the

agent, holding its personality characteristics, coordi-

nating the other modules, deﬁning the overall high

level strategy of the agent through the deﬁnition of its

goals, and being in charge of selecting and executing

the moves for the player.

In order to do this the PR keeps a knowledge base

of everything it needs to know about the environment

and its opponents. This knowledge base is then also

used and modiﬁed by the remaining three modules,

allowing the PR to make the best decisions possible

with up-to-date useful information regarding the en-

vironment. The information contained in the knowl-

edge base is the following:

• The current state of the game.

• The moves played during the course of the game

by each player.

• The current player goals for the game and their

importance.

• The lists of deals conﬁrmed, completed and pro-

posed by itself and other players over the course

of the game.

A Generic Agent Architecture for Cooperative Multi-agent Games

109

• The player’s current disposition towards other

players, such as who are its allies and enemies.

• The opponent models for each other player.

• The general trustworthiness levels of each player.

• The trustworthiness levels of each deal.

Additionally, the PR also has a set of personality

traits that can be deﬁned depending on the game be-

ing played. These govern the general strategy of the

PR, such as how aggressive it is, how trusting of other

players it is or how prone to taking risks it is. Finally,

the PR also keeps lists of moves and deals suggested

by the other modules, which the PR can then choose

to execute depending of several factors.

When deﬁning the PR module the developer must

deﬁne what constitutes a deal, a move and a goal be-

cause these are game-speciﬁc concepts that are difﬁ-

cult to generalize. Different games (such as Diplo-

macy and Werewolves of Miller’s Hollow) have very

different possibilities for what moves and deals a

player can make. These deﬁnitions specify the game-

speciﬁc elements that are stored in the knowledge

base and used by all modules.

One important role of the President is deciding

what overall goals the agent is striving for and the

relative importance to attribute to each goal. This in-

formation is then used to inform the behavior of other

modules, such as what moves are suggested by the

Strategy Ofﬁce or what deals are accepted by the For-

eign Ofﬁce. This allows the PR to dictate the over-

all strategy it wants to follow to its subordinate mod-

ules, allowing them to focus on the individual details

of what actions are more likely to result in attaining

these goals.

Different PR modules allow the developer to cus-

tomize the agent’s general strategy and personality al-

lowing for different player archetypes (Ferreira et al.,

2015).

3.1.2 The Strategy Ofﬁce

The Strategy Ofﬁce (SO) has the purpose of analyzing

the strategical situation of the game and suggesting

good moves to the PR. It contains most of the game-

speciﬁc heuristics, evaluating the utility of possible

moves and deals, and as such is highly dependent and

adapted to the speciﬁc game being played. In addi-

tion, the SO also deﬁnes the search strategy used to

explore the space of different moves.

This module is generally separated into two parts:

the search strategy used when looking for moves to

analyze and the evaluation function used for calculat-

ing the utility value of moves and deals. While the

search strategy used can generally be applied to dif-

ferent environments relatively easily, the tactical eval-

uation is, in general, entirely dependent on the game

being played, as it relies on speciﬁc knowledge about

the game’s rules in order to calculate what constitute

good moves.

In order to ﬁnd the best moves, the SO has ac-

cess to the PR’s knowledge base, being able to make

use of the information contained there to evaluate the

utility of different moves and deals. When the PR re-

quests move suggestions, the SO ﬁnds good moves

and suggests them back to the PR, who stores them in

its internal list.

Swapping the Strategic Ofﬁce allows a devel-

oper the choice among different search strategies and

heuristics for the game, which can have a major im-

pact on a player’s effectiveness.

3.1.3 The Foreign Ofﬁce

The Foreign Ofﬁce (FO) has the purpose of manag-

ing any interaction with other players and negotiat-

ing deals and coalitions in a way that best allows the

PR to execute the moves it is considering in order

to fulﬁll its goals. When the PR requests the FO to

negotiate with other players, it sends a list of which

moves it is considering, for which the FO should at-

tempt to ﬁnd supporting deals. Using this information

as well as any other information available in the PR’s

knowledge base that the FO ﬁnds useful, this module

then autonomously communicates with other players

and decides what deals to propose, reject and accept.

When a deal is proposed, conﬁrmed or completed the

FO informs the PR so that it can add these deals to the

appropriate lists in the Knowledge Base.

The negotiation strategy used is deﬁned in this

module and determines what deals are proposed and

accepted and what concessions the agent is willing to

make. This module also deﬁnes the negotiation proto-

col used by the agent when communicating with other

players. The decision of what protocol to use is of-

ten dependent on the game being played or even the

speciﬁc development framework on top of which the

agent is being implemented.

Swapping the FO allows a developer to customize

the negotiation capabilities of the agent, allowing the

use of different negotiation and concession strategies,

or even removing the FO altogether for an agent with

no negotiation capabilities.

3.1.4 The Intelligence Ofﬁce

The Intelligence Ofﬁce (IO) is in charge of calculating

the trust values and opponent models for the different

players in the game.

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

110

This module is divided into two parts: the op-

ponent modeling function and the trust reasoning

function. The opponent modeling function outputs

the predicted goals and their relative importance for

each opponent, to be updated in the PR’s knowledge

base. How this is done is often speciﬁc to each game

since the goals themselves as well as the actions and

deals being analyzed are also speciﬁc to each game.

The trust reasoning function is similar, outputting the

trustworthiness values both for each opponent as well

as for each individual deal, depending on how likely

they are to be kept.

Different IOs can allow the developer to cus-

tomize the opponent modeling and trust reasoning

strategies, or lack thereof, of an agent. This module

is especially useful in conjunction with the FO, since

negotiations are likely to beneﬁt from a good oppo-

nent model and accurate trust reasoning.

3.2 Alpha Framework

In order to simplify the application of the Alpha archi-

tecture, we developed a framework composed of sev-

eral abstract classes which represent the modules and

behavior described. These classes deﬁne what each

module should do as well as the data available and

how it is updated and communicated to and by each

of the modules. Each module is deﬁned in its own

class and implements a speciﬁc interface.

In practice all a developer has to do to create an

agent for a given domain is to implement the abstract

classes of the modules he wishes to use. When imple-

menting the modules, the developer must implement

their abstract methods in order to deﬁne the domain

speciﬁc negotiation strategies, protocols, heuristics,

models and message handling. The data produced

by the different modules is automatically updated and

available for use by all modules for their calculations.

Additionally, the developer must also implement

the data classes with the domain speciﬁc deﬁnitions

of what a move, a deal, a goal and an opponent are.

The different modules can then be attached to the PR,

so that an agent can be instantiated to play the game.

4 THE ALPHA ARCHITECTURE

IN PRACTICE

In this section we describe the details of the imple-

mentation of two different agents using the proposed

Alpha architecture, for two very different coopera-

tive negotiation games: Diplomacy and Werewolves

of Miller’s Hollow. These two games were chosen as

a proof of concept to test the Alpha architecture due to

the very different characteristics and challenges they

offer as well as the wide breadth of existing work for

the game Diplomacy.

4.1 AlphaDip

AlphaDip is a Diplomacy playing agent heavily based

on D-Brane, using a modiﬁed version of its strategic

module as well as the NB

algorithm to search for

the best moves. It has a few key improvements com-

pared with D-Brane, the most notable ones being an

improved strategic module, a deﬁned strategy for ne-

gotiating coalitions and some ability to predict its op-

ponents’ goals and trustworthiness.

In the context of AlphaDip, a move is considered a

set of orders, one for each unit the player controls, as

well as possible supporting orders from other players

that may be necessary. The representation of player

goals is relatively simple. Since in Diplomacy, the

goal of the game is to capture as many supply cen-

ters as possible to win the game, a player’s goals are

simply a measure of how much they want to control

a certain supply center at the moment. This is repre-

sented by a positive real number, where 0 means no

intention to control a supply center, 1 means neutral

intention to control a supply center and values above

that meaning greater intentions of controlling a supply

center. On the other hand,the trust values for players

stored by the PR are positive real numbers that are

inversely proportional to the trustworthiness of these

players. This means that 0 represents full trust in a

player, 1 represents neutral trust and values above that

meaning lower levels of trust in a player.

When a round starts the PR ﬁrst asks the SO for a

fallback move that is expected to work even without

any supporting deals with other players or any kind of

negotiation. This move will be used by the PR in the

eventuality that all negotiations fail, or in the absence

of a FO. The PR then asks periodically the SO, who

continually searches for the best moves, for suggested

moves to consider.

AlphaDip’s SO tries to ﬁnd moves that maximize

the number of controlled supply centers by the player,

and is based on D-Brane’s strategic module and the

algorithm. The objective of the game is to take

control of as many supply centers as possible. As

such, one way of determining the utility of a move

is simply the number of supply centers that are en-

sured to be controlled by a player when it plays that

move. This is the method used by D-Brane to calcu-

late the utility of a move. AlphaDip calculates utility

in a similar way, but introduces trust reasoning and

the prediction of opponent goals in order to attempt

to obtain a more accurate value than D-Brane. While

A Generic Agent Architecture for Cooperative Multi-agent Games

111

D-Brane attributes the same score of 1 to every sup-

ply center, AlphaDip uses the player goals to inﬂu-

ence the value of each supply center. Additionally, if

a move requires supporting orders from other players

to succeed, their trust values are taken into account

when determining the utility value. This is so that SO

suggests moves that are likely to be easy for the FO to

obtain any necessary supporting move commitments

from other players. Equation 1 shows how the SO

determines the utility of a move.

(m) =

∑

i=1

(i) × g

(i)

(m)

(1)

Where U

(m) is the utility value of move m for

player p, n is the total number of supply centers, I

is a function where for each supply center it returns

1 if that supply center is sure to be controlled after

move m and 0 if not, g

is the goal value that player p

has or is assumed to have for each supply center, and

is the average trust that player p has on all other

players involved in the move or 1 if no other players

are involved.

The suggested moves may include order commit-

ments by other players in order to be feasible and so

the PR passes the current best move it is consider-

ing on to the FO for it to negotiate any possible sup-

port deals. AlphaDip’s FO performs two types of ne-

gotiation: coalition establishment with other players

and order commitments for the current round. This

is an improvement on D-Brane, which did not have

a strategy for the establishment of coalitions, instead

assuming that all D-Branes simply formed a coalition

against all other players in the game. Currently, Al-

phaDip is not able to negotiate move commitments

for the following rounds as that would increase the

complexity of the agent tremendously.

The strategy employed to negotiate coalitions is

similar to the strategy used by DipBlue. Like Dip-

Blue, at the start of the game AlphaDip proposes a

peace agreement to every other player in the game.

After that, during the rest of the game the FO attempts

to propose alliances against the stronger player in the

game with which it is not in peace with. If a player’s

trust value rises above a certain threshold (meaning

the player is less trusted) the peace with that player

is broken. Conversely, if the trust value drops be-

low a certain level (meaning the player is trusted) Al-

phaDip proposes peace to this player. Additionally,

if the game has 4 or less players remaining AlphaDip

immediately breaks any alliances it has with a player

if that player controls 14 or more supply centers. This

is so that AlphaDip does not let a player get too close

to winning in the ﬁnal stages of the game.

The FO also attempts to negotiate joint order com-

mitments for the current round. The PR periodically

asks the FO to negotiate deals concerning the moves

being currently considered by the PR. Each time this

happens, the FO compares the utility of the suggested

moves with the utility of each of the proposals it re-

ceived and either accepts the best proposal received

if it has more utility, or proposes any necessary joint

order commitments required by the moves proposed

by the PR.

If the FO receives a proposal from another player

and it is compatible with any deals it has already ac-

cepted, it asks the SO to calculate the utility of that

deal, and informs the President for it to store it in the

proposed deals list of the knowledge base for later

consideration. The reason it does not choose to im-

mediately accept or reject the proposal, as explained

in (de Jonge, 2015), is so that the SO is given some

time to continue searching and looking for any pos-

sibly better options for other joint moves, before the

agent commits to the proposed orders. By commit-

ting to an offer and adding it to the PR’s conﬁrmed

deals list, the search performed by the SO is automat-

ically constrained to only look for moves that satisfy

the conditions in the accepted deals.

Finally, after a certain negotiation deadline has

passed and depending on whether the FO managed

to negotiate any supporting moves deemed necessary,

the PR picks the best move suggested to it that has a

chance to succeed.

AlphaDip may also use the IO to calculate trust

values for players and predict their current goals in

the game. In order to update the trust values, the

IO uses a strategy similar to DipBlue (Ferreira et al.,

2015), where trust in players increases steadily over

the course of the game if no aggressive actions are

taken by these players and decreases when aggressive

actions are taken. The amounts by which the trust

score increases and decreases are dependent on the

current trust value the players have, as well as whether

AlphaDip considers himself to be at peace or at war

with these players. This way, if a player is highly

trusted or in peace with AlphaDip, any aggressive ac-

tions it takes will have a bigger impact on that player’s

trust. On the other hand, if a player is not trusted or is

at war with AlphaDip, any aggressive actions it takes

have a smaller impact on that player’s trust, since Al-

phaDip already expects that player to take aggressive

actions.

The IO also attempts to predict its opponent’s

goals, that is, which supply centers it believes each

player wants to control more, using a simple strategy

exempliﬁed in Algorithm 1. Each time a player takes

an offensive action against a certain supply center, the

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

112

IO increases the likelihood that that player wants to

control that supply center (line 9 in algorithm 1). If

a player takes no offensive actions against a supply

center, or takes actions that would help another player

capture that supply center such as support orders, the

IO decreases the likelihood that the player wants to

control that supply center (lines 5 and 12). Like the

trust values, these increases and decreases are depen-

dent on the current values for each supply center. That

way if a player is already expected to want control of a

certain supply center any actions it takes have a small

impact on the value for that supply center. On the

other hand, if a player suddenly makes a move on a

supply center that AlphaDip believed that player was

not interested in, the value for that supply center will

be affected more signiﬁcantly.

Algorithm 1: AlphaDip IO Goal Prediction Algorithm.

1: playerOpponents ← getOpponentsFromPR()

2: opponentGoals ← getOpponentGoalsFromPR()

3: for all op ∈ playerOpponents do

4: for all g ∈ opponentGoals[op] do

5: g ← g × 0.99

6: forActions ← getActionsSupportingGoal(op,g)

7: againstActions ← getActionsAgainstGoal(op,g)

8: for all o ∈ forActions do

9: g ← g +

0.04

10: end for

11: for all o ∈ againstActions do

12: g ← g × 0.95

13: end for

14: end for

15: end for

16: return opponentGoals

4.2 AlphaWolf

Werewolves of Miller’s Hollow was the second game

chosen to test the implementation of the Alpha ar-

chitecture. As there are, to the best of our knowl-

edge, no available frameworks for the development of

Werewolves of Miller’s Hollow agents, we have im-

plemented our own server using the JADE multi-agent

framework. We then implemented an agent capable of

communicating with this server and playing the game,

which we nicknamed AlphaWolf.

In order to simplify the implementation, and be-

cause certain roles are more suited to be played phys-

ically with humans, we use a simpliﬁed version of the

game with a subset of the available player roles and

abilities. In our version of the game there are 4 possi-

ble roles for the players: werewolves, villagers, seers

and doctors. Werewolves have the goal of killing

every other non-werewolf player in the game while

every other player has the goal of killing the were-

wolves. The werewolves, seers and doctors each have

a special ability that they can secretly perform during

the night phase of the game. Werewolves can col-

lectively vote on an enemy player to kill during the

night. The seers can choose any player to investigate

during the night, learning its secret role. Finally, the

doctors are able to choose a player, who if attacked by

the werewolves during the night will be healed and re-

main in the game, informing the doctor that this hap-

pened.

The AlphaWolf’s PR works much the same as de-

scribed in Section 3. At the start of each phase of

the game it requests the IO to update it’s opponents’

trust values and predicted goals. In the context of this

game a player’s goal is tied to its role and as such pre-

dicting a player’s goal means predicting the likeliness

that a player has a certain role. In the PR’s knowl-

edge base this means that each player is attributed

a role certainty for each role, from 0 to 100%. The

sum of all role certainties totals 100%, so that if a cer-

tain role has a certainty of 100%, the PR knows that

player’s role and consequently, its goals. A player’s

trust is represented by a positive real number, where 1

means neutral trustworthiness, 0 means no trustwor-

thiness and values above 1 mean progressively higher

trustworthiness.

Afterwards, the PR requests the SO to suggest a

good move. What constitutes a move in this context

is dependent on the current phase of the game but it

always involves choosing a player, to either vote out

of the game or as a target for the player’s ability dur-

ing the night phase. After a player is suggested by the

SO, and depending on whether the current phase of

the game allows negotiation between the players, the

PR may ask the FO to attempt to negotiate with the

other players for joint votes against some player or re-

quests for investigation or healing. When the FO has

ﬁnished negotiating, the PR decides to either vote or

target a certain player for its special action. If no deal

has been reached the player is randomly chosen from

the list of players suggested by the SO, with players

with higher utility being more likely to be picked, oth-

erwise if a deal has been reached for a different player,

the PR will take the action it agreed to on the deal.

The SO implements a simple strategy to suggest

good potential players to either attempt to eliminate or

protect, depending on the current phase of the game

and the player’s role and goals. The way it does this

is by attributing to each player a threat score, which

is a measure of what roles and goals the player be-

lieves an opponent to have (calculated by the IO) and

how dangerous these roles are to the player. In gen-

eral terms, if a player is on the werewolf faction, roles

that have the ability to gather more information or use

abilities that hinder the werewolves’ actions will have

A Generic Agent Architecture for Cooperative Multi-agent Games

113

a higher threat level to the player. In the same way, if

a player is on the villager faction, roles that have the

ability to gather more information or hinder the were-

wolves are less likely try to kill the player, and thus

are less threatening. Then depending on the current

phase of the game and whether the actions available

to the player will hinder an opponent, such as voting

to kill it, or help another player, such as healing it, ei-

ther this threat score is used as the utility for the move

or its inverse is used, respectively.

Equation 2 shows how the threat value of a player

is calculated.

∑

i=1

×C

∑

i=1

(2)

Where T

is player p’s threat value, n is the num-

ber of different possible roles a player can be, B

the base threat value for role i and C

is the current

certainty that player p has role i.

The SO also has the purpose of calculating the

utility of deal proposals. This utility is based on the

previously mentioned threat value of the proposer of

the deal, the threat value of the player whom the deal

concerns, what type of action the deal is proposing

and the trust of the player in the proposer of the deal.

This calculation is described in Algorithm 2. The type

of action proposed and the threat values for the pro-

poser and the player affected by the proposal are used

to calculate two values, one for the proposer and one

for the target of the proposed action, representing how

much the player is willing to help the proposer and

hurt the target. These two values are then multiplied

together with the trust on the proposer, representing

how much the player trusts the proposer to abide by

the deal and not take any actions against him, to reach

the ﬁnal utility value for the deal (line 9).

Algorithm 2: AlphaWolf SO Deal Utility Calculation.

1: target ← getTargetFromDeal()

2: proposer ← getProposerFromDeal()

3: proposerValue ←

getT hreatValue(proposer)

4: if dealActionIsPositive() then

5: targetValue ←

getT hreatValue(target)

6: else

7: targetValue ← getThreatValue(target)

8: end if

9: return targetValue × proposerValue × getTrust-

FromPR(proposer)

In Werewolves of Miller’s Hollow the players can

only communicate during certain phases of the game,

namely the discussion phase and, for werewolves, the

night phase. As the game is very reliant on communi-

cation between players negotiation is very important

in order to obtain effective players. Otherwise play-

ers would not be able to coordinate their votes or use

their abilities during the night. This is the purpose of

the FO.

AlphaWolf’s FO implements a simple negotia-

tion strategy where each player proposes a joint vote

against another player who they think is the most

threatening, as well as other agreements such as in-

vestigation or heal requests depending on their lev-

els of trust with other players. Players then await for

conﬁrmations from their opponents that they’ll follow

the agreement, locking the agreement in place if they

receive a conﬁrmation. Each negotiation round play-

ers compare the utility of the proposals they received

with their concession value, which is based on their

own proposal and decreases over time, and decide ei-

ther to continue waiting or accept another proposal,

retracting their own.

AlphaWolf’s IO has the function of attempting to

predict a player’s goals and its trustworthiness. As de-

scribed previously, since a player’s goals are tied to its

role in the game predicting its goals is a matter of pre-

dicting its role. In order to predict an opponent’s role

the IO analyses the proposals and votes of that player

over the course of the game. The predicted role cer-

tainties for that opponent are thus a function of the

threat values of the players that that opponent voted

against, or proposed votes against, and the rounds in

which that player took those actions. Algorithm 3 de-

scribes the calculation for the prediction of opponent

goals by the IO.

The IO searches through each player’s past actions

and for each vote or proposal that that player made it

calculates a vote or proposal damage value (line 9 in

algorithm 3). This value indicates the likeliness that

an action was taken with the intent of damaging the

player’s faction and is based on the threat values of

the players who are the targets of that opponent’s ac-

tions. A high threat value for the target of the action

indicates that the action was not very damaging to Al-

phaWolf’s faction, and may have even been helpful,

and a low threat value indicates a damaging action,

as that opponent was voting against players that are

considered likely to be allies.

For each action its vote damage is then used to

calculate a scaling factor for each possible opponent

role (line 10) and that scaling factor is ﬁnally used to

scale the role certainties of each role proportionally

(lines 11-12). The reason each role has a different

scaling factor is because certain roles are more likely

to have more information than others. So seers have

a higher scaling factor than doctors, and doctors have

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

114

a higher scaling factor than villagers. In this way if

an opponent takes a damaging action, the likeliness

that it is a seer diminishes comparatively more than

the likeliness that it is a villager, since a seer would

be less likely to commit damaging actions against the

villagers, having more information about the player

roles. These scaling factors are then multiplied with

each current role certainty, and the values for the roles

are then re-scaled back so that they total 100% (line

14).

To calculate the trust values the IO analyses the

previous round and checks for each opponent if it kept

any agreements it accepted or if it voted against the

player. If an opponent broke an agreement or voted

against the player its trust value is decreased by a cer-

tain amount, otherwise its trust value increases.

Algorithm 3: AlphaWolf IO Role Prediction Calculation.

1: pastRounds ← getPastRoundsFromPR()

2: opponents ← getOpponentsFromPR()

3: opponentGoals ← getOpponentGoalsFromPR()

4: for all op ∈ opponents do

5: for all round ∈ pastRounds do

6: roundAgeFactor ← getAgeFactor(round)

7: for all actions ∈ getOpponentActions(op, round)

8: target ← getTarget(action)

9: voteDamage ←

getT hreatValue(target)

getAverageThreatValue()

roundAgeFactor

10: scalingFactors ← calculateRoleScalingFac-

tors(voteDamage)

11: for all r ∈ opponentGoals[op] do

12: r ← r× scalingFactors[r]

13: end for

14: normalizeOpponentGoals(opponentGoals[op])

15: end for

16: end for

17: end for

18: return opponentGoals

5 EXPERIMENTS AND RESULTS

This section describes the methodology and results of

the tests and experiments performed with the agents

implemented using the Alpha architecture.

5.1 AlphaDip Tests Conﬁguration

The tests on AlphaDip were conducted using the

DipGame platform (Fabregues and Sierra, 2011). We

compared AlphaDip with two previously developed

Diplomacy playing agents, DumbBot and DipBlue

These were chosen mainly for their availability in the

DipGame platform.

In order to compare the performance of AlphaDip

with those agents we performed some of the same

tests reported in (Ferreira, 2014) and (de Jonge, 2015)

and compared our results with the results obtained

there. It should be noted that unlike the tests per-

formed using D-Brane in (de Jonge, 2015), which as-

sumed that the D-Branes always formed a coalition

against every other agent in the game, we allow our

agents to negotiate at will, establishing and breaking

coalitions.

In each of the experiments, we tested AlphaDip

using 3 distinct conﬁgurations, in order to separately

test the impact of negotiation and opponent and trust

modeling in its performance. The conﬁgurations used

were: an agent using only the PR and SO, an agent

adding to this the FO and, ﬁnally, an agent using all 4

modules: PR, SO, FO and IO.

For every conﬁguration, in each experiment we

played a number of games of Diplomacy, stopping af-

ter 40 game phases. After a game had ﬁnished we

ordered the players by ranking, from 1st to 7th, and

collected the ranking results. Ranking is determined

by the number of supply centers that a player con-

trolled at the end of the game if that player was alive,

or by the game phase in which that player was elim-

inated otherwise. Players with more supply centers

or that were eliminated later than other players have a

higher rank in the game and are thus considered bet-

ter. For conﬁgurations without the FO (and thus, with

no negotiation capabilities) we played a total of 100

games. For conﬁgurations having the FO we set the

negotiation deadline at 15 seconds per round. Since

these tests take considerably longer to execute we

only played a total of 50 games per conﬁguration in

these cases.

All tests and experiments were performed in a lap-

top computer with 8GB of RAM and an Intel Core

i5-6440HQ mobile CPU clocked at 3.5GHz.

5.2 AlphaDip Results

Like in Ferreira’s (Ferreira, 2014) and de

Jonge’s (de Jonge, 2015) works, who had two

instances of their agents play against 5 DumbBots,

we had two instances of AlphaDip play against 5

instances of DumbBot. Since we have two agents

playing in each game, the best possible average rank

for our agent in these tests is 1.5, while the worst

possible average rank is 6.5. By comparing the

average ranks of AlphaDip with the average ranks

of DipBlue and D-Brane we can determine how

well each agent performs comparatively against the

DumbBot. The best rank achieved by DipBlue in the

tests performed by Ferreira is 3.57 (Ferreira, 2014),

A Generic Agent Architecture for Cooperative Multi-agent Games

115

Table 1: The average rank of 2 AlphaDips when playing

with 5 DumbBots.

AlphaDip Conﬁg. Avg Rank

PR + SO 2.35 ± 0.15

PR + SO + FO 2.21 ± 0.21

PR + SO + FO + IO 2.11 ± 0.19

while the best rank obtained by D-Brane in the tests

performed by De Jonge is 2.35 (de Jonge, 2015).

Table 1 shows the average rank obtained by Al-

phaDip in each conﬁguration and their standard de-

viations. These results show that AlphaDip plays

signiﬁcantly better than the DumbBot and DipBlue,

even without having negotiation, opponent modeling

or trust modeling. However it also appears that the

inclusion of the IO and the FO only has a small effect

on the performance of the agent. A t-test performed

on the data from these tests obtains a value of 0.554

when comparing the results of the second test with

the last test, and a value of 0.109 when comparing

the ﬁrst test with the last. This second value indicates

that the difference in the second case appears to be

statistically signiﬁcant, though further testing would

be required to conﬁrm the signiﬁcance of the increase

in performance of the AlphaDips with all modules ac-

tive compared to those having just the PR and SO.

In order to complement the previous experiments

we also tested AlphaDip in an environment with a

higher number of negotiating agents, having 2 Al-

phaDips play with 2 DipBlues and 3 DumbBots. The

2 DipBlues played with the standard adviser conﬁg-

uration described in (Ferreira, 2014) in all tests. The

results for this experiment are shown in Table 2.

These results show that when the AlphaDips are

playing with just the PR and SO or with all modules

running they get a similar average rank between 2.3

and 2.4. A statistical t-test performed using the data

from these tests gives us a value of approximately

0.653, which shows that the difference observed is not

statistically signiﬁcant. This indicates that the inclu-

sion of negotiation and trust reasoning does not sig-

niﬁcantly affect the performance of the AlphaDips.

One exception is when they play with the FO but

without the IO, meaning that they negotiate without

making any attempt to predict their opponent’s goals

or trustworthiness, where their average ranking de-

creases signiﬁcantly to 3.56.

This lack of impact from negotiation is similar to

the results obtained by De Jonge in (de Jonge, 2015),

where he concludes that even though the NB

algo-

rithm manages to ﬁnd good joint moves for the play-

ers when they exist, the impact of these in the overall

result of the game is negligible. As such, negotiating

joint moves only for the current round is not enough

Table 2: The average rank of 2 AlphaDips when playing

with 2 DipBlues and 3 DumbBots.

AlphaDip Conﬁg. AlphaDips DipBlues

PR + SO 2.38 ± 0.16 5.03 ± 0.20

PR + SO + FO 3.56 ± 0.26 3.44 ± 0.32

PR + SO + FO + IO 2.3 ± 0.22 4.73 ± 0.29

to signiﬁcantly increase the performance of the play-

ers – in order to obtain better results one would have

to attempt to negotiate further rounds ahead as well.

An interesting observation is that when playing

with the DipBlues, while the AlphaDips do obtain a

small increase in their average rank when all modules

are running compared to having just the PR and SO,

the DipBlues themselves are also beneﬁted. The Dip-

Blues obtain a better average ranking of 4.73 when

playing with the AlphaDips with all modules active,

compared with an average ranking of 5.03 when play-

ing with AlphaDips incapable of negotiation. These

observations were also corroborated by De Jonge’s

observations in (de Jonge, 2015), where he found that

other agents could also beneﬁt from the deals discov-

ered by agents running the NB

search algorithm.

5.3 AlphaWolf Tests Conﬁguration

Tests were also run using the Werewolves of Miller’s

Hollow playing agent, AlphaWolf. Unfortunately,

due to the lack of any comparable agents developed

for this game, we were only able to test the relative

performance of our agent with different conﬁgura-

tions of active modules.

In order to test the effect of the different modules

on the performance of the agents we opted to have the

werewolves always playing with all modules running,

and changed only the conﬁgurations of any villager

agents in the different tests. This way we can eas-

ily see the effect that each module has on the perfor-

mance of the villagers. We tested 3 different conﬁg-

urations for this agent, just like with AlphaDip: just

the PR and the SO, all modules except the IO and all

modules active.

In each test we had the agents play 100 games

in a 10 player game where 2 of the players were

werewolves, and the remaining 8 were from the vil-

lager faction, with 1 seer, 1 doctor and the remain-

ing 6 being standard villagers. This ratio of were-

wolf players to villager players was chosen because it

is the recommended ratio for werewolves to villagers

in the ofﬁcial Werewolves of Miller’s Hollow rules.

We recorded the win percentage for the villagers over

those games as well as the average number of villager

agents left alive at the end of the game when the vil-

lager faction won.

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

116

Table 3: The win percentages and average number of re-

maining villagers for a team of 8 villagers playing against 2

werewolves.

Villagers Conﬁg. Win % Avg # Villagers

PR + SO 27% 3.56

PR + SO + FO 46% 3.20

PR + SO + FO + IO 73% 4.88

5.4 AlphaWolf Results

Unlike with Diplomacy, the results for the AlphaWolf

agents, shown in Table 3, show that negotiation, trust

modeling and opponent modeling have a signiﬁcant

impact on the effectiveness of the agents. With the

inclusion of the FO and the IO the performance of the

agents steadily increases from a 27% win ratio to a

46% win ratio, and ﬁnally a 73% win ratio with all

modules active. The inclusion of the IO also signif-

icantly increases the number of villagers remaining

alive in games where the villagers win. This means

that with the inclusion of trust and opponent modeling

the players are able to identify the werewolves much

earlier in the game, allowing for quicker victories.

One possible explanation for the difference in the

relative impact of negotiation, trust and opponent

modeling in the game of Werewolves of Miller’s Hol-

low compared with Diplomacy is that in the latter

the agents already implicitly have an idea of their

opponent’s goals. Since in Diplomacy the rules of

the game encourage players to capture supply cen-

ters, players can already play with the assumption that

other players will try to maximize their number of

supply centers over the course of the game. On the

other hand, in the game of Werewolves of Miller’s

Hollow players have no way to know at the start of

the game what their opponents will be trying to do.

This means that players have no way to predict an op-

ponent’s utility function at the start of the game, and

must analyze a player’s actions in order to predict it.

Negotiation may also have a greater impact in

Werewolves of Miller’s Hollow because each player

only has a single vote to affect the round. Without

coordination and organizing joint votes, players have

a hard time completing their goals. In Diplomacy

players can have differing numbers of supply centers

and units, which allows certain players to affect the

outcome of the rounds more than others; this means

strong players can use their superior strength to obtain

their objectives even without negotiation.

6 CONCLUSIONS AND FUTURE

WORK

The objectives of this work were the study of what el-

ements were necessary to create effective agents that

could play cooperative negotiation games, and devel-

opment of a generic architecture that included these

elements that could be used to facilitate the develop-

ment of effective agents for a wide variety of games.

We tested the proposed architecture by developing

agents for two very different cooperative negotiation

games and believe that the proposed Alpha architec-

ture is generic enough to be applied to many other

different games. The two most important agents de-

veloped using the Alpha architecture and framework

were AlphaDip and AlphaWolf. AlphaDip is an agent

with strategies inspired by D-Brane and DipBlue,

with the inclusion of opponent modeling to make pre-

dictions about an opponent’s intention to capture cer-

tain supply centers, as well as a negotiation strategy

for the establishment of coalitions, which was not

present in D-Brane. AlphaWolf is a Werewolves of

Miller’s Hollow agent that also includes negotiation,

trust and opponent modeling capabilities, allowing it

to predict its opponents’ roles and negotiate deals ac-

cordingly.

The results of the tests performed using these two

agents show that AlphaDip was in general superior to

both DipBlue and D-Brane, obtaining better average

ranks in the games played. However, the inclusion of

negotiation, trust reasoning and opponent modeling

capabilities did not have a very large impact on the

performance of the agent. The results obtained for

AlphaWolf show that the inclusion of the Foreign Of-

ﬁce and Intelligence Ofﬁce had a larger impact in the

performance of the agent. This indicates that negotia-

tion, trust and opponent modeling are more important

in Werewolves of Miller’s Hollow than in Diplomacy.

We believe that these results are positive and the

inclusion of negotiation, trust reasoning and opponent

modeling capabilities generally improved the perfor-

mance of the agents, though the impact was much

greater for AlphaWolf than for AlphaDip. We also be-

lieve that the developed architecture and framework

are a helpful contribution to the ﬁeld by facilitating

the development of agents with these capabilities.

However, while the developed architecture is very

modular and allows agents to be built upon it and

make use of negotiation, trust and opponent model-

ing, there is still room for improvement. The Al-

pha architecture allows developers to deﬁne the dif-

ferent strategies for negotiation, trust reasoning and

opponent modeling that they want to use depending

on the speciﬁc game, such as D-Brane’s NB

algo-

A Generic Agent Architecture for Cooperative Multi-agent Games

117

rithm. However, this process can be made simpler

by the inclusion of generic strategies that can be ap-

plied equally to any environment. The inclusion of a

generic way to predict opponent goals and strategies,

calculate trust values and decide what deals to accept,

based on the knowledge base of the President, would

simplify the process of developing an efﬁcient agent

even more.

An even larger step in obtaining a truly generic

system would be the inclusion of some form of ab-

stract understanding about the rules of the game being

played and the board state, which could be deﬁned by

the developer using a formal language such as the one

used in the Zillions Of Games software (Corporation,

2016) or in the General Game Playing project (Gene-

sereth et al., 2005). With this capability it would be

possible to have a system that could generate agents

able to play and negotiate in many different types of

negotiation games, by simply providing it with a ﬁle

containing an abstract description of the game.

The agents implemented during the course of this

work, while generally efﬁcient, could also be im-

proved. One major improvement to AlphaDip could

be to allow the agent to search for and negotiate move-

ment commitments for several rounds ahead instead

of only the current round. In the case of AlphaWolf

and the Werewolves of Miller’s Hollow server imple-

mented, a key improvement would be the capability

for AlphaWolf to use strategies involving blufﬁng, by

for example making opponents believe it has a differ-

ent role than its true role, a strategy human players

frequently use in the game. If correctly implemented,

this ability could make AlphaWolf much more effec-

tive, especially when playing with human opponents.

ACKNOWLEDGEMENTS

We wish to thank Andr

e Ferreira and Dave de Jonge

for their previous work in this area, upon which our

work is based, as well as always being available to

talk and help whenever we needed.

REFERENCES

Calhamer, A. B. (2000). The Rules of Diplomacy. Avalon

Hill, 4th edition.

Corporation, Z. D. (2016). Zillions of Games.

http://www.zillions-of-games.com/. Accessed: 23-11-

2016.

de Jonge, D. (2015). Negotiations over Large Agree-

ment Spaces. Phd thesis, Universitat Auton

oma de

Barcelona.

des Palli

eres, P. and Marly, H. (2009). Werewolves of

Miller’s Hollow: The Village. Lui-m

eme.

Drogoul, A. (1995). When ants play chess (or can strate-

gies emerge from tactical behaviours?). In Castel-

franchi, C. and M

uller, J.-P., editors, From Reaction to

Cognition: 5th European Workshop on Modelling Au-

tonomous Agents in a Multi-Agent World, MAAMAW

’93 Neuch

atel, Switzerland, August 25–27, 1993 Se-

lected Papers, pages 11–27. Springer.

Fabregues, A. and Sierra, C. (2011). DipGame: A challeng-

ing negotiation testbed. Engineering Applications of

Artiﬁcial Intelligence, 24(7):1137–1146.

Ferreira, A. (2014). Dipblue: a diplomacy agent with strate-

gic and trust reasoning. Master thesis, Universidade

do Porto.

Ferreira, A., Lopes Cardoso, H., and Reis, L. P. (2015).

Strategic negotiation and trust in diplomacy – the dip-

blue approach. In Nguyen, N. T., Kowalczyk, R., Du-

val, B., van den Herik, J., Loiseau, S., and Filipe, J.,

editors, Transactions on Computational Collective In-

telligence XX, pages 179–200. Springer International

Publishing, Cham.

Genesereth, M., Love, N., and Pell, B. (2005). General

Game Playing: Overview of the AAAI Competition.

AI Magazine, 26(2):62–72.

Heinrich, J. and Silver, D. (2016). Deep reinforce-

ment learning from self-play in imperfect-information

games. In Proceedings of the Third Deep Reinforce-

ment Learning Workshop, NIPS-DRL.

Johansson, S. and Olsson, F. (2005). Mars – a multi-agent

system playing risk. In Proceedings of Paciﬁc Rim

International Workshop on Multi-agents (PRIMA).

Johansson, S. J. and H

ard, F. (2005). Tactical Coordina-

tion in No-press Diplomacy. In Proceedings of the

Fourth International Joint Conference on Autonomous

Agents and Multiagent Systems, AAMAS ’05, pages

423–430, New York, NY, USA. ACM.

Kraus, S., Gan, R., and Lehmann, D. (1995). Designing and

Building a Negotiating Automated Agent. Computa-

tional Intelligence, 11(972):132–171.

Kraus, S., Lehmann, D., and Ephrati, E. (1989). An auto-

mated diplomacy player. In Levy, D. and Beal, D.,

editors, Heuristic Programming in Artiﬁcial Intelli-

gence: The 1st Computer Olympiad, pages 136–153.

Ellis Horwood Limited, Chinester, UK.

Nash, J. (1951). Non-Cooperative Games. The Annals of

Mathematics, 54(2):286–295.

Norman, D. (2013). David Norman’s DumbBot.

http://www.daide.org.uk/index.php?title=DumbBot

Algorithm. Accessed: 12-07-2013.

Silver, D., Huang, A., Maddison, C. J., Guez, A., Sifre, L.,

van den Driessche, G., Schrittwieser, J., Antonoglou,

I., Panneershelvam, V., Lanctot, M., Dieleman, S.,

Grewe, D., Nham, J., Kalchbrenner, N., Sutskever, I.,

Lillicrap, T., Leach, M., Kavukcuoglu, K., Graepel,

T., and Hassabis, D. (2016). Mastering the game of

go with deep neural networks and tree search. Nature,

529:484–503.

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

118
