Combining Machine Learning with a Genetic Algorithm to Find Good

Complier Optimizations Sequences

Nilton Luiz Queiroz Junior, Luis Gustavo Araujo Rodriguez and Anderson Faustino da Silva

Department of Informatics, State University of Maring´a, Maring´a, Brazil

Keywords:

Optimization Selection Problem, Machine Learning, Genetic Algorithms.

Abstract:

Artiﬁcial Intelligence is a strategy applied in several problems in computer science. One of them is to ﬁnd

good compilers optimizations sequences for programs. Currently, strategies such as Genetic Algorithms and

Machine Learning have been used to solve it. This article propose an approach that combines both, Machine

Learning and Genetic Algorithms, to solve this problem. The obtained results indicate that the proposed

approach achieves performance up to 3.472% over Genetic Algorithms and 4.94% over Machine Learning.

1 INTRODUCTION

Artiﬁcial intelligence is applied in several prob-

lems, like scheduling problems (Ansari and Bakar,

2014), natural language processing (Tambouratzis,

2016), estimate good compilers optimizations se-

quences (Martins et al., 2016).

Compilers are programs capable of transforming

source code to a target code, in a process that is di-

vided into several stages. A critical step in this pro-

cess is to apply a compiler optimization sequence

(transformations in the code) to improve the quality

of the target code (Aho et al., 2006).

Modern compilers such as (

GCC

ICC

and

LLVM

)

provide standard compiler optimization levels (

), which can be used to optimize the source

code. However, speciﬁc levels are only appropriate

for particular programs. This is because of the se-

lection process for the optimizations that will be ap-

plied to a speciﬁc program, becoming into a program-

dependent problem.

Artiﬁcial intelligence techniques are the most

common in chose compilers optimizations for spe-

ciﬁc programs (Park et al., 2012; Zhou and Lin,

2012; Jantz and Kulkarni, 2013b; Jantz and Kulkarni,

2013a; Lima et al., 2013; Junior and da Silva, 2015).

The Artiﬁcial intelligence approaches to select com-

piler optimizations can be divided in two: Iterative

Compilation and Machine Leaning.

Iterative Compilation (

) evaluates the quality of

the target code generated by different sequences, and

returns the best target code. These approaches can use

search methods, like Genetic Algorithms, and take

much time to converge to good solutions.

On the other hand, Machine Learning (

) ap-

proaches attempt, from previously-successful compi-

lations, to predict sequences that will have a good

performance in new programs. These methods, in

general, are faster than iterative compilation, but,

they usually have worse results (Jantz and Kulkarni,

2013b).

It is worth mentioning that ﬁnding the best com-

piler optimization sequence for a particular program

is an undecidable problem, due to the size of the

search space (quantity of optimizations provided by

the compiler and possible combinations).

This article describes a hybrid approach, that com-

bines the best of

and

, to mitigate the optimiza-

tion selection problem (

OSP

). The objective is to de-

scribe an approach that initially uses

to select po-

tential optimization sequences, considering the char-

acteristics of the test program, and then applies

adapt the potential optimization sequences to the test

program. Thus, it is expected that adapting a solution

will improve the performance instead of only using

potential sequences.

The results indicate that the hybrid approach out-

performs both

and

in terms of balancing perfor-

mance (speedup x number of evaluated sequences).

Furthermore, the average speedup achievedby the hy-

brid approach is superior when comparing it to the

best compiler optimization level of

LLVM

Junior, N., Rodriguez, L. and Silva, A.

Combining Machine Learning with a Genetic Algor ithm to Find Good Complier Optimizations Sequences.

DOI: 10.5220/0006270403970404

In Proceedings of the 19th International Conference on Enterprise Information Systems (ICEIS 2017) - Volume 1, pages 397-404

ISBN: 978-989-758-247-9

397

Model Creator

(ML Algorithm)

Base Filter

Base Generator

(Genetic Algorithms)

Training

ML Model

Sequence Predictor

Feature Stractor

Test

Iterative Compilation

Adapter

(Genetic Algorithm)

Best Sequence

Program

Features

Sequences

Program

Features

Sequences

Program

Features

Sequences

Program

Features

Sequences

Knowledge Base

New Source

Code

Figure 1: Mixed Approach Architecture.

2 RELATED WORKS

Zhou and Lin (Zhou and Lin, 2012) employed

, uti-

lizing a genetic algorithm called NSGA-II, to investi-

gate multi-objective compilations. Jantz and Kulka-

rni (Jantz and Kulkarni, 2013a) proposed a strategy to

reduce the search space in order to explore dependen-

cies between the optimizations. These works applied

only

and, thus, the starting point of the solution

did not consider the program characteristics. Further-

more, Jantz and Kulkarni only explored the relation-

ship between the optimizations.

Malik (Malik, 2010) utilized a histogram, con-

structed from the data-ﬂow graph, to establish the

similarity between programs and, thus, select a good

optimization sequence from a database. Malik made

calculations on the histogram and created

models,

utilizing decision-tree algorithms and Support Vector

Machines (

SVM

), to predict a good optimization se-

quence. Park et al. (Park et al., 2012) introduced a

program-characterization model, using a control-ﬂow

graph, and added information about the instructions to

each node. Junior and da Silva (Junior and da Silva,

2015) evaluated the performance of different conﬁg-

urations for case-based reasoning (

CBR

). These works

applied

, without taking into consideration an adap-

tive solution for each program.

Martins et al. (Martins et al., 2016) implemented

an approach that combines clustering with

, result-

ing in a very similar work to the one proposed in this

article. However, both have different strategies to se-

lect the initial optimization sequences. While Martins

et al. utilized a clustering algorithm, this article de-

scribes an approach that applies

SVM

3 THE HYBRID APPROACH

is an appealing option because it achieves better

results than

. On the other hand,

is interesting

because it applies supervised strategies that are ca-

pable of accelerating the convergence to a good so-

lution. This article describes a hybrid approach to

solve the

OSP

, which aims to combine the best of both

previously-discussed approaches, and can be synthe-

sized as follows.

Suppose there exists a training set (database), con-

taining

good optimization sequences for

pro-

grams. First, the approach creates a model based on

the training set, which is used to predict good opti-

mization sequences for a particular test program. In

the second step, utilizing the created model, the ap-

proach selects

potential optimization sequences for

the test program. Afterwards, the

sequences will

feed a solution adapter,which utilizes a strategy based

to adapt (improve) the solution found in the

phase. Finally, the best target code found by the

adapter is returned to the user and the database is up-

dated with the new knowledge. The Figure 1 illus-

trates the process.

3.1 The Machine Learning Phase

The

phase follows a traditional model, which con-

sists of two stages: training and testing. The training

stage aims to create a database containing good opti-

mization sequences for different programs. In addi-

tion, it provides the model that will be utilized, by the

test phase, to predict potential optimization sequences

for the test program.

Training consists in a database generator that em-

ploys an

strategy. In addition, it creates a

database containing, for each test program, a tuple

with the following information: program features

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

398

and good optimization sequences (sequences that

possess a better performance than the best com-

piler optimization level). This information will be

ﬁltered by the optimization goal (for example ex-

ecution time, code size) and utilized to create a

model that will be applied during the test stage.

This model connects program features with good

optimization sequences, and therefore, it is pos-

sible to predict potential sequences given a deter-

mined set of characteristics.

Test predicts potential optimization sequences for

the test program. First, this step extracts the

characteristics of the test program which are ini-

tially collected to predict potential sequences. Af-

terwards, these characteristics feed the model,

which in turn provide

potential optimization se-

quences. The assumption utilized in

is that

similar programs are those that react similarly

when compiled with the same optimization se-

quences. Therefore, if a model is capable of iden-

tifying similarities between programs, it is possi-

ble to use sequences, found for training programs,

to compile test programs.

3.2 Iterative Compilation Phase

After

potential optimization sequences are selected

in the initial phase, the next step is to adapt these

sequences to the test program. This process is per-

formed through an

strategy.

In various works,

usually begins with the pro-

cess of discovering good sequences randomly or em-

ploying heuristics to selectively investigate the search

space. In addition, these works do not utilize program

features to assist during the search process.

The advantage of a preliminary

phase is that

it provides assistance to guide, based by program fea-

tures, the process of adapting a solution. Thus, it aims

to guide the process of exploring the search space, of-

fering capabilities to discover potential search points

and not random points. Consequently, better results

are expected than that obtained by other strategies

that investigate the search space using unguided pro-

cesses.

In summary, this stage performs two tasks. First,

based on

potential sequences, an

strategy adapts

the optimization sequences, provided by the previ-

ous phase, to the test-program features and returns the

best sequence. Second, it updates the database in or-

der to maintain the acquired knowledge and reuse it.

3.3 Strategies to Feed the Database

Although the hybrid approach can operate without

feeding the database, utilizing a scheme for such pro-

cess generates knowledge in medium and long terms.

Thus, two approaches to feed the database are pro-

posed:

1. Constant feeding: for every test program com-

piled, the hybrid approach stores new information

in the database (characteristics and sequences)

and recreates the model.

2. Batch feeding: for every test program compiled,

the hybrid approach stores new information in the

database, and after

compiled programs, it recre-

ates the model.

The constant feeding strategy has the potential of

providing recently-discovered knowledge, but has a

cost to recreate the model. On the other hand, batch

feeding reduces that cost, but does not provide knowl-

edge when it is recently discovered.

3.4 Strategies for Program

Representation

In this article, a program is represented utilizing the

characteristics proposed by Namolaru et al. (Namo-

laru et al., 2010), which are systematically extracted

from relationships between the program entities and

deﬁned by the speciﬁcities of the programming lan-

guage. The appeal of using these characteristics is

that Namolaru et al. proves their inﬂuence in apply-

ing optimizations.

In fact, this article uses two representation ap-

proaches:

1. Based on hot functions: this indicates that the pro-

gram will be represented using only its hottest

function, because it is a portion of the code that

the compiler will have the highest beneﬁt in opti-

mizing.

2. Based on the entire program structure: this indi-

cates that the extracted characteristics describe the

entities of the full program.

4 INSTANTIATION OF THE

HYBRID APPROACH

The hybrid approach, described in the previous sec-

tion, can be instantiated using different strategies.

Thus, this section aims to describe how it was imple-

mented.

Combining Machine Learning with a Genetic Algorithm to Find Good Complier Optimizations Sequences

399

4.1 Implementation

The proposed strategy was implemented as a tool

LLVM

3.7.0 (LLVM3.7, 2016), which was chosen

based on the fact that it allows full control over the

optimizations. This means that it is possible to enable

a list of optimizations through the command line, in

which the position of each optimization indicates its

order of applying.

In addition, two

plugins

were implemented for

LLVM

: (1) libWuLars: used for extracting the pro-

gram’s hottest function, as proposed by Wu and Larus

(Wu and Larus, 1994); and (2) libFeaturesExtractor:

used for extracting the characteristics proposed by

Namolaru et al. (Namolaru et al., 2010).

4.1.1 The Machine Learning Phase

Search Space. The search space is formed by the op-

timizations that exist on the three

LLVM

compiler

optimization levels:

and

Test Programs.

Microbenchmarks

, taken from the

test suite of

LLVM

, were utilized to create the

database. Table 1 presents the

microbenchmarks

Table 1: Microbenchmarks.

ackermann fp-convert partialsums whetstone

ﬂops-6 nsieve-bits spectral-norm ﬂops-3

methcall reedsolomon ﬁb2 mandel-2

quicksort dt intmm puzzle-stanford

ary3 hash perlin ﬂops-4

ﬂops-7 richards bench strcat mandel

misr fannkuch ﬂdry queens

random heapsort lists ﬂops-5

bubblesort oourafft perm matrix

ﬂops-8 salsa20 towers queens-mcgill

n-body fbench ﬂops-1 fasta

realmm himenobmtxpa pi fasta-redux

chomp oscar treesort mandelbrot

ﬂops sieve ﬂops-2 binary-trees

recursive ffbench lpbench regex-dna

dry huffbench puzzle pidigits

Database Creation. The hybrid approach uses a ge-

netic algorithm (

) to reduce the search space

and ﬁnd a good compiler optimization sequence

for each training program. The

consists in ran-

domly generating an initial population, which will

evolve through an iterative process. This proce-

dure involves choosing the parents; applying ge-

netic operators; evaluating new individuals; and

deciding which individuals will compose the new

generation.

This iterative process is performed until a stop-

ping criterion is reached. The ﬁrst generation is

composed of individuals that are generated by a

uniform sampling of the optimization space. The

process for a population to evolve requires two ge-

netic operators:

1. crossover; and

2. mutation.

Crossover has a probability of 60% to create a

new individual. In this case, a tournament strat-

egy (Tour = 5) selects the parents. Mutation

has a probability of 40% to transform an indi-

vidual. In addition, each individual has an ar-

bitrary initial length, which ranges from 1 to

|Number of Optimizations in Space|. Thus, the

crossover operator can be applied to individuals

of different lengths. In this case, the length value

for the new individual is the average of its parents.

Four types of mutation operations were used:

1. Insert a new optimization into a random point;

2. Remove an optimization from a random point;

3. Exchange two optimizations from random

points; and

4. Alter one optimization in a random point.

Both operators have the same probability of oc-

currence. In addition, only one mutation is ap-

plied over the individual selected to be trans-

formed. This iterative process uses elitism, which

maintains the best individual in the next gener-

ation. Furthermore, it executes twice: over 100

generations and 50 individuals; and over 20 gen-

erations and 10 individuals. The stop criterion

consists in whether the standard deviation of the

current ﬁtness score is less than 0.01, or the best

ﬁtness score does not change in three consecutive

generations. Finally, they are merged and used as

one reduced search space. The strategy utilized to

reduce the search space is similar to the strategy

proposed by Martins et al. (Martins et al., 2016)

and Purini and Jain (Purini and Jain, 2013).

Model Creation. The

algorithm is responsible for

creating the model, and applies the

SVM

classi-

ﬁer to identify similar programs. The instantiation

process uses the

SVM

version from the scikit-learn

library (ScikitLearn, 2016), with a linear

kernel

and the decision function

one-versus-rest

This

algorithm was chosen based on results

obtained comparing

SVM

and other

approaches

presented in literature (Park et al., 2011; Malik,

2010).

4.1.2 Iterative Compilation Phase

Initial Sequences. These are extracted from training

programs that are considered similar to the test

program. Thus, each training program

will con-

tribute with a quantity of sequences. This value is

given by:

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

400

Population size×

Decision

val

∑

x∈Base

Decision

val

(1)

The sequence-extraction process from different

programs is done in order to generate diversity.

Therefore, the solution adapter uses a guided pro-

cedure to explore potential search points.

It is worth noting that

Population size

is the

number of potential sequences that the

model

will provide. Thus, when this value is reached,

the selection process is interrupted and the chosen

sequences are sent to the adaptation phase.

The Solution Adapter. The solution adapter is the

utilized to create the database, with an initial

population of 10 individuals, and a maximum of

20 generations.

4.2 Utilizing the Approach

The hybrid approach can be described in the follow-

ing steps:

1. Creation of the database by applying a

;

2. Exclusion of the optimization sequences that

under-perform the best

LLVM

compiler optimiza-

tion levels, for each program of the database;

3. Creation of the prediction model applying

SVM

;

4. Extraction of the characteristics of the test pro-

gram;

5. Calculation of the decision function, according to

the model created in Step 3, for the characteristics

of the test program;

6. Calculation of the number of optimization se-

quences that each test program will provide in the

10 potential optimization sequences, according to

the Equation (1);

7. Selection of the 10 safe

compiler optimization

sequence and validation of the potential optimiza-

tion sequences that will be provided to the solu-

tion adapter of the (

);

8. Attributionof the valid optimization sequences, as

in the ﬁrst generation of the

;

9. Execution of the

on selected sequences;

10. Re-feeding of the database with all sequences cre-

ated by the

Steps 1 to 7 summarize the

phase. Step 8 is

a transition phase from

. Step 9 consists in

. Lastly, Step 10 retains the knowledge created by

A safe sequence means that it does not cause error on

the compiler infrastructure during the target code genera-

tion.

. Step 1 is executed once because it is part of the

training phase of

, which is not dependent on the

parametrization of the model.

5 EXPERIMENTS

This section analyzes the performance of the ap-

proach proposed in this article. First, the performance

will be analyzed and compared to

and

. After-

wards, the performance, utilizing different data sets

and hardware platforms, will be analyzed as well.

5.1 Methodology

Experimental Architecture. The experiments were

conducted on a hardware with an Intel Core i7-

3770 processor with a frequency of 3.40GHz, 8

MB cache, 8 GB of RAM and the Ubuntu 15.10

operating system with kernel 4.2.0-35-generic.

Test Programs. The Collective Benchmark

(CBENCH) was utilized for testing purposes

(excluding stringsearch and ispell), with data set

1; and the Polyhedral Benchmark (POLYBENCH)

(excluding JACOBI-1D), with data set extralarge.

Each benchmark suite consists in a batch, for the

batch feeding strategy.

Metrics. The evaluation uses four metrics to analyze

the results: (1)

Speedup

; (2)

NPS

: number of pro-

grams achieving speedup over the best compiler

optimization level, also called covering; (3)

NoS

number of sequences evaluated; and (4)

ReT

: re-

sponse time. The speedup is calculated as follows:

Speedup = Runtime

Level O0/Runtime

Strategies. Table 2 summarizes the evaluated ap-

proaches.

Table 2: Evaluated Approaches.

Approach

Program

Representation

Feeding

Strategy

Compilation

Order

Maximum

NoS

The Proposed Hybrid Approaches

HHBP Hot Batch Poly-cBench 200

HHBC Hot Batch cBench-Poly 200

HHC Hot Constant Alphabetical 200

HFBP Full Batch Poly-cBench 200

HFBC Full Batch cBench-Poly 200

HFC Full Constant Alphabetical 200

Machine Learning Approaches

MLH Hot - - 10

MLF Full - - 10

Iterative Compilation Approaches

IC50 - - - 5000

IC10 - - - 200

B10 - - - 10

Combining Machine Learning with a Genetic Algorithm to Find Good Complier Optimizations Sequences

401

The

IC50

and

IC10

approaches are applications of

the

used in the creation of the database.

IC50

is a strategy with 50 individuals in the popula-

tion, on the other hand,

IC10

has 10 individuals.

The

B10

approach consists in applying the 10 se-

quences found by Purini and Jain, and returning

the best target code (Purini and Jain, 2013).

5.2 Performance

The obtained results are presented in Table 3.

Table 3: Summary of Experiments (GMS: geometric mean

speedup, AVG: Average).

Strategy

Speedup

NPS

NoS

Best GMS Worst Max AVG Min

HHBP 4.466x 1.997x 1.055x 46 110 51.085 10

HHBC 4.500x 1.988x 1.067x 45 117 54.845 10

HHC 4.479x 1.972x 1,056x 46 180 55.458 10

HFBP 6.000x 1.990x 1.062x 45 140 50.135 10

HFBC 4.442x 1.958x 1.068x 44 99 51.983 10

HFC 4.459x 1.954x 1.054x 43 119 52.796 10

MLH 4.491x 1.910x 1.050x 33 10 10 10

MLF 4.060x 1.903x 1.056x 35 10 10 10

IC50 4.353x 2.083x 1.075x 56 650 286.169 100

IC10 6.714x 1.930x 1.035x 46 120 53.678 10

B10 3.751x 1.801x 1.046x 24 10 10 10

O1 4.7x 1.692x 0.992x - 1 1 1

O2 4.368x 1.843x 1.033x - 1 1 1

O3 4.361x 1.844x 1.052x - 1 1 1

Speedup. It can be seen that the hybrid approach,

in all its variations, outperforms all the evalu-

ated approaches, except

IC50

. Among the dif-

ferent variations made in the hybrid approach, a

better performance is reached when applying the

batch feeding strategy. In addition, the speedups

achieved, using only the characteristics of the

hottest function, are superior to those reached by

the full program representation. This also occurs

in the pure

approaches. Thus, it demonstrates

that optimizing the hot functions is a smart strat-

egy to mitigate the

OSP

An interesting result is that constant feeding un-

derperforms when compared to batch feeding.

This indicates that inserting knowledge and utiliz-

ing it immediately does not always provide bene-

ﬁts.

Comparing the results obtained by the hybrid ap-

proaches to the best compiler optimization level

(

) shows that the worst result obtained by the

hybrid approach (

HFC

) had a gain of 5.965%, and

the best (

HHBP

) had a gain of 8.297%. On the other

hand, comparing the hybrid approach with pure

, the performance gain ranges from 4.555% to

4.940%, which proves that combining

and

brings beneﬁts in terms of

GMS

. Furthermore, the

gain achieved by the hybrid approach compared

IC10

ranges from 1.244% to 3.472%. How-

ever, the performance gain of the

IC50

approach

ranges from 4.306% to 6.602% over the hybrid

approach, and it is 7.927% over the gain obtained

by the

IC10

approach.

Covered Programs. The

NPS

indicates the superior-

ity of the strategy

IC50

, which covers 95% of the

programs. The hybrid approach and

IC10

cover

78% of the programs, while

B10

and

cover

41% and 51%, respectively.

Number of Evaluated Sequences. A factor that in-

creases the response time is the quantity of se-

quences that will be evaluated. It is important to

note that to evaluate a sequence means to compile

and execute the program, to measure its runtime.

Therefore, reducing the

NoS

is crucial to reduce

the response time of the system.

The results show that it is possible to outperform

the compiler optimization levels (concerning the

GMS) evaluating a few sequences; however, re-

ducing the

NoS

. This is the case for

MLH

MLF

, and

B10

Increasing the

NoS

increases the speedup and the

NPS

, consequently increasing the response time.

This is the case for

IC50

that reaches a better

speedup than the hybrid approach; howeverevalu-

ating 5 times more sequences. This indicates that

can reach good speedups at the cost of a high

response time. Therefore, there exists a trade-

off between performance (speedup) and response

time, which the hybrid approach balances.

Response Time. The evaluated response time is the

total time spent by the system, excluding the cre-

ation of the database since this step is executed

only once ofﬂine. The lowest

Ret

comes from

the

and

B10

approaches that consumed 42 and

43 minutes in average per program. On the other

hand, the

IC10

and

IC50

approaches consumed an

average of 2 hours and 18 minutes, and 14 hours

and 30 minutes respectively. Lastly, the hybrid

approach, consumed an average of 2 hours and 58

minutes per program.

The hybrid approach outperforms

IC10

up to

3.47% (in regards to the speedup), adding up 29%

of the time. In addition,

IC50

outperforms the

IC10

approach up to 7.927%; however, with a

increase in time of 530%. This results indicate

that the approaches that are more time-consuming

reach the best speedups, besides proving how ef-

ﬁcient the hybrid approaches are in cost-beneﬁt.

Observing all approaches, it is worth highlighting

that when the number of evaluated sequences grows,

the performance increases as well; however, not in

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

402

the same proportion. Thus, it is important to an-

alyze the objective of the system to decide which

strategy should be utilized. Some strategies achieve

lower speedups with a lower response time, while

others have a high response time but achieve higher

speedups.

5.3 Performance using Different Data

sets and Hardware

The experiments for different data sets were per-

formed only with constant feeding, and CBENCH due

to the availability of several data sets. Table 4 displays

the speedups based on different data sets.

Table 4: Evaluated Input.

Input

Hot Function Full Program

Best GMS Worst Best GMS Worst

1 4.116x 1.987x 1.064x 3.352x 1.966x 1,061x

10 3.178x 1.961x 1.072x 3,197x 1,947x 1,080x

20 3.184x 1.895x 1.076x 3,089x 1,890x 1,060x

It can be seen that the alteration of the data sets in-

ﬂuences the performance, as reported in the literature

(Chen et al., 2010). The performance loss was only

up to 4.855%, independent from the characterization

of programs utilized.

It is important to note that the extraction of good

sequences, from the database, considers only static

characteristics. This has the disadvantage of not con-

sidering the program behavior by exchanging data

sets. On the other hand, it has the advantage of not

requiring the execution of the program for feature ex-

traction, which will impact on the system response

time. Therefore, a loss of up to 4.855% in perfor-

mance is appealing against the cost of executing pro-

grams.

The experiments with different hardware archi-

tectures were also executed only with the approach

of constant feeding, but using CBENCH and POLY-

BENCH. Table 5 exhibits the

GMS

obtained in the ar-

chitecture described in Section 5.1 (Core-i7) and the

following infrastructure: Intel Xeon E5504 proces-

sor with a frequency of 2.00GHz, 4 MB of cache

and 24GB of RAM (Xeon). The experiment with the

second architecture considers that there is already a

database created previously. Thus, the presented re-

sults utilize the same database created in the ﬁrst ar-

chitecture.

Table 5: Evaluated Architectures.

Hot Full O1 O2 O3

Xeon 2.243x 2.233x 1.935x 2.086x 2.098x

Core i7 1.972x 1.954x 1.692x 1.843x 1.844x

It can be observed that the architecture with the

Xeon processor had better results when compared to

the Core-i7 processor. Furthermore, the gain in per-

formance of the hybrid approach over the the best

compiler optimization level (

) is up to 6.491% in

the Core-i7 architecture, and up to 6.465% in the

Xeon architecture. The gains on the

and

levels

are very similar, where the variations reach at most

a 1%, from one architecture to another. The results

indicate that for both architectures, the gains in the

hybrid approach are approximately the same propor-

tion.

The results indicate that:

• it is possible to achieve good speedups using a

database created in a different hardware platform;

• representing programs based on their hot func-

tions is an efﬁcient strategy to reduce the loss in

performance when the data set is changed, as well

as the hardware platform; and

• using a hybrid approach is a smart strategy to miti-

gate the

OSP

, regardless of the data set or the hard-

ware platform.

6 CONCLUSIONS AND FUTURE

WORKS

Finding a good compiler optimization sequence is a

program-dependent problem. An efﬁcient approach

performs two steps. The ﬁrst inspects the program

features, and based on these features, it predicts po-

tential previously-successful compilations. The sec-

ond step adapts the potential sequences to the pro-

gram. In addition, considering that a substantial

amount of runtime is spent in a small portion of the

code, such an approach is guided by the features ex-

tracted from hot functions. Thus, this paper proposed

a hybrid approach to mitigate the optimization selec-

tion problem, which combines iterative compilation

and machine learning.

The results indicate that the proposed hybrid ap-

proach outperforms both iterative compilation ap-

proaches and machine learning approaches. There-

fore, the hybrid approach is an efﬁcient approach to

mitigate the optimization selection problem, because,

even when compared to the most aggressive iterative

compilation approach, it had a better cost-beneﬁt.

It is intended, as a future work, to evaluate the

hybrid approach with other instantiations, altering

characteristics for program representations, machine

learning algorithms and solution adapters.

Combining Machine Learning with a Genetic Algorithm to Find Good Complier Optimizations Sequences

403

REFERENCES

Aho, A. V., S., L. M., Sethi, R., and Ullman, J. D. (2006).

Compilers: Principles, Techniques and tools. Prentice

Hall.

Ansari, A. and Bakar, A. A. (2014). A comparative study of

three artiﬁcial intelligence techniques: Genetic algo-

rithm, neural network, and fuzzy logic, on scheduling

problem. In 2014 4th International Conference on Ar-

tiﬁcial Intelligence with Applications in Engineering

and Technology, pages 31–36.

Chen, Y., Huang, Y., Eeckhout, L., Fursin, G., Peng, L.,

Temam, O., and Wu, C. (2010). Evaluating Iterative

Optimization Across 1000 Datasets. SIGPLAN No-

tices, 45(6):448–459.

Jantz, M. R. and Kulkarni, P. A. (2013a). Exploiting Phase

Inter-dependencies for Faster Iterative Compiler Opti-

mization Phase Order Searches. In International Con-

ference on Compilers, Architecture and Synthesis for

Embedded Systems, pages 1–10.

Jantz, M. R. and Kulkarni, P. A. (2013b). Performance po-

tential of optimization phase selection during dynamic

jit compilation. SIGPLAN Notices, 48(7):131–142.

Junior, N. L. Q. and da Silva, A. F. (2015). Finding Good

Compiler Optimization Sets - A Case-based Reason-

ing Approach. In Proceedings of the International

Conference on Enterprise Information Systems, pages

504–515.

Lima, E. D., De Souza Xavier, T., Faustino da Silva, A., and

Beatryz Ruiz, L. (2013). Compiling for Performance

and Power Efﬁciency. In International Workshop on

Power and Timing Modeling, Optimization and Simu-

lation, pages 142–149.

LLVM3.7 (2016). The LLVM Compiler Infrastructure

Project. http://llvm.org.

Malik, A. M. (2010). Spatial Based Feature Generation for

Machine Learning Based Optimization Compilation.

In Ninth International Conference on Machine Learn-

ing and Applications, pages 925–930.

Martins, L. G. A., Nobre, R., Cardoso, J. M. P., Delbem,

A. C. B., and Marques, E. (2016). Clustering-Based

Selection for the Exploration of Compiler Optimiza-

tion Sequences. ACM Transactions on Architecture

and Code Optimization, 13(1):8:1–8:28.

Namolaru, M., Cohen, A., Fursin, G., Zaks, A., and Fre-

und, A. (2010). Practical Aggregation of Semantical

Program Properties for Machine Learning Based Op-

timization. In Proceedings of the International Con-

ference on Compilers, Architectures and Synthesis for

Embedded Systems, pages 197–206. ACM.

Park, E., Cavazos, J., and Alvarez, M. A. (2012). Using

Graph-based Program Characterization for Predictive

Modeling. In Proceedings of the International Sym-

posium on Code Generation and Optimization, pages

196–206, New York, NY, USA. ACM.

Park, E., Kulkarni, S., and Cavazos, J. (2011). An eval-

uation of different modeling techniques for iterative

compilation. In 2011 Proceedings of the 14th Inter-

national Conference on Compilers, Architectures and

Synthesis for Embedded Systems (CASES), pages 65–

74.

Purini, S. and Jain, L. (2013). Finding Good Optimization

Sequences Covering Program Space. ACM Transac-

tions on Architecture and Code Optimization, 9(4):1–

23.

ScikitLearn (2016). Scikit-Learn: Machine Learning In

Python. http://scikit-learn.org.

Tambouratzis, G. (2016). Applying pso to natural language

processing tasks: Optimizing the identiﬁcation of syn-

tactic phrases. In 2016 IEEE Congress on Evolution-

ary Computation (CEC), pages 1831–1838.

Wu, Y.and Larus, J. R. (1994). Static Branch Frequency and

Program Proﬁle Analysis. In Proceedings of the An-

nual International Symposium on Microarchitecture,

pages 1–11, New York, NY, USA. ACM.

Zhou, Y.-Q. and Lin, N.-W. (2012). A Study on Optimiz-

ing Execution Time and Code Size in Iterative Com-

pilation. In International Conference on Innovations

in Bio-Inspired Computing and Applications, pages

104–109.

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

404
