Distributing Scenario-based Models: A Replicate-and-Project Approach

Shlomi Steinberg

, Joel Greenyer

, Daniel Gritzner

, David Harel

, Guy Katz

and Assaf Marron

The Weizmann Institute of Science, Rehovot, Israel

Leibniz Universit

at Hannover, Hannover, Germany

Stanford University, Stanford, U.S.A.

Keywords:

Software Engineering, Scenario-based Modeling, Concurrency, Distributed Systems.

Abstract:

In recent years, scenario-based modeling has been proposed to help mitigate some of the underlying difﬁcul-

ties in modeling complex reactive systems, by allowing modelers to specify system behavior in a way that is

intuitive and directly executable. This modeling approach simpliﬁes the speciﬁcation of systems that include

events occurring in distinct system components. However, when these system components are physically dis-

tributed, executing the scenario-based model requires inter-component coordination that may negatively affect

system performance or robustness. We describe a technique that aims to reduce the amount of joint event-

selection decisions that require coordination and synchronization among distributed system components. The

technique calls for replicating the entire scenario-based executable speciﬁcation in each of the components,

and then transforming it in a component-speciﬁc manner that induces the required differences in execution

while reducing synchronization requirements. In addition to advantages in streamlining design and improving

performance, our approach captures the fact that in certain “smart” distributed systems it is often required that

components know what rules govern the behavior of other components. Our evaluation of the technique shows

promising results.

1 INTRODUCTION

With modern reactive systems becoming both perva-

sive and highly complex, modeling them is becoming

increasingly difﬁcult. Modelers are forced to spend

ever-larger amounts of time and effort in order to rec-

oncile two goals: (1) accurately describe complex

real-world systems and phenomena; and (2) do so us-

ing models that are simple, comprehensible and intu-

itive to humans. These two goals are often conﬂict-

ing: it is difﬁcult to describe the properties of such

systems accurately while at the same time avoiding

clutter, which makes it harder for humans to compre-

hend the resulting models.

Over the recent two decades, an approach termed

Scenario-Based Modeling (Damm and Harel, 2001)

has emerged as an attempt at tackling these difﬁcul-

ties. The idea at its core is to model systems in

a way that is more intuitive and understandable to

humans — by deﬁning scenarios that describe de-

sirable or undesirable system behavior — and then

to automatically combine these scenarios in a way

that produces a cohesive, global model. Appropriate

scenario-based approaches and tools have executable

semantics, thus helping to streamline the deployment

of scenario-based models in the real world.

A scenario-based approach has been claimed to

be more intuitive for humans to understand (see,

e.g., (Gordon et al., 2012)). It allows the modeler to

specify different but possibly interrelated behavioral

aspects as separate scenarios, reducing the inherent

complexities of the modeling process. However, by

default and as explained later, a scenario-based exe-

cution requires that all scenarios synchronize at every

step for the purpose of joint event selection. When ex-

ecuting scenario-based speciﬁcations in a distributed

architecture, inter-scenario synchronization induces

inter-component synchronization, which may be un-

desirable in real-world systems, where communica-

tion is often costly, slow, or unreliable. This difﬁculty

constitutes a serious barrier when considering the use

of scenario-based modeling in a real-world setting.

We seek to address this problem by proposing an

automated technique for the transformation of clas-

sical, highly synchronous scenario-based models into

equivalent models with a greatly reduced level of syn-

chronization. The basis of our approach is a rather

straightforward replicate-and-project technique but

182

Steinberg S., Greenyer J., Gritzner D., Harel D., Katz G. and Marron A.

Distributing Scenario-based Models: A Replicate-and-Project Approach.

DOI: 10.5220/0006271301820195

In Proceedings of the 5th International Conference on Model-Driven Engineering and Software Development (MODELSWARD 2017), pages 182-195

ISBN: 978-989-758-210-3

with some subtle facets: we replicate the full set of

scenarios in all the distributed components but project

them in a component-speciﬁc fashion, so that each

component is made responsible only for the actions

that fall within its the local scope. Other, external

actions are assumed to be performed by projections

running on other components.

In order to make the replicated-and-projected sce-

narios behave the same as their non-distributed ver-

sion, the distributed components broadcast the local

actions they perform to all other components. At

times a situation arises that forces some of the dis-

tributed components to mutually agree on the next ac-

tion to perform. This might happen either due to an

exclusive choice among multiple enabled actions (i.e.,

events), or due to communication latency that might

result in different orders of broadcast actions as ob-

served by different components. An important part of

the work in this paper is dedicated to classifying these

cases, presenting them when they arise, and propos-

ing practical approaches to resolving them.

This process is handled automatically by our dis-

tribution algorithm and infrastructure, and, as we dis-

cuss and demonstrate later, it aims to generate a dis-

tributed model that has as few synchronization points

as possible.

The motivation behind the approach is to retain the

modeler’s ability to use classical scenario-based mod-

eling, with its associated advantages, but to be able to

then transform the model into a version that is more

amenable to distribution and deployment in the real

world. We prove that, under certain restrictions, our

proposed transformation preserves the behavior of the

original model. This gives rise to a methodology for

developing distributed scenario-based models, where

one models a distributed system as if it were central-

ized, and the model is then automatically adjusted to

more accurately simulate (or even run in) its ﬁnal set-

ting.

Automatic distribution of general models (i.e., not

just scenario-based) or synthesizing distributed mod-

els from speciﬁcations have been long-standing goals

of the software modeling and engineering community.

Speciﬁcally, distributed synthesis is known to be un-

decidable in some cases (Stefanescu et al., 2003). We

contribute to this effort by studying the problem in the

context of scenario-based modeling, and leveraging

some of the paradigm’s properties of naturalness and

relative simplicity. However, difﬁculties nevertheless

arise. We classify and describe them, and explain how

they can still be addressed. Our experimental results

indicate that the technique holds much potential for

becoming practical.

The rest of the paper is organized as follows.

In Section 2 we provide a brief introduction to the

scenario-based approach. In Section 3 we introduce

the notion of a distributed scenario-based model, and

show how it can be automatically generated from

a non-distributed model by our replicate-and-project

technique. The correctness of this transformation is

proved in Appendix 8. Section 4 describes how the

approach can be applied when different components

in the model operate on different time scales. An

example implementation and its evaluation appear in

Section 5, followed by a discussion in Section 6 of

our ongoing and planned future work. In section 7,

we discuss related work that has been carried out on

automatic distribution, both in the general setting and

in the context of scenario-based modeling. We con-

clude in Section 8.

2 BACKGROUND:

SCENARIO-BASED MODELING

Scenario-based modeling was ﬁrst presented via the

Live Sequence Charts (LSC) formalism (Damm and

Harel, 2001; Harel and Marelly, 2003a). The ap-

proach, aimed at developing executable models of re-

active systems, shifts the focus from describing indi-

vidual objects of the system into describing individ-

ual behaviors of the system. The basic building block

in this approach is the scenario: an artifact that de-

scribes a single behavior of the system, possibly in-

volving multiple different components thereof. Sce-

narios can describe either desirable behaviors of the

system or undesirable ones. A set of user-deﬁned sce-

narios can then be interwoven into one cohesive, po-

tentially complex, system behavior.

Several facets of scenario-based modeling have

been discussed and handled in different ways: sce-

narios can be represented graphically, as in the

original LSC approach, or textually (Harel et al.,

2012b; Greenyer et al., 2016a); scenario-based

models can be executed by na

ıve play-out (Harel

and Marelly, 2003b), by smart playout with look-

ahead (Harel et al., 2002) or via controller synthesis

(see, e.g., (Harel and Segall, 2011; Greenyer et al.,

2016a)). The modeling process can be augmented by

a variety of automated veriﬁcation, synthesis and re-

pair tools (Harel et al., 2012a; Harel et al., 2013b).

However, research has shown that the basic princi-

ples at the core of the approach, shared by all ﬂa-

vors, are naturalness and incrementality — in the

sense that scenario-based modeling is easy to learn

and understand, and that it facilitates the incremen-

tal development of complex models (Gordon et al.,

2012; Alexandron et al., 2014). These properties stem

Distributing Scenario-based Models: A Replicate-and-Project Approach

183

from the fact that modeling is done in a way similar to

the way humans explain complex phenomena to each

other, detailing the various steps and behaviors one at

a time.

For the remainder of the paper, we focus on a par-

ticularly simple variant of scenario-based modeling,

called behavioral programming (BP) (Harel et al.,

2012b). Despite its simplicity, BP has been success-

fully used in developing medium scale projects (Harel

and Katz, 2014; Harel et al., 2016), and is also

known to be particularly amenable to automatic anal-

ysis tools (Harel et al., 2015c). These properties ren-

der BP a good candidate for demonstrating our ap-

proach. The rest of this section is dedicated to demon-

strating and formally deﬁning BP.

In BP, a model is a set of scenarios, and an execu-

tion is a sequence of points, in which all the scenar-

ios synchronize. At every behavioral-synchronization

point (abbreviated bSync) each scenario pauses and

declares events that it requests and events that it

blocks. Intuitively, these two sets encode desirable

system behaviors (requested events) and undesirable

ones (blocked events). Scenarios can also declare

events that they passively wait-for — stating that they

wish to be notiﬁed if and when these events occur.

The scenarios do not communicate their event decla-

rations directly to each other; rather, all event declara-

tions are collected by a central event selection mech-

anism (ESM). Then, at every synchronization point

during execution, the ESM selects (triggers) an event

that is requested by some scenario and not blocked by

any scenario. Every scenario that requested or waited

for the triggered event is then informed, and can up-

date its internal state, proceeding to its next synchro-

nization point. Fig. 1 (borrowed from (Harel et al.,

2016)) demonstrates a simple behavioral model.

Formally, BP’s semantics are deﬁned as follows.

A scenario, also referred to in the literature as a be-

havior thread (abbreviated b-thread), is deﬁned as a

tuple

BT = hQ,q

,δ,R,Bi

and with respect to a global set of events Σ. The com-

ponents of the tuple are: a set of states Q represent-

ing synchronization points; an initial state q

∈ Q; a

deterministic transition function δ : Q × Σ → Q that

speciﬁes how the thread changes states in response

to the triggering of events; and, two labeling func-

tions, R : Q → P (Σ) and B : Q → P (Σ), that specify

the events that the thread requests (R) and blocks (B)

in a given synchronization point.

A behavioral model M is deﬁned as a collection of

b-threads

M = {BT

,...,BT

wait for

WATERLOW

request

ADDHOT

request

ADDHOT

request

ADDHOT

ADDHOTWATER

wait for

WATERLOW

request

ADDCOLD

request

ADDCOLD

request

ADDCOLD

ADDCOLDWATER

wait for

ADDHOT

while

blocking

ADDCOLD

wait for

ADDCOLD

while

blocking

ADDHOT

STABILITY

···

WATERLOW

ADDHOT

ADDCOLD

ADDHOT

ADDCOLD

ADDHOT

ADDCOLD

···

EVENT LOG

Figure 1: Incrementally modeling a controller for the wa-

ter level in a tub. The tub has hot and cold water sources,

and either may be turned on in order to increase/reduce

the water temperature. Each scenario is given as a tran-

sition system, where the nodes represent synchronization

points. The scenario ADDHOTWATER repeatedly waits for

WATERLOW events and requests three times the event AD-

DHOT. Scenario ADDCOLDWATER performs a similar ac-

tion with the event ADDCOLD, capturing a separate re-

quirement, which was introduced when adding three wa-

ter quantities for every sensor reading proved to be insufﬁ-

cient. When a model with scenarios ADDHOTWATER and

ADDCOLDWATER is executed, the three ADDHOT events

and three ADDCOLD events may be triggered in any order.

When a new requirement is introduced, to the effect that

water temperature be kept stable, the scenario STABILITY

is added, enforcing the interleaving of ADDHOT and ADD-

COLD events by using event blocking. The execution trace

of the resulting model is depicted in the event log.

all of them with respect to the same event set Σ. De-

noting the individual b-threads as

= hQ

,δ

an execution of model M starts at the initial state

,...,q

i. Then, at every state hq

,...,q

i, the

model progresses to the next state h ¯q

,..., ¯q

i by:

1. selecting an event e ∈ Σ that is enabled, i.e. re-

quested by at least one b-thread and blocked by

none:

e ∈

[

i=1

)

[

i=1

)

2. triggering event e and advancing the individual b-

threads according to their transition systems:

∀i, ¯q

= δ

,e)

For reactive systems, executions are often inﬁnite —

although BP can also be used to model systems with

ﬁnite executions.

The BP deﬁnitions above are abstract, and make

it easier to reason about behavioral models. How-

ever, for practical purposes, the BP modeling princi-

ples have been integrated into a variety of high-level

languages such as Java, C++, Erlang and Javascript

(see the BP website at http://www.b-prog.org/).

These frameworks allow engineers to integrate re-

active scenarios into their favorite programming or

MODELSWARD 2017 - 5th International Conference on Model-Driven Engineering and Software Development

184

modeling environments. Further, the same principles

as underly BP, play a signiﬁcant role in several pop-

ular modeling frameworks such as publish-subscribe

architectures (Eugster et al., 2003) and supervisory

control (Ramadge and Wonham, 1987).

3 DISTRIBUTION VIA

REPLICATE-AND-PROJECT

The execution of a classical BP model, as described

in Section 2, is highly synchronized and central-

ized by nature: at every step along the execution,

the ESM gathers the sets of requested and blocked

events from each individual b-thread, selects an en-

abled event, and then broadcasts it back to the b-

threads. While this underlies some of the beneﬁts

of BP (Harel et al., 2012b), it also results in limited

scalability and distributability. Excessive synchro-

nization tends to add unnecessary complexity, impact

performance, and create inter-component dependen-

cies which reduce robustness. For example, having a

scenario wait for an event that is supposed to be re-

quested by a scenario running on a separate, failed

component might result in a deadlock. Furthermore,

synchronization forces b-threads to execute in lock-

step, which can be undesirable if they are to model

phenomena that occur at different timescales.

In this section we propose a distribution process

that transforms a centralized (undistributed) behav-

ioral model into a distributed one: it generates mul-

tiple component models — subsets of the original,

centralized behavioral model — each designed to be

run on a separate machine. When run simultaneously,

however, these component models mimic the behav-

ior of the original system, but require much less syn-

chronization. Below we elaborate on the abstract con-

cepts and formal deﬁnitions of the proposed process.

An example showing how these concepts apply in the

setting of a particular distributed application appears

in Section 5.

Each of the component models produced by our

distribution process is a behavioral model in its own

right, intended to be responsible for a certain subset of

the events of the original model, which are uniquely

owned and controlled by it — meaning that no other

component can request or block them. The compo-

nent models are intended to be executed in an asyn-

chronous manner in a distributed system, resulting in

a natural, robust and simple extension of the scenario-

based paradigm.

The main difﬁculty in this approach is to ensure

that the distributed components behave in the same

way as the original model although they are not syn-

chronized at every step. In order to resolve this difﬁ-

culty, the crux of our distribution process is the repli-

cation of the entire set of original scenarios in each of

the distributed components, granting the components

the ability to follow what other components are do-

ing, but avoiding synchronization when possible. By

default, every component runs a local ESM, which

performs local event selection without synchroniz-

ing with other components. However, at every syn-

chronization point where multiple components have

to agree on the particular event to select, the ESMs of

these components do synchronize.

The communication between components is asyn-

chronous, and they notify each other about chosen

events as they progress through the scenarios. Keep-

ing track of each scenario state is simply a matter of

listening to incoming broadcasts and updating the cur-

rent state.

The classical problem of multicasting or broad-

casting a message efﬁciently in a distributed network

is well studied (e.g. (Miller and Poellabauer, 2009)

presents an approach for minimum-energy-broadcasts

in distributed networks with limited resources and un-

known topology), however it is beyond the scope of

this paper. For simplicity we assume that the cost

of those boradcasts and bookkeeping is small. Note

that even in systems with a large number of compo-

nents and scenarios, a component often needs to keep

track of only a small subset of the other components;

for example, an autonomous car considers other cars

only when they are in its immediate vicinity, and does

not keep track of all vehicles in the world. Still, this

dynamic registering and unregistering of components

is also beyond the scope of this paper and is left for

future work.

In the remainder of the section we formalize these

notions and the distribution process itself.

3.1 Event Components

Let M denote a behavioral model over event set Σ. An

event component E is a subset of the global event set,

E ⊆ Σ. An event e ∈ E is said to be a local event of

E; otherwise, if e /∈ E then e is external to E.

A collection of event components {E

,...,E

} is

an event separation of Σ if

i=1

= Σ. An event

separation is strict if it also forms a partition of Σ:

∀ i, j, 1 ≤ i 6= j ≤ k =⇒ E

∩ E

In the remainder of the paper we will only deal with

strict event separations and assume that they are pro-

vided by the user to reﬂect the physical layout of the

system and the responsibility of each distributed com-

ponent. Automated ways of generating an event sep-

aration are discussed in section 7.

Distributing Scenario-based Models: A Replicate-and-Project Approach

185

3.2 Component Models

Given a behavioral model M = {BT

,...,BT

}, each

event component E gives rise to a component model

C, in the following way. C is the behavioral model

C = {BT

,...,BT

}, obtained by projecting each

of the original b-threads along event component E,

denoted C = project(M, E). Formally, if BT

,δ

i then

= hQ

,δ

The state set Q

, initial state q

and transition function

are unchanged; whereas the labeling functions R

and B

are changed into:

(q) = R

(q) ∩ E

(q) = B

(q) ∩ E

Intuitively, the projected b-threads are modiﬁed to

only request and block events that are in E; but be-

cause δ

is unchanged they continue to respond in

the same way to the triggering of all events, includ-

ing those not in E. Consequently, requested external

events effectively become waited-for events.

Now, given a strict event separation {E

,...,E

our distribution process entails projecting the model

M along each of the event components, producing a

set of component models {C

,...,C

} such that

∀ 1 ≤ i ≤ k, C

= project(M,E

)

By treating each component C

as a separate be-

havioral model that performs event selection locally,

the components can be run independently and in a dis-

tributed manner. The following useful corollary is a

direct conclusion that arises from the deﬁnition of the

distribution process.

Corollary 1. An event e ∈ Σ can be selected by one

component only.

Proof. {E

,...,E

} is a strict event separation, hence

there is only one value of i such that e ∈ E

. By def-

inition only C

can request e. Therefore only C

can

select e.

In order to keep the execution consistent between

components, occasionally two or more components

may need to synchronize, as we discuss in the next

section.

3.3 Executing Component Models

The following deﬁnition is useful in identifying the

points during the execution in which multiple compo-

nents need to synchronize:

Deﬁnition 1. Observe a component model C

project(M,E

), a b-thread BT

and some state q ∈ Q

We say that BT

is controlled by C

at state q if one or

more of E

’s local events is requested or waited-for in

q; i.e., if ∃e ∈ E

such that δ

(q,e) 6= q or e ∈ R

(q).

Whenever a scenario reaches a state that is con-

trolled by multiple components, these components

synchronize with each other and together select an

event for triggering, while the other components only

track the progress passively and need not synchro-

nize. We refer to these situations, where at some state

a single b-thread is controlled by multiple compo-

nents, as inter-component decision points. For exam-

ple, an inter-component decision point occurs when

two robot-controlled cars (each operated by a sepa-

rate component) arrive at an intersection exactly at

the same time and attempt to decide on which car

should yield to the other. Because the scenario con-

trolling the intersection waits for movement events

that are controlled by both components, the two car

components are forced to synchronize, mutually agree

on a single triggered event, and then broadcast it —

informing all interested threads, in all components,

about the selection.

In order to support this sort of distributed execu-

tion, each of the component models runs an ESM that

is slightly different from the one described in Sec-

tion 2. Speciﬁcally, the ESM from Section 2 is a tool

for picking one event for triggering from among the

set of all enabled events. In contrast, each of our dis-

tributed ESMs is capable of broadcasting events that

were triggered locally by “its” component to all other

model components, and, dually, to process external

events broadcast by the ESMs of other components.

The distributed version of the ESM operates as

follows:

• When a local event is triggered by a component’s

ESM, that event is broadcast to all other running

components.

• When a component’s ESM receives an event e that

was broadcast by another component’s ESM, e is

added to a dedicated event queue within the ESM.

• When choosing an event for triggering, an ESM

ﬁrst checks its event queue for external events.

If the queue is not empty, it pops an event from

the queue and declares it to be the triggered event

to its local b-threads. If the queue has multi-

ple stored events, this process repeats until the

queue becomes empty. Once the queue is empty

the ESM resumes normal event selection, as de-

scribed in Section 2: it selects a local event that is

requested and not blocked.

• Inter-component synchronizations: Whenever a

MODELSWARD 2017 - 5th International Conference on Model-Driven Engineering and Software Development

186

b-thread arrives at a state that requires synchro-

nization with one or more other components, the

ESMs of these threads synchronize and mutually

agree upon a triggered event. This event is then

broadcast to all ESMs.

Event selection is performed precisely as in the case

of a centralized ESM, by choosing a requested but not

blocked event.

The actual inter-component decision between

multiple ESMs can be performed, e.g., via a dis-

tributed leader election protocol (Ghosh and Gupta,

1996). Once a speciﬁc ESM has been selected as the

leader, it chooses the next triggered event based on

the requested and blocked events in the current state.

We observe that deadlocks need to be treated dif-

ferently in the distributed case than in the centralized

case. According to the semantics given in Section 2,

the system deadlocks if the ESM determines at some

point that there all requested events are blocked, so

that none can be selected. However, in the distributed

case this is no longer the case if one of the local b-

threads has an external waited-for event, since there

is yet hope that another component might broadcast

this event later. Thus, the component is stalled until

such a broadcast arrives.

3.4 Equivalence to Centralized

Executions

Given a centralized behavioral model M over an

event set Σ and a strict event separation {E

,...,E

our distribution process produces a set of component

models {C

,...,C

}. These components have the fol-

lowing property:

Lemma 1. Assuming that communication between

component models is instantaneous, the set of all pos-

sible executions (the language) of M is identical to the

set of all possible executions produced by the compo-

nent models {C

,...,C

} when run jointly in a dis-

tributed fashion.

This lemma, which is the main proven result of

this work, is of practical importance, as it implies that

the distribution process will not cause the model to

behave in unexpected ways (note that this lemma is

about the collection of all runs, and does not claim

that if the distributed and centralized models are run

side-by-side, they will produce the same run). In other

words, one can study and analyze the centralized ver-

sion of the model (which is far easier for humans

to grasp and comprehend, and for tools to analyze)

and the conclusions will apply to the distributed set-

ting too. We will discuss some of the implications of

this result in Section 6. The lemma is proved in Ap-

pendix 8.

At ﬁrst glance, the requirement that communica-

tion be instantaneous might seem unrealistic. How-

ever, in practice we make no such assumptions and

our technique can also be used where communication

is delayed due to various reasons, as discussed in the

next section.

3.5 Dealing with Latency

Once we relax our assumption that communication la-

tency and external-event processing is instantaneous,

the distributed system’s behavior may diverge from

that of the centralized case in a number of ways.

1. Inter-component Decisions: In section 3.3 we

described how multiple components may need to

synchronize in order to proceed in a state that

they all control. As a simple example, consider

a model with a single b-thread and a single syn-

chronization point, in which two events, a and b,

are simultaneously requested. Clearly, executing

this model will result in either a or b getting trig-

gered.

Now, suppose that we distribute this program with

the strict event separation {E

= {a}, E

= {b}}.

The projection process results in two component

models, C

and C

. In C

the projected single

thread will request a while waiting for b, and in

the projected thread will request b while wait-

ing for a.

In a no-latency situation, this is acceptable: no

matter which component performs event selection

ﬁrst, it will notify the second component immedi-

ately, resulting in either a or b getting triggered,

but not both. However, if communication is not

immediate, it is possible that component C

will

trigger a and component C

will trigger b, result-

ing in a behavior that the original model did not

have.

As each component knows at each state which

components control the b-thread, the solution

is simply to synchronize with them. Inter-

component decisions are handled entirely by our

distribution framework as outlined in Section 3.3

above.

2. Maintaining Order: It is possible for broad-

cast events to arrive at different components in

different orders, resulting in these components

having different views of the execution. Conse-

quently, projections of the same b-thread within

these components may be in different states. As

with inter-component decisions, this would create

inconsistent behavior.

Observe that this situation can only arise at system

Distributing Scenario-based Models: A Replicate-and-Project Approach

187

states where event-selection decisions that differ

across components result in transitions to differ-

ent successor states. Detecting these instances can

be performed ofﬂine by a model checker, or by an

online look-ahead mechanism. Once the poten-

tially problematic states are identiﬁed, the prob-

lem can be circumvented by having the distributed

components treat them as inter-component deci-

sion points, and perform inter-component syn-

chronization. Note that we assume that between

any two components, communications arrive or-

dered correctly. This can be guaranteed by TCP

or PGM, but not by protocols that allow out-of-

order delivery, such as UDP.

Another proposed solution is to synchronize the

clocks of the different components, and add a

time-stamp to each selected event. By delaying

the announcement of received external events and

selected local events to a component’s b-threads,

the ESM can interweave the events in the correct

order.

3. Accommodating Delays: Consider the following

example: a robot-driven car is approaching an in-

tersection, and in order to avoid collisions it must

communicate with other cars. However, if the

communication happens just before entering the

intersection, any delay or missed messages could

cause an accident.

In order to avoid this kind of issues, programs de-

signed for distribution should employ design pat-

terns and methods that take a realistic commu-

nication delay into account. E.g., checking for

other cars early, while approaching the intersec-

tion, rather than, say, relying on scenarios to block

all events of cars entering the intersection follow-

ing the occurrence of an event reporting that one

car already entered that intersection. We feel that

this is a valid assumption in designing distributed

systems and does not contradict or make redun-

dant the advantages of BP.

4 PER-COMPONENT

TIMESCALES

As explained earlier, in a centralized behavioral

model, all b-threads must synchronize in order for

the ESM to announce the selected event. The b-

thread that takes the longest to reach its synchroniza-

tion point (e.g., because it performs slow local cal-

culations or writes to a ﬁle) forces the rest of the b-

threads to wait until it synchronizes. This lockstep

execution thus results in the slowest b-thread dictat-

ing the timescale for the whole system. This is a com-

mon issue in behavioral models that involve multiple

scenarios operating on different timescales (see, e.g.,

(Harel et al., 2015a)), and it also applies to our dis-

tributed variant of BP: for example, a slower com-

ponent might experience delays before broadcasting

events that a faster component depends on, forcing the

latter to wait. Furthermore, external events can “pile

up”, increasing the processing time of future event se-

lections and delaying the selection of potentially cru-

cial events.

In this section we discuss how to allow the gen-

erated components to operate efﬁciently on different

timescales.

Previous work (Harel et al., 2015a) has tackled

this difﬁculty in a variety of ways. One approach

in (Harel et al., 2015a) introduced an eager execu-

tion mechanism for behavioral models. This tech-

nique lessened the severity of the problem by some-

times allowing the ESM to trigger an event even when

some of the b-threads have not yet synchronized. Our

distribution technique lends itself naturally to this

kind of idea, because within a given component, we

know that b-threads controlled by other components,

which have not synchonized yet, cannot block local

requested events. Thus, by applying a method similar

to eager execution, the ESM does not have to wait for

b-threads which wait only for external events (such b-

threads may be in the original speciﬁcation, or they

may be the projected version of b-threads with event

requests changed to waiting for events).

In our distributed setting, eager execution can be

applied as follows. Given a behavioral model M =

{BT

,...,BT

} and its distributed component mod-

els {C

,...,C

}, let q ∈ Q

be a state in which b-thread

is not controlled by component C

. Observe BT

i.e., the copy of BT

that is running in component C

Because BT

is not controlled by C

, it does not re-

quest or wait for any local events and must be waiting

for an external event e controlled by some other com-

ponent C

. In other words, until such time as e is

triggered by C

, thread BT

will not affect local event

selection in component C

. In such situations we pro-

pose to temporarily detach thread BT

from its local

ESM, effectively allowing event selection in compo-

nent C

without considering BT

. This allows com-

ponent C

to operate in its own pace, while BT

can

be regarded as temporarily operating in the same time

scale as C

. Whenever e is ﬁnally triggered and BT

reaches a new state ¯q in which it is controlled by C

, it

is reattached to the local ESM. This technique readily

enables different components to simultaneously oper-

ate at different timescales.

To support eager execution within our distributed

MODELSWARD 2017 - 5th International Conference on Model-Driven Engineering and Software Development

188

framework, the external event queue within each com-

ponent model needs to be decoupled from the dis-

tributed ESM. Instead, each b-thread in the compo-

nent receives its own external-event queue, and at

each synchronization point pops all external events

and selects them one at a time. The changes in the

BP execution engine are summarized as follows:

• Each b-thread should ﬂag itself as synchronized

or unsynchronized at each bSync, depending on

the state.

• A separate event queue is created in each b-thread,

thus allowing b-threads to process external events

independently of the local ESM. A b-thread that

arrives at a bSync ﬁrst empties its event queue by

repeatedly popping and selecting an event.

• External events received at a given component are

injected into all the b-thread event queues by the

component’s BP execution engine. B-threads that

are already awaiting the local ESM are notiﬁed to

handle the external events.

5 EXAMPLE AND EVALUATION

In many situations, participants, be they mechanical

entities or people, have to carry out actions “in turns”,

one participant after the other. A typical example is

the all-way-stop trafﬁc intersection (a.k.a. four-way

stop). When there are long queues in each of the in-

tersecting roads, the cars cross the intersection one

at a time, from each of the roads, in a round-robin

fashion. Another example is an audience in a packed

stadium “doing the wave”, where groups of people

stand up brieﬂy and then sit down, in sequential or-

der. These behaviors are very easily described using

scenario-based speciﬁcations, where the most basic

behavior can be described with one scenario show-

ing all the relevant entities performing their required

actions in turn (additional scenarios for, e.g., starting

such a wave, are beyond the scope of our discussion).

More speciﬁcally, we consider a simple drone-

based light show (see elaborate shows by Disney in

www.youtube.com/watch?v=gYr-PO9meHY, and by Intel

in www.youtube.com/watch?v=teQwViKMnxw): each of

four drones has a green light and a red light. Initially,

the drones “do the wave”, each ﬂashing its green light

brieﬂy, in turn. This is implemented by the scenario in

Algorithm 1. The scenario in Algorithm 2 shows the

projection of the scenario in Algorithm 1 to Drone1.

Our example is a slightly richer scenario, coded

as a behavioral program written in C++. The four

drones (labeled Drone0 through Drone3) participate

in “a green wave”, starting with Drone0. After the

i=0;

while true do

bSync(R = {FlashGreen((0 + i)%4)});

bSync(R = {FlashGreen((1 + i)%4)});

bSync(R = {FlashGreen((2 + i)%4)});

bSync(R = {FlashGreen((3 + i)%4)});

nextEvent =

bSync(R = {NW 0,NW 1,NW 2,NW 3});

i = indexOfWave(nextEvent);

end

Algorithm 1: Pseudocode of a BP scenario demonstrating

a simple undistributed wave example. For each bSync syn-

chronization point, R is set requested events. The events

NW0 through NW3 indicate a request the start a new wave

at the corresponding component. These events are re-

quested after each full cycle, and BP event selection then

decides which component starts the new wave. The method

indexOfWave translates an event NWi to the index i.

i=0;

while true do

bSync(W = {FlashGreen((0 + i)%4)});

bSync(R = {FlashGreen((1 + i)%4)});

bSync(W = {FlashGreen((2 + i)%4)});

bSync(W = {FlashGreen((3 + i)%4)});

nextEvent = bSync(R = {NW 1},W =

{NW 0, NW 2,NW 3});

i = indexOfWave(nextEvent);

end

Algorithm 2: Projection of the scenario of Algorithm 1

onto the component Drone1. Notice that requested events

controlled by other components become waited-for (repre-

sented by the W sets).

conclusion of two full cycles, the drones jointly de-

cide which of the drones will start the next wave. The

next wave will, again, last for two full cycles, and the

entire process repeats ﬁve times. For now, the entire

speciﬁcation consists of a single scenario. In this im-

plementation, the light-ﬂashing events are labeled as

FlashGreen0 through FlashGreen3, each representing

the ﬂashing of the light in the respective drone, in ei-

ther a centralized or distributed implementation. The

selection of the drone that will start the next wave

is carried out by the scenarios requesting four “new

wave” events, NW0 through NW3, and the BP event-

selection mechanism arbitrarily selecting one of these

events. We then associate each of the FlashGreen and

the NW events with the corresponding component. In

this simpliﬁed example the duration of the ﬂashing of

each light is implemented in a delay (sleep) of 250

msec in the b-thread that is about the request a Flash-

Green event.

For simplicity, this implementation uses a cen-

tralizer component and does not implement a leader-

election mechanism. The centralizer is an infrastruc-

Distributing Scenario-based Models: A Replicate-and-Project Approach

189

ture component which is responsbile for: (i) receiv-

ing notiﬁcations of events triggered in any behavior

components, and broadcasting this information to all

other components, and (ii) managing joint decisions,

by receiving notices from any component ESM that

wishes to synchronize, which include the sets of re-

quested and blocked events, waiting for all other com-

ponents to reach their corresponding state, selecting

an event which is requested and not blocked, and no-

tifying all components of the selection. Note that the

centralizer serves only in simulations and studies of

the approach, and that in real distributed implementa-

tions broadcasting can be performed by a vartiety of

techniques (including the above), and joint decisions

can be reached by classical distributed-processing so-

lutions, such as leader election.

At this point it is important to distinguish between

the concepts of classes and objects and the concept

of components as used here. Events may be self-

standing entities, or they may be associated with ob-

jects. In our example, each drone is a component,

and objects may reside within a component, or may

span multiple component. Such objects can be, e.g.,

a drone controller, a drone light, a wave effect (which

can have a beginning and end events, or a color prop-

erty) or an entire light show. As can be seen in the

example given in Algorithm 2, each component exe-

cutes “the entire speciﬁcation”, in this case, this one

scenario. In the distributed implementation, when

scenarios request or wait for FlashGreen events, they

do not synchronize, but when they request the four

new wave events, they all synchronize. This results

in a partially synchronized execution, which mimics

the centralized execution but does so with less inter-

component synchronization.

We compare our target, partially synchronized ex-

ecution of a speciﬁcation created with the replicate-

and-project implementation (abbr. R&P), with a fully

synchronized distributed execution (abbr. FS), where

each component executes the same speciﬁcation, and

they synchronize with every event selection. The de-

cision in each component whether to actually turn

on its own light following its respective FlashGreen

event is left as a small implementation detail, i.e., the

light-switch actuation method skips the operation if

there is no direct connection with the device. Both

implementations execute the same one-scenario spec-

iﬁcation, replicated over four components. The to-

tal number of events that occurred, all of which were

broadcast to all components, is 44 — the same for FS

and for R&P (ﬁve repetitions of two four-event cycles,

and four joint decisions). In the R&P however, only

four of these required synchronization. The total ex-

ecution time was the same in both cases, dominated

by the duration of the light ﬂashes, but if synchro-

nization delay is artiﬁcially increased, total execution

time is increased accordingly (e.g., a 100 msec delay

purely due to synchronization, in addition to any or-

dinary communication delay, would add 400 msec to

the duration of each cycle of this single wave).

We now extend our mini-light-show example with

another wave of ﬂashing lights. We add a scenario

in which, starting with Drone2, each of the drones

brieﬂy ﬂashes a red light, in its turn. This multi-cycle

wave continues uninterrupted and with no change un-

til the ten cycles of the green wave terminate. The

delay (sleep) before requesting a FlashRed event is

1000 msec. When multiple events are requested e.g.,

both a FlashRed together with FlashGreen or NW, the

ESM selects an event at random. The forty Flash-

Green events in the ten-cycles determine the begin-

ning and end of the run, and the number of FlashRed

events selected during this time varies. Since we are

presently more interested in understanding the under-

lying effects than in measuring improvements over a

large number of runs, we sufﬁce with this artiﬁcial ex-

ample. To highlight these effects we show in Table 1

a comparison of the two cases when in both FS and

R&P, 44 FlashGreen events were triggered.

The basic communication delay in these experi-

ments is set to 50 msec, resulting in 100 msec delay

for broadcasting an event occurence via the central-

izer.

Some interesting explanations and observations

include:

• In FS, at every synhcronization point, both a

FlashRed event, and, either a FlashGreen or NW

events are enabled. This is true regardless of

sleep delays and number of components. Hence

in such runs, on average, half of the events will

be FlashRed. By contrast in R&P, FlashRed is

enabled in a component together with one of the

other two events in a way that depends on lengths

of sleep delays and on the number of components

in the cycle, yielding, in our case fewer FlashRed

events during the run.

• Common to all runs is a 40∗250 msec taken by the

FlashGreen events, plus 4 ∗ 100 msec minimum

number of joint decisions, plus about 3 seconds

of overhead (total of 13-14 seconds).

• The 41 seconds duration of R&P is the result of

adding to the above ~13 seconds 28 ∗ 1000 msec

FlashRed events.

• The 67 seconds duration of FS is the result of

adding to the above 41 seconds of R&P 17 ∗ 1000

msec of additional FlashRed events and 85 ∗ 100

msec communication delays due the additional

MODELSWARD 2017 - 5th International Conference on Model-Driven Engineering and Software Development

190

synchronizations, all of which had to occur dur-

ing the same ten cycles of the green wave.

• Even though the total number of events triggered

in R&P is less than in FS, the per-second event

rate is higher.

While the above examples illustrate and quantify the

kind of savings resulting from reduced synchroniza-

tion, we must note that the synchronization delay it-

self is sometimes not the main issue. For exam-

ple, if we were to replace the FlashGreen event(s)

in our design with, e.g., pairs of TurnGreenLightOn

and TurnGreenLightOff events, all scenarios might

have had enough time to synchronize with each other

following the event TurnGreenLightOn, in parallel

to waiting for the time ticks that would signal the

end of the shining of the light. A relaxed synchro-

nization approach, separating the scenarios of the

two waves into separate modules within each com-

ponent, would further streamline an otherwise fully

synchronized implementation. Nevertheless, the re-

duced inter-component synchronization still helps in

simplifying the designs, and in enhancing system ro-

bustness. For example, consider recovering from loss

of a drone, due to battery running out, while “the show

must go on”. It is much easier for all drones to ob-

serve and react to delays in other drones’ behavior,

when they are fully functional as opposed to waiting

in a global synchronization point (even when the lat-

ter is enhanced with timeout facilities as in (Harel and

Katz, 2014)).

6 FORMAL ANALYSIS AND

FUTURE WORK

Previous research on scenario based programming has

shown the great importance of formal methods and

tools in ensuring that the resulting models, composed

of many individual scenarios, perform as intended as

a whole. Past efforts have yielded a large portfolio

of tools for model checking (Harel et al., 2011a), au-

tomatic repair (Harel et al., 2012a; Katz, 2013) and

compositional veriﬁcation (Katz et al., 2015; Harel

et al., 2013b), and have even indicated that scenario-

based programming may be more amenable to formal

analysis than other modeling approaches (Harel et al.,

2015c; Harel et al., 2015b).

Given the above, applying formal analysis in

the distributed case seems even more vital, as dis-

tributed models are inherently more difﬁcult for hu-

mans to comprehend than centralized ones. Fortu-

nately, Lemma 1 enables us to immediately apply ex-

isting tools in our setting. Because the centralized

and distributed models present the same behavior, it

is possible to apply existing approaches to the cen-

tralized version and use them to draw conclusions re-

garding the distributed case.

Nonetheless, in a distributed environment there

are some hazards that do not appear in the fully-

synchronized model, and may thus be overlooked by

existing tools:

• Inter-component Deadlock: An inter-

component deadlock occurs when a component

C has no enabled local events that it can trigger,

and is thus waiting for certain external event(s).

However due to various reasons, these external

events may never arrive. For example, the reason

might be that another component is actually

waiting for an event that C needs to trigger. Note

that a situation where a component is waiting on

events local to a crashed component is not an

inter-component deadlock, but a soft deadlock, as

restarting the failed component might resolve the

issue.

• External Event Queue Overﬂow: When a com-

ponent repeatedly takes longer to process exter-

nal events than it takes the other components to

trigger and broadcast these events, could result in

exceeding the memory available for the external

event queue. An example of this could be a log-

ger component that takes too long to post its log

entries to a remote location.

• Latency: Communication delays can cause

poorly-designed systems to exhibit undesired be-

havior. As we discussed in Section 3.4, Lemma 1

does not hold when latency is too high, and so

such errors cannot be detected by existing tools.

We are working on extending the presently avail-

able techniques to handle the issues listed above.

For instance, in the latency case an improved model

checking algorithm might simulate a realistic latency

for external event communication, depending on the

communication method used (e.g., wired communi-

cations over a local network will have a much lower

latency than a satellite connection). We are also ex-

ploring the use of quantitative approaches to formal

veriﬁcation to attempt and derive bounds on the max-

imal size a queue can reach, given certain constraints

on the broadcast and processing times of system com-

ponents.

In the context of inter-component deadlock, one

approach for recovering from component failure or

missed messages could be adding state information

to the external events, permitting components that

missed a transition to “fast-forward” to the correct

state in a scenario. Another direction could involve

Distributing Scenario-based Models: A Replicate-and-Project Approach

191

Table 1: Comparing an execution of a fully synchronized (FS) implementation of a two-scenario speciﬁcation in a four-

component conﬁguration, to an execution of the partially synchronized replicate-and-project implementation (R&P). See

discussion in the Section 5.

Measure: FS R&P

Number of FlashGreen event notiﬁcation broadcast 40 40

Number of FlashRed event notiﬁcation broadcast

∗

45 28

Number of “new wave” event notiﬁcation broadcast 4 4

Total number of events 89 72

Total number of Inter-component synchronizations 89 4

Run duration (in seconds) 67 41

Events per second 1.32 1.75

having multiple instances of critical components, for

redundancy.

As an additional future work direction, we would

like to study approaches to choosing a strict event sep-

aration. While the components are usually derived

manually from physical system requirements, at times

it might be desired to delineate their boundaries auto-

matically based on other criteria. One approach is to

use clustering algorithms that take as input a func-

tion f that assigns, for every two events e

∈ Σ

a correlation value f (e

) ∈ [−1,+1]. The clus-

tering algorithms then attempt to partition the events

into a strict separation into k components (with k ei-

ther known or unknown beforehand), such that two

events are in the same component if their correlation

is high and are in separate components if their cor-

relation is low. While this problem is known to be

NP-Complete, it can be approximated up to a log-

factor (Bansal et al., 2004).

7 RELATED WORK

A different framework for the distributed execution

of scenarios is presented in (Greenyer et al., 2015).

Their approach is similar to ours in that the distributed

components can each choose to execute events that

they are responsible for, and selected events are

broadcast to all other components. The main issues

with this implementation relative to R&P are that (i)

it requires that scenarios are written to not have states

where events of multiple components are enabled, and

(ii) it relies on the fact (enforced by a central coor-

dinator) that all components observe all event occu-

urrences in the same order. By contrast, R&P au-

tomatically coordinates all components when reach-

ing a state where a joint decision is required, and it

allows components to advance asynchronously when

possible, and in particular, after locally selecting an

event. An advantage, though, of the enforced event

order in (Greenyer et al., 2015) is that it avoids the

risk of sensivity to different event orders. In R&P,

automatic handling of the latter is left for future re-

search, e.g. using formal methods, as discussed in

Section 3.5.

The research in (Greenyer et al., 2016b) describes

(though without an implementation) a mechanism for

the distributed execution of scenarios with dynamic

role bindings. There, synchronization is done only

among relevant components, as determined dynami-

cally.

An orthogonal approach proposed for distributing

BP models (Harel et al., 2013a) is by partitioning the

b-threads into modules, where each module runs its

set of b-threads and synchronizes with other modules

upon choosing events that might matter to other mod-

ules. However, in (Harel et al., 2013a), the component

structure is dynamic and is implied by the speciﬁca-

tion, in contrast to the present paper where the com-

ponent structure is dictated by the physical structure

of the system.

Yet another alternative approach is suggested in

(Harel et al., 2011b), where the distributed system

consists of multiple independent programs, called be-

havior nodes (b-nodes), each with its own set of inter-

nal events. Such b-nodes never synchronize with each

other. Similar to our approach the b-nodes communi-

cate by external events, however those events require

manual translation to and from internal events. By

contrast, in our approach external events emerge natu-

rally and automatically from internal events. Further-

more our approach supports more general designs,

inter-component scenarios and ﬁne-grained synchro-

nizations when scenarios give rise to inter-component

decisions.

There has also been work on synthesizing

scarcely-synchronizing distributed controllers from

scenario-based speciﬁcations (Brenner et al., 2015).

Distributed ﬁnite automaton controllers can be syn-

thesized from scenario speciﬁcations in a way that

greatly reduces communication overhead compared

to previous approaches, especially compared to the

the broadcasts of events as also suggested in this

work. However, the synthesis procedure is computa-

MODELSWARD 2017 - 5th International Conference on Model-Driven Engineering and Software Development

192

tionally complex and does not scale well as speciﬁca-

tion and system size increase. In (Fahland and Kantor,

2013), the authors study a similar problem and present

an approach for synthesizing executable implementa-

tions from speciﬁcations given in a distributed variant

of LSC, termed dLSC.

Outside the scope of scenario-based modeling,

the trade-off between performance optimization and

communication minimization in parallel and dis-

tributed settings has been studied extensively. These

two conﬂicting goals are discussed in (Cheng and

Robertazii, 1988; Yook et al., 2002). In (van Gemund,

1997) the author suggests imposing certain limita-

tions on the communication between the components,

thus allowing for execution-time optimization to be

performed during compilation.

8 CONCLUSION

We presented an approach towards transforming a

scenario-based model so that it can be executed in

a distributed conﬁguration, by creating component-

speciﬁc variations, or projections, based on each com-

ponent’s scope of responsibility. This replicate-and-

project approach allows us to distribute any central-

ized model based on speciﬁcations which can be de-

rived from practical physical requirements, such as

number of processors and the speciﬁc hardware con-

trolled by each of them. We have shown that the

resulting distributed models behave similarly to the

centralized model from which they originated. This

important property allows us to carry out most of

the modeling work, including testing and analysis,

in the centralized setting, which is easier to model-

check and reason about. The projected models retain

the naturalness and incrementality traits of behavioral

programming. In their avoidance of excessive syn-

chronization, they improve robustness and the ability

to model systems with multiple time scales. To the list

of future research avenues which this direction opens,

one may add the possibility that replicate-and-project

approaches may be applicable in software develop-

ment contexts other than scenario-based / behavioral

programming.

ACKNOWLEDGEMENTS

This work is funded by grants from the German-

Israeli Foundation for Scientiﬁc Research and Devel-

opment (GIF) and from the Israel Science Foundation

(ISF).

REFERENCES

Alexandron, G., Armoni, M., Gordon, M., and Harel, D.

(2014). Scenario-Based Programming: Reducing the

Cognitive Load, Fostering Abstract Thinking. In Proc.

36th Int. Conf. on Software Engineering (ICSE), pages

311–320.

Bansal, N., Blum, A., and Chawla, S. (2004). Correlation

Clustering. Machine Learning, 56(1–3):89–113.

Brenner, C., Greenyer, J., and Sch

afer, W. (2015). On-the-

Fly Synthesis of Scarcely Synchronizing Distributed

Controllers from Scenario-Based Speciﬁcations. In

Proc. 18th Int. Conf. on Fundamental Approaches to

Software Engineering (FASE), pages 51–65.

Cheng, Y. and Robertazii, T. (1988). Distributed Com-

putation with Communication Delay [Distributed In-

telligent Sensor Networks]. IEEE Transactions on

Aerospace and Electronic Systems, 24(6):700–712.

Damm, W. and Harel, D. (2001). LSCs: Breathing Life into

Message Sequence Charts. J. on Formal Methods in

System Design, 19(1):45–80.

Eugster, P., Felber, P., Guerraoui, R., and Kermarrec, A.

(2003). The Many Faces of Publish/Subscribe. ACM

Computing Surveys (CSUR), 35(2):114–131.

Fahland, D. and Kantor, A. (2013). Synthesizing Decen-

tralized Components from a Variant of Live Sequence

Charts. In Proc. 1st Int. Conf. on Model-Driven

Engineering and Software Development (MODEL-

SWARD), pages 25–38.

Ghosh, S. and Gupta, A. (1996). An Exercise in Fault-

containment: Self-stabilizing Leader Election. Inf.

Process. Lett., 59(5):281–288.

Gordon, M., Marron, A., and Meerbaum-Salant, O. (2012).

Spaghetti for the Main Course? Observations on

the Naturalness of Scenario-Based Programming. In

Proc. 17th Conf. on Innovation and Technology in

Computer Science Education (ITICSE), pages 198–

203.

Greenyer, J., Gritzner, D., Gutjahr, T., Duente, T., Dulle,

S., Deppe, F.-D., Glade, N., Hilbich, M., Koenig,

F., Luennemann, J., Prenner, N., Raetz, K., Schnelle,

T., Singer, M., Tempelmeier, N., and Voges, R.

(2015). Scenarios@run.time — Distributed Execution

of Speciﬁcations on IoT-Connected Robots. In Proc.

10th Int. Workshop on Models@Run.Time (MRT),

pages 71–80.

Greenyer, J., Gritzner, D., Katz, G., and Marron, A.

(2016a). Scenario-Based Modeling and Synthesis for

Reactive Systems with Dynamic System Structure in

ScenarioTools. In Proc. 19th Int. Conf. on Model

Driven Engineering Languages and Systems (MOD-

ELS), pages 16–32.

Greenyer, J., Gritzner, D., Katz, G., Marron, A., Glade,

N., Gutjahr, T., and K

onig, F. (2016b). Distributed

Execution of Scenario-based Speciﬁcations of Struc-

turally Dynamic Cyber-Physical Systems. In Proc.

3rd Int. Conf. on System-Integrated Intelligence: New

Challenges for Product and Production Engineering

(SYSINT), pages 552–559.

Distributing Scenario-based Models: A Replicate-and-Project Approach

193

Harel, D., Kantor, A., and Katz, G. (2013a). Relaxing Syn-

chronization Constraints in Behavioral Programs. In

Proc. 19th Int. Conf. on Logic for Programming, Arti-

ﬁcial Intelligence and Reasoning (LPAR), pages 355–

372.

Harel, D., Kantor, A., Katz, G., Marron, A., Mizrahi, L.,

and Weiss, G. (2013b). On Composing and Proving

the Correctness of Reactive Behavior. In Proc. 13th

Int. Conf. on Embedded Software (EMSOFT), pages

1–10.

Harel, D., Kantor, A., Katz, G., Marron, A., Weiss, G., and

Wiener, G. (2015a). Towards Behavioral Program-

ming in Distributed Architectures. Science of Com-

puter Programming, 98(2):233–267.

Harel, D. and Katz, G. (2014). Scaling-Up Behavioral Pro-

gramming: Steps from Basic Principles to Applica-

tion Architectures. In Proc. 4th Int. Workshop on Pro-

gramming based on Actors, Agents, and Decentral-

ized Control (AGERE!), pages 95–108.

Harel, D., Katz, G., Lampert, R., Marron, A., and Weiss, G.

(2015b). On the Succinctness of Idioms for Concur-

rent Programming. In Proc. 26th Int. Conf. on Con-

currency Theory (CONCUR), pages 85–99.

Harel, D., Katz, G., Marelly, R., and Marron, A. (2016).

An Initial Wise Development Environment for Behav-

ioral Models. In Proc. 4th Int. Conf. on Model-Driven

Engineering and Software Development (MODEL-

SWARD), pages 600–612.

Harel, D., Katz, G., Marron, A., and Weiss, G. (2012a).

Non-Intrusive Repair of Reactive Programs. In Proc.

17th IEEE Int. Conf. on Engineering of Complex Com-

puter Systems (ICECCS), pages 3–12.

Harel, D., Katz, G., Marron, A., and Weiss, G. (2015c). The

Effect of Concurrent Programming Idioms on Veri-

ﬁcation. In Proc. 3rd Int. Conf. on Model-Driven

Engineering and Software Development (MODEL-

SWARD), pages 363–369.

Harel, D., Kugler, H., Marelly, R., and Pnueli, A. (2002).

Smart Play-Out of Behavioral Requirements. In Proc.

4th Int. Conf. on Formal Methods in Computer-Aided

Design (FMCAD), pages 378–398.

Harel, D., Lampert, R., Marron, A., and Weiss, G. (2011a).

Model-Checking Behavioral Programs. In Proc. 11th

Int. Conf. on Embedded Software (EMSOFT), pages

279–288.

Harel, D. and Marelly, R. (2003a). Come, Let’s Play:

Scenario-Based Programming Using LSCs and the

Play-Engine. Springer.

Harel, D. and Marelly, R. (2003b). Specifying and Execut-

ing Behavioral Requirements: The Play In/Play-Out

Approach. Software and System Modeling (SoSyM),

2:82–107.

Harel, D., Marron, A., and Weiss, G. (2012b). Behav-

ioral Programming. Communications of the ACM,

55(7):90–100.

Harel, D., Marron, A., Weiss, G., and Wiener, G. (2011b).

Behavioral Programming, Decentralized Control, and

Multiple Time Scales. In Proc. 1st SPLASH Work-

shop on Programming Systems, Languages, and Ap-

plications based on Agents, Actors, and Decentralized

Control (AGERE!), pages 171–182.

Harel, D. and Segall, I. (2011). Synthesis from live se-

quence chart speciﬁcations. Computer System Sci-

ences. To appear.

Katz, G. (2013). On Module-Based Abstraction and Re-

pair of Behavioral Programs. In Proc. 19th Int. Conf.

on Logic for Programming, Artiﬁcial Intelligence and

Reasoning (LPAR), pages 518–535.

Katz, G., Barrett, C., and Harel, D. (2015). Theory-Aided

Model Checking of Concurrent Transition Systems. In

Proc. 15th Int. Conf. on Formal Methods in Computer-

Aided Design (FMCAD), pages 81–88.

Miller, C. and Poellabauer, C. (2009). A Decentralized Ap-

proach to Minimum-Energy Broadcasting in Static Ad

Hoc Networks. In Proc. 8th Int. Conf. on Ad-Hoc, Mo-

bile and Wireless Networks (ADHOC-NOW), pages

298–311.

Ramadge, P. and Wonham, W. (1987). Supervisory Control

of a Class of Discrete Event Processes. SIAM J. on

Control and Optimization, 25(1):206–230.

Stefanescu, A., Esparza, J., and Muscholl, A. (2003). Syn-

thesis of Distributed Algorithms Using Asynchronous

Automata. In Proc. 14th Int. Conf. on Concurrency

Theory (CONCUR), pages 27–41.

van Gemund, A. (1997). The Importance of Synchroniza-

tion Structure in Parallel Program Optimization. In

Proc. 11th Int. Conf. on Supercomputing (ICS), pages

164–171.

Yook, J., Tilbury, D., and Soparkar, N. (2002). Trading

Computation for Bandwidth: Reducing Communica-

tion in Distributed Control Systems Using State Esti-

mators. IEEE Transactions on Control Systems Tech-

nology, 10(4):503–518.

Appendix: Proof for Lemma 1

Here we discuss the execution semantics of our dis-

tributed model, show that they produce runs that are

compatible with the BP semantics, and prove an im-

portant property: assuming communication is instan-

taneous, the distributed system behaves identically to

the undistributed one.

Deﬁnition 2. A distributed model produced from a

behavioral model M, with respect to a strict event sep-

aration, S = {C

,...,C

}, denoted as D (M,S), is de-

ﬁned to be the set of projections of M along the com-

ponents of the event separation:

D (M) = {project(M,C

),...,project(M,C

)}.

Executing a distributed model means executing the

component models (i.e., the projections) according to

the operational semantics deﬁned in Section 3.3.

Next we formally deﬁne the global state (the cut)

of a behavioral model that is being executed:

MODELSWARD 2017 - 5th International Conference on Model-Driven Engineering and Software Development

194

Deﬁnition 3. Given a behavioral model M =

{BT

,...,BT

}, the program cut r ∈ Q

× · · · ×Q

deﬁned to be the current model state: r = hq

,...,q

where q

is the current state of b-thread BT

For the remainder of this section we assume that

the inter-component communication latency is negli-

gible, and that external-event processing is instanta-

neous. This allows us to assume that selected events

can be ordered serially. Given these conditions, we

can make the following observation:

Claim 1. In a distributed execution of D(M, S), the

cuts of all component models are identical at every

point in time.

Proof. The proof is by induction. For the basis of the

induction, observe that in the execution of D(M,S)

all components begin at the same initial program cut

,...,q

i. Next, for the inductive step, suppose that

all components are currently in cut hq

,...,q

i. Once

any component selects an events e ∈ Σ, that event is

instantly broadcasted and processed by the rest of the

components. Each projected b-thread BT

in compo-

nent C

transitions to state δ

,e). By deﬁnition of

the projection process, the δ

functions are identical

across components, and hence all projections of each

thread proceed to the same successor state. The claim

follows.

As the component programs cuts are identical

across all components, we can extend the deﬁnition

and refer to program cut of a distributed system as

the program cut of any of the components.

Deﬁnition 4. An enabled event at some program cut

of behavioral model M is an event that is requested

by some b-thread and is not blocked by any of the b-

threads of M. Analogically, for a distributed system

D (M) an enabled event is an event requested by some

b-thread of some component, and not blocked by any

b-thread of any component.

Deﬁnition 5. Let ∆(r,e) denote the program cut

transition function, where r is a program cut and

e ∈ Σ is an event. ∆ is fully deﬁned by the b-

threads state transition function δ

as follows: for

r = hq

,...,q

i,∆(r, e) = hδ

,e),...,δ

,e)i.

We can now deﬁne what the formal language gen-

erated by a behavioral model is and prove that the lan-

guages of the undistributed model and the distributed

one are the same.

Deﬁnition 6. The language L of a behavioral model

M denoted L(M) is a set of words deﬁned over the

alphabet Σ. A word w = e

...e

... is in L(M) if its

letters constitute a legal run of M; i.e., if we begin in

the initial cut and apply ∆ according to the sequence

of events in w, the next event is always enabled in the

current cut. The language of the distributed model

D(M,S) is deﬁned similarly.

The equality between L(M) and L(D (M,S)) will

follow from the following claim:

Claim 2. At any given program cut r = hq

,...,q

the sets of all enabled events of M and of D(M, S) are

equal.

Proof. By deﬁnition, the set of enabled events of M

is (

)) \ (

)). In the distributed model

D(M,S), as components cannot block external events,

the set of enabled events is the union of sets of enabled

events of each component:

[

)

[

)

[

)

[

)

∩C

[

)

[

)

which is identical to the set of enabled events of M.

Claim 3. The language of a behavioral model L(M)

is equal to the language of its distributed version

L(D(M,S)).

Proof. As the thread transition functions are un-

changed by the projection, it immediately follows

that, for any cut r and event e, ∆(r, e) is equal in M

and in D(M,S). Furthermore we saw in claim 2 that

the enabled events of M and D(M,S) are equal at any

given program cut. Finally, as the initial cuts for M

and D(M,S) are identical, it follows by induction that

both models generate the same language.

Thus, when ignoring communication latency, the

distributed system operates indistinguishably from

the original undistributed one. This also implies that

the distributed model behaves correctly, i.e., produces

executions that are allowed under BP semantics.

Distributing Scenario-based Models: A Replicate-and-Project Approach

195
