A Trust Reputation Architecture for Virtual Organization Integration in

Cloud Computing Environment

Luis Felipe Bilecki

, Adriano Fiorese

and Fernando Matos

Department of Computer Science (DCC), Santa Catarina State University (UDESC), Joinville, Brazil

Department of Computer Systems (DSC), Federal University of Para

ıba (UFPB), Jo

ao Pessoa, Brazil

Keywords:

Trust, Virtual Organization, Reputation, Cloud Computing, Collaborative Networks.

Abstract:

Virtual Organization (VO) represents a prominent collaboration initiative, where a set of entities share compe-

tencies and risks attending a common goal. Moreover, their interactions can be supported in an Internet basis,

using Cloud Computing (CC) resources. The VO and CC integration brings several beneﬁts, such as: reduc-

tion of costs and maintenance, interoperability, among others. However, there are issues related to privacy,

trust and security that need to be addressed. One of the issues observed is how much trust VO members put

in the cloud provider (CP), particularly, in a scenario where VO members use the resources provided by a CP

to made available their services and in order to interact with other members. Thus, the proposed reputation

architecture intends to assist the decision-making processes present in the VO’s life-cycle reputing CP trust.

The reputed trust is based on two sources: a) objective (Quality of Service (QoS) indicators) and b) subjective

(feedback from users regarding those QoS indicators). The evaluation results show that the architecture is

resilient to attacks on subjective trust during the reputation calculation. Also, it is possible to note that the

proposed architecture presents an acceptable average time for each one operation, and a signiﬁcant role during

VO’s creation and operation.

1 INTRODUCTION

The socioeconomic challenges faced by society (e.g.

globalization and competitiveness), have motivated

small and medium-sized enterprises in the adoption of

collaborative methodologies, reducing time and costs

of the production process (Esposito and Evangelista,

2014).

Virtual Organization (VO) is a collaborative net-

work where via a temporary alliance, a set of legally

independent entities (enterprises), heterogeneous and

geographically disperse, share resources, skills, capa-

bilities and risks in order to attend a collaboration op-

portunity (Camarinha-Matos et al., 2009). VOs may

use technologies such as Cloud Computing, to sup-

port the transactions between people and enterprises.

In the cloud based scenario presented in (Ruaro

and Rabelo, 2016), the exchange of information, host-

ing and execution of applications are performed in the

cloud. This means that VO members can use cloud

resources to execute and provide their services and

information.

In this sense, Cloud Computing (CC) acts as a

technology that provides access to computing re-

sources (e.g. infrastructure and applications) on

a practical and on-demand way (Mell and Grance,

2011).

This integration between VO and CC, presents

some beneﬁts, such as: cost reduction, competitive

advantage, resources provided according to demand,

among others (Ruaro and Rabelo, 2016). However,

some issues could arise, such as: security, search

and selection of cloud providers, and trust assess-

ment (Noor et al., 2013). A particular challenge con-

cerns the trust assessment from VO members to CC

providers. This is an important issue since trust plays

a signiﬁcant role in the collaboration opportunity at-

tendance (Arenas et al., 2010), because VO members

use the provided resources as a support to execute

their activities.

Considering the trust issue in this environment,

this work presents a trust reputation architecture to

support the several decision-making processes exist-

ing in the VO’s life-cycle. The proposed reputation

architecture is responsible for generate the trust indi-

cators for reputation from two sources (objective and

subjective), disseminate reputation and attend other

requests through a centralized approach, monitor the

Bilecki, L., Fiorese, A. and Matos, F.

A Trust Reputation Architecture for Virtual Organization Integration in Cloud Computing Environment.

DOI: 10.5220/0006276506950702

In Proceedings of the 19th International Conference on Enterprise Information Systems (ICEIS 2017) - Volume 2, pages 695-702

ISBN: 978-989-758-248-6

695

objective source during VO’s operation, and receive

feedbacks from VO’s member to CC providers, in or-

der to update the cloud provider’s reputation.

Thus, the proposed architecture intends to cover

all stages and decision-making processes existing in

VO’s life-cycle. During the VO’s creation stage, the

reputation can be used as an indicator in the process

of cloud providers search and selection. In Opera-

tion stage, the reputation should be veriﬁed and eval-

uated. In the Evolution stage, a potential change of

cloud providers may be necessary, and ﬁnally, in Dis-

solution the transactions feedbacks are collected, in

order to update the subjective trust and consequently

the reputation of any cloud provider.

The remainder of this work is organized as fol-

lows. Section 2 presents the related concepts of this

work. Section 3 presents the proposed trust repu-

tation architecture. Section 4 presents the scenario

where simulations are performed, the parameters used

in simulation and shows and discusses results from

the evaluation. Finally, Section 5 presents the conclu-

sions and future work.

2 GENERAL BACKGROUND

2.1 Virtual Organizations and Cloud

Computing

Due to dynamic environment and market competitive-

ness, enterprises have been noticing need to work to-

gether in order to operate with greater agility and ﬂex-

ibility, joining collaborative networks to achieve com-

mon goals (Alawamleh and Popplewell, 2010).

A Virtual Organization (VO), a form of collabo-

rative network, is understood as a temporary alliance,

where a set of legally independent and heterogeneous

entities (usually enterprises) share skills, resources,

competences and risks, in order to achieve speciﬁc

business goals (to attend a collaboration opportunity)

(Camarinha-Matos et al., 2009). A striking and de-

cisive VO feature is the use of resources provided by

a communication infrastructure to obtain competitive

advantage. Thus, the VO is conﬁgured as a single en-

tity through the union of the core competencies of its

entities (Arenas et al., 2010).

The VO’s life-cycle is composed of several stages

(Camarinha-Matos et al., 2009). In the Creation stage,

partners are discovered, selected and the network is

conﬁgured. In Operation stage, partners interact and

exchange information to achieve a common goal. The

Evolution stage is performed during VO’s operation,

when minor changes occur in membership, roles or

operation principles. Finally, in the Dissolution stage,

the VO’s ﬁnishes its operation and this stage can oc-

cur in two ways, where the business objectives are

achieved successfully or due to serious problems in

operation that invalidates the VO’s existence.

The emergence of new concepts of information

and communication technologies (ICT), such as grid

computing and cloud computing, brought a new ap-

proach to VO and its operation, which could improve

its service quality and enhance market survival.

Cloud Computing (CC) can be deﬁned as a set

of computing resources (processing, storage, con-

nectivity, platforms, applications, and services) that

are available over the network (Internet) and can be

quickly provisioned without any human intervention

(Mell and Grance, 2011).

The main characteristics of cloud computing are:

on-demand self-service, resource pooling, broad net-

work access, rapid elasticity and measured services

(Mell and Grance, 2011). The CC provides services to

the users based on three different models, SaaS (Soft-

ware as a Service), PaaS (Platform as a Service), and

IaaS (Infrastructure as a Service) (Ruaro and Rabelo,

2016).

Through the mentioned models, small and

medium enterprises use these resources, for the de-

velopment of business systems and information shar-

ing in collaborative environment, that set up CC as a

infrastructure to support VO’s operation.

Nevertheless, the integration of CC and VO, of-

fer several beneﬁts. The necessary perception of trust

arouses the need for trust assessment, specially dur-

ing the several stages of VO’s life-cycle. The trust in

the cloud providers appears as a key element that can

jeopardize the collaboration opportunity during VO’s

operation. Thus, Section 2.2 presents trust and repu-

tation concepts and their relationship with VO.

2.2 Trust and Reputation

Trust is a multidisciplinary concept and it has been

used in many areas. Besides multidisciplinary, trust

is a complex concept and have different meanings on

each context.

A formal deﬁnition about the concept of trust is

provided by Gambetta (Gambetta et al., 2000): “trust

(or, symmetrically, distrust) is a particular level of the

subjective probability with which an agent assesses

that another agent or group of agents will perform a

particular action, both before he can monitor such ac-

tion (or independently of his capacity ever to be able

to monitor it) and in a context in which it affects his

own action”.

Thus, in a computational implementation, trust

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

696

can be deﬁned as a numeric value that indicates how

trustworthy an agent is, allowing others to consider

this value to decide whether or not to interact with

(Noor et al., 2013).

Some characteristics according to (Firdhous et al.,

2012) are common to any trust deﬁnition, they are:

helps to manage uncertain and high risk environ-

ments; it is used as a basis for decision-making; based

in objective or subjective source; based in historical

performance and past experience; context sensitive

and dynamic over time.

In a VO environment, the trust assessment is

guided by some requirements, such as: direct re-

lationship (non symmetric), subjective (feedbacks)

and/or objective (past performance) basis, automated

management and trust is dynamic over time and new

observations (Winkler et al., 2007).

The reputation concept is closely related to trust,

and can be used in VO environments to assess conﬁ-

dence from members to cloud providers (Bilecki and

Fiorese, 2016). Thus, reputation is deﬁned as a collec-

tion of feedbacks about an object, character, or related

to attributes of an entity (reliability, capability and us-

ability) (Resnick and Zeckhauser, 2002). Therefore,

in a VO and CC integration environment, reputation

should be based on objective indicators (Bilecki and

Fiorese, 2016) and subjective indicators (feedbacks)

(Noor et al., 2013).

Nevertheless, some threats on reputation systems

are described in literature, and these systems should

be robust to cope with the attacks. There are many

attacks types (Jøsang and Golbeck, 2009), however in

the VO and CC integration, some are considered, such

as: (i) Feedback Collusion: Set of fake feedbacks that

aims to maximize or decrease the reputation of an

entity; (ii) Unfair Rating: A VO’s member provides

malicious ratings to the CC provider, in order to in-

crease or decrease reputation level. In this attack, the

attacker can have a disproportionately inﬂuence over

computed reputation.

2.3 Related Work

With the prominent integration of CC as a form of

VO’s infrastructure, some contributions related to

trust assessment and management, should be ana-

lyzed as related work.

PathTrust (Kerschbaum et al., 2006), is a central-

ized reputation system applied to the search and se-

lection step during the VO’s formation. To partic-

ipate in the VO formation process, a member must

dissolution stage, each member sends his feedbacks

regarding the performed transaction with other mem-

bers. Thus, the utilization of a reputation system in

VO’s provides non-monetary beneﬁts. Conversely, it

provides a means to ensure a better or more reliable

service (Kerschbaum et al., 2006).

In (Arenas et al., 2010), a centralized reputation

system has been applied to a VO, which uses the Grid

Computing infrastructure. The reputation of each

user is evaluated according to the use of provided re-

sources and jobs, and the user evaluates the quality of

service provided by the service provider. Otherwise,

a reputation algorithm is applied in VO’s creation us-

ing cloud resources, where the resources are selected

according to cloud provider’s reputation (Pan et al.,

2013). However, the algorithm does not cover all the

VO’s life cycle stages.

In (Mashayekhy and Grosu, 2012) a VO’s forma-

tion mechanism based on reputation of Grid Service

Provider’s (GSP) is presented. This mechanism acts

in the integration between VO and Grid Computing,

where a key element is the GSP’s reliability regarding

the delivery of promised resources. The GSP reputa-

tion’s is based on their past interactions, to evaluate

how likely is to provide the requested resources. In

some cases, a GSP agrees to participate in VO, but it

fails to deliver the promised resources, affecting the

operation step.

Stochastic Reputation Service for Virtual Organi-

zations (STORE) (Haller, 2008) is a reputation system

in order to assist the decision-making process existent

in the VO’s creation. The trust indicator, used as repu-

tation model, represents an aggregation of a hierarchi-

cal indicators composed by ﬁnancial, operational, or-

ganizational, externals, and third-party indicators that

reﬂects the organizational’s performance.

Despite the small sample of related work, it is

possible to note that although one address the issue

of VO’s integration with CC, none of them provides

means to attend the several stages of the VO’s life-

cycle, and, few studies address the issue of trust and

reputation applied to VO’s integration with CC.

Thus, this work intends to cover the existent lack

of trust in the VO and CC integration, providing a

trust reputation architecture, where reputation is com-

posed by two trust sources (objective and subjective)

and this reputation will help in the several decision-

making process existent in VO’s life-cycle.

3 PROPOSED ARCHITECTURE

The emergence of new ICT concepts, such as cloud

computing, brought a new approach to VO and its op-

eration. The cloud computing provides computational

resources and the VO uses these resources to deliver

A Trust Reputation Architecture for Virtual Organization Integration in Cloud Computing Environment

697

its service in a distributed manner, geographically dis-

persed, thereby facilitating the collaboration process.

Hence, to build a trust indicator for reputation in a

VO and CC integration environment, the cloud com-

puting providers quality of service (QoS) properties

are exploited. In this integration scenario, the QoS

indicators represent an important role in trust assess-

ment, because the VO’s members are using the CC

resources to make available their systems and attend

the collaboration opportunity.

In order to assess and manage the trust in this sce-

nario, the reputation concept can be applied, aiming to

cover all stages in the VO’s life-cycle. Therefore, in

the proposed architecture, depicted in Figure 1, data

and reputation requests will be managed through a

centralized approach.

The reputation architecture comprises four mod-

ules, namely: monitoring module, data repository,

aggregation module and reputation broker service

(RBS). The Monitoring Module is responsible for

monitoring and updating QoS indicators of each CC

provider, during the VO’s operation stage. The Data

Repository stores historical and current values for

QoS indicators and VO’s members feedbacks. The

Aggregation Module is responsible for calculating the

reputation for CC providers based on QoS indicators

and users feedbacks. The RBS module is the inter-

face through which communication occurs with oth-

ers members. For example, the VO’s member can

send its feedback regarding a provider to RBS, or may

request a cloud provider’s reputation, at any time, to

RBS.

3.1 Aggregation Module

Reputation and trust systems are used in different

scenarios to assist someone in the choice of some-

thing that is reliable. In most e-commerce reputation

and trust systems, the trust is based on the feedbacks

given by consumers. Thus, in the VO environment us-

ing cloud resources, other sources of trust should be

considered too, such as SLA, QoS indicators, among

others, along with consumer feedbacks (Noor et al.,

2013).

Taking this into account, the main objective of

aggregation module is calculate the cloud computing

providers’ reputation, based on two sources of trust:

objective and subjective.

The objective trust indicator is related to QoS indi-

cators that reﬂect the performance of cloud computing

provider. In this work, objective trust is composed of

availability (A), response time (RT), security (S), sta-

bility (E) and cost (C) indicator (Garg et al., 2013).

The subjective trust is composed of the feed-

backs provided by VO’s members to cloud computing

providers. During the VO’s dissolution or operation,

a VO’s member sends its feedback related to QoS pro-

vided by its cloud computing provider.

During the reputation calculation, current objec-

tive values monitored by the monitoring module can

be also used together with the historical ones to take

a current reputation snapshot.

Thus, the reputation value R

of a cloud comput-

ing provider s, according Equation 1, is deﬁned as

a combination of objective and subjective trust indi-

cators by means of a weighted sum, where ω

ob j

and

sub

are the weights deﬁned by the VO’s manager,

ob j

(s) and T

sub

(s) are the objective and subjective

trust indicators, respectively.

= ω

ob j

∗T

ob j

(s) + ω

sub

∗T

sub

(s) (1)

3.1.1 Objective Trust

This section proposes a objective trust assessment

methodology for cloud computing provider, using the

aforementioned QoS indicators, where these indica-

tors are independent of cloud service model.

The objective trust (T

ob j

(s)), represented by Equa-

tion 2, is calculated by two approaches: analyzing the

efﬁciency (E f f (s)) of cloud providers based on the

historical QoS data and scoring the QoS indicators by

means of a multi-criteria approach (MC (s)).

ob j

(s) = E f f (s) ∗MC (s) (2)

The cloud providers’ (CP) efﬁciency is calculated

by the Data Envelopment Analysis (DEA) method.

The DEA is a nonparametric method that calculates

the relative efﬁciency of multiple decision-making

units (DMUs), where DMU refers an entity capable

to convert multiple inputs to outputs (Banker et al.,

1984).

Therefore, for DEA application, the input and out-

put should be modeled and are related to the QoS indi-

cators. Thus, the output (O

k j

) for each cloud provider

(k) as a DMU, represented by Equation 3, is under-

stood as the average of historical data (VO’s participa-

tions) for each QoS indicator ( j). Moreover, the stan-

dard deviation is considered due to a possible ﬂuctua-

tion in CP’s past performances.

k j

= H

k j

+ σ(H

k j

) (3)

The input data set (I

) is composed of the aver-

age of estimated values, by a linear regression from

the QoS indicators (i) historical ones for each cloud

provider (k). To generate the estimated values, the

linear regression is used, taking the ﬁrst and second

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

698

Reputation

Broker

Service

Reputation

Business

Partner

Cloud

Provider

Subjective

Evaluation

Update

Participation

Monitoring

Module

Reputation

Broker

Service

REPUTATION ARCHITECTURE

Aggregation

Module

Data

Repository

Operation

Evolution

Dissolution

Creation

Possible replacement of cloud providers

Figure 1: Conceptual Model Involving the Reputation Architecture.

historical values from QoS indicators and predicting

the third, and so on, until the n-nth historical partici-

pation. This approach is necessary to verify the CP

behavior at future VO’s participations. Equation 4

represents the input calculated for each indicator us-

ing the aforementioned method.

= X

− σ(X

) (4)

Thus, after the input and output data set deﬁnition,

the efﬁciency can be calculated. The efﬁciency is cal-

culated solving a DEA model through linear program-

ming. In this context, the DEA-BCC model output-

oriented (Banker et al., 1984) will be used, because

the output values are independent from the estimated

ones.

Also, the proposed objective trust also considers

a multi-criteria trust (MC (s)), understood as a score

which represents the importance assigned by the VO’s

manager to the QoS indicators. To calculate MC (s),

the comparison matrix of the Analytical Hierarchy

Process (AHP) multi-criteria method is used.

To determine the weights of indicators the Saaty’s

scale is used (Saaty, 1990). This scale is composed by

degrees of importance (from 1 to 9), where for exam-

ple, 9 represents the largest discrepancy between the

indicators. Through this scale, a judgment matrix is

created to perform a pairwise comparison of the QoS

indicators and by means of some normalization and

averaging processes result in the weight of each indi-

cator.

Therefore, multi-criteria trust (MC (s)), presented

in Equation 5, is calculated by multiplying the nor-

malized average historical QoS indicator values (A,

RT , S, E, and C) by their corresponding weights

...w

MC (s) = (w1 ∗A) + (w2 ∗RT ) + (w3 ∗S) +

(w4 ∗E) + (w5 ∗C)

(5)

3.1.2 Subjective Trust

The subjective trust assessment of a CP exploits

users’ ratings about the QoS provided. This subjec-

tive source was adapted from (Noor et al., 2013) and

these ratings are collected and stored by the proposed

architecture.

Each VO’s member gives its feedback, during

VO’s dissolution or operation stage, about the transac-

tion performed with a CP. The feedback is composed

by a set of ratings ranging from 0 to 5, to each one

of the QoS indicators. The subjective trust assess-

ment of a CP s made by a VO’s member c is seen

as Q

(c, s) and it is understood as a weighted sum of

all QoS ratings, where the weights are calculated ac-

cording the multi-criteria trust approach (see more in

Subsection 3.1.1).

Then, the subjective trust of a CP s, is calculated

as a ratio between the subjective assessments Q

(c, s)

given by the VO’s members c to a CP multiplied

by the credibility factor (C

(c, s)), and the total of

subjective assessments (|V (s)|). Thus, the subjective

trust is represented by Equation 6, in which n refers

to the VO’s members who evaluated a CP s.

sub

(s) =

∑

c=1

(c, s) ∗C

(c, s)

|V (s)|

(6)

The credibility factor allows to identify some mis-

leading feedbacks from attacks (Noor et al., 2013).

Particularly at the VO’s dissolution stage, the subjec-

tive trust should be evaluated, analyzing the credibil-

ity of the feedbacks’ set provided by a VO’s mem-

ber. The attack types presented in Section 2.2 are

A Trust Reputation Architecture for Virtual Organization Integration in Cloud Computing Environment

699

considered in the credibility analysis, where D(s) and

U(c,s), respectively, represent the feedback density

(collusion) and unfair rating attack.

Then, the credibility factor, presented by Equa-

tion 7, is understood as the average of these attack

factors multiplied by their weights (ρ and Ω) deter-

mined by the VO’s manager.

(c, s) =

(ρ ∗D(s)) + (Ω ∗U(c,s))

(7)

The feedback density (D(s)), exposed in Equa-

tion 8, aims to address the scenario where VO’s mem-

bers give numerous feedbacks to manipulate the sub-

jective trust (Noor et al., 2013). This factor consists of

the feedback mass M(s), which denotes the total num-

ber of VO’s members who gave feedback to a CP s,

|V (s)| represents the total number of feedbacks given

to a CP s, and L(s) represents the feedback collusion

factor.

D(s) =

M(s)

|V (s)|∗L(s)

(8)

The feedback collusion factor (L(s)), identiﬁed by

Equation 9, aims to reduce the credibility of those

VO’s members who send multiple feedbacks to the

same CP (Noor et al., 2013). This factor is calculated

as the ratio of the number of feedbacks given by VO’s

members |V

(c, s)|, who gave more feedbacks than

speciﬁed in volume collusion threshold e

(s), deﬁned

by VO’s manager, over the total of feedbacks received

by that CP s.

L(s) = 1 +

|V (s)|

∑

c=1

(c, s)|

[|V

(c,s)|>e

(s)]

(9)

Lastly, regarding unfair rating attacks, malicious

VO’s members give several misleading feedbacks, in

a period of time to promote or prejudice the subjec-

tive trust of a CP s. This attack can be identiﬁed by

applying a K-Means clustering algorithm, on all his-

torical feedbacks to form K clusters, and the centroid

of the most densely populated cluster is called major-

ity cluster (M) (Malik and Bouguettaya, 2009). Then,

the unfair rating factor (U(c, s)), is understood as the

euclidean distance between M and the reported rat-

ings (V

), where σ is the standard deviation, and n are

the total number of ratings for a VO’s member c.

U(c, s) =







1 −

√

∑

i=1

(M−V

)

, if

∑

i=1

(M −V

)

< σ

1 −

√

∑

i=1

(M−V

)

, otherwise

(10)

4 EXPERIMENTAL SCENARIO

AND RESULTS

An experiment scenario simulating VO and CC inte-

gration was developed to evaluate the proposed work.

This scenario, depicted in Figure 2, was built in a P2P

network simulator, called PeerFactSim.KOM (Stingl

et al., 2011). Thus, different network nodes are cre-

ated to represent each element presents in the pro-

posed architecture. The scenario concerns the ex-

change of messages and operations between VO’s

members and the proposed architecture, allowing to

evaluate trust assessment and reputation provided.

ARQ

Monitoring Node

CP1

CP2 CP3 CP n

...

RBS

Legend

Architecture Node

Cloud Provider Node

Enterprise Node

Figure 2: Experimental Scenario.

The following are the node types developed:

(i) Architecture Node (ARQ): receives messages des-

tined to architecture, such as feedback ratings

send operation, request reputation list, request

cloud provider’s reputation, and monitoring ac-

tions. This node has implemented the function-

ality of Reputation Broker Service (RBS);

(ii) Enterprise Node (En): it is a VO’s member in an

organized VO as a logical ring topology;

(iii) Cloud Provider Node (CP): represents the cloud

providers offering their services to the VO;

(iv) Monitoring Node: perform the QoS Monitoring of

each CP.

During the simulation step, the following parame-

ters were used: VO’s duration (simulation time 10080

min), ten cloud providers, ten historical participa-

tions, ten simulation rounds and, the weights for

each QoS indicator are deﬁned as: A (0.3830), RT

(0.2317), E (0.1861), S (0.1350), and C (0.0642), ob-

tained by means of multi-criteria trust assessment.

Thus, in the following sections the experimental re-

sults are presented.

4.1 Reputation

The reputation of a cloud provider’s s uses the his-

torical objective and subjective trust according to the

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

700

methodology proposed in the Section 3.1.

In this sense, to compose the historical objective

CP’s data, random values were generated to each one

QoS indicator. The values were generated through a

linear distribution, and the average values of ten past

participations are presented in Table 1, where each

column refers to QoS indicators.

Table 1: QoS Indicators values.

Provider A RT E S C

Rackspace 0,9648 99ms 62 3 $ 0,75

GreenGeeks 0,9439 647ms 58 4 $ 0,65

Dot5Hosting 0,9188 114ms 57 7 $ 0,53

Cari 0,9683 20ms 59 8 $ 0,79

JustCloud 0,8924 535ms 64 7 $ 0,84

GoGrid 0,5743 250ms 36 5 $ 0,32

ElephantDrive 0,5604 869ms 67 7 $ 0,64

GoDaddy 0,7809 691ms 12 2 $ 0,52

EpmSolutions 0,4959 332ms 33 9 $ 0,48

AgileIT 0,6370 696ms 49 8 $ 0,64

Then, the historical subjective CP’s data was

based in the dataset presented in (Noor et al., 2013).

In the dataset was performed a pre-processing step

with the purpose of extract ten subjective evaluations

from ten cloud providers, where each one subjective

evaluation is composed by a ratings set, comprising

values in a scale from 0 to 5, for each one QoS indi-

cator.

Afterwards the objective and subjective trust data

are deﬁned, a VO composed by ten business partners

and ﬁve cloud providers was simulated, with the pur-

pose of presenting the updated CP’s reputation after

a new VO’s participation. In this sense, to calculate

the reputation, weights are deﬁned as 0.85 and 0.15,

respectively, to objective and subjective sources.

Therefore, the reputation of each cloud provider is

depicted in Figure 3, and it is calculated considering

subjective trust with credibility analysis (Reputation

W/ F. Cred.) and disregarding credibility (Reputation

W/O F. Cred.).

rackspace greengeeks dot5hosting cari agileit

0.0

0.2

0.4

0.6

0.8

1.0

Cloud Provider’s Reputation

0.83

0.76

0.82

0.95

0.74

0.76

0.66

0.78

0.86

0.68

Reputation W/O F. Cred.

Reputation W/ F. Cred.

Figure 3: Cloud Provider’s Reputation.

It is possible to note that some of the cloud

providers (rackspace, dot5hosting, and cari) have

higher reputation values, because they present best

past performances and they are best subjectively as-

sessed. Otherwise, when subjective credibility fac-

tor was not considered, the CP’s reputation dispropor-

tionately increases, under malicious attack, regarding

to real behavior.

4.2 Architecture Evaluation

The average time for each architecture operation dur-

ing VO’s operation stage was analyzed in architecture

evaluation. The analyzed operations were reputation

of a CP, subjective assessment of a VO’s member to a

CP, and the QoS monitoring.

In this sense, the simulation are performed con-

sidering business partners (VO’s members) varying

from 5 to 25 to verify the scalability and the afore-

mentioned operations are uniformly distributed over

simulation time. Thus, Figure 4 presents the results

of simulation.

5 10 15 20 25

Total of Business Partners

125

250

375

500

Average Response Time (ms)

Monitoring

Reputation

Send Feedbacks

Figure 4: Average Response Time.

It is possible to note that send feedback operation

is tightly coupled to the number of business partners.

The monitoring operations, which consists of mes-

sages carrying data about QoS being exchanged be-

tween monitoring node, cloud providers and the arc

node. Therefore, one can conclude that monitoring

operation, according to the presented approach, con-

sumes most of the time during VO’s operation, and

increases in relation to the number of business part-

ners. This assumption is due to the fact that when

there are more business partners, consequently more

monitoring actions will be carried out.

5 CONCLUSION

This paper presented a trust reputation architecture

applied to a VO which uses CC resources. The pro-

posed architecture allows to assist the VO’s manager

during the decision-making processes of the VO’s

life-cycle. It was also presented a proposal to address

the trust issue existent in this integration.

A Trust Reputation Architecture for Virtual Organization Integration in Cloud Computing Environment

701

The proposed architecture presents a centralized

approach composed of four modules: the Aggrega-

tion Module, Monitoring Module, Reputation Broker

Service and Data Repository. The CP’s reputation is

calculated by the aggregation module, using two trust

sources: objective and subjective.

For the evaluating purpose, a simulation environ-

ment was developed in PeerFactSim.KOM, compris-

ing the architecture and the VO’s elements (cloud

providers and enterprises). The achieved results

demonstrate that this work provided a promising way

to deal with the attack types during reputation calcu-

lation. Moreover, the presented average time results

show that the reputation architecture can be used dur-

ing the VO’s operation, given the trust importance in

this context.

Finally, future works include to analyze other as-

pects, such as scalability feedback optimization, test-

ing of objective trust using historical data generated

by other probability distributions, and a objective re-

ward and penalty mechanism.

ACKNOWLEDGEMENTS

The authors would like to thank to UDESC PROMOP

ﬁnancial programme as well as to LabP2D.

REFERENCES

Alawamleh, M. and Popplewell, K. (2010). Risk Sources

Identiﬁcation in Virtual Organisation. In Enterprise

Interoperability IV, pages 265–277. Springer Science

+ Business Media.

Arenas, A. E., Aziz, B., and Silaghi, G. C. (2010). Reputa-

tion management in collaborative computing systems.

Security and Communication Networks, 3(6):546–

564.

Banker, R. D., Charnes, A., and Cooper, W. W. (1984).

Some models for estimating technical and scale inef-

ﬁciencies in data envelopment analysis. Management

science, 30(9):1078–1092.

Bilecki, L. F. and Fiorese, A. (2016). A conﬁdence indi-

cator model for virtual organization creation in cloud

computing environment. In PRO-VE 2016. Springer.

Camarinha-Matos, L. M., Afsarmanesh, H., Galeano, N.,

and Molina, A. (2009). Collaborative networked

organizations–concepts and practice in manufactur-

ing enterprises. Computers & Industrial Engineering,

57(1):46–60.

Esposito, E. and Evangelista, P. (2014). Investigating vir-

tual enterprise models: literature review and empiri-

cal ﬁndings. International Journal of Production Eco-

nomics, 148:145 – 157.

Firdhous, M., Ghazali, O., and Hassan, S. (2012). Trust

Management in Cloud Computing: A Critical Review.

International Journal on Advances in ICT for Emerg-

ing Regions, 4(2):24–36.

Gambetta, D. et al. (2000). Can we trust trust ? Trust:

Making and breaking cooperative relations, 13:213–

237.

Garg, S. K., Versteeg, S., and Buyya, R. (2013). A frame-

work for ranking of cloud computing services. Future

Generation Computer Systems, 29(4):1012–1023.

Haller, J. (2008). STORE Stochastic Reputation Service for

Virtual Organisations. In IFIP International Confer-

ence on Trust Management, pages 367–370. Springer.

Jøsang, A. and Golbeck, J. (2009). Challenges for robust

trust and reputation systems. In SMT.

Kerschbaum, F., Haller, J., Karabulut, Y., and Robinson, P.

(2006). Pathtrust: A trust-based reputation service for

virtual organization formation. In iTrust 2006, pages

193–205. Springer.

Malik, Z. and Bouguettaya, A. (2009). Rateweb: Repu-

tation assessment for trust establishment among web

services. The VLDB Journal, 18(4):885–911.

Mashayekhy, L. and Grosu, D. (2012). A reputation-based

mechanism for dynamic virtual organization forma-

tion in grids. In ICPP 2012, pages 108–117. IEEE.

Mell, P. M. and Grance, T. (2011). SP 800-145. The NIST

Deﬁnition of Cloud Computing. Technical report, Na-

tional Institute of Standards & Technology.

Noor, T. H., Sheng, Q. Z., Ngu, A. H., Alfazi, A., and Law,

J. (2013). Cloud Armor: A Platform for Credibility-

based Trust Management of Cloud Services. In CIKM

’13, pages 2509–2512. ACM.

Pan, M., Li, M., and Yu, Y. (2013). A group-choose al-

gorithm supporting virtual organization creation for

workﬂow deployment in cloud environment. Con-

currency and Computation: Practice and Experience,

25(13):1894–1908.

Resnick, P. and Zeckhauser, R. (2002). Trust among

strangers in internet transactions: Empirical analysis

of eBay reputation system. The Economics of the In-

ternet and E-commerce, 11(2):23–25.

Ruaro, A. F. and Rabelo, R. J. (2016). Do cloud computing

tools support the needs of virtual enterprises? In PRO-

VE 2016, pages 481–493. Springer.

Saaty, T. L. (1990). How to make a decision: the analytic

hierarchy process. European journal of operational

research, 48(1):9–26.

Stingl, D., Gross, C., R

uckert, J., Nobach, L., Kovacevic,

A., and Steinmetz, R. (2011). PeerfactSim.KOM: A

simulation framework for Peer-to-Peer systems. In

HPCS 2011, pages 577–584.

Winkler, T. J., Haller, J., Gimpel, H., and Weinhardt,

C. (2007). Trust Indicator Modeling for a Reputa-

tion Service in Virtual Organizations. ECIS 2007,

1(April):1584–1595.

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

702
