Towards a REST Cloud Computing Lexicon

Fabio Petrillo

1,3

, Philippe Merle

, Naouel Moha

and Yann-Gaël Guéhéneuc

Université du Québec à Montréal, Montréal, Canada

Inria Lille - Nord Europe, Villeneuve d’Ascq, France

École Polytechnique de Montréal, Montréal, Canada

Keywords:

REST, Lexicon, Cloud, Services.

Abstract:

Cloud computing is a popular Internet-based computing paradigm that provides on-demand computational

services and resources, generally offered by cloud providers’ REpresentational State Transfer (REST) APIs.

To the best of our knowledge, there has been no study on the analysis of the lexicon adopted by cloud providers,

despite its importance for developers. In this paper, we studied three different and well-known REST APIs

(Google Cloud Platform, OpenStack, and Open Cloud Computing Interface) to investigate and organise their

lexicons. This study presents three main contributions: 1) a tooled approach, called CLOUDLEX, for extracting

and analysing REST cloud computing lexicons, 2) a dataset of services, resources, and terms used in the three

studied REST APIs, 3) our analysis of this dataset, which represents a ﬁrst attempt to provide a common REST

cloud computing lexicon. After analysing our dataset, we observe that although the three studied REST APIs

to describe the same domain (cloud computing), contrary to what one might expect, they do not share a large

number of common terms, and only 5% of terms (17/352) are shared by two providers. Thus, the three APIs

are lexically heterogeneous, and there is not a consensus on which terms to use on cloud computing systems.

We discuss new avenues for cloud computing API designers and researchers.

1 INTRODUCTION

Cloud computing has transformed the Information

Technology (IT) industry (Armbrust et al., 2010) by

hosting applications and providing resources (e.g.,

CPU and storage) as services on-demand over the In-

ternet (Zhang et al., 2010), offering huge opportu-

nities for the IT industry. Cloud providers, such as

Google Cloud Platform (a commercial public cloud)

and OpenStack (an open source stack for building

public/private clouds), usually offer these services in

the form of REST (REpresentational State Transfer)

(Fielding, 2000) APIs, the de facto standard adopted

by many software organisations for publishing their

services. In particular, we observe that most of cloud

providers, such as Google Cloud Platform or Open-

Stack, propose their own proprietary APIs. Con-

versely, open and standard cloud APIs have also been

proposed, such as the Open Cloud Computing Inter-

face (OCCI) (Nyren et al., 2016), which is a neutral-

vendor cloud standard.

However, there is a wide variety of cloud APIs that

might be difﬁcult to understand and use by develop-

ers, especially within such a complex and technical

context as cloud computing. Moreover, well-designed

and well-named REST APIs may attract client de-

velopers to use them more than poorly designed and

named ones, particularly in the current open market,

where Web services are competing against one an-

other (Masse, 2011). Indeed, client developers must

understand the providers’ APIs while designing and

developing their systems that use these APIs. There-

fore, in the design and development of REST APIs,

their understandability and reusability are two major

quality characteristics, which are reachable when best

practices for REST APIs design (Masse, 2011) and

naming are followed.

To improve the understandability and cloud com-

puting adoption, a better comprehension of the tech-

nology is essential (Youseff et al., 2008) and we be-

lieve that this understanding involves the right choice

of lexicon used to describe the cloud computing APIs.

Nevertheless, despite its importance and to the best

of our knowledge, there has been no study on the

analysis of the lexicon adopted by cloud providers.

This raises three open research questions: RQ1:

Which Lexicon Is Adopted by Cloud Computing

Providers? RQ2: Are There Common Terms Be-

348

Petrillo, F., Merle, P., Moha, N. and Guéhéneuc, Y-G.

Towards a REST Cloud Computing Lexicon.

DOI: 10.5220/0006281203760383

In Proceedings of the 7th International Conference on Cloud Computing and Services Science (CLOSER 2017), pages 348-355

ISBN: 978-989-758-243-1

tween Providers’ Lexicons? RQ3: What Is the

Global Lexicon of All Cloud Providers?

To answer these questions, we studied three dif-

ferent and well-known REST APIs (Google Cloud

Platform, OpenStack, and Open Cloud Computing

Interface) by investigating and organising their lex-

icons. This study presents three main contributions

in response to the three open research questions: 1)

a tooled approach, called CLOUDLEX, for extract-

ing and analysing REST cloud computing lexicons,

2) a dataset of services, resources, and terms used in

the three studied REST APIs, 3) our analysis of this

dataset, which represents a ﬁrst attempt to provide a

common REST cloud computing lexicon.

The remainder of the paper is organised as fol-

lows. Section 2 presents our study: the three studied

cloud computing REST APIs, our conceptual model

for cloud computing REST APIs, the design and im-

plementation of our CLOUDLEX approach to extract

and analyse lexicons from cloud computing REST

APIs. Section 3 presents our results, answers the three

open research questions, and discusses threats to va-

lidity. Section 4 presents some related work. Finally,

Section 5 concludes the paper with future work.

2 STUDY DESIGN

2.1 Objects

The objects of our study are three different cloud

REST APIs including the API of Google Cloud Plat-

form (GCP)

, the API of OpenStack

, and the API

of OCCI

. We speciﬁcally target these APIs because

they represent the range of the different types of

cloud APIs available: a well-known commercial pub-

lic cloud, a worldwide used open source implementa-

tion for building private clouds, and a community-led

open standard for cloud computing.

2.2 Conceptual Model for Cloud

Computing REST APIs

Cloud computing is provided by many companies

like Amazon, Google, Microsoft, IBM, Oracle, im-

plemented by different open source stacks like Open-

Stack, CloudStack, Nebula, Eucalyptus, and speci-

ﬁed by few standards like OGF’s (Open Grid Fo-

rum) OCCI (Nyren et al., 2016) and DTMF’s CIMI

(Cloud Infrastructure Management Interface) (Davis

documented at https://cloud.google.com/docs

documented at http://docs.openstack.org

available at http://occi-wg.org

and Pilz, 2012), to cite a few. In our conceptual

model, we abstract this diversity of cloud computing

actors (companies, implementations, and standards)

under the single concept of Provider.

Each provider supplies a set of REST APIs. In

Google Cloud Platform, each API is in fact a com-

mercial product of Google, such as compute and

sql. OpenStack simply provides APIs, such as

orchestration-api and os-compute-2. In OCCI,

each API is speciﬁed as an extension of the OCCI core

model, such as Infrastructure and Platform ex-

tensions. Independently of the name used by cloud

providers (product, API, extension), each provider’s

REST API is conceptually a useful service, e.g., man-

aging virtual machines, networks, databases, or ap-

plications, orchestrating their deployment, control-

ling their access, etc. The number and contents of

these services are extremely heterogeneous for each

provider: tens of services in Google Cloud Platform,

more than one hundred in OpenStack, and ﬁve in

OCCI. In our conceptual model, we abstract this di-

versity of functional services (product, API, exten-

sion) under the single concept of Service.

Each service of a provider manages a set of com-

puting resources such as virtual machine, storage

disk, network, application, etc. Each computing re-

source is implemented as a REST resource character-

ized by a unique resource identiﬁer (e.g., URI, URL,

etc.). For instance, virtual machines are accessible

through the URI /{project}/zones/{zone_id}/

instances/{instance_id} in the compute service

of Google Cloud Platform, the URI /{tenant_

id}/servers/{server_id} in the os-compute-2

service of OpenStack, and are reachable by URI

/compute/{compute_id} in the Infrastructure

service of OCCI. Our conceptual model abstracts this

diversity of computing resources under the single

concept of Resource.

Each resource supports common CRUD (Create,

Retrieve, Update, and Delete) operations and some

speciﬁc business behaviors like start and stop a vir-

tual machine, attach a disk to a virtual machine, etc.

Our conceptual model abstracts this diversity (opera-

tion, behavior) under the single concept of Action.

To instantiate this conceptual model, we designed

a tooled approach for automatically identifying Ser-

vice, Resource and Action data from cloud comput-

ing REST APIs of three Providers, and then for ex-

tracting and analysing lexicons of these APIs.

2.3 CloudLex Approach

Our study is supported by the CLOUDLEX tooled ap-

proach composed of four steps illustrated in Figure 1:

Towards a REST Cloud Computing Lexicon

349

Step 1. Collecting Documentation. The ﬁrst

step of the CLOUDLEX approach consists in

manually collecting the documentation of cloud

computing providers’ REST APIs. The Web site

of Google Cloud Platform contains HTML pages

documenting all GCP’s REST APIs. For instance,

the HTML page https://cloud.google.

com/compute/docs/reference/latest/

describes all GCP’s compute services. Open-

Stack’s REST APIs are documented with Swagger

documents such as http://rackerlabs.

github.io/wadl2swagger/openstack/sw

agger/dbaas.json. OCCI is speciﬁed by a set

of PDF documents such as https://redmine.ogf.

org/attachments/220/infrastructure.pdf. We

analysed the three provider’s documentation, search-

ing for pages with API URIs. Then, we identiﬁed

all API pages manually and stored their URLs. At

the end of this step, we obtain a list of API pages

URLs that contain both GCP and OpenStack URIs

organised by service, and for OCCI, a list of relevant

PDF speciﬁcation documents.

Step 2. Parsing Documentation. The second step

of the CLOUDLEX approach consists in automatically

parsing all the providers’ documentation to collect all

provided services (e.g., compute and sql for GCP,

orchestration-api and os-compute-2 for Open-

Stack, Infrastructure and Platform for OCCI),

resource URIs and allowed HTTP request methods

in order to feed the implementation of our concep-

tual model presented in Section 2.2. However, the

nature of this documentation is heterogeneous since

it varies from one provider to another. Therefore,

the CLOUDLEX toolchain contains a set of heteroge-

neous parsers, each dedicated to a speciﬁc documen-

tation format, including GCP Parser, OCCI Parser,

and OpenStack Parser as shown in Figure 1. The

CLOUDLEX toolchain is extensible by design as it

could support other cloud provider’s APIs, e.g. Ama-

zon Web Services, with its own documentation for-

mat by just adding a new parser, as illustrated by

Other Parser at the bottom of Figure 1. Each

parser identiﬁes Provider, Service, Resource and

Action data from a speciﬁc provider’s documenta-

tion, and then feeds the Cloud Dataset, which is the

tooled implementation of the CLOUDLEX conceptual

model. Table 3 gives an excerpt of the obtained Cloud

Dataset. We parsed these API’s pages and docu-

ments to identify their structure. OpenStack provides

a page with Swagger JSON ﬁles, from which we ex-

tracted directly URIs. As for Google Cloud Platform,

which provides HTML documentation pages, we had

to develop an HTML parser to extract URIs. Unfor-

tunately, OCCI documents do not explicitly list URIs

but only give rules about how URIs must be gener-

ated by an OCCI implementation. Then, we added a

generator to OCCIWARE STUDIO, which is a model-

driven implementation of OCCI, and ran it to obtain

all the URIs for OCCI. At the end of this second step,

we get the Cloud Dataset, a dataset with the list of

resource URIs with allowed HTTP request methods

for each provider’s service, as illustrated in Table 3.

Figure 1: CLOUDLEX Approach.

Step 3. Extracting Lexicon. The third step of the

CLOUDLEX approach consists in automatically ex-

tracting the lexicon of each provider from its asso-

ciated Cloud Dataset. The lexicon of each provider

contains the name of all services of this provider, the

terms extracted from the path of the uri of all pro-

vided resources, and the name of all the actions de-

ﬁned by provided resources. The path of a URI is

usually organised in a hierarchical form, which ap-

pears as a sequence of segments separated by slashes.

For example, the URI /{project}/zones/{zone_

id}/instances/{instance_id} contains ﬁve seg-

ments: {project}, zones, {zone_id}, instances,

and {instance_id}. We keep all segments not en-

closed by braces in the lexicon, e.g., zones and

instances. Segments enclosed by braces, such as

{project} and all {*_id}, are identiﬁers either com-

puted by the cloud provider or freely chosen by the

cloud user. For this reason, these identiﬁer segments

are not part of the lexicon. We then performed a ﬁne-

grained analysis of all obtained URIs automatically,

parsed the URIs following provider’s URI patterns,

and extract lexicon terms. These extractions resulted

in the Lexicon Dataset, a dataset of terms associ-

ated with each API.

Step 4. Analysing Lexicon. The fourth step of

the CLOUDLEX approach consists in automatically

CLOSER 2017 - 7th International Conference on Cloud Computing and Services Science

350

analysing the lexicons. Various analyses are pro-

vided to count occurrences of each term in the lexi-

con datasets, and identify nouns versus verbs, singu-

lar versus plural terms, and lower/upper/camel case

of terms. The results of these analyses are reported in

several tables and charts of Section 3.

2.4 Implementing CLOUDLEX

Both Cloud and Lexicon Datasets are encoded

as CSV (Comma-Separated Values) ﬁles. This im-

plementation choice fosters the reusability of our

datasets by other researchers and practitioners. CSV

ﬁles can easily be generated from any program-

ming language and read from any analysis software

like Apache OpenOfﬁce or Microsoft Excel spread-

sheets. Most of the CLOUDLEX parsers, extractors

and analyses are implemented in Python, a dynamic

scripting language providing simple libraries to get

and parse HTML pages/Swagger ﬁles, and read/write

CSV ﬁles, etc. This implementation choice fosters

readability, comprehension and auditability of our

parsing, extraction and analysis scripts by other re-

searchers and practitioners. Finally, we used OpenOf-

ﬁce spreadsheet software to produce tables and charts

shown in Section 3. Our implementation of the

CLOUDLEX tooled approach and all the produced

datasets are freely available on https://github.

com/Spirals-Team/CloudLexicon.

3 RESULTS

3.1 Analysis of the Cloud Dataset

Using the tooled approach CLOUDLEX presented in

Section 2.3, we extracted a total of 1,297 URIs from

the 142 services of the three cloud providers, as

shown in Table 1. The distribution of URIs is 588

for OpenStack (45,34% of all URIs), 505 for GCP

(38,94%), and 204 for OCCI (15,53%). The distri-

bution of services is 115 for OpenStack (80,99% of

all services), 22 for GCP (15,49%), and 5 for OCCI

(3,52%). An excerpt of the whole Cloud Dataset

is given in Table 3. The average number of URIs

Table 1: Services and URIs by cloud provider.

Cloud provider # of services # of URIs

OpenStack 115 588

GCP 22 505

OCCI 5 204

Total 142 1.297

by service is 9; indicating that the number of anal-

ysed cloud services is small compared to the provided

URIs. However, this mean is very different from one

provider to another: 5 for OpenStack, 23 for GCP, and

41 for OCCI.

Table 2: The ten biggest cloud provider’s services.

Provider Service # of URIs

GCP compute 198

OCCI Infrastructure 77

OCCI Platform 45

OpenStack orchestration-api 39

GCP sql 38

GCP storage 36

OpenStack os-compute-2 33

OCCI Service Level Agreements 32

OCCI Monitoring 26

OCCI Compute Resource Templates 24

Proﬁle 24

Table 2 gives the ranking of the top ten biggest

services in terms of provided URIs, which are

compute for GCP (198 URIs, 15,27% of all URIs),

Infrastructure for OCCI (77, 5,94%), Platform

for OCCI (45, 3,47%), orchestration-api for

OpenStack (39, 3,01%), sql for GCP (38, 2,93%),

storage for GCP (36, 2,78%), os-compute-2

for OpenStack (33, 2,54%), Service Level

Agreements for OCCI (32, 2,47%), Monitoring

for OCCI (26, 2,00%), and Compute Resource

Templates Profile for OCCI (24, 1,85%). To-

gether these ten services provide 42,25% of all URIs.

We also observed that 71% of all URIs (922/1297)

are provided by only 23% of services (33 services out

of 142 services) including 14 services of OpenStack

(12,17% of all OpenStack services), 14 of GCP

(63,63%), and 5 of OCCI (100%). Each of the other

109 services provides less than 10 URIs. These

results show that the studied REST APIs are not

homogeneous in terms of number of URIs by service.

We conclude that most of the analysed cloud ser-

vices are tiny in terms of number of provided URIs,

i.e., less that 10 URIs. Most of OpenStack services,

i.e., 101 out of 115 (87,8%), are very small. About

two-thirds of GCP services and all OCCI services are

medium or large services, i.e., more than 10 URIs.

We analysed the HTTP methods (GET, POST,

PUT, DELETE, PATCH and HEAD) associated with

each URI. As shown in Figure 2, we observed that

globally 45% of HTTP requests are GET, 30% are

POST, 15% are DELETE, 9% are PUT, and 2% are

PATCH requests. The HEAD method is used only

by OpenStack on two requests. We notice that GET

and POST are the most common HTTP methods used

in the analysed cloud computing REST APIs. Thus,

client developers should mainly deal with retrieving

and updating cloud resources.

Towards a REST Cloud Computing Lexicon

351

Table 3: Excerpt of the Cloud Dataset.

Provider Service Resource URI HTTP Verb

GCP compute /{project}/aggregated/addresses GET

GCP compute /{project}/regions/{region}/addresses/{address} DELETE

GCP compute /{project}/regions/{region}/addresses/{address} GET

GCP compute /{project}/regions/{region}/addresses POST

GCP compute /{project}/regions/{region}/addresses GET

... ... ... ...

OpenStack dbaas /v1.0/{accountId}/instances/{instanceId}/databases/{databaseName} DELETE

OpenStack dbaas /v1.0/{accountId}/instances/{instanceId}/users/{name} DELETE

OpenStack dbaas /v1.0/{accountId}/instances/{instanceId} DELETE

OpenStack dbaas /v1.0/{accountId}/instances/{instanceId} GET

OpenStack dbaas /v1.0/{accountId}/ﬂavors GET

... ... ... ...

OCCI Infrastructure {provider_speciﬁc_path}/network/ GET

OCCI Infrastructure {provider_speciﬁc_path}/network/ POST

OCCI Infrastructure {provider_speciﬁc_path}/network/ DELETE

OCCI Infrastructure {provider_speciﬁc_path }/network/?action=up POST

OCCI Infrastructure {provider_speciﬁc_path}/network/?action=down POST

Figure 2: Distribution of HTTP Methods.

3.2 RQ1: Which Lexicon Is Adopted by

Cloud Computing Providers?

The lexicon adopted by each provider contains 185

terms for GCP, 137 for OpenStack, and 47 for OCCI.

Each Table 4, 5 and 6 provides the ﬁve most used

terms for GCP, OpenStack, and OCCI, respectively.

For each term, the number of occurrences represents

the number of URIs containing this term. More-

over, we observed the parts of speech that providers

adopted in their APIs.

Firstly, APIs use nouns and verbs with 67% of

nouns and 33% of verbs. If we study this aspect by

providers, we observed that GCP uses 50% of nouns

and 50% of verbs, OCCI has a proportion of 70% of

nouns for 30% of verbs, while OpenStack adopts 88%

of nouns and 12% of verbs. Figure 3 shows these re-

sults with absolute values by providers.

Secondly, the analysis of APIs in terms of singu-

lar and plural terms reveals that 51,5% of terms are

singular, and 48,5% are plural. OCCI has 100% of

singular terms. GCP has 48,65% of singular terms

Table 4: The Five Most Used Terms in GCP.

Term # of occurrences

projects 111

global 108

zones 84

instances 52

regions 51

Table 5: The Five Most Used Terms in OpenStack.

Term # of occurrences

servers 81

ﬂavors 43

images 38

users 37

detail 31

and 51,35% of plural terms. OpenStack has 38,69%

of singular terms and 61,31% of plural terms.

Thirdly, the analysis of APIs in terms of lower,

upper and camel cases shows that 72,9% of

terms are lowercase, 25,5% use camel case, and

about 1,6% are upper case. OCCI is 100% lower

case. OpenStack mainly uses lower case, but

it has six terms with upper case and one camel

case: OS-KSADM, OS-OAUTH1, OS-KSCATALOG,

OS-OS-KSS3, OS-KSEC2, OS-KSVALIDATE, and

ec2Credentials. GCP uses camel case, but there

are two exceptions, i.e., trainedmodels, and

serverconfig.

Petrillo et al. (Petrillo et al., 2016) compiled a cat-

alog of 73 best practices in the design of REST APIs.

In the catalog, there are four best practices directly

related with URI lexicon: 1) lowercase letters should

be preferred in URI paths; 2) a singular noun should

be used for document names; 3) a plural noun should

CLOSER 2017 - 7th International Conference on Cloud Computing and Services Science

352

Table 6: The Five Most Used Terms in OCCI.

Term # of occurrences

action 36

compute 17

agreement 17

storage 11

network 11

Figure 3: Nouns and Verbs by Provider.

be employed for collection names; 4) a verb or verb

phrase should be used for controller names. Match-

ing these practices with our lexicon’s analysis, our re-

sults show that the three APIs, in general, follow these

four good practices for REST APIs, using lowercase

letters, nouns and verbs correctly, and a correct appli-

cation of plural and singular on API terms.

To summarize, we found that the lexicon of anal-

ysed cloud computing REST APIs contains a ma-

jority of nouns, which are equally singular or plu-

ral, and are mainly in lower case, following REST

API best practices.

3.3 RQ2: Are There Common Terms

Between Providers’ Lexicons?

We tabled all terms and analysed which terms are in

common in three or two APIs. No common term ap-

pears in the three APIs. Table 7 presents the list of

the 17 common terms in two APIs, which represents

less than 5% (17/352) of terms used simultaneous by

two APIs, the majority of nouns (12 nouns versus 5

verbs). Consequently, Table 7 highlights an important

ﬁnding: the three cloud computing REST APIs do

not share a common lexicon and very few terms

are common between two APIs.

3.4 RQ3: What Is the Global Lexicon of

All Cloud Providers?

Globally, if we combine all terms and identify the

number of occurrences of common terms, the three

APIs formed a lexicon of 352 different terms (nouns

Table 7: Common terms in two APIs.

Term Noun Verb GCP OpenStack OCCI

action X X X

databases X X X

events X X X

images X X X

instances X X X

members X X X

networks X X X

resources X X X

restart X X X

resume X X X

snapshots X X X

start X X X

stop X X X

storage X X X

types X X X

users X X X

validate X X X

and verbs) to express all provided services. As illus-

trated in Figure 4, we present the most common terms

in the form of a tag cloud to illustrate our REST cloud

computing lexicon. Visually, we can see the high

heterogeneity between APIs, and it highlights terms

as servers, images, ﬂavors, instances, users, projects.

Brieﬂy, we conclude that there is no consensus cur-

rently on which terms to use on cloud computing

systems.

Figure 4: Cloud lexicon tag cloud.

3.5 Threats to Validity

As with any such empirical study, threats exist that

reduce its validity, which we attempted to mitigate or

had to accept. We now discuss these threats and the

measures that we took on them.

Threats to the construct validity of our study

concern the relationship between theory and obser-

vations. We assumed that good naming practices

(Petrillo et al., 2016) improve the quality of the REST

APIs of the cloud providers that follow them (Zhang

et al., 2010). Although these assumptions are legiti-

mate and have been withheld by many researchers and

works before, for example that of Zhang and Budgen

Towards a REST Cloud Computing Lexicon

353

(Zhang and Budgen, 2012), future work should study

whether these good naming practices apply univer-

sally to all cloud services. Also, we argued that the

presented lexicon is exhaustive to the three analysed

APIs (GCP, OpenStack and OCCI). However, other

terms could be included if a different approach were

adopted.

Threats to internal validity concern confounding

factors that can affect our dependent variables. Al-

though we did not carry any statistical analysis on the

characteristics of the studied REST APIs, we assumed

that the lexicon was a typical feature of the REST

APIs. However, there may be other terms that de-

scribe more accurately these REST APIs, in particular

analysing their documentations. Future work includes

analysing and contrasting more APIs with more terms

and documentation. Further, other researchers should

perform similar analyses to conﬁrm or invalidate ours.

Threats to external validity concern the general-

ization of our results. Although we presented, to the

best of our knowledge, the largest study on the lexicon

of cloud computing REST APIs, we cannot generalise

our results to all cloud computing REST APIs. Future

work is necessary to analyze more REST APIs, from

other cloud providers, open source implementations,

and standards to conﬁrm or invalidate our observa-

tions. However, as we state in the introduction, this

study represents the ﬁrst attempt towards a common

REST cloud computing lexicon.

3.6 Discussion

Our results raise important open questions for re-

searchers, as well as new opportunities for educators

and cloud service designers. First, CLOUDLEX pro-

vides an approach that researchers could use or extend

to analyse new qualitative aspects about REST cloud

services. Second, our conclusion that the cloud lex-

icon is currently very heterogeneous could inﬂuence

cloud providers endeavour to work together to create

a consensual nomenclature for cloud services, simpli-

fying adoption, maintenance and interoperability on

cloud computing APIs. Finally, educators could use

our results to guide their courses, focusing on more

relevant services and applying common terms cor-

rectly.

4 RELATED WORK

Recently, there is a growing interest in the design

quality evaluation of REST APIs. However, to the

best of our knowledge, few studies made speciﬁcally a

lexical evaluation of REST APIs in general, and none

in the domain of cloud computing.

In related work for the general design quality

evaluation of REST APIs, we can cite the research

work of Hausenblas (Hausenblas, 2011), who stud-

ies some widely used RESTful Web APIs in terms

of URI space design, resource representations, and

hyperlinking support. Rodríguez et al. (Carlos Ro-

dríguez et al., 2016) also evaluated the conformance

of good and bad design practices in REST APIs from

the perspective of mobile applications. They analysed

large data logs of HTTP calls collected from the In-

ternet trafﬁc of mobile applications, identiﬁed usage

patterns from logs, and compared these patterns with

best design practices. Zhou et al. (Zhou et al., 2014)

showed how to ﬁx design problems related to the use

of REST services in existing Northbound networking

APIs in a Software Deﬁned Network and how to de-

sign a REST Northbound API in the context of Open-

Stack. These previous works made contributions to

the design evaluation of REST APIs for general or

speciﬁc domains, mobile and networking, while we

consider the domain of cloud services.

Some researchers have dealt with the linguistic as-

pects of RESTful APIs, in particular in terms of lex-

icon. For instance, Parrish (Parrish, 2010) performs

a subjective lexical comparison between two well-

known RESTful APIs, i.e., Facebook and Twitter. In

the comparison, the author speciﬁcally focuses on the

analysis of verbs and nouns in URIs naming. Palma

et al. (Palma et al., 2015) evaluated the linguistic as-

pects of several REST APIs based on REST patterns

and anti-patterns, which correspond to good and bad

practices in the design of REST services. However,

the APIs evaluated were selected from different and

general domains. They included Facebook, Twitter,

Dropbox, and Bestbuy. So, it was not possible to com-

pare and discuss the results among the APIs. More-

over, the list of patterns and anti-patterns was really

comparable to this focused study.

Petrillo et al. (Petrillo et al., 2016) evaluated three

cloud computing REST APIs using a catalog of 73

general best practices. However, this catalog was

mainly dedicated to the design of REST APIs from a

conceptual and syntactic point of view, but not neces-

sarily lexical. The present paper speciﬁcally focuses

on a lexical evaluation of cloud computing REST

APIs.

5 CONCLUSION

Towards the end-goal of a thorough comprehension of

the ﬁeld of cloud computing and a more rapid adop-

CLOSER 2017 - 7th International Conference on Cloud Computing and Services Science

354

tion from the scientiﬁc community, we claimed in

this paper that well-named REST APIs might attract

client developers to use them. A better comprehen-

sion of the technology involves the right choice of

lexicon used to describe the cloud computing APIs.

We supported our claim by performing, to the best

of our knowledge, the ﬁrst study extracting, organis-

ing and analysing the lexicon of the REST APIs of

several cloud providers. We included in our study

the REST APIs provided by Google Cloud Platform,

OpenStack, and OCCI.

We thus presented three contributions. For our

ﬁrst contribution, we presented CLOUDLEX, our ap-

proach to building the lexicon of cloud computing

REST APIs, introducing a conceptual model and pro-

viding a toolkit to extract and analyse the lexicon of

cloud computing REST APIs. For our second contri-

bution, we shared a full dataset of services, resources,

and terms used in the three studied REST APIs. Fi-

nally, analysing our dataset, we showed that the three

APIs formed a lexicon of 352 different terms (nouns

and verbs) to express all provided services, in which

there are only 17 shared terms, representing less than

5% (17/352) of terms used simultaneously by two

APIs. Thus, the three APIs do not share a common

lexicon, and we conclude that there is not a consen-

sus actually on which terms to use on cloud com-

puting systems. However, we found that the cloud

computing REST APIs follow, in general, the good

lexicon practices for REST APIs.

A part of our future work is related to threats to

validity presented in Section 3.5. Mainly, this in-

volves the analysis and contrast of more APIs with

more naming practices to cover other possible charac-

teristics. We plan to consider other REST APIs, from

other cloud providers, e.g., Amazon, open source im-

plementations, e.g., CloudStack, and standards, e.g.,

DTMF’s CIMI. Another future work is to build an on-

tology of cloud computing APIs, establishing seman-

tic joins between services and resources from differ-

ent providers in order to deal with semantic interop-

erability between clouds.

Last but not least, this work is the ﬁrst contribu-

tion towards understanding cloud computing lexical

aspects, claiming that a deep understanding of the na-

ture of API and a common lexicon will further boost

the cloud computing adoption.

ACKNOWLEDGMENTS

This work is co-funded by the French PIA OCCIware

research and development project (www.occiware.

org) and by the Natural Sciences and Engineering Re-

search Council of Canada (NSERC).

REFERENCES

Armbrust, M., Stoica, I., Zaharia, M., Fox, A., Grifﬁth, R.,

Joseph, A. D., Katz, R., Konwinski, A., Lee, G., Pat-

terson, D., and Rabkin, A. (2010). A View of Cloud

Computing. Communications of the ACM, 53(4):50.

Carlos Rodríguez, C., Baez, M., Daniel, F., Casati, F.,

Carlos, J., Canali, L., and Percannella, G. (2016).

REST APIs : A Large-Scale Analysis of Compliance

with Principles and Best Practices. In Proceedings

of 16th International Conference on Web Engineering

(ICWE2016), pages 21–39.

Davis, D. and Pilz, G. (2012). Cloud Infrastructure Man-

agement Interface (CIMI) Model and REST Interface

over HTTP. DMTF Speciﬁcation Document DSP-

0263, Distributed Management Task Force, Inc.

Fielding, R. T. (2000). Architectural Styles and the Design

of Network-based Software Architectures. PhD thesis,

University of California, Irvine.

Hausenblas, M. (2011). On Entities in the Web of Data,

pages 425–440. Springer New York, New York, NY.

Masse, M. (2011). REST API Design Rulebook, volume 53.

O’Reilly Media.

Nyren, R., Edmonds, A., Papaspyrou, A., Metsch, T., and

Parak, B. (2016). Open Cloud Computing Interface –

Core. OCCI-WG Speciﬁcation Document 1.2, Open

Grid Forum.

Palma, F., Gonzalez-Huerta, J., Moha, N., Guéhéneuc,

Y.-G., and Tremblay, G. (2015). Are RESTful

APIs Well-Designed? Detection of their Linguistic

(Anti)Patterns. In Proceedings of International Con-

ference on Service-Oriented Computing, volume 8954

of LNCS, pages 171–187.

Parrish, A. (2010). Social Network APIs : A Revised Lex-

ical Analysis. decontextualize : words and projects

[Online; accessed 14-July-2016].

Petrillo, F., Merle, P., Moha, N., and Guéhéneuc, Y.-G.

(2016). Are REST APIs for Cloud Computing Well-

Designed? An Exploratory Study. In Proceedings

of 14th International Conference on Service-Oriented

Computing, ICSOC 2016, pages 157–170.

Youseff, L., Butrico, M., and Silva, D. D. (2008). To-

ward a Uniﬁed Ontology of Cloud Computing. In

Proceedings of 2008 Grid Computing Environments

Workshop, pages 1–10.

Zhang, C. and Budgen, D. (2012). What Do We Know

about the Effectiveness of Software Design Pat-

terns? IEEE Transactions on Software Engineering,

38(5):1213–1231.

Zhang, Q., Cheng, L., and Boutaba, R. (2010). Cloud Com-

puting: State-of-the-Art and Research Challenges.

Journal of Internet Services and Applications, 1(1):7–

18.

Zhou, W., Li, L., Luo, M., and Chou, W. (2014). REST API

Design Patterns for SDN Northbound API. In 2014

28th International Conference on Advanced Informa-

tion Networking and Applications Workshops, pages

358–365. IEEE.

Towards a REST Cloud Computing Lexicon

355
