User-based Load Balancer in HBase

Ahmad Ghandour

, Mariam Moukalled

, Mohamad Jaber

and Yli

es Falcone

American University of Beirut, Computer Science Department, Beirut, Lebanon

Univ. Grenoble Alpes, Inria, Laboratoire d’Informatique de Grenoble, F-38000 Grenoble, France

Keywords:

Big Data, NoSQL, HBase, Load Balancer.

Abstract:

Latency of read and write operations is an important measure in relational and non-relational databases. Load

balancing is one of the features that manages the distribution of the load between nodes in case of distributed

servers to improve the overall performance. In this paper, we introduce a new load balancer to HBase (a non-

relation database), which monitors the most requested keys and dynamically acts to redistribute the regions by

splitting and moving them. Our load balancer takes into account the average response time of clients’ requests

and the most requested keys. Our method is fully implemented and can be integrated in HBase distribution.

Experimental results show that we get on average an improvement of latency of 15%, and up to 35% in some

scenarios.

1 INTRODUCTION

We live in the big data era. A tremendous amount of

data, petabytes in size, are accessed by users. In stan-

dard relational database management systems, han-

dling a huge amount of data in a reasonable amount

of time became a bottleneck. Standard relational

database management systems suffer from handling

huge volume of data in reasonable amount time. This

is mainly due to its relational structure of data. To

this end, non-relational databases (NoSQL) were pro-

posed to provide a mechanism to efﬁciently store and

retrieve big data, which is no longer modeled with the

tabular relations used in relational databases.

HBase is a NoSQL database. It is an open source

implementation of Big Table (Chang et al., 2008).

Big Table was proposed by Google to handle big

data using distributed ﬁle system storage, Google

File System (Ghemawat et al., 2003), in well-formed

structure. The main goals of NoSQL databases are

wide applicability, scalability, high performance and

high availability. Contrarily to relational databases,

NoSQL uses a simple data model which allows for

dynamic control over data layout and format.

NoSQL databases are built on top of a distributed

ﬁle system storage. For instance, HBase stores its data

in Hadoop Distributed File System (HDFS) (Hadoop,

2016). HDFS consists of distributed nodes where data

is stored. However, HDFS only allows for sequential

access to the ﬁles which requires reading block of data

to access a single row, while HBase is built on top

of it to allow random ﬁle access, and hence efﬁcient

handling of read/write operations.

In HBase a table is a collection of rows, where the

rows are sorted according to keys. The table schema

deﬁnes only column families, which are the key-value

pairs. A table may have multiple column families and

each column family can have any number of columns.

Additionally, each cell value of the table has a time-

stamp.

Hbase system is composed of several components

that formulate a hierarchical structure: (1) on the top

level there are Zookeeper and HMaster; (2) in the

middle level there are region servers and regions; and

(3) ﬁnally there are the store, store ﬁle, HFile and

MemStore. Zookeeper provides coordination services

for distributed applications such as naming, conﬁgu-

ration management, synchronization, and group ser-

vices. It consists of several servers. One of the

server acts as the master and the others as replicas.

Zookeeper stores all the META data, which is com-

posed of all region servers and their data start and end

keys. It also coordinates with the HMaster to update

its META data accordingly. Moreover, it handles all

the clients’ requests to locate the region servers given

the requested key. HMaster is a centralized node that

handles the management of its region servers (e.g.,

crash of servers, new servers). It also communicates

with Zookeeper to update META data information,

and it is responsible for the assignment of regions

364

Ghandour, A., Moukalled, M., Jaber, M. and Falcone, Y.

User-based Load Balancer in HBase.

DOI: 10.5220/0006290103920396

In Proceedings of the 7th International Conference on Cloud Computing and Services Science (CLOSER 2017), pages 364-368

ISBN: 978-989-758-243-1

among region servers and re-assignment of regions

due to failure or load balancing. Region servers store

regions. Each region server has a start and an end

key except for the ﬁrst region has empty start key.

Region server handles all read/write requests for all

its regions. Regions act as the container for one or

more store. Each region has a maximum size of 10GB

and it can be manually conﬁgured with smaller sizes.

A store in the region has a minimum size of 64MB

and it can be conﬁgured with larger sizes. Store

contains MemStore and HFiles. MemStore acts as a

cache memory, which initially stores any data writ-

ten. When the MemStore is full, it is ﬂushed and the

data is transferred to HFiles.

HBase supports several load balancing techniques

to equally split the work amongst the region servers.

Nonetheless, all the load balancers implemented in

HBase do not take into account the response time of

the users’ requests. Additionally, the existing load

balancers split the regions in the middle and do not

take into account the hot keys (i.e., keys requested so

frequently) by the clients.

In this paper, we introduce a new balancer of

HBase region servers, which takes into account the

response time of the users’ requests and automati-

cally detects regions causing delay in response times.

Then, it splits those regions in order to dispatch the

users’ requests into the new created regions. More-

over, if some region servers have too many (with re-

spect to some threshold) regions, it moves regions

from high-loaded region servers to other less-loaded

region servers.

The remainder of the paper is structured as fol-

lows. In section 2, we present our main method to

load balance the distribution of the regions. Section 3

shows experimental results. In Section 4, we discuss

related work. Finally, Section 5 draws some conclu-

sions and perspectives.

2 ADAPTIVE HBase

In this section, we introduce an efﬁcient user-based

balancing method, which automatically splits and

moves HBase regions to improve response time of

clients’ requests. The method mainly consists of two

phases. First, we integrate a monitoring feature to the

APIs provided by HBase that allow clients to access

data. Second, we implement an algorithm to automat-

ically detect regions causing overhead, and accord-

ingly regions are split or moved to improve the per-

formance of the clients’ request.

2.1 Runtime Monitoring and Proﬁling

The ﬁrst step is to detect regions causing overhead.

For this, we intercept the HBase API to monitor the

load of the region servers. The interception allows to

keep track of the keys accessed per regions, the to-

tal number of accesses per key and the average re-

sponse time with respect to each region. The proﬁl-

ing data is stored in the META table. Consequently,

whenever a client requests to get any key using shell-

based or API, the new integrated code allows to mon-

itor and store the required information to the META

table. Note that the META table remains on one of

the region servers and it does not split regardless of

its size. Moreover, the new column family containing

the logs is cleared each time we execute the balancer,

which is deﬁned in the following.

2.2 Runtime User-based Load

Balancing

We implement a user-based load balancer, which dy-

namically distributes the load among the servers ac-

cording to client requests. We deﬁne a CronJob, a

time-based scheduler, to periodically run the user-

based balancer at speciﬁc time instants (to be speci-

ﬁed by the HBase administrator). The user-based bal-

ancer is split into three phases.

2.2.1 Select Victim Regions

The ﬁrst phase consists in selecting victim regions ac-

cording to the following:

1. Compute, from the proﬁled information, the av-

erage response time per region. Let ART =

{(R

, art

), .. . , (R

, art

)}, where art

is the aver-

age respond time of region R

2. Select the top k victim regions V Rs with aver-

age response time greater than some threshold,

ART

threshold

. ART

threshold

is an input parame-

ter of the algorithm to be speciﬁed by the HBase

administrator depending on the clients’ need and

the speciﬁcation of the cluster. Formally, V Rs =



| (R

, art

) ∈ ART ∧ art

≥ ART

threshold



2.2.2 Split Phase

The second phase consists in splitting victim regions

with respect to some keys. A region has to be split so

that the requests are dispatched over the two new re-

gions. That is, consider the case where there is a mas-

sive number of requests on two keys k

and k

in some

region, where the two keys belong to the ﬁrst part of

the region. Then, it is not desirable to split the region

User-based Load Balancer in HBase

365

in the middle, since it will remain congested. For this,

we split the region with respect to a balance key so

that after the split, the future requests would be even-

tually dispatched between the two new regions. Note

that small regions should not be split to avoid explo-

sion of regions, but they should be moved to another

less loaded region server, which will be discussed in

the next phase. For this, we only split the region if its

size is greater than RS

threshold

. For every victim re-

gion vr ∈ V Rs of size is greater than RS

threshold

, the

split phase is deﬁned as follows:

1. Let (k

, r

), . . . , (k

, r

) be the number of re-

quests, sorted with respect to the keys in the vic-

tim region vr.

2. We deﬁne the balance key to be equal to one if

α is equal to one (i.e., only one key is requested

by this region). Otherwise, we deﬁne the balance

key, bk, so that after the split the requests would

be split into the two new regions. For this, we ﬁrst

select the ﬁrst key, k

, from the requested keys

satisfying the following property. The number of

requests to the keys less than or equal to k

would

be greater than the number of requests to the keys

greater than k

. Then, we set the balance key to

be between k

and k

β+1

. Formally, bk =

β+1

where β is the index of the key such that

∑

i=β

i=1

≤

and

∑

i=β+1

i=1

> r

and r

∑

i=α

i=1

2.2.3 Move Phase

After the split phase some region servers may have

many regions. For this, for every region server that

corresponds to some victim regions, we count its

number of regions. If the number of regions is greater

than some threshold, NR

threshold

, we move the extra

regions to other region servers with minimum num-

ber of regions and less than NR

threshold

. NR

threshold

is an input parameter of our algorithm, which depends

on the capacity of region servers.

2.3 General Algorithm

The general structure of the algorithm of the user-

balancer is depicted in Listing 1. It mainly consists

of three phases:

1. Select victim regions.

2. Splitting of victim regions.

3. Moving of regions from highly-loaded region

servers to less-loaded region servers.

Table 1: Execution Times (Seconds) - 1 client - 2 keys.

Requests RT Before RT After Improvement

100,000 26.61 19.6 26.34%

250,000 52.39 48.85 6.76%

500,000 101.97 93.61 8.20%

750,000 153.64 140.10 8.81%

1,000,000 203.43 183.80 9.65%

Table 2: Execution times (seconds) - 1 client - 4 keys.

Requests RT Before RT After Improvement

100,000 40.71 36.60 10.10%

250,000 97.70 88.86 9.05%

500,000 196.82 162.69 17.34%

750,000 300.52 245.01 18.47%

1,000,000 410.46 326.61 20.43%

Discussion. In case where the average response

time is very high (i.e., greater than ART

threshold

the size of the region is smaller than RS

threshold

, and

the other region servers contain more regions than

threshold

, the performance of the HBase cluster is

not compatible with respect to user needs, and hence

region servers have to be replaced with more powerful

machines to satisfy the users’ needs.

3 EXPERIMENTAL RESULTS

We evaluate our algorithm on a Hadoop cluster con-

sisting of 8 nodes with 8 cores each. We populate the

HBase with a table consisting of several regions, each

of size 4GB.

We implement several scenarios: (1) one client

requesting two keys; (2) one client requesting four

keys; (3) four clients requesting two keys; and (4)

four clients requesting four keys. For each scenario,

we vary the number of requests from 100, 000 to

1, 000, 000 and we measure the execution times to

handle them.

The threshold parameters were deﬁned according

to the cluster conﬁguration: (1) AR

threshold

, i.e., av-

erage response time per request, is set to be 0.2ms;

and (2) RS

threshold

to be 1GB. Tables 1, 2, 3 and

4, show the execution times before and after running

our user-based load balancer. Note that, the execu-

tion times of monitoring are included when running

our balancer. In case of requesting two keys by one

clients we get an average improvement of 11.95%. In

case of requesting four different keys we get an aver-

age improvement of 15.08%. In case of four clients,

we get an improvement of 37.59% in case of request-

ing two keys each with 250, 000 hits. Moreover, as

average we get an improvement 15.16%. In case of

four clients requesting four different keys, we get an

CLOSER 2017 - 7th International Conference on Cloud Computing and Services Science

366

Listing 1: User-Based Balancer Algorithm.

/* ** S ele ct Vi ct i m R eg ion s ** */

ART = a ve r ag eR T P e rR eg i on () ;

VRs = f il t er Vi t i m Re gi o ns ( ART );

/* ** S plit Phas e ** */

f o r ( vr : VRs ) {

i f ( s ize (vr ) < R S _ T H RE SH OL D ) c o n t i n u e ;

To p KK ey s = g et To pK Ke ys ( vr ) ;

i f ( s ize ( To kK Ke y s ) == 1 ) {

ba la nc e K e y = mid dl eK e y ( vr ) ;

} e l s e {

re qu es t A v er ag e = sum Re qu es ts ( T ok KK eys ) ;

be ta I nd ex = co m p u te Be t a I nd ex ( To pK Ke ys );

ba la nc e K e y = ( T op KK eys [ be ta In de x ] + T opK Ke ys [ b et aI n d e x + 1]) / 2;

}

spl i t ( vr , ba la nc eK ey );

}

/* ** Mo ve Ph ase ** */

f o r ( vr : VRs ) {

RS = reg io nS er ve r ( vr ) ;

i f ( nu m b er Re gi on s ( RS ) <= NR _ T HR ES HO LD ) c o n ti n u e ;

cou n t = n u m b e r Re gi on s (RS ) - N R_ TH RE SH OL D ;

RM = se l e ct Re g io ns T oM ov e () ;

move ( count , vr , RM ) ;

}

average improvement of 9.99%.

4 RELATED WORK

4.1 Native HBase Load Balancing

HBase supports several types of load balancing. By

default, it runs the stochastic load balancer periodi-

cally every 5 minutes. Below is the description of

different balancers supported by HBase:

• Simple load balancer (Simple Load Balancer,

2016) computes the average number of regions

and iterates through the most loaded servers to re-

distribute the regions on the less loaded servers

(i.e., less number of regions).

• Favored node load balancer (Favored Node Load

Balancer, 2016) takes into consideration server

failure, so that when a server fails the regions will

Table 3: Execution times (seconds) - 4 clients - 2 keys.

Requests RT Before RT After Improvement

100,000 40.45 35.48 12.29%

250,000 133.23 83.15 37.59%

500,000 178.17 164.58 7.63%

750,000 263.9 244.48 7.36%

1,000,000 365.54 325.56 10.94%

allocate to the less favorable server, which is de-

ﬁned in HDFS.

• Stochastic Load Balancer (Stochastic Load Bal-

ancer, 2016) is based on the cost of region load,

table load, data locality, MemStore sizes, store ﬁle

sizes and change the state of the cluster.

• Capacity-aware load balancer unlike other bal-

ancers takes into consideration the capacity and

the characteristics of the nodes and distribute the

load according to the capacities of the machines.

• Table region balancer is based on distributing ta-

ble equally on all region servers. This balancer

results in good performance when clients requests

the data from same table.

To the best of our knowledge none of the above

balancers consider: (1) the average response time of

clients’ requests and; (2) the number of requests per

keys, where we can perform an efﬁcient split based

on balanced keys as presented in our algorithm.

Table 4: Execution times (seconds) - 4 clients - 4 keys.

Requests RT Before RT After Improvement

100,000 67.07 61.13 8.86%

250,000 167.96 151.37 9.88%

500,000 329.74 298.64 9.43%

750,000 511.57 448.59 12.31%

1,000,000 658.01 595.65 9.48%

User-based Load Balancer in HBase

367

4.2 Mixed Load Balancer

In Locality-Aware Load Balancer for HBase (Ke-

wal Panchputre and Garg, 2016), they implemented

an algorithm to combine different types of load bal-

ancers supported by HBase. The locality load bal-

ancer takes into consideration server balance, table

balance and locality. The algorithm was tested on ba-

sics read write operations where it shows a better per-

formance than simple load balancer. The proposed

solution does not take into consideration neither the

balance key to do optimized splits nor the average re-

sponse time of clients’ requests.

4.3 HBase Monitoring

Hannibal (Hannibal, 2016) introduced a monitoring

tool to help HBase administrators to monitor and

maintain HBase clusters that are conﬁgured for man-

ual splitting. The proposed tool introduces monitor-

ing technique for the region distribution on the cluster

and region splits per table. Moreover, it displays the

regions of a table ordered by size to help administra-

tors making decision of splitting. Nonetheless, it does

not provide an automatic split or move of the regions

and the administrator has to manually distribute the

regions based on the reported results.

4.4 Latency-based Optimization

The basic motivation of our algorithm was the so-

lution proposed in (Sharov et al., 2015) to dynami-

cally handle leader selection in distributed systems by

monitoring client workload for previous time frames.

Then, based on certain threshold and the location of

the servers, the leader will be selected. The consid-

ered workload is the global load in the cluster and

not the local one. Moreover, the clients are dynami-

cally grouped according to their location and requests

(read/write). The leader election algorithm is parti-

tioned in two phases:

• Leader placement based on averaging latency of

server operations. The latency is calculated based

on the last time interval (1 day) and introducing a

weight decay parameter to compute latency based

on past intervals.

• Leader and Replica roles: in this tier the algorithm

optimizes the voters selection in quorum based on

replica location the selected leader.

5 CONCLUSION AND FUTURE

WORK

We propose an algorithm that enhances client opera-

tion latency by monitoring and dynamically balancing

(by splitting or moving regions) the region servers of

HBase system based on the most requested keys and

the average response time of clients’ requests. The

evaluation shows that our algorithm reduces the la-

tency of client requests in case where some keys are

highly requested.

For future work, we consider several directions.

First, we want to extend our algorithm to take into

account write operations. Second, we consider testing

our algorithm on larger clusters and tables. Third, we

want to introduce an automatic compaction of regions

when the number of regions becomes too small.

REFERENCES

Chang, F., Dean, J., Ghemawat, S., Hsieh, W. C., Wallach,

D. A., Burrows, M., Chandra, T., Fikes, A., and Gru-

ber, R. E. (2008). Bigtable: A distributed storage sys-

tem for structured data. ACM Trans. Comput. Syst.,

26(2).

Favored Node Load Balancer (2016). Favored Node

Load Balancer. https://hbase.apache.org/

devapidocs/org/apache/hadoop/hbase/master/

balancer/FavoredNodeLoadBalancer.html.

Ghemawat, S., Gobioff, H., and Leung, S. (2003). The

google ﬁle system. In Proceedings of the 19th ACM

Symposium on Operating Systems Principles 2003,

SOSP 2003, Bolton Landing, NY, USA, October 19-

22, 2003, pages 29–43.

Hadoop (2016). HDFS. https://hadoop.apache.org/

docs/r1.2.1/hdfs_design.html.

Hannibal (2016). Hannibal HBase. https://github.com/

sentric/hannibal.

Kewal Panchputre, P. C. and Garg, R. (2016). Locality-

aware load balancer for hbase. Technical report, Uni-

versity of Minnesota, Twin Cities.

Sharov, A., Shraer, A., Merchant, A., and Stokely, M.

(2015). Take me to your leader! online optimiza-

tion of distributed storage conﬁgurations. PVLDB,

8(12):1490–1501.

Simple Load Balancer (2016). Simple Load Bal-

ancer. https://hbase.apache.org/devapidocs/

org/apache/hadoop/hbase/master/balancer/

SimpleLoadBalancer.html.

Stochastic Load Balancer (2016). Stochastic Load Bal-

ancer. https://hbase.apache.org/devapidocs/

org/apache/hadoop/hbase/master/balancer/

StochasticLoadBalancer.html.

CLOSER 2017 - 7th International Conference on Cloud Computing and Services Science

368
