High Availability and Performance of Database in the Cloud

Traditional Master-slave Replication versus Modern Cluster-based Solutions

Raju Shrestha

Oslo and Akershus University College of Applied Sciences, Oslo, Norway

Keywords:

High Availability, Performance, Cloud, Database Replication, Master-slave, Galera Cluster, MariaDB.

Abstract:

High availability (HA) of database is critical for the high availability of cloud-based applications and services.

Master-slave replication has been traditionally used since long time as a solution for this. Since master-slave

replication uses either asynchronous or semi-synchronous replication, the technique suffers from severe

problem of data inconsistency when master crashes during a transaction. Modern cluster-based solutions

address this through multi-master synchronous replication. These two HA database solutions have been

investigated and compared both qualitatively and quantitatively. They are evaluated based on availability

and performance through implementation using the most recent version of MariaDB server, which supports

both the traditional master-slave replication, and cluster based replication via Galera cluster. The evaluation

framework and methodology used in this paper would be useful for comparing and analyzing performance of

different high availability database systems and solutions, and which in turn would be helpful in picking an

appropriate HA database solution for a given application.

1 INTRODUCTION

In computing, high availability (HA) refers to a

system or service or component that is continuously

operational for a desirably long length of time.

Availability is often expressed as expected system

uptime (in percentage) in a given period of time (such

as in a week or a year). 100% availability indicates

that the system is “always on” or “never failing”. For

instance, 90% availability (one nine) in a period of

one year means the system can have up to 10%, i.e.,

36.5 days of down time.

There are basically three principles, which can

help achieve high availability. They are (a)

elimination of single point of failure (SPOF) by

adding redundancy, (b) reliable crossover from a

failed to a standby component, and (c) detection of

failures as they occur (Piedad and Hawkins, 2001).

In today’s always-on, always-connected world,

high availability is one of the important quality

attributes of a cloud-based application or service.

High availability of all the system components

such as the application itself, storage, database

etc. contributes to the high availability of the

entire application. Since most of the cloud-based

applications and services, in general, are dynamic

database-driven web-based applications, database

plays an important role in the system’s high

availability. Therefore, the focus of this paper is on

high availability database.

Traditionally, master-slave (single master,

multiple slaves) based database replication

techniques (Ladin et al., 1992; Wiesmann et al.,

2000; Earl and Oderov, 2003; Wiesmann and

Schiper, 2005; Curino et al., 2010) is being used

as a solution for high availability databases since

more than 15 year. Most recently, multi-master

cluster-based database replication techniques such

as MariaDB Galera cluster (Galera Cluster, 2016),

MySQL cluster (MySQL, 2016) have been made

available as more effective alternatives.

In this paper we have studied and evaluated

master-slave and cluster-based HA database solu-

tions, qualitatively as well as quantitatively. In our

study, the most recent version of MariaDB server

at the time (v10.1) that has built-in Galera cluster

support is used. MariaDB was chosen because it is not

only free, open and vibrant, but also has more cutting

edge features and storage engines, compatible with

MySQL, performsbetter,and easy to migrate (Seravo,

2015). Performance comparison has been made

based on the benchmark results obtained on an

OpenStack/DevStack cloud platform.

Shrestha, R.

High Availability and Performance of Database in the Cloud - Traditional Master-slave Replication versus Moder n Cluster-based Solutions.

DOI: 10.5220/0006294604130420

In Proceedings of the 7th International Conference on Cloud Computing and Services Science (CLOSER 2017), pages 385-392

ISBN: 978-989-758-243-1

385

2 TWO MAJOR HIGH

AVAILABILITY DATABASE

SOLUTIONS

HA databases use an architecture which is designed to

continue working normally even in case of hardware

or network failures within the system and end users

do not experience any interruption or degradation of

service. HA database aims not only for reduced

downtime, but also for reduced response time and

increased throughput (Hvasshovd et al., 1995). HA

database cannot be retroﬁt into a system; rather it

should be designed in the early stages to provide

minimal downtime, optimal throughput and response

time, in order to maximize customer satisfaction.

Different applications can have very different

requirements for high availability. For instance, a

mission critical system needs 100% availability with

24x7x365 read & write access while many other

systems are better served by a simpler approach with

more modest high availability ambitions. Adding

high availability increases complexity and cost.

Therefore, an appropriate solution needs to be chosen

for a given application at hand.

Various techniques and solutions have been

proposed and used for HA databases. Widely

used open-source databases such as MariaDB and

MySQL has an array of high availability solutions

ranging from simple backups, through replication and

shared storage clustering all the way up to 99.999%

availability (i.e. 5mins. of downtime per year), shared

nothing, geographically replicated clusters.

In general, HA database solutions can be broadly

categorized into two types: master-slave (master-

replica) architecture and multi-master cluster-based

architecture. The two architectures offer different

guarantees on Brewer’s CAP theorem, which states

that it is impossible for a distributed system

to simultaneously provide more than two out of

three guarantees among consistency, availability,

and partition tolerance (Brewer, 2012). The two

architectures are described in the following two

subsections.

2.1 Master-slave Architecture

Master-slave architecture is a traditional solution,

which is commonly used since long time in the

database world, where one master handles data writes

and multiple slaves are used to read data. In many

applications, a large number of end users use services,

which require data reading from the database and

small number (mostly by system administrators) does

data writing for database updates. Such systems use

read-write splitting mechanism whereby a primary

database server (master) is used for data writing

while slave multiple database servers (slaves) are load

balanced for data reading. The architecture thus

supports read scalability as the number of slaves can

be scaled out easily in a cloud according to needs

at a given time. Figure 1 illustrates a master-slave

architecture. Most of the popular databases such as

MariaDB, MySQL, Microsoft SQL Server support

master-slave architecture.

Slave 1 Master Slave 2

Web server

Data read

Data

write

Figure 1: Master-slave architecture.

Wheneverthere is a change in the master database,

the change is applied in all the slaves, the process

known as database replication. The replication

process is normally asynchronous (Wiesmann et al.,

2000; Elnikety et al., 2005), which means the

master does not check to conﬁrm if slaves are

always up-to-date. Asynchronous replication does

not guarantee about delay between applying changes

on master node and propagation of changes to

slave nodes. Therefore, slave databases are always

bit outdated. Moreover, as the delay could be

short and long, some latest changes may be lost,

when the master crashes. This may cause data

inconsistencies when something goes wrong in the

master in the middle of a transaction. Newer

versions of widely adopted open-source databases

such as MariaDB and MySQL provide support for

semi-synchronous replication, which makes sure at

least one slave is synchronized with the master.

After committing a transaction, master waits for an

acknowledgment from that slave. However, this

still does not prevent from data inconsistencies in

other slaves. Therefore, according to the CAP

theorem, master-slave replication provides guarantee

of availability and partition tolerance at the sacriﬁce

of consistency.

Master-slave replication does not provide high

availability of the master itself. It is used along

with a tool such as MariaDB replication manager

(MRM) (MariaDB, 2016) and master high availability

(MHA) (Matsunobu, 2016) in order to promote a

CLOSER 2017 - 7th International Conference on Cloud Computing and Services Science

386

slave to a master (automatic failover) when master

fails. These tools keep monitoring master and if

the master server goes down, it quickly promotes

a slave as the new master. It will also switch the

IP of the old master to the new master, so that

applications do not need to be reconﬁgured. In

theory, master-slave HA database solution looks quite

simple and straightforward. However, in practice, the

transfer of the master role during failover might result

in some downtime.

2.2 Cluster-based Multi-master

Architecture

This is a relatively new solution where HA database

is often achieved through a multi-master architecture

that uses clustering, in which multiple servers (called

nodes) are grouped together. Any node within a

cluster can respond to both read and write requests.

Change of data in a node is replicated across

all nodes in the cluster instantly, thus providing

system redundancy and minimizing the possibility

of downtime. Figure 2 illustrates a cluster-based

architecture.

Master 1

Master 3

Master 2

Web server

Figure 2: Cluster-based multi-master architecture.

Replication in a cluster-based architecture is per-

formed synchronously, which unlike asynchronous

replication, guarantees that if any change happens on

one node of the cluster, the change is applied in other

nodes as well at the same time. Therefore, even when

a node fails, the other nodes continue working and

hence the failure has no major consequences. The

data gets replicated from the existing nodes when

the failed node joins the cluster again later. It thus

maintains data consistency. However, in practice,

synchronous database replication has traditionally

been implemented via the so-called 2-phase commit

or distributed locking, which proved to be very

slow. Because of low performance and complexity

of implementation of synchronous replication, asyn-

chronous replication has long been remained as the

dominant solution for high availability database.

MySQL cluster (MySQL, 2016) stores a full copy

of the database in multiple servers so that each

server will be independently function as the master

database. But this method results in data conﬂicts

when there is a network connection problem. Galera

cluster addresses this problem through conditional

updates whereby each server accepts new updates

only if it can reach a majority of other servers.

It uses active eager replication based on the

optimistic approach (Gautam et al., 2016) to ensure

local consistency, and handles data write conﬂicts

using certiﬁcation-based replication based on group

communication and transaction ordering techniques

(Pedone et al., 1997; Pedone, 1999; Kemme and

Alonso, 2000) to enforce global consistency. Galera

cluster replication combines these techniques to

provide a highly available, transparent, and scalable

synchronous replication solution. According to the

CAP theorem, Galera cluster guarantees consistency

and availability of the database. We have used

MariaDB Galera cluster in our study.

2.3 Selection of a Database Server

In both master-slave and cluster-based replication

setups, there should be a way to determine which

database server is to be selected for a database access

(or transaction). In general, scaled-out database

servers are load balanced. There are mainly two ways

database selection is implemented. First method is to

handle the selection mechanism at the application tier,

and the second method is to handle it separately using

a database proxy.

An example of the ﬁrst method is to handle the

database selection using the PHP MySQL Native

driver (PHP-MySQLnd) and its master-slave plugin

MySQLnd MS (Shaﬁk, 2014). This is applicable

for master-slavearchitecture only, and MySQLnd MS

is so far not yet available for newer versions of

PHP including the current version 7. Load-balancing

and failover strategies are deﬁned in MySQLnd

conﬁguration. The plugin redirects database query

to a database server based on read-write splitting,

where all write access is directed to master and

all read statements to a slave selected based on a

load balancing strategy. Automatic master failover

is done based on failover strategy deﬁned in the

conﬁgurations. An advantage of this method is

that it does not require any additional hardware.

High Availability and Performance of Database in the Cloud - Traditional Master-slave Replication versus Modern Cluster-based Solutions

387

However, there are several disadvantages with this

method. A conceptual drawback of this method is that

handling database selection in the application side

(or tier) blurs the separation between application and

database. Read-write splitting with MySQLnd

is naive as it assumes all queries starting with

SELECT as read statements, but there could be

write statements starting with SELECT. Master

failover is not instantaneous as it takes some time

(which might be several minutes) to determine

if the master is failed before promoting a slave

to master, and this causes database unavailability

for that time. Since all the web servers (PHP

servers) needs to be conﬁgured for MySQLnd

plugin, this could be annoying when one need to

change environment, for example when adding a

new slave. A possible solution to minimize the

changes that need to be done on the PHP-MySQLnd

conﬁguration ﬁle is to use a proxy server such as

HAProxy between PHP driver and database together

with PHP-MySQLnd (Severalnines, 2016). Proxy

server provides a single point database access to

the application. Since HAProxy is not SQL-aware,

MySQLnd

MS is required to understand the type of

SQL statement.

A better approach is to use a SQL-aware proxy

server such as MaxScale, which not only provides a

single point access to the application but it also fully

decouples application and database processes. The

proxy server redirects a SQL query to an appropriate

database server/node. The method is applicable for

both master-slave and cluster-based database setups.

MaxScale, which is considered a next generation

database proxy, is an open source project developed

by MariaDB. It can load balance both connectionsand

individual database requests, ﬁlter requests according

to a set of deﬁned rules, and monitor availability,

utilization, and load on back-end servers to prevent

requests from going to overburdened and unavailable

resources (Trudeau, 2015; MaxScale, 2016). We

use database proxy method using MaxScale in our

implementation.

3 EXPERIMENTAL SETUP

Experiments are performed in a single machine

OpenStack cloud setup using DevStack. DevStack

is installed in a VMware virtual machine (VM) on

a MacBook Pro machine. VMware was chosen as

it supports nested virtualization. The speciﬁcation of

the computer and the VM used is given below.

Speciﬁcation of the computer:

• CPU: Intel(R) Core i7 3.1GHz processor

• Memory: 16GB

• OS: MacOS Sierra

Speciﬁcation of the VMware VM:

• CPU: 2 processor cores

• Memory: 9GB

• Hard disk: 50GB

• Network: two Network Interface Cards (NICs),

one with NAT to get access to the Internet via host

machine and one with vmnet2 which is used as a

public network interface for accessing VMs from

outside

• Advanced options: VT-x/EPT and code proﬁling

enabled

• OS: Ubuntu 16.04 LTS (Xenial Xerus)

Eight servers were provisioned in the OpenStack

cloud for a widely used LAMP stack (Linux, Apache,

MySQL, PHP) based cloud service (Infrastructure as

a Service-IaaS) architecture for a high availability

dynamic database-driven web application, which

consists of two Apache2 web servers that are load

balanced with two HAProxy 1.6 load balancers, three

MariaDB database servers, and a MariaDB MaxScale

server, all running Ubuntu 16.04 (Xenial Xerus) from

the cloud image available on the web (Ubuntu, 2016).

Figure 3 depicts the cloud system setup. All the

three database servers are installed with MariaDB

server v10.1, which comes with built-in Galera cluster

support. MaxScale v2.1 server is installed and used as

a database proxy server in both the master-slave and

Galera cluster setups.

In the master-slave database replication setup,

one server is used as the master and the other

two servers are used as slaves. Global transaction

id (GTID) based replication is used as it has

many beneﬁts compared to the traditional bin-log

based replication (Combaudon, 2013). Automatic

master failover mechanism is implemented with

MariaDB replication manager (MRM). In the Galera

cluster-based setup, MariaDB 10.1 installed in the

three database servers are conﬁgured to use Galera

cluster. The three servers then act as three nodes of a

cluster. If there is any change in one node, the changes

will be updated in the other two nodes synchronously.

Synchronization method is set to use rsync. In both

setups, slaves are load balanced with equal server

weights.

CLOSER 2017 - 7th International Conference on Cloud Computing and Services Science

388

Database

server 1

Database

server 2

Database

server 3

Database proxy

(MaxScale)

Web server 1

(Apache 2)

Web server 2

(Apache 2)

Load balancer 1

(HAProxy)

Load balancer 2

(HA Proxy)

(

)

Database er

Internet

Figure 3: Cloud setup used in experiments.

A widely used open source benchmark suite,

Sysbench (Sysbench, 2016), speciﬁcally OLTP

(Online Transaction Processing) benchmark, is used

to evaluate and compare performance of the two

setups under intensive loads, using the same set of

parameters. Sysbench v0.5 is installed and executed

from the DevStack VM. All database is thus accessed

through the MaxScale proxy server.

4 EXPERIMENTAL RESULTS

Test database is prepared with 50 tables of size

10000, Pareto distribution for an OLTP test using

Sysbench. Then test runs are executed for readonly

and read-write with different number of threads n

(which corresponds to concurrent clients), for n =

1,8,16,32,64, 72,80. The three Sysbench commands

used for test database preparation, read-onlytests, and

read-write tests respectively are given below. OLTP

read-write benchmark simulates a real-world usage

consisting of 70% read (SELECT) and 30% write

(INSERT, UPDATE, DELETE) operations.

sysbench --test=/usr/share/doc/sysbench/tests/

db/oltp.lua --oltp_tables_count=50 --

oltp_table_size=10000 --mysql-host=

maxscale --mysql-user=root --rand-type=

pareto --rand-init=on prepare

sysbench --test=/usr/share/doc/sysbench/tests/

db/oltp.lua --oltp-read-only=on --oltp-

reconnect=on --oltp-reconnect-mode=random

--num-threads=n --mysql-host=maxscale --

mysql-user=root --max-requests=5000 --rand

-type=pareto --rand-init=on run

sysbench --test=/usr/share/doc/sysbench/tests/

db/oltp.lua --oltp-read-only=off --oltp-

test-mode=complex --oltp-reconnect=on --

oltp-reconnect-mode=random --num-threads=n

--mysql-host=maxscale--mysql-user=root --

max-requests=5000 --rand-type=pareto --

rand-init=on run

Performance is measured in terms of throughput

(transactions per second [tps]) and response time

(or latency), for both read-only and read-write tests.

For statistically robust results, tests are repeated for

twenty times. Figure 4 and 5 show plots from the

test results of the readonly and read-write tests on

both HA database solutions. Figure 4 shows the

performance in terms of throughput, whereas Figure 5

shows the performance in terms of response time.

Mean and standard error of the mean (SEM) are

computed from the twenty tests. The plots show

the mean values, along with the lower and the upper

bounds of the 95% conﬁdence intervals shown as

vertical lines bounded by shaded areas. Conﬁdence

intervals are computed as Mean − 1.96 × SEM and

Mean + 1.96 × SEM (assuming normal probability

distribution), where SEM is given by Std./

√

Std. being the standard deviation and N the sample

size (Moore et al., 2010).

From the performance plots, we see that in

readonly tests, throughput increases sharply when the

number of threads increases from 1 to 16, then the

increment slows down and drops on further increasing

the number of threads beyond 64. This trend is

similar in both the master-slave and Galera cluster

based implementations. The trend also follows in

read-write tests but changes occur at different number

of threads (8 and 16). Drop of performance after

certain number of threads in general occurs because

of internal contention and row locks. Average

response time increases with more or less linearly

with the increase in the number of threads, indicating

a consistent increase in latency under an increasing

load. Both HA solutions have similar performance

in readonly tests. However, master-slave setup shows

better performance both in terms of throughput and

response time in read-write tests.

High Availability and Performance of Database in the Cloud - Traditional Master-slave Replication versus Modern Cluster-based Solutions

389

1 8 16 32 64 72 80

Number of threads

100

120

140

160

180

Throughput (tps)

Galera cluster (Readonly)

Master slave (Readonly)

Galera cluster (Read/Write)

Master slave (Read/Write)

Figure 4: Throughputs from tests with different number of

threads.

1 8 16 32 64 72 80

Number of threads

500

1000

1500

2000

2500

3000

3500

Response time (ms)

Galera cluster (Readonly)

Master slave (Readonly)

Galera cluster (Read/Write)

Master slave (Read/Write)

Figure 5: Response time from tests with different number

of threads.

Next, the two setups were investigated for

their behaviors under various failure scenarios. In

master-slave setup, when one or both the slaves were

down, the system continued to work as expected as

both data read and write was provided by the live

master. When the two slaves were working but the

master was crashed, it took signiﬁcant time (more

than one minute) for MariaDB replication manager

to check if the master is down and then promote a

slave to the new master. However, in Galera setup,

the system worked smoothly without showing any

failure-related symptoms even when one or two nodes

were crashed.

5 COMPARATIVE ANALYSIS

AND DISCUSSION

In this section, we analyze, compare and discuss

the two HA database solutions, qualitatively and

quantitatively.

Qualitative Analysis: Because of loosely coupled

master-slave nature in asynchronous replication, slave

can be arbitrarily behind the master in applying

changes, and hence read on a slave can give old

data. More seriously, upon the master’s failure,

slave may not have latest committed data resulting

in data loss. This might stall failover to a slave

until all transactions have been committed as it

is not instantaneous. This is true in the case of

semi-synchronous replication as well even though

it guarantees one slave to be synchronized with

the master. Read scale-out is straightforward, in

master-slave setup, but write scale-out is not.

Synchronous replication in a cluster-based setup

guarantees all slaves to receive and commit changes

in the master and this in turn guarantees latest

data to be read from any slave. Master failover

to a slave is integrated and automatic, which

makes sure data writes to continue on new master

almost instantaneously. Therefore, this high

availability solution is more effective compared to the

master-slave replication based solution. Moreover,

the setup supports both read and write scalability.

In both master-slave and cluster-based solutions,

replication overhead increases with the number of

nodes/slaves present in the system. Failure test results

show that cluster-based setup do not suffer from

any failure related hiccups unlike with master-slave

setup as failure situations are handled smoothly and

transparently.

CLOSER 2017 - 7th International Conference on Cloud Computing and Services Science

390

Quantitative Analysis: Quality of a database

system is measured quantitativelyby high availability,

throughput, and response time (Hvasshovd et al.,

1995). In this paper,we compare the two HA database

solutions based on throughput and response time

under heavy database loads.

From the experimental results, we see that

throughput is much higher and response time is

much lower from readonly tests compared to those

read-write tests, in both HA setups. This is expected

as data writing takes signiﬁcantly longer time than

data reading. Moreover, data needs to be replicated or

synchronized after writing in the master, which takes

some time. In the case of read-write tests, throughput

from the Galera cluster setup was lower compared

to the master-slave setup. This is because there is

signiﬁcant overhead due to synchronous replication in

the former setup. This is also reﬂected by the higher

response time. However, both HA solutions show

similar performance for readonly tests, since there is

no synchronization required and hence no delay in

readonly tests,

Based on both the qualitative and the quantitative

analysis of the two HA database solutions, Table 1

provides a comparative summary.

Table 1: Comparison table between master-slave and

cluster-based HA database solutions. Texts shown in

green

indicate advantageous over the one shown in red.

Master-slave HA soluon Galera cluster-based soluon

Replicaon type Asynchronous or semi-synchronous Synchronous

Automac failover Need to use a tool such as MRM, MHA Built-in

Extra hardware Can be implemented without one Required for at least one database proxy

Minimum number of servers 1 3

Failover delay Not instantaneous Instantaneous

Data loss Possible No

Data inconsistency Possible No

Scale-out Read scale-out Both read and write scale-out

Availability Lower Higher

Throughput Higher Lower

Response me Lower Higher

It is important to note the limitations of the

experiments carried out in this work. Firstly, even

though OLTP benchmark is designed to make it

close to a common real-world scenario, it may not

truly represent real-world application. Secondly,

experiments are carried out in a single machine

OpenStack cloud setup using DevStack within a

VMware virtual machine and role of virtualization

has not been considered. However, it can be

expected that the relative results obtained reﬂect the

performance and behavior that is good enough to have

a general impression about the two HA solutions.

This work can be considered our ﬁrst step towards

the study of major HA database solutions. Future

work could be to extend this with an extensive

study of various other major solutions as well

including database sharding techniques, which has

gain popularity over the past several years. The

study could include more testing and detailed failover

scenarios.

6 CONCLUSIONS

This paper investigated effectiveness of the two major

solutions to high availability database solutions:

traditional master-slave replication and modern

cluster-based techniques. Performance evaluation of

both solutions implemented using MariaDB 10.1 with

Galera cluster has shown that traditional master-slave

replication solution performs equal or better in terms

of throughput and response time. Because of simpler

setup and better performance, this method is still

being widely used. However, cluster-based solution

is superior when it comes to high availability, data

consistency and scalability as it offers instantaneous

failover, no data inconsistency and loss of data, and

at the same time providing both read and write

scalability. Therefore, despite some performance

lag, Galera cluster is an effective solution for

applications and services where data consistency and

high availability is critical.

REFERENCES

Brewer, E. (2012). Pushing the cap: Strategies for

consistency and availability. Computer, 45(2):23–29.

Combaudon, S. (2013). Replication in MySQL 5.6:

GTIDs beneﬁts and limitations - Part 1 & 2.

https://www.percona.com/blog/2013/05/21/replication-

in-mysql-5-6-gtids-beneﬁts-and-limitations-part-1/,

https://www.percona.com/blog/2013/05/30/replication-

in-mysql-5-6-gtids-beneﬁts-and-limitations-part-2/.

Blog.

Curino, C., Jones, E., Zhang, Y., and Madden, S. (2010).

Schism: A workload-driven approach to database

replication and partitioning. Proc. VLDB Endow.,

3(1-2):48–57.

Earl, L. and Oderov, S. (2003). Database replication system.

US Patent App. 10/426,467.

Elnikety, S., Pedone, F., and Zwaenepoel, W. (2005).

Database replication using generalized snapshot

isolation. In 24th IEEE Symposium on Reliable

Distributed Systems (SRDS’05), pages 73–84.

Galera Cluster (2016). MariaDB Galera Cluster.

https://mariadb.com/kb/en/mariadb/galera-cluster/,

http://galeracluster.com/. Last access: Nov. 2016.

High Availability and Performance of Database in the Cloud - Traditional Master-slave Replication versus Modern Cluster-based Solutions

391

Gautam, B. P., Wasaki, K., Batajoo, A., Shrestha, S.,

and Kazuhiko, S. (2016). Multi-master replication

of enhanced learning assistant system in IoT cluster.

In 2016 IEEE 30th International Conference on

Advanced Information Networking and Applications

(AINA), pages 1006–1012. IEEE.

Hvasshovd, S.-O., Torbjørnsen, O., Bratsberg, S. E., and

Holager, P. (1995). The clustra telecom database:

High availability, high throughput, and real-time

response. In Proceedings of the 21th International

Conference on Very Large Data Bases, VLDB ’95,

pages 469–477, San Francisco, CA, USA. Morgan

Kaufmann Publishers Inc.

Kemme, B. and Alonso, G. (2000). Don’t be lazy, be

consistent: Postgres-R, a new way to implement

database replication. In VLDB, pages 134–143.

Ladin, R., Liskov, B., Shrira, L., and Ghemawat, S. (1992).

Providing high availability using lazy replication.

ACM Trans. Comput. Syst., 10(4):360–391.

MariaDB (2016). MariaDB Replication Manager.

https://github.com/tanji/replication-manager. Last

access: Dec. 2016.

Matsunobu, Y. (2016). MySQL Master High Availability

(MHA). https://code.google.com/p/mysql-master-ha/.

Last access: Dec. 2016.

MaxScale (2016). MariaDB MaxScale. https://

mariadb.com/products/mariadb-maxscale. Last ac-

cess: Nov. 2016.

Moore, D., McCabe, G. P., and Craig, B. (2010).

Introduction to the Practice of Statistics. W. H.

Freeman, 7th edition.

MySQL (2016). MySQL Cluster. https://www.mysql.com/

products/cluster/. Last access: Dec. 2016.

Pedone, F. (1999). The database state machine and

group communication issues. PhD thesis,

Ecole

Polytecnique F´ed´erale de Lausanne, Switzerland.

Pedone, F., Guerraoui, R., and Schiper, A. (1997).

Transaction reordering in replicated databases. In

Reliable Distributed Systems, 1997. Proceedings., The

Sixteenth Symposium on, pages 175–182.

Piedad, F. and Hawkins, M. (2001). High availability:

Design, techniques and processes. Prentice Hall.

Seravo (2015). 10 reasons to migrate to Mari-

aDB. https://seravo.ﬁ/2015/10-reasons-to-migrate-to-

mariadb-if-still-using-mysql. Blog.

Severalnines (2016). High availability read-write splitting

with PHP-MySQLnd, MySQL replication and

HAProxy. http://severalnines.com/blog/high-

availability-read-write-splitting-php-mysqlnd-mysql-

replication-and-haproxy. Last access: Nov. 2016.

Shaﬁk, D. (2014). Easy read/write splitting with PHPs

MySQLnd. https://blog.engineyard.com/2014/easy-

read-write-splitting-php-mysqlnd. Blog.

Sysbench (2016). Sysbench 0.5.

http://repo.percona.com/apt/pool/main/s/sysbench/.

Last access: Nov. 2016.

Trudeau, Y. (2015). MaxScale: A new tool to

solve your MySQL scalability problems.

https://www.percona.com/blog/2015/06/08/maxscale-

a-new-tool-to-solve-your-mysql-scalability-

problems/. Blog.

Ubuntu (2016). Ubuntu 16.04 LTS (Xenial Xerus). https://

cloud-images.ubuntu.com/releases/xenial/release/.

Last access: Nov. 2016.

Wiesmann, M., Pedone, F., Schiper, A., Kemme, B., and

Alonso, G. (2000). Database replication techniques: a

three parameter classiﬁcation. In Reliable Distributed

Systems, 2000. SRDS-2000. Proceedings of The 19th

IEEE Symposium on, pages 206–215.

Wiesmann, M. and Schiper, A. (2005). Comparison of

database replication techniques based on total order

broadcast. IEEE Transactions on Knowledge and

Data Engineering, 17(4):551–566.

CLOSER 2017 - 7th International Conference on Cloud Computing and Services Science

392
