Public Transport Stops State Detection and Propagation

Warsaw Use Case

Marcin Luckner

, Paweł Kobojek

and Paweł Zawistowski

Faculty of Mathematics and Information Science, Warsaw University of Technology, Koszykowa 75, Warsaw, Poland

Institute of Computer Science, Faculty of Electronics and Information Technology, Warsaw University of Technology,

Nowowiejska 15/19, Warsaw, Poland

Keywords:

Open Data, Public Transport, Text Mining, Events Detection, Geographic Information System.

Abstract:

Publication of information on public transport in a form acceptable to third–party developers can improve a

quality of services offered to the citizens. Usually, published data are limited to localisations of the stops and

the schedules. However, a public transport model based on these data is incomplete without information about

a current state of the stops. In this paper, we present a system that observes public sources of information on

public transport such as Twitter feeds and ofﬁcial web pages hosted by the City of Warsaw. The incoming

messages are parsed to extract information on events that concern public transport lines and stops. Extracted

information allows us to detect a current state of the stops and to create linguistically independent and spatial

oriented information in Geography Markup Language format that can be published using a web service. The

system has been tested on real data from Warsaw district and the suburban zones.

1 INTRODUCTION

Public transport is an area that still needs improve-

ment to satisfy its users. The public transport user’s

perception survey showed that the most important fac-

tors in public transport evaluation are on–time perfor-

mance and reduction of waiting time (Nesheli et al.,

2016). These criteria are strongly connected with

stops and their current state.

Lack of information about the current state of

the stops inﬂuence on public transport users’ percep-

tion.When the user suddenly discovers that the stop is

closed or the schedule on the stop is temporary chan-

ged his evaluation of the public system will decrease.

Similarly, lack of knowledge about newly opened or

reopened stops disturbs the user to take an advantage

of public transport.

The City of Warsaw – as many other cities – pu-

blishes information about changes in public trans-

port using various forms such as Rich Site Summary

(RSS) or Tweeter. Figure 1 shows examples of publi-

shed messages. However, the messages are published

in Polish, without spatial localisation, and in the form

that cannot be directly reused in third–party applica-

tions.

The last factor is critical because recent studies

emphasise the role of Open Data also as an enabler

of innovation (Lakomaa and Kallberg, 2013). Among

other purposes in this area, Open Data can be used

for application development (Lakomaa and Kallberg,

2013; Lindman et al., 2014). For example, 43 percent

of surveyed Swedish start-up IT entrepreneurs ﬁnd

Open Data essential for their business plans (Lako-

maa and Kallberg, 2013). Other survey showed, that

most frequently designed and developed applications

involve location based services (LBS) and dynami-

cally changing urban data (Grabowski et al., 2015).

Therefore, a proper politics in city data opening may

increase services for the citizens. Moreover, informa-

tion on stops’ states are critical for public transport

information systems and modelling (see Section 2).

In this paper, we presented a system that collects

text data on public transport produced by the city hall.

The data are collected from several sources including

public city web pages and Twitter (Section 3). Next,

the collected data are parsed to extract information

about lines, stops, a type of the event, and a time span

for the event (Section 4). The collected information is

used to detect a current state of the public transport

stops. Finally, the information is transferred into a lo-

calised form that contains a linguistically independent

graphical presentation and can be reused through web

services (Section 5). The system was tested on real

data from City of Warsaw (Section 6).

Luckner, M., Kobojek, P. and Zawistowski, P.

Public Transport Stops State Detection and Propagation - Warsaw Use Case.

DOI: 10.5220/0006305102350241

In Proceedings of the 6th International Conference on Smart Cities and Green ICT Systems (SMARTGREENS 2017), pages 235-241

ISBN: 978-989-758-241-7

235

(a) RSS

(b) Twitter

Figure 1: The examples of information about public trans-

port events. The ﬁrst example 1(a) is a well structured

HTML broadcast as RSS. The second example 1(b) refers

to the same event. The link in the tweet links to the same

HTML.

2 RELATED WORK

Our system is a dynamic solution that informs about

events that inﬂuence public transport but may not be

noted in timetables.

Work (Tyrinopoulos, 2004) summarised types of

models available in the public transport business. On-

ly 11 percent of them were dynamics models that inc-

lude real-time passenger information. That stress de-

mand on dynamic systems.

Work (García et al., 2009) named three main

subsystems of public transport information systems:

timetable information subsystem, route information

subsystem, and payment subsystem. In this categori-

sation a state of the stop is included in timetable infor-

mation subsystem. An existence of a timetable sugge-

sts that the stop is working. Unfortunately, very often

the schedules are not modiﬁed when stops are closed

because of a sudden or temporary event.

Information on stops’ states are also critical for

any public transport model (Zheng et al., 2016; Ro-

drigues et al., 2016; Álvarez et al., 2010). The model

should disable closed stops and enable reopened ones.

Our system can conveys such information.

Work (Rathod and Khot, 2016) proposed an inte-

resting alternative in a detection of events that inﬂu-

ence the schedules. A multi-sensor system in a bus

detects accidents and simultaneously sends informa-

tion to public transport system.

3 COLLECTION OF TEXT DATA

In order to get some insights into the current state of

transport stops ﬁrst raw data needs to be collected and

analysed. After preliminary analysis of the available

data sources, four relevant text feeds have been cho-

sen:

• RSS (http://www.ztm.waw.pl/rss.php) and Twit-

ter (https://twitter.com/ztm_warszawa) feeds ho-

sted by the Public Transport Authority in War-

saw, which contain important information about

the municipal communication system,

• articles posted on http://warszawa19115.pl/

glowna website which often indicates important

events within the city which might inﬂuence also

the transportation,

• information submitted by Warsaw citizens direc-

tly to 19115 which is the name of one of the ofﬁ-

cial API services hosted by the city of Warsaw.

3.1 Overall Architecture

The task of getting external text data into our system

consists of two parts:

1. retrieving data directly from the feed sources, par-

sing and identifying external weblinks – which

is the responsibility a python component called

VaVelFeeds,

2. fetching the external links along with all their

dependencies (i.e. links present on the fetched

HTML pages) – which is handled by a Spark Stre-

aming job called UriDownloader.

The main reason behind having two components

responsible for downloading web data is that the feed

messages might link to external ﬁles of various types

like for example images or video clips which may be

large in size. Therefore a decision has been made to

handle downloading and saving these links in a desi-

gnated separate component which would be conﬁgu-

red in an environment with efﬁcient storage access.

At the same time the readers communicating direc-

tly with the chosen data sources have only to fetch

SMARTGREENS 2017 - 6th International Conference on Smart Cities and Green ICT Systems

236

Figure 2: Schema of information collecting system. Custom

components implemented for the project have gradient bac-

kround.

and process (relatively short) text documents, there-

fore these have a different performance characteristic

and may beneﬁt from a different deployment conﬁgu-

ration.

The interaction between the mentioned compo-

nents is depicted in Figure 2.

3.2 Fetching Text-feed Data

The VaVelFeeds python package (implemented spe-

ciﬁcally for the purposes of the described system)

consists of a number of readers downloading text-

feed data. These are also responsible for extracting

necessary information like timestamps and main con-

tent and identifying external links which should also

be downloaded. The messages fetched from all four

sources are effectively converted into JSON objects

and passed for further processing. Here Apache Flu-

me is utilised to deliver these objects to both Kafka

and HDFS sinks. A designated Kafka channel makes

the feed messages available in near real-time for other

components. To be precise, the latency is mostly in-

ﬂuenced by polling frequencies of the individual text

feed sources — these may be set very low to make the

feed messages available as soon as possible, however

certain restrictions regarding for example the usage of

Twitter’s API apply here.

The package strives to provide exactly-once pro-

cessing semantics on a best-effort basis. Therefore,

the history of recently consumed messages is stored

on disk for each of the readers. This allows rejec-

tion of possibly duplicated messages early on in the

processing pipeline. Such an approach is however not

bulletproof – making the history size too small or de-

leting the contents of these ﬁles may result in proces-

sing duplicated messages. On the other hand shutting

down the feed readers entirely for a too long period

will result in loosing messages.

Scaling the system to handle more text-feed sour-

ces is straightforward, as it requires only creating an

appropriate feed reader and plugging it in into Apa-

che Flume. Here it is also possible to beneﬁt from the

already existing Flume sources which may be utilised

in many cases.

3.3 Downloading Linked Content

A Spark streaming job called UriDownloader is re-

sponsible for downloading links extracted from text-

feed messages. As depicted in Figure 2, this job con-

sumes JSON messages from Kafka, processes them

and saves the results to external storage. Each of the

utilised technologies (and thus the entire system) is

easily scalable.

Processing a single message proceeds as follows.

First, the URIs from the message’s links ﬁeld are do-

wnloaded — if these contain HTML, further links are

extracted from the content and also downloaded (this

process is not continued for these ’2nd level’ links).

Each downloaded link is stored in a seperate ﬁle with

the ﬁle name generated as a hash of the ﬁle’s content

— this approach helps to avoid the problem of storing

multiple copies of the same binary content.

Apart from the downloaded content, a record con-

taining metadata is stored in Apache Hive. A sample

record (in CSV) is given below:

1 2016−09−02T11 : 04 : 03 . 195+02 : 00 , h t t p :

/ /www. foo . com / foo . html , TEXT, abc /

def / ab cde f 123 , ab cde f 123

where the consecutive columns are: download

timestamp,URI,file type (BINARY or TEXT),

file path, file content checksum.

As the same URIs appear in multiple feed mes-

sages at various times, there is a need to handle po-

tentially duplicated content. Storing each downloaded

link as a separate ﬁle may lead to wasting storage spa-

ce, therefore a hashing approach (described above) is

used to prevent such problems. Although the content

will not be stored multiple times using this solution,

it still needs to be downloaded multiple times, which

potentially wastes network bandwidth. A naive reme-

dy would be to fetch the content of each URI only on-

ce, however this breaks in case of links that get upda-

ted – like news websites. Another solution is to utilise

HTTP’s ETags to detect whether the content has chan-

ged or not.

4 FEATURES EXTRACTION

The parsing module extracts meaningful and struc-

tured information about public transportation events

from observed sources. Those events should regard

particular lines and stops, usually lay in some span

of time and be of some type. On the other hand, data

from which this information is extracted forms a stre-

am consisting of well-structured records. Each such

record is in JSON format and contains information

Public Transport Stops State Detection and Propagation - Warsaw Use Case

237

about its source (e.g. twitter or RSS) along with other

data.

The module operates as follows. Each record –

whether it is sourced from twitter or RSS – contains

at least one website URL. Final results are extracted

directly from these websites. If there is more than one

hyperlink, results are gathered from each of those and

then merged additively (i.e. if there’s information abo-

ut line A and line B in the ﬁrst link, and line B and line

C in the second link, then the ﬁnal result will contain

lines A, B and C).

The website is only parsed when it is of a certa-

in structure. More speciﬁcally, only Public Transport

Authority websites with speciﬁc information type are

taken into the consideration. What is actually requ-

ired by the website in order to be parsed by the mo-

dule is an existence of an HTML element <td> with

CSS class "linie". As it is implied by the data we have

gathered, this element is only used when the news is

about some public transportation event.

Once it is known that the processed page concerns

such an event, four HTML elements are extracted for

further computations. The ﬁrst one is a header, which

is always a ﬁrst <h4> child element of the <div> with

id "PageContent". We will refer to this element as "he-

ader". The second is a table cell which lists all the li-

nes correlated with the news. It is the <td> element

with class "linie", which is exactly the one used to de-

termine whether the website is useful for further pro-

cessing. We will refer to this element as "line header".

The third one is a <p> element containing information

about date range. This one is always a ﬁrst direct si-

bling of the header element. We will refer to this ele-

ment as "dates". The last one is text content. It con-

sists of all <p> elements which are direct children of

the <div> with id "PageContent". We will refer to this

element as "content".

4.1 Parsing Schemes

Since all lines related to the news are listed in the line

header element and separated by commas, extracting

the lines is just splitting the text content of this ele-

ment by the separator.

When it comes to dates, there are several possible

scenarios. An event may or may not start at a spe-

ciﬁc date and may or may not stop at a speciﬁc da-

te. What is more, both dates may or may not conta-

in information about speciﬁc time. The module as-

sumes, that if there is no time speciﬁed, it is set to

00:00 for starting date and 23:59 for ending date. One

more possible scenario is when the event spans over

one exact day. The pattern for a starting date looks

as follows: "od dd.MM.yyyy (a day of the week) <od

godz. HH:mm>" (text between <> is optional). This is

parsed using the following regular expression (in Java

language syntax):

1 od ( [ 0−9 ] \ {2 \ } \ \ . [ 0−9 ] \ {2 \ } \ \ . [ 0−9 ] \

{4 \ } ) \ \ ( [A−Za−z ] ∗ \ \ ) ( od godz

\ \ . ( [ 0−9 ] {2} : [ 0−9 ] \ {2 \ } ) ) ?

In this and in the following regular expression dia-

critical mark were removed for a presentation reason.

As it was previously stated, if there is no time spe-

ciﬁed, the "00:00" is assumed. However, if the event

only concerns one, speciﬁc day, the pattern is: "dn.

dd.MM.yyyy". The related regular expression:

1 dn . ( [ 0−9 ] \ {2 \ } \ \ . [ 0−9 ] \ {2 \ } \ \ . [ 0−9 ]

\ {4 \ } )

The end date is a similar case. The regular expres-

sion used for parsing:

1 do ( [ 0−9 ] \ {2 \ } \ \ . [ 0−9 ] \ {2 \ } \ \ . [ 0−9 ] \

{4 \ } ) \ \ ( [A−Za−z ] ∗ \ \ ) ( do godz

\ \ . ( [ 0−9 ] \ {2 \ } : [ 0−9 ] \ {2 \ } ) ) ?

Stops information is extracted from the content

text. Stops in the text are written in uppercase letters

and usually consists of one or more words, separa-

ted by a dot, dash, or space and two digits. Example

stops: RAKOWIECKA-SANKTUARIUM 06, KUL-

SKIEGO 02, METRO POLE MOKOTOWSKIE 06.

This is extracted using following regular expression:

1 ( [A−Z ] ++ [ − .\ ] ? ) + [ 0−9 ] \ {2 \ }

Type is obtained from header element. It is who-

le text from this element without lines and stops. In

order to remove the stops, it is required to remove the

white spaces from stops name, as it is sometimes spelt

differently in content text and in the header.

5 GRAPHICAL PRESENTATION

The transformation module converts the parsed events

into Keyhole Markup Language format (KML). The

KML is a descriptive language developed by Google

Company, which complements Geography Markup

Language (Open Geospatial Consortium, 2007) (stan-

dard deﬁned by Open Geospatial Consortium) as a

format for describing and storing geographical infor-

mation including three-dimensional objects.

KML is connected a Web Map Service (WMS) z

Web Feature Service (WFS). WMS (Open Geospa-

tial Consortium, 2009b) produces a visual represen-

tation of spatial data, which is not the data itself.

WFS (Open Geospatial Consortium, 2009a) enables

the client to retrieve geospatial data through HTTP

SMARTGREENS 2017 - 6th International Conference on Smart Cities and Green ICT Systems

238

protocol (Chunithipaisan and Supavetch, 2009). It al-

lows clients and servers to share data without having

to convert data between proprietary formats (Ribeiro

et al., 2004). The result is encoded in Geography Mar-

kup Language.

The format enables marking of spatial data with

a time stamp or a time span. Therefore, the presen-

tation of the events can be limited to requested pe-

riod and published to interested receivers. Moreover,

the created Geography Markup Language ﬁles can be

easily published using a spatial data web service. The

format can be successfully applied in various GIS ta-

sks (Ying-Jun et al., 2009; Grzenda et al., 2011).

Before transformation of the events into KML

structure data are cleaned by an elimination of dupli-

cates that could be created during collection of data

from various sources.

Next, all events are localised in time and space.

For a spatial localisation the parsed stops’ names are

used. The geolocation is done using the Google Maps

Geocoding API. In the results, stops’ names are co-

nverted into geographic coordinates: latitude and lon-

gitude. To deﬁne a term of the event, the parsed dates

are used to deﬁne a time stamp or a time span.

The localised events were described by a type.

One and two words long preﬁxes are extracted from

the parsed types of the events. The preﬁxes are com-

pared with entries from a directory that exclusive

maps a preﬁx into one of the following three groups:

restored stop the stop that was reopened after a mo-

dernisation,

closed stop the stop that was closed because of a mo-

dernisation or other event,

change on stop the stop with some changes on it.

Mostly the events describe changes in the sche-

dules and the routes.

Bus lines affected by stop’s status are symboli-

sed by a polyline that connects the localisations of the

stops grouped by the event.

The ﬁnal description of the events is stored using

Keyhole Markup Language format:

< d e s c r i p t i o n >< ! [CDATA[ c l o s e d ] ] >< /

d e s c r i p t i o n >

< s t y l e U r l ># icon −1899−DB4436< /

s t y l e U r l >

< P o i n t >

< c o o r d i n a t e s >

21.018658 , 5 2 . 2 1 2 2 8 8 , 0 . 0 < /

c o o r d i n a t e s >

< / P o i n t >

< / Pla cemar k >

Figure 3: Detected event: closed stops with attached lines.

<name>222 , N37 , 522 , N81 , 138 ,

501 , N31 , 519 , 131< / name>

< d e s c r i p t i o n >< ! [CDATA[ c l o s e d ] ] >< /

d e s c r i p t i o n >

< s t y l e U r l ># l i n e −A52714−6< / s t y l e U r l

< L i n e S t r i n g >

< t e s s e l l a t e >1< / t e s s e l l a t e >

< c o o r d i n a t e s >

21.018658 , 5 2 . 2 1 2 2 8 8 , 0 . 0

2 1 . 0 2 0 7 , 5 2 . 2 1 0 3 5 ,0.0

2 1 . 0 1 9 7 8 , 5 2 . 2 0 9 7 ,0.0

2 1 . 0 1 5 4 9 ,52 . 2 0 9 ,0. 0 < /

c o o r d i n a t e s >

< / L i n e S t r i n g >

< / Pla cemar k >

Figure 3 presents – in graphical form – the event

presented in Figure 1.

The obtained event description is very limited in

comparison to the original information. However, the

created description is linguistically independent, lo-

calised, and can be propagated through a web service.

6 TESTS AND RESULTS

The designed system was tested on real data. RSS and

Twitter feeds hosted by the Public Transport Authori-

ty in Warsaw were observed and collected over one

month.

In observer period – from 10th of September 2016

to 10th of October 2016 – we have collected 827 mes-

sages from the observed sources. Among that number

733 did not contain information about public transport

lines and stops. The rest of the messages – 94 cases

– were successfully parsed and information on lines

and stops were extracted. The extracted information

was veriﬁed manually. No mistakes were detected.

Public Transport Stops State Detection and Propagation - Warsaw Use Case

239

Tabela 1: Fragment of data on events connected with public transport produced by the city hall. For the presentation the

descriptions were translated into English and the events were labelled with the states.

lines stops state description beginning end

157, 116,

N44

GEN.ZAJ ˛ACZKA 01,

GEN.ZAJ ˛ACZKA 51

restored

stop

restored primary locali-

sation of the stop

2016-09-03

00:00

null

204, 527,

N11

OS. DERBY 01, OS. DERBY

VI 01, OS. DERBY III 01

closed

stop

renovation of the surface

of Skarbka z gór street

2016-10-01

00:00

2016-10-03

05:00

509, 186 NOWODWORY 55, NOWO-

DWORY 02

change

on stop

change of trafﬁc orga-

nization on the terminal

stop Nowodwory

2016-10-01

00:00

2016-10-02

23:59

. . . . . . . . . . . . . . . . . .

The extracted information allowed us to remove

duplicated entries. The duplication came into existen-

ce because of the various sources of raised informa-

tion. After the ﬁltration, 24 events were deﬁned.

Table 1 shows partial information on 14 events as-

signed to stops. Each event contains information on

lines and stops, a short description, the beginning ti-

me, and the end time. For a presentation reason, the

descriptions were translated into English.

There are two types of observed events according

to their localisation in the time. The ﬁrst group inclu-

des temporary events. The beginning and the end of

the event are known. The group consists of planned

renovations, changes in schedules and localisations

caused by various events in the city. For this group,

the states are established temporarily.

The second group of the events has only one time-

stamp that describes the beginning of the event. This

group – with a single exception – contains informa-

tion on restored stops. The group also includes infor-

mation on changes on the stop without a known end

of the event.

The events were divided into three classes using

events’ descriptions. Each class is connected with a

state of the stop. The distribution of the states is as

follows: 4 messages about restored stops, 6 messa-

ges about closed stops, and 4 messages on changes on

stops. Because a single event touches several stops the

number of the stops with assigned states is as follows:

7 restored, 28 closed, and 10 with the changes in the

schedules or locations.

The events were localised using geolocation of the

stops. Figure 4 shows the positioned stops. The icons

symbolise a type of the events: the restored stop, the

closed stop, and changes on the stop. The results co-

ver not only the Warsaw district but also the suburban

zones.

Not all of the stops were localised on the map. The

Google Maps Geocoding API does not cover tempo-

rary stops. All stops labelled with the numbers over

ﬁfty are temporary stops created mostly as a substi-

tute stop for the closed one. The localised stops we-

re distributed as follows: 4 restored stops, 22 closed

Figure 4: Localisation of detected events on the map

stops, and 8 stops with the changes in the schedules

or locations. The number of the stops was reduced to

34 stops from 45 stops mentioned in events but each

event is represented by at least a single localised stop.

7 CONCLUSIONS

We have presented the system that collects text da-

ta on public transport produced by the Warsaw city

hall. The collected data are parsed to extract informa-

tion about the status of stops used by public transport.

Information about closed stops, reopened stops, and

changes on stops is presented in graphical linguisti-

cally independent form using geolocation of the stops.

Data are prepared using Geography Markup Langu-

SMARTGREENS 2017 - 6th International Conference on Smart Cities and Green ICT Systems

240

age format that can be easily published using a web

service. The output should be consumed by a notiﬁ-

cation system that allows us to analyse the users feed-

back. The notiﬁcation system is in development.

ACKNOWLEDGEMENTS

This research has been supported by the European

Union’s Horizon 2020 research and innovation pro-

gramme under grant agreement No. 688380 VaVeL:

Variety, Veracity, VaLue: Handling the Multiplicity of

Urban Sensors.

REFERENCES

Álvarez, A., Casado, S., González Velarde, J. L., and Pa-

checo, J. (2010). A computational tool for optimizing

the urban public transport: A real application. Jour-

nal of Computer and Systems Sciences International,

49(2):244–252.

Chunithipaisan, S. and Supavetch, S. (2009). The deve-

lopment of web processing service using the power

of spatial database. In Emerging Trends in Engine-

ering and Technology (ICETET), 2009 2nd Interna-

tional Conference on, pages 832 –837.

García, C. R., Pérez, R., Lorenz, Á., Alayón, F., and Padrón,

G. (2009). Supporting information services for travel-

lers of public transport by road. In Computer Aided

Systems Theory - EUROCAST 2009: 12th Internatio-

nal Conference, pages 406–412, Berlin, Heidelberg.

Springer Berlin Heidelberg.

Grabowski, S., Grzenda, M., and Legierski, J. (2015). The

adoption of open data and open api telecommunica-

tion functions by software developers. In Business

Information Systems: 18th International Conference,

Proceedings, pages 337–347, Pozna

n, Poland,. Sprin-

ger International Publishing.

Grzenda, M., Kaczmarski, K., Kobos, M., and Luckner, M.

(2011). Geospatial presentation of purchase transac-

tions data. In FedCSIS, pages 291–296.

Lakomaa, E. and Kallberg, J. (2013). Open data as a fo-

undation for innovation: The enabling effect of free

public sector information for entrepreneurs. IEEE Ac-

cess, 1:558–563.

Lindman, J., Kinnari, T., and Rossi, M. (2014). Industrial

open data: Case studies of early open data entrepre-

neurs. In 2014 47th Hawaii International Conference

on System Sciences, pages 739–748.

Nesheli, M. M., Ceder, A. A., and Estines, S. (2016). Pu-

blic transport user’s perception and decision asses-

sment using tactic-based guidelines. Transport Policy,

49:125 – 136.

Open Geospatial Consortium (2007). OpenGIS Geography

Markup Language (GML) Encoding Standard(Version

3.2.1) [EB/OL].

Open Geospatial Consortium (2009a). OpenGIS Web Featu-

re Service (WFS) Implementation Speciﬁcation Ver-

sion 1.1.0.

Open Geospatial Consortium (2009b). OpenGIS Web Map

Service (WMS) Implementation Speciﬁcation Version

1.3.0.

Rathod, R. and Khot, S. T. (2016). Smart assistance for pu-

blic transport system. In 2016 International Conferen-

ce on Inventive Computation Technologies (ICICT),

volume 3, pages 1–5.

Ribeiro, J., de Farias, O., and Roque, L. (2004). A syntactic

and lexicon analyzer for the geography markup langu-

age (gml). In Geoscience and Remote Sensing Sym-

posium, 2004. IGARSS ’04. Proceedings. 2004 IEEE

International, volume 5, pages 2896 – 2899 vol.5.

Rodrigues, F., Borysov, S., Ribeiro, B., and Pereira, F.

(2016). A bayesian additive model for understanding

public transport usage in special events. IEEE Trans-

actions on Pattern Analysis and Machine Intelligence,

PP(99):1–1.

Tyrinopoulos, Y. (2004). A complete conceptual model for

the integrated management of the transportation work.

Journal of Public Transportation, 7(4):101–121.

Ying-Jun, D., Chong-Chong, Y., and Jie, L. (2009). A study

of gis development based on kml and google earth.

In INC, IMS and IDC, 2009. NCM ’09., pages 1581

–1585.

Zheng, P., Wang, W., and Ge, H. (2016). The inﬂuence

of bus stop on trafﬁc ﬂow with velocity-difference-

separation model. International Journal of Modern

Physics C, 27(11):1650135.

Public Transport Stops State Detection and Propagation - Warsaw Use Case

241
