Automatic Generation of English Reference Question by Utilising

Nonrestrictive Relative Clause

Arief Yudha Satria and Takenobu Tokunaga

Department of Computer Science, Tokyo Institute of Technology, Tokyo, Japan

Keywords:

Automatic Question Generation, English Reference Test, TOEFL Reference Question.

Abstract:

This study presents a novel method of automatic English reference question generation. The English reference

question is a multiple choice question which is comprised of a reading passage, a target pronoun, a correct

answer (an antecedent of the target pronoun), and three distractors. The reading passage is generated by

transforming human made passages using the proposed sentence splitting technique on nonrestrictive relative

clauses (NRC). The correct answer is generated by the analysis of parse trees of the passage. The distractors

are extracted from the reading passage by using a part-of-speech (POS) tagger and a coreference resolver.

Human evaluation showed that 53% of the generated questions were acceptable.

1 INTRODUCTION

Answering questions is one of effective methods to

learn a subject. By answering questions, learners

could get feedback to what extent they understand

about the subject (Davis, 2009). Questions are usually

generated by human experts. Creating those ques-

tions needs high skill, and is time consuming. The

past research showed that human experts in question

generation could be replaced with machines. For

example, Susanti et al. (2015) attempted to create

multiple choice questions for vocabulary assessment

while Karamanis et al. (2006) generated questions

in the medical domain. Similarly, Skalban et al.

(2012) made questions for multimedia-based learn-

ing whereas Heilman (2011) constructed WH factual

questions. Automatic question generation has been

an active research area, particularly in the language

learning domain.

From a viewpoint of question consumers, the main re-

source of question exercises for language learners is

usually language learning preparation books, past ex-

amination papers and student workbooks and so on.

The amount of resources available to accommodate

learner needs for practising is still limited. This fact

motivates us to leverage abundant number of human

made texts for making questions automatically. The

present research would contribute to reducing teacher

burden on creating those questions and accommodat-

ing learners with abundant question exercises as well.

Similar to those aforementioned studies, this study

These laws are universal in their application,

regardless of cultural beliefs, geography, or

climate. If pots have no bottoms or have large

openings in their sides, they could hardly be

considered containers in any traditional sense.

Since the laws of physics, not some arbitrary

decision, have determined the general form of

applied-art objects, they

follow basic patterns,

so much so that functional forms can vary

only within certain limits.

The word “they” in the

passage refers to

(A)

applied-art objects

(B)

the laws of physics

(C)

containers

(D)

the sides of pots

Reading passage

Question

1: reading passage

2: target pronoun

3: correct answer

4: three distractors

Figure 1: TOEFL reference question example.

works on automatically generating questions, in par-

ticular questions for language learning. We focus

on reference questions which has been introduced in

TOEFL iBT

A reference question has four components: (1) a read-

ing passage, (2) a target pronoun, (3) a correct answer,

and (4) three distractors as illustrated in Figure 1. The

reference question asks test takers to choose the cor-

rect antecedent of the target pronoun in the reading

passage from the four choices. Although the refer-

ence question appears at most twice out of 12 to 14

for each reading passage in TOEFL iBT, we argue

that the reference question is crucial to measure test

takers’ ability in reading comprehension. When peo-

ple read a passage and ﬁnd a pronoun in it, they will

naturally resolve the pronoun, i.e. they ﬁnd its an-

tecedent (Gordon and Scearce, 1995). Therefore, ask-

ing the antecedent of a pronoun could evaluate the test

takers’ ability in understanding the reading passage.

To the best of our knowledge, there is no research in

the past which focuses on generating the reference

https://www.ets.org/toeﬂ/ibt/about

Satria, A. and Tokunaga, T.

Automatic Generation of English Reference Question by Utilising Nonrestrictive Relative Clause.

DOI: 10.5220/0006320203790386

In Proceedings of the 9th International Conference on Computer Suppor ted Education (CSEDU 2017) - Volume 1, pages 379-386

ISBN: 978-989-758-239-4

379

coreference chain

detector

Text DB

paragraph

w/ NRC

… ante…, which …

sentence w/ NRC

extraction

… ante…, which …

lexical parser

(3) correct answer

dependency parser

relative clause

boundary detector

(1) reading passage

(2) target pronoun

coreference chains (4) distractors

… ante…, which …

distractor generation

antecedent

identiﬁcation

sentence

splitting

antecedent

relative clause boundaries

syntactic tree

dependency relations

nonrestrictive

relative clause (NRC)

retrieval

Figure 2: Overview of reference question generation.

question. One possible approach to automatically

generate reference questions is by applying a coref-

erence resolver to the reading passage. The corefer-

ence resolver could ﬁnd every pair of a pronoun and

its antecedent in the reading passage. The system then

will choose a pair of a pronoun and its antecedent

as the target pronoun and the correct answer respec-

tively. In this approach, however, the quality of the

correct answer will heavily rely on the performance

of the coreference resolver. Unfortunately the perfor-

mance of the currently available coreference resolver

remains still unsatisfactory for using our purpose (Lee

et al., 2013).

We take a different approach to utilise nonrestrictive

relative clauses (NRC) as the resource for pronoun

and antecedent pairs. The key idea is splitting a sen-

tence at the relative pronoun and replacing it with

an appropriate pronoun to have the pronoun and an-

tecedent pair, assuming that it is easier to identify

the antecedent of a relative pronoun within a sentence

than that of a pronoun across the sentences. The de-

tails of sentence splitting will be explained in sec-

tion 4.

2 SYSTEM OVERVIEW

Figure 2 illustrates the overview of our system. The

system ﬁrst retrieves human made paragraphs that

contain at least one NRC from text databases. The

NRCs are retrieved by using simple pattern match-

ing, i.e. by checking if the paragraph includes the

string “, which”. The sentence with a NRC is ex-

tracted from the paragraph to be processed by the lex-

ical parser and the dependency parser to perform an-

tecedent identiﬁcation, and then by the relative clause

boundary detector and the lexical parser to perform

sentence splitting. The antecedent identiﬁcation must

be performed ﬁrst because the antecedent will be used

in sentence splitting to generate the reading passage

and the target pronoun, and will be used in distractor

generation. The antecedent then will be the correct

answer. After the reading passage, the target pronoun,

and the correct answer are generated, then the coref-

erence chains are identiﬁed in the human made para-

graph for generating the distractors. Finally, the ques-

tion could be made by ﬁlling the question template

with four question components. During the course of

the above process, the retrieved paragraph in the ﬁrst

step will be discarded immediately when it is found to

generate inappropriate question. Since we have plenty

of paragraphs, we take high accuracy at the expense

of high recall.

In the overall process, using NRCs for generating ref-

erence questions is the key idea of our proposal. A

NRC is a relative clause which provides additional in-

formation to its modifying noun phrase

. It does not

deﬁne its modifying noun as opposed to the restric-

tive relative clause. Hence, removing the NRC from

the matrix sentence will retain the sentence essential

meaning. Consider the following two sentences.

(1) The drill, which is whirled between the palms

of the hands, consists of a stalk perhaps a

quarter of an inch in diameter.

(2) The drill which is whirled between the palms

of the hands consists of a stalk perhaps a

quarter of an inch in diameter.

(1) contains a NRC while (2) contains a restrictive rel-

ative clause. The difference is located in the existence

of a comma before the “which”. In (1), the NRC is

used to indicate that there is only one drill in the dis-

course; the relative clause provides additional infor-

mation about the drill. On the other hand, (2) uses the

restrictive relative clause to specify that the speaker

is talking about the whirled drill. Removing the rela-

tive clause in (1) retains the core meaning of the sen-

tence but this is not the case for (2). Therefore, we

can safely transform a sentence with a NRC in a para-

graph into two sentences with keeping the meaning of

https://en.oxforddictionaries.com/grammar/relative-

clauses

CSEDU 2017 - 9th International Conference on Computer Supported Education

380

the overall paragraph. At the same time, we obtain the

target pronoun by replacing the relative pronoun with

an appropriate pronoun in the sentence derived from

the relative clause.

3 CORRECT ANSWER

GENERATION

In order to generate the correct answer, our system

ﬁnds the antecedent of the relative pronoun. The

antecedent identiﬁcation must be performed ﬁrst be-

cause the antecedent plays an important role in the

other two subprocesses: sentence splitting and dis-

tractor generation. We accomplish the antecedent

identiﬁcation by searching the parse tree of the sen-

tence including a NRC, and by employing depen-

dency parser. The following subsections describe the

antecedent identiﬁcation by parse tree search, that by

dependency parser, and the aggregation of the both

results.

3.1 Parse Tree Search

A parse tree could be utilised to ﬁnd the boundary of

the NRC and to locate the antecedent (noun phrase)

which the NRC is attached to. The original sentence is

parsed using Stanford Lexical Parser (Klein and Man-

ning, 2003), and the resultant parse tree is traversed to

ﬁnd the antecedent of the NRC by using the following

heuristics:

1. Find the nearest noun phrase which is left sister of

the NRC in the resultant parse tree.

2. If no such noun phrase is found, ﬁnd the nearest

noun phrase parent of the NRC.

Tregex (Levy and Andrew, 2006), a tool for querying

tree data structures, is used in order to locate the an-

tecedent in the resultant parse tree based on the fore-

going heuristics.

3.2 Dependency Parser

A dependency parser could also be employed to ﬁnd

the antecedent of NRCs. By using Stanford Depen-

dency Parser (Chen and Manning, 2014), our sys-

tem will ﬁnd the attachment of the NRC. Figure 3

shows an example of the dependency parser output.

Among many dependencies, the antecedent could

be identiﬁed by ﬁnding a dependency labelled with

“acl:relc”

. This dependency connects the modi-

http://universaldependencies.org/docs/en/dep/acl-

relcl.html

ﬁed noun and the modifying relative clause by a di-

rected arc starting from the antecedent to the relative

clause. Note that we omitted the labels of other de-

pendencies for simplicity in the ﬁgure.

3.3 Result Aggregation

Both parse tree search and dependency parser provide

the antecedent of the NRC. Our system conjoins their

results to vote on the correct answer. Only if both re-

sults agree on the same antecedent, we adopt the sug-

gested antecedent as the correct answer of the ques-

tion, then move to the succeeding processes. When

the both results do not agree, the analysed sentence

is simply discarded and other retrieved paragraph will

be tried.

4 READING PASSAGE

GENERATION

The reading passage in the reference questions of

TOEFL is created by changing college-level text-

books as little as possible to assess how well test tak-

ers could understand academic text (Service, 2012).

The reading passage in our system is generated from

text databases, which are free e-books by Project

Gutenberg

spanning across several genres: science,

history, and technology. The process of reading pas-

sage generation comprises three steps: NRC detec-

tion, sentence splitting and target pronoun creation.

4.1 NRC Detection

To extract the NRC from the sentence, our system

employs the Stanford Lexical Parser (Klein and Man-

ning, 2003) and the relative clause boundary detec-

tion algorithm (Siddharthan, 2002). Since detecting

NRC boundaries is not always easy, both methods are

employed to obtain the reliable relative clause bound-

aries. As in the correct answer generation in the pre-

vious section, only if both agree on the boundary of

the NRC, the extracted NRC is processed further, oth-

erwise the paragraph itself is discarded.

4.2 Sentence Splitting

Sentence splitting divides the original sentence into

the matrix clause and the relative clause. There are

two possibilities in ordering these two clauses when

generating the reading passage. Consider the follow-

ing example.

https://www.gutenberg.org/

Automatic Generation of English Reference Question by Utilising Nonrestrictive Relative Clause

381

The drill, which is whirled between the palms of the hands, consists of a stalk perhaps a quater of an inch in diameter.

acl:relcl

Figure 3: Example of dependency parser output.

(3) The drill consists of a stalk perhaps a quarter

of an inch in diameter. The drill is whirled

between the palms of the hands.

(3) is derived from (1) by moving the NRC after the

matrix clause and substituting “which” with its an-

tecedent, “the drill”. There is another way to arrange

sentences as in (4).

(4) The drill is whirled between the palms of the

hands. The drill consists of a stalk perhaps a

quarter of an inch in diameter.

The decision in sentence ordering could be made by

considering the number of distractor candidates that

appear before the pronoun.

4.3 Target Pronoun Creation

The target pronoun of the reference question is de-

rived from the relative pronoun in the original sen-

tence.

(5) The drill consists of a stalk perhaps a quarter

of an inch in diameter. It is whirled between

the palms of the hands.

(5) is derived from (3) by substituting “the drill” with

“it”. This substitution introduces a new pronoun to be

the target pronoun of the question. When creating the

target pronoun, morpho-syntactic features, e.g. the

number, gender, and animacy are considered so that

they agree with that of the antecedent. In (5), “the

drill” is a singular inanimate noun, thus the pronoun

would be “it”.

(6) We know that the temple was built as

early as the time of TJsertsen, for in

it have been found one or two of his

blocks; and no doubt the original shrine,

which was rebuilt in the time of Philip

Arrhidseus, was of the same period, but

hitherto no remains of the centuries between

his time and that of Hatshepsu had been

found.

(7) We know that the temple was built as early

as the time of TJsertsen, for in it have been

found one or two of his blocks; and no doubt

the original shrine was of the same period,

but hitherto no remains of the centuries be-

tween his time and that of Hatshepsu had been

found. It was rebuilt in the time of Philip Ar-

rhidseus.

There are cases in which the introduced pronoun is

prone to be misinterpreted in term of its antecedent.

In (7) derived from (6), humans tend to interpret “tem-

ple” as the antecedent of the introduced “it” since

this interpretation retains the topic across the two sen-

tences by sharing the subject, although it is actually

“shrine” in the original sentence (6). Such transfor-

mation that distorts the meaning of the original sen-

tence should be avoided. To this end we employ the

Centering theory (Brennan et al., 1987; Grosz et al.,

1995) to conﬁrm that the introduced pronoun natu-

rally refers to the original antecedent. The Center-

ing theory models natural topic transition in the dis-

course, thus that could be the fundamentals for pre-

dicting the antecedent of pronouns. The Centering

theory assigns preference to four types of topic transi-

tions in the order of CONTINUE, RETAIN, SMOOTH-

SHIFT and ROUGH-SHIFT. The CONTINUE transition

is the most natural and the ROUGH-SHIFT is the least.

These topic transitions are determined in terms of the

relation between a pronoun and its antecedent. We

adopt the pronoun and antecedent pairs that consti-

tute transitions except for ROUGH-SHIFT. The reason

why we adopt less natural transitions is to diversify

the generated questions.

5 DISTRACTOR GENERATION

Distractors are plausible but incorrect options which

distract test takers from selecting the correct answer.

We propose the following conditions that must be ful-

ﬁlled by distractor candidates.

1. The POS of the distractor candidate is either sin-

gular noun (NN), proper noun (NNP) or plural

noun (NNS) because we deal with only the case

where the antecedent of the pronoun is a noun.

2. The distractor candidate has the same number,

gender, and animacy features as the correct an-

swer. For instance, a singular distractor would be

too obvious for a plural correct answer.

CSEDU 2017 - 9th International Conference on Computer Supported Education

382

3. The distractor candidate should precede the tar-

get pronoun. There are two kinds of reference

phenomena: anaphora and cataphora. Anaphora

refers back to the preceding word, while cat-

aphora refers forward to the following word. Our

system deals with only anaphora because cat-

aphora is rare in normal texts.

4. The distractor candidate should not belong to

the same coreference chain as the correct an-

swer. Any word belonging to the same corefer-

ence chain as the correct answer would also be

the correct answer, thus it must be avoided to be a

distractor candidate.

To fulﬁl the ﬁrst condition, our system uses Stanford

POS Tagger (Toutanova et al., 2003) to extract all

nouns for distractor candidates. After all the nouns

are extracted, they are checked for their number, gen-

der, and animacy. To avoid creating easy distractors,

incompatible noun phrases are discarded to fulﬁl the

second condition. The third condition is achieved

by selecting only nouns that appears before the tar-

get pronoun. The order of derived sentences in the

sentence splitting process is determined so that more

distractor candidates are obtained.

The drill consists of a stalk perhaps a quarter of an inch in diameter.

It is whirled between the palms of the hands. This is made to

revolve on the edge of a small notch cut into a larger stalk, perhaps

an inch in diameter.

Figure 4: Example of coreference chains.

Error sources in distractor generation.

The coreference chain is a set of words which refer

to the same entity in the discourse. As the reference

question asks the antecedent of the target pronoun,

the distractors must not refer to the same entity as the

correct answer refers to. In order to fulﬁl the fourth

condition, Stanford Coreference Resolver (Lee et al.,

2013) is used to extract all coreference chains in the

reading passage. It receives the reading passage as its

input and provides all coreference chains as its out-

put. After the coreference chain of the correct answer

is determined, the distractor candidates in the same

chain are discarded. Figure 4 illustrates an example

of coreference chains where the expressions referring

to the same entity are linked by dashed lines.

The drill consists of a stalk

(3)

perhaps a quarter of an

inch

(2)

in diameter

(1)

. It is whirled between the palms

of the hands. This is made to revolve on the edge of a

small notch cut into a larger stalk, perhaps an inch in

diameter.

Figure 5: Recency-based distractor candidate ranking.

We need at least three distractors to generate a ref-

erence question. When more than three distractor

candidates remain after ﬁltering with the four con-

ditions, we need to choose three out of them. It is

well known that recently mentioned entity is likely

to be referred to by a pronoun (Walker et al., 1998).

Keeping this in mind, our system ranks the distrac-

tor candidates based on their distance from the target

pronoun. The closest distractor candidate is ranked

at the highest position as illustrated in Figure 5. Our

system then chooses three highest ranked distractor

candidates. In the ﬁgure, the distractor candidates are

underlined with their rank in the parentheses. “Diam-

eter”, “inch” and “stalk” are adopted as distractors in

this example.

6 EVALUATION

We evaluate the proposed method in component by

component. As a source of texts, we used the texts

from the Project Gutenberg. The evaluation are con-

ducted based on the subjective judgement of the au-

thor. The following subsections describe the evalu-

ation of the components: correct answer generation,

reading passage generation and distractor generation.

6.1 Correct Answer Generation

The correct answer generation was evaluated by mea-

suring the accuracy of antecedent identiﬁcation. In

order to evaluate to what extent the parse tree search

and the dependency parser could ﬁnd the antecedent

of the relative pronoun, we retrieved 100 paragraphs

from the Gutenberg texts, and applied the parse tree

search and the dependency parser to these paragraphs.

Table 1: Number of correctly identiﬁed antecedents.

method correct antecedents

parse tree search 50

dependency parser 51

Table 1 represents the number of correctly identiﬁed

antecedents in the 100 paragraphs in each method.

The numbers are almost the same between the two

methods, which agreed on the antecedent in 58 cases,

and 41 of them were correct. Therefore aggregating

the results from the two methods increases the accu-

racy from 50% to 70%.

The wrong 17 cases happened when the relative

clause came after a noun phrase with a prepositional

phrase, as in (8). The both methods happened to at-

tach the relative clause to the object of the preposition,

“Abydos” in (8), instead of the correct antecedent,

“the oldest temple”.

Automatic Generation of English Reference Question by Utilising Nonrestrictive Relative Clause

383

(8) Petrie has traced out the plan of the

oldest temple of Osiris at Abydos,

which may be of the time of Khufu, from

scanty evidences which give us but little

information.

Another error is subject verb disagreement error; a

singular antecedent was chosen for a plural relative

pronoun and vice versa. For instance, our system de-

tected “place” as the antecedent of the relative pro-

noun “which” in (9). Since the predicate of the rel-

ative clause is “are”, the correct antecedent must be

“junipers and cedars”. There are two cases found in

the output of parse tree search.

(9) Going downward they merge into

nons, useful for ﬁrewood but val-

ueless as timber, and these in turn

give place to junipers and cedars,

which are found everywhere throughout the

foothills and on the high mesa lands.

To conﬁrm the effectiveness of the result aggregation,

we conducted an additional experiment in which the

paragraphs were repeatedly retrieved from the Guten-

berg texts and tested if the results of the parse tree

search and the dependency parser were agreed on the

same antecedent, until the number of the accumu-

lated paragraphs reached 100. Since the paragraph

was adopted into the pool only if the both results

agreed, it is guaranteed that the both methods agreed

on the antecedent of the NRC in the accumulated 100

paragraphs. Among these 100 agreed antecedents, 70

were correct ones and 30 were not. As a result of these

experiments, we could say that we can obtain 70% in

accuracy for identifying the antecedents of NRCs by

applying the result aggregation. As we adopt the an-

tecedent as a correct answer, the performance of the

correct answer generation is 70% in accuracy.

6.2 Reading Passage Generation

The reading passage generation was evaluated by

measuring the performance of sentence splitting. The

main source of errors in the sentence splitting pro-

cess is the wrongly identiﬁed relative clause bound-

aries. In order to evaluate to what extent the lexical

parser and the relative clause boundary detector could

ﬁnd the boundary of relative clause for the purpose

of reading passage generation, we retrieved 100 para-

graphs randomly from the Gutenberg texts and anal-

ysed them by the lexical parser and the relative clause

boundary detector.

Table 2 shows the number of correctly identiﬁed rel-

ative clause boundaries in the 100 paragraphs in each

method. The relative clause boundary detector shows

Table 2: Number of correctly identiﬁed relative clause

boundaries.

method correct boundaries

lexical parser 79

relative clause boundary detector 88

around 10% higher accuracy than the lexical parser.

In the 100 paragraphs, the both methods agreed on

the same 70 boundaries, 67 out of which were cor-

rect boundaries. As in the antecedent identiﬁcation

described in the previous subsection, we could gain

8% and 17% in accuracy respectively by aggregating

the results from the different methods.

Similarly to the antecedent identiﬁcation evaluation,

to conﬁrm the aggregation effectiveness, we con-

ducted an additional experiment which accumulated

the agreed 100 results by both methods. The result

showed that in the 97 out 100 agreed cases the identi-

ﬁed boundaries were correct ones. We could say that

we can obtain 97% in accuracy for identifying the cor-

rect boundary of relative clauses.

Additionally, we evaluated the sentence splitting per-

formance with regard to the extent to which the target

pronoun can be interpreted as referring to the correct

antecedent. We generated 50 passages with the CON-

TINUE transition and 50 passages with the SMOOTH-

SHIFT transition to ensure the diversity of the gener-

ated questions

Table 3: Number of correctly interpretable pronouns.

transition type pronouns

CONTINUE 48

SMOOTH-SHIFT 41

Table 3 shows the number of correctly interpretable

pronouns. The table indicates that the CONTINUE

transition gives more appropriate pronouns than

SMOOTH-SHIFT because CONTINUE is more natural

than SMOOTH-SHIFT. This result suggests that by

adopting CONTINUE, our system could generate 48

appropriate pronouns out of 50 questions. However,

if we generate all questions by using the CONTINUE

transition only, the generated questions will be homo-

geneous thus the correct answer could be guessed eas-

ily.

6.3 Distractor Generation

As we can see from Figure 2, errors in the sentence

splitting and the antecedent identiﬁcation affect the

We did not adopt passages with the RETAIN transition be-

cause they tend to be similar passages as those with the

CONTINUE transition because of its deﬁnition.

CSEDU 2017 - 9th International Conference on Computer Supported Education

384

performance of the distractor generation. To evalu-

ate the distractor generation independently from these

preceding steps, we ﬁrst collected 100 questions that

are free from errors in these preceding steps. The dis-

tractor generation was applied to the correctly gener-

ated reading passages and pronouns, and the correctly

identiﬁed antecedents. The generated distractors were

judged valid if all three distractors fulﬁlled the condi-

tions described in section 5.

Table 4: Error sources in distractor generation.

error source errors

coreference chain detection 6

feature agreement 5

We had 11 cases in which at least one generated dis-

tractor was invalid. The main sources of these errors

are categorised into two: errors in coreference chain

detection, and agreement errors in features of pro-

nouns and their antecedent. The distribution of error

sources are summarised in Table 4.

A knowledge of the various Semitic alphabets is nec-

essary for copying inscriptions. Unless the traveler be

also acquainted with the languages he had better be cau-

tious about copying Semitic inscriptions; without such

knowledge he runs the risk of confusing different Semitic

letters. They often closely resemble one another. He

should, however, be able to make squeezes and pho-

tographs.

The word “they” in the passage refers to

(A) letters

(B) inscriptions

(D) alphabets

Figure 6: Example of invalid distractors due to the corefer-

ence chain detection error.

Figure 6 shows an example of invalid distractors

caused by the coreference chain detection error. The

coreference chain detector failed to capture “alpha-

bets” and “letters” in the same coreference chain. Due

to this error, (D) alphabets was generated as one of the

distractors even though it belongs to the same coref-

erence chain as the correct answer (A) letters.

Some errors occurred in feature agreement. When a

person entity was not recognised as a person, it would

be chosen as the distractor for the target pronoun “it”

as shown in Figure 7. The “Hammurabi” was not

recognised as a person, thus it was chosen as one of

the distractor. It is obvious that a person could not be

a distractor for inanimate correct answer.

We have in total 11 generated questions with at least

one inappropriate distractor, suggesting that our sys-

tem successfully generated distractors with 89% in

accuracy.

6.4 Overall Evaluation

Since a question consists of a reading passage, a target

pronoun, a correct answer and distractors, the ques-

tion could be considered acceptable only if all of those

components are error-free. We generated 100 ques-

tions fully automatically and counted errors in each

component. Table 5 shows the number of errors in

each question component in the 100 questions.

Table 5: Errors in the components of 100 questions.

question component #error

reading passage 3

target pronoun 9

correct answer 30

distractors 6

Since a single question might contains errors in mul-

tiple components, this categorisation is not disjoint.

The most common errors happened in correct answer

generation because ﬁnding the antecedent of relative

clauses is a difﬁcult task. The target pronoun tended

to be wrong when it appeared as the object argument

in the sentence. In all nine cases of the wrong target

pronoun, the pronoun were the object of verbs. From

100 questions, 53 of them are error-free, suggesting

that we have 53% in accuracy for automatically gen-

erating reference questions.

It is true that Gudea, the Sumerian patesi of Shirpurla,

records that Hammurabi rebuilt the temple of the god-

dess Ninni (Ishtar) at a place called Nina. Now Nina

may very probably be identiﬁed with Nineveh, but

many writers have taken it to be a place in Southern

Babylonia and possibly a district of Shirpurla itself.

No such uncertainty attaches to Hammurabi’s refer-

ence to Nineveh. It is undoubtedly the Assyrian city

of that name.

The word “it” in the passage refers to

(A) Nineveh

(B) reference

(D) uncertainty

Figure 7: Example of invalid distractors due to agreement

error.

7 CONCLUSION

In this paper, we presented a novel method to auto-

matically generate reference questions for evaluating

test taker’s reading comprehension ability. A refer-

ence question consists of four components: a reading

passage, a target pronoun, a correct answer and three

distractors. It asks test takers the antecedent of the tar

Automatic Generation of English Reference Question by Utilising Nonrestrictive Relative Clause

385

-get pronoun in the reading passage. Questions were

automatically generated from existing human made

paragraphs so we believe that the present study con-

tributes to reducing teacher burden on creating those

questions and accommodating learners with abundant

question exercises as well.

In our proposed method, nonrestrictive relative

clauses (NRC) were utilised to generate the reading

passage using the sentence splitting technique. For

generating correct answers, the parse tree search and

the dependency parser worked together to enhance the

reliability of the generated answer. In creating distrac-

tors, the coreference resolver and the part-of-speech

tagger were employed.

According to the subjective evaluation of the gener-

ated questions, 53% of the questions were acceptable.

That means the half of the generated questions could

be used for the real test, but the performance still re-

mains far from fully automatic question generation.

Our system generated reading passage with 97% in

accuracy, correct answer with 70% in accuracy, and

distractors with 89% in accuracy; those results show

promising potential to generate the reference ques-

tions automatically. With the current performance

as is, it will be practical to incorporate the proposed

components into a kind of authoring system for creat-

ing reference questions, so as to reduce the burden of

human experts in creating questions.

At the same time, we need to further reﬁne each com-

ponent generation module to obtain a better perfor-

mance of the total system. For instance, in order

to improve the performance of correct answer gen-

eration, checking the agreement between the relative

clause and the antecedent could help antecedent iden-

tiﬁcation perform better. In order to remedy the ani-

macy error in distractor generation illustrated in Fig-

ure 7, we could incorporate a named entity recogniser

in our system to distinguish a person from an inani-

mate entity. We are also planning to conduct exper-

iments on real English learners to see to what extent

the automatically generated questions by our method

could discriminate test takers’ ability in reading com-

prehension.

REFERENCES

Brennan, S. E., Friedman, M. W., and Pollard, C. J. (1987).

A centering approach to pronouns. In Proceedings of

the 25th annual meeting on Association for Compu-

tational Linguistics, pages 155–162. Association for

Computational Linguistics.

Chen, D. and Manning, C. (2014). A fast and accurate de-

pendency parser using neural networks. In Proceed-

ings of the 2014 Conference on Empirical Methods in

Natural Language Processing (EMNLP), pages 740–

750, Doha, Qatar. Association for Computational Lin-

guistics.

Davis, B. G. (2009). Tools for teaching. John Wiley & Sons.

Gordon, P. C. and Scearce, K. A. (1995). Pronominalization

and discourse coherence, discourse structure and pro-

noun interpretation. Memory & Cognition, 23(3):313–

323.

Grosz, B. J., Joshi, A. K., and Weinstein, S. (1995). Cen-

tering: A framework for modeling the local coherence

of discourse. Computational Linguistics, 21(2):203–

225.

Heilman, M. (2011). Automatic factual question generation

from text. PhD thesis, Carnegie Mellon University.

Karamanis, N., Ha, L. A., and Mitkov, R. (2006). Gen-

erating multiple-choice test items from medical text:

A pilot study. In Proceedings of the Fourth Inter-

national Natural Language Generation Conference,

pages 111–113. Association for Computational Lin-

guistics.

Klein, D. and Manning, C. D. (2003). Accurate unlexical-

ized parsing. In Proceedings of the 41st Annual Meet-

ing on Association for Computational Linguistics-

Volume 1, pages 423–430. Association for Computa-

tional Linguistics.

Lee, H., Chang, A., Peirsman, Y., Chambers, N., Surdeanu,

M., and Jurafsky, D. (2013). Deterministic coref-

erence resolution based on entity-centric, precision-

ranked rules. Computational Linguistics, 39(4):885–

916.

Levy, R. and Andrew, G. (2006). Tregex and Tsurgeon:

tools for querying and manipulating tree data struc-

tures. In Proceedings of the ﬁfth international confer-

ence on Language Resources and Evaluation, pages

2231–2234. ELRA.

Service, E. T. (2012). Ofﬁcial Guide to the TOEFL Test, 4th

Edition. McGraw-Hill Education.

Siddharthan, A. (2002). Resolving attachment and clause

boundary ambiguities for simplifying relative clause

constructs. In Proceedings of the Student Workshop,

40th Meeting of the Association for Computational

Linguistics (ACL02), pages 60–65.

Skalban, Y., Ha, L. A., Specia, L., and Mitkov, R. (2012).

Automatic question generation in multimedia-based

learning. In Proceedings of COLING 2012: Posters,

pages 1151–1160, Mumbai, India. The COLING 2012

Organizing Committee.

Susanti, Y., Iida, R., and Tokunaga, T. (2015). Automatic

generation of english vocabulary tests. In Proceed-

ings of the 7th International Conference on Computer

Supported Education (CSEDU 2015), pages 77–78.

Toutanova, K., Klein, D., Manning, C. D., and Singer, Y.

(2003). Feature-rich part-of-speech tagging with a

cyclic dependency network. In Proceedings of the

2003 Conference of the North American Chapter of

the Association for Computational Linguistics on Hu-

man Language Technology-Volume 1, pages 173–180.

Association for Computational Linguistics.

Walker, M. A., Joshi, A. K., and Prince, E. F. (1998). Cen-

tering theory in discourse. Oxford University Press.

CSEDU 2017 - 9th International Conference on Computer Supported Education

386
