Introducing Context Awareness

in Unmodiﬁed, Context-unaware Software

Markus Raab

and Gergö Barany

2∗

Institute of Computer Languages, Vienna University of Technology, Vienna, Austria

Inria Paris, France

Keywords:

Context-aware Software Engineering, Conﬁguration Speciﬁcation.

Abstract:

Software tends to be highly conﬁgurable, but most applications are hardly context aware. For example, a web

browser provides many settings to conﬁgure printers and proxies, but nevertheless it is unable to dynamically

adapt to a new workplace. In this paper we aim to empirically demonstrate that by dynamic and automatic

reconﬁguration of unmodiﬁed software we can systematically introduce context awareness. In 16 real-world

applications comprising 50 million lines of code we empirically investigate which of the 2,683 run-time

conﬁguration accesses (1) already take context into account, or (2) can be manipulated at run-time to do so.

The results show that context awareness can be exploited far beyond the developers’ initial intentions. Our tool

Elektra dynamically intercepts the run-time conﬁguration accesses and replaces them with a context aware

implementation. Users only need to specify contexts and add context sensors to make use of this potential.

1 INTRODUCTION

Context—information about the environment in which

software executes—strongly inﬂuences the behavior

we expect from software, and most software is subject

to context. As our running example, we describe a

web browser with its local network settings as context:

In different networks, web browsers may require dif-

ferent proxy settings for Internet access. The default

printer might also have to be changed to a physically

co-located one.

If software (more) readily adapts its behavior au-

tomatically to its current context, we call it (more)

context aware (Alegre et al., 2016). Context aware-

ness fundamentally increases user experience (Dey

and Abowd, 2000). For example, if a web browser

considers its network context, users will be able to dis-

play a web page regardless of which proxy is required

by the network.

Context-oriented software engineering (COSE)

puts context awareness in its focus. Previous COSE ap-

proaches required developers to consider every context

already at design time (Kamina et al., 2014). Thus they

were not applicable for already existing large software

∗

This work was performed while the author was at CEA

LIST Software Reliability Laboratory, France, and supported

by the French National Research Agency (ANR), project

AnaStaSec, ANR-14-CE28-0014.

projects and in particular for legacy software.

To improve on these issues, we propose to move

COSE to deployment time. This way we delay de-

cisions about supported contexts. Three classes of

stakeholders participate: (1) the developers, who still

focus on conﬁgurability without the need to explicitly

implement context awareness; (2) the administrators,

who enable context-awareness in applications with our

novel COSE process during deployment; and (3) the

end users, who enjoy more context-aware applications.

1.1 Research Questions

We claim that it is possible and practical to take un-

modiﬁed software, and by run-time reconﬁguration,

improve their context awareness. Our goal is to ex-

ploit already existing run-time conﬁguration accesses

(RCAs) in free and open source software (FLOSS).

To validate our claim, we answer 3 research questions:

First we need to show that enough RCAs are

present in FLOSS to support run-time reconﬁguration.

To conﬁrm that, in Section 4 we analyze the source

code in a sample of 16 popular and large-scale FLOSS

applications and count RCAs to answer

RQ 1:

How

often are RCAs used in FLOSS?

To ﬁnd out whether RCAs occur sufﬁciently fre-

quently during run time, a dynamic analysis is needed.

218

Raab, M. and Barany, G.

Introducing Context Awareness in Unmodiﬁed, Context-unaware Software.

DOI: 10.5220/0006326602180225

In Proceedings of the 12th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2017), pages 218-225

ISBN: 978-989-758-250-9

In Section 5 we evaluate case studies with the same 16

applications and answer

RQ 2:

How many RCAs can

be made context aware?

In Section 6 we investigate if our proposed solution

is efﬁcient enough by answering

RQ 3:

What is the

overhead of context-aware RCAs?

1.2 Contributions

This paper is (to the best of our knowledge) the ﬁrst

endeavor to empirically investigate context awareness

in large-scale FLOSS applications:

•

We collected profound evidence that RCAs in

FLOSS applications can be used to improve con-

text awareness.

•

In case studies with 16 real-world applications we

found out that COSE improves unmodiﬁed FLOSS

applications.

•

No previous evaluation of context-aware applica-

tions was conducted using such large, complex,

and popular applications.

Contribution 1:

In a source-code analysis of 16

FLOSS applications we observe that a particular kind

of RCAs, namely invocation of the

getenv

function, is

used pervasively (2,683 call sites). (Section 4)

Contribution 2:

We conﬁrm that RCAs are used ubiq-

uitously also at run time. We systematically investi-

gated which RCAs can be used to improve context

awareness in all 16 applications. We improved con-

text awareness in nearly every studied application and

found promising candidates in the others. For example,

from 316 candidates in browsers, in total we found 40

RCAs that certainly enable context awareness. In some

cases applications were made completely aware of in-

dividual contexts. Furthermore, we could integrate all

1,957 conﬁgurations settings of Firefox, which pro-

vided seamless adaption to workplaces. We never

needed to modify the source code. (Section 5)

Contribution 3:

By evaluating performance charac-

teristics of browsers in realistic proxy transitions, we

found that in minimalist applications there is signiﬁ-

cant overhead. For feature-rich applications such as

Firefox, however, the overhead of our tool is below

1 %. (Section 6)

2 PRELIMINARIES &

MOTIVATION

An important aspect of software conﬁguration is

to specify run-time conﬁguration accesses (RCAs).

RCAs are the places within code that deﬁne differ-

ent behavior based on conﬁguration. Usually RCAs

are calls to conﬁguration application programming

interfaces (APIs) such as

getenv

but can also be direct

accesses to data structures.

The

getenv

function is a low-level conﬁguration

RCA. It accesses the environment variables of the

current process, which is set by the caller (e. g., the

user’s shell) when a program is started. After the start

of the process, its environment variables can no longer

be changed externally, only from within the process

using the

setenv

function. We chose it for most of our

investigations because it is widely standardized and

available in many programming languages.

For example, in web browsers we ﬁnd code such as:

gete nv ( " ht tp _pr ox y " ) ;

In this example, the return value of

getenv

can con-

tain an outdated proxy after network changes because

environment variables are not updated for processes.

Context-oriented programming (COP) allows de-

velopers to naturally separate multi-dimensional con-

cerns (Dey and Abowd, 2000; Salvaneschi et al., 2012;

Schippers et al., 2010). COP is one way to specify

programs that adapt their behavior to the context.

Layers are the foundation of COP (Appeltauer

et al., 2009; Costanza et al., 2006; von Löwis et al.,

2007; Wasty et al., 2010). Every layer constitutes

one dimension of context that cuts across the software

system. The (de)activation of layers occurs during

program execution. All active layers together deﬁne

the current context of the program.

Contextual values originate from Lisp sys-

tems (Asirelli et al., 1979). Tanter revived contex-

tual values as a lightweight subset of COP. They “boil

down to a trivial generalization of the idea of thread-

local values” (Tanter, 2008) and can be described as

variables whose values depend on the current context.

Contextual values naturally work along with the con-

cept of layers.

In the present paper we will interpret access to con-

ﬁguration settings as contextual values. Every RCA,

such as a

getenv

invocation, will be considered as read-

ing a contextual value.

Context awareness is a property of a program and

deﬁnes the degree of context taken into account. For

every possible context a combination of layers consid-

ers necessary adaptations. Organizing such dynamic

behavioral changes requires careful engineering (Sal-

vaneschi et al., 2012). Alternatively, contextual values

are by design always context aware (Raab, 2016c).

Context-oriented software engineering (COSE)

provides a “methodology that guides us to a speci-

ﬁcation of context-dependent requirements” and a sys-

tematic mapping from context-dependent use cases to

layers (Kamina et al., 2014).

Introducing Context Awareness in Unmodiﬁed, Context-unaware Software

219

Context sensors (Dey and Abowd, 2000; Baldauf

et al., 2007) are hardware and software with the

main purpose of activating layers according to con-

text changes. We will use them as separate processes

that wait for context change events (Raab, 2016c).

Yin et al. (Yin et al., 2011) found out that in “a large

portion (

46.3 %

61.9 %

) of the parameter miscon-

ﬁgurations” the context was not considered. Our goal

is to explicitly specify the contextual values that make

the execution of the applications more context-aware.

This speciﬁcation leads to a better understanding of

the context in teams maintaining the software. We are

positive that the speciﬁcation helps reduce external

misconﬁguration errors as a side effect.

For newly written context-aware software, cur-

rent COP and COSE approaches would be a viable

choice (Jong-yi et al., 2009). For large FLOSS

projects, however, rewriting the whole source code

is not feasible.

3 Elektra

Elektra is a library developed by one of the authors,

which implements uniform, consistent and context-

aware conﬁguration access. In the present paper we

describe an approach to use Elektra as a tool to in-

tegrate unmodiﬁed applications. The approach is to

apply Elektra in COSE processes at deployment.

Elektra (Raab, 2016a) works as follows: At appli-

cation start, Elektra initializes itself by parsing conﬁg-

uration ﬁles. The conﬁguration ﬁles contain both the

speciﬁcations and conﬁgurations for contextual values.

Elektra supports over 190 conﬁguration ﬁle formats

including the widely-used INI, XML and JSON for-

mats. The support for these formats enables Elektra to

directly manipulate conﬁguration of applications.

In its essence, Elektra provides a key-value data-

base with unique keys and a speciﬁcation for every

conﬁguration setting.

3.1 Interception

To work with unmodiﬁed applications, Elektra inter-

cepts important library calls, including the following:

•

Each

getenv

invocation to provide context-aware

access for environment variables.

•

Each

open

invocation to return conﬁguration ﬁles

with conﬁguration settings respecting the current

context.

Interceptions of library calls are platform-

dependent but are available for every major OS, e. g.,

LD_PRELOAD

and

/ etc / ld .so. preload

for Linux. In-

stead of requiring developers to implement new behav-

ior for context adoption, we rely on already existing

behavioral adoptions that are guarded by RCAs.

3.2 Context Speciﬁcation

Elektra itself is conﬁgured via a conﬁguration speci-

ﬁcation language. In this paper we will use a simple

key-value syntax to illustrate the speciﬁcation of the

key-value database and its contents. For example, let

us specify the contextual value getenv / http_proxy:

[ g et en v / h t t p _ p r o x y ]

c o n t e x t = ht t p _ p r o x y /%i n t e r f a c e%/%netwo r k%

The key within

[ ]

represents a unique identiﬁer to a

conﬁguration setting. Entries in the database are orga-

nized hierarchically with

as the level separator. The

getenv

-interceptor reads its conﬁguration from keys

starting with

getenv /

. We conﬁgure it to handle

getenv

invocations with the parameter "http_proxy".

In the example above, the only property for this

key, i. e.,

context

, speciﬁes that the value to be returned

from such invocations should be context aware. Using

the

%...%

syntax we specify placeholders to be sub-

stituted by the values of layers. The

getenv

invocation

returns the proxy conﬁgured for the currently active

interface

and

network

layers. This functionality allows

us to modify conﬁguration settings passed to appli-

cations: An application that requests a conﬁguration

setting from the environment transparently receives

a setting from our key-value database instead. By

honoring context in the lookup we introduce context

awareness in the client software.

The context-aware lookup makes sure that the re-

turned value recursively respects context speciﬁcations.

With changing context, i. e., different values in layers,

the same requested key has different values. We ex-

press the possible values using straight-forward pattern

matching. E. g., the placeholder

will match any layer

that was not matched speciﬁcally by name:

h t t p _ p r o x y / wlan / home= proxy . example . org

h t t p _ p r o x y / e t h / work = proxy . example . com

h t t p _ p r o x y / * / * = d e f a u l t . example . com

Personalization is an important aspect of context-

aware systems (Alegre et al., 2016). In Elektra we

personalize applications by changing such conﬁgura-

tion values for every individual context.

3.3 Context Changes and Sensors

When the context changes, this information must be

communicated to applications. For the present work,

ENASE 2017 - 12th International Conference on Evaluation of Novel Approaches to Software Engineering

220

we use external context sensors: small programs run-

ning in separate processes that monitor the context of

interest. When the sensor detects a change, it updates

the corresponding layer’s value in the key-value data-

base. Future requests for contextual values via Elektra

(through intercepted

getenv

open

invocations) will

use these updated layer values in their lookups. Having

context sensors running in their own process separates

concerns between the application and the code detect-

ing context changes.

In the running example, users switch networks by

changing their location or by connecting a network

cable. A sensor detects this change and updates Elek-

tra’s database accordingly. We used hooks in network

interfaces to implement this use case. Assume that

the

interface

changes to

eth

and the

network

work

Then the next

getenv("http_proxy")

invocation will

return

proxy.example.com

. This is an increase in con-

text awareness: Normally

getenv

is not context-aware

because the program’s environment is initialized at

startup and cannot be modiﬁed externally, only by the

program itself using

setenv

. Thus the standard

getenv

function always returns the same value for a given ar-

gument. In contrast, Elektra’s modiﬁed

getenv

returns

different values if the underlying context changes.

Elektra is not limited to pulling conﬁguration set-

tings while RCAs are executed. Instead Elektra can

push information to applications by notifying them

to reload their conﬁguration, e. g., via signals for dae-

mons or socket communication for Firefox.

4 RQ1: USE OF getenv

In this section we collect empirical evidence of

getenv

invocations in the source code of applications.

4.1 Methodology

We count the total lines of code and occurrences of

getenv

in selected applications. Obvious wrapper func-

tions (e. g.,

LYGetEnv

in Lynx) are treated identically

to getenv itself.

To improve external validity we carefully sampled

16 applications. We started by including large applica-

tions that have a thriving community. In addition we

took care to have a broad range of diverse applications.

We searched for further popular applications to reduce

the familiarity heuristic. If Internet pages repeatedly

mentioned some applications, we considered them for

inclusion. Finally, we set a focus on browsers to have

a better picture for a speciﬁc domain.

The evaluation of the paper consistently uses the

same applications with the same versions. We ana-

lyzed applications in the version as included in Debian

Jessie 8 amd64 available at snapshot.debian.net. Con-

sidering these factors we compiled the following list

of 16 applications and versions:

application version application version

0ad 0.0.17 Gimp 2.8.14

Akonadi 1.13.0 Inkscape 0.48.5

Chromium 45.0.2454 Ipe 7.1.4

Curl 7.38.0 Libreofﬁce 4.3.3

Eclipse 3.8.1 Lynx 2.8.9dev1

Evolution 3.12.9 Man 2.7.0.2

Firefox 38.3.0esr Smplayer 14.9.0 ds0

Gcc 4.9.2 Wget 1.16

We used Cloc 1.60 to determine the code size of

the applications in the versions as listed above. We

used

grep −rio

to ﬁnd all textual

getenv

occurrences.

Finally we manually looked at every

getenv

occurrence

to check whether it is an invocation or something else

like text in a comment.

4.2 Results

In the following table below the column 1k lines of

code shows the code size of the applications, expressed

as multiples of 1,000 lines of code. For the column

counted getenv we manually counted

getenv

invoca-

tions.

application 1k lines

of code

counted

getenv

lines per

getenv

0ad 474 55 8,617

Akonadi 37 13 2,863

Chromium 18,032 770 23,418

Curl 249 53 4,705

Eclipse 3,312 40 82,793

Evolution 673 23 29,252

Gcc 6,851 377 18,172

Firefox 12,395 788 15,730

Gimp 902 56 16,102

Inkscape 480 19 25,255

Ipe 116 21 5,529

Libreofﬁce 5,482 284 19,304

Lynx 192 89 2,157

Man 142 62 2,293

Smplayer 76 1 76,170

Wget 143 32 4,456

Total 49,556 2,683 18,470

Median 477 54

The applications we analyzed have 2,683

getenv

invocations in 50 million lines of codes. We excluded

textual occurrences in wrappers, comments, ChangeL-

ogs or similar.

Introducing Context Awareness in Unmodiﬁed, Context-unaware Software

221

Finding 1:

We demonstrate that

getenv

is used

pervasively by ﬁnding 2,683 invocations. This is

one getenv occurrence in 18,470 lines of code.

5 RQ2: RUN-TIME BEHAVIOR

In this section we validate the applicability of our ap-

proach at run-time. Run-time analysis considers

getenv

invocations by all participating libraries, complement-

ing our source-code analysis. We will investigate how

often changed return values of

getenv

invocations ac-

tually modify the application’s behavior to improve

context awareness.

This study is a partial replication of our previous

study (Raab, 2016d). Unlike the previous study, we

compare the context awareness of every single param-

eter. Furthermore, we added more applications and

introduce

open

interception. For brevity, however, we

only report about selected and representative cases.

5.1 Methodology

We applied our approach for all 16 applications. As

described in Section 3, we use the library preload

mechanism to use Elektra’s implementations of

getenv

and open instead of the ones in the standard library.

First we started the 16 applications and clicked

through the user interface. While doing so, we logged

every

getenv

invocation and its parameters. To check

if the

getenv

invocation is used as if standard

getenv

were context aware, we modiﬁed the return values

getenv

while the application was running. Then

we repeated the user-interaction to see if the

getenv

invocation inﬂuences the behavior.

5.2 Results

application getenv

all

uniq

later

uniq

later

conﬁg

context

aware

Chromium

2,723 1,056

73 ≥ 24 ≥ 1

Curl 87 14 9 6 6

Firefox

8,185

273 210 118 ≥ 15

Lynx

1,428

45 23 19 16

Wget 13 7 1 1 1

The table above shows the number of

getenv

in-

vocations on a freshly installed Debian system. The

number of invocations varies widely from system to

system depending on conﬁguration and installed soft-

ware. E. g., on other machines, we observed up to four

times more unique

getenv

invocations during run-time

for Firefox. Sometimes we found settings that are

likely to be context aware (indicated by

≥

) but lacked

the resources to investigate them in detail.

In the column getenv all we see how many times

the browsers called

getenv

in total. The next column

shows the number of

getenv

invocations with unique

parameters. The column later uniq only considers

getenv

invocations with unique parameters and only af-

ter startup. The next column are candidates for context

awareness: they are additionally related to conﬁgura-

tion. The last column shows which of the candidates

actually successfully inﬂuenced behavior at run time

without reloading.

In the analysis we found many

getenv

invocations

after startup. Loops implementing user interactions of-

ten repeatedly call functions that redo the same

getenv

invocations.

5.3 Case Study: Firefox

In a case study we conducted the complete COSE pro-

cess. We selected Firefox and speciﬁed

http_proxy

and

PRINTER_LIST

as conﬁguration options of in-

terest as shown in Section 3. We implemented

the layer-changes with one-line hooks in the

/ etc /NetworkManager scripts.

Then we needed to specify printers/proxy for ev-

ery context line-by-line. Within a day, Firefox fully-

automatically selected nearby printers and proxies im-

mediately on network changes (available printers are

even modiﬁed while the printer dialog is open).

Elektra also allows us to modify options in conﬁg-

uration ﬁles. We needed 9 hours to conﬁgure Firefox

to enable rereading its conﬁguration ﬁles. In 2 more

hours we implemented an Elektra plugin for Firefox’s

conﬁguration ﬁles. With

open

interception we have

a context-aware mechanism for all of 1,957 conﬁg-

uration options available in Firefox’s conﬁguration

ﬁles (Jin et al., 2014).

Finding 2:

In each of the 16 application user in-

teractions caused

getenv

invocations, often useful

to make features ﬂawlessly context aware.

We successfully used Elektra in a real-world

case study with Firefox. To enable our imple-

mentation of retroﬁtting context-awareness for

ﬂexible workplaces, only three actions were re-

quired: (1) specify contextual values, (2) create

context mapping for every workplace, and (3) add

context sensors to switch layers.

Implication:

Our tool can be practically applied in

real-world case studies with small effort.

ENASE 2017 - 12th International Conference on Evaluation of Novel Approaches to Software Engineering

222

6 RQ3: PERFORMANCE

EVALUATION

To evaluate the performance we proﬁled different

browsers during a proxy transition on a hp



EliteBook

8570w. In the experiment we opened a web page, then

changed the context, and ﬁnally opened a different

web page. For the proxy transition Elektra performs

the following steps for every process: First the pro-

cess needs to parse the context speciﬁcation. Then the

actual

getenv

is replaced with our context-aware imple-

mentation. On layer transitions, the conﬁguration ﬁle

needs to be reread.

We measured the number of executed CPU instruc-

tions with Valgrind’s tool Callgrind. We report inclu-

sive costs, i. e., the cost of the

getenv

invocation includ-

ing every callee. Thus Valgrind simulates a CPU, the

results are deterministic.

Results:

In the ﬁrst benchmark we will use the Lynx

browser. It is written in a lean way and has negligible

startup times. Such an efﬁcient implementation allows

more precise exploration of the impact the context

switches have.

First we started Lynx without Elektra and visited

two links. Valgrind counted 92,888,073 instructions

(median of three invocations). Then when we acti-

vated Elektra and changed the proxy before visiting

the second link, we counted 114,049,336 instructions,

which are about

18.5 %

more instructions. We used

the context speciﬁcation with the two layers

network

and interface .

Without context-aware

getenv

, the

getenv

invoca-

tions needed

0.33 %

of all instructions. If we modify

getenv / http_proxy

directly (without using layers)

getenv

needs

24.51 %

. If using the setup with the two layers,

getenv invocations needed 25.27 %.

With Firefox the comparison was more difﬁcult

because it consumes resources even without user in-

teraction. The startup times with Valgrind are nearly

two minutes. We estimated the overhead by look-

ing at the proﬁle data, similar to the

getenv

overhead

in Lynx. Overall 20,362,848,539 instructions were

needed to display two web pages. Internal Elektra

overhead, by summing up all costs from the Elek-

tra library, are 68,750,481, i. e.,

0.39 %

. The

g_getenv

function (a wrapper for

getenv

used within Firefox)

needs 16,614,089 instructions (i. e.,

0.08 %

) instead of

22,703 instructions (i. e., 0.00 %) without Elektra.

Finding 3: In minimalist applications such as Lynx

our approach can cause some overhead. The num-

ber of participating layers caused only minimal dif-

ferences. For feature-rich applications the overhead

is below 1 %.

7 RELATED WORK

Xu et al. investigated which conﬁguration settings

are actually used in practice (Xu et al., 2015). They

argue that users get confused by too many settings.

We fully agree and think that our approach helps here

by automatically deducing most settings from context.

Then developers can remove these settings from user

guides. Advanced users, however, still can override

context-aware conﬁguration settings.

Jin et al. describe different challenges in conﬁgur-

ing real-world systems (Jin et al., 2014). Our approach

addresses them by (1) working across language barri-

ers, (2) having a holistic integration of different RCAs,

and (3) making sure that RCAs do not return outdated

values. The authors uncovered 1,957 settings for Fire-

fox and assumed that only a “small part” of settings is

missing. But our study shows, that even

getenv

alone

adds a large amount of otherwise unconsidered conﬁg-

uration settings.

Most other approaches require modiﬁcations in the

source code. Tanter et al. (Tanter et al., 2006) propose

to make aspects context aware. COP (Salvaneschi

et al., 2012; Appeltauer et al., 2009; von Löwis et al.,

2007; Baldauf et al., 2007; Jong-yi et al., 2009; Raab,

2015a) improves the modularity in programs. In earlier

work we investigated how contextual values are syn-

thesized with code generation (Raab, 2015a; Raab and

Puntigam, 2014; Raab, 2015b). A survey discusses

many different approaches how to implement context-

aware applications (Alegre et al., 2016). Mens et al.

created a taxonomy for context-aware variability ap-

proaches (Mens et al., 2016). All these approaches re-

quire at least some context-speciﬁc design upfront the

implementation. The speciﬁcation language Elektra

does not only improve context awareness, but fosters

system integration (Raab, 2016b). Some approaches

focus on deployment, but require decisions at design

time (Lee et al., 2014). Alexandrov et al. facilitates

intercepting of library calls to improve user experience,

but with a different goal (Alexandrov et al., 1998).

The survey of Xu and Zhou gives an overview of

the different approaches for improving on conﬁgura-

tion problems (Xu and Zhou, 2015). In contrast, our

basic idea is to automatically derive correct conﬁgura-

tion settings from context.

8 THREATS TO VALIDITY

Internal.

Both the code and run-time analysis have

the danger of subjective classiﬁcation and oversight.

To minimize such errors we included second opinions

and only report large differences. Additionally the

Introducing Context Awareness in Unmodiﬁed, Context-unaware Software

223

combination of code and run-time analyses yields a

more complete picture as proposed for mixed meth-

ods (Ihantola and Kihn, 2011).

External.

An important concern is whether the eval-

uated applications and their developers are represen-

tative. We address it by studying a high number of

diverse applications. We included both small and large

applications. We took care that different domains, de-

velopment teams and programming languages are rep-

resented. In particular the browsers are used heavily

in mobile contexts.

We have to acknowledge that most software we

evaluated is written in C/C++. Nevertheless, Java,

JavaScript and Python were well represented with

4.3, 3.3, and 1.1 million lines of code, respectively.

Furthermore, we added Eclipse to also have a large

project mainly implemented in Java. Since we found

no context-aware application of reasonable size with

an active community, we could not include such appli-

cations into the analysis. Hence our claims exclude ap-

plications developed with context-awareness as goal.

An equally important concern is whether

getenv

our main subject of study, represents every form of

RCA. Based on many previous studies (Jin et al., 2014;

Rabkin and Katz, 2011; Xu et al., 2013), run-time

RCAs are in their essence simple key-value accesses.

Higher-level RCAs, e. g. with type-safety, would only

complicate the implementation.

Because we did an in-depth source code analysis,

we could not pick closed-source applications. A signif-

icant portion of the evaluated software, however, has

at least roots as closed-source applications. Also based

on experience within companies, we are positive that

our conclusions hold for closed-source applications.

It is well known that in experimental analysis high

standards are required (Johnson, 2002); e. g., to miti-

gate measurement issues we always used two different

proﬁling tools.

Overall we cannot draw any general conclusions

applicable to every form of conﬁguration. In partic-

ular we focus on observations how RCAs are used

in FLOSS applications. Thus results should be in-

terpreted and generalized with awareness of our fo-

cus. Nevertheless our study provides profound insights

about connections between conﬁguration and context

awareness.

9 CONCLUSION AND FUTURE

WORK

In this paper we claimed that unmodiﬁed applications

can become more context aware. We demonstrated that

such an approach exists and is practical. We evaluated

the approach on 16 large, real-world FLOSS applica-

tions. By conﬁguring a simple tool, context awareness

was improved in case studies, often even ﬂawlessly.

We applied a straightforward context-oriented soft-

ware engineering process which enables systematic

applicability during deployment.

Our work shows that it is realistic to deduce con-

ﬁguration settings from context. We are positive that

doing so contributes to reduce one of the major source

of conﬁguration errors, i. e., forgetting about context

in conﬁguration.

We propose that environment variables should be

speciﬁed and documented like other conﬁguration set-

tings. Our approach shows that it is not necessary

that developers foresee every possible context. Instead

layers and conﬁguration settings per context are intro-

duced during deployment. Our approach is modular

because context sensors are implemented separately

from applications.

Elektra is available as free software from

http://www.libelektra.org

and is more general than described in this paper: For

example, it can be used for newly developed context-

aware software by generating contextual values. This

paper focuses on its use for unmodiﬁed software.

The source code analysis suggest that dependency

injection (‘hijacking’ existing

getenv

open

invocations

or other APIs) makes it easy to introduce context

awareness. Elektra is not limited to intercepting

getenv

and

open

. For example, we implemented the

gsettings

API which has the potential to make GNOME set-

tings context-aware. As future work Elektra can be

extended to make even more forms of conﬁguration

context-aware (conﬁguration for modules, plugins, de-

pendency injections, rich mobile APIs etc.).

Although we did not ﬁnd a single occurrence where

existing context awareness conﬂicted with our ap-

proach, combining Elektra with already context-aware

software is future work. Another research direction is

to investigate how many applications allow reloading

of conﬁguration settings. Enabling Elektra to push

conﬁguration settings to more applications improves

the user experience again.

REFERENCES

Alegre, U., Augusto, J. C., and Clark, T. (2016). Engineer-

ing context-aware systems and applications: A survey.

Journal of Systems and Software, 117:55 – 83.

Alexandrov, A. D., Ibel, M., Schauser, K. E., and Scheiman,

C. J. (1998). UFO: A personal global ﬁle system based

on user-level extensions to the operating system. ACM

Trans. Comput. Syst., 16(3):207–233.

ENASE 2017 - 12th International Conference on Evaluation of Novel Approaches to Software Engineering

224

Appeltauer, M., Hirschfeld, R., Haupt, M., Lincke, J.,

and Perscheid, M. (2009). A comparison of context-

oriented programming languages. In International

Workshop on Context-Oriented Programming, COP

’09, New York, NY, USA. ACM.

Asirelli, P., Degano, P., Levi, G., Martèlli, A., Montanari,

U., Pacini, G., Sirovich, F., and Turini, F. (1979). A

ﬂexible environment for program development based

on a symbolic interpreter. ICSE ’79, pages 251–263,

Piscataway, NJ, USA. IEEE Press.

Baldauf, M., Dustdar, S., and Rosenberg, F. (2007). A survey

on context-aware systems. International Journal of Ad

Hoc and Ubiquitous Computing, 2(4):263–277.

Costanza, P., Hirschfeld, R., and De Meuter, W. (2006). Efﬁ-

cient layer activation for switching context-dependent

behavior. In Lightfoot, D. and Szyperski, C., editors,

Modular Programming Languages, volume 4228 of

LNCS, pages 84–103. Springer.

Dey, A. K. and Abowd, G. D. (2000). The what, who, where,

when, why and how of context-awareness. In CHI ’00

Extended Abstracts on Human Factors in Computing

Systems, CHI EA ’00, NY. ACM.

Ihantola, E. and Kihn, L. (2011). Threats to validity and reli-

ability in mixed methods accounting research. Qualita-

tive Research in Accounting & Management, 8(1):39–

58.

Jin, D., Qu, X., Cohen, M. B., and Robinson, B. (2014).

Conﬁgurations everywhere: Implications for testing

and debugging in practice. In Companion Proceed-

ings of the 36th International Conference on Software

Engineering, ICSE Companion 2014, pages 215–224.

Johnson, D. S. (2002). A theoretician’s guide to the experi-

mental analysis of algorithms. In Proceedings of the

5th and 6th DIMACS Implementation Challenges.

Jong-yi, H., Eui-ho, S., and Sung-Jin, K. (2009). Context-

aware systems: A literature review and classiﬁcation.

Expert Systems with Applications, 36(4):8509 – 8522.

Kamina, T., Aotani, T., Masuhara, H., and Tamai, T. (2014).

Context-oriented software engineering: A modularity

vision. In Proceedings of the 13th International Con-

ference on Modularity, MODULARITY ’14, pages

85–98, New York, NY, USA. ACM.

Lee, K. C. A., Segarra, M.-T., and Guelec, S. (2014). A

deployment-oriented development process based on

context variability modeling. In Model-Driven Engi-

neering and Software Development (MODELSWARD),

2nd International Conference, pages 454–459. IEEE.

Mens, K., Capilla, R., Cardozo, N., Dumas, B., et al. (2016).

A taxonomy of context-aware software variability ap-

proaches. In Workshop on Live Adaptation of Software

Systems, collocated with Modularity 2016 conference.

Raab, M. (2015a). Global and thread-local activation of

contextual program execution environments. In Pro-

ceedings of the IEEE 18th International Symposium on

Real-Time Distributed Computing Workshops (ISOR-

CW/SEUS), pages 34–41.

Raab, M. (2015b). Sharing software conﬁguration via speci-

ﬁed links and transformation rules. In Technical Report

from KPS 2015, volume 18. Vienna University of Tech-

nology, Complang Group.

Raab, M. (2016a). Elektra: universal framework to access

conﬁguration parameters. The Journal of Open Source

Software, 1(8).

Raab, M. (2016b). Improving system integration using

a modular conﬁguration speciﬁcation language. In

Companion Proceedings of the 15th International Con-

ference on Modularity, MODULARITY Companion

2016, pages 152–157. ACM.

Raab, M. (2016c). Persistent contextual values as inter-

process layers. In Proceedings of the 1st International

Workshop on Mobile Development, Mobile! 2016,

pages 9–16. ACM.

Raab, M. (2016d). Unanticipated context awareness for

software conﬁguration access using the getenv API.

In Computer and Information Science, pages 41–57.

Springer International Publishing, Cham.

Raab, M. and Puntigam, F. (2014). Program execution envi-

ronments as contextual values. In Proceedings of 6th

International Workshop on Context-Oriented Program-

ming, pages 8:1–8:6, New York, NY, USA. ACM.

Rabkin, A. and Katz, R. (2011). Static extraction of program

conﬁguration options. In Software Engineering (ICSE),

2011 33rd International Conference on, pages 131–

140. IEEE.

Salvaneschi, G., Ghezzi, C., and Pradella, M. (2012).

Context-oriented programming: A software engineer-

ing perspective. Journal of Systems and Software,

85(8):1801 – 1817.

Schippers, H., Molderez, T., and Janssens, D. (2010). A

graph-based operational semantics for context-oriented

programming. In Proceedings of the 2nd International

Workshop on Context-Oriented Programming, COP

’10, New York, NY, USA. ACM.

Tanter, E. (2008). Contextual values. In Proceedings of the

2008 Symposium on Dynamic Languages, DLS ’08,

pages 3:1–3:10, New York, NY, USA. ACM.

Tanter, É., Gybels, K., Denker, M., and Bergel, A. (2006).

Context-Aware Aspects, pages 227–242. Springer.

von Löwis, M., Denker, M., and Nierstrasz, O. (2007).

Context-oriented programming: Beyond layers. In

Proceedings of the 2007 International Conference on

Dynamic Languages, ICDL ’07, pages 143–156. ACM.

Wasty, B. H., Semmo, A., Appeltauer, M., Steinert, B., and

Hirschfeld, R. (2010). ContextLua: Dynamic behav-

ioral variations in computer games. In Proceedings of

the 2nd International Workshop on Context-Oriented

Programming, COP ’10, pages 5:1–5:6. ACM.

Xu, T., Jin, L., Fan, X., Zhou, Y., Pasupathy, S., and Tal-

wadker, R. (2015). Hey, you have given me too many

knobs! Understanding and dealing with over-designed

conﬁguration in system software. In Proceedings of the

2015 10th Joint Meeting on Foundations of Software

Engineering, ESEC/FSE 2015, pages 307–319. ACM.

Xu, T., Zhang, J., Huang, P., Zheng, J., Sheng, T., Yuan,

D., Zhou, Y., and Pasupathy, S. (2013). Do not blame

users for misconﬁgurations. In Proceedings of the

Twenty-Fourth ACM Symposium on Operating Systems

Principles, pages 244–259. ACM.

Xu, T. and Zhou, Y. (2015). Systems approaches to tackling

conﬁguration errors: A survey. ACM Comput. Surv.,

47(4):70:1–70:41.

Yin, Z., Ma, X., Zheng, J., Zhou, Y., Bairavasundaram,

L. N., and Pasupathy, S. (2011). An empirical study

on conﬁguration errors in commercial and open source

systems. SOSP ’11, pages 159–172.

Introducing Context Awareness in Unmodiﬁed, Context-unaware Software

225
