Guildlines of Data Quality Issues for Data Integration in the Context

of the TPC-DI Benchmark

Qishan Yang

, Mouzhi Ge

and Markus Helfert

Insight Centre for Data Analytics, School of Computing, Dublin City University, Dublin, Ireland

Faculty of Informatics, Masaryk University, Brno, Czech Republic

.ie

Keywords: Data Quality, Data Integration, TPC-DI Benchmark, ETL.

Abstract: Nowadays, many business intelligence or master data management initiatives are based on regular data

integration, since data integration intends to extract and combine a variety of data sources, it is thus

considered as a prerequisite for data analytics and management. More recently, TPC-DI is proposed as an

industry benchmark for data integration. It is designed to benchmark the data integration and serve as a

standardisation to evaluate the ETL performance. There are a variety of data quality problems such as

multi-meaning attributes and inconsistent data schemas in source data, which will not only cause problems

for the data integration process but also affect further data mining or data analytics. This paper has

summarised typical data quality problems in the data integration and adapted the traditional data quality

dimensions to classify those data quality problems. We found that data completeness, timeliness and

consistency are critical for data quality management in data integration, and data consistency should be

further defined in the pragmatic level. In order to prevent typical data quality problems and proactively

manage data quality in ETL, we proposed a set of practical guidelines for researchers and practitioners to

conduct data quality management in data integration.

1 INTRODUCTION

The data warehouse, as the organizations’ data

repository, is a subject-oriented, integrated,

non-volatile and time-variant collection of data in

support of management’s decision (Inmon et al.,

2010). The links and relationships among the

Extract-Transform-Load (ETL), data warehouse and

data quality were denoted by Kimball and Caserta

(2011): ETL systems extract data from the source

data, enforce data quality and consistency standards,

and conform data, which enable the separate sources

to be used together and finally deliver data in a data

warehouse with the presentation-ready format.

Recently, a more comprehensive acronym DI

(data integration) replaced the ETL. The process of

the ETL can be described by DI which extracts and

combines data from source data with a variety of

formats, transforms the data into a unified data

model representation and populates it into a data

repository (Poess et al, 2014).

When building a data warehouse, ETL tools are

the bridge for the data migration from data sources

to destinations. Even though, it is invisible to end

users and a black room activity, it could cost 70

percent of the resources needed for the data

warehousing implementation and maintenance

(Kimball and Caserta, 2011). Data integration

systems manipulate and examine data streams to

avoid rubbish data in for a data warehouse and

rubbish out for decision-making or presentation

systems. Hence, DI benchmark plays an vital role to

evaluate ETL tools when there are several ETL

candidates to choose. It could also provide data and

a schema to benchmark ETL tools and build a ETL

evaluation-oriented data warehouse respectively.

The TPC-DI

is designed as the first benchmark

to evaluate Data Integration systems(Poess et al.,

2014). The data used in the TPC-DI benchmark for

testing and data warehouse populating is generated

by a (fictitious) brokerage firm's operating system

along with other sources of data. This benchmark

also designs the source and destination data models,

data transformations and implementation rules

(TPC, 2016).

http://www.tpc.org/tpcdi/

Yang, Q., Ge, M. and Helfert, M.

Guildlines of Data Quality Issues for Data Integration in the Context of the TPC-DI Benchmark.

DOI: 10.5220/0006334301350144

In Proceedings of the 19th International Conference on Enterprise Information Systems (ICEIS 2017) - Volume 1, pages 135-144

ISBN: 978-989-758-247-9

135

Data quality issues appear frequently in the stage

of the data integration when ETL tools extract data

from resources, migrate and populate data into data

repositories. Hence, data quality is an important

aspect in the data integration process (Kimball and

Caserta, 2011). Data quality has become a critical

concern to the success of organisations. Numerous

business initiatives have been delayed or even

cancelled, citing poor-quality data as the main

reason. Previous research has indicated that

understanding the effects of data quality is critical to

the success of organisations (Ge et al. 2011). A high

quality of data provides the foundation for the data

integration.

Most initial data quality frameworks have

considered all the data quality dimensions are

equally important (Knight and Burn, 2005). More

recently, as Fehrenbacher and Helfert (2012) stated,

it is necessary to prioritise certain data quality

dimensions for data management. However, as far as

we know, there is not yet work to prioritise data

quality diemensions in ETL. Furthermore, there is

limited research in guiding the data quality

management in the data integration process.

Therefore, in this paper we intend to find out

which data quality dimensions are crucial to data

integration and also attempt to derive the guidelines

for proactive data quality management in data

integration. The contribution of this paper are two

folds, first, we found that some typical data quality

problems exist in data integration process. We have

specified those data quality problems and related

them to different data quality dimensions. It can be

seen that certain data quality diemsnions need to be

further refined, and more dimenions towards

operational squence and data uniqueness should be

used in the data quality management in ETL. On the

other hand, in order to proactively manage data

quality in data integration, we have derived a set of

data quality guidelines that can be used to avoid data

quality pitfalls and problems when integrating data

and using the TPC-DI Benchmark.

The remainder of the paper is organised as

follows. Section 2 reviewes the related work of data

quality and data integration. Section 3 describes the

research methodology used to conduct our research.

Then in Section 4 we list the data quality problems

in data integration process and classify those data

quality problems into different data quality

dimensions in section 5. Section 6 describes the

guidelines we divided for data quality management

in data integration. Finally Section 7 concludes the

paper and outlines the future research.

2 RELATED WORK

In order to manage data quality, Wang (1998)

proposed the Total Data Quality Management

(TDQM) model to deliver high quality information

products. This model consists of four continuous

phases: define, measure, analyse and improve, in

which the measurement phase is critical, because

one cannot manage information quality without

having measured it effectively and meaningfully

(Batini and Scannapieco 2016). In order to measure

data quality, data quality dimensions must be

determined. To this end, Wang and Strong (1996)

used an exploratory factor analysis to derive 15 data

quality dimensions, which are widely accepted in the

following data quality research. Based on the 15

proposed dimensions, data quality assessment has

been applied in different domains such as Healthcare

(Warwicka et al., 2015), Supply Chain Management

(Ge and Helfert, 2013), and Smart City Applications

(Helfert and Ge, 2016).

Among the application domains, DI or ETL

systems have been emerging as an important field

that requires data quality management. The goal of

the data integration system denoted by Doan et al.

(2012) is decreasing the effort of users to acquire

high-quality answers from a data integration system.

They also defined a data warehouse in two tasks: (1)

implementing the centralised database schema and

physical design, (2) defining a batch of ETL

operations. Hence, the DI or ETL system is the

groundwork of the data warehousing in order to

provide synthesized, consistent and accurate data.

The ETL system manages some procedures

specifically in (1) revising or removing mistakes and

missing data, (2) offering confident documented

measures in data, (3) safekeeping the captured data

flow of transactions, (4) calibrating and integrating

multiple sources data to be leveraged

collaboratively, (5) structuring data to be usable by

end-user tools (Kimball and Caserta, 2011). It is not

only just extracting data from source systems, but

also as a combination of traffic policemen and

garages for the motorway of data flows in the data

warehousing architecture.

Due to the importance of data quality

management in ETL systems, previous research has

been conducted to study the data quality problems in

ETL systems. Singh and Singh (2010) attempted to

tabulate all possible data quality issues appearing in

the process of the data warehousing (the data source,

data integration and data profiling, data staging, ETL

and database schema). In this research, there were

totally 117 data quality problems demonstrated in

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

136

four tables for each data warehousing phases

respectively. Nearly half of them (52) data quality

flaws were contributed from the data sources stage,

36 issues were listed at the stage of ETL tools, and

rest of them occupied 29 data quality problems. By

reviewing the previous research, we found that there

is lack of clearly defining the data quality problems

and matching the data quality problems to data

quality dimensions. Moreover, as far as we know,

there is still no study that focuses on the data quality

problems in the ETL process that aligns with the

TPC-DI benchmark.

Before TPC-DI, there were some self-defined

measurements to benchmark ETL systems, such as

DWEB (Darmont et al., 2005) and Efficiency

Evaluation of Open Source ETL Tools (Majchrzak

et al. 2011). However, there was a lack of industry

standardised ETL benchmarks which can be used to

evaluate performances of ETL tools (Wyatt et al.,

2009). The TPC-DI was the first industry benchmark

to fill this gap regarding to ETL evaluations (Poess

et al., 2014). The TPC-DI benchmark was released

by the Transaction Processing Performance Council

(TPC) which is a non-profit corporation founded to

define transaction processing and database

benchmarks. This standardised measurement is

characterised by (1) operating and populating large

volumes of data, (2) multiple-sources data sets and a

variety of different data formats, (3) manipulations

in fact and dimensional tables’ creation and

maintenance, (4) a myriad of transformations

incorporating data validation, key lookups,

conditional logic, data type conversions, complex

aggregation operations, etc., (5) historical and

incremental Data Warehousing population loadings,

(6) guaranteeing trustable and correct data results in

integration processes under consistency

requirements. It also provides a standard

specification for the TPC-DI benchmark, in which

14 clauses have been given to deeply explain data

sources, data warehousing schema, transformations,

description of the system under test, execution rules

& metrics, pricing etc. (TPC-DI, 2016). The code for

data sets generation can be downloaded and

executed under JDK. The data set size can be

controlled by configuring the scale factor parameter.

There are three batches of data sets, the Batch 1 is

for the historical loading, the Batch 2 and 3 are

aimed at incremental loadings.

Poess et al. (2014) summarised and explained the

components of the TPC-DI including the source and

target data models, characteristics and technical

details for the generation of the data sets, the

transformations of the DI workload, the execution

rules, metric and a performance study. The TPC-DI

source data come from five different data sources,

which have to be integrated into a decision support

system. The data warehousing architecture and

workflow were pictured hierarchically and divided

into the SUT (system under test) and out of SUT

parts. The SUT part will be benchmarked, while the

out of SUT will be ignored in the process of the

evaluation. The relationships and structure of fact,

dimension and reference tables were depicted to

better demonstrate the target schema, which would

be useful in processes of constructing and populating

the data warehouse.

Since benchmarking is critical for data

integration (Vassiliadis, 2009) and TPC-DI is the

first industrial standard benchmark for data

integration (Poess et al., 2014), it is thus valuable to

study how to manage data quality in data integration

that is aligned with TPC-DI benchmark. Therefore,

based on the previous research we have not only

identified the data quality problems in the TPC-DI

context, but also classified those problems to data

quality dimensions, which can be used for data

quality management.

3 RESEARCH METHODOLOGY

AND SCENARIO

In this section, we describe the data integration

process that is aligned with the TPC-DI benchmark.

Along with this process, we present a typical

scenario herein for data integration. We frame our

research in this scenario and derive guidelines

accordingly.

Figure 1: The outline of process in the data warehousing architecture.

Guildlines of Data Quality Issues for Data Integration in the Context of the TPC-DI Benchmark

137

The data integration process with the TPC-DI

benchmark usually begins from the source data files

generated by DIGen which is built on top of the

Parallel Data Generation Framework (PDGF). The

capabilities of the PDGF were extended to create

data sets accompanied by the specific characteristics

required by this benchmark. The DIGen is required

to be executed under Java environment and the

PDGF needs to be placed in the same directory

(TPC-DI, 2106). After the data sources are generated

by the DIGen, the data will be delivered into the

Data Staging Area. This process is just the migration

of the source data from outside to SUT (system

under test) and no data cleansing operations. In the

Data Staging Area, all discovered data quality issues

need to be addressed and the data quality

management is conducted. Afterwards the ETL will

be carried out to import the data to data warehouse.

The outline of whole data integration workflow is

depicted in figure 1.

In practice, it is common to extract source data

firstly into flat files rather than transport data from

data resources to data warehouses directly. It is

sometimes necessary to obtain or purchase external

data from outside free source data or third-party

companies. In this case, a retail brokerage data

warehouse is built using source data provided by

TPC-DI. During this process, some data quality

issues appeared in the source data, since the data

was collected from internal and external data

resources.

In our scenario, the data is aggregated from five

sources, which are Trading Database, Human

Resource Database, Customer Prospect List,

Financial Newswire and Customer Management

System. In the data warehouse, there are some tables

which need to be emphasised because they are

involved herein as the data quality management

examples. The DimCustomer dimension table stores

customer records and DimAccount dimension table

archives customers’ account details. A new customer

must accompany a new account, but existed

customers can open more than one account. In some

scenarios, these two tables need to be looked up.

When analysing the key customers or a quarter

or annual trades made by customers via their

accounts, we need to obtain the records from

DimTrade table, and join corresponding entities

from DimCustomer and DimAccount tables. The

DimCompany table contains companies’ ID, name,

CEO, address etc. The DimSecurity table

incorporates securities issued by companies. The

Financial table gathered all the financial data of

companies. All data for these three tables is provided

by the FINWIRE files. When reviewing the market

history or rating the companies with finance, the

Fact MarketHistory table would be retrieved, and the

DimCompany, DimSecurity and Financial tables

would be looked up.

4 DATA QUALITY PROBLEMS IN

DATA INTEGRATION

In this section, we describe the data quality problems

investigated in the data sets provided by TPC-DI

when doing the data integration process in this case.

For each type of data quality problem, we define the

data quality problem and provide typical examples

to describe the data quality problems based on our

scenario. Afterwards, we also classify the data

quality problems into different data quality

dimensions. Thus, we are able to identify which data

quality dimensions are important for data quality

management in data integration.

4.1 Missing Values

There are mainly two types of missing value

problems in the data integration process. First, the

data in one field appears to be null or empty, we

define this type of missing value as direct

incompleteness, which means this can be directly

detected by rule-based query. On the other hand,

the data can be missing because of the data

operations such as data update. We define this type

of missing value as indirect incompleteness. We

describe the two types of missing value in details as

follows.

4.1.1 The Missing Value in a Field

The Missing Value in a field indicates there is no

non-null requirement or no compulsory value

needed in some specific fields in a table. In our

scenario, the DimCompany table’s data is obtained

from FINWIRE files, some values are missing in the

field of the FoundingDate which shows when a

company has been created with the granularity of the

date.

Even this field can be empty in the DimCompany

table, but the missing values would influence the

further Data Mining or data analysis jobs (e.g. the

company reputation assessment). Even through the

DimCompany table has a field named Sparting for

standard & poor company’s rating, but it would be

revised based on other attribute of values (e.g.

FoundingDate), so in this situation, the value of the

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

138

FoundingDate attribute might be considered to

re-rate the value in the Sparting attribute.

4.1.2 The Updating Record with Missing

Values

When updating a record, only new values are given

to revise the old values in the record, other fields

which are unnecessary to update are not provided in

updating records. As a typical feature in the data

warehouse, the update is not directly carried out in

the record, instead, the data warehouse will maintain

and mark this record as a legacy record and create a

new record for the updated values.

In our scenario, in the process of the

DimCustomer update, a record may only provide

customerID, address or phone values to update, the

rest fields are empty. The customerID is the

Customer identifier to uniquely identify a certain

customer, which is the primary key in the Customer

table. According to TPC-DI and the dimension

tables’ characteristic of the data warehouse, when

updating the record, the new fresh records will be

inserted and the legacy records will still be

maintained rather than be deleted. Moreover, the

fields for updating in the records may be disparate as

some records only need to update address, while

some only need to update email etc. The generalised

samples from the TPC-DI source data are tabulated

below:

Table 1: The updating records with missing values.

Customer ID Address Email

Action

Type

956 XXX X@X.X New

956 NULL Y@Y.Y Update

956 YYY NULL Update

The updating records could not be inserted into

the dimension tables directly. Errors may be thrown

by a database system because there is a violation to

insert a null or empty value into non-null-allowed

fields.

4.2 The Conflict of Entities

In this paper an entity is defined an object which is

stored in dimension table as a record. The reason

why we differentiate entity and record is that one

record may contain different entities, and sometimes

a record is an entity. The conflicts of entities mean

that there are more than one valid or active record

with the same identifier in a table. The records in

tables need to agree with each other and no conflicts.

In our scenario, when we are inserting a record in

the DimSecurity table, a lookup needs be performed

to check whether the same ID already exists, if

existed, the IsCurrent field of old record should be

modified to false firstly, and then the following

inserting operation continues. However, it is typical

to use a batch to insert and update a list of records.

In order to speed up the process, several threads may

carry out the inserting and updating operations in

parallel. If inserting and updating for a certain entity

in flat files are very close, updating this entity could

be placed before inserting the record. Thus, the

lookup job would return not found and the old

record’s IsCurrent field is still true.

The situation above appeared in our experiment

when loading data with big cache. the old record’s

status would be still valid all the time even it has

already been updated. If this case is ignored or

solved improperly, there could be more than one

entity which have the same identifier and active

status but different surrogate keys. When querying

this kind of entities, which are current or valid, more

than one entity would be given with the same entity

identifier because of the conflict.

4.3 Format Incompatibility

This issue is very frequently appearing for the Date

format in data resources. The Data format conflicts

are mainly triggered by the inconsistent styles

between the data resource and data warehouse.

In our scenario, in some dimension tables of the

data source, the field of EffectiveDate is the

beginning of effective date range of a certain record.

The date retrieved from source data is a String with

the format of the YYYY-MM-DDTHH24:MI:SS

which contains date and time split by the capital T.

Using a data warehouse in the Oracle database

system as an example, the date format is

DD-Mon-YY HH.MI.SS.000000000 AM/PM which

has different date and time formats compared with

the formats in source date. Two EffectiveDate

samples from source data and the Oracle data

warehouse are given in table 2.

Table 2: The samples of format incompatibility.

Date Format Place

2007-07-07T04:28:56 In the data resource

07-JUL-07

04.28.56.000000000 AM

In the data warehouse

If the original data with the date format in the

data resource is inserted into the data warehouse

without format transformations, the error would be

thrown as the format violation. Therefore, the

Guildlines of Data Quality Issues for Data Integration in the Context of the TPC-DI Benchmark

139

original date values need to be reformatted to match

the data warehouse date style.

4.4 Multi-Resource or Mixed Records

In the raw data resource, a record may contain more

than one table’s entities. The entities in this record

normally have referential or dependent relationships.

The number of entities in the raw data record

depends on the planned data operations. For

example, in the CustomerMgmt.xml, a record may

contain two dimension tables’ entities

(DimCustomer and DimAccount tables). An account

must belong to a certain customer, while a customer

could have more than one account (One-to-Many

Relationship). For each record, there is a planned

operation, named as ActionType in Table 3. When

we insert or update an account, we need to know this

account belongs to which customer, thus this record

contains two entities, which are customer and

account. On the other hand, when we only update

the customer information, the ActionType is filled

with “UPDCUST” which means Update Customer.

In this case, the record only contains one entity. In

practice, there might be more entities in one record.

As such, when we carry on the data operations

with raw data sources, we could either firstly

differentiate the entities and extract the data

operation or firstly extract the data operation and

then base on the data operation to differentiate the

entities. We found that it is time-consuming to first

differentiate the entities, since the data operation

may not use all the differentiated entities.

4.5 Multi-Table Files

In the data resource, there are some files that contain

more than one table’s records. This situation may

happen when records in the tables are collected from

the one system.

In our scenario, one file may contain three

tables’ data: CMP, SEC and FIN. The CMP records

are related to DimCompany table; the SEC belongs

to DimSecurty table; the FIN denotes to the

Financial table. The three records in Table 4 come

from the data source.

Based on the record type, the data stream

extracted from this data source file is divided into

several branches. Each branch may have

sub-branches for different purposes such as status

can be further split into different sub-branches

(ACTV and INAC). Then there are several branches

and sub-branches need to be considered in the

process of loading data into (ACTV and INAC). If

there are dependencies among the tables, the

sequence of loading the data into table needs to be

refined as some table may depend on other tables in

terms of foreign keys. If other tables are not loaded,

then there could trigger an error that the foreign keys

are not found.

4.6 Multi-Meaning Attributes

In the data source, an attribute or a field may allow

to contain different types of data which could have

different meanings, while it could be difficult to

avoid ambiguous and inseparable identifications.

In our scenario, in the data resource files there is

Table 3: The samples in mixed records.

Customer ID Account ID Action Type Other Customer Info. Other Account Info.

1 1 New ...

...

1 Null UPDCUST

...

Null

1 1 UPDACCT

...

Null

Table 4: The samples in multi-table files.

Posting date & time Record Type Status Other Information

19670401-065923 FIN NULL Other Financial Information

19670425-114814 SEC ACTV Other Security Information

19670425-083141 CMP ACTV Other Company Information

Table 5: The samples of multi-meaning attributes.

Posting date & time Record Type CoNameOrCIK …

19670401-065923 FIN 1836200100000000056 ...

19670403-194201 FIN 501026396GKXARCFbFebKiAlLUJXKJgRjmqXdA

QcnJFJAKTzRouxMxMVkXQMjtVZu

...

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

140

a field named CoNameOrCIK that can carry the

company identification code (10 chars) or company

name (60 chars). In table 5, the first row is using a

company identification code and the second one is

using a company name.In the Financial table, there

is an attribute called SK_CompanyID which is the

primary key of DimCompany as well as foreign key

of Financial. Thus, when we insert the two records

into the Financial table, from the data source, We

could use either the company identification code or

company name to look up the DimCompany table to

find the primary key and then insert it into the

Financial table as a foreign key.

However, in practice, the different type data can

be very similar but have different meanings. In our

example, the company identification code and

company name could be very similar and hard to

differentiate. If the program cannot differentiate the

data types, there will be a “not found” error that

means we are using the wrong data to locate the

primary key.

5 CLASSIFY DATA QUALITY

PROBLEMS INTO DQ MODEL

In order to facilitate the data quality management in

data integration, we have classified the data quality

problems investigated in this experiment into the

classic data quality dimensions proposed by Wang

and Strong (1996). The last two data quality

problems are not totally fitting into the proposed

data quality dimensions and we have proposed new

dimensions for the data quality problems.

Table 6: Data quality dimensions in data integration (new

data quality dimensions in ETL are marked with *).

Data quality dimension

Data quality problem

Completeness

Missing Value

Timeliness

Conflict of Entities

Consistency

Format Incompatibility

Operational Sequence*

Multi-Resource or Mixed

Records

Multi-Table Files

Uniqueness*

Multi-Meaning Attributes

In the context of data integration, we could see

that not all the data quality dimensions are equally

important. This has been confirmed in other data

quality studies such as Fehrenbacher and Helfert

(2012). For data quality management in ETL, we

propose to initially focus on the dimensions of

completeness, timeliness and consistency. This small

set of dimensions not only point out the key focus of

data quality management in data integration but also

provide a foundation for data cleansing in data

integration.

Moreover, some data quality dimensions need to

be further refined. For example, representational

consistency in data integration is not enough. We

need to align the definitions of the data rather than

only align the names. Therefore the consistency can

be further refined into syntactic, pragmatic and

semantic levels.

Accuracy is always considered as the most

important data quality dimensions in data quality

management. However, in the data integration, it is

usually lack of the ground truth for the data.

Therefore, wrong value is not included in our data

quality problems. As an initial step in data quality

management, we recommend to focus on the

tangible set of data quality dimensions.

Not all the data quality problems can be

classified into classic data quality dimensions,

especially the problems about the sequence of the

data operations. A correct sequence of data

operation can increase the process efficiency and

avoid data quality errors. For example, we could use

the different type of operations to determine which

entities are involved, or use table dependency to

define the sequence of loading the data.

Furthermore, as Dakrory et al. (2015) has stated,

uniqueness is one of the important data quality

dimensions in ETL. We also found that apart from

the classic data quality dimensions, data uniqueness

is a critical indicator to differ the data meaning in

order to avoid possible data ambiguity.

6 GUIDELINES FOR DATA

QUALITY MANAGEMENT

In order to prevent the data quality problems in ETL

and proactively manage data quality, we propose the

following guidelines to help researchers and

practitioners to avoid data quality pitfalls and guild

effective data quality management process.

Specifically, guideline 1 and 2 tackle the missing

value problems; Guideline 3 can be used to prevent

the entity conflicts; Guideline 4 deals with the

format incompatibility; Guideline 5 is for optimising

mixed records and multi-table files in ETL and

guideline 6 intends to solve the problem of

multi-meaning attributes.

6.1 Guideline 1

In order to manage the possible effects of missing

values after ETL, one can use business logic to

Guildlines of Data Quality Issues for Data Integration in the Context of the TPC-DI Benchmark

141

derive the field dependency, and then pay attention

especially to the fields that are involved in the field

dependency and meanwhile allow null or empty

values.

After we have finished the ETL, there can be

certain fields that allow null or empty value in the

data warehouse. Those fields may not cause errors in

the ETL process but when those fields are used in

the data analytics or some business operations, this

type of field may play as an independent variable

and can be used to determine other fields or values.

It will then cause a problem because of the missing

value.

6.2 Guideline 2

In the data quality management for ETL, the

dimension of completeness should be further refined,

since there can be direct incompleteness such as

missing value in the record or indirect

incompleteness that are caused by data operations.

Completeness is one of the well-known

dimensions in data quality management. Managing

data completeness is especially important during

ETL, since it is usually a straightforward problem

one can foresee, whereas in the meantime there

might be certain incompleteness pitfall that people

will overlook. As the example given in Section

4.1.2, the new data for updating and the original data

to be updated are both complete. Only when

carrying out the update operation, the updated

records can turn to be incomplete without lookup.

Therefore, to deal with the indirect incompleteness

caused by update, it is necessary to use lookup to get

the values that do not need to be updated.

6.3 Guideline 3

During ETL, when insert and update records appear

together in the batch operation, the sequence of data

operations in the batch needs to be designed to

avoid entity conflicts.

In the ETL, batch operations are typically used to

perform the data CRUD operations. In order to

accelerate this process, in practice, distributed

operations are usually conducted in parallel to

process the data. Thus, for the same entity, it is

necessary to avoid for example update or delete

before the insert operation. One of the best practices

is to separate the CRUD operations into different

batches. Inside the separated batch, one can use the

parallel operations.

6.4 Guideline 4

For ETL, assuring format consistency in the

syntactic (representational) level is not enough.

Data format consistency between data source and

data warehouse should be aligned in a pragmatic

level.

Data format consistency cannot be only

confirmed by the format name. With the same data

format name (syntactic level), there might be

different real usages or different definitions

(pragmatic level) for the same data format name.

One of the prevalent format inconsistency is the

Date format unconformity. Thus before carrying out

the ETL, practitioners should especially look into

what certain format means and whether the

definitions and data types of the format are aligned

between data source and data warehouse.

6.5 Guideline 5

Optimizing the sequence of data operations can

increase the efficiency of the ETL process and avoid

data quality problems.

In the ETL process, the CRUD data operations

can be mixed together with the data entities. We

recommend firstly extracting the data operation and

based on the data operation to differentiate the data

entities. In this way, we can avoid to look up the

entities that are not used in the data operation. This

will largely increase the efficiency when many

entities are mixed in one record. Moreover, when we

load the data source to various tables, optimising the

loading sequence can avoid the errors triggered by

table dependencies.

6.6 Guideline 6

Data uniqueness is an important dimension in data

quality management. A complete logic should be

used to identify the data.

In ETL, regular expressions are usually used to

identify certain type of data. However, they are not

always enough to differentiate the data, for example,

when different letters or letter combinations have

different meanings, it can be difficult for regular

expressions to separate the meanings. Therefore, we

recommend deriving a set of comprehensive

conditional logic that can be used to categorise the

data to their semantics.

To summarise the typical data quality problems

in ETL and the corresponding proactive actions, we

have used the Table 7 to provide an overview.

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

142

Table 7: The summary of guidelines.

Data quality problems Guidelines Proposed proactive actions for data integration

Missing Values

Guideline 1 Field dependencies and indirect incompleteness caused by

data operations should be specified.

Guideline 2

Conflict of Entities Guideline 3

The sequence of data operations in the batch needs to be

properly designed to avoid entity conflicts.

Format Incompatibility Guideline 4

Representational and pragmatic consistency should be both

examined before ETL.

Multi-Resource or Mixed Records

Guideline 5

The sequence of data operations can be optimised by firstly

extracting the types of data operations and then differentiating

the entities.

Multi-Table Files

Multi-Meaning Attributes Guideline 6

Data uniqueness should be included in the data quality

management in data integration.

7 CONCLUSION

In this paper, we have investigated the data

integration process in line with the TPC-DI

Benchmark, which is the first and well known

industry data integration benchmark. We have found

a set of typical data quality problems that can occur

in the data integration process. For each data quality

problem, we have defined the problem and provided

examples to demonstrate the problem trigger and

possible effects. In order to facilitate the data quality

management in data integration, we have classified

the data quality problems into different data quality

dimensions. This result indicates which data quality

dimensions are important in data integration. These

important dimensions can help researchers and

practitioners to set the focus in data quality

management and reduce the unnecessary cost and

time. In addition, we found that operational

sequence and data uniqueness are two critical data

quality dimensions beyond the common data quality

dimensions. Moreover, we have proposed a set of

guidelines to avoid the data quality pitfalls and

problems and construct proactive data quality

management during data integration.

As future works, we plan to carry out the data

improvement experiment to examine which data

quality dimensions can be improved and how to

coordinate the trade-offs between the data quality

dimensions. The evaluation of this experiment needs

to be enhanced as regards the effect of guidelines for

data quality issues. Furthermore, the effects of data

quality in the data integration process can be further

studied. In addition, we also plan to further

investigate the data quality problems in Big Data.

ACKNOWLEDGMENTS

This publication was supported by Science

Foundation Ireland grant SFI/12/RC/2289 to Insight-

Centre for Data Analytics (www.insight-centre.org).

REFERENCES

Batini, C. and Scannapieco, M., 2016. Erratum to: Data

and Information Quality: Dimensions, Principles and

Techniques. In Data and Information Quality. Springer

International Publishing.

Dakrory, S.B., Mahmoud T.M., Ali A.A., 2015,

Automated ETL Testing on the Data Quality of a Data

Warehouse, International Journal of Computer

Applications, 131(16) pp.9-16

Darmont, J., Boussaid, O. and Bentayeb, F., 2005. Dweb:

A data warehouse engineering benchmark. In

proceedings of Data Warehousing and Knowledge

Discovery 2005, volume 3589, pp. 85-94.Doan, A.,

Halevy, A. and Ives, Z., 2012. Principles of data

integration. Elsevier.

Fehrenbacher, D. and Helfert, M., 2012 Contextual factors

influencing perceived importance and trade-offs of

information quality, Communications of the

Association for Information Systems. 30(8).

Ge, M., Helfert, M., and Jannach, D., 2011 Information

Quality Assessment: Validating Measurement

Dimensions and Process, in proceedings of 19th

European Conference on Information Systems,

Helsinki, Finland, 2011.

Ge, M. and Helfert, M., Impact of information quality on

supply chain decisions, Journal of Computer

Information Systems, 53 (4), 2013.

Helfert, M. and Ge, M., 2016. Big data quality-towards an

explanation model in a smart city context. In

proceedings of 21

International Conference on

Information Quality, Ciudad Real, Spain, 2016.

Inmon, W.H., Strauss, D. and Neushloss, G., 2010. DW

2.0: The architecture for the next generation of data

Guildlines of Data Quality Issues for Data Integration in the Context of the TPC-DI Benchmark

143

warehousing: The architecture for the next generation

of data warehousing. Morgan Kaufmann.

Kimball, R. and Caserta, J., 2011. The data warehouse

ETL toolkit: practical techniques for extracting,

cleaning, conforming, and delivering data. Publisher:

Wiley.

Knight, S.A. and Burn, J.M., 2005. Developing a

framework for assessing information quality on the

World Wide Web. Informing Science: International

Journal of an Emerging Transdiscipline, 8(5),

pp.159-172.

Majchrzak, T.A., Jansen, T. and Kuchen, H., 2011.

Efficiency evaluation of open source ETL tools. In

Proceedings of the 2011 ACM Symposium on Applied

Computing (pp. 287-294).

Poess, M., Rabl, T., Jacobsen, H.A. and Caufield, B.,

2014. TPC-DI: the first industry benchmark for data

integration. In proceedings of the VLDB Endowment,

7(13), pp.1367-1378.

Singh, R. and Singh, K., 2010. A descriptive classification

of causes of data quality problems in data

warehousing. International Journal of Computer

Science Issues, 7(3), pp.41-50.

Stvilia, B., Gasser, L., Twidale, M.B. and Smith, L.C.,

2007. A framework for information quality

assessment. Journal of the American society for

information science and technology, 58(12),

pp.1720-1733.

TPC-DS. (2016) TPC-DS Available at:

http://www.tpc.org/tpcds/ [Accessed 16 December

2016].

TPC-DI. (2016) TPC-DI. Available at:

http://www.tpc.org/tpcdi/ [Accessed 16 December

2016].

Vassiliadis, P. (2009). A Survey of

Extract-Transform-Load Technology, International

Journal of Data Warehousing & Data Mining, 5(3),

1-27, 2009

Warwicka, W., Johnsona, S., Bonda, J., Fletchera, G. and

Kanellakisa, P., 2015. A framework to assess

healthcare data quality. European Journal of Social &

Behavioural Sciences, 13(2), pp.1730.

Wang, R.Y., 1998. A product perspective on total data

quality management. Communications of the ACM,

41(2), pp.58-65.

Wang, R.Y. and Strong, D.M., 1996. Beyond accuracy:

What data quality means to data consumers. Journal of

management information systems, 12(4), pp.5-33.

Wyatt, L., Caufield, B. and Pol, D., 2009, August.

Principles for an ETL Benchmark. In Technology

Conference on Performance Evaluation and

Benchmarking (pp. 183-198). Springer Berlin

Heidelberg.

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

144
