An Intercepting API-Based Access Control Approach for Mobile

Applications

Yaira K. Rivera Sánchez

, Steven A. Demurjian

and Lukas Gnirke

Department of Computer Science & Engineering, University of Connecticut, Storrs, CT, U.S.A.

Department of Computer Science, Oberlin College, Oberlin, OH, U.S.A.

Keywords: Access Control, Application Programming Interface (API), Authorization, Data Management, Mobile

Application, Mobile Computing, Representational State Transfer (REST), Role-Based Access Control

(RBAC).

Abstract: Mobile device users employ mobile applications to realize tasks once limited to desktop devices, e.g., web

browsing, media (audio, video), managing health and fitness data, etc. While almost all of these applications

require a degree of authentication and authorization, some involve highly sensitive data (PII and PHI) that

must be strictly controlled as it is exchanged back and forth between the mobile application and its server

side repository/database. Role-based access control (RBAC) is a candidate to protect highly sensitive data of

such applications. There has been recent research related to authorization in mobile computing that has

focused on extending RBAC to provide a finer-grained access control. However, most of these approaches

attempt to apply RBAC at the application-level of the mobile device and/or require modifications to the

mobile OS. In contrast, the research presented in this paper focuses on applying RBAC to the business layer

of a mobile application, specifically to the API(s) that a mobile application utilizes to manage data. To

support this, we propose an API-Based approach to RBAC for permission definition and enforcement that

intercepts API service calls to alter information delivered/stored to the app. The proposed intercepting API-

based approach is demonstrated via an existing mHealth application.

1 INTRODUCTION

In the last decade, the increase of mobile devices

(e.g., smartphones, phablets, tablets) has led to the

decrease in the usage of stationary devices (e.g.,

desktop computers). Mobile devices have taken over

daily tasks such as reading a document, browsing the

internet, managing emails, gaming, social media,

health & fitness, e-books, banking, email, music, etc.

According to (Lella et al., 2015)

, mobile application

(app) usage is rapidly increasing among mobile

device users, surpassing the time spent on a mobile

device web browser as well as the time spent

utilizing their desktop computers.

Mobile applications often contain dynamic data,

which requires delivering data taken from a data

source (e.g., repository, database, etc.) and/or storing

data to/from the source, both at frequent intervals. In

order to do these types of data transactions between

a mobile app and a server/database, an Application

Programming Interface (API) is utilized. The data

that is displayed/obtained from an application can

vary in sensitivity, ranging from seen by anyone

(non-sensitive data) to custom subsets for specific

users (highly sensitive data such as personally

identifiable information (PII) and protected health

information (PHI)). Access control mechanisms are

commonly utilized to secure highly sensitive data in

order to control which information each user can

access/store in a particular system, with the proviso

that disclosing the wrong information could lead to

serious consequences (Rindfleisch, 1997). The three

dominant access control models (Sandhu and

Samarati, 1994) to achieve this are: role-based

access control (RBAC) which defines roles with

permissions on objects that are assigned to users;

discretionary access control (DAC) where security

policies are established based on the user’s identity

and authorization and can be delegated; and,

mandatory access control (MAC) where sensitivity

levels (Top Secret, Secret, Confidential, and

Unclassified) are assigned to objects (classifications)

and users (clearances) to control who can see what.

The work presented in this paper focuses on

Sánchez, Y., Demurjian, S. and Gnirke, L.

An Intercepting API-Based Access Control Approach for Mobile Applications.

DOI: 10.5220/0006354301370148

In Proceedings of the 13th International Conference on Web Information Systems and Technologies (WEBIST 2017), pages 137-148

ISBN: 978-989-758-246-2

137

securing highly sensitive information (PII and PHI)

that is present in many mobile applications and is

accessible via an API, where the data transactions

between a mobile app and a server are performed via

calls to the services of the API. This is achieved via

the utilization of RBAC in a two-phase process of

definition and enforcement on a user of a mobile app

with a given role to control which services of the

app’s API can be invoked. First, RBAC permissions

are defined on a role-by-role basis on the API

services of the mobile app to identify which services

can be called by which user by role utilizing the

mobile app. Second, RBAC enforcement is achieved

at runtime by intercepting each of the mobile app

calls of a user by role on authorized services in order

to perform real-time permission checks. Our choice

of RBAC to control APIs is motivated by its wide

usage for securing highly sensitive data for:

corporate data (West, 2015); and, healthcare data in

electronic health records (Fernández-Alemán et al.,

2013). Another motivation for the latter case is the

emergent Fast Healthcare Interoperability Resources

(FHIR) (FHIR, 2016) standard for exchangeable

healthcare resources that are accessible via an API

from EHRs and other health information technology

systems.

Through the mobile app API, we seek to provide

a means for a user playing a role to be constrained to

deliver/store data by limiting access to API services

when utilizing the mobile app via the interception of

the API services. According to (Cobb, 2014), every

API service should be verified to ensure that the user

accessing the mobile app has the necessary

permissions to manage the requested data. The

Intercepting API-Based approach presented in this

paper supports the interception of API services by

generating a new API that mirrors the original

mobile app API (in terms of signatures) and serves

as a wrapper which includes calls to the original

mobile app API to proceed based on RBAC checks

that control the data that is displayed (delivered) and

managed (stored). The larger intent of our research

would be to define RBAC, MAC, and DAC

permissions on API services and intercept calls for

access control permission checks that determine the

filtered information returned to the mobile app and

control information that can be stored in the mobile

application's server. For the purposes of this paper,

we focus on RBAC.

The remainder of the paper has five sections.

Section 2 reviews background on RBAC and APIs,

motivates the need to securely control APIs in

mobile apps, and describes the Connecticut

Concussion Tracker (CT

) mHealth app for tracking

concussions from kindergarten to 12

grade. Section

3 introduces the Intercepting API-Based approach

for RBAC definition and enforcement and,

underlying infrastructure to secure data in mobile

applications through a combination of API and

RBAC in order to realize the intercepting API-based

approach. Section 4 provides a proof-of-concept

demonstration of the intercepting API-based

approach into the CT

mHealth app and discusses the

limitations of our work and possible solutions.

Section 5 compares and contrasts related work to our

approach. Finally, Section 6 concludes the paper and

discusses ongoing work.

2 BACKGROUND, MOTIVATION,

AND THE CT

MHEALTH APP

This section provides: background on RBAC and

APIs; motivation on the increasing role of APIs and

a need for security; and, a review of the Connecticut

Concussion Tracker (CT

) mHealth application.

First, access control mechanisms are utilized to

manage which permissions should be granted or

denied in regards to the resources of a system or

application. One of the most popular mechanisms is

role-based access control (RBAC), proposed in

(Ferraiolo and Kuhn, 1992) and established as a

standard (Ferraiolo et al., 2001) in 2004. In RBAC,

users are assigned roles and each role contains

different permissions, which contain the policies of

which operations and objects a user with a particular

role can have access to. Note that each user is

limited to one assigned role per session. For the

purposes of our paper, we apply RBAC concepts at

the API level of the mobile app in support of the

proposed approach to define by role which services

of the API can be called at which times and under

which conditions that are then enforced when a

service is invoked by a user/role combination.

Second, in order to do data transactions between

a server/database and a mobile application, many

developers utilize the Application Programming

Interface (API) concept. This consists of different

tools, protocols, and libraries used to interface data

to an application (Beal, 2014). Basically, the client

sends a request through the means of a URL, the

API receives the URL and interprets it, and then

sends this to the data source. The data source will

then execute the request and send back a response to

the API. The API encodes the response in a human-

readable format (e.g., JSON, XML) and sends the

response in this format to the client. Some

WEBIST 2017 - 13th International Conference on Web Information Systems and Technologies

138

advantages of APIs are: utilized in several

applications as most of them are modular (e.g.,

Facebook Graph API (Facebook, 2014)); useful in

applications that contain dynamic data; facilitate the

sharing of data or processes between two systems;

and, are highly interoperable (Developer Program,

2012; Flanders et al., 2012). The concept of API

originated with traditional desktop devices and is

now being heavily utilized in mobile applications.

The proposed intercepting API-based approach is

aimed towards APIs that are built under the REST

architectural style (REST API Tutorial, 2012) and

that use HTTP as a transfer protocol (Rouse, 2006).

In terms of motivating the ideas in the paper, we

acknowledge one of the most recognized options to

display (deliver) and manage (store) dynamic data in

a mobile app is to utilize the concept of API.

However, before attempting to implement an API,

one must evaluate their security risks and their

effective management (Collet, 2015). For example,

consider the recent security breaches in Snapchat

and Instagram APIs. Snapchat, a mobile app that

enables users to view and send self-destructive

pictures and videos (Snapchat, 2011), had a data

breach that affected 4.6 million users (Snapchat,

2013). The company quickly posted a statement

revealing that the vulnerability allowed individuals

to compile a database that contained usernames and

phone numbers of users of the mobile app and, that

this problem came from their private API. To

address this issue, Snapchat is attempting to identify

which third-party applications offered in the iTunes

store and Google Play store are accessing their

private API and any application that uses it is

accessing Snapchat’s information without their

permission (Zeman, 2015). Instagram, a mobile app

that allows users to take pictures and share them

with family and friends (Instagram, 2010), had a

password breach in 2015 (Dellinger, 2015). The

breach allowed a third-party application to steal

more than 500,000 usernames and passwords, and

used the information to post spam on Instagram

accounts without permission. To remedy this,

Instagram is now reviewing all of the applications

that utilize their API and adding new usage policies

(Larson, 2015). Clearly both public and private APIs

need to be continuously secured and monitored to

prevent disclosure of restricted information from

occurring. To address this issue, a number of

companies have added security and associated

management mechanisms to APIs.

Lastly, to serve as an example throughout the

paper and in support of the prototyping of Section 4,

the Connecticut Concussion Tracker (CT

) mHealth

application, database, and its server are utilized. CT

is a collaboration between the Departments of

Physiology and Neurobiology, and Computer

Science & Engineering at the University of

Connecticut and Schools of Nursing and Medicine in

support of a new law passed in the state of

Connecticut to track concussions of kids between

ages 7 to age 19 in public schools (CT Law

HB6722) (Connecticut General Assembly, 2015).

The CT

application is for Android and iOS devices

and utilizes a REST API in order to manage its data.

The CT

mHealth app contains seven tabs (‘Home’,

‘List’, ‘Student’, ‘Cause’, ‘Symptoms’, ‘Follow-up’,

and ‘Return’) where: the ‘Home’ tab allows the user

to add a concussion, to retrieve an open case, or to

find a student by name; the ‘List’ tab which contains

the list of students the user has permission to view

and, for each student gives him/her the option to add

a concussion or edit an existing one; the ‘Student’

tab (left screen in Figure 1) allows the user to input

the student’s general information (e.g., name,

birthdate, school) and the date of concussion; the

‘Cause’ tab (right screen in Figure 1) allows the user

to specify how an where the concussion occurred;

the ‘Symptoms’ tab allows users to record the

symptoms the student had within 48 hours and other

pertinent data; the ‘Follow-up’ tab allows users to

record the status of the student over time; and the

‘Return’ tab allows users to specify when the student

can return to various activities at school.

Figure 1: Two Screens of the CT

mHealth App.

3 INTERCEPTING API-BASED

APPROACH

In this section, the Intercepting API-Based approach

is explored. This approach offers the versatility of

intercepting original API service calls and has no

An Intercepting API-Based Access Control Approach for Mobile Applications

139

impact on the source code of the mobile application.

We differentiate between three types of APIs in the

discussion: the original mobile app APIs that are

used by the mobile app; the intercepting mobile app

APIs that have the same signatures as the original

mobile app APIs to replace these and provide

permission checks; and, the renamed mobile app

APIs (former original mobile app APIs) that are

wrapped by the intercepting mobile app APIs. The

remainder of this section provides details of our

proposed intercepting API-based approach by:

defining the architecture of a mobile app extended

with our work in Section 3.1; classifying the services

of an API so that they can be assigned to users by

role in Section 3.2; explaining the interactions and

infrastructure of the intercepting API-based

approach in Section 3.3; and, by reporting the

programmatic changes needed in order to apply the

approach to a mobile app in Section 3.4.

3.1 Proposed Architecture

For the general architecture of a mobile app we

employ a client mobile app (Microsoft Corporation,

2008) augmented with the intercepting API-based

approach. We focus on client applications since

these are easier to maintain and assume that the app

is always fully connected to the Internet. This

assumes that all of the data is processed server-side

and does not contain cache and local data. The

architecture consists of four main layers as shown in

the left side of Figure 2: the User Layer which

symbolizes the users of the mobile application; the

Presentation Layer which consists of the UI

components of the mobile application; the Business

Layer which contains the logic of the mobile app

(e.g., libraries, APIs, source code); and, the Data

Layer which contains all of the data the mobile app

manages (e.g., retrieves, inserts).

The right side of Figure 2 details the architecture

of the intercepting API-based approach across the

four layers in three groups. The first group, Role

Assignment, involves the user layer and contains the

users of the mobile app and their assigned roles.

This is achieved via a separate user interface the

security administrator will have access to in order to

manage users and roles (not shown or discussed).

The second group, Define RBAC Permissions on

API Services by Role, spans the presentation and

business layers and contains the original mobile app

API services to retrieve/insert data from/into the data

source. This group is utilized to define RBAC

permissions on a role-by-role basis on which mobile

app API services are authorized to each role, which

in turn will be assigned to different users. Once

permissions by role on the mobile app API are

defined, our approach can intercept API services

utilized by the mobile app in order to perform

security and permissions checks. To transition from

the second to third group, our intercepting API-

based approach utilizes the data layer as a pass via

the renamed API service calls, and as a result, does

not require modifying the source code of the mobile

app in order to achieve. Lastly, the third group,

Enforce Permissions on API Services by Role,

contains the RBAC policies that need to be

incorporated in the original data source(s) so that

they can be enforced. This includes a new set of

intercepting API services that must be defined and

then utilized to replace the original mobile app API

services to enforce the defined RBAC policies to

control the data that is displayed (delivered) and

managed (stored) on a user/role combination.

Figure 2: Intercepting API-Based Approach Architecture.

To illustrate the third group, Figure 3 details the

modifications of the original API services that are

needed for interception. Specifically, for a mobile

app, there is a set of original mobile app API

services, as shown in the left side of Figure 3. To

maintain the functionality of the mobile app and

provide an ability to continue to invoke services by

name, the original mobile app API services are

renamed (as shown on the right side of Figure 3) in

order to reuse the original name of the original

service for the new intercepting API services so that

services from the mobile app remain unchanged

(would now be occurring against the intercepting

services). For each original mobile app API service,

we define a corresponding intercepting API service,

as shown in the bottom (middle) part of Figure 3,

that is able to: perform RBAC security checks for

the user/role combination; call the corresponding

WEBIST 2017 - 13th International Conference on Web Information Systems and Technologies

140

mobile app API service (if it is allowed); and then

return either filtered data (retrievals) or a

success/failure (inserts, updates, or deletes) status.

The mobile app is still able to invoke the same

APIs by name and signature, which are now the

intercepting API services (with the same signature)

that are able to step in and interrupt the process. As a

result, the intercepting API services act as a wrapper

that adds a security layer to the original API

services. The dashed arrows in Figure 3 indicate that

the process of renaming the original API services as

well as the process of creating the intercepting file

needs to be done only once. Therefore, the developer

only needs to create these files once and after that

security administrators can manage the RBAC

policies without modifying the server-side portion of

the mobile app through the means of a separate user

interface. The solid arrow indicates the way that the

API behaves when a user makes a request through

the mobile app; first, the request is intercepted in

order to be evaluated with the pertinent access

control policies and then, depending on the result,

we either proceed to execute the request or send an

error message to the user who sent the request.

Figure 3: Conceptual API Process.

3.2 Classifying Services of APIs

This section discusses the way that the API of a

mobile app is viewed from a RBAC security

perspective in order to control who can invoke

which service(s) of an API at which times, and the

way that each service is viewed from a security

standpoint. From a RBAC perspective, we partition

the services of an API into two broad categories:

secure and unsecure services. Secure services are a

subset of the API that require control from a security

perspective and can be assigned to individual roles.

Not all of the API services need to be in the secure

category; for example, API services to load drop

downs, display web content, etc., may not need to be

secure. The secure API services are the ones that

will lead to data that is stored/edited/displayed that

must be controlled by role. Unsecure services need

not be assigned and are available to any user.

The following four definitions formalize a

mobile app, a role, and permissions for services.

Defn. 1: A mobile application

has an API α =

{α



,α



,…,α



} where each α



is a service

that has a service name, set of service

parameters, and a return type. Note that

services are either web or cloud APIs.

Defn. 2: A role r is defined as a two-pair 





,



 with unique 



identifier

and name



Defn. 3: The API α of a mobile application MA can

be partitioned into two disjoint sets Secure

API S

and Unsecure API U

in regards to

the services that are to be assigned by role:

 Secure API S

 α are the services of

MA that need to be controlled.

 Unsecure API U

 α are the services

of MA that do not need to be

controlled where α = S

 U

and S



=  (e.g., U

= α - S

To facilitate permission assignment, we define:

Defn. 4: Secure API Permission Assignment: Each

role r

can be assigned Secure API role

permissions which represents a subset of

services in the Secure API S

(Defn. 3)

that denote those services that can be

invoked by a user playing role r

To illustrate Defns. 1 and 2, let MA = CT

and

four roles be defined: the Nurse role, which has

access to all seven tabs (see Figure 1) for a school

nurse to manage a student’s concussion incident

from its occurrence to its resolution; the Athletic

Trainer (AT) role which has access to home, list,

student, cause, and symptoms tabs (see Figure 1) to

do a limited preliminary assessment if a concussion

incident occurs at the event; the Coach role, which

has access to home, list, student and cause tabs (see

Figure 1) to report a concussion incident at an

athletic event with very limited information on the

student; and, the Parent role, which has access to

home, list, and student tabs (see Figure 1) to view

and edit his/her children’s general information (e.g.,

name, date of birth) in addition to being able to track

the current status of his/her children that have

ongoing concussions.

The access to the different screens are reflected

in the services of the Secure API from Figure 4 that

are assigned to each role. The subset of the Secure

APIs for the Nurse, Athletic Trainer (AT), Coach,

and Parent roles have the following Secure API

Permission Assignments:

 Nurse: Assigned to s17 to s25

An Intercepting API-Based Access Control Approach for Mobile Applications

141

 AT: Assigned to s18, s22, and 24

 Coach: Assigned to s18 and s22

 Parent: Assigned to s19

Notice each of the roles has been assigned a

subset of the Secure API from Figure 4 by referring

to the unique IDs assigned to each service. In

addition, note that we are only assigning a subset of

the services s17 to s25 to the four roles. These are

the Secure services whose HTTP method is POST;

we are assuming that all the roles have access to the

Secure services whose HTTP method is GET

(services s1 to s16 in Figure 4).

Now, for Defs. 3 and 4, there are forty-two

REST API services to retrieve, insert, and update

information. Figure 4 shows the way that the

available API services are classified in the CT

mobile app based on the Secure and Unsecure APIs.

Basically, we have divided the services into the ones

that need to be secured (the Secure API) and the

ones that do not need to be secured (the Unsecure

API) as they do not contain confidential data.

Identifying the services beforehand will benefit us in

reducing the overhead of achieving the intercepting

API-based approach since we only need to apply

additional security policies in the intercepted

services that are part of the Secure API.

Figure 4: CT

API Service Classification.

3.3 Interactions and Infrastructure

Figure 5 depicts the detailed interactions of the

intercepting API services approach. The top portion

of Figure 5 embodies the core RBAC model that we

are utilizing as a basis for our approach. The middle

portion of Figure 5 represents, at a high level, the

various steps and the associated process that needs

to be performed in order to authorize a user playing

a role to manage certain fields of a mobile

application. Note that a user’s role has been set

administratively. The steps from the user’s

perspective from left to right are: log in to his/her

mobile app account; for successful login, extract the

user’s role that is part of the login credentials; store

the extracted user role in a secure access token in

order to use it in future API services; utilize the

mobile app which results in multiple mobile app API

calls and are intercepted (data processing step in

Figure 5); and, the intercepted API service interacts

with the RBAC permissions and policies to enforce

the defined security before calling the original

mobile app API service. This final step involves

each role having a specific set of API permissions

(see Defn. 4 in Section 3.2) as a subset of the Secure

API (see Defn. 3 in Section 3.2).

There are two possible requests that can occur as

an end result of the interactions in the middle portion

of Figure 5. In the insert/update/delete request (via

an intercepting mobile app API service in the upper

portion of the RBAC API rounded square), the

request will be intercepted to perform the RBAC

checks against the Secure API and Secure

Permissions for that role, and depending on the

response, the action will either get done (the original

mobile app API service is allowed) or not. In the

retrieve request the user is trying to retrieve data (via

an intercepting mobile app API service in the lower

portion of the RBAC API rounded square), the data

source will perform this action but the mobile app

API is intercepted to allow RBAC checks to be

performed to verify whether the requested service is

in the Secure API for that user. This will allow the

intercepted API service to determine if the user has

access to all/some/none parts of the data with the

resulting original API service returning data

(all/some case) or null/error message (none case). In

both types of requests, the security policies utilized

to perform the RBAC checks in the intercepting API

service that involves checking the permissions to the

Secure API are stored in the database in Figure 6.

The primary changes to support the intercepting

API services approach are made in the backend of

the mobile app (server-side – bottom portion of

Figure 2) and include the addition of RBAC security

policies on the permitted subset of Secure API by

role, in a permission database to create the mapping

from the original mobile app API services to the

corresponding new intercepting API services. Figure

6 shows the three database tables that need to be

added in order to realize the RBAC security policies

WEBIST 2017 - 13th International Conference on Web Information Systems and Technologies

142

on the server side: the roles table that contains the

list of available roles; the api_calls table that

contains the list of the API service calls that are

available along with an id for each one of these; and,

the api_calls_map_access table that defines whether

a role has permission to a specific API service call

or not. To support these tables, the role_id foreign

key has been added to the existing user_accounts

table in order to reference and link the user to a role.

Note that there are two new additional tables that are

placed in the database as well (api_calls_parameters

and http_methods tables) nevertheless, these are not

part of the security policy but hold part of the

content that could be utilized to generate the

intercepting code. More details about both of these

tables are discussed in Section 3.4.

Figure 5: Interactions of Intercepting API Calls with

RBAC Model as Base.

Figure 6: Security Policy Tables in the Database.

The database tables as given in Figure 6 provide

the infrastructure that is needed to link the original

mobile app API service to its corresponding new

intercepting API counterpart. Each new intercepting

API service has the same signature (same address

and parameter) as its original mobile counterpart, so

that the intercepting API service can substitute for

the original API of the mobile app to allow the

aforementioned security checks for retrieve and

insert/update/delete requests. As a result, the

intercepting API services effectively wrap the

original mobile app API services. The mobile app

now seamlessly invokes the intercepting API

services. These intercepting API services contain the

appropriate RBAC security checks on the subset of

the Secure API by role, adding a layer of security to

enforce the policies. The renamed mobile app API

services will be invoked based on the outcomes of

the security checks. The end result is that the mobile

app will appear differently based on the user/role

combination, to limit information that is delivered

(retrieve request) or that impacts the data that is

stored (insert/update/delete requests).

3.4 Algorithm Generation

The intercepting API-based approach utilizes an

algorithm to automatically generate the intercepting

code. In order to achieve this, we need to create a

file that contains the same API services as the

original mobile app API via the generate function

RBAC_API_Generator (depicted as a pseudocode in

Figure 7) which has a parameter that contains an

array of all the API services available in the mobile

app (line 1 of Figure 7). The API services reside in

the api_calls table in Figure 6, which also contains

the respective HTTP method (e.g., GET, POST)

from both the Secure and Unsecure APIs. Note the

generation of the Unsecure API services is trivial

since they simply pass through from the new

intercepting services to the original API services

without any required security checks.

Figure 7: General Idea of Code for Generating the Body of

an Access Control Service.

For each of the API services in the array, we

obtain the parameters (if any), which are stored in

An Intercepting API-Based Access Control Approach for Mobile Applications

143

the api_calls_parameters table in Figure 6, and store

these in an array (line 5 of Figure 7). Once we obtain

the parameters of the API service that is being

evaluated, we can generate the heading of the

intercepting API call function by using the current

API service as well as its parameters (if any) (line 6

of Figure 7). After generating the heading for the

intercepting API call function, we then generate the

body of the API service, which contains the security

policies (i.e., the security permission to a subset of

the Secure API by role) for that specific service and

calls the original mobile app API service if the user

has access to it (line 9 of Figure 7). The resulting

heading and body of the current API service will be

stored in an array (line 11 of Figure 7). Once all of

the intercepting services have been created, we

traverse the array in which they are stored in order to

generate the intercepting file (line 13 of Figure 7).

This approach was achieved with the assumption

that the API we want to intercept was created with

Slim (Slim, 2015), which is a PHP micro framework

that allows people to write web applications as well

as APIs. Therefore, we consider that our approach is

useful for those mobile applications/web

applications that contain an API developed with a

PHP-based framework.

4 PROOF-OF-CONCEPT AND

LESSONS LEARNED

This section presents the proof-of-concept

demonstration of the intercepting API-based

approach reviewed in Section 3 coupled with lessons

learned. Section 4.1 explores the usage of the

intercepting API-based approach on the Connecticut

Concussion Tracker (CT

) Android mHealth

application, database, and server. Section 4.2

examines lessons learned including the limitations

found when implementing our approach and an

alternate proposed approach to address them.

4.1 Implementation

Programmatically, we have source code for the

Android version of the CT

app and a REST API

that accesses the CT

MySQL database. The

realization of the intercepting API-based approach is

achieved without any modification to the mobile app

UI and is intended to allow fine-grained access

control on the information that is displayable and/or

storable of the authorized tabs for each user/role

combination via controlling access to the services of

the Secure API on a role-by-role basis. There is a

very clear mapping from the process described in the

previous section and the accompanying figures to its

realization in CT

. The database in CT

was

augmented with a table that contains a list of all the

API calls available along with a call_id (similar to

the api_calls table shown in Figure 6), and a table

that contains the security policies that determine

which calls the roles have access to (similar to the

api_calls_map_access table shown in Figure 6).

Given these database changes, we then take the

original CT

REST API calls and rename these using

an analogous process to the one shown in Figure 3.

Afterwards, a set of new CT

intercepting REST API

calls were generated using the algorithm in Figure 7

that will perform a series of RBAC checks based on

the services of the Secure API assigned to each role,

and if successful, invoke the corresponding renamed

original CT

REST API calls.

From a process perspective, the steps in CT

follow the middle portion of Figure 5. The user logs

on to the CT

mHealth app and a combination of

his/her user id with his/her role is stored in a JSON

Web Token (JWT) (JWT, 2015) in the session in

order to support the class that manages the API

services as presented and discussed in Section 3 and

in Figure 4 for roles, the Secure API, and

Permissions (Defns. 2, 3, and 4, respectively).

Figure 8 illustrates the impact of the intercepting

API services (error message) and associated process

for a user with the role of Coach which has access to

only the home, list, student, and cause tabs. This role

can add basic information on the ‘Student’ tab, can

add information in the ‘Cause’ tab and, after adding

the information, the user can view but not edit. The

error in Figure 8 indicates that a user with the Coach

role tried to update information on the Cause tab.

Figure 8: CT

mobile app screen.

The original mobile app CT

API services support

WEBIST 2017 - 13th International Conference on Web Information Systems and Technologies

144

the insert of information in the database and the

intercepting API service in this case allows that first

save to occur. At a later point in time, if the user

with the role of Coach attempts to edit and perform

another save, the intercepting API service in this

case performs the RBAC check that does not allow

the edit. As a result, the intercepting API service

alerts that he/she does not have permission to

perform that action. This checking process consults

the Secure API Permission Assignments of the

Secure API by role, to verify if the Coach role has

access to the desired action. Specifically, for the

Coach role, all of the POST services (s17 to s25) are

intercepting services and as a result each call

performs an RBAC check. If the service is s18 or

s22, the RBAC check succeeds and the

corresponding original API method is called.

Otherwise, if the service is s17, 19, 20, 21, 23, 24, or

25, then the RBAC check fails and the original API

method is not called. The other tabs of CT

‘Symptoms’, ‘Follow-Up’ and ‘Return’, are still

visible within the app. However, when a user with

the Coach role attempts to access one of these tabs,

the app will try to obtain the pertinent data via the

former original CT

API service that has been

replaced by a new CT

intercepting API service that

checks for permissions and returns that the specified

role does not have permission to retrieve the data for

those screens. Attempting to access other tabs with

services other than those authorized for the Coach

role (s18 and s22) results in a failed RBAC check

that denies the action.

To evaluate if the approach affected the

performance of the mobile app in any significant

way, we tracked the time the app took to perform

services with and without interception. Table 1

contains the time average (in seconds) the mobile

app took to process the services requested by the

clients without the intercepting API-based approach

versus the time it took to process the services

requested by the clients with interception. For this

evaluation, we assumed multiple users were utilizing

the mobile app simultaneously and that each of these

users made one request only, therefore, we emulated

the calling of 25, 50, 100, 250 services concurrently

to determine the time variation. By looking at the

results in Table 1, we observe that the time taken to

process services in their original state is smaller than

the time elapsed when the services are processed

with the use of our approach. Nevertheless, we

consider that even though adding time to process

services is not desirable, our intercepting API-based

approach is still quick since it takes only a matter of

microseconds to analyze the service requested by a

user and return a secured response. Therefore, in

terms of overhead, the mobile app did not take a

significant amount of additional time to execute a

user’s request.

Table 1: Original vs. Intercepting API service

Performance Evaluation (in seconds).

#of services 25 50 100 250

Original 3.34x10

-6

3.41x10

-6

3.54x10

-6

3.98x10

-6

Intercepting

API

1.08x10

-4

1.11x10

-4

1.18x10

-4

1.19x10

-4

4.2 Limitations and Discussion

The intercepting API-based approach performs

security checks to determine whether the API

service can occur based on the user and his/her role

that has been given permission to call a subset of the

services of the Secure API, thereby controlling what

is returned to the user. The approach as described in

this paper essentially creates a replica of the API that

the mobile app uses so that the mobile app utilizes

our intercepting API which can perform security

checks and then pass the call through to the original

mobile app API if the security permissions are met

(i.e., the role is authorized to the service of the

Secure API attempting to be invoked). This was

accomplished by renaming the calls to the services

of the original mobile app API. There are two

possible issues with this approach. First, we may not

have access to the mobile app API. Second, even if

we do, then the renaming would require changes to

the service names of the original mobile app API. As

a result, we believe that it is possible to realize a

solution to eliminate these two issues by proposing

an intercepting server that does not modify the

original mobile app API file but contains the original

service calls that the mobile app has access to and

then forward each call from the intercepting API

service of the same name to the original API service.

Figure 9: Alternate Process for the Intercepting API-Based

Approach.

Figure 9 illustrates an alternate process for the

Intercepting API-based approach that establishes an

intercepting server that has an API that will mimic

what the mobile app is expecting but is our

An Intercepting API-Based Access Control Approach for Mobile Applications

145

intercepting API (second box from the left in Figure

9). The intercepting API server must also be able to

mimic multiple APIs since the mobile app may

interact with several of these (depicted in third box

from the left in Figure 9). The original and

intercepting servers would need to be run on

different ports if on the same host with the

intercepting server being accessible publicly while

the original might only be accessible locally. The

intercepting server(s) could forward any allowed

calls to the original server(s) and filter the results as

needed before returning to the client. This is

facilitated by using the login credentials (user/role

combination) to determine the security level in each

of the API Services. Currently, we manage to pass

on the user id and the user’s role between calls by

storing these server-side in a JSON Web Token

(JWT) (JWT, 2015). This is done to secure the

user’s data and to verify that the user has access to

the action he/she requested by utilizing his/her role.

5 RELATED WORK

There are many efforts that propose access control

mechanisms to secure mobile applications by

limiting the permissions and resources a mobile app

can access in different areas of the mobile

device/app. In this section, we discuss several

existing proposed approaches that attempt to apply

access control mechanisms on different locations on

a mobile device and, we explain the way our

approach compares and contrasts.

The first area of related work involves sensor

management on smartphones that is commonly

addressed by applying access control mechanisms to

the sensors of a mobile device so that mobile apps

obtain fine-grained permissions. This facilitates the

managing of sensor data in mobile apps (e.g., user’s

location, use of Bluetooth) (Cappos et al., 2014; Xu

and Zhu, 2015). BlurSense (Cappos et al., 2014) and

SemaDroid (Xu and Zhu, 2015) allow users to

define and add privacy filters to sensor data, through

the means of a user interface, that is being used on

their mobile applications. In contrast to these efforts,

our work presented in this paper focuses on API

access control management for the API services that

are utilized within a mobile app to populate data in

the app and to add/edit data and store it in a data

source. In other words, instead of focusing on

modifying the operating system to filter sensor data

we modify the backend of a specific mobile app and

filter the data that a user can have access to

according to his/her role, which can include sensor

data as well if there was an API service included in

the intercepted API that managed this.

The second area of related work involves

permission control in Android in which access

control can be applied on the mobile device itself.

There are many existing approaches (Beresford et

al., 2011; Benats et al., 2011; Wang et al., 2014; Jin

et al., 2015; Hao et al., 2013; Backes et al., 2014)

that focus on applying fine-grained access control

policies to mobile devices that contain Android as

their operating system. This is due to the fact that

Android contains a coarse-grained access control

mechanism when it comes to allowing permissions

in mobile applications. In other words, in order for a

user to install a mobile app he/she needs to accept all

of the permissions that the app requires. This may

disregard the fact that some permissions may not be

necessary for the app to function and that some of

the permissions may not make sense for app that is

being downloaded and could result in using the

allowed component for malicious purposes (e.g., a

flashlight app tells user it needs permission to get the

user’s location). Adding fine-grained access control

to the APIs that Android uses for the device and

apps to function properly has been addressed by:

mocking the values that an app receives in order to

function (Beresford et al., 2011) (e.g., mocking

latitude and longitude coordinates); extending the

security policies of the mobile device (Benats et al.,

2011; Wang et al., 2014; Jin et al., 2015); by

rewriting the bytecode of the mobile device (Hao et

al., 2013); and by adding security modules to the

mobile device (Backes et al., 2014). In contrast to

this effort, our work presented in this paper focuses

on applying access control mechanisms to the APIs

that are not part of the mobile system itself. In

addition, most of these works are specific for

Android OS/API while ours can be implemented for

any type of application (even though we focus on the

mobile setting) since our access control approach is

enforced server-side.

The third area of related work involves role-

based access control and extensions that expand

RBAC with context-aware techniques in order to

provide finer-grained access control security policies

to those systems that contain highly sensitive data.

One effort does this by proposing an RBAC model

with a spatiotemporal extension for web applications

(Aich et al., 2009) and another effort proposes a

similar approach but for mobile applications

(Abdunabi et al., 2013). The proposed access control

system made for web applications (Aich et al., 2009)

can be applied to an existing system as a dll

component. Another approach proposes a dynamic

WEBIST 2017 - 13th International Conference on Web Information Systems and Technologies

146

RBAC approach for Android devices (Rohrer et al.,

2013). That approach focuses on modifying the

Android framework to provide a uniform security

policy to mitigate security risks in mobile devices

that are utilized by users who are part of an

enterprise. Finally, an effort (Fadhel et al., 2016)

proposed a model that extends RBAC to generate

RBAC conceptual policies. Nevertheless, the

aforementioned effort does not provide details of

which specific application domain(s) the approach

could support. Our proposed framework could easily

be extended to support other types of access control,

can be applied to mobile web applications and, it is

not domain-specific; this contrasts to discussed

related work.

6 CONCLUSION & ONGOING

WORK

This paper presented and discussed an intercepting

API-based access control approach for mobile

applications achieved via role-based access control

defined and enforced on services. Specifically, the

work in this paper demonstrated the way that RBAC

can be incorporated into an intercepting API that

wraps the original mobile app API in order to

manage the data displayed in a mobile application.

To begin the presentation, Section 2 reviewed

background on RBAC and APIs, motivated the

usage of RBAC in mobile applications, and

described the Connecticut Concussion Tracker (CT

)

mHealth app. Using that as a basis, Section 3

detailed our proposed intercepting API-based

approach, which included the transition from the

original mobile app API to a renamed mobile app

API that is then wrapped with the intercepting API.

To demonstrate the feasibility and utility of our

work, Section 4 explained the realization of the

intercepting API-based approach into the CT

mobile application and discussed a way to address

the limitations of the proposed approach. Lastly,

Section 5 reviewed and contrasted related work to

our effort.

As part of our ongoing work, we are researching

on the way to incorporate RBAC, MAC, and DAC

into the Fast Interoperable Healthcare Resources

(FHIR) specification and infrastructure (FHIR,

2016) to facilitate information exchange between a

mHealth app and multiple EHRs and health

information technology systems. So far, we have

published a paper (Rivera Sánchez et al., 2017) with

our findings on incorporating RBAC in FHIR

through the means of the HAPI FHIR reference

implementation (HAPI FHIR, 2014). Our solution

utilizes unique capabilities in HAPI FHIR that allow

our code to intercept the FHIR server API service

calls so that the service calls that the mHealth app

makes against the RESTful API service calls are

checked against defined RBAC policies. We believe

that this in turn will aid us in the development of a

general approach for securing data that is managed

through the means of APIs.

REFERENCES

Abdunabi, R., Ray, I., & France, R., 2013. Specification

and analysis of access control policies for mobile

applications. 18th ACM Symposium on Access

Control.

Models and Technologies (SACMAT '13). ACM, pp. 173–

184.

Aich, S., Mondal, S., Sural, S., & Majumdar, A. K., 2009.

Role Based Access Control with Spatiotemporal

Context for Mobile Applications. Transactions on

Computational Science IV: Special Issue on Security

in Computing.

Backes, M., Bugiel, S., Gerling, S., & von Styp-

Rekowsky, P., 2014. Android Security Framework:

Extensible multi-layered access control on Android.

30th Annual Computer Security Applications.

Conference, pp. 46-55.

Beal, V., 2014. API - application program interface.

[Online] Available.

at: http://www.webopedia.com/TERM/A/API.html.

Benats, G. et al., 2011. PrimAndroid: privacy policy

modelling and analysis for android applications. In

Symposium on Policies for Distributed Systems and

Networks (POLICY ‘11). IEEE.

Beresford, A., Rice, A., Skehin, N., & Sohan, R., 2011.

MockDroid: trading privacy for application

functionality on smartphones. 12th Workshop on

Mobile Computing Systems and Applications. Phoenix,

Arizona.

Cappos, J., Wang, R., Yang, Y. & Zhuang, Y., 2014.

Blursense: Dynamic fine-grained access control for

smartphone privacy. [Online] Available at:

DOI=10.1109/SAS.2014.6798970.

Cobb, M., 2014. API security: How to ensure secure API

use in the enterprise. [Online] Available at:

http://searchsecurity.techtarget.com/tip/API-security-

How-to-ensure-secure-API-use-in-the-enterprise.

Collet, S., 2015. API security leaves apps vulnerable: 5

ways to plug the leaks. [Online] Available at:

http://www.csoonline.com/article/2956367/mobile-

security/api-security-leaves-apps-vulnerable-5-ways-

to-plug-the-leaks.html.

Connecticut General Assembly, 2015. Substitute for

Raised H.B. No. 6722. [Online] Available at:

https://www.cga.ct.gov/asp/CGABillStatus/CGAbillst

An Intercepting API-Based Access Control Approach for Mobile Applications

147

atus.asp?which_year=2015&selBillType=Bill&bill_nu

m=HB6722.

Dellinger, A., 2015. This Instagram app may have stolen

over 500,000 usernames and passwords. [Online]

Available at: http://www.dailydot.com/technology.

/instaagent-instagram-app-malware-ios-android/

Developer Program, 2012. Benefits of APIs. [Online]

Available at: http://18f.github.io/API-All-the-

X/pages/benefits_of_apis.

Facebook, 2014. Facebook Graph API. [Online]

Available at:https://developers.facebook.com/docs/

graph-api.

Fadhel, A., Bianculli, D., Briand, L. & Hourte, B., 2016. A

Model-driven Approach to Representing and Checking

RBAC Contextual Policies. CODASPY 2016. ACM,

pp. 243–253.

Fernández-Alemán, J., Señor, I., Lozoya, P. & Toval, A.,

2013. Security and privacy in electronic health

records: A systematic literature review. Journal of

Biomedical Informatics, 46(3), pp. 541-562.

Ferraiolo, D. & Kuhn, R., 1992. Role-Based Access

Control. NIST-NSA National (USA) Computer Security

Conference, pp. 554-563.

Ferraiolo, D. et al., 2001. Proposed NIST standard for

role-based access control. ACM Transactions on

Information and System Security (TISSEC), Volume 4,

pp. 224-274.

FHIR, 2016. Welcome to FHIR. [Online]

Available at: https://www.hl7.org/fhir/index.html.

Flanders, D., Ramsey, M., & McGregor, A., 2012. The

advantage of APIs. [Online]

Available at: https://www.jisc.ac.uk/guides/the-

advantage-of-apis.

Hao, H., Singh, V. & Du, W., 2013. On the effectiveness

of API-level access control using bytecode rewriting

in Android. 8th ACM SIGSAC symposium on

Information, computer and communications security.

Hangzhou, China.

HAPI FHIR, 2014. HAPI. [Online] Available at:

http://hapifhir.io/

Instagram, 2010. Instagram. [Online] Available at:

https://www.instagram.com/

Jin, X., Wang, L., Luo, T. & Du, W., 2015. Fine-Grained

Access Control for HTML5-Based Mobile

Applications in Android. 16th Information Security

Conference (ISC), pp. 309-318.

JWT, 2015. Introduction to JSON Web Tokens. [Online]

Available at: https://jwt.io/introduction/

Larson, S., 2015. Instagram restricts API following

password breach, will review all apps going forward.

[Online] Available at: http://www.dailydot.com/

technology/instagram-api-restrictions/

Lella, A., Lipsman, A. & Martin, B., 2015. The 2015

Mobile App Report.

[Online] Available at:

https://www.comscore.com/Insights/Presentations-

and-Whitepapers/2015/The-2015-US-Mobile-App-

Report.

Microsoft Corporation, 2008. Mobile Application

Architecture Guide. [Online] Available at:

http://apparch.codeplex.com/releases/view/19798.

REST API Tutorial, 2012. Learn REST: A RESTful

Tutorial. [Online] Available at: http://

www.restapitutorial.com/

Rindfleisch, T., 1997. Privacy, Information Technology,

and Health Care. Communications of the ACM, 40(8),

pp. 93-100.

Rivera Sánchez, Y. K., Demurjian, S.A., & Baihan, M.,

2017. An Access Control Approach for FHIR. 5th

IEEE International Conference on Mobile Cloud

Computing, Services, and Engineering (IEEE Mobile

Cloud 2017).

Rohrer, F., Zhang, Y., Chitkushev, L. & Zlateva, T., 2013.

DR BACA: dynamic role based access control for

Android. 29th Annual Computer Security Applications

Conference. New Orleans, Louisiana, USA.

Rouse, M., 2006. HTTP (Hypertext Transfer Protocol).

[Online] Available at: http://searchwindevelopment.

techtarget.com/definition/HTTP.

Sandhu, R. & Samarati, P., 1994. Access Control:

Principles and Practice. Communications Magazine,

32(9), pp. 40-48.

Slim, 2015. Slim a micro framework for PHP. [Online]

Available at: https://www.slimframework.com/

Snapchat, 2011. Snapchat. [Online] Available at:

https://www.snapchat.com/

Snapchat, 2013. Finding Friends with Phone Numbers.

[Online] Available at: http://blog.snapchat.com/post/

71353347590/finding- friends-with-phone-numbers.

Wang, Y. et al., 2014. Compac: enforce component-level

access control in android. 4th ACM conference on

Data and application security and privacy. San

Antonio, Texas, USA.

West, A., 2015. 5 Roles of Role Based Access Control.

[Online] Available at: https://www.itouchvision.com/

5-roles-of-role-based-access-control-the-software-

security-guard/

Xu, Z. & Zhu, S., 2015. Semadroid: A privacy-aware

sensor management framework for smartphones. 5th

ACM Conference on Data and Application Security

and Privacy. ACM, pp. 61-72.

Zeman, E., 2015. Snapchat Lays Down The Law On

Third-Party Apps. [Online] Available at:

http://www.programmableweb.com/news/snapchat-

lays-down-law-third-party-apps/2015/04/07.

WEBIST 2017 - 13th International Conference on Web Information Systems and Technologies

148
