Proactive Trust Assessment of Systems as Services

Jorge López

, Natalia Kushik

1,2

and Nina Yevtushenko

2,3

SAMOVAR, CNRS, Télécom SudParis, Université Paris-Saclay, 9 rue Charles Fourier 91011 EVRY, France

Department of Information Technologies, Tomsk State University, 36 Lenin str., 634050 Tomsk, Russia

Software Engineering Department, Institute for System Programming of the Russian Academy of Sciences,

25 Alexander Solzhenitsyn str., 109004 Moscow, Russia

Keywords: Systems as Services, Machine Learning, Dynamic Code Analysis, Trust, Software Testing.

Abstract: The paper is devoted to the trust assessment problem for specific types of software/hardware systems,

namely Systems as Services. We assume that such systems are designed and utilized in all application

domains, and therefore the aspects of trust are becoming crucial. Moreover, these systems are mainly used

on-demand and are often represented by a composition of ‘smaller’ services. Thus, an effective method for

estimating/assessing the trust level of a given component service (or a system as a whole) needs to be

utilized. Most known methods and techniques for trust evaluation mainly rely on the passive testing and

system monitoring; in this paper, we propose a novel approach for this problem taking advantage of active

testing techniques. Test sequences to be applied to a system/service under test are derived based on

determining the critical values of non-functional service parameters. A set of these parameters can be

obtained via a static code analysis of the system/service or by addressing available experts. Machine

learning techniques can be applied later on, for determining critical parameter values and thus, deriving

corresponding test sequences. The paper contains an illustrative example of RESTFul web service which

components are checked w.r.t. critical trust properties.

1 INTRODUCTION

The concept of Systems as Services (SaS) is

ambitious and emerging, as it aims to expand the

existing “cloud” concepts to any type of system

(Ardagna et al., 2015). In fact, it is a natural system

evolution to start at different locations, and then

slowly move to a utility service. In recent years,

cloud computing entitled computational resources to

be distributed as a utility service, and this concept

has encouraged to provide any system as a service.

Arguably, augmenting a system with a cloud/web

interface might enable it to become a SaS.

Nevertheless, there exist several issues, such as

interoperability, system/service composition,

trustworthiness, etc., that need to be considered. In

order to rely on such SaS from a user or a provider

point of view, the trustworthy level of SaS needs to

be guaranteed.

Trust as a computer science concept is an active

field of research in the scientific community. In the

literature, two main trust notions are used, namely i)

hard trust, which is based on security policies, and

ii) soft trust, which is based on different dynamic

parameters. The hard trust approach is rigid; the

trustees have predefined sets of privileges granted,

and the system’s interactions are managed by the

acceptance or rejection of actions based on these

predefined privileges. Some examples of pioneering

works on hard trust can be found in (Lee et al., 2009;

Blaze et al., 1996; Jim, 2001). On the other hand,

soft trust is flexible, and the interactions are

managed depending on the trust level of a trustee at

a given time instance. Intuitively, the level of trust

depends on a set of “trust parameters”; according to

the literature, the most common trust parameters

include experience, reputation, and risk. Soft trust

has been applied to different domains, some

examples of such applications can be found in (Chen

and Guo, 2014; López and Maag, 2015).

Both major approaches for trust definition have

their own drawbacks. Hard trust guarantees that

some entities can have access to certain resources

regardless of potentially untrustworthy behavior of

such entities at execution time. Soft trust, on the

other hand, is a reactive approach, i.e., an

untrustworthy behavior needs to occur before

establishing that a trustee is not trustworthy.

López, J., Kushik, N. and Yevtushenko, N.

Proactive Trust Assessment of Systems as Services.

DOI: 10.5220/0006354502710276

In Proceedings of the 12th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2017), pages 271-276

ISBN: 978-989-758-250-9

271

To overcome the inherent and potentially present

disadvantages that the current trust approaches tend

to have, we propose a proactive trust assessment

approach. The key idea behind a proposed approach

is based on guaranteeing that a given system can

only produce trustworthy outputs under critical

inputs to such system. Therefore, the approach can

be seen as some form of a certification method and

could/should be applied to a system under design

when application of critical inputs does not

jeopardize the data of the application or the system’s

data are not susceptible to such input application.

The problem statement we address in this paper is as

follows: what are the important/critical trust

parameters for systems as services, what are the

crucial values of those and how to actively test such

systems to ensure that they can produce only

trustworthy interactions when the parameters reach

their critical values? We mention that testing

techniques have been previously developed for

cloud environments, however they mostly cover the

security checking of the corresponding

applications/services. A comprehensive review of

such techniques is given in (Ardagna et al., 2015).

The method proposed in the paper is divided into

two main phases. The first phase is to determine the

parameters that might affect the trustworthiness of

the system. For this purpose, we propose to build a

dataset of potentially sensitive trust parameters,

given by experts, for example. Such list of

parameters can also be specified by service

providers. Then, by the use of supervised machine

learning techniques a trust prediction model is

derived. The second phase relies on applying a

proper test suite in order to verify the

trustworthiness of the system. The verification of the

trustworthiness of the system is based on the

extraction of the values of the sensitive trust

parameters. The approach is illustrated on a running

example of a RESTFul web service.

The rest of the paper is organized as follows.

Section 2 contains preliminary concepts. Section 3

describes how to extract the sensitive trust variables

from the source code of a System Under Test (SUT).

Section 4 contains the description of the approach

for applying different input (test) sequences to the

SUT that contain sensitive values of critical

variables; the prediction model is used to determine

if the SUT produces values considered to be

untrustworthy. Finally, Section 5 concludes the

paper.

2 PRELIMINARIES

2.1 Systems as Services and Trust

Issues

The concept of Systems as Services (SaS) has

emerged and been used nowadays almost

everywhere. We assume that such systems are

represented as compositions of heterogeneous

hardware and/or software modules. These modules

are usually created by different producers or service

providers. The main goal of such creation is to meet

user requirements and as a result, to deliver a high-

level Quality of Experience (QoE). At the same

time, a user experience can never be guaranteed

before the trust of the service components is

estimated thoroughly.

Grandison and Sloman define trust as “the firm

belief in the competence of an entity to act

dependably, securely, and reliably within a specified

context” (Grandison and Sloman, 2000). In other

words, the trustworthiness of a SaS involves

different aspects. For example, it is assumed that a

SaS must be capable (competent) of performing the

task it is designed, and inquired for. If the SaS

contains defects (or bugs), the SaS is not considered

to be trustworthy. The levels of trustworthiness of a

SaS can vary. It is naturally to use three different

trust levels (López and Maag, 2015): Trustworthy,

for systems that are entirely trusted; Untrustworthy,

for systems that are distrusted; and Neutrally

Trusted, for systems that are partially trusted. We

note that the systems associated with the last trust

level can be of a wide use as well. For example, one

might still interact with a SaS which has neutral

trust, using a limited set of non-critical operations.

2.2 Active Testing Techniques

Active testing techniques and approaches are used in

software testing for assuring the software quality.

Usually, active testing includes the generation of test

sequences or test cases, application/executions of

those against a SUT and drawing the conclusion

about the SUT properties. The notion active in this

case underlines the fact that the system is being

stimulated via its input interfaces. Various test

generation strategies define the test fault coverage,

i.e. the set of (program) faults that can be detected

by a given test suite. The test length is another

important test quality criterion, and therefore, there

have been proposed numerous test generation

approaches. These approaches start from random

input generation and finish with complex model

ENASE 2017 - 12th International Conference on Evaluation of Novel Approaches to Software Engineering

272

based techniques that demonstrate lower

performance but higher fault coverage.

The known trust assessment approaches in

telecommunication systems mostly rely on passive

testing techniques or monitoring (López, 2015)

when only system observation is performed. In this

paper, we take advantage of stimulating the SUT for

producing the untrustworthy actions, i.e. we

intensely try to apply the critical input data to the

SaS which can potentially be never observed during

its ordinary monitoring. The decision about which

actions can be considered ‘suspicious’ is done with

the use of supervised machine learning techniques.

2.3 Supervised Machine Learning

Machine learning algorithms are designed to learn

from available data in order to make

predictions/estimations. Typically, the machine

learning algorithms operate by building a model.

The model “learns” to predict from the data without

being explicitly instructed. Supervised machine

learning algorithms take training examples along

with their expected outputs as the algorithm’s inputs.

The final goal is to get a machine (after learning)

that maps the training examples to their expected

outputs.

Formally, the inputs are called features. A feature

vector is an -tuple of the different inputs. The

expected output for a given feature vector is a label.

The set of examples, called a training set, consists of

pairs of a feature vector and a label. The objective is

to find a function called the hypothesis, that maps a

given feature vector to a label. Therefore, the

objective is, in fact, to find the function that

minimizes the error between the predictions and the

real output.

There exist various known machine learning

techniques starting from the classical linear

regressions and decision trees, and finishing with

Support Vector Machines (SVMs) and their

modifications. In this paper, we use such techniques

in order to estimate if the SUT behaves in a

trustworthy manner. The corresponding training set

is derived based on the example data provided by an

expert’s assessment. Another important step before

training the model, is the relevant features’ selection.

If a certain parameter p

does not affect the overall

prediction result (a label), deleting this parameter

makes the process more scalable. Usually, such

statistical parameter analysis is considered as a pre-

processing phase. There exist some well-known

methods for selecting the relevant parameters. In

(Blum and Langley, 1997), the authors showcase a

number of such methods.

3 EXTRACTING RELEVANT

PARAMETERS FOR SAS

TRUST ASSESSMENT

Different systems have different parameters that

influence the trustworthiness of the system. Some

parameters might be related to functional properties

of the system while others can represent various

non-functional ones, such as, for example response

time for a given request. Occasionally, the trust

parameters might be observable as system outputs.

For example, a trust parameter can be the support of

certain algorithms of encryption of the

communication, and the respective size of the

encryption key of a SUT. On the other hand, a

desired trust parameter can be an internal variable,

which might influence the behavior of the SUT.

Thus, we assume that the trust parameters are

variables and outputs in the associated source code

of the system. Therefore, the question arises: how

can different trust parameters be observed?

In order to better exemplify which trust

parameters may be associated with the source code,

consider a SaS with a RESTFul web service

(Pautasso et al., 2008). RESTFul web services use

the hyper text transfer protocol (HTTP) as an

underlying communication protocol. HTTP defines

standard request methods, however, the HTTP

version 1.1 as specified in RFC 2616, allows

arbitrary extension methods. Further specifications

such as the semantics and content of HTTP version

1.1 found in the RFC 7231 state that additional

methods need to be registered in AINA (see section

4.1 and 8.2 of the RFC). However, widely-spread

web servers as the Apache HTTP Server might

allow extension methods and leave the

application/framework to ‘decide’ how to process it.

Many frameworks allow the use of extended

methods. The behavior of such frameworks for

extended methods can include treating an extended

method as a normal GET request. However, some

policies of authentication are only applied to GET or

POST request. The result is that the application

might allow bypassing security/authentication

mechanisms by a request with an extended method

(Dabirsiaghi, 2016). Other frameworks might even

output the source code of the application.

Assume a SaS framework/application is

implemented as shown in the pseudo-code below:

$httpMethod=getMethod($httpRequest);

…

$startTime = getTime();

($responseCode, $httpResponse) =

processData($httpMethod, $URI);

$time = startTime – getTime();

…

Proactive Trust Assessment of Systems as Services

273

The variable $httpMethod contains the HTTP

request method, $URI contains the requested

resource, and $responseCode contains the response

code after the request is processed. The variable

$time contains the time to process the request. A

trust/security expert might find untrustworthy if a

known method to a given resource replies a

redirection (3xx HTTP response code), and an

extended method replies with success (2xx HTTP

response code). The expert can find untrustworthy

the systems that exceed one second to process a

request, given the fact that the implementation does

not reply in a proper time. Therefore, from the

observation of the internal variables and outputs of

the source code the expert can provide a trust

assessment. The trust parameters in this example

are: $httpMethod, $responseCode, $URI, and $time.

Given the fact that different systems have

different trust parameters, we assume that the initial

selection of them is performed by an expert which

can often be represented by a developer or a service

provider. Furthermore, the expert can provide a set

of ranges for those parameters when the application

is considered to be trustworthy. Based on the

assessment of the expert a dataset can be derived;

this dataset contains different classifications of the

trustworthiness of a system. For example, the expert

can define three different classes of trust, trusted (3),

not trusted (1) and neutrally trusted (2). The dataset

D contains a set of vectors of values for all trust

parameters p

, p

, …, p

. Each vector of values







,





,…,





 has an associated trust evaluation

∈ [1-3], for j = 1, 2,…, m, where m is the size of

the dataset. The dataset D can be used as a training

set for a supervised machine learning problem. In

(López and Maag, 2015), the authors proposed a

multi-class classification trust prediction model

based on Support Vector Machines (Boser et al.,

1992). Depending on the characteristics of the

dataset, one might be interested to use other

supervised machine learning techniques, which are

faster, such as the well-known logistic regression or

a scalable prediction model based on logic circuits

(Kushik et al., 2016). In general, the prediction

model is adapted to its requirements. The trust

prediction model separates the data into the trusted,

untrusted, and neutrally trusted hyperspaces. By the

observation of the different values of the system

parameters, one can conclude about the level of

trustworthiness of the system. After selecting the

parameters, the relevant feature selection pre-

processing should be performed.

On the other hand, after the relevant feature (and

training example) selection, the dataset can be used

to build a trust prediction model using any

supervised machine learning technique which allows

multi-class classification. Then, the model M that

predicts the trust level (in the [1-3] range) based on

the sensitive trust parameters is obtained.

4 ACTIVE TESTING

TECHNIQUES FOR TRUST

ASSESSMENT

As mentioned above, to the best of our knowledge

existing trust evaluation methodologies for

telecommunications mostly rely on passive testing

assessment, i.e. when the conclusions are being

made while only observing the behavior of the SUT.

The idea behind the proposed approach is, on the

contrary, trying to violate the SUT by applying

specific inputs that can make this SUT behave

untrustworthy. The approach relies on the machine

learning techniques that can be used to predict the

trust level of the SUT under the given values of its

internal/external variables. In this case, the machine

that predicts such trust level plays a role of an oracle

or a specification that ‘knows’ the expected

outcome, i.e. the level of trust for the SUT under the

given conditions. The test suite to be executed

against the SUT can be derived in different ways,

starting from random simulation and finishing with

model based test generation techniques. If the source

code of the SUT is (partially) open, the test suite TS

can be also derived using static analysis.

Given the SUT Sys, its source code SC, a set

P = {p

, …, p

} of relevant SUT variables and a

machine M that predicts the trust level T based on

the values v

, …, v

of p

, …, p

, correspondingly,

TS is a test suite derived for the SUT Sys.

Algorithm 1 can be used to assess the

trustworthiness of Sys w.r.t. P = {p

, …, p

}. We

assume that the SUT Sys behaves trustworthy if for a

given test sequence the machine M assures the trust

level T greater or equal to a given constant K1. We

also take into account how many sequences of a test

suit actually bring the SUT to an untrustworthy state.

We compare this value with a given constant K2 that

represents the ‘allowed’ level of fluctuations, i.e.,

represents the percentage of test sequences for which

the oracle M returns a level T < K1. We note that as

M is the machine that was previously learned by

experts and/or users/developers, this percentage K2

is usually chosen as K2 < 10.

Algorithm 1 returns the verdict ‘Pass’ whenever

the oracle M represented by a (self-) adaptive model

replies that the values v

, …, v

of variables p

, …,

do not reach their critical (from the trust point of

view) values more than for K2 percent of test cases.

ENASE 2017 - 12th International Conference on Evaluation of Novel Approaches to Software Engineering

274

Algorithm 1 for assessing the trustworthiness of the

SUT based on active testing

Input: SUT Sys with the source code SC, a set

P = {p

, …, p

} of parameters/variables, a machine

M, a minimal trust level K1, an allowed

untrustworthy percentage K2, a test suite TS

Output: ‘Pass’ or ‘Fail’

1. i := 1; j := 0;

2. If (i > | TS |)

then Return the verdict ‘Pass’.

3. Execute the test sequence α

∈TS against the SUT

Sys;

Trace (observe in the code SC) the values v

, …, v

of p

, …, p

, correspondingly;

Apply the vector (v

, …, v

) to the machine M and

obtain the output value t of the trust level T, i.e.

simulate M over (v

, …, v

If (t < K1) then j := j + 1;

If ((j / |TS|) > K2)

then Return the verdict ‘Fail’.

4. i := i + 1; and Go to Step 2.

The main idea of the proposed approach is

schematically represented in Fig. 1.

Figure 1: The idea behind the proposed approach.

For better illustration, consider the following

inputs for Algorithm 1, taken from the example of

RESTFul service (Section 3). The source code SC is

the pseudo-code shown above. Let p

be a parameter

that represents the response time, i.e., $time. Let p

be a parameter that represents the response code, i.e.

$responseCode. As we are only interested in the

HTTP codes 3xx and 2xx, we consider p

to be a

Boolean variable, where 0 stands for 2xx and 3xx

for 1, correspondingly. Assume also that as a

prediction model we use a linear combination

0.40.6



2



 (result is round w.r.t the

nearest integer). Let K1 = 2, and K2 = 0 and the test

suite TS = {GET /login.php HTTP/1.1, POST

/login.php HTTP/1.1, FAKE /login.php HTTP/1.1}.

This test suite contains three input sequences of

length one. Each sequence represents a typical

HTTP request. For example, the first sequence GET

/login.php HTTP/1.1 denotes that a method GET is

sent, the URL is /login.php and the protocol of

version 1.1 is being used.

Assume that the traces shown in Table 1 are

obtained for the above source code.

Table 1: Example values from traces of the SaS

under

test.

Test sequence p

Trust

level

GET /login.php HTTP/1.1 1 1 3

POST /login.php

HTTP/1.1

0,001 1 2

FAKE /login.php

HTTP/1.1

1 1 3

Algorithm 1 returns the verdict ‘Pass’ for values

in Table 1. On the other hand, assume the traces of

the SaS are different, as shown in Table 2.

Table 2: Example values from traces of the SaS

under

test.

Test sequence p

Trust

level

GET /login.php HTTP/1.1 1 1 3

POST /login.php

HTTP/1.1

0 1 2

FAKE /login.php

HTTP/1.1

1 0 1

In the latter case, Algorithm 1 returns the verdict

‘Fail’. Indeed, the SaS

is not trustworthy for the

criteria listed above.

We mention that the effectiveness of the

algorithm essentially relies of the fact how a test

suite TS has been generated. Many test generation

techniques focus on conformance testing, namely on

assuring functional requirements of a SaS or its

components. In this case, the test suite TS has

another objective, i.e. an application of a test

sequence should bring the SUT to a state or to a

configuration (when internal variables are

introduced as inputs of the machine M) where this

SUT behaves untrustworthy. Therefore, the

proposed approach can also be used for estimating

the correlation between functional tests and their

non-functional properties, namely ‘trust estimating’

properties. A given functional test suite TS can be

very effective/powerful with respect specific fault

domain, however it can rarely bring the SUT to an

untrustworthy state. On the other hand, it is also

possible that random tests that are known to have

rather low fault coverage can probably propagate the

critical values of the sensitive variables more often.

Thus, one of interesting questions for future work

Proactive Trust Assessment of Systems as Services

275

can be a test prioritization, when test sequences or

test cases are distributed between several classes. In

functional testing, these classes are usually

represented by the number of faults or the number of

mutants that can be killed by a given test case. In the

case of active trust assessment, test cases can be

assigned with the scores as the trust levels obtained

from a SUT. Studying the dependencies between

functional and non-functional score assignment is

one of the directions of our future work.

5 CONCLUSIONS

In this paper, we have proposed an active testing

based trust assessment approach. The approach can

be applied to any entity of a telecommunication

system; however, we preferred to draw our attention

to the emerging concept of Systems as Services.

In order to decide which input sequences can be

included into a test suite under derivation, we

proposed to use a machine learning approach. In this

case, the machine that represents the prediction

engine is built based on the training set provided by

the experts. Later on, the machine allows to choose

the test sequences that can potentially cause the

system under test to produce untrustworthy outputs.

To the best of our knowledge, it is the first proposal

for using active testing techniques for SaS trust

assessment, and the proposed approach brings a lot

of challenges for the future work. In particular, we

would like to perform experiments with the various

SaS for estimating its validity and effectiveness.

Later on, we would like to consider the test

prioritization problem when the test sequences are

being classified according to their abilities of setting

the system to untrustworthy states. Finally, the

active assessment of trustworthiness of an entity

might be the first step in a trust certification process.

Investigation of the applicability of the approach for

the SaS trust certification is another challenge.

The issues listed above form the nearest

directions of the future work.

ACKNOWLEDGEMENTS

The work was partially supported by the Russian

Science Foundation (RSF), project № 16-49-03012.

REFERENCES

Ardagna C.A., Asal R., Damiani E., Vu Q.H., 2015. From

Security to Assurance in the Cloud: A Survey. In

ACM Computing Surveys , 48(1), pp. 1-50.

Blum, A., Langley, P., 1997. Selection of Relevant

IFeatures and Examples in Machine Learning. In

Artificial Intelligence. V. 97, I. 1-2, pp. 245-271.

Kushik, N., Yevtushenko, N., Evtushenko, T., 2016.

Novel machine learning technique for predicting

teaching strategy effectiveness. In International

Journal of Information Management, DOI:

10.1016/j.ijinfomgt.2016.02.006.

López, J., Maag, S., 2015. Towards a Generic Trust

Management Framework Using a Machine-Learning-

Based Trust Model. In IEEE Trustcom / BigDataSE /

ISPA, Helsinki, pp. 1343-1348. doi:

10.1109/Trustcom.2015.528.

Lee, A.J., Winslett, M., Perano, K.J., 2009. TrustBuilder2:

A Reconfigurable Framework for Trust Negotiation.

In the IFIP International Conference on Trust

Management. pp. 176-195.

Blaze, M., Feigenbaum, J., Lacy, J., 1996. Decentralized

Trust Management. In the IEEE Symposium on

Security and Privacy. pp. 164-173.

Jim, T., 2001. SD3: A Trust Management System with

Certified Evaluation. In the IEEE Symposium on

Security and Privacy. pp. 106-115.

Chen, I., Guo, J., 2014. Dynamic Hierarchical Trust

Management of Mobile Groups and Its Application to

Misbehaving Node Detection. In the IEEE

International Conference on Advanced Information

Networking and Applications. pp. 49-56.

López, J., Maag, S., Morales, G., 2016. Behavior

evaluation for trust management based on formal

distributed network monitoring. In World Wide Web

V. 19, I. 1, pp. 21-39.

Pautasso, C., Zimmermann, O., Leymann, F., 2008.

Restful web services vs. “big”’ web services: making

the right architectural decision. In the 17

international conference on World Wide Web. pp.

805-814.

Dabirsiaghi, A. 2016. Bypassing VBAAC with HTTP

Verb Tampering: How to inadvertently allow hackers

full access to your web application, Electronic

resource:http://cdn2.hubspot.net/hub/315719/file-

1344244110-pdf/download-

files/Bypassing_VBAAC_with_HTTP_Verb_Tamperi

ng.pdf?t=1479325184680 (seen 01/12/2016).

Boser, B.E., Guyon, I.M., Vapnik, V.N., 1992. A training

algorithm for optimal margin classifiers. In the Fifth

Annual Workshop on Computational Learning

Theory. pp.144–152.

Grandison, T., Sloman, M., 2003. Trust management tools

for internet applications. In Trust Management,

Springer First International Conference, iTrust,

Heraklion, Crete, Greece. pp. 91–107.

López, J., 2015. Distributed on-line network monitoring

for trust assessment. Thesis of the University of Paris-

Saclay, France.

ENASE 2017 - 12th International Conference on Evaluation of Novel Approaches to Software Engineering

276
