Establishing Trust in Cloud Services via Integration of Cloud Trust

Protocol with a Trust Label System

Vincent C. Emeakaroha

, Eoin O’Meara

, Brian Lee

, Theo Lynn

and John P. Morrison

Irish Centre for Cloud Computing and Commerce,

University College Cork, Cork, Ireland

Irish Centre for Cloud Computing and Commerce,

Athlone Institute of Technology, Athlone, Ireland

Irish Centre for Cloud Computing and Commerce,

Dublin City University, Dublin, Ireland

Keywords:

Cloud Trust Label, Cloud Trust Protocol, Cloud Monitoring, Quality of Service, Service Level Agreement,

Cloud Computing.

Abstract:

Cloud computing has transformed the computing landscape by enabling ﬂexible compute-resource provision-

ing. The rapid growth of cloud computing and its large-scale nature provide many advantages to business

enterprises. Lack of trust in cloud services however remains a major barrier to the adoption of cloud comput-

ing. Trust issues typically relate to concerns about the location, protection and privacy of data. The concept of

trust includes trust in both novel technologies and cloud service providers and is composed of both persistent

and dynamic trust elements. We have previously developed a trust label system that is capable of facilitating

both persistent and dynamic trust building in both cloud services and cloud service providers; however, it

lacks reliable information delivery mechanisms. The Cloud Trust Protocol (CTP) aims to provide a reliable

information communication system for cloud service consumers and thus offers a natural complement to the

trust label system by providing a reliable and interoperable information exchange mechanism. In this paper,

we propose a novel integration of the trust label system with CTP to provide end-to-end visibility of cloud

service operational information to consumers.

1 INTRODUCTION

The adoption of cloud computing is growing at such

rates that some analysts forecast public IT cloud ser-

vices will account for more than half of worldwide

software, server, and storage spending growth by

2018 (Gens, 2014). Highly scalable, shared and dis-

tributed infrastructure that can be rapidly deployed

at arms-length can accrue many business beneﬁts,

not least quicker response times to customer require-

ments, work efﬁciencies, and reduced IT costs (Buyya

et al., 2009; Hogan et al., 2011; Low et al., 2011).

Unsurprisingly, enterprises are attracted by the com-

bination of IT efﬁciencies and business agility that the

cloud computing model can offer (Kim, 2009).

Despite the widely reported beneﬁts of cloud com-

puting, lack of trust in cloud services remains a ma-

jor barrier to its adoption. Such trust issues typically

relate to concerns about the location, protection and

privacy of data in storage, in transit and while being

processed in the cloud. However, these issues con-

sist of a wider class of security concerns including

increased vulnerabilities relating to virtualisation, au-

thentication and identiﬁcation, web application and

network security (Leimbach et al., 2014; Bradshaw

et al., 2012; Subashini and Kavitha, 2011; Pearson

and Benameur, 2010). The concept of trust in com-

puting is complex. It involves trust in both a novel

technology and external cloud service providers and

is composed of both persistent and dynamic trust el-

ements (Lynn et al., 2016; Pearson and Benameur,

2010). The global and distributed nature of the cloud

exacerbates trust issues by introducing a lack of clar-

ity on the identity and role of various actors within the

chain of service provision, their associated responsi-

bilities, and potential liabilities in the event of service

failure.

Given these challenges, various mechanisms have

been proposed for introducing accountability and as-

surance (Pearson and Benameur, 2010; Lynn et al.,

2013; Zissis and Lekkas, 2012; Pearson, 2013) in

an effort to address trust issues but they suffer lim-

590

Emeakaroha, V., O’Meara, E., Lee, B., Lynn, T. and Morrison, J.

Establishing Trust in Cloud Services via Integration of Cloud Trust Protocol with a Trust Label System.

DOI: 10.5220/0006362906180625

In Proceedings of the 7th International Conference on Cloud Computing and Services Science (CLOSER 2017), pages 590-597

ISBN: 978-989-758-243-1

itations, such as lack of dynamism. Previously,

the authors have presented a validated trust label

to collate and communicate trust in both cloud ser-

vices and cloud service providers (Lynn et al., 2016;

Emeakaroha et al., 2016; Masevic et al., 2016). The

trust label system facilitates both persistent and dy-

namic trust building in cloud services and cloud ser-

vice providers; however, it assumes reliable informa-

tion delivery mechanisms are in place to communi-

cate the required data to populate the interface.

The Cloud Trust Protocol (CTP) (Cloud Security

Alliance, 2015a) is a recent initiative by the Cloud

Security Alliance (CSA). It aims to provide a reliable

information communication system for cloud service

consumers to ask for and receive information about

essential security conﬁguration and operational char-

acteristics as applied to cloud service providers. As

such the CTP provides a natural complement to the

trust label system by providing a reliable and inter-

operable information exchange mechanism. In this

paper, we propose a novel integration of the trust la-

bel system with CTP to provide end-to-end visibil-

ity of cloud service operational information to con-

sumers. This is facilitated by the implementation of

a robust bridge library. Based on a use case scenario,

we demonstrate the efﬁciency of the integrated sys-

tem.

The rest of the paper is organised as follows: Sec-

tion 2 discusses the challenges and presents some

background information on the trust label system and

CTP. In Section 3, we detail the system integration

and describe the supporting components. Section 4

describes the implementation choices and the realisa-

tion of the system while Section 5 presents its evalu-

ation. In Section 6, we discuss related work and con-

clude the paper in Section 7.

2 BACKGROUND

This section discusses trust-related challenges in

cloud computing and how trust labels and the Cloud

Trust Protocol purport to address these challenges.

2.1 Challenges

There is a well-established literature base on the im-

portance of trust as a determining factor in the accep-

tance and use of online technologies (Gefen, 2003;

Pavlou and Gefen, 2004; Mcknight et al., 2011; Bente

et al., 2012). Similarly, in the cloud computing con-

text, lack of trust has been consistently identiﬁed as

a major barrier in the adoption of cloud computing

in both academic and professional literature (Hwang

and Li, 2010; Bradshaw et al., 2012; Leimbach et al.,

2014). Trust is commonly deﬁned as a “....psycho-

logical state comprising the intention to accept vul-

nerability based on positive expectations of the inten-

tions or behavior of another” (Rousseau and Sitkin,

1998). In the context of information technology, the

object of our trust is not necessarily a human person

but a technology artefact and/or the provider of that

artefact (McKnight and Chervany, 2001). Similarly,

stakeholder expectations in relation to trusting tech-

nology are different, focussing on functionality, re-

liability and helpfulness in an IT context (Mcknight

et al., 2011). The nature of cloud computing exacer-

bates issues of trust in many different ways, primar-

ily by increasing perceived risk. Cloud computing in-

volves an element of outsourcing of system and/or in-

frastructure to a third party on a shared distributed ba-

sis. As such, in adopting cloud computing, stakehold-

ers face relational, performance, and regulatory and

compliance risks. Relational risk is concerned with

risk associated with poor cooperation and opportunis-

tic behaviour while performance risk relates to op-

erational or performance factors that may undermine

the success of an outsourcing project (Das and Teng,

1996). Compliance and regulatory risk is concerned

with the end-consumer failure to adhere to regulatory

standards because of provider errors (Anderson et al.,

2014). These high-level risks surface in commonly

cited practical concerns relating to data jurisdiction

and location, security and data protection, and porta-

bility and technology transparency (Bradshaw et al.,

2012; Pearson and Benameur, 2010).

In cloud computing, trust issues are typically ad-

dressed through contracting (Pearson and Benameur,

2010). As cloud computing involves both persistent

trust (trust in the long term underlying properties or

infrastructure) and dynamic trust (trust speciﬁc to cer-

tain states, contexts, or short-term or variable infor-

mation), parties to cloud computing contracts seek to

minimise their risk by relying on both a general con-

tract and a service level agreement.

While contracting may reduce risk and distrust,

it does not necessarily build trust in the same way

that trust mechanisms based on experience between

parties or with a service might (Lewicki and Bunker,

1996; Deitz and DenHartog, 2006).Lynn et al. (Lynn

et al., 2013) propose a dynamic trust label to en-

able and maintain consumer trust in cloud services.

Similar to a food nutritional label, they argue such a

trust label for cloud computing would work by suc-

cinctly communicating up-to-date values for a num-

ber of high-level dependability measures generated

from the underlying cloud service. Using an online

adaptation of the Delphi conference method, Lynn et

Establishing Trust in Cloud Services via Integration of Cloud Trust Protocol with a Trust Label System

591

al. (Lynn et al., 2016) identiﬁed the information re-

quired for the label from a panel of 28 industry ex-

perts. Figure 1 presents a graphical view of the trust

label interface. It comprises 81 information compo-

nents, covering the cloud service provider (e.g. physi-

cal location, legal jurisdiction), the cloud service itself

(e.g. data location, security, backup, certiﬁcation),

and a historical service-level summary (e.g. uptime

data, support response times).

2.2 Trust Label System

Emeakaroha et al. (Emeakaroha et al., 2016) present

the underlying trust label system as shown in Figure

1. The historic service-level summary, in particular,

is based on a monitoring framework that is capable of

monitoring the different cloud layers and presenting

service-level data to the trust label in real time. Ma-

sevic et al. (Masevic et al., 2016) report that the pro-

posed trust label performed as hypothesised in valida-

tion experiments with a sample of 227 potential cloud

consumers.

2.3 Cloud Trust Protocol

As mentioned earlier, the Cloud Trust Protocol (CTP)

(Cloud Security Alliance, 2015a) is a protocol, de-

signed by the Cloud Security Alliance (CSA), to gen-

erate evidence-based conﬁdence that everything that

is claimed to be happening in the cloud is indeed hap-

pening as described. The CTP is a means by which

cloud service consumers ask for and receive informa-

tion about the elements of transparency, i.e. important

pieces of information concerning the compliance, se-

curity, privacy, integrity, and operational security his-

tory of service elements being executed in the cloud.

It aims to enable user conﬁdence in the security and

performance capabilities of cloud services both when

choosing a service or continually monitoring a service

to validate its agreed SLAs.

As such CTP provides evidence to build dynamic

trust in cloud services in the vei if Pearson and

Benameur (Pearson and Benameur, 2010) Figure 2

shows an overview of CTP deployed in a multi-cloud

service provider environment. CTP presents a stan-

dardised uniﬁed API that is designed to be a RESTful

protocol. The APIs are used by consumers to query

cloud service providers for information relating to a

particular service.CTP provides the information to be

queried using a standardised data model that can be

adapted to various scenarios that implement or intend

to use CTP.

New Company Ltd

Cloud Services

Sacramento, USA

California, USA

Performance

Policy

Preference

Can I

measure ?

Is there a

policy ?

Can I

modify ?

Data Security

YES

Certification

YES

Service Levels

YES

Variation of Terms

YES

Data Portability

Onboard

YES

Offboard

YES

Backup of Data

YES

Data Location

YES

Ownership

Data

N/A

YES

Meta Data

YES

Service

Customisation

YES

Application

Customisation

YES

Sharing of Data

Commercial

YES

Legal

YES

Insurance Levels

YES

Audit Approvals

YES

Customer Service Level

YES

Service Level Summary

Target

Current

3-Month

12-Month

Service Uptime

100%

Internal Network Uptime

100%

External Network Uptime

100%

Dynamic Load Balancing

100%

Cloud Storage Service

100%

Primary DNS Availability

100%

Server Reboot

<15m

6.7E-5m

0.000067m

Emergency Support

Response Time

<30m

General Support Response

Time

<120m

130m

Engineering Support

23 x 365

Physical Security

24 x 365

Figure 1: Trust Label Interface Overview.

3 SYSTEM ARCHITECTURE

INTEGRATION

This section describes the integration of the trust la-

bel system (Emeakaroha et al., 2016) with the Cloud

Trust Protocol.

The aim of this integration is to add compli-

ance and transparency to the communication of trust-

worthiness information in cloud service provisioning.

Such information is gathered by a monitoring frame-

work that is usually part of a provider’s management

layer. In our case, it is communicated through the

trust label interface to the cloud consumers. Figure 3

presents an overview of the system integration archi-

tecture.

This system integration demonstrates the feasibil-

ity of communicating information about cloud service

CLOSER 2017 - 7th International Conference on Cloud Computing and Services Science

592

Figure 2: CTP Deployment Overview.

operations in a standards compliant and transparent

manner. As shown in Figure 3, the Monitoring Frame-

work gathers the information for eventual transmis-

sion to the Trust Label system, which displays the

data on a customisable web interface for cloud con-

sumers. To realise a standard and transparent means

of communicating this information, we adopted the

CTP Server prototype provided by the Cloud Security

Alliance.

The CTP Server provides a standard data model

for describing cloud services and management data

such as monitoring information. This is key for pro-

viding compliance and it should be clearly understood

at design and implementation time to enable interop-

erability and compatibility.

In the integrated system as shown in Figure 3, the

monitoring framework is extended with a bridge li-

brary that provides access to the CTP server. The

bridge library enables communication between the

monitoring framework and the CTP Server as well as

between the CTP server and the trust label interface.

This is realised using REST APIs. The communica-

tion directions could be both ways. We use the dot-

ted arrows to indicate that the CTP server supports a

query-response pattern of communication.

Applica'on*

VM*

Cloud Provider Platform

DB*

Monitoring

Framework

Bridge*Library*

CTP*Server*

Prototype*

Bridge*

Library*

Communication

Mechanism

Trust*

Label*

Interface*

Consumer

Figure 3: System Integration Architecture.

The trust label interface is customisable and can

be setup independently for different consumers based

on their Service Level Agreements (SLA) with the

cloud provider.

4 IMPLEMENTATION DETAILS

This section describes the implementation of the in-

tegrated system. We focus on the bridge library and

provide a brief overview of the components with ref-

erences for further details.

4.1 Bridge Library

The CTP bridge is a Spring Boot application writ-

ten in Java. This component implements interfaces

to the CTP server, Monitoring framework and Trust

Label interface. It provides APIs for writing monitor-

ing data after formatting them using the standard data

model into the CTP server and also for reading from

the CTP server to update the Trust label interface. The

APIs for the different communications are as follows:

• CTP Admin REST API - for updating the CTP

server prototype with the monitoring data and

other information.

• CTP REST API - for getting information/data

from the CTP server prototype.

• Trust Label REST API - for updating the Trust La-

bel interface with the information gathered from

the CTP server.

The above three APIs are supported by their own

Java classes, each a Spring component, which inherit

common code from another class for the basics of

REST API invocation, including passing tokens in

headers for security. The common code includes stan-

dard Spring mechanisms to invoke REST APIs.

The CTP Bridge uses Spring Scheduling to invoke

the code to copy from the CTP Server to Trust Label

every 10 seconds. A simple annotation on the method

to invoke it ensures it is triggered automatically by the

Spring Framework. Gradle is used as the dependency

manager and build system for the project.

4.2 Other Components

Monitoring Framework: This component is im-

plemented using the Java Programming language.

It uses monitoring agents for gathering low-level

resource metrics. At the application level, it employs

HTTP pings among other methods to supervise

application execution status. For storing monitoring

data, it uses the MySQL database. Hibernate is

used to realise easy interaction between the Java

classes and the database. Further details about this

component can be found in (Emeakaroha et al., 2016).

CTP Server Prototype: This is implemented as a

Unix-style daemon written in the Go language. It

Establishing Trust in Cloud Services via Integration of Cloud Trust Protocol with a Trust Label System

593

uses the MongoDB NoSQL database as a backend to

store data. CTP has been tested on Linux and Mac

OS X environments. The current implementation

includes APIs for reading and writing to the server.

Further information can be read from (Cloud Security

Alliance, 2015b).

Trust Label Interface: This component is realised

using Ruby on Rails. It uses a backend database to

maintain the displayed content. Due to the generic na-

ture of Ruby, it is capable of using different database

engines such as SQLite, Postgre SQL, MySQL, etc. It

implements RESTful APIs and uses the JSON data in-

terchange format for structuring data. Additional in-

formation is available from (Emeakaroha et al., 2016).

5 EVALUATION

This section presents a demonstration of the inte-

grated system as a proof of concept. We show how

quality of service information is being communicated

based on a use case scenario and evaluate the perfor-

mance of the bridge library.

5.1 Use Case Scenario

We present a use case scenario of service provisioning

between a cloud provider and a consumer. The mon-

itoring of this service and the communication of the

service status facilitate trust establishment between

the provider and the consumer. The service is a trans-

actional video-serving web application that responds

to requests and makes queries to storage databases. It

runs on top of a load balancer that distributes the in-

coming request to compute resources to sustain heavy

load. The expected quality for the service is speciﬁed

in a Service Level Agreement (SLA) document that

is signed between the provider and the consumer to

guide the provisioning of the service. Table 1 presents

the SLA metric values for this particular service.

Table 1: Service SLA Document.

Metric Name QoS Target

Service Uptime 100%

Internal Network Uptime 100%

External Network Uptime 100%

Dynamic Load Balancing 100%

Cloud Storage Service 100%

Primary DNS Availability 100%

Server Reboot Time < 5mins

The cloud provider makes every effort to guaran-

tee the QoS targets speciﬁed in the SLA. Any vio-

lation of the SLA incurs a penalty for the provider.

In order to assure consumers of their service quality,

the provider needs to provide them with real time ev-

idence of their service operations.

5.2 Quality of Service Performance

As discussed in the use case scenario, providers

should furnish consumers with continuous evidence

of their service performance in order to gain their

trust. This section details how our proposed inte-

grated system facilitates the communication of such

information.

Cloud Solutions

Dummy CRMA

New York, NY10006

State of New York, USA

Performance

Policy

Preference

Can I measure

Is there a

policy ?

Can I modify

Data Security

YES

Certification

YES

Service Levels

YES

Variation of Terms

YES

Data Portability

Onboard

YES

Offboard

YES

Backup of Data

YES

Data Location

YES

Ownership

Data

N/A

YES

Meta Data

YES

Service

Customisation

YES

Application

Customisation

YES

Sharing of Data

Commercial

YES

Legal

YES

Insurance Levels

YES

Audit Approvals

YES

Customer Service Level

YES

Service Level Summary

Target

Current

3-Month

12-Month

Service Uptime

100%

99.99%

Internal Network Uptime

100%

99.999%

External Network Uptime

100%

Dynamic Load Balancing

100%

Cloud Storage Service

100%

92%

99.999%

Primary DNS Availability

100%

Server Reboot

<15m

0.00055m

0.000094m

0.00045mins

Emergency Support Response

Time

<30m

38m

31.17m

28.05m

General Support Response

Time

<120m

118.6m

109.13m

113.1m

Engineering Support

23 x 365

YES

N/A

Physical Security

24 x 365

N/A

Figure 4: QoS Performance Information.

Figure 4 depicts a screenshot of an extract of the

Trust Label interface showing in real time the com-

munication of the quality of service metrics. The in-

formation contains the current monitored values for

the SLA metrics speciﬁed in Table 1 and other infor-

mation. For simplicity, we modelled the display of

the SLA values on the Trust Label interface in terms

of 0% or 100% whereby 0% indicates a violation and

100% shows satisﬁed.

As shown in Figure 4, the Trust Label interface

conveys to the consumer the current performance sta-

tus and three and twelve month performance aver-

ages. These data give the consumer a clear overview

of the service operation and a basis to trust the cloud

provider. Our proposed integrated system facilitates

this trust establishment by enabling this end-to-end

communication of trustworthiness information.

5.3 Bridge Library Benchmarking

In this section, we present our benchmarking of the

bridge library communication performance. The aim

is to demonstrate the non-intrusiveness of this com-

ponent in the end-to-end integration.

Figures 5 and 6 present a plot of an extract from

the use case scenario execution. The application in the

CLOSER 2017 - 7th International Conference on Cloud Computing and Services Science

594

use case scenario was executed for about three hours

and we selected the middle hour execution period to

avoid startup and wind-down effects. Thus, the ﬁg-

ures show a full hour execution.

16:20:00 16:30:00 16:40:00 16:50:00 17:00:00 17:10:00 17:20:00

Time Values (ms)

Day Timestamp (hh-mm-ss)

Performance Metrics

Service Uptime

Internal Network Uptime

External Network Uptime

Dynamic Load Balacing

Cloud Storage Service

Primary DNS Availability

Server Reboot

Figure 5: Monitor-to-CTP Performance.

Figure 5 shows the time it takes to communicate

each of the monitored SLA metrics from the cloud

platform to the CTP server in parallel. As can be ob-

served from Figure 5, the bridge library takes an aver-

age of 12 milliseconds to communicate data from the

monitoring framework to the CTP server.

300

350

400

450

500

16:20:00 16:30:00 16:40:00 16:50:00 17:00:00 17:10:00 17:20:00

Time Values (ms)

Day Timestamp (hh-mm-ss)

CTP Server to Trust label

CTP to Trust label

Figure 6: CTP-to-Trust Label Performance.

Figure 6 presents the time for communicating the

whole information gathered from the CTP server to

the Trust Label interface. This data is bundled to-

gether and sent in one communication. It can be ob-

served that it takes an average of 380 milliseconds in

this case. This is also an impressive performance for

the bridge library.

Combining the results of these two benchmarks

indicates quick communication and therefore reﬂects

the efﬁciency of the bridge library. We could not ef-

fectively evaluate the overall end-to-end communica-

tion time since the CTP server is being used as a black

box. Besides, the communication between the CTP

and Trust Label components is a pull operation at pe-

riodic intervals. This is why we opted to focus on the

implemented bridge library.

5.4 Discussion/Recommendation

This end-to-end integration demonstration for com-

municating cloud data through CTP and Trust label

system provides a practical reference. This can be

very beneﬁcial to cloud and service providers includ-

ing brokers who are looking for a means of establish-

ing and maintaining evidence-based trust with their

consumers.

What we presented in this paper is simply a means

of adopting and integrating CTP. There are other pos-

sible ways of using these software components. In

fact, in a production environment, it is likely that the

cloud monitoring framework would be more closely

integrated with the CTP server; indeed they could

be so closely coupled that there would be no REST

API between them. Similarly the functionality of the

CTP Bridge and Trust Label could be merged. An

ideal architecture therefore would have Trust Label

use the CTP REST API to communicate directly with

the cloud provider. In this scenario, the CTP function-

ality and monitoring need not be separate services.

6 RELATED WORK

The Cloud Trust Protocol is at an early stage

of adoption and validation by both industry and

academia. Some recently completed EU funded re-

search projects have adopted this protocol to ad-

dress different challenges. The FP7 SPECS (Se-

cure Provisioning of cloud Services based on Ser-

vice Level Agreement (SLA) Management) project

(SPECS project, 2016) is adopting CTP to achieve

transparent communication between cloud providers

and cloud users. The goal of this project is to provide

comprehensible and enforceable security assurance

by cloud providers to their users. The project takes

an SLA-based approach for negotiating the cloud se-

curity parameters in the SLA and includes monitoring

of a limited number of metrics to enable their enforce-

ment. This project is similar to ours; however, we

consider a broader range of performance metrics that

can facilitate consumer trust in cloud services.

A4cloud (Cloud Accountability project, 2016) fo-

cuses on accountability for clouds. One of the ar-

eas this project investigates is means to enable cloud

providers to give their users transparent control over

how their data is being used or handled in clouds. The

Establishing Trust in Cloud Services via Integration of Cloud Trust Protocol with a Trust Label System

595

goal is to boost user conﬁdence and to ensure compli-

ance. The project is using CTP in addressing these

challenges. This project differs from ours because it

focuses on data location management. Our trust label

system includes data location management, alongside

other trustworthiness information, to enable evidence

based trust of cloud services.

The CUMULUS (Certiﬁcation Infrastructure for

Multi-Layer Cloud Services) project (CUMULUS

project, 2016) aims to provide an automated process

to certify security properties of cloud services at the

different layers of cloud stack. The goal is to over-

come the manual, costly and lengthy inspections and

auditing schemes for certiﬁcation purposes. Such

schemes do not support dynamic change in the struc-

ture, deployment or conﬁguration of resources under-

lying cloud provisioning. This project is applying

CTP towards their goal of achieving compliance in

certifying cloud services. The objective of this project

is to enable user trust through certiﬁcation. This ap-

proach is similar to ours, however, we aim to com-

municate trustworthiness information directly to con-

sumers to enable evidence-based trust instead of es-

tablishing certiﬁcation seals.

The Security Content Automation Protocol

(SCAP) (NIST, 2016) is also considered a cloud

trust interoperability protocol (Ron Knode, 2010).

SCAP (pronounced ess-cap) consists of a suite

of speciﬁcations for standardising the format and

nomenclature by which software ﬂaws and security

conﬁguration information are communicated, both

to machines and humans. The CTP developers have

however incorporated several parts of the SCAP

speciﬁcation into the development of CTP and so

the two protocols can be seen as complementary

rather than as competitors. In relation to our trust

label system that provides broad metrics to facilitate

consumer trust in cloud services, these two protocols

are considered as extension possibilities as we have

demonstrated in this paper.

To the best of our knowledge, none of the exist-

ing literature has reported on practical integration of

CTP to facilitate consumer trust in cloud services and

thereby increase the adoption of cloud computing.

7 CONCLUSION

In this paper, we presented a practical integration of

Cloud Trust Protocol (CTP) with a trust label sys-

tem designed to facilitate both persistent and dynamic

trust building in both cloud services and cloud ser-

vice providers. The trust label system includes a novel

monitoring framework to supervise service provision-

ing and to gather performance metrics data.

We described the trust label system and CTP de-

ployments while highlighting the challenges to be ad-

dressed. Our focus was mainly on the integration ar-

chitecture that details the components and the realisa-

tion of the end-to-end communication of trustworthi-

ness information between cloud service providers and

consumers. The design and implementation of this ar-

chitecture including a Bridge library were presented.

For the evaluation, a practical use case scenario

was introduced. The use case describes an end-to-end

consumer service provisioning. It uses a sample SLA

document to explain how the quality of service ele-

ments of the consumer service were monitored and

communicated through the integrated system. We

demonstrated the correct working of the system and

presented some efﬁciency results.

In the future, we aim to carry out real validation of

the system by end-users to gather empirical evidence

about the effect of the system on their trust of cloud

services. This will inform on the novelty of our ap-

proach. We intend to publish the system code under

open source licence to open up its usage by others and

thereby buttress our vision of increasing cloud service

adoption.

ACKNOWLEDGEMENTS

The research work described in this paper was sup-

ported by the Irish Centre for Cloud Computing

and Commerce, an Irish national Technology Centre

funded by Enterprise Ireland and the Irish Industrial

Development Authority.

REFERENCES

Anderson, S. W., Christ, M. H., Dekker, H. C., and Seda-

tole, K. L. (2014). The use of management controls

to mitigate risk in strategic alliances: Field and sur-

vey evidence. Journal of Management Accounting Re-

search, 26(1):1–32.

Bente, G., Baptist, O., and Leuschner, H. (2012). To buy or

not to buy: Inﬂuence of seller photos and reputation

on buyer trust and purchase behavior. Int. J. Hum.-

Comput. Stud., 70(1):1–13.

Bradshaw, D., Folco, G., Cattaneo, G., and Kolding, M.

(2012). Quantitative estimates of the demand for

cloud computing in europe and the likely barriers to

up-take. In IDC Analize de Future.

Buyya, R., Yeo, C. S., Venugopal, S., Broberg, J., and

Brandic, I. (2009). Cloud computing and emerging

it platforms: Vision, hype, and reality for delivering

computing as the 5th utility. Future Generation Com-

puting Systems, 25(6):599–616.

CLOSER 2017 - 7th International Conference on Cloud Computing and Services Science

596

Cloud Accountability project (2016). A4Cloud.

http://www.a4cloud.eu/objectives Accessed

on 22/08/2016.

Cloud Security Alliance (2015a). Cloud trust protocol.

https://cloudsecurityalliance.org/group/

cloudtrust-protocol/ Accessed on 22/08/2016.

Cloud Security Alliance (2015b). Cloud trust proto-

col daemon prototype. https://github.com/

cloudsecurityalliance/ctpd Accessed on

07/09/2016.

CUMULUS project (2016). Certiﬁcation infrastruc-

ture for multi-layer cloud services. http://www.

cumulus-project.eu/ Accessed on 22/08/2016.

Das, T. and Teng, B. S. (1996). Risk types and inter-ﬁrm

alliance structures. Journal of management studies,

33(6):827–843.

Deitz, G. and DenHartog, D. (2006). Measuring trust inside

organizations. JPersonnel Review, 35(5):557–588.

Emeakaroha, V., Fatema, K., Vanderwerff, L., Healy, P.,

Lynn, T., and Morrison, J. (2016). A trust label sys-

tem for communicating trust in cloud services. IEEE

Transactions on Services Computing, PP(99):1–1.

Gefen, D. (2003). TAM or just plain habit: A look at expe-

rienced online shoppers. Journal of End User Com-

puting, 15(3):1–13.

Gens, F. (2014). Worldwide and regional public cloud it ser-

vices 2014-2018 forecast. https://www.idc.com/

research/viewtoc.jsp?containerId=251730

Accessed on 20/10/2016. IDC Market Analysis.

Hogan, M., Liu, F., Sokol, A., and Tong, J. (2011). Nist

cloud computing standards roadmap. NIST Special

Publication, 35.

Hwang, K. and Li, D. (2010). Trusted cloud computing

with secure resources and data coloring. IEEE Inter-

net Computing, 14(5):14 –22.

Kim, W. (2009). Cloud computing: Today and tomorrow.

Journal of object technology, 8:65 – 72.

Leimbach, T., Hallinan, D., Bachlechner, D., Weber, A.,

Jaglo, M., Hennen, L., Nielsen, R., Nentwich, M.,

Strau, S., Lynn, T., and Hunt, G. (2014). Potential

and impacts of cloud computing services and social

network websites. Science and Technology Op-

tions Assessment (STOA) http://www.europarl.

europa.eu/RegData/etudes/etudes/join/2014/

513546/IPOL-JOIN_ET(2014)513546_EN.pdf

Accessed on 15/08/2016.

Lewicki, R. and Bunker, B. (1996). Developing and main-

taining trust in work relationships. Technical report,

Trust in organizations: Frontiers of theory and re-

search. edited by Roderick M. Kramer, Tom R. Tyler.

Low, C., Chen, Y., and Wu, M. (2011). Understanding the

determinants of cloud computing adoption. Industrial

management and data systems, 111:1006 – 1023.

Lynn, T., Healy, P., McClatchey, R., Morrison, J., Pahl, C.,

and Lee, B. (2013). The case for cloud service trust-

marks and assurance-as-a-service. In Intl. Conference

on Cloud Computing and Services Science Closer,

pages 8–10.

Lynn, T., van der Werff, L., Hunt, G., and Healy, P. (2016).

Development of a cloud trust label: A delphi ap-

proach. Journal of Computer Information System,

56(3):185–193.

Masevic, I., van der Werff, L., Emeakaroha, V., Morrison,

J., and Lynn, T. (2016). Validating a cloud trust label:

Inﬂuencing consumer trust. In Cloud British Academy

of Management Conference.

Mcknight, D. H., Carter, M., Thatcher, J. B., and Clay, P. F.

(2011). Trust in a speciﬁc technology: An investi-

gation of its components and measures. ACM Trans.

Manage. Inf. Syst., 2(2):12:1–12:25.

McKnight, D. H. and Chervany, N. L. (2001). What trust

means in e-commerce customer relationships: An in-

terdisciplinary conceptual typology. Int. J. Electron.

Commerce, 6(2):35–59.

NIST (2016). Security content automation proto-

col. https://scap.nist.gov/revision/1.2/

index.html Accessed on 22/08/2016.

Pavlou, P. A. and Gefen, D. (2004). Building effective on-

line marketplaces with institution-based trust. Info.

Sys. Research, 15(1):37–59.

Pearson, S. (2013). Privacy, security and trust in cloud com-

puting. In Computer Communications and Networks,

pages 3 – 42.

Pearson, S. and Benameur, A. (2010). Privacy, security

and trust issues arising from cloud computing. In

Cloud Computing Technology and Science (Cloud-

Com), 2010 IEEE Second International Conference

on, pages 693–702.

Ron Knode (2010). Cloud trust 2.0. https:

//scap.nist.gov/events/2010/itsac/

presentations/day2/Security_Automation_

for_Cloud_Computing-CloudTrust_2.0.pdf

Accessed on 22/08/2016.

Rousseau, D. M. and Sitkin, S. B. (1998). Not so different

after all: A cross-discipline view of trust. Academy of

Management Review, 23(3):393–404.

SPECS project (2016). Secure provisioning of cloud

service based on SLA management. http://

www.specs-project.eu/project/description/

Accessed on 22/08/2016.

Subashini, S. and Kavitha, V. (2011). A survey on security

issues in service delivery models of cloud computing.

Journal of network and computer applications, 34:1 –

11.

Zissis, D. and Lekkas, D. (2012). Addressing cloud com-

puting security issues. Future Generation computer

systems, 28(3):583 – 592.

Establishing Trust in Cloud Services via Integration of Cloud Trust Protocol with a Trust Label System

597
