A Vertical Search Engine for Domain of Online Shopping

Vigan Abdurrahmani, Lule Ahmedi and Korab Rrmoku

Faculty of Electrical and Computer Engineering, University of Prishtina, Kodra e Diellit, Pristina, Kosovo

Keywords: Search Engine, Web Crawler, Indexing, Search Ranking.

Abstract: Along with general search engines which search the entire web, vertical search engines that are rather

focused on specific domains of search have also gained in popularity in web search. In our case we are

focused on domain of online shopping. We treat main processes of search engines which include crawling,

indexing and query processing. Each process is developed based on general search engines and adapted to

tackle the problems of the specified domain. Specifically, a search result ranking algorithm called

Warehouse, which may be adapted to rank results of any specific domain, is introduced.

1 INTRODUCTION

Search engines have appliance in many different

fields including searching medical literature,

enterprise servers, and usually general search in web

(Croft et al., 2010). Depending on their search

domain these engines must address different issues,

for example desktop search engines must index new

documents, emails, web pages. On the other side

web search engines like Google must crawl large

scale of information and must have very short query

response time. Issues that must be addressed by our

system does not differ too much from general web

search engines, because basically it's a web search

engine. The only difference is that we focus on field

of online shopping and not on the entire web. Main

issues that must be treated in our system include

efficient search, response time, freshness and

extensibility.

In our paper we discuss three main components

of search engines: Input agents, database engine and

query servers (Connolly and Hoar, 2014). Input

agents handle process of information collection,

parsing and text processing of data before indexing

process. On our system we focus on finding and

extracting product articles on commercial websites.

We have developed a scrapper for specific websites

which retrieves minimal information required to

identify a product, not the entire document/page

(more on Section 4).

The database engine’s main purpose is to store

the information in a manner that can it be found

easily during query processing, usually through

inverted indexes. Data and index structure strongly

depends on the ranking algorithm. In our case we

have chosen a relational database system as data

storage which offers more flexibility to convert user

input into structured queries

The most important component of the system is

query processing which determines the quality of the

search. It consists of the ranking algorithm which

determines the relevant information for user's

request. In E-Shop system we have developed an

algorithm called warehouse who treats articles as

nodes with properties and applies some filters

(feature functions) to determine the document score.

2 RELATED WORK

Web Search engines have existed since 90’s. Early

systems only searched for string matches inside

large archives of documents (called web directories),

but their efficiency was low. However during the

time there have been developed many algorithms for

intelligent and efficient ranking during the search

(example Google’s PageRank algorithm (Brin and

Page, 1998)).

Today’s search engines aren’t focused only on

entire web, but also on many specific domains

(called as vertical search engines). Most known

existing search engines for our domain include

376

Abdurrahmani, V., Ahmedi, L. and Rrmoku, K.

E-Shop - A Vertical Search Engine for Domain of Online Shopping.

DOI: 10.5220/0006366303760381

In Proceedings of the 13th International Conference on Web Information Systems and Technologies (WEBIST 2017), pages 376-381

ISBN: 978-989-758-246-2

Google Shopping (Vise, et al., 2006), Yahoo

Shopping

and local engines implemented in e-

commerce sites (Zhou et al., 2013). However our

approach is not based on any existing system for

domain of appliance. Instead we have combined

well known principles of general search engines and

basic principles of Google Shopping.

3 SYSTEM ARCHITECTURE

E-Shop's architecture consists of three internal

components and four external systems which are

used as source for information retrieval. These

external systems are web systems for online

shopping and are labeled as web stores (Amazon,

Ebay, Walmart and Ali Express).

The internal components consist of:

 Web Server,

 Database Server, and

 Windows Service.

Database component (Article Storage Server) serves

as storage for retrieved information, and shortens the

time needed for query processing because there is no

need to re-retrieve and re-structure the information.

The Web Server is the central component of the

system which is involved nearly at all processes, and

serves as a communication bridge between other

components. The main purpose of Windows Service

(Crawling Monitor Service) (Microsoft, n.d.) is to

monitor the crawling and the indexing processes,

where in this case the service is used as master who

invokes tasks to other components. The reason why

we have used a windows service is because web

server is a passive entity and cannot invoke

commands to himself.

Below is listed the physical model of the system

and the interactions between its components (Figure

1).

https://shopping.yahoo.com

WalmartWebStores EbayWebStores

AmazonWebStores

AliExpressWebStores

E‐Shop

WebServer

ArticleStorage

Server

Crawling

Monitor

Service

Send/Retrieve

Data

Sends

Crawling

Operations

CrawlData

Searchesfor

products

Users

Figure 1: System architecture.

4 INPUT AGENTS

The indexing process is initialized by the windows

service (master) based on a schedule when we

suppose that the traffic at the system is lowest. First,

the master requests the list of indexes and phrases to

be crawled from the REST API of web server

(slave). These indexes/phrases consist of two lists

where the first one contains the phrases that doesn’t

relate to articles on the system's storage, and the

second one includes the indexes (keywords) that are

outdated. For the first list, for each phrase we send

crawling request to the slave and also break the

phrase into indexes which will be appended to the

second list (outdated indexes). We need to mention

that each term is considered outdated 1 month after

last crawling to keep retrieving fresh information.

The crawling process starts when the master

sends an index or phrase crawling command to the

slave. Upon receiving the request, the slave starts 4

child threads (Figure 2) where each worker handles

information collection for specific web store.

Start

crawling

proces

Retrieve

termlistfor

crawling

Startthreads

forcrawling

AmazonWorker

EbayWorker

AliExpressWorker

WalmartWorker

Join

threads

Return

collection

Figure 2: Crawling process activity diagram.

E-Shop - A Vertical Search Engine for Domain of Online Shopping

377

The worker (thread) uses a crawling component

(called as Web Spider) to collect relevant data. Each

web store has specific web spider which adapts to

the structure of the web page. The spider component

only crawls the first page and then uses a scrapper

component (DOMNode) to extract the products. The

scrapper treats the pages as XML documents and

performs XPath queries and regular expressions to

extract the information. In the end the scrapper

performs a final check to discard the products which

contains incomplete information.

After collecting and transforming the

information each worker’s collection is merged into

single collection and prepared for indexing process.

Below in Figure 3 we have listed a diagram showing

the interaction between the crawling components.

WebStore

Worker

WebStore

WebSpider

WebStore

DOMNode

Usesas

scraper

forfetching

article

fields

Usesas

crawler

function

Figure 3: Interaction between components of crawling

process.

The weakness of the current implementation of

crawling process is that if we want to extend the

crawling to other web stores, we need to develop a

new scrapper/spider component that adapts the

structure of the web store. Also if any of existing

web stores change their structure no information will

be collected and therefore we need to rewrite the

scrapper/spider component of specified web store.

The priority of current design is that it uses a

single thread for each store and single request for

each store. The only overhead is the time required to

initialize the threads and merging the results which

is still more efficient than single thread operation.

Also we need to mention that we crawl information

from other information retrieval systems, so without

any knowledge how their algorithms works we

benefit from them. There are also some side effects

from the external systems because they have their

policies how to rank the search results, and

sometimes the higher ranked products are not much

relevant. This is especially expressed in case of Ali

Express store. To tackle this problem we have added

an attribute which gives a relevance coefficient to

each web store.

5 INDEXING PROCESS

Upon receiving the data collection from crawling

process the slave first stores the articles to storage.

Then the slave maps the relation between articles

and keywords. This way we create the inverted

index where the keyword points to articles.

The model of database storage that we have

chosen is relational database model (Figure 4). The

reason that we have chosen this model is that

because it creates indexes for fast access by using

key constraints. We have decided to implement

numeric identifiers for both articles and index terms

(keywords) because the search for numeric values is

way faster than text search.

Article

Title

Price

Link

Reliability

Store

Amazon

Category

Ebay

Country

Time

Stamp


Keyword

Constant

ArticleIndexes

OutdatedIndexes

Temp

Keyword

TempPhraseList

Temp

Phrase

Figure 4: Entity Relationship model.

Each index also has a specific constant which is

stored along the term on the database. This constant

is calculated by the formula:

  1





(1)

In the above formula F represents the number of

articles who contain the keyword (index), and C

represents the total number of articles.

This constant (KC) defines the inverted term

frequency for the specified term (Croft et al., 2010).

These constants are updated every day during the

low traffic time in system by the event schedulers

provided by database. The constants of inverted

indexes have big importance on Warehouse

Algorithm which will be discussed on Section 7.

In our indexing process we haven't included

stemming and stopping processes (Croft et al., 2010)

which will reduce the efficiency of query process.

The stopping process should not be included because

we deal with many product brands and if we stop

terms like “and” we may reduce relevance of

retrieved information (e.g. “AND 1” brand).

However, the inverted term frequency helps by

reducing the weight of stop words. The stemming

process will be treated on future works.

WEBIST 2017 - 13th International Conference on Web Information Systems and Technologies

378

6 QUERY PROCESSING

Query processing is realized through simple steps by

retrieving the products that match the user keywords

and then by processing the Warehouse algorithm to

rank the results. In our system we do not provide

query expansion features or user tracking. We only

transform the user query to SQL query to limit the

relevant article list.

The first step of query processing involves

transforming query input into indexes (keywords).

After transformation we check into storage which

indexes exist and add the indexes that doesn’t exist

to the list of outdated indexes for later crawling.

Also if at least one keyword (index) doesn’t exist we

add the phrase to the list for later crawling. After this

step we check the percentage of indexes that exist in

storage. If percentage of found indexes is greater

than 60% we consider that we have relevant data for

user’s query and perform the warehouse algorithm.

If the percentage is lower than 60% we consider that

our system doesn’t have relevant data for user’s

query and we rely on external systems (web store)

by performing direct crawling. In this case we do not

store any data to the storage, we just show the

retrieved ranked results from web stores (Figure 5).

The only ranking that we perform to these results

include relevance coefficient of web stores.

Requestreceived

Converttermto

keywords

Findkeywordsin

databaseandaddnew

keywordstokeyword

searchlist

count(termkeywords)

!=foundkeywords

Addtermtotemporary

termlist

Checkpercentageof

foundkeywords

percentage>60%

Performcrawl

fromwebstores

Perform

WarehouseRanking

Algorithm

Splitcontentinto

pages(perform

pagination)

Returnrequestedpage

Figure 5: Workflow of query processing.

7 WAREHOUSE ALGORITHM

Warehouse ranking algorithm is a document at time

scoring algorithm. The idea of this algorithm is to

treat related data structures as node with properties,

and then by applying featured functions (in our case

called as filters) to the properties we compute the

final document score where the score is ≤ 1. In

warehouse algorithm we can extend featured

functions to adapt the needs of domain of appliance.

The only required featured function is “At least one

rule”.

7.1 Featured Functions

In Warehouse we have to kinds of filters that we

apply to the nodes:

 Global filters,

 Local filters

The local filters are featured functions that apply to

particular property of the node, example: word

matching to the title of a book. The global filters are

featured functions that apply to whole or a set of

properties of the node, example: priority of sections

of a web page. After performing all featured

functions we calculate the final result as algebraic

sum of product between local filters and global

filters:

























⋯





















(2)

In the above formula G

represents global filters, F

represents local filters and WR(n) the final document

score for document n.

In next sections we will treat the featured

functions applied at E-Shop system.

7.1.1 At Least One Rule

This rule belongs to local featured functions. Its

purpose is to eliminate every node that don’t have at

least one of the search terms, this way it shortens the

number of nodes to be ranked. In our case it applies

to products where we eliminate the products that

don’t match any of the terms in user’s query. This

filter must be included at every application of

warehouse algorithm no matter of the domain of

appliance.

E-Shop - A Vertical Search Engine for Domain of Online Shopping

379

7.1.2 Word Closeness Rule

This rule also belongs to local featured functions,

and its purpose is to search for word matches in a

given text. The first step of this rule is to check if

entire phrase is found in node’s property. If there’s

no match the phrase is split into smaller phrases

where the new phrases have length of n – 1 (n – total

number of words in phrase). The splitting is done in

way that we start at the beginning of the phrase and

we continue to remove the first word and add new

word at the end. If no match is found again we

continue the splitting into n – 2, so this process is

continued until the phrase length is one word. If the

phrase length is one word the returned result will be

0. In case we find a match we apply the following

formula to compute the result of the rule:

   











(3)

In the formula above F is the number of matches

found in search in i depth, N is number of words in

search term, C is number of words in property/text, i

is number of phrase subgroups of search term.

ALGORITHM WCR(text, term)

C ← WordCount(text);

N ← WordCount(term);

F ← 0; i ← 0; k ← N; WCR ← 0;

wordGroups ← term;

while k > 1

F ← CheckForMatches(property,

wordGroups);

if F > 0

WCR ← F x (N – i) / (N x C);

break

else

k--; i++;

wordGroups ← SubgroupTerm

(term, k)

To clarify more the rule below we have depicted

a diagram in Figure 6 describing how the rule splits

the groups until a match is found.

PHPandMySQLWebDevelopment

phpandwebdevelopment

Nodepropertyvalue:

Termvalue:

phpandweb andwebdevelopment

webdevelopmentandwebphpand

i=0

i=1

i=2

Figure 6: Appliance of Word Closeness Rule.

In the example above the result of WCR rule will

be as follow:

   





2

42

45

0.20

(4)

In our system this rule is applied on title of the

product. Disadvantage of this rule is that it only

should apply at short texts. In large texts the search

time will be very long.

7.1.3 Property Priority Rule

The purpose of this featured function is to define the

weight of particular properties in manner that the

sum of all weights must be 1, and belongs to global

filters. In our case we divide the weight between

only three properties: title (0.3), keywords (0.5) and

reliability (0.2). The distribution of weights is not

based on any analysis.

The final score of article with Warehouse

ranking algorithm in our case will apply the

following formula:

















0.30









0.50

0.20

(5)

To clarify how the warehouse algorithm is

implemented in our system below is depicted a

diagram that describes its appliance on a simple

node (article in our case). In Figure 7 we show the

applied local feature functions (filters on top of

properties) and the applied global feature functions

(filter on the left side). Also there are some extended

featured functions that can be used using advanced

search based on filters chosen by user interface.

Node

Article

WCR

Property

PriorityRule

Title

Price


Link

Keywords

Reliability

Amazon
