Identifying Innovative Documents: Quo vadis?

Ivonne Schröter

1,2

, Jacob Krüger

1,3

, Philipp Ludwig

, Marcus Thiel

Andreas Nürnberger

and Thomas Leich

2,3

Otto-von-Guericke-University, Universitätsplatz 2, 39106, Magdeburg, Germany

METOP GmbH, Sandtorstraße 23, 39106, Magdeburg, Germany

Harz University of Applied Sciences, Friedrichstraße 57-59, 38855, Wernigerode, Germany

Keywords:

Enterprise Information System, Empirical Study, Survey, User Questionnaire, Requirements Engineering.

Abstract:

The number of new research documents and patents published each year is steadily increasing. Despite this

development, identifying innovative documents in a timely manner has received only little attention in re-

search. Nevertheless, this use case is important for companies that strive to keep up with current innovations

in their ﬁeld. However, since existing solutions do not take context and background of the particular ﬁrm or

researcher into account, they fall short in supporting the user in his search for suitable documents. In this

paper, we describe an industrial case study we conducted within sheet-metal working companies and related

research institutes in Germany. We i) report a qualitative study on innovation research, ii) provide a list of

features that industrial researchers demanded, and iii) discuss implementation challenges for systems that sup-

port interactive retrieval of innovative documents. Based on the initial results, we argue that existing systems

fall short to provide an integrated workﬂow. Overall, we discuss how to implement such a system and the

corresponding problems.

1 INTRODUCTION

Monitoring patents and academic publications is an

essential task for scientists and companies alike to

not miss opportunities for innovation, research, or

workﬂow improvement. However, this usage scenario

differs greatly from conventional research processes:

Evaluating how innovative a document is requires ad-

ditional effort and thorough reviews. Hence, assess-

ing innovative documents provides new challenges to

search engines, user guidance, and the presentation of

results (Kuhlthau, 1991; Marchionini, 2006).

A lot of digital libraries are available (Meyyap-

pan et al., 2000; Aghaei Chadegani et al., 2013) and

several approaches to browse and explore such col-

lections have been presented in the past (Lehmann

et al., 2010; Lashkari et al., 2009). Still, only lit-

tle attention has been brought to the task of help-

ing users in identifying innovative documents (Xie,

2006). While topic-oriented search engines such

as dblp

(in the domain of computer science) are

available, these systems are hardly sufﬁcient to con-

sider individual demands (Frias-Martinez et al., 2006;

http://dblp.uni-trier.de/, 06.09.2016

Jayawardana et al., 2001). For example, experts in-

terested in new development in their ﬁeld are most

likely not interested in ﬁnding patents published by

the company they work for or which they published

themselves. However, these documents might be con-

sidered new by other people.

Furthermore, experts have to sight a great variety

of resources, for instance, papers, patents, or norms.

This is especially a problem in smaller ﬁrms, where

sufﬁcient resources for technological monitoring may

not be available. To this point, these users could ben-

eﬁt from systems that support them in retrieving doc-

uments and patents relevant to their current problems.

Hence, we argue that innovation researchers re-

quire an tool that integrates all steps of search pro-

cesses and considers their context. In order to discuss

this claim, we conducted a case study during which

we interviewed experts in the ﬁeld of a particular in-

dustrial domain, sheet-metal working. We further an-

alyzed our ﬁndings, derived opportunities to support

the search process, and possible problems with two

experts. Overall, we provide a detailed discussion on

important features for innovation research. In partic-

ular, we describe the following:

• A case study we conducted in the sheet-metal

Schröter, I., Krüger, J., Ludwig, P., Thiel, M., Nürnberger, A. and Leich, T.

Identifying Innovative Documents: Quo vadis?.

DOI: 10.5220/0006368706530658

In Proceedings of the 19th International Conference on Enterprise Information Systems (ICEIS 2017) - Volume 1, pages 653-658

ISBN: 978-989-758-247-9

653

working domain to identify characteristics of the

corresponding search process for innovative doc-

uments. With this, we analyze search and evalua-

tion behavior of users and direct further research.

• A discussion on potential features and challenges

to implement systems to support search processes.

We argue for our position that such systems are

required for users and researchers but also result

in new problems.

In this paper, we ﬁrst introduce design and results

of our empirical study in Section 2. We discuss the

results and their implications in Section 3. Finally,

we summarize our contributions in Section 4.

2 STUDY DESIGN

The goal of our study was to identify experts’ work-

ﬂows while they investigate innovations. Therefore,

we designed a four-step study with close cooperation

to industry and experts. We illustrate our workﬂow

in Figure 1.

Different

Companies/

Research Institutes

Two Experts

1. Brainstorming

Workshop

3. User

Questionaire

(19 Participants)

4. Result

Discussion

Two Companies

2. Workshops

Figure 1: Steps of our conducted study.

Firstly, we conducted a brainstorming workshop

with two experts in the ﬁeld of sheet-metal research.

We discussed workﬂows and tasks in their search and

analysis processes. As a result, we have identiﬁed

possible participants and questions for our next steps.

Secondly, we performed workshops in two sheet-

metal working companies. During this on-site study,

we asked industrial researchers to specify their work

processes. In addition, we monitored their search and

analysis behavior to identify steps and tools in their

workﬂow. This allowed us to obtain a ﬁrst overview

about the research focus and potential points of sup-

port with tools.

Thirdly, based on the results, we developed a user

questionnaire and sent it to several sheet-metal work-

ing companies and research institutions. 19 employ-

ees in different positions rated ideas that we gathered

in the previous steps. One main result is a practice-

driven rating of important features in applications in

order to support the research for innovation.

Finally, we discussed our observations with the

experts that aided us during our initial workshop.

With them, we summarized our results and closed re-

maining gaps. Moreover, we identiﬁed and discussed

the industrial context in research for innovation and

corresponding tools. In the following sections, we

provide detailed information on applying our study in

the proposed context (i.e., Steps 2 and 3 in Figure 1).

2.1 Workshops

For our on-site case study (Step 2 in Figure 1), we per-

formed workshops in two companies. During these,

we used guided interviews to receive information

from domain experts. For this, we prepared a cata-

log of questions to ensure similar treatment. These

questions were acquired through the previous brain-

storming workshop (Step 1 in Figure 1). We used

a ﬁxed process to slowly introduce the interviewees

from general aspects of their research behavior to our

actual goal. To do this, we performed the following

steps:

1. Explaining the procedure of our study.

2. Investigating the reasons for research.

3. Identifying the research process.

4. Detecting tasks that can be supported with tools.

5. Reviewing these points of support with the inter-

viewees.

To address all steps, we developed questions with

different aims and scopes. For instance, we wanted to

identify the expertise of our workshop groups while

investigating their reasons for research. These ques-

tions were on a more general level, for example, we

asked: “How often do you research?”, “To what pur-

pose do you research?”, and “How much expertise do

you have in technological research?” to slowly intro-

duce the participants into our study. Other questions,

for instance, “Is there an operational workﬂow for the

search/analysis of innovative documents?” or “Which

resources do you access in your research process?”,

helped us to identify workﬂows and opportunities for

tool support.

We combined the results at the end to summarize

views on the same questions. The agreement on per-

ceived problems and challenges was quite high, re-

sulting in a uniﬁed view. This means, that most par-

ticipants reported similar on their search behavior and

its challenges. Hence, we identiﬁed ﬁve main issues:

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

654

• Research is mainly done with classical search en-

gines for the web (e.g., Google), patents (e.g., DE-

PATISnet

(Jürgens and Herrero-Solana, 2015))

or other resources (e.g., research institutes).

• Direct search for innovations is usually not possi-

ble, for instance, due to only partial availability of

solutions. Hence, an extensive search with seem-

ingly ﬁtting keywords is done. Also, incremental

speciﬁcation of the research is conducted in an ex-

haustive manner.

• Exchanges on the research rarely or never happen,

especially not across several departments. This

proves prior results in the professional search do-

main (Knight and Spink, 2008; Nürnberger et al.,

2015).

• Pre-ﬁltering is usually done by source, institution,

or abstract. This may leave out potentially inter-

esting and relevant documents.

• Patents must be carefully read and evaluated,

while pre-selection is done via ﬁtting, but also

broad, keywords (Lupu et al., 2013).

In order to address these issues, workshop partic-

ipants proposed solutions. Additionally, we deduced

possibilities from the described search processes. To

reduce the effort and time necessary for our further

study, we limited the number of potential solutions to

the ten ideas that the majority of participants empha-

sized. We illustrate these ideas in Table 1.

Table 1: Proposed ideas for supporting research.

P-1 Marking and extracting parts of a document.

P-2 Creating a research history.

P-3 Comparing different search result lists.

P-4 Development of a topic over time (trend analysis).

P-5 Listing important institutions and authors for a topic.

P-6 Filtering documents by domain, country of origin, etc.

P-7 Comparing different versions of the same document.

P-8 Sorting of documents by their topics.

P-9 Referencing documents to other publications.

P-10 Summarizing parts of a document.

Some of these proposals are already implemented

in similar applications. For instance, marking doc-

ument parts (P-1) is possible in most digital readers

and comparing different document versions (P-7) is

part of version control systems to some extend. Also,

many features for ﬁltering, sorting, or similar tasks

are partly supported in reference management sys-

tems (Gilmour and Cobus-Kuo, 2011). However, we

are not aware of an application which combines all

ideas in an integrated system and supports search pro-

cesses as a whole.

https://depatisnet.dpma.de, 06.09.2016

To this point, we argue that the most important

ideas have to be identiﬁed and deﬁned as require-

ments. Further assessing context information and in-

vestigating potential challenges is necessary. In order

to initiate corresponding research, we conducted user

questionnaires to evaluate the ideas.

2.2 User Questionnaire

During the third step (i.e., Figure 1), we determined

the importance of previously proposed ideas. To this

point, we conducted a user questionnaire with 19 ex-

perts from different sheet-metal working companies

or related research institutes. We asked them to rank

the ideas mentioned in Table 1 from 1 (very impor-

tant) to 10 (not that important). Each priority number

could only be selected once. In addition, the propos-

als could be rated in high, middle and low relevance

(as a complementary ranking) to track whether the

participants understood the system. Furthermore, we

recorded additional ideas, if a participant proposed an

important feature the workshops did not cover.

We did not evaluate ﬁve questionnaires, since they

were not completely or wrongly ﬁlled out. For exam-

ple, participants described an idea as important but

to have low relevance (the complementary ranking),

which is contradictory, or used the same rank multi-

ple times. We display the results of the remaining 14

responses in Table 2. While we are aware that this

can only be considered an initial sample, we could

still identify the most important ideas from Table 1

that were consistent over almost all questionnaires to

reason our position. For example, summarizing (P-

10) and referencing documents (P-9), as well as list-

ing important authors (P-5) were regularly demanded.

In contrast, the participants considered pre-ﬁltering of

documents (P-6) as least relevant.

Several additional ideas were named, for example

to create a report from result lists, adding information

about addresses of institutions and contact persons, or

to display the relevance of a document to certain top-

ics. During our evaluation, we mapped these ideas

with those we already had. Then, we merged all re-

sults and discussed them with the two experts that ini-

tially helped us. We identiﬁed opportunities but also

challenges to support the process of retrieving inno-

vative documents.

3 DISCUSSION

During our study, we found several tasks for innova-

tion research we can support with tools. However,

Identifying Innovative Documents: Quo vadis?

655

Table 2: Results of the user questionnaire. Smaller priority numbers indicate a more important proposal. Thus, a low average

(x) shows the ideas most interesting to the participants.

Proposal

Priority

1 2 3 4 5 6 7 8 9 10 x

P-1: Mark/extract document parts 1 1 2 1 1 0 1 3 0 4 6.36

P-2: Research history 0 0 0 0 2 3 4 2 0 3 7.29

P-3: Compare result lists 0 0 1 0 4 4 1 2 1 1 6.36

P-4: Temporal evolution 0 3 2 3 1 2 0 1 2 0 4.79

P-5: List institutions and authors 3 1 4 1 0 0 2 0 3 0 4.43

P-6: Pre-ﬁlter by domain, etc. 0 0 1 1 0 1 2 3 3 3 7.71

P-7: Display version differences 1 1 0 1 2 2 2 0 3 2 6.43

P-8: Sort documents by topic 1 2 1 3 1 2 1 2 0 1 5.00

P-9: Reference documents to another 3 3 2 2 2 0 0 1 1 0 3.57

P-10: Summarize parts of a document 5 3 1 2 1 0 1 0 1 0 3.07

not all of them are engineering tasks but require ad-

ditional research. In further discussions with the two

experts (i.e., Step 4 in Figure 1), we identiﬁed sev-

eral challenges. In the following, we analyze the re-

search context, how to support search processes, and

the evaluation of innovation degree. For each aspect,

we discuss its importance and map it with the propos-

als we display in Table 2.

3.1 Research Context

We argue that one of the main aspects of innovation

research is its context. During our studies, we found

that most researchers demand for features that im-

prove search speed (e.g., P-1, P-6, P-10) or help them

to reﬁne results to their background (e.g., P-6, P-8, P-

9). Overall, during our study we identiﬁed four main

types of context information that we display in Fig-

ure 2 and which inﬂuence searches for innovative doc-

uments:

• User: The users’ background inﬂuences which in-

novations are important to them. For example, an

employee who works on aluminum research may

not be interested in copper, but it could be impor-

tant.

• Company: A company’s research agenda or mar-

ket segment further scope which innovations are

interesting for its researchers. For instance, if a

company develops metal it might be unnecessary

to search documents in regard to plastic research.

• Documents: Researchers might be interested in

speciﬁc documents, such as, its type, innova-

tion degree, or topic, which deﬁne the basis of

further research. For example, when informing

about a new alloy, research articles are interest-

ing while patents are important when develop-

ment shall start.

• Trends: Trends help researchers to assess in which

direction a speciﬁc ﬁeld evolves. For instance,

they can assess which production methods are out

of date or will become standards.

So, a suitable tool for innovation research should

track and utilize these context information. Thus, we

can inﬂuence the search process and evaluation re-

sults without direct intervention of the user. For in-

stance, a tool could automatically ﬁlter documents to

context speciﬁcs, such as a domain or country (P-6).

This leads to improved results and less time consum-

ing search processes. Still, users may want to search

documents outside of their context, which must also

be supported.

In the following, we propose features for a system

that integrates the context in a search process. Fur-

thermore, we discuss a main challenge in this regard:

Determining the innovation degree of documents.

3.2 Supporting Search Processes

To support the development of a corresponding tool,

we discussed approaches to support searches for in-

novative documents. In particular, the proposed fea-

tures allow users to easier retrieve documents related

to their context. The following examples provide an

initial overview:

• Extracting meta data and abstracts helps to sum-

marize, ﬁlter, and sort documents (P-6, P-8, P-10),

to identify leading names in a topic (P-5), or to

reference literature (P-9).

• Filtering and categorizing found documents en-

ables researchers to map their results to speciﬁc

topics (P-8) or separate the works of speciﬁc au-

thors and institutions (P-5).

• Automated text generation helps developers to

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

656

Company

Trends

Documents

User

Scope

Background

Basis

Evolution

Innovation

Figure 2: Context of innovation research.

faster summarize gained information (P-10) or ex-

tract marked text (P-1).

• Analyzing and visualizing the publication date

can help researchers to overview temporal devel-

opments of a speciﬁc topic (P-4).

• Storing search processes separately provides the

possibility to create a research history and reuse

old results (P-2).

• Illustrating results in a list provides an overview

of found documents and allows to compare litera-

ture (P-3) or different versions (P-7).

• Supporting an ontology tree allows researchers to

store and connect keywords, allowing them to ﬁl-

ter (P-6), sort (P-8), and assess documents.

These are only some examples of features that can

help users. As we stated before, several applications

have been introduced to partly support such functions.

However, we emphasize the importance of the fea-

tures and of a tool that integrates these into a deﬁned

process. Many of these features are part of more gen-

eral tasks in exploratory search as discussed by Mar-

chionini (Marchionini, 2006) and, thus, elements of

corresponding retrieval tools could be applied here.

3.3 Evaluating Innovation Degree

In addition to the interactive support of the users’

search workﬂow, we propose to use semi-automatic

evaluation of a documents’ innovation degree. For

instance, we could base this analysis on previously

assessments of users and provide them to a recom-

mender system (Felfernig et al., 2007). Also, sim-

pler mechanisms may provide assistance, for example

evaluating the development of a topic over time.

Increasing numbers of citations or publications

can be an indicator for a research ﬁeld that is sig-

niﬁcant for practice. Other interesting factors are the

topics addressed or combined, the authors and their

networks, or where the document is published. For

example, a new topic introduced by a reputable au-

thor at an innovative conference is likely to have high

innovation degree. Still, automating this analysis re-

quires further investigations. We argue that this is the

most challenging step towards automation and con-

sidering context information is essential.

Overall, there are several features that can support

innovation research. While these are partly supported

in existing tools, in our study users asked for further

improvements and integration into a workﬂow. To de-

scribe a scope for corresponding research, we argue

that context information are the most important as-

pect.

4 CONCLUSIONS

The number of new research documents increases

continuously. Hence, for researchers in academia and

companies it becomes more complicated to identify

and assess innovative documents. Existing search en-

gines cannot adapt to consider a users background for

a given search task. Also, there are different informa-

tion needs that require the usage of adopted search en-

gines, e.g. for patent retrieval. This results in a great

number of potentially interesting documents that must

be assessed and aggregated manually.

We argue that considering context information and

applying an integrated workﬂow are essential. To sup-

port this position, we reported the results of a qualita-

tive study on industrial research processes. We found

strong points on which tasks are costly but could be

Identifying Innovative Documents: Quo vadis?

657

(partially) automated. Furthermore, we identiﬁed sev-

eral features this user group asks for. Finally, we dis-

cussed approaches and challenges that must be ad-

dressed while implementing a corresponding system

and in further research.

Based on the results, we aim to develop a suit-

able tool for the search and assessment of innovative

documents. While we already identiﬁed some fea-

tures and challenges, this will require additional dis-

cussions. Thus, we aim to conduct further qualitative

and quantitative user studies and discussions with ex-

perts.

ACKNOWLEDGEMENTS

This research is supported by BMWi

grants KF3358702KM4, KF3358803KM4,

KF2885203KM4, DFG grant LE 3382/2-1, and

Volkswagen Financial Services AG.

REFERENCES

Aghaei Chadegani, A., Salehi, H., Yunus, M. M., Farhadi,

H., Fooladi, M., Farhadi, M., and Ale Ebrahim, N.

(2013). A Comparison Between Two Main Academic

Literature Collections: Web of Science and Scopus

Databases. Asian Social Science, 9(5):18–26.

Felfernig, A., Friedrich, G., and Schmidt-Thieme, L.

(2007). Introduction to the IEEE Intelligent Systems

Special Issue: Recommender Systems. IEEE Intelli-

gent Systems, 22(3):18–21.

Frias-Martinez, E., Magoulas, G., Chen, S., and Macredie,

R. (2006). Automated User Modeling for Personal-

ized Digital Libraries. International Journal of Infor-

mation Management, 26(3):234–248.

Gilmour, R. and Cobus-Kuo, L. (2011). Reference Man-

agement Software: A Comparative Analysis of Four

Products. Issues in Science and Technology Librari-

anship, 66(66):63–75.

Jayawardana, C., Hewagamage, K. P., and Hirakawa, M.

(2001). A Personalized Information Environment for

Digital Libraries. Information Technology and Li-

braries, 20(4):185–196.

Jürgens, B. and Herrero-Solana, V. (2015). Espacenet,

Patentscope and Depatisnet: A Comparison Ap-

proach. World Patent Information, 42:4–12.

Knight, S. A. and Spink, A. (2008). Toward a Web Search

Information Behavior Model. In Web search, pages

209–234. Springer.

Kuhlthau, C. C. (1991). Inside the Search Process: Infor-

mation Seeking from the User’s Perspective. Jour-

nal of the American Society for Information Science,

42(5):361.

Lashkari, A. H., Mahdavi, F., and Ghomi, V. (2009). A

Boolean Model in Information Retrieval for Search

Engines. In International Conference on Information

Management and Engineering, ICIME, pages 385–

389. IEEE.

Lehmann, S., Schwanecke, U., and Dörner, R. (2010). In-

teractive Visualization for Opportunistic Exploration

of Large Document Collections. Information Systems,

35(2):260–269.

Lupu, M., Hanbury, A., et al. (2013). Patent Retrieval.

Foundations and Trends in Information Retrieval,

7(1):1–97.

Marchionini, G. (2006). Exploratory Search: From Find-

ing to Understanding. Communications of the ACM,

49(4):41–46.

Meyyappan, N., Chowdhury, G. G., and Foo, S. (2000). A

Review of the Status of 20 Digital Libraries. Journal

of Information Science, 26(5):337–355.

Nürnberger, A., Stange, D., and Kotzyba, M. (2015).

Professional Collaborative Information Seeking: On

Traceability and Creative Sensemaking. In Semanitic

Keyword-based Search on Structured Data Sources,

pages 1–16. Springer.

Xie, H. I. (2006). Evaluation of Digital Libraries: Criteria

and Problems from Users’ Perspectives. Library &

Information Science Research, 28(3):433–452.

ICEIS 2017 - 19th International Conference on Enterprise Information Systems

658
