Improving Throughput in BB84 Quantum Key Distribution

Shawn Prestridge and James Dunham

Electrical Engineering, Southern Methodist University, 6425 Boaz Ln, 75205, Dallas, Texas, U.S.A.

Keywords:

QKD, BB84, Winnow, B92, CASCADE.

Abstract:

Quantum Key Distribution (QKD) is a scheme that allows two parties to exchange a key in a provably secure

manner that will be used in a more conventional encryption system. The ﬁrst implementation of QKD was

BB84 by Bennett and Brassard. Several techniques have been used to attempt to maximize the number of

bits realized at the end of the BB84 protocol. One of the techniques used is the B92 protocol (and its follow-

on, CASCADE) introduced by Bennett et al. which uses 1-bit parities to reconcile the keystream between

Alice and Bob (Bennett et al., 1992). Another is the Winnow protocol introduced by Buttler et al. which

uses Hamming codes to increase the efﬁciency of the BB84 protocol to allow error rates up to 13.22%(Buttler

et al., 2003). In this paper, the Winnow protocol is enhanced and extended to allow arbitrarily high error rates

thus greatly improving the effectiveness of the protocol while preserving security. This enhancement also

provides a marked improvement over the original B92 protocol in terms of the number of bits preserved in the

keystream.

1 INTRODUCTION

BB84 is a well-known protocol to do QKD and quite

a bit of research has been done on the last part of

the protocol (commonly referred to as the reconcilia-

tion phase) which ensures that Alice and Bob have the

same bitstream that will be used as a key in their con-

ventional cryptosystem. Most algorithms rely on sim-

ple parity-check schemes to ensure that Alice and Bob

can detect and correct inconsistencies between their

respective bitstreams. Moreover, they also rely on

bit-discarding (often referred to as “burning”) tech-

niques to restore security to the remaining bits. This

paper will brieﬂy describe the manner in which this

resolution takes place and will also provide the basic

framework for systematic codes that extend the Win-

now protocol to be effective at very high error rates.

1.1 Brief Description of BB84 (Bennett

and Brassard, 1984)

The BB84 protocol allows Alice to send a new cryp-

tosystem key to Bob in a manner that is provably se-

cure via a Quantum Channel (QC). Alice chooses a

key k and a series of orthogonal bases b on which she

encodes k so that they can be transmitted across a QC.

Both k and b have maximum entropy and the same

length for reasons that are detailed in the original pa-

per. Bob chooses a random set of bases b

by which

he measures what Alice sends to him. Due to the na-

ture of the orthogonal bases and the QC, if Bob does

not guess the correct basis by which to measure a bit

of k, then the result becomes random for that bit. At a

high level, the protocol can be summarized in a series

of steps in Fig.1.

Figure 1: BB84 Protocol illustrated.

This paper will focus solely on improving the

methods used in the last step of the protocol, so the

only security concerns that need to be addressed con-

cern the leakage of key information in the reconcil-

iation process. In the last step, Alice and Bob have

approximately the same bitstream which will be dis-

Prestridge, S. and Dunham, J.

Improving Throughput in BB84 Quantum Key Distribution.

DOI: 10.5220/0006422104370443

In Proceedings of the 14th International Joint Conference on e-Business and Telecommunications (ICETE 2017) - Volume 4: SECRYPT, pages 437-443

ISBN: 978-989-758-259-2

437

tilled down to a ﬁnal key. There are a number of

protocols that are designed to resolve these remain-

ing errors, but the underlying theme to most of these

protocols is that that Alice and Bob select a number

of bits from their bitstream to form a block and com-

pute a parity check value on the block. They then

exchange this parity check value across an unsecured

medium (most likely the Internet) to try to determine

if there are errors in the block. If there is an error,

the protocol attempts to correct the errors. These pro-

tocols stipulate that certain bits within the remaining

bitstream must be discarded in order to prevent in-

formation leakage due to the fact that the parity check

information was exchanged on an unsecured medium.

Where these methods typically differ from one an-

other is in the way they comprise blocks, compute

parities, and when they discard bits. Additionally,

some protocols will use Privacy Ampliﬁcation (PA)

which feeds the distilled key into a hash algorithm to

increase security. Even if a protocol does not include

PA as one of its steps, it can add PA as a bolt-on to

its output to increase security by use of randomness

extractors (Dodis et al., 2004).

1.2 B92 Protocol (Bennett et al., 1992)

In the reconciliation phase, the B92 protocol divides

the bitstream into blocks of length k (the paper pro-

vides empirical data on how to determine the length

of k) and then computes a 1-bit parity on each block.

Each block has a random selection of bits from the

bitstream with each bit only going into one block per

round to ensure that all bits are checked. When the

parity information is exchanged, a bit is burned from

the block to preserve security. If the parities agree,

then they move on to the next block. If the parities

between Alice and Bob disagree, they split the block

in half and perform a 1-bit parity on each half of the

block, burning a bit on each half to preserve security;

this process is repeated until the error in the block is

eliminated. When all blocks have been checked, the

process is repeated again with the smaller bitstream

(because bits have been discarded along the way to

preserve security). These rounds of error-detection

with 1-bit parities are repeated until 20 successive

rounds have been completed with no errors found in

any of the blocks. At the end of this reconciliation,

the remaining bits can be used as-is or can be fed into

a PA scheme.

1.3 Winnow Protocol (Buttler et al.,

2003)

The reconciliation phase of the Winnow protocol

computes a simple 1-bit parity for the block and if

the parities computed by Alice and Bob match, then

they assume that the block does not contain an er-

ror and a single bit is discarded from each of their

blocks to restore maximum entropy to the remain-

ing bits in the block. If the parities do not match,

the block is bisected and a 1-bit parity is computed

for each half of the block to determine in which half

the error lies. This protocol sacriﬁces a bit for every

parity bit that is exchanged on the unsecured chan-

nel, therefore it preserves security in a fashion that

most closely resembles the one that will be presented

in this paper and will thus be the primary baseline

for comparison. Once this single-bit parity round is

complete, Winnow uses Hamming codes to attempt

to further eliminate errors and preserve information-

theoretic security. Winnow is typically compared to

the CASCADE protocol and B92 for efﬁciency pur-

poses (Bennett et al., 1992). CASCADE delays the

burning of bits but uses privacy ampliﬁcation to ad-

dress the issue, therefore it is better to compare our

new protocol to Winnow and to B92.

2 PDG CODES

This paper will introduce a protocol called Prestridge-

Dunham Guardian (PDG) Codes that will further the

Winnow protocol by exploiting probabilities concern-

ing the Hamming code syndrome and the number

of estimated errors remaining in code blocks. PDG

codes will allow them to resolve errors in the bit-

stream with a much greater frequency than Winnow

and at much higher bit error rate (BER) values. PDG

Codes consist of a series of rounds that iteratively

search through the string identifying and correcting

errors. After several rounds, Bob’s string will then be

compared with Alice’s to see if they are indeed equiv-

alent.

In general, the PDG Coding System will mirror

Winnow by taking the entire message that was trans-

mitted from Alice to Bob and break it up into a series

of blocks of a particular length (the speciﬁcs of which

length to choose are detailed in section 2.2). Where

PDG will differ from Winnow and how it achieves

much higher error detection and correction rates is in

how the syndrome information is exploited to maxi-

mize the error detection and correction capability. In

both PDG and Winnow, the following takes place for

each block:

SECRYPT 2017 - 14th International Conference on Security and Cryptography

438

1. Alice computes a Longitudinal Redundancy

Check (LRC) of the block (essentially a one-bit

parity check) and sends the result to Bob;

2. Bob computes the LRC for his received block;

3. If Bob’s computation matches that of Alice, they

assume that the bits in that block have no errors

and sacriﬁce one bit in the block to re-randomize

the data;

4. Otherwise, Alice and Bob independently compute

Hamming Code parity bits and Alice sends hers to

Bob via the unsecured public channel; Bob uses

this information to correct his received data and

he and Alice sacriﬁce as many message bits as

there were parity bits exchanged on the unsecured

channel.

Since the LRC is a linear systematic code, sacri-

ﬁcing a message bit in the block will re-randomize

the data to account for the single parity bit that was

exchanged on the unsecured channel; this result has

been proven many times (Prestridge, 2017). As PDG

progresses, it will always sacriﬁce as many message

bits as there were parity bits exchanged on the public

channel, so at each step along the way the data is re-

randomized in such a way that Eve gleans no informa-

tion about the remaining bits. Hamming codes were

selected for that very reason: the number of parity bits

that it uses are low thus providing a good throughput

of message bits. Other error-detection and -correction

codes can be used, but they will require delaying the

sacriﬁcing of message bits to preserve message bit

throughput. Therefore, there will be some amount of

information leakage before a PA scheme is used to

distill a ﬁnal key. As it stands, PDG gives the user

the option whether they want to use PA or not since

the bits it distills are secure. Once all the blocks have

been processed, it is likely that Alice and Bob will

engage in a second round of resolution with a larger

block size to account for the fact that the number of

errors in the message bits has decreased, thereby gain-

ing performance for the second round. The real efﬁ-

ciency of PDG comes from how Hamming codes are

exploited to get better results than other codes.

2.1 Getting More from Hamming Codes

To see how we can more effectively exploit the syn-

drome, let us ﬁrst examine a very simple Hamming

code. A standard [7,4] Hamming code has seven

overall bits in the codeword, of which four are infor-

mation and three are parity bits. The mechanics of

how to compute the syndrome for single-error detec-

tion and correction can be found in many textbooks

(MacWilliams and Sloane, 1978). A standard syn-

drome for decoding single-bit errors is:







0 0 0

0 0 1

0 1 0

0 1 1

1 0 0

1 0 1

1 1 0

1 1 1













Bit in error

No Error







(1)

Using the [7,4] code, four information bits are be-

ing transmitted over the noisy secure (quantum) chan-

nel and the three parity bits are being transmitted over

a noiseless insecure channel (Internet). It is known

that the Hamming distance of this code will allow the

user to correct all single-bit errors, but what about cor-

recting double-bit errors since it is now known that an

error cannot occur in the parity bits? A standard In-

formation Theory maxim is that any error rate at or

below 1E

−6

is considered negligible (MacWilliams

and Sloane, 1978). Since the parity information is

transmitted on the Internet which has a BER less

than 1E

−6

, the parity information can be considered

a lossless transmission as the IEEE 802 Fuctional Re-

quirements Document provides that the error rate on

the MAC Service Data Unit is below this threshold

(IEEE, 1991). A traditional analysis of the [7,4] Ham-

ming code says that if there is more than a single bit

error per packet, the error is undetectable and uncor-

rectable. For a 5% BER, the probability of an unde-

tected error is given by:

∑

i=2





(1 − p)

4−i

= 0.0140. (2)

Thus, the probability of an undetected error is approx-

imately 1.40%.

Because the parity bits are transmitted perfectly,

if the syndrome indicates that an error has been en-

countered in one of the parity bits it can be logically

assumed that what has actually happened is that more

than one bit error has occurred. Because of the sym-

metric nature of Hamming codes, it is only necessary

to examine one case of the pool of possible informa-

tion bit combinations, so vector [0000] is used. Table

1 shows that six different double-bit errors can occur

within the four information bits.

Table 1: Syndromes for all single-bit errors.

Received vector Bit errors Syndrome

0010100 3, 5 110

0010010 3, 6 101

0010001 3, 7 100

0000110 5, 6 011

0000101 5, 7 010

0000011 6, 7 001

Improving Throughput in BB84 Quantum Key Distribution

439

In the case of a double-bit error, there are two pos-

sibilities: the resultant syndrome indicates a single bit

error in either a parity bit or a single-bit error in a

non-parity bit. When the syndrome indicates that an

error has occurred in a non-parity bit (double errors

in code bits [3, 5], [3, 6] and [5, 6]), an undetectable

error has occurred. However, three of the six pos-

sible double-bit error patterns indicate an error in a

parity bit ([3, 7], [5, 7] and [6, 7]); since we know

that a parity bit error cannot occur, then we know that

one of these three double-bit error patterns has oc-

curred. Three of the four information bits will be dis-

carded, so the user only needs to be concerned about

correcting the bit that will be kept. Therefore, there

are really only three possible double-bit error patterns

that concern the user and so no matter which bit the

user selects to keep, there is one double-bit error pat-

tern that is detected and corrected, thus improving the

[7,4] Hamming code by lowering the probability of

an undetected error to 0.95%:





(1 − p)

∑

i=3





(1 − p)

4−i

= 0.0095066.

(3)

The chosen bit will still be correct half of the time,

so the effective error rate is approximately 0.475%, a

29.52% improvement over the traditional method.

This same technique can be extrapolated to larger

Hamming codes, e.g. consider a block that is being

checked with a (31,26) Hamming code and Bob’s

computed syndrome is 00100. There are eleven dif-

ferent double-bit error patterns that map to the same

syndrome. Since there were ﬁve parity bits p

that

were exchanged across the unsecured public channel,

ﬁve bits of the block b

must be burned to preserve

the security. If Bob chooses one bit from ﬁve of the

eleven possibilities, he has a

= 55.6% chance of

eliminating one of the bits that was in error. More-

over, if Bob was successful in eliminating one of the

errors in the block, then it is easier to eliminate the

other error in the block on a different pass.

2.2 Detailed Outline of the PDG Coding

System

PDG begins by looking at both k and k

to remove the

remaining errors. In most QKD schemes, both Alice

and Bob have an estimate of the BER for their channel

because they run a preliminary string of data through

the QC to estimate the BER. With this BER in mind,

the PDG code proceeds like this for each round:

1. Choose block length k to divide the string into k-

length blocks, zero-padding the last block to make

it ﬁt the proper length.

2. Randomly select bits from the string to ﬁll the

block; each bit will be selected only once per

round.

3. Compute a one-bit LRC check for the block; if the

LRC check passes, burn one bit and move to the

next block.

4. If the LRC fails, use a Hamming code in the man-

ner described in section 2.1 to eliminate the error;

burn (n − k) bits as this is how many parity bits

were used in the Hamming code.

5. Repeat until all blocks have been processed for

this round.

The number of rounds necessary have been deter-

mined experimentally for different initial BERs. Now

we will delve into the details for each step mentioned

above.

2.2.1 Choosing Block Lengths

Since the BER (p

BER

) on the QC is known, we can

compute the probability of having more than one bit

error in the block via the formula:

UDE

∑

i=2





BER

(1 − p

BER

)

k−i

(4)

where p

UDE

is the probability of an undetected error

for a Hamming code. We adjust our block length such

that the p

UDE

is approximately 1% to get maximum

efﬁciency for our code by balancing the need to burn

bits but still having a high-rate Hamming code. There

are only certain Hamming codes available (e.g (7,4),

(15,11), etc.), so the selection of k must take this into

account and err on the side of caution so that results

will be skewed conservatively.

2.2.2 Randomly Selecting Bits to Fill Each Block

Assuming that an (n, k) Hamming code is chosen,

the string will be broken up into a series of k-length

blocks, the last block being 0-padded if necessary.

These blocks are ﬁlled with bits randomly selected

from the distilled bits of Alice and Bob’s respective

collections; they each select the same random pattern

from their collections to ﬁll blocks and each bit goes

in precisely one block for the round. The rationale for

this mixing is to prevent “bursty” errors (a string of

successive bit errors) from corrupting the entire string

which would burn more bits than is necessary.

SECRYPT 2017 - 14th International Conference on Security and Cryptography

440

2.2.3 Computing the LRC on the Block

Once the blocks are ﬁlled, Alice and Bob will run

a Longitudinal Redundancy Check (LRC) on each

block b

. The results are compared across the unse-

cured public channel which allows Alice and Bob to

do a rudimentary check for an odd number of bit er-

rors without burning a great deal of information bits.

If the LRC does not detect an odd number of errors,

then the block is considered to be free of errors be-

cause the careful selection of the block size minimizes

the probability that there are two or more errors con-

tained within a single block. Clearly, this can some-

times be incorrect but these errors are almost always

caught by running successive rounds of the algorithm.

2.2.4 If LRC Fails, Run Hamming Code

If the LRC indicates the presence of an odd number of

errors, Bob will ask Alice over the unsecured public

channel for the parity bits p

of the Hamming code for

the block being examined. The block b

is combined

with those parity bits to form c

and then multiplied

by the corresponding parity check matrix H to gener-

ate the syndrome s:

• H = s. (5)

This syndrome is then used in the manner previ-

ously described to determine if Bob’s b

has no er-

rors, a single error or two errors. If two errors are

detected, Bob uses the syndrome tables to determine

which combination of bits in b

can produce the com-

puted syndrome. Depending on which (n, k) Ham-

ming code is currently being used, it may be possi-

ble for Bob to correct one or both errors; if not, Bob

earmarks all the suspect bits as being “sacriﬁcable”

in order to minimize the number of times the suspect

bits are checked. This process is continued for each

block b

in the string.

For each block, Bob must burn as many bits in b

as the number of parity bits p

that were communi-

cated on the unsecured channel. If a single-bit error

has been detected, then Alice sends Bob the parity in-

formation for the corresponding Hamming Code. If a

double-bit error has been detected, Bob will examine

the number of possible pairs of bits in b

that could

generate such an error and select one bit from sep-

arate pairs to burn; this increases the probability that

Bob has removed at least one of the errors in the block

without burning a bit in the rest of b

that has a high

probability of being correct.

2.2.5 Repeat for all Blocks

This process is repeated for all the blocks remain-

ing in the round. When all the blocks have been

checked, Bob uses the unsecured public channel to

send a list of the bits that he has burned so that Al-

ice will also remove those bits from her pool. Again,

knowing the position of the bits that have been burned

does not compromise the security because the parity

of the remaining bits in the sundry b

blocks are re-

randomized which prevents Eve from gleaning any in-

formation about them.

The number of rounds and which Hamming codes

to use have been determined experimentally and are

summarized in Table 2 for BERs of 1%-10%.

Table 2: PDG Selection parameters by BER.

BER Pass 1 Pass 2 Pass 3 Pass 4

1% (15,11) (31,26) (63,57) (127,120)

2% (15,11) (31,26) (63,57) (127,120)

3% (15,11) (31,26) (63,57) (127,120)

4% (15,11) (31,26) (63,57) (127,120)

5% (15,11) (15,11) (63,57) (127,120)

6% (15,11) (31,26) (31,26) (31,26)

7% (15,11) (15,11) (31,26) (31,26)

8% (15,11) (15,11) (15,11) (31,26)

9% (15,11) (15,11) (15,11) (31,26)

10% (15,11) (15,11) (15,11) (15,11)

The bits that remain can be used either as a key for

a cryptosystem or they can be used in a PA scheme.

For comparison, we look at B92 and Winnow since

they give the number of raw bits remaining before a

PA stage is applied.

3 RESULTS

We will now compare PDG against two of the most

commonly used techniques for performing bit recon-

ciliation, namely B92 and Winnow.

3.1 PDG vs. B92

On average, the PDG codes return better results 80%

of the time than the B92 protocol because either:

1. PDG returns more bits to Alice and Bob than B92.

2. PDG corrects all errors in the block and B92 does

not.

Clearly, the PDG codes demonstrate a remarkable im-

provement over B92 while still preserving the security

of the key exchanged by the protocol.

Running a slate of tests that allow the BER to vary

from 1% to 10% and the initial message size to vary

from 1k to 10k bits (a total of 100 test parameters with

Improving Throughput in BB84 Quantum Key Distribution

441

10k tests per parameter) reveals some surprising re-

sults for the B92 protocol. While PDG maintains ap-

proximately the same performance for a given BER

regardless of the initial packet size, the performance

of the B92 protocol suffers drastically as the size of

the packets increases for all BERs greater that 2%.

Selecting typical use cases of a BER of 1%, 3% and

7%, it is easily seen that the PDG code outperforms

the B92 protocol on almost all of the test cases per-

formed. Given that the PDG performance is equiva-

lent regardless of the packet size (and to allow B92

to perform its best), a packet size of 1,000 bits can

be compared. For the 1% case, PDG returns a total

of 252,095 bits more than B92, a 3.1% improvement.

For the 3% case, PDG returns a total of 200,443 bits

more than B92 for a 2.8% improvement. For the 7%

case, PDG returns a total of 2,466,405 bits, an 83.9%

improvement. From these cases, it is clear that PDG

provides a more efﬁcient coding solution than B92 for

extracting bits in a QKD scheme. For the grand total

of 1,000,000 tests run to compare how PDG performs

against B92, PDG was able to outperform B92 more

than 50% of the time on 99 of the 100 parameters and

missed a perfect record by a mere 4% on the test pa-

rameter in question.

Table 3 shows a typical use case where Alice and

Bob would exchange 2,000 bits. Each row of the ta-

ble shows the results of running 10k tests with the

selected BER and 2k packet size. The column for

“% Int” is the percentage of results that were deemed

interesting, i.e. where PDG successfully returns bits

and either B92 does not return as many bits or B92

does not remove all the bit errors. The columns “PDG

Bad” and “B92 Bad” indicate the number of test cases

where PDG and B92 did not remove all the errors, re-

spectively. The column of “Bit diff” shows the total

number of bits that PDG leaves in excess of those left

by B92 when both PDG and B92 were able to elimi-

nate all errors in the packet.

Table 3: Comparing PDG to B92.

BER % Int PDG Bad B92 bad Bit diff

10 84.01 1,370 8,856 6,634,518

9 85.15 1,240 8,864 7,446,470

8 90.12 304 8,868 8,777,072

7 89.04 310 8,750 9,509,198

6 68.19 1,679 8,125 7,700,175

5 58.40 2,130 6,044 5,315,023

4 70.81 2,417 3,050 1,110,910

3 93.06 421 822 873,984

2 99.17 37 110 419,612

1 100.0 0 10 304,615

PDG returns a successful result at least 75% of

the time and quite often more than 85% of the time.

When you divide the total number of PDG bits by the

number of test cases run (10000), you can see that the

average number of bits for each test would leave

an adequate key length regardless of which standard

cryptosystem was employed by Alice and Bob for

their communication (at 10% BER, an average of 759

bits per case and at 1%, an average of 1685 bits per

case). It is interesting to note that PDG leaves more

bits than the B92 in all cases, particularly when the

BER is high. At a high BER, B92 can rarely correct

all errors in Bob’s bitstream. As the physical distance

between Alice and Bob increases, so does the BER

on the quantum channel. These results indicate that

PDG would permit a greater physical distance to ex-

ist between Alice and Bob than could be tolerated by

B92.

3.2 PDG vs. Winnow

Winnow is capable of distilling a key so long as the

BER on the quantum channel is below 13.22% (But-

tler et al., 2003). However, PDG is capable of return-

ing keys for error rates up to 47%. PDG effectively

has some double-error detecting and correcting capa-

bility that Winnow does not; as such, PDG is capa-

ble of distilling at least some key between Alice and

Bob when Winnow cannot. As one would expect,

the probability of successfully distilling a key and the

length of the distilled key become arbitrarily low as

the BER increases and the size of the initial packet

decreases. Table 4 shows the effectiveness of PDG

at a 47% error rate when the initial packet size varies

from 10000 bits down to 1000 bits. In this table, the

“% Int” column shows the number of times PDG was

able to correct all errors in the packet and “PDG Bad”

is the number of cases where PDG could not success-

fully remove all errors in the string; “Ave. bits” is the

average number of bits left when PDG successfully

removed all errors.

Table 4: PDG performance at 47% BER.

BER Size % Int PDG Bad Ave. bits

47 10000 99.39 61 204

47 9000 99.25 75 183

47 8000 99.01 99 162

47 7000 98.34 166 141

47 6000 97.79 221 120

47 5000 97.12 288 99

47 4000 95.18 482 79

47 3000 92.91 709 58

47 2000 89.43 1,057 38

47 1000 80.60 1,940 19

Since PDG is capable of consistently correcting

all errors even at high error rates, it can be used to

quickly distill a secret key between Alice and Bob. As

the sample table indicates, the performance at a 47%

BER is roughly linear with a 1k bit packet returning

an average of 19 bits per case (1.9% of the bits make

SECRYPT 2017 - 14th International Conference on Security and Cryptography

442

it through the distillation) and a 10k bit packet returns

an average of 204 bits per case (2.0% of the bits make

it through the distillation).

Comparing PDG to Winnow at rates below 10%

further illustrates the efﬁciency gain realized by PDG.

Table 5 shows the average fraction of bits remaining

at bit error rates ranging from 1% to 10% when Win-

now is used with the PDG parameters speciﬁed in Ta-

ble 2. These results reﬂect only the error-detection

and -correction portion of the respective codes with-

out PA; assuming that the same PA would be applied

to both codes, the ﬁnal results including PA would be

multiplied by the same scalar.

Table 5: Fraction of bits remaining at various error rates.

BER Winnow remaining PDG remaining

10 0.1640 0.3866

9 0.2081 0.4307

8 0.2152 0.4943

7 0.2642 0.5450

6 0.3353 0.5097

5 0.3412 0.5463

4 0.4331 0.5864

3 0.4563 0.7361

2 0.5211 0.8041

1 0.6121 0.8426

4 CONCLUSIONS

PDG codes are capable of outperforming the most

popular BB84 coding schemes by utilizing extra in-

formation available from Hamming codes. This en-

ables PDG to leave more bits than the B92 protocol

more than 80% of the time while not leaking any in-

formation bits to Eve. Additionally, PDG can outper-

form the Winnow protocol by being able to reliably

detect and correct errors all the way up to 47% BER

on the quantum channel, thus allowing Alice and Bob

to create longer ﬁber links between them to take ad-

vantage of the enhanced throughput. Even when the

BER is less than Winnow’s maximum, PDG leaves

more bits to create a longer key than Winnow can dis-

till.

REFERENCES

Bennett, C. H., Bessette, F., Brassard, G., Salvail, L., and

Smolin, J. (1992). Experimental quantum cryptogra-

phy. Journal of Cryptology, 5(1):3–28.

Bennett, C. H. and Brassard, G. (1984). Quantum Cryp-

tography: Public Key Distribution and Coin Tossing.

In Proceedings of the IEEE International Conference

on Computers, Systems and Signal Processing, pages

175–179, New York. IEEE Press.

Buttler, W. T., Lamoreaux, S. K., Torgerson, J. R., Nickel,

G. H., Donahue, C. H., and Peterson, C. G. (2003).

Fast, efﬁcient error reconciliation for quantum cryp-

tography. Phys. Rev. A, 67:052303.

Dodis, Y., Reyzin, L., and Smith, A. (2004). Fuzzy Ex-

tractors: How to Generate Strong Keys from Biomet-

rics and Other Noisy Data, pages 523–540. Springer

Berlin Heidelberg, Berlin, Heidelberg.

IEEE (1991). Functional requirements IEEE 802.

http://www.ieee802.org/802˙archive/fureq6-8.html.

Accessed: 2017-05-21.

MacWilliams, F. and Sloane, N. (1978). The Theory of

Error-Correcting Codes. North-Holland Publishing

Company, 2nd edition.

Prestridge, S. (2017). Applying Classical Information The-

ory to Quantum Key Distribution. PhD thesis, South-

ern Methodist University. unpublished thesis.

Improving Throughput in BB84 Quantum Key Distribution

443
