Formal Analyze of a Private Access Control Protocol to a Cloud Storage

Mouhebeddine Berrima

, Pascal Lafourcade

, Matthieu Giraud

and Narjes Ben Rajeb

LIP2, Universit

e de Monastir, Monastir, Tunisia

LIMOS, Universit

e Clermont Auvergne, Aubi

ere, France

LIP2, Universit

e Tunis El-Manar, Tunis, Tunisia

Keywords:

Cloud Storage, Formal Methods, Attribute Based Signature, Attribute Based Encryption, Data and User

Privacy.

Abstract:

Storing data in the Cloud makes challenging data’s security and users’ privacy. To address these problems

cryptographic protocols are usually designed. Cryptographic primitives have to guarantee some security prop-

erties such that data and user privacy or authentication. Attribute-Based Signature (ABS) and Attribute-Based

Encryption (ABE) are very suitable for storing data on an untrusted remote entity. In this work, we formally

analyze the Ruj et al. protocol of cloud storage based on ABS and ABE schemes. We model the protocol and

its security properties with ProVerif an automatic tool for the veriﬁcation of cryptographic protocols. We dis-

cover an unknown attack against user privacy. We propose a correction, and automatically prove the security

of the corrected protocol with ProVerif.

1 INTRODUCTION

Cloud storage refers data storage services hosted over

the Internet. The cloud users store data online, so that

they or any other authorized users can access them

from any location via the Internet. However, the share

of the sensitive data on a third party through a pub-

lic network brings some security challenges. In par-

ticular, there are concerns with the privacy of users

and data. Protecting privacy in cloud is more difﬁcult

than in traditional environments, because sensitive

data may be disseminated and stored over many exter-

nal location, managed by external service providers

(Wang et al., 2010a), and both cloud and user can

be malicious (Mulazzani et al., 2011; Zhang et al.,

2012). User privacy is required in many applica-

tions when users store sensitive information like ﬁ-

nancial or health data (Tang et al., 2012). There

are two important privacy requirements when a user

stores data on the cloud: anonymity and unlinkability.

The ISO/IEC standard (governmental organisations,

2009) deﬁne anonymity as the property ensuring that

a user may use a service or a ressource without dis-

closing his (or her) identity. However, preserving

the anonymity property may still release information

about a user by allowing an adversary to track several

uses of a resource by the same user. Such information

might allow an adversary to deduce or at least

restrict the possible identities of a user. Therefore, the

unlinkability property is required, ensuring that the

different uses of a service or a ressource for the same

user should not be linked by an adversary. On the

other hand, the Cloud Service Provider (CSP) must

authenticate the user to be sure that he has the right

to store data on the cloud, moreover this authenti-

cation must be done without reveal any information

about his identity. Attribute-Based Signature (ABS)

is a cryptographic scheme privacy-preserving authen-

tication. Indeed, in ABS the veriﬁer of a signature can

only check if the message is signed by authorized one

without knowing any information about its identity.

Data Privacy has been also gained research inter-

est because only authorized users have access to sen-

sitive data on the cloud. Data must be protected when

transmitted to CSP and during the storage. The pro-

tection is against the unauthorized users as well as

the CSP since the cloud is often assumed to be hon-

est but curious (Li et al., 2010; Yu et al., 2010). To

ensure data privacy, several works propose the stor-

age of data in encrypted form. Thus, if the storage

is compromised, then the leaked information should

be protected. Identity based cryptography is not fea-

sible in this situation because the inability of users

to share their encrypted data at a ﬁne-grained level.

Attribute-Based Encryption (ABE), introduced by Sa-

hai and Waters (Sahai and Waters, 2005), solves the

Berrima, M., Lafourcade, P., Giraud, M. and Rajeb, N.

Formal Analyze of a Private Access Control Protocol to a Cloud Storage.

DOI: 10.5220/0006461604950500

In Proceedings of the 14th International Joint Conference on e-Business and Telecommunications (ICETE 2017) - Volume 4: SECRYPT, pages 495-500

ISBN: 978-989-758-259-2

495

problem of ﬁne grained access control. There are

two complementary forms of ABE (Goyal et al.,

2006): Ciphertext-Policy Attribute-Based Encryption

(CP-ABE) and Key-Policy Attribute-Based Encryp-

tion (KP-ABE). In CP-ABE, the users have given a set

of attributes and the data are encrypted under an ac-

cess policy described as Boolean formula. Only users

having the attributes satisfying the access policy can

decrypt the ciphertext. In KP-ABE, the situation is re-

versed: users are associated with access policies and

ciphertexts are encrypted with sets of attributes.

Related Work: (Bertino et al., 2009; Angin et al.,

2010; Chow et al., 2012) proposed approaches to deal

with security and privacy. In (Bertino et al., 2009),

the privacy of users is preserved with zero-knowledge

proof protocols while it is based on anonymous iden-

tiﬁcation in (Angin et al., 2010). Recently, taking ad-

vantages of ABS and ABE has emerged as a widely

accepted approach by the cloud security community

(Ruj et al., 2012; Li et al., 2010; Zhao et al., 2011).

The ABS is used to ensure the authentication while

hiding anonymity, and the ABE allows a ﬁne-grained

access control to data. The protocol proposed by (Ruj

et al., 2012) is among the pioneering works to use

ABS and ABE. The protocol uses the SSH protocol to

secure the communication between the users and the

cloud, and supports reading and writing data stored in

the cloud.

Contributions: We analyze the Ruj et al. pro-

tocol (Ruj et al., 2012) which we abbreviate

RSN’12 protocol. We model it in the applied π-

calculus (Abadi and Fournet, 2001).We use ProVerif

tool (Blanchet et al., 2001) to analyze cryptographic

protocols (Puys and Lafourcade, 2015; Cremers et al.,

2009). For sake of simplicity, we consider one at-

tribute in our modeling of the ABE and ABS schemes.

We formalize and verify the fundamental security

properties of the protocol. In writing mode, we verify

the writer authentication and writer privacy which is

expressed by the anonymity of writer’s identity and

unlinkability, that is a user who stores data on the

cloud. While in reading mode, we check the required

property that is data privacy. We show that the un-

linkability of a writer is not satisﬁed against an attack

in which the adversary delays the messages of some

writers. Then, we propose a ﬁx, which prevents this

attack.

Outline: We give a description of RSN’12 protocol in

Section 2. We model RSN’12 protocol in Section 3

and analyze the security properties in Section 4. Fi-

nally, we conclude in Section 5.

2 RSN’12 PROTOCOL

DESCRIPTION

In (Ruj et al., 2012) the authors propose a proto-

col for reading and writing data stored in the cloud

which is based on the decentralized approach of CP-

ABE (Lewko and Waters, 2011) and ABS (Maji et al.,

2008) where many authorities distribute secret keys

associated to attribute. Using ABS the cloud veriﬁes

the authenticity of a user without knowing his identity

before storing data. Using ABE only valid users are

able to decrypt the stored data. The protocol makes

the following assumptions:

1. The CSP is honest-but-curious, i.e. it tries to

derive some information from the messages he

learned during the execution of the protocol, but

cannot modify the user’s content.

2. Users can have a read or/and write access to a ﬁle

stored in the CSP.

3. All the communications between participants are

secured by SSH (Secure Shell) protocol.

The RSN’12 protocol involves a user who may be

a writer or/and a reader, a Trusty Authority (TA) reg-

istering users, one or more Key Distribution Center

(KDC) issuing the secret keys associated to users’ at-

tributes, and a CSP. The TA and the KDC are trusted

entities while the CSP is semi-trusted. Some users

can be malicious and thus are considered as untrusted

entities. The protocol is composed of three sub-

protocols.

CSP

User

TAKDC

write

read

Figure 1: RSN’12 protocol.

Registering and getting attribute secret keys. In a

ﬁrst phase, a user gets attribute secret keys from the

KDCs by presenting his token obtained from TA:

• The user presents his identity to the TA, for in-

stance a federal government (

 in Fig. 1).

• TA registers the user if he is eligible and gives

him a token as described in ABS scheme (

 in

Fig. 1). TA embeds a random value in the token

which will be incorporate in the attribute secret

keys for signing to prevents collusion of the users.

• The user on presenting the token to the KDC re-

ceives secret attribute keys for signing and de-

SECRYPT 2017 - 14th International Conference on Security and Cryptography

496

cryption (

 in Fig. 1). The KDC checks the va-

lidity of the token using TA’s public key, and sends

the corresponding keys for signing and decryption

(

 in Fig. 1).

Writing on the cloud. To store a message MSG on

the cloud, the user proceeds as follows:

• He creates an access policy X containing all re-

quired ﬁelds, and encrypts the message MSG un-

der X as C = Encrypt(MSG, X ).

• Then he calculates the message C

= H (C)kτ

where H is a hash function, τ is a timestamp and

k is the concatenation operation. The timestamp

is used to prevent the user to use stale message

back with a valid signature, when his attributes

have been revoked. Next, he generates the signa-

ture σ of C

with a claim policy Y .

• Finally, he sends c = (C, τ, σ, Y ) to the CSP. Then

CSP veriﬁes, using Veri f y algorithm, if the mes-

sage H (C)kτ was signed by a user satisfying the

claim policy Y .

Reading from the cloud. A user can access at any

time to the data and requests a ciphertext, then the

CSP sends the requested ciphertext using SSH. Note

that, the authors do not propose any revocation model,

but it is still possible to incorporate it. The protocol is

clear but contains some ambiguities. We discuss these

minor problems and explain how to ﬁx them.

3 MODELING RSN’12

PROTOCOL

In this section we describe the Proverif processes used

to model RSN’12 protocol.

The main process. It is speciﬁed as the parallel com-

position of the processes modeling the roles of writ-

ers, readers, TA, KDC and CSP. First, the fresh se-

cret keys used respectively by the TA, the KDC, and

the CSP for asymmetric encryption and signature, are

generated. Their corresponding public keys are then

sent on a public channels, i.e. they are made available

to the adversary. Moreover, the fresh secret keys used

in ABS and ABE schemes, are also generated and

their corresponding public keys are published. The

secret keys of the writer and the reader are made un-

der replication to model an inﬁnite number of writers

and readers. The processes writer and reader are un-

der replication, because one user may establish many

sessions with the CSP. In our modeling, we use public

keys of asymmetric encryption as identities of partic-

ipants.

The writer process. The writer process models the

role of a writer. After the receipt of a token form the

TA, the writer sends a request to the KDC to get at-

tribute secret key for signing, this request is encoded

by a pair (token,write). Afterwards, the writer en-

crypts his message and signs it using the attribute se-

cret key.

The reader process. At ﬁrst, a reader behaves as a

writer by requesting a token from the TA and an at-

tribute secret key for decryption from the KDC. Next,

it has access to the CSP, to read a message stored on

the cloud. Finally, he decrypts the message read from

the CSP using his attribute secret key, and behaves as

a sub-process with the received message.

The KDC process. When receiving a request from

a user, the KDC checks the correctness of the token

using the public key of user used as its identity, which

was authenticated during SSH authentication proto-

col. If the token is valid, it issues an attribute secret

key for encryption or signing following the mode ac-

cess ”write” or ”read”.

The CSP process. The CSP is responsible of the stor-

age of user data.If the signature is valid with respect

to the claim policy, the CSP stores the message that

becomes immediately accessible by the readers. A

reader access directly to the CSP to read a ﬁle.

4 SECURITY ANALYSIS

We analyse the security properties of the protocol. All

proofs of our propositions are not presented because

they are directly implied by our ProVerif codes.

4.1 Conﬁdentiality

It means that a user without valid access policy can-

not decrypt the data stored on the cloud. In applied

π-calculus this property can be expressed as a secrecy

property: it should be impossible for an adversary, in-

teracting with the protocol and without valid attribute

secret key, to learn a message which is encrypted and

stored on the cloud.

Deﬁnition 1. Given an access policy AP, a cloud

storage protocol ensures conﬁdentiality if a secret

message stored on the cloud by an honest writer is

not deducible by an attacker without attribute secret

key satisfying AP.

Proving secrecy property is expressed by the

reachability notion. We request ProVerif to check that

a private message, encrypted using a public access

policy, cannot be deduced by the attacker. Proverif

proves this property in less one minute.

Proposition 1. RSN’12 protocol ensures the conﬁ-

dentiality property.

Formal Analyze of a Private Access Control Protocol to a Cloud Storage

497

4.2 Writer Authentication

A user can only write in the cloud if he has the

attribute validating the claim policy. Moreover, an

invalid user can not receive attribute from a KDC,

if does not have the token from TA. Authentication

property can be captured as a correspondence asser-

tion. To deﬁne the authentication of a writer, we an-

notate the protocol by the following events:

• AcceptSign: This event is placed inside the CSP’s

process and emitted if the signature is valid, i.e.

absCheckSign returns true.

• DelivKeySign(IdUser): This event is placed in-

side the KDC’s process and emitted when the

KDC issues an attribute secret key for signing to

a user with identity IdUser.

• DelivToken(IdUser): This event is placed inside

the TA’s process and emitted when the TA delivers

a token to a user with identity IdUser.

Deﬁnition 2. A cloud storage protocol ensures the

authentication of a writer with identity Id if for every

execution trace of the protocol each occurrence of the

event AcceptSign is preceded by an occurrence of De-

livKeySign(Id) which is preceded by an occurrence of

DelivToken(Id).

This property can be expressed in ProVerif in

terms of nested correspondence (Blanchet, 2009)

which allows us to order events. ProVerif can auto-

matically prove the corresponding nested correspon-

dence in less one second:

event(acceptSign) ⇒(event(DelivKeySign(pkwriter))

⇒ event(DelivToken(pkwriter)))

Proposition 2. RSN’12 protocol satisﬁes the authen-

tication of a writer.

4.3 Writer Privacy

In the context of cloud storage, writer privacy is ex-

pressed by two properties; anonymity and unlinkabil-

ity. Anonymity of a writer’s identity is ensured if it

is not possible for anyone, even the CSP, to learn the

writer’s identity of a stored message. Unlinkability

means that no one can link the messages stored on the

cloud, more precisely no one is able to decide if two

messages were stored by the same writer, or not.

Anonymity: A cloud storage system ensures

anonymity if it keeps the writer’s identity secret from

everyone. Hence, anonymity can be formalized as a

secrecy property: no one can deduce the identity of a

writer who store a message on the cloud. Since the

identities of the writers are known values, anonymity

is captured by the concept of strong secrecy. Strong

secrecy means that the adversary cannot distinguish

two instances of the same protocol with two different

values of the secret. For the precise deﬁnition, we

refer the reader to (Blanchet, 2004). In ProVerif,

strong secrecy is expressed by diff-equivalence de-

ﬁned between processes that share the same structure

and differ only in the choice of terms representing the

secret values (Blanchet et al., 2008).

Deﬁnition 3. A cloud storage protocol ensures

anonymity of a writer’s identity if for any two writers

with identities IdW

, IdW

and for any message msg,

an adversary cannot distinguish whether msg comes

from IdW

or IdW

We request to ProVerif to check if

C[W riter(IdW

, msg)] ≈ C[W riter(IdW

, msg)].

with C[ ] is an evaluation context modeling the whole

cloud storage protocol as described in main process

with a hole for a writer process, and the process

W riter(IdW, msg) models a writer with identity IdW

storing a message msg on the cloud. ProVerif suc-

ceeds to prove this request in 3 seconds.

Proposition 3. RSN’12 protocol preserves anonymity

of writer’s identity.

Unlinkability: Informally, in cloud storage context,

unlinkability holds when the differents stored mes-

sages of the same writer can not be linked by an at-

tacker even a dishonest user (writer or reader). Thus,

unlinkability can be viewed as the secrecy of link be-

tween writer and its messages stored on the cloud.

The deﬁnition of unlikability is similar to the deﬁ-

nition of voter privacy in e-voting protocol (Kremer

and Ryan, 2005) in the sense that we must consider

at least two honest writers. To understand this as-

sumption, consider the case where all the writers are

dishonest except one, as the stored messages on the

cloud are published by the CSP, the dishonest writers

can collude and determine the message of the honest

writer.

Deﬁnition 4. A cloud storage protocol ensures un-

linkability if for any two writers with identities IdW

IdW

and for any two messages msg1 and msg2, an

adversary cannot distinguish the situation in which

IdW

stores msg1 and IdW

stores msg2 from the sit-

uation in which IdW

stores msg2 and IdW

stores

msg1.

In applied π-calculus this deﬁnition can be formal-

ized as the following equivalence:

C[W riter(IdW

, msg1)|W riter(IdW

, msg2)]

≈

C[W riter(IdW

, msg2)|W riter(IdW

, msg1)] ,

SECRYPT 2017 - 14th International Conference on Security and Cryptography

498

where C[ ] is an evaluation context modeling the

whole protocol with a hole for two writers. In

ProVerif, the above pair of process can be expressed

as single biprocess as follows:

C[W riter(IdW

, choice[msg

, msg

])] |

C[W riter(IdW

, choice[msg

, msg

])] .

ProVerif ﬁnds an attack, in which a man-in-the-

middle attacker selectively delays or delete some mes-

sages sent to the CSP by one writer until he can link

a message to somebody.

Proposition 4. RSN’12 protocol does not ensure un-

linkability property.

For this attack we consider an attacker that is a

semi-honest reader with valid attribute secret keys,

who wants link the messages to a writer. In a real

cloud storage environment, to achieve the attack, an

attacker performs the following steps:

• Access to CSP and memorize all the ﬁles stored

in the cloud.

• Listen to the network, and wait for a message send

to the CSP.

• When a new message MSG is sent, he identiﬁes

its sender IdW and blocks all the messages sent to

CSP after the message MSG. He now has just to

wait until MSG becomes available on the CSP, i.e.

CSP appends MSG to the previous ﬁles.

• Then, he can access to the ﬁles and then learn

MSG by comparing the current contents of ﬁles

with the previous contents. Thus, he concludes

that MSG was sent by a writer with identity IdW

and can link a ﬁle to somebody.

Fixed protocol: To ﬁx this problem, a solution is

that the CSP simultaneously publishes at least two in-

coming messages from different persons. However,

the messages are accessible from a ﬁle, so if the mes-

sages are written on the ﬁle in a deterministic order,

for instance following arriving time of the messages,

the adversary can link a message with its writer by in-

specting the order of the sent messages to the CSP on

the network. Then, the CSP must write the incoming

messages on the ﬁles in non-deterministic way.

Proposition 5. The revisited RSN’12 protocol en-

sures unlinkability property.

5 CONCLUSION

In this paper, we revisit the security of the protocol

of (Ruj et al., 2012).We use ProVerif to prove auto-

matically claimed security properties by the authors

in the original paper. ProVerif helps us to discover

a ﬂaw in this protocol for the unlinkability property.

We then give a correction and prove the security of

the modiﬁed version with ProVerif. The next step is

to use our framework to model and analyze more pro-

tocols using ABE and ABS in order to discover ﬂaws

or formally prove the security of these protocols.

ACKNOWLEDGEMENTS

This research was conducted with the support of the

FEDER program of 2014-2020, the region council of

Auvergne-Rh

one-Alpes, the Indo-French Centre for

the Promotion of Advanced Research (IFCPAR) and

the Center Franco-Indien Pour La Promotion De La

Recherche Avanc

ee (CEFIPRA) through the project

DST/CNRS 2015-03 under DST-INRIA-CNRS Tar-

geted Programme.

REFERENCES

Abadi, M. and Fournet, C. (2001). Mobile values, new

names, and secure communication. In ACM SIGPLAN

Notices, volume 36, pages 104–115. ACM.

Adams, C., Cain, P., Pinkas, D., and Zuccherato, R. (2001).

Internet x.509 public key infrastructure time-stamp

protocol (tsp). RFC 3161.

Angin, P., Bhargava, B., Ranchal, R., Singh, N., Linderman,

M., Othmane, L. B., and Lilien, L. (2010). An entity-

centric approach for privacy and identity management

in cloud computing. In Reliable Distributed Systems,

2010 29th IEEE Symposium on, pages 177–183.

Bertino, E., Paci, F., Ferrini, R., and Shang, N. (2009).

Privacy-preserving digital identity management for

cloud computing. IEEE Data Eng. Bull., 32(1):21–27.

Blanchet, B. (2004). Automatic proof of strong secrecy for

security protocols. In Security and Privacy, 2004. Pro-

ceedings. 2004 IEEE Symposium on, pages 86–100.

Blanchet, B. (2009). Automatic veriﬁcation of correspon-

dences for security protocols. J. Comput. Secur.,

17(4):363–434.

Blanchet, B., Abadi, M., and Fournet, C. (2008). Auto-

mated veriﬁcation of selected equivalences for secu-

rity protocols. The Journal of Logic and Algebraic

Programming, 75(1):3–51.

Blanchet, B. et al. (2001). An efﬁcient cryptographic proto-

col veriﬁer based on prolog rules. In CSFW, volume 1.

Blanchet, B. and Smyth, B. (2016). Automated reasoning

for equivalences in the applied pi calculus with barri-

ers. In CSF’16, pages 310–324.

Chow, S. S., He, Y.-J., Hui, L. C., and Yiu, S. M.

(2012). Spice–simple privacy-preserving identity-

management for cloud environment. In International

Conference on Applied Cryptography and Network

Security, pages 526–543. Springer.

Formal Analyze of a Private Access Control Protocol to a Cloud Storage

499

Cremers, C. J. F., Lafourcade, P., and Nadeau, P. (2009).

Comparing state spaces in automatic security proto-

col analysis. In Formal to Practical Security - Papers

Issued from the 2005-2008 French-Japanese Collabo-

ration, pages 70–94. Springer.

governmental organisations (2009). Iso 15408-2: Common

criteria for information technology security evaluation

- part 2: Security functional components.

Govinda, K. and Sathiyamoorthy, E. (2012). Identity

anonymization and secure data storage using group

signature in private cloud. Procedia Technology,

4:495–499.

Goyal, V., Pandey, O., Sahai, A., and Waters, B. (2006).

Attribute-based encryption for ﬁne-grained access

control of encrypted data. In ACM CCS’06.

Kremer, S. and Ryan, M. (2005). Analysis of an electronic

voting protocol in the applied pi calculus. In European

Symposium on Programming, pages 186–200.

Lewko, A. and Waters, B. (2011). Decentralizing attribute-

based encryption. In Annual International Confer-

ence on the Theory and Applications of Cryptographic

Techniques, pages 568–588. Springer.

Li, M., Yu, S., Ren, K., and Lou, W. (2010). Securing

personal health records in cloud computing: Patient-

centric and ﬁne-grained data access control in multi-

owner settings. In International Conference on Se-

curity and Privacy in Communication Systems, pages

89–106. Springer.

Maji, H. K., Prabhakaran, M., and Rosulek, M. (2008).

Attribute-based signatures: Achieving attribute-

privacy and collusion-resistance. IACR Cryptology

ePrint Archive, 2008:328.

Mulazzani, M., Schrittwieser, S., Leithner, M., Huber, M.,

and Weippl, E. (2011). Dark clouds on the horizon:

Using cloud storage as attack vector and online slack

space. In Proceedings of the 20th USENIX Conference

on Security, SEC’11.

Puys, M. and Lafourcade, P. (2015). Evaluations of cryp-

tographic protocols: Veriﬁcation tools dealing with al-

gebraic properties. In Foundations and Practice of Se-

curity - FPS 2015. Springer.

Ruj, S., Nayak, A., and Stojmenovic, I. (2011). Dacc: Dis-

tributed access control in clouds. In TrustCom’11,

pages 91–98. IEEE.

Ruj, S., Stojmenovic, M., and Nayak, A. (2012). Privacy

preserving access control with authentication for se-

curing data in clouds. In Cluster, Cloud and Grid

Computing (CCGrid), 2012 12th IEEE/ACM Interna-

tional Symposium on, pages 556–563. IEEE.

Sahai, A. and Waters, B. (2005). Fuzzy identity-based

encryption. In Annual International Conference on

the Theory and Applications of Cryptographic Tech-

niques, pages 457–473. Springer.

Tang, Z., Wang, X., Jia, L., Zhang, X., and Man, W.

(2012). Study on data security of cloud computing.

In Engineering and Technology (S-CET), 2012 Spring

Congress on, pages 1–3. IEEE.

Wang, B. Y., Ming, J., Zhang, S. M., Jiang, H., and Luo, H.

(2014). An access control method based on cp-abe and

abs algorithm in cloud storage. In Applied Mechanics

and Materials, volume 644, pages 1919–1922. Trans

Tech Publ.

Wang, C., Ren, K., Lou, W., and Li, J. (2010a). Toward

publicly auditable secure cloud data storage services.

IEEE Network, 24(4):19–24.

Wang, G., Liu, Q., and Wu, J. (2010b). Hierarchical

attribute-based encryption for ﬁne-grained access con-

trol in cloud storage services. In ACM CCS’10, pages

735–737.

Ylonen, T. and Lonvick, C. (2006). The secure shell (ssh)

authentication protocol. RFC 4252, RFC Editor.

Yu, S., Wang, C., Ren, K., and Lou, W. (2010). Attribute

based data sharing with attribute revocation. In Pro-

ceedings of the 5th ACM Symposium on Information,

Computer and Communications Security.

Zhang, G., Yang, Y., Zhang, X., Liu, C., and Chen, J.

(2012). Key research issues for privacy protection

and preservation in cloud computing. In Second Inter-

national Conference on Cloud and Green Computing,

CGC’12, pages 47–54.

Zhao, F., Nishide, T., and Sakurai, K. (2011). Realizing

ﬁne-grained and ﬂexible access control to outsourced

data with attribute-based cryptosystems. In Interna-

tional Conference on Information Security Practice

and Experience, pages 83–97. Springer.

SECRYPT 2017 - 14th International Conference on Security and Cryptography

500
