Context-based Encryption Applied to Data Leakage

Prevention Solutions

Pilar Holgado

, Alberto García

, Jose Javier García

, Jorge Roncero

, Víctor A. Villagrá

and Helena Jalain

Departamento de Ingeniería y Sistemas Telemáticos, Universidad Politécnica de Madrid,

Avenida Complutense, 30, 28040, Madrid, Spain

Nokia, Departamento de Innovación, Calle de María Tubau, 9, 28050, Madrid, Spain

Keywords: Data Leakage Prevention, Context-based Encryption.

Abstract: Data leakage pose a serious threat to companies as the number of leakage incidents and the cost continues to

increase. Data Leakage Prevention (DLP) has been studied to solve this information leakage. We propose a

DLP solution applying context-based encryption concept, thus sensitive files are encrypted at all time. The

cipher key is obtained through the execution of challenges based in the environment context and the

company policies. In this paper, we explain the architecture and the design of our DLP system and the

proposed challenges.

1 INTRODUCTION

Nowadays, many companies deal with sensitive data

including intellectual property, financial information

or users information. Accidental or unintentional

distribution of private data to an unauthorized entity

is a serious issue for companies. The potential

damage of a data leakage can include reputation,

exposure of intellectual property to competitors, or

loss of future sales.

In the data leakage context, the attacker may be

an internal employee or an external attacker

attempting to leak sensitive information. It can be

caused not only by malicious intent, but by an

inadvertent mistake. In addition, an authorized user

is not the same as a trusted user. In many cases

organizations are victims of their own employees

who intentionally share confidential data with

external persons for personal purposes (Abbadi and

Alawneh, 2008). In this case, the user is authorized

to access to sensitive information and it is no

detected from classic external measures such as

firewalls.

Data Leakage Prevention (DLP) (Raman,

Kayacik and Somayaji, 2011) aim to keep

confidential information secure, preventing potential

data leakage or unauthorized information disclosure.

These solutions can be characterized according to a

taxonomy that incorporates the following attributes

(Shabtai, Elovici and Rokach, 2012): data-state,

deployment scheme, leakage handling approach and

action taken upon leakage. However, data leakage

and data misuse are considered an emerging security

threats to organizations, especially when carried out

by insiders. In many cases, it is very difficult to

detect insiders because they misuse their credentials

to perform an attack.

In this paper, we propose a DLP solution based

on an encryption/decryption process of confidential

documents where the cipher key is obtained through

the execution of challenges. These challenges use

the environment context and the company policies in

the encryption/decryption time. In this way,

sensitive files are encrypted at all time and can only

be read within our DLP system.

The rest of this paper is organised as follows.

Section 2 outlines the current state of art in context-

based encryption. Section 3 explains our DLP

system using context-based encryption. Proposed

challenges are explained in Section 4. Section 5

describes the key generation from challenges results.

Finally, final remarks obtained during this study are

included in Section 6.

566

García, A., Moro, A., García, J., Roncero, J., Villagrá, V. and Jalain, H.

Context-based Encryption Applied to Data Leakage Prevention Solutions.

DOI: 10.5220/0006475205660571

In Proceedings of the 14th International Joint Conference on e-Business and Telecommunications (ICETE 2017) - Volume 4: SECRYPT, pages 566-571

ISBN: 978-989-758-259-2

2 CONTEXT-BASED

ENCRYPTION

Some researchers have proposed attribute based

encryption (ABE) method and access controls for

data privacy. ABE can be divided by two types,

called KP-ABE (Key Policy Attribute Based

Encryption) and CP-ABE (Cipher text Policy

Attribute Based Encryption).

On the one hand, in KP-ABE each data has

attributes (such as Name, Position or Place) and the

users have keys based on an access tree that can

distinguish attributes. For example, in (Goyal et al.,

2006) each user’s key is associated with a tree-

access structure where the leaves are associated with

attributes for encryption with fine-grained access

control in applications such as sharing audit log

information.

On the other hand, CP-ABE can control the data

access from an access tree included in each

ciphertext. The methodology proposes in (Waters,

2011) allows any encryptor to specify access control

in terms of any access formula (equivalently tree

structures) over the attributes in the system. This

access formula can be expressed in term of a Linear

Secret Sharing Scheme (LSSS) and the access

control included several LSSS in a matrix. However,

LSSS matrices are much less intuitive to use when

compared with other approaches such as boolean

formulas or access trees. To address this problem, in

(Liu, Cao and Wong, 2010), it is proposed a new

algorithm which, in addition to AND and OR gates,

can directly support threshold gates, and obtain

much smaller LSSS matrices

Similarity, the user attributes have to satisfy the

boolean formulas or access tree conditions in both

KP-ABE and CP-ABE methods. Our proposed

encryption architecture is not based on any access

structure for data protection but we control data

access through several complex challenges that

return correct sub-keys related to environment

context.

Jungyub Lee et. al. introduce the context-based

encryption term in IOT (Internet of Things)

scenarios (Lee, Oh and Jang, 2015). They claim that

contexts related with user or device can be used as

an attribute of data when data was encrypted in an

ABE schema. The contexts are extracted by the

detection method based on the user’s situations. In

the same way, we use context-based encryption for

data privacy but applied to a DLP architecture.

J. Al-Muhtadi et. al. propose context and

location-aware encryption for pervasive computer

environment (Al-Muhtadi et al., 2006). Specifically,

they use a node’s location to authorize access to a

resource. Furthermore, the material is stored in an

encrypted fashion, and can be aggregated and

decrypted only when the requestor entity is at the

correct location or under the correct context. The

administrator sets up the spatial region(s) in which

data access is authorized. Each region pre-calculates

and storage a key based on the location context. This

method need use certificates to establish user

sessions for the authorize access process in the

server. Furthermore, the data is sent between

Location Service and the file system of the client. In

contrast, our proposal does not need asymmetric

cryptography or sessions management because it is

very difficult that the attacker knows the correct

context parameters for a specific file. Also, the data

always remain in our encryption file system and is

not transmitted.

In our proposal we apply this concept of users

context, such as their location to make these

parameters part of the key that will give access to an

encrypted file. We execute several context

challenges in the encryption/decryption time without

storing any key or sub-key in a persistent form.

Thus, if that specific context is not met, the

generated key will be incorrect and the file could not

be decrypted.

3 CONTEXT-BASED

ENCRYPTION APPLIED TO

DLP

The design of our DLP system is based on context

data for the encryption/decryption of sensitive data.

The proposal pretends to use, not only the traditional

user’s information such as his username or his

employment, but also include the device context as

the current date, GPS location, and so on. The file

encryption/decryption is possible if the context has

not changed when DLP system performs both

processes, for example, users are working within the

same hour interval, in the same place, etc. Thus, the

cipher/decipher key is context-based based on the

execution of multiple pieces of code called

challenges. Each of these challenges generates a

sub-key based on a specific context to obtain the

final cipher key.

This kind of context-based encryption is

appropriate for a DLP tool since a user, who can be

authorized but not trusted, will only have access to

the data when the context corresponds to the policy

Context-based Encryption Applied to Data Leakage Prevention Solutions

567

of the company. Otherwise, the encipher/decipher

key will be wrong.

Figure 1: DLP tool architecture with server.

The architecture (Figure 1) is composed of a DLP

tool and a External Server, which executes remote

challenges and performs user authorization process.

The calculation of the challenges-based sub-keys

in external server make the system more secure

since a potential attacker trying to break the data

should manipulate also that external server.

Furthermore, executing remote challenges help to

save some battery if the DLP tool is running in a

mobile device. The server is an HTTP server

implemented by an API-REST. Furthermore, the

database stores context policies established by an

administrator.

The DLP tool will generate the cipher/decipher

key with every single sub-key returned by the local

challenges and the remote challenges.

Figure 2: Flow between DLP tool and the server.

In Figure 2, we can see this behaviour in detail. The

DLP tool sends a request to the server with some

context information of the user for the remote

challenge that wants to execute. The External Server

receives this request and executes the desired remote

challenge, accessing the database to obtain the

parameters established by an administrator. Finally,

the server sends back the sub-key(s) calculated in

JSON format.

4 CHALLENGES

Challenges are different mechanisms to calculate

sub-keys needed in our symmetric encryption

process. Each challenge is related to a particular

environment context parameter. It should be noted

that the remote challenges in both the encryption

and the decryption processes are the same, so it is

not necessary to make different requests to the

server. In the following subsections the proposed

remote challenges are explained in more detail.

4.1 GPS Location Challenge

In this case, the challenge limits access to

confidential files in all places that are not bounded

within a geolocation area delimited by the system

administrator and included in the database using two

parameters:

 Geographical coordinates of the centre of the

allowed area. For example, the centre of the

office building.

 The area to be covered is circular, so the

server only storage the radius of the circle to

cover per system.

When a device needs to encrypt or decrypt a file

it makes a POST request to the server with the

geographical coordinates in which it is. First, the

challenge using the radius and the centre stored by

the manager, calculates the four points of the circle

whose latitudes are higher and lower (that is, the

minimum and maximum values of latitude that can

be given in all points of the interior of the circle) and

checks which is the common part between the

points. For example, the latitude points 3.4567º and

3.4589º have in common the 3.45º part. In other

words, they have in common the first 3 digits of the

coordinate. This process would be done for both

latitude and longitude, obtaining the number of

invariant digits in each of them, generating two

variables that contain the number of invariant digits

in each of the dimensions of the area. Whenever you

access from within this area, you get the same sub-

key for a particular file, while outside it, a random

and invalid sub-key value is returned.

4.2 Date Challenge

Date challenge limits data access according to

specific date range, such as being able to decrypt

files whether the date lie within the framework of

the project definition. This challenge could be

solved locally, but changing the date in a device is

very easy.

SECRYPT 2017 - 14th International Conference on Security and Cryptography

568

Our design is based on a mask that marks the

valid month range established by the administrator

in the database, as is done in IP addressing. If we

perform an operation of type Month AND Mask

using a given Mask, then we always obtain the same

key when the Month is in the correct range. To do

this, the fortnights of each month will be binary

coded according to their order, so that the months

close to each other share the largest number of

possible bits to be able to use the mask and that

different date ranges can be implemented. Therefore,

to encode the 24 fortnights in a year, we must use 5

bits (at least). A possible encoding would be (for

fortnights): January (00000, 00001), February

(00010, 00011)...

Once the fortnights of each month have been

coded, we can assign different masks depending on

the period of validity of the files. For example, the

Mask 11111 is represented a period of a fortnight

from the creation date of the file and the Mask

11100 correspondig to 2 months. Furthermore, we

take into account the day and the year of creation

date of each file. Thus, the key is calculated using

the current year and a offset as the day value in the

encryption/decryption time.

When the client encrypt/decrypt a file, the POST

request to the server must include the creation date

of the file as parameter to fixed the range. Then, the

challenge obtains the sub-key based on current date.

4.3 Time Challenge

Time challenge is checking the moment to

encrypt/decrypt a file. In this way, we can limit

access according to the time, such as files access

limited to working hours. This challenge could be

solved locally, but changing the time in a device is

usually very easy.

The administrator includes a strip of time in the

database for each department. We implement this

challenge using a mask that marks the duration of

the valid range of time, as in the date challenge. If

we perform an operation of type Time AND Mask

using a given Mask, then we always obtain the same

key when Time are in the correct range. For this

propose, the hours of the day will be binary coded

according to their order, so that the hours close to

each other share the largest number of possible bits

to be able to use the mask and that different time

ranges can be implemented. That is, every hour have

binary representation, so 24 hours require 5 bits to

be able to encode all the hours.

Once the hours are been coded, we can assign

different masks depending on different time periods.

For example the Mask 11111 is represented a period

of one hour and the Mask 11000 is corresponding to

8 hours.

When the client encrypt/decrypt a file, the server

must include the creation time of the file as

parameter to fixed the range.

4.4 Wi-Fi Challenge

Wifi networks that are within reach of the equipment

can be used to determine the location of the user.

The administrator stores the SSID, the channel and

the minimum power of the Wifi networks configured

to solve the challenge in the database. Thus, we can

determine where the confidential files can be

accessed. The minimum power value is used to

verify that the user is in the specified place, such as

the company building and not on the street at a close

distance.

Once Wifi networks are configured, the device

makes a POST request to the server and sends the

wifi networks within reach. It should be noted that

the device does not know which are the good

networks (to pass the challenge), so it has to send all

wifi networks within reach, and it is the server

which must verify that all the necessary are among

those sent by the device. With each Wi-Fi network

whose existence has been proven, a sub-key chunk

of this challenge will be generated. In this way, if all

the Wi-Fi networks are found, the key will be

generated completely, while if any missing the

generated key will be incomplete and, therefore, will

not be valid to decrypt the file of the device.

4.5 Operator Challenge

If you have a list of telephone operators by country,

you can check the operator of the equipment to find

out which country you are in and thus have another

location parameter. Typically, companies have their

mobile phone service with the same company, so the

operator will always be the same and will be a

condition to be able to decrypt the file.

Thus, we configure the challenge to generate a

key, doing a series of operations with the name of

the operator. That is, with each operator a different

key will be getting.

4.6 Robustness

Once we have all the key challenges calculated,

together they form a complete key which is the one

for encryption/decryption, since each of them by

themselves are useless. To do this, the client device

Context-based Encryption Applied to Data Leakage Prevention Solutions

569

needs an encryption utility or module that will

calculate the final key and encrypt/decrypt the file.

Thus, if an attacker would know a sub-key value or

all sub-keys value, the decryption key would not be

obtained.

Another case is where the attacker has a client

device with our DLP system installed, either by an

insider or external attacker. The main difficulty of

breaking this type of system is that to calculate the

correct key of a file it is necessary to fulfill all the

challenges, since if one is not verified the

corresponding sub-key will be incorrect and,

therefore, the final key as well, i.e. the attacker have

to know the correct values of all context parameter.

On this way, we can avoid that attackers getting

authorization or fake any context parameter obtain

confidential information.

5 KEY GENERATION

The encryption module generates a key for each file

in the client device. The final key must be calculated

from the sub-keys obtained from the execution of the

remote and local challenges, respecting two

indispensable properties: computational efficiency

and collision-resistance. A cryptographic hash

function is a mathematical function that satisfies

these two properties as well as other interesting ones

including generation a fixed size output for any

input size, computacional efficiency of O(n), where

n is the number of bits in the string, unidirectional,

and generation the same output any time it is called

with a same input.

Specifically, the encryption module receives as

inputs the N sub-keys and these are concatenated by

obtaining a single 256 * N bit string. Finally, the

encryption 256-bit key is generated making the

SHA-256 hash of the string. In this way, files that

meet the same parameters for the challenges would

get the same sub-keys and therefore, the same final

key. Furthermore, the algorithm will take into

account a different random value for each file.

6 CONCLUSIONS

Nowadays, data leakage and data misuse are

considered an emerging security threats to

organizations, especially when carried out by

insiders.

In addition, DLP tools in the market have usually

been focused on preventing data leakage from

external attackers and treats their users as trusted

ones. The application of context-based encryption

into a DLP tool is a big step forward to solve this

problem.

Our proposal is based on the execution of several

challenges to obtain the encryption key related to

different environment context parameters. Thus,

only if the authorized users comply with the context

values set by the administrator, the confidential files

are decrypted. This process is carried out in a

transparent way to the user, who is not aware of the

environment context valid for each file.

The definition of more challenges and the

robustness study of the passwords will be included

as future work.

ACKNOWLEDGEMENTS

This work has been partially funded with support

from the Spanish MINECO (project DroneFS), with

code RTC-2015-4064-8 and the Spanish MINETUR

(project CiberNoid) with code TSI-100200-2015-

035.

REFERENCES

Abbadi, I. M. and Alawneh, M. (2008) ‘Preventing insider

information leakage for enterprises’, in Emerging

Security Information, Systems and Technologies,

2008. SECURWARE’08. Second International

Conference on, pp. 99–106.

Al-Muhtadi, J., Hill, R., Campbell, R. and Mickunas, M.

D. (2006) ‘Context and location-aware encryption for

pervasive computing environments’, in Pervasive

Computing and Communications Workshops, 2006.

PerCom Workshops 2006. Fourth Annual IEEE

International Conference on, p. 6--pp.

Goyal, V., Pandey, O., Sahai, A. and Waters, B. (2006)

‘Attribute-based encryption for fine-grained access

control of encrypted data’, in Proceedings of the 13th

ACM conference on Computer and communications

security, pp. 89–98.

Lee, J., Oh, S. and Jang, J. W. (2015) ‘A Work in

Progress: Context based encryption scheme for

Internet of Things’, Procedia Computer Science.

Elsevier, 56, pp. 271–275.

Liu, Z., Cao, Z. and Wong, D. S. (2010) Efficient

generation of linear secret sharing scheme matrices

from threshold access trees.

Raman, P., Kayacik, H. G. and Somayaji, A. (2011)

‘Understanding data leak prevention’, in 6th Annual

Symposium on Information Assurance (ASIA 11), p.

27.

SECRYPT 2017 - 14th International Conference on Security and Cryptography

570

Shabtai, A., Elovici, Y. and Rokach, L. (2012) A survey of

data leakage detection and prevention solutions.

Springer Science & Business Media.

Waters, B. (2011) ‘Ciphertext-policy attribute-based

encryption: An expressive, efficient, and provably

secure realization’, in International Workshop on

Public Key Cryptography, pp. 53–70.

Context-based Encryption Applied to Data Leakage Prevention Solutions

571
