BotWheels: A Petri Net based Chatbot for Recommending Tires

Francesco Colace

, Massimo De Santo

, Francesco Pascale

, Saverio Lemma

and Marco Lombardi

DIIn, University of Salerno, Fisciano (SA), Italy

SIMASLab, University of Salerno, Fisciano (SA), Italy

Keywords: Chatbot, Petri Net, Recommender Systems.

Abstract: Technological progress seems unstoppable: large companies are ready to implement more and more

sophisticate solution to improve their productivity. The near future may be represented by so-called Chatbot,

already present in the instant messaging platforms and destined to become more and more popular. This paper

presents the realization of a prototype of a conversational workflow for a Chatbot in tires domain. The initial

purpose has focused on the design of the specific model to manage communication and propose the most

suitable tires for users. For this aim, it has been used the Petri Net. Finally, after the implementation of the

designed model, experimental campaign was conducted in order to demonstrate its enforceability and

efficiency.

1 INTRODUCTION

Make a Chatbot that can be as close and similar to a

human being, today is a very important challenge,

both as regards its possible applications, especially

web and social, both for its use in the research scope.

One of the biggest problems is to try to make it look

like the Bot as close as possible to a human being.

There is the propensity of persons to give more

listening to a person rather than to a robot: it is

because in some way, since the people used to talk to

each other, it is difficult to interact with an automaton,

both because a robot does not always behave during

a natural dialogue as we expect. In research fields, the

issue of Chatbot and Bot in general has been

discussed for many years, although it has seen an

increasingly gradual slowdown in recent years. This

is due in part to the inherent difficulty of the same,

both since it is very difficult to appropriately describe

the evolution of a discussion, without making the

appropriate considerations and upstream reflections.

In fact, the amount of investment by companies in

trying to create a Bot as similar to an operator is

growing (Casillo et al., 2016). Indeed all the major

social platforms have now integrated this service and

offer the ability to customize and then to map the

conversations between a bot and a user. This happens

because the company generally considers it.

Currently the technology limits, however, prevent

existing Chatbot to have good performance since the

bottleneck is that generally a user during a

conversation is unpredictable. As seen from the

Turing test to be able to assume that a machine can be

like a man, it is important that this more than five

minutes of talk time. This means that the

conversational flow plays an important role in to the

project of a Chatbot. To create and manage the

workflow of a Bot appears to be today one of the main

objectives, because the existing systems are not

always responsive given a user input, and often fail in

the recognition and processing of user-written

sentences. The main aim of this paper is to describe a

software module prototype, called workflow

manager, who is responsible for the management of

the flow of conversation between a Chatbot and a

user, applied at a real case. Our case study concerns a

Chatbot, called BotWheels, which will serve for help

the choice of tires to buy. After an analysis on the

state of art, we have realized the general pattern of

operation of the bot and then using the Petri Nets, we

have realized the workflow model. Finally, it was

conducted the experimental phase that has

highlighted the strengths and weaknesses points of

the Bot. In the next section, the related works are

presented.

2 RELATED WORKS

One of the biggest problems on Bots always has been

to be able to understand, in a sentence uttered by a

350

Colace, F., Santo, M., Pascale, F., Lemma, S. and Lombardi, M.

BotWheels: a Petri Net based Chatbot for Recommending Tires.

DOI: 10.5220/0006491903500358

In Proceedings of the 6th Inter national Conference on Data Science, Technology and Applications (DATA 2017), pages 350-358

ISBN: 978-989-758-255-4

person, his/her intent, that is what our user is asking

the automaton. The usually used approach is to create

an ontology of reference, in which inside there is

mapped throughout the domain of knowledge.

Already from this observation, you can understand

how the definition of the correct reference ontology

is fundamental to the proper functioning of Bot. From

this, it is possible to extrapolate the object of which

you are speaking with Latent Semantic Analysis

(LSA) algorithm. To observe how very similar thing

was done, it is possible using LSA, the conversational

skills of an agent has been improved. It is therefore

possible to identify in this way the topic of the

conversation and structure a dialogue flow (Pilato et

al., 2007). Another important work shown how is

possible implement a dialogue management

mechanism through formalisms and finite state

machines. It shows how now one of the issues of

greatest interest and critical problem has been to

develop a model of the discussion flow between

human and robot (Kronlid and Lager, 2007).

In the last times, there have been some interesting

works that worth mentioning. An important work

presents how the interaction between man and some

Chatbot present on the internet in order to make a

classification and to verify the actual efficiency

(Gianvecchio et al., 2011). This was done analyzing

the conversation log between Bot and users through

log-based classification, that unlike Turing test, it

differs for the duration and for the comparative

metrics of the discussion (e.g. length of sentence and

delay between question and answer). A case study,

where the relations are between users and their

messages, was shown in another work (Gligorijevic

et al., 2012). One of the first prototypes of Chatbot for

social networks was developed in last recent times.

The critical point remains, as noted earlier, the

workflow management. In this case, an algorithmic

approach is used and it provides for a very flexible

management of the conversation (Rodrigo et al.,

2012). Last times was improved a tool to describe a

Chatbot conversational model, which extrapolating

certain keywords from texts on Wikipedia and it is

able to take on a particular conversational lexicon

based on training (Haller and Rebedea, 2013). In

recent times, the greatest efforts have focused on

trying to create a robot that could be as much as

possible like a human: the dialog flow plays a

fundamental role in the modeling of a Chatbot. For

describe a model that helps the Bot to maintain

conversations with people through the development

of natural language, was improved a software tool

(Ravichandran et al., 2015). All this was achieved

through a conversational Flow Chart, which describes

the operation that occurs through the activation of

appropriate responses based on input. Another

example is a self-learning Chatbot model, through

user-entered phrases. This system carries out the

matching of new constructs: a POS-tagged tokens

system performs the matching of phrases, then makes

an assessment of the correct answers and finally all

mated sentences are been analyzed (Bang et al.,

2015). An improved version of AluxBot software was

developed, which is a Chatbot developed in Visual

Basic with integration of speech recognition of OS

Windows (Peniche-Avilés et al., 2016). AluxBot is

focused on promoting the care of the environment and

sustainable development for school children, in order

to provide an alternative use of new technologies. It

can be possible observe a particular architecture of a

Chatbot prototype used without a server platform, in

which all the necessary features are implemented on

the inside, without the need to request external

services (Yan et al., 2016). Another example is a Bot

to Bot system that it can write controlled applications

by voice using the natural language processing and

robotic control in order to make the voice command

of a user and translate it into a structured intent for the

robot (Fischer et al., 2016). Furthermore, it is possible

to instruct the robot via a Chatbot, which is

responsible for providing input the desired command.

Another usefully study is on the usefulness of

ontology-based Chatbot technology to the design of

intelligent agents for medical diagnosis (Edwards et

al., 2016). It is apparent from this study the need for

a technology to support the diagnosis, which can not

be separated from the use of medical information of

the patient, such as his/her clinical record and his/her

medical history, which will be needed for a higher

quality for interaction with the Chatbot. The system

also should be regularly trained to stay updated. A

very interesting case of study present a teaching

Chatbot assistance, named CS 221, for students,

where the system classifies any question under three

aspects: Policy, Assignment and Conceptual

(Chopram et al., 2016). The union of the classification

of the three types provides the answer to make on

output. Finally, another important work is a Chatbot

model created by IBM and named Curious Cat: it is a

crowdsourcing model that guides the user to provide

information of interest, using a base of existing

knowledge, and helps him/her in the process

acquisition, requesting coherent questions and

checking the answers (Bradeško et al., 2016).

BotWheels: a Petri Net based Chatbot for Recommending Tires

351

3 MODELING AND

FORMALIZATION

In order to model and formalize the flow of execution

of a Chatbot on more possible contexts (Colace et al.,

2016), evaluating what today is present in research, it

was analyzed the point of view of the individual

conversation atom between human and the

automaton. In fact, a conversation can be seen as a

succession of user's questions/answers and

questions/answers of the automaton. It has been

mapped the single interaction in order to determine

what are the topic in question, at a particular time, and

what are the attributes of the argument on which the

automaton will have to ask a question or give an

answer. It allows to be able to model in a general way

a possible operation of Chatbot, regardless of its

actual realization, and to formalize the problem

analytically.

Through the analysis of the sentence obtained from a

semantic engine, which extrapolates the intent (e.g.

tire change) and its associated attributes (e.g. height,

width, diameter), it is possible to think about

modeling, starting from a predetermined context (e.g.

tires), any sentence during a conversation with two

fundamental information:

• TOPIC: what we are talking (1 word)

• TAG: the topic attributes (N words)

This pair of information then constitute the current

ITEM of information concerning the sentence

considered. Then it can be defined the two bounded

sets:

• A: finite set of topics

• B: finite set of tag

T is defined as a Cartesian product of A and B: T = A

x B. C is a subset of A x B, that is defined as all

possible items of possible conversation, in a given

context and intent.

⊆ ∀ →  +  (1)

where Co is the context and I is the intent.

It is possible to have multiple tags for topic but no

more topic for tag. This means that the topic must

always be one.

This helps to define a priori, in current context and

with a specific intent, all the inputs of all interactions

that Chatbot can capture and can give an answer or

question depending on the requirement. Therefore is

possible to use a logic model to be able to describe

the dynamic operation for the single interaction.

It is possible to treat the finite state machine model,

in particular the Mealy machine, that is a sextuple, {S,

S0, Σ, Λ, T, G}:

• finite set of state (S)

• an initial state S0, that is an element of (S)

• a finite set called the input alphabet ( Σ )

• a finite set called the output alphabet ( Λ )

• a transition function (T : S × Σ → S)

• an output function (G : S × Σ → Λ)

In general, the Mealy machine is a finite state

automaton whose output values are determined by the

current state and input; unlike the Moore machine,

that works only in the current state function. An

example of Mealy Machine model is reported in the

figure 1.

Figure 1: Example of Mealy Machine.

Through this model, it can be possible obtain the

logical model of human-robot interaction.

Considering the single interaction, there are two

states: Si state, where the user provides in input a

proper conversation item, and Si+1 state, where the

available information will update and the automaton

will provide a response or an answer. The outputs are

calculated according to the inputs and the previous

state. The inputs are the items of the current

conversation (user's response or answer); the outputs

will be the actions to be taken. Into the state the item

of conversation will be preserved in the previous

Figure 2: General Model of Finite State Machine for two

states.

KomIS 2017 - Special Session on Knowledge Discovery meets Information Systems: Applications of Big Data Analytics and BI -

methodologies, techniques and tools

352

point so that they can process the correct next action.

The outputs depend on the current input and the

previous state, which means that for each item of the

current conversation, and since the previous state, it

must map the appropriate output (answer/question) to

be provided.

Remembering that at every item of conversation can

have only one topic, which must have a finished

number N of tags, is important to consider two things:

a topic change involves a change of information

(tags) to be requested, and it can not have two items

in the same topic. In fact, at every step of the

conversation, the automaton must update the

information on the current state (TOPIC + TAGS)

and then, according to these, gives the appropriate

output (REQUEST/RESPONSE).

Defined K as the number of finished levels of

interaction for which, given topic of interest, it is

possible to produce a final output of conversation and

describe the operation of the machine in this way:

∑

Σ



=





(2)

where S is the current state, Σ is the set of the input

alphabet Σ = C ⊆A x B, Λ is the set of output

alphabet. This means that it can be defined the level

of items according to their specific weight within our

workflow. According to this concept, this definition

can be extended by a finite state machine with Sn

states that represent the current state with respect to

the user and Sm state that represent the current state

with respect to the automaton. A general model of

Finite State Machine for N state is reported in the

figure 3.

Figure 3: General Model of Finite State Machine for N

states.

4 BOTWHEELS: WORKFLOW

MANAGER DESIGN

The design of BotWheels’s Workflow Manager was

divided in two phases: in the first place, it is provided

to define a model able to explicitly describe and

represent the considered knowledge domain (tires). In

the second place, the purpose was to define a

workflow module that was able to navigate the

reference model realized in the first step, in order to

maintain a logical discourse with the user and to

generate a flow of operations that would allow to

identify the most appropriate output. Therefore, the

first aim has been to build an ontology, shown in

figure 4, to describe the reference taxonomy. The

advantage of this approach is to be able to represent

concepts, properties, attributes and constraints of the

one part and of the other part a reference model for

the workflow. The general data structure of a

common ontology is a directed graph whose nodes

represent concepts and its links represent the relations

between these. The root may have several

descendants: in this work, it can be considered the

child pneumatic concept. It has several children

including the vehicle node, whose descendants are the

cars and motorcycles node, and the node size. Each of

these nodes presents, in turn, determined descendants.

A choice of this type has been effected because,

generally, to find a specific pneumatic, must be

indicated in detail the characteristics of the vehicle or

the size of the eraser.

Then, the ontology allows to achieve a knowledge

and the links between concepts (for example, we can

see that we have various types of vehicles or that the

concept of car is made up of the attributes of the

brand, model, version and year).

Figure 4: Reference Ontology.

The next goal was to provide a reasoner that can

access in a reference ontology and that it was able to

generate and follow a consistent and efficient

workflow, defined by a sequence of steps. The

conversational module then must be able to navigate

autonomously the ontology, moving through the

concepts relationships.

The selected model is the Petri Net (figure 5 and

figure 6), because it lends well for this kind of

applications. This model is composed of a set of basic

BotWheels: a Petri Net based Chatbot for Recommending Tires

353

objects: places, transactions and arcs, graphically

represented by circles, rectangles and oriented lines.

The first aspect relates to the identification of the

user's intents by BotWheels: it is necessary in practice

to understand what he/she is interested. Various

options are considered, including changing tires, the

workshop nearest search and request for information.

• In particular, the conversation begins through

the activation of the transition "start

conversation", then the system asks the intent

(“ask intent” transition) as long as it is not

understood; below, after obtaining the intent

(“get intent” transition), through “ask vehicle”

transition, system will be asked to user the

vehicle (car, motorcycle, etc...).

• Assuming it has been identified the intent of

wanting to change the car tires, it can begin the

process of tires recommendation for car: the

system will randomly ask general information

on the car or the tire size, activating the “ask car”

or “ask tire” transition. Obtained an answer, “get

response for cars” or “get response for tire size”

transition is activated.

• If it is aware of the brand and model, “get car”

transition is activated, and then it can be

possible to ask later the car version and year; as

well as if it is aware of the width, height and

diameter, the transition “get size” is activated,

requiring later load and speed.

• Finally, “get tire from car data” or “get tire from

tire data” transition is activated only when the

system will have obtained all the information

(brand, model, version and year) or the context

of the tire (width, height, diameter, load and

speed). Obtained result will be represented from

one or more tires that correspond at the research

done, based on the data provided.

• The result obtained can then be further filtered

based on optional parameters, such as the

season, in order to activate “recommend tire”

final transition.

• The transition ends the conversation is activated

and the conversation ends.

The most delicate initial aspects to consider are as

follows:

1. Controls relating to the information that the user

communicates;

2. The next question that the system will has to

make;

3. Any flow of communication changes.

For this purpose, the monitor places were used, which

are a control structure of the system evolution:

recording some events, commanding the other

eligible events and by disabling other.

1. In detail, monitor places related to car context

(brand mp, car_model mp, version mp, year mp)

and to the dimension context of tire (width mp,

height mp, diameter mp, load mp, speed mp)

have been defined: they tell what information of

the context the system knows.

For example, in the case where the system has

requested information on the car and the user

has provided the brand (brand monitor place

fills with a token), “get car” transition could not

enabled, having the need to know also model;

information that the system will require.

Obtained this information (model monitor place

fills with a token), the transition is activated and

the system will prompt version and year. Also

received these information, “get tire from car

data” transition is activated.

The monitor places may be filled by direct

method and indirect method. In the first case, a

determined monitor place is filled directly

following an explicit user response, for example

relative to the car model. A monitor place can be

filled indirectly also, if for example, the user

provides the model and can be traced back to the

brand in that, in the ontology of reference, there

is a single association: in this case, also brand

monitor place will be filled.

For example, the user provides Panda model,

can be traced back to FIAT brand.

2. To determine which question the bot will ask the

user, we have considered the monitor places in

a denied context, graphically defined by an

underline name. For example, for car denied

context, a token in MODEL MP indicates that

the system does not know the car model.

For example, when the user has already

provided the brand of his/her car, BRAND MP

will be filled and “ask brand” transition will not

be active. Instead, BRAND MP of the car

context will be filled and consequently “ask

model” transition will be active. Obtained brand

and model, “get car” transition is enabled;

VERSION MP and YEAR MP are filled and

subsequent transitions to enable will be “ask

version” and “ask year”.

3. When the weighted sum of the missing

information on the total of a context is smaller

than the current value, there is a change context.

Suppose the user after providing the car brand,

gives information about the height, width and

diameter tire; there is a change of context from

the current context C (drive) to another context

N (size) because the weighted sum of the

missing tokens of N on total - the product of the

KomIS 2017 - Special Session on Knowledge Discovery meets Information Systems: Applications of Big Data Analytics and BI -

methodologies, techniques and tools

354

weighted sum of monitor places null for the

number of monitor places null divided by the

total number of monitor places in N- is less than

the weighted sum of the missing tokens of C.

When this condition occurs, the monitor place

of context switch is enabled, in the specific case,

Context_Dimension MP: it allows to transfer the

tokens by brand / model / version / year in height

/ width / diameter / load / speed allowing the

change of the communication flow for the new

context. In this case, the monitor places related

to the height, width and diameter will be

occupied by its token: “get size” transition can

be turned on and the system will have to ask the

load and speed. When user has provided this

information, “get tire from tire data” transition

is enabled.

Analytically, it must check the following

expression:



∑ᵢ





∗







∑ᵤ





∗





(3)

where MPN N and MPN C are the monitor

places null of N and C; MP N and MP C are the

monitor places total of N and C; α and β

represent the weight associated to a specific

question of monitor place null, of N and C.

A context switch can also occur due to a situation of

context stall, when the tokens of a place in that

context and the related monitor places are equal to

zero.

• Following a context stall, there is a change of

context or a reactivation of context.

• If all contexts are stalled, the system does not

have minimum information to produce a result.

Following the resolution of the listed problems, the

goal was to handle situations such as those in which a

value is unknown or in any case is not provided, and

the cases in which the user updates the values of the

current context.

For this purpose, we inserted a maximum (equal to 1)

to the number of tokens that may be present in brand,

model, version and year places, as well as diameter,

width, height, load and speed places. This allows the

system, in normal situations, to request a question for

the user only once.

In special situations, it can be possible a context

reactivation current that allows to "recharge" the

tokens present in the places indicated.

In particular, to have a context reactivation (first

level) of current context if occurrence a deadlock, (1)

the current context has more tokens of the context to

the previous state, or (2) is identical to the previous

context but we have a greater number of tokens in the

optional context, containing the monitor places for

the information considered optional, as the season or

rubber speed.

• For example, initially the user provided

information about the car brand. Later, when the

system asks the model, he/she returns the car

information. In this case, we will have a deadlock

since model monitor place and model place are

null. The current context (2) it has more tokens of

the context to the previous state (1), we will have

a context reactivation (first level) that will allow

to recharge tokens of brand / model / version /

year, allowing the system to request the model at

the user.

• A similar situation is in the case of the question on

the model, the user responds by providing

optional information, additional to those already

present.

The design approach enables to set a limit to the

number of times in which the system will ask certain

questions, thus avoiding loops in situations of

information not provided and / or unknown.

It is possible to have a context reactivation of second

level: it occurs when, starting from a change of value

of one or more information, the number of tokens in

that context is less or equal to the number of tokens

in the same context to the previous state.

• Suppose that the user has provided brand and

model of car, FIAT and Panda respectively. The

system asks about the year of the car and user

answers TOYOTA.

Every monitor place is correlate at data JSON object

representing the context, we are aware that there has

been a value change of two information. The number

of tokens in the current context (equal to 1) is less

than the number of tokens in the same context to the

previous state (equal to 2): we have, therefore, a

context reactivation of second level. It follows that,

since the only occupied monitor place is the brand,

the system will ask model.

Finally, it was analyzed the case in which information

is not mandatory for the purposes of obtaining a

result. An example is “select season” transaction. It is

activated with enabling of “get tire from car data” or

“get tire from tire data” transaction: a particular

choice allows to enable “recommender tire”

transaction and then further filter the results

previously obtained, while a lack of response from the

user does not affect what has already been obtained.

•

Examples of optional information are the season

or the tire data. The relevant questions are asked

when it does not know the answers (and then

observing the optional context denied).

Finally, some experimental are discussed in the next

chapter.

BotWheels: a Petri Net based Chatbot for Recommending Tires

355

Figure 5: Petri Net of BotWheel’s Workflow Manager (Part I).

5 EXPERIMENTAL RESULTS

For evaluating the performance of the proposed

system an experimental campaign has been

developed. In particular, the aim of the

experimentation has been the evaluation of the system

effectiveness in the recognition of the users’ requests.

In addition, the usability of the system has been

evaluated. An implementation of the Chatbot has

been developed and inserted in a Web Site of a tires

seller. At the end of the chat session, an email with

the suggested model tires has been sent to the

potential customer. The email, showed in the store,

guaranteeing a 5% discount on tires’ price. In this

way, it was possible to check whether the tires

suggested by the system were right for the car and the

needs of the customer. In two months about five

hundreds potential customers (identified with the

email address) used the Chatbot and 173 of them

showed the email in the store and bought tires. The

experimental analysis has been conducted about these

173 customers. First of all the performance of the

Chatbot in providing the correct suggestions to the

user has been evaluated. In particular, three different

situations has been considered:

• Chatbot furnishes a correct suggestion

• Chatbot furnishes a correct suggestion, but it

does not fit with the real needs of the customer

• Chatbot furnishes a wrong suggestion

The obtained results are the following Chatbot

furnished the following results:

A) Correct Suggestion: 113 - 65,32%

B) Correct Suggestion, but not suitable for the

needs of the customer: 24 - 13,87%

C) Wrong Suggestion: 36 - 20,81%

Analyzing the Wrong Suggestion case, we noticed

that the system fails when customer talks about a

model that have various versions because it proposes

tires of different dimensions. Another critical aspect

occurs when the system does not understand what

kind of vehicle the customer is considering. It

happens, for example, when it is not clear if we are

considering a car or a motorcycle produced by an

automotive group. In the case of Correct Suggestion,

but not suitable for the needs of the customer the main

problem is in the identification of the real user needs.

For example, when the customer says that works in a

snowing city but lives in city on the sea the system

fails to identify the correct tires. From the point of

view of the usability a questionnaire about his/her

interaction with the Chatbot was submitted to each

customer. In general, they find the Chatbot easy to use

and user friendly. Comparing it with other Chatbot

(for example Telegram Chatbot or similar) customers

says that BotWheels is more simple and effective.

KomIS 2017 - Special Session on Knowledge Discovery meets Information Systems: Applications of Big Data Analytics and BI -

methodologies, techniques and tools

356

Figure 6: Petri Net of BotWheel’s Workflow Manager (Part II).

6 CONCLUSIONS

In this paper, an original approach to a Chatbot has

been introduced. In particular, the proposed system is

based on the Petri Net formalism. A real case has been

investigated developing a Chatbot, BotWheels, for a

tires’ seller. The results obtained by the experimental

campaign are satisfying and show the good

perspective of this kind of approach. Further

developments involve the application of the proposed

approach in various contexts and an improvement of

the recommender approach.

REFERENCES

M. Casillo, F. Colace, S. Lemma, M. Lombardi, and A.

Pietrosanto, “An Ontological Approach to Digital

Storytelling,” In Proceedings of the The 3rd

Multidisciplinary International Social Networks

Conference on SocialInformatics 2016, Data Science

2016 (p. 27). ACM, 2016.

G. Pilato, A. Augello, G. Vassallo and S. Gaglio, “Sub-

Symbolic Semantic Layer in Cyc for Intuitive Chat-

Bots,” International Conference on Semantic

Computing, 2007.

F. Kronlid and T. Lager, “Implementing the Information-

State Update Approach to Dialogue Management in a

BotWheels: a Petri Net based Chatbot for Recommending Tires

357

Slightly Extended SCXML,” Proceedings of the 11th

International Workshop on the Semantics and

Pragmatics of Dialogue (DECALOG), 2007.

S. Gianvecchio, M. Xie, Z. Wu, and H. Wang, “Humans

and Bots in Internet Chat: Measurement, Analysis, and

Automated Classification,” IEEE/ACM Transactions

On Networking, Vol. 19, No. 5, 2011.

V. Gligorijevic, M. Skowron and B.Tadic, “Directed

Networks of Online Chats: Content-Based Linking and

Social Structure,” Eighth International Conference on

Signal Image Technology and Internet Based Systems,

2012.

S. M. Rodrigo, and J. G. F. Abraham, “Development and

Implementation of a Chat Bot in a Social Network,”

Ninth International Conference on Information

Technology- New Generations, 2012.

E. Haller and T. Rebedea, “Designing a Chat-bot that

Simulates an Historical Figure,” 19th International

Conference on Control Systems and Computer Science,

2013.

G. Ravichandran, N.M. Reddy and G. S. Shriya, “dBot: AI

Based Conversational Agent,” International Journal of

Science and Research (IJSR) ISSN (Online): 2319-7064

Index Copernicus Value (2015): 78.96 | Impact Factor

(2015): 6.391.

J. Bang, H. Noh, Y. Kim and G.G. Lee, “Example-based

Chat-oriented Dialogue System with Personalized

Long-term Memory,” International Conference on Big

Data and Smart Computing (BigComp), 2015.

J. Peniche-Avilés, C. Miranda-Palma, L. Narváez-Díaz and

E. Llanes-Castro, “AluxBot - A Chatbot that

Encourages the Care for the Environment,” IJCSI

International Journal of Computer Science Issues,

Volume 13, Issue 6, November 2016.

M. Yan, P. Castro, P. Cheng and V. Ishakian, “Building a

Chatbot with Serverless Computing”, Proceedings of

the 1st International Workshop on Mashups of Things

and APIs, 2016.

M. Fischer, S. Menon and O. Khatib, “From Bot to Bot:

Using a Chat Bot to Synthesize Robot Motion,” The

AAAI Fall Symposium Series: Artificial Intelligence for

Human-Robot Interaction Technical Report FS-16-01,

2016.

B. Edwards, I. Muniru and A. Cheok, “Robots to the

Rescue: A Review of Studies on Differential Medical

Diagnosis Employing Ontology- Based Chat Bot

Technology,” 6 December 2016.

S. Chopram, R. Gianforte and J. Sholar, “Meet Percy: The

CS 221 Teaching Assistant Chatbot,” ACM

Transactions on Graphics, Vol. 1, No. 1, Article 1,

Publication date: December 2016.

L, Bradeško, J, Starc, D, Mladenic, M, Grobelnik, and M.

Witbrock, “Curious Cat: Conversational Crowd based

and Context Aware Knowledge Acquisition Chat Bot,”

IEEE 8th International Conference on Intelligent

Systems, 2016.

F. Colace, L. Greco, S. Lemma, M. Lombardi, D. Yung, and

S.K. Chang, “An Adaptive Contextual Recommender

System: a Slow Intelligence Perspective,” The Twenty-

Seventh International Conference on Software

Engineering and Knowledge Engineering (SEKE), pp.

64-71, 2015

KomIS 2017 - Special Session on Knowledge Discovery meets Information Systems: Applications of Big Data Analytics and BI -

methodologies, techniques and tools

358
