Accurate Continuous and Non-intrusive User Authentication with

Multivariate Keystroke Streaming

Abdullah Alshehri, Frans Coenen and Danushka Bollegala

Department of Computer Science, University of Liverpool, Liverpool, U.K.

Keywords:

Keystroke Time Series, Continuous Authentication, Keystroke Streams, Behavioral Biometric.

Abstract:

In this paper, we demonstrate a novel mechanism for continuous authentication of computer users using

keystroke dynamics. The mechanism models keystroke timing features, Flight time (the time between con-

secutive keys) and Hold time (the duration of a key press), as a multivariate time series which serves to

dynamically capture typing patterns in real/continuous time. The proposed method differs from previous ap-

proaches for continuous authentication using keystroke dynamics, founded on feature vector representations,

which limited real-time analysis due to the computationally expensive processing of the vectors, and which

also yielded poor authentication accuracy. The proposed mechanism is compared to a feature vector based ap-

proach, taken from the literature, over two datasets. The results indicate superior performance of the proposed

multivariate time series mechanisms for continuous authentication using keystroke dynamics.

1 INTRODUCTION

Distance learning (eLearning) and Massive Open On-

line Courses (MOOCs) have witnessed a rapid growth

over the last decade (Clark and Mayer, 2016). Con-

sequently, an increasing number of people are taking

online assessments and exams remotely. As a result,

user authentication has become an issue; is the person

taking the assessment the person who they say they

are? Traditional one-off validation, such as the util-

isation of passwords and usernames (also known as

static authentication (Bours, 2012)) is clearly not suf-

ﬁcient. The challenge is not just how to ensure that the

person is who they say they are at the beginning of the

assessment but throughout the assessment. What is

required is real time continuous authentication rather

than static authentication.

Keystroke dynamics (typing patterns) are a

promising biometric recognition mechanism that can

provide the desired continuous authentication (Bours,

2012). They offer the advantage that no special equip-

ment is required such as in the case of continuous

iris or ﬁngerprint recognition. The idea is motivated

by the observation that keyboard behaviour (typing

rhythm and style) varies between individuals (Gaines

et al., 1980). Keyboard behaviour can be expressed

in the form of patterns made up of keystroke tim-

ing attribute-values (keystroke dynamics) describing

the timing information associated with key-hold times

(K H

) and ﬂight times (F

) (Gaines et al., 1980).

The ﬁrst is the duration of holding down a key; the

second is the time from the ﬁrst key press to the

last key release of n-graphs. An n-graph in this con-

text is a sequence of keyboard characters; if we have

one character this is called a monograph, two charac-

ters a digraph, three characters a trigraph, and so on

(Gunetti and Ruffo, 1999; Ahmed and Traore, 2014).

Much previous work directed at user (keyboard)

authentication using keystroke dynamics has focussed

on Keystroke Static Authentication (KSA) where typ-

ing patterns are extracted from short predeﬁned texts,

for example, passwords or pin numbers, to strengthen

user credentials (Joyce and Gupta, 1990; Monrose

et al., 2002; Killourhy and Maxion, 2009; Syed et al.,

2014). The authentication process utilises keystroke

dynamics to create a feature vector (often referred

to as a typing proﬁle), for example, made up of the

mean and standard deviation of digraph ﬂight times.

Then, given a previously unseen proﬁle, allegedly be-

longing to a certain user, this can be authenticated by

comparing it to a stored proﬁle for the indicated user,

by computing the similarity between the two feature

vectors. The idea of using keystroke dynamic feature

vectors for free text, Keystroke Continuous Authen-

tication (KCA), has also been proposed (Shepherd,

1995; Dowland and Furnell, 2004; Gunetti and Pi-

cardi, 2005; Ahmed and Traore, 2014). This is typ-

ically conducted in the context of speciﬁc n-graphs

Alshehri A., Coenen F. and Bollegala D.

Accurate Continuous and Non-intrusive User Authentication with Multivariate Keystroke Streaming.

DOI: 10.5220/0006497200610070

In Proceedings of the 9th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (KDIR 2017), pages 61-70

ISBN: 978-989-758-271-4

(such as “th”, “ing”, “tion” and so on). The generation

of the desired feature vector (proﬁle), and the conse-

quent authentication, is typically carried out once the

subject has ﬁnished typing.

The feature vector representation when used in the

context of KCA, as described above, has a number of

disadvantages (Ahmed and Traore, 2014). The most

signiﬁcant is the resource required to generate the fea-

ture vectors, which is why authentication is typically

conducted on typing completion rather than in real

time as would be desirable in the context of online

assessment. The reason for this is that a great many

n-graphs need to be considered so as to acquire an

effective typing proﬁle. By increasing the number

of n-graphs to, for example, all digraphs, real time

KCA (while the subject is typing) becomes intractable

given the size of the feature vectors that need to be

generated and compared.

In this paper, a new approach to KCA is proposed

that takes into consideration all keystroke features,

rather than those associated with speciﬁc digraphs,

by considering typing behaviour in terms of a mul-

tivariate time (keystroke) series. More formally, each

keystroke is considered to be a multivariate discrete

(indexed) temporal event (p

) forming a sequence of

multidimensional events {p

, p

,...} where each p

represents the timing information of ﬂight F

and

key-holds K H

timings. The idea is to conduct real

time authentication by continuously extracting subse-

quences of a keyboard usage multivariate time series,

that are representative of typing behaviour and which

can consequently be used for real time KCA. In the

proposed method, the subsequences are extracted us-

ing a non-overlapping sliding window (of length ω).

The real time authentication is conducted by com-

paring the most recent subsequence with the previ-

ous subsequence extracted during the typing session.

Of course, on start up, the subject’s identity needs to

be initially conﬁrmed in a “traditional” manner with

reference to a stored typing pattern. Time series sim-

ilarity was calculated using Dynamic Time Warping

(DTW) (Berndt and Clifford, 1994) which it results

in a warping distance which can, in turn, be used as a

similarity measure.

The main contributions of the work presented in

this paper are as follows. A process for real time KCA

founded on the concept of multivariate time series, as

opposed to the feature vector-based approaches pro-

posed to date, that is independent of keyboard lay-

out. The mechanism is also privacy preserving in that

knowledge of which keys are actually being pressed

is not required. The proposed mechanism, although

intended for use with respect to online assessment,

has general applicability. For example, it may equally

well be used to detect certain human conditions, such

as Parkinson’s disease, as described in (Giancardo

et al., 2016) or to detect keyboard user emotions as

described in (Raja and Sigg, 2016). A further contri-

bution is the novel manner in which typing behaviour

is captured in the form of a multivariate time series

representation. Note also that in the proposed mecha-

nism, other than on start up, there is no requirement to

compare to a “bank”

of user proﬁles for the claimed

user.

The rest of this paper is organised as follows. Sec-

tion 2 reviews the background and the related work

concerning KCA feature representation. Section 3

presents some deﬁnitions, and some preliminaries,

concerning the keystroke multivariate time series rep-

resentation. The proposed KCA process is then in-

troduced in Section 4. The evaluation of the proposed

approach is reported on in Section 5. Finally, the work

is concluded in Section 6.

2 PREVIOUS WORK

As noted in Section 1, most previous work directed

at KCA, although limited, has been founded on the

use of statistical measurements to deﬁne features from

predeﬁned sets of n-graphs (see for example (Dow-

land and Furnell, 2004; Gunetti and Picardi, 2005;

Ahmed and Traore, 2014)).

One of the earliest examples of this approach can

be found in (Dowland and Furnell, 2004) where the

focus was on the most frequent occurring digraphs.

In this case, the created typing proﬁles comprised the

mean and standard deviation of the ﬂight time for dif-

ferent digraphs. These proﬁles could then be used for

authentication purposes. The limitation of this mech-

anism was that to obtain an accurate performance, a

substantial number of digraphs (for each user) was re-

quired. The authors stated that, in their experiments,

an average of 6,390 digraphs were required to con-

struct a reliable typing proﬁle. In (Gunetti and Pi-

cardi, 2005) the average ﬂight time for shared di-

graphs and trigraphs (between two typing samples)

was used to create typing proﬁles that were stored

in arrays. Given a new proﬁle, this was compared

to existing proﬁles by comparing the array order-

ing of the new proﬁle with existing proﬁles using

the R measure

. Thus, authenticating a new sample

required comparison with all stored sample proﬁles

A repository holding a collection of relevant typing

proﬁles.

An idea inspired by Spearman’s rank correlation coef-

ﬁcient.

(reference proﬁles), a computationally expensive pro-

cess. In the reported evaluation, 600 reference pro-

ﬁles were considered (generated from 40 users, each

with 15 samples); the time taken for a single match,

in this case, was 140 seconds (using a Pentium IV,

2.5 GHz). However, for most KCA applications, the

current sample need only be compared against the

claimed user’s reference proﬁle.

An issue with the work presented in both (Dow-

land and Furnell, 2004) and (Gunetti and Picardi,

2005) was the size of feature vectors used to repre-

sent typing proﬁles which required a substantial re-

source to collect, hence authentication was conducted

on typing completion. To address this disadvantage,

the idea presented in (Ahmed and Traore, 2014) was

to collect only a small number of features (average

hold time for monograms and average ﬂight time for

frequently occurring digraphs) and predict the values

for missing features to complete a new typing pro-

ﬁle. Once completed this could be compared with the

appropriate reference proﬁles (the stored proﬁles for

the person the new user claimed to be). A neural net-

work based classiﬁer was trained to predict the miss-

ing values. The proposed mechanism worked well un-

der controlled experimental conditions, although ide-

ally, we would like to undertake the evaluation in an

uncontrolled setting (as in the case of (Dowland and

Furnell, 2004) and (Gunetti and Picardi, 2005)).

There has been very little previous work directed

at time series analysis in the context of user authen-

tication using keyboard dynamics. In (Richardson

et al., 2014) a streaming algorithm was proposed

for which a potential suggested application domain

was real time KCA, although no further investigation

was ever conducted. In (Alshehri et al., 2016a) and

(Alshehri et al., 2016b) the concept of using single-

variate time series with respect to keystroke dynamics

was considered, but only in the context of static au-

thentication. Therefore, the work presented in this pa-

per is directed at continuous authentication using mul-

tivariate time series. The ﬁrst hypothesis investigated

in this paper is the idea that when incorporating more

than one keystroke timing feature, in a keyboard time

series representation, the quality of the user authen-

tication can be improved signiﬁcantly. The second

hypothesis is that the computational complexity of

the proposed mechanism, although clearly exceeding

the complexity associated with single-variate analy-

sis, will be such that real time user authentication will

be viable. To the best knowledge of the authors, real

time KCA using multivariate time series has not been

considered previously in the literature.

3 KEYSTROKE TIME SERIES

PRELIMINARIES

The generic concept of time series is well described

in the literature (see for example (Wang et al., 2013)).

This section presents the application of the concept

to keystroke multivariate time series starting with

a formal description of what a keystroke time series is.

Deﬁnition 1: A keystroke time series K

is an

ordering of keyboard events {p

, p

,... , p

} where

n ∈ N is the length of the series.

Deﬁnition 2: A dimensional keyboard event

(keystroke) p

∈ K

is parametrised as a tuple of the

form ht

i, where t

is an identifying index and k

a collection of multivariate keystroke timing features.

The keystroke timing features used in the proposed

representation are ﬂight time F

and and key-hold

K H

. That is, each event p

∈ K

can be given as:

→ ht

i | t = [0,n),k = {F

,K H

} (1)

such that a keystroke time series can be for-

mulated as a multivariate series of the form

{ht

,K H

i,ht

,K H

i,... }.

The fundamental idea is then to extract short

keystroke time series subsequence, using a moving

window of size ω, and use these for real time KCA by

comparing the current subsequence with earlier sub-

sequences so as to conﬁrm that the subject remains

who they say they are and has not been replaced by

another subject. For the implementation presented

later in this paper, Dynamic Time Warping (DTW),

as described in (Berndt and Clifford, 1994), was used

to determine the similarity between multivariate sub-

sequences. DTW was used because, unlike other sim-

ilarity devices such as Euclidean distance, it has the

ability to capture shape offsets (Lines et al., 2012).

In other words, it supports non-linear similarity deter-

mination. For completeness the process of DTW is

brieﬂy described in Sub-section 3.1 below.

3.1 Multivariate Similarity Checking

using DTW

The concept of multivariate time series, although not

new (Vlachos et al., 2003), has attracted much recent

attention in the literature (Hu et al., 2013; Cao and

Liu, 2016). There have been many approaches pro-

posed to determine the similarity between multivari-

ate time series; in this paper, because we are interested

in the effectiveness of the multivariate keystroke time

series representation in the context of KCA, a multi-

variate time series is considered in terms of its com-

ponent single time series. Thus in our case similarity

is expressed in terms of two warping path distances,

determined using the technique presented (Vlachos

et al., 2003), from which an average distance is ob-

tained.

Thus, given two multivariate keystroke time series

subsequences:

ts1

= {(a

}

),(a

}

),... ,(a

}

and

ts2

= {(b

}

),(b

}

),... ,(b

}

where ω is the subsequence (window) length, and the

set {x, y} is the coordinate set, y → F

or y → K H

The DTW commences with the creation of a matrix X

of size ω×ω holding the absolute Euclidean distances

d between each point a

∈ K

ts1

and all points b

∈ K

ts2

such that:

d(a

) =



)

− b

)

) + (a

)

− b

)



(2)

The warping path is then the path from location h0,0i

to location hω, ωi in the matrix X

X, that features the

lowest Euclidean distance values in the matrix. The

warping path distance (w) associated with this path

is the sum of the individual Euclidean distances nor-

malised by the distance associated with the path that

features the maximum Euclidean distance values in

the matrix X

X. If w = 0 the subsequences K

ts1

and K

ts2

are identical, otherwise they are different by some de-

gree. Thus w is a measure of similarity. The principle

of DTW is illustrated in Figure 1. The Figure shows

the optimal warping path with respect to two scenar-

ios: Figure 1(a) shows an example of the warping

path that results when comparing two keystroke time

series from the same user, but typing different texts;

whereas Figure 1(b) shows an example of the warping

path that results when comparing two keystroke time

series for different users typing the same text. In both

cases ω = 100. From the ﬁgures, it can be noted that

the warping path is shorter with respect to the same

user than in the different user case.

To decide whether two subsequences can be con-

sidered to be similar or not, a threshold value σ was

employed. In the context of the proposed real time

KCA, the value of σ was derived dynamically; how

this is achieved is discussed in Sub-section 4.2 be-

low. Note that the length of both keystroke time series

ts1

and K

ts2

) does not have to be equal, the reason

they are equal in the above explanation is simply be-

cause this was the case with respect to the proposed

real time KCA approach which uses a ﬁxed window

size ω.

4 CONTINUOUS/REAL TIME

KCA

The proposed real time KCA process is presented in

this section. As established above, the process com-

prises the comparison of time series subsequences

collected, using a sliding window of size ω, whilst the

subject is typing. As already noted the keystroke dy-

namics used were ﬂight time (F

) and key-hold time

(K H

). An issue with ﬁght time is that the value can

be large, for example when the subject pauses during

their typing or as a result of an “away from keyboard”

event. For each collected time series it was thus nec-

essary to address this issue, before commencing any

further KCA authentication. How this was achieved is

presented in Sub-section 4.1. Whatever the case, on

“start-up”, it was ﬁrst necessary to authenticate the

user with respect to a set of stored proﬁles for the

claimed user. At the same time, we need to establish a

value for σ. How this is achieved is presented in Sub-

section 4.2. Once we have authenticated the user we

can commence the monitoring process as described in

Sub-section 4.3.

4.1 Noise Reduction for Flight Time

In the foregoing, it was noted that a given ﬂight time

value F

might be greater than normal because the

subject has paused during his/her typing. Essentially

such high values introduce noise into the real time

KCA process. To address this issue, a limit was

placed on the F

values in a given time series K

us-

ing a second threshold value ϕ. In other words, given

a speciﬁc F

value in access of ϕ, the value was re-

duced to ϕ. In the evaluation presented later in this

paper a range of values for ϕ were considered, rang-

ing from 0.75 to 2.00 seconds, increasing in steps of

0.25 seconds ({0.75,1.00,1.25,1.50, 1.75, 2.00}).

4.2 User Authentication on Start-up

At the beginning of the process, it will be ﬁrst neces-

sary to conﬁrm that the user is who(s)he says (s)he

is. This is done by comparing the ﬁrst extracted

subsequence, S

, with a collection of reference sub-

sequences (of the same length ω) extracted from a

sample typing proﬁle K

, known to belong to the

claimed subject and obtained previously. Note that

in this case, K

needs to be substantially greater

than the maximum anticipated value for ω, so that

(a) (b)

Figure 1: The application of DTW: (a) warping path for the same user typing different texts, and (b) warping path for different

users typing the same text.

a number of subsequences can be extracted. S

then compared, using DTW, with the reference sub-

sequences set, and an average warping path distance

¯w obtained. The required value for σ is obtained by

comparing all the proﬁle subsequences pair combina-

tions in K

and obtaining a set of warping path values

W = {w

,... }. The average value of W is then

calculated and used as the value of σ which is com-

pared with ¯w to determine whether the user is who

they say they are. Note that the σ value derived in this

manner is used throughout the rest of the real time

KCA process for the current typing session. Note also

that the window size ω, is user deﬁned. For the exper-

iments reported on later in this paper a range of ω

values were considered from 25 to 150 increasing in

steps of 25 ({25,50,75,100, 125,150}).

4.3 Continuous User Authentication

Once the initial authentication had been completed,

and a value for σ obtained, the real time KCA can

be commenced. The pseudo code for the process is

presented in Algorithm 1. The inputs are: (i) the de-

sired window size ω and (ii) the similarity threshold

σ (derived as described above) and the desired ϕ limit

value for F

. The process loops continuously until

the keyboard session is terminated (the subject com-

pletes the assessment, times out or logs-out); on each

iteration, the ﬂight time F

and K H

values are si-

multaneously recorded. Each F

value is checked to

ensure that it is within the limit (ϕ). This is done us-

ing the function checkLimit (line 8) which returns the

value if it is less than ϕ, and ϕ otherwise (as de-

scribed above). F

and K H

are then appended to the

keystroke time series K

so far. Note that K

is built

up as the process progresses. The counter is moni-

tored and subsequences are extracted whenever

Algorithm 1: Multivariate KCA process.

Input: ω, σ, ϕ.

Output: Authentication commentary.

1: counter = 0

2: K

3: loop

4: if end of session signal received then

5: break

6: end if

7: F

= current keystroke dynamic (ﬂight time)

8: F

= checkLimit(F

,ϕ)  Noise reduction.

9: K

= K

∪ F

10: counter + +

11: if REM(counter/ω) == 0 then

12: S

= subsequence {K

counter−ω

...K

counter

}

13: if counter = ω then

14: Start-up: authenticate S

w.r.t reference

proﬁles and σ

15: else

16: Authenticate S

w.r.t. S

i−1

and σ

17: end if

18: end if

19: end loop

the number of keystrokes reaches ω. For the ﬁrst col-

lected subsequence (S

∈ K

) this is the start-up sit-

uation and consequently S

is processed as described

above in Sub-section 4.2 and a report returned. Other-

wise the subsequence S

is compared to the previous

subsequence S

i−1

(i > 1), using the DTW process as

described in Sub-section 3.1.

5 EVALUATION

The evaluation of the proposed multivariate time

series-based approach to continuous/real time

keystroke authentication is presented in this section.

For the evaluation two data sets were used; these are

thus ﬁrst discussed in Sub-section 5.1. Experiments

were conducted to: (i) evaluate the processing time

required to generate user proﬁles, (ii) determine how

well the proposed approach performed in terms of

the detection of impersonators, (iii) compare the

operation of the proposed multivariate keystroke

time series with the use of univariate keystroke time

series for KCA (when we only use the F

feature as

proposed in the previous study presented in (Alshehri

et al., 2016b)) and (iv) compare the operation of the

proposed approach with the traditional feature vector

representation based approach when applied to KCA.

The results obtained with respect to these objectives

are discussed in further detail in Sub-sections 5.2,

5.3, 5.4 and 5.5 respectively. The metrics used for the

evaluation were: (i) authentication accuracy (Acc.),

(ii) the False Acceptance Rate (FAR), (iii) the False

Rejection Rate (FRR) and (iv) Runtime (seconds).

Note that FAR and FRR are the traditional metrics

used to measure the performance of biometric au-

thentication systems (Polemi, 1997). Two-fold cross

validation was conducted, hence results presented

below are average results from two cross validations.

5.1 Datasets and Experimental Setting

The experiments reported on in this section were con-

ducted using two datasets: (i) ACB, collected by the

authors, and (ii) VHHS obtained from (Vural et al.,

2014) (the identifying acronyms are made up of the

relevant author initials). Note that each dataset com-

prised keystroke dynamics from free text sessions ob-

tained from volunteer keyboard users, however each

featured differing characteristics, thus different: (i)

number of subjects, (ii) lengths of typed samples, (iii)

subject matter (speciﬁed or unspeciﬁed) and (iv) en-

vironments in which the samples were collected (lab-

oratory or otherwise). Each is discussed in some fur-

ther detail below. Table 1 provides some statistics

concerning both datasets.

For the evaluation, the record associated with each

subject was split into two so that one-half could be

used as the reference proﬁle and the other to simulate

a typing stream. Recall that for the proposed real time

KCA, the reference proﬁles were used to: (i) derive a

value for σ and (ii) for “start-up authentication”.

5.1.1 ACB Dataset

The ACB dataset was collected anonymously using

undergraduates, postgraduates and staff at the au-

thors’ university; the total number of subjects par-

ticipating was 30. Some additional information re-

garding the gender and/or age were deliberately ig-

nored for two reasons: (i) to minimise the resource

required by subjects providing the data, and (ii) so

as to focus only on comparing user typing patterns

for user authentication, not on drawing any conclu-

sions about the nature of keyboard usage behaviour

in the context of (say) age or gender. Furthermore,

the subjects were asked to provide answers to gen-

eral questions to simulate the way that online assess-

ments might be run. Thus, the subjects were al-

lowed to undertake the exercise in their own time us-

ing whatever keyboard, operating system and browser

they had at hand. The website interface from where

the ACB dataset was collected can be found at:

(http://cgi.csc.liv.ac.uk/hsaalshe/WBKTR3.html).

5.1.2 VHHS Dataset

The VHHS dataset was generated by the authors of

(Vural et al., 2014) and comprised both ﬁxed and free

text samples. For the evaluation reported here, only

the free text samples were considered so that mean-

ingful comparisons could be made with the results

obtained using the ACB dataset. Note also that the

VHHS dataset was collected under laboratory condi-

tions, not the case with respect to the ACB dataset. A

total of 39 subjects were recruited.

5.2 Typing Proﬁle Generation

Table 2 shows the run-time values (seconds) taken to

generate the reference proﬁles, required on start-up of

the proposed real time KCA process, using different

ω values. The “per subject” values were obtained by

dividing the total run time with the number of records

in the dataset from Table 1. The experiment was run

twice, each time with a different half of the data (two-

fold cross-validation), the results presented in the ta-

ble are thus average values. From the table, it can be

clearly seen that, regardless of the dataset, process-

ing time increased with ω. This was to be expected

because the computation time required by the DTW

would increase as the size of the subsequence con-

sidered increased (even though there might be less

of them). There are well known solutions in the lit-

erature to mitigate against the complexity of DTW

(Itakura, 1975; Sakoe and Chiba, 1978), no such mit-

igation was applied with respect to the experiments

reported here. Nevertheless, we obtained much bet-

ter efﬁciency compared with the feature vector ap-

proach as stated in (Gunetti and Picardi, 2005) where

the time taken to construct typing proﬁle was 140 sec-

onds. Thus, we have a worst case runtime ratio 1 : 23;

using ω = 100 (the best performing value for ω as

demonstrated later in this section) we have a ratio of

1 : 29, which is a signiﬁcant “speed-up”.

Table 1: Summary of Evaluation Datasets.

Dataset # Subject. Environment. Language used. Average size Standard Deviation (SD)

ACB 30 Free English 4625 1207

VHHS 39 Lab. English 4853 1021

Table 2: The time taken (in seconds) to construct subject

reference proﬁles.

Entire Dataset Per Subject

ACB VHHS ACB VHHS

25 1.007 1.180 0.034 0.030

50 1.969 1.570 0.066 0.040

75 2.980 3.523 0.099 0.090

100 5.095 6.244 0.170 0.160

125 7.940 9.742 0.265 0.250

150 12.000 14.130 0.400 0.362

5.3 User KCA Performance

For each dataset, the continuous typing process was

simulated by presenting the keystroke dynamics for

each subject in the form of a data stream. In each

case, the data stream was appended with a randomly

selected second data stream from another user. The

idea being to simulate one subject being imperson-

ated by another half way through a typing session.

For every comparison of a subsequence S

with a sub-

sequence S

i−1

(line 17 in Algorithm 1) we recorded

whether this was a True Positive (TP), False Posi-

tive (FP), False Negative (FN) or True Negative (TN).

In this manner a confusion matrix was built up from

which accuracy (Acc.), FAR and FRR could be calcu-

lated (using Equations 3, 4 and 5).

Acc =

T P + T N

T P + FP + FN + T N

(3)

FAR =

FP + T N

(4)

FRR =

FN + T P

(5)

Table 3 presents the accuracy results ob-

tained, with respect to both datasets, us-

ing ω = 25,50, 75,100,125, 125 and ϕ =

0.750,1.00,1.25,1.50, 1.75, 2.00. Recall that in

each case, the experiment was run twice each time

with a different half of the data; the results presented

are therefore averages. From the table, it can be

observed that ω and ϕ values of 100 and 1.50

respectively tended to produce best results for all

datasets (the best accuracy result recorded for ACB

was 98.39%, whereas the best result for VHHS was

97.32%). Note also that the selection of ϕ does not

seem to have as much impact as the selection of ω,

and that the performance tends to decrease if the

selected ω value is too big or too small.

Table 4 shows the best results obtained in terms

of FAR and FRR (to give a clear comparison, the

best accuracy values from Table 3, written in bold

font, have been included in the table). The average

recorded results for FAR and FRR are 0.036% and

1.971% respectively; an indicator that the proposed

method gives promising results, and furthermore that

it can be usefully employed as a behavioural biomet-

ric based approach for continuous user authentication.

5.4 Comparison with Univariate

Keystroke Time Series

This subsection presents evaluation results obtained

when the operation of the proposed mechanism was

compared with univariate time series keystroke rep-

resentation as introduced in (Alshehri et al., 2016b).

More speciﬁcally univariate time series used for

the experimentation were generated using the F

keystroke dynamic. The results are presented in Table

5. From the table, it can be observed clearly that the

univariate representation produced worse results, in

term of accuracy, than the proposed multivariate ap-

proach. Best recorded results for ACB were 96.48%

(with ω = 100 and ϕ = 1.25), and for VHHS it was

96.54% (with ω = 100 and ϕ = 1.00) compared with

98.39% and 97.32% respectively when using the mul-

tivariate approach (see Table 3). However, the run

time results (not shown) indicate that the efﬁciency of

constructing typing proﬁles during the start-up stage

was slightly increased when using univariate time se-

ries compared with the use of multivariate time se-

ries. This was to be expected because the computa-

tional expensive of applying DTW univariate time se-

ries less than when applied to multivariate time series.

Figure 2 shows a comparison of run time versus

ω. Inspection of the ﬁgure indicates that, as to be

expected, the use of univariate time series is more ef-

ﬁcient than the use of multivariate time series. In con-

clusion, it can thus be observed that the multivariate

representation gives better accuracy results than the

univariate representation, but at a small efﬁciency ex-

pense. In other words, incorporating more keystroke

dynamics produces a better KCA performance. Note

that the limitation of the multivariate time series rep-

resentation for KCA is a topic for future work.

Table 3: Accuracy recorded for Keystroke Multivariate Time Series realtime KCA (best results in bold font).

ACB VHHS

0.750 1.00 1.25 1.50 1.75 2.00 0.750 1.00 1.25 1.50 1.75 2.00

25 83.21 88.34 89.27 96.13 94.79 91.77 91.28 93.03 94.59 95.25 92.67 93.52

50 87.81 87.93 90.87 97.61 96.39 92.37 91.40 90.64 95.20 92.87 94.28 91.13

75 86.81 87.94 92.87 96.40 98.17 93.36 90.96 92.71 94.27 97.15 94.35 93.20

100 92.25 91.37 93.31 98.39 94.83 90.81 93.45 95.09 96.65 97.32 95.73 95.11

125 92.42 92.55 94.48 98.34 96.10 96.98 92.02 93.77 95.33 95.99 95.41 94.26

150 94.46 96.59 95.12 97.40 97.57 95.13 92.44 94.19 95.75 96.42 95.83 94.68

Table 4: Best Average Acc., FAR and FRR values obtained

using the proposed real time KCA method (ω = 100 and

ϕ = 1.50 ).

Dataset FAR (%) FRR (%) Accuracy (%)

ACB 0.045 1.922 98.39

VHHS 0.027 1.950 97.32

Average 0.036 1.936 97.86

Univariate Representation.

Multivariate Representation.

(a)

Univariate Representation.

Multivariate Representation.

(b)

Figure 2: Efﬁciency performance comparison for keystroke

univariate time series and keystroke multivariate time se-

ries: (a) ACB dataset, (b) VHHS dataset.

5.5 Comparison with Feature Vector

Approach

This subsection reports on the results obtained when

the operation of the proposed real time KCA method

is compared with the Feature Vector Representa-

tion (FVR) approach frequently encounter in previ-

ous work. As noted in Section 2, there are a num-

ber of reports where the feature vector approach has

been applied to KCA although not in real time; the

authentication is conducted on typing completion. Of

these, the approach described in (Gunetti and Picardi,

2005) was selected for the comparison reported here

because: (i) the study obtained, to the best knowl-

edge of the authors, the best FAR and FRR results

to date; and (ii) the approach was well explained in

the literature, therefore it was easy to reproduce. The

data for each subject, as before, was divided into two.

One-half to be used to create a typing proﬁle, and the

other half as the test data. The features used were the

values for all shared digraph, trigraphs and quad-

graphs in each corresponding sample. A typing pro-

ﬁle was thus constructed for each user and compar-

isons conducted as described in (Gunetti and Picardi,

2005) (again see also Section 2). The results are pre-

sented in Table 6. For a comparison purpose, the table

includes the accuracy (Acc.), FAR and FRR results

presented earlier with respect to the proposed multi-

variate approach and comparator univariate approach.

From the Table, it can be observed that the proposed

multivariate time series-based approach to KCA ob-

tained a better performance than the other two meth-

ods considered with respect to both datasets. Thus,

conﬁrming the hypothesis posed in the introduction

to this paper that a multivariate time series represen-

tation would serve to better encapsulate keystroke dy-

namics than the univariate and feature vector based

approach that has typically been used to date. For

completeness, Figure 3 presents the best accuracy re-

sults in a graphical form.

6 CONCLUSION

In this paper, a novel mechanism for real time

Keystroke Continuous Authentication (KCA) has

been presented. The idea is to use sequences of

keystroke dynamics in the form of multivariate time

series, incorporating ﬂight time F

and key-hold time

Table 5: Accuracy recorded for Keystroke Univariate Time Series.

ACB VHHS

0.750 1.00 1.25 1.50 1.75 2.00 0.750 1.00 1.25 1.50 1.75 2.00

25 72.14 75.35 80.14 85.65 85.01 86.24 80.58 79.76 82.96 83.20 82.00 81.92

50 86.00 83.20 88.64 80.00 80.54 81.00 80.13 82.14 85.46 86.14 85.00 84.00

75 92.12 94.78 95.19 92.00 93.37 94.00 83.33 83.33 83.33 83.33 83.33 83.33

100 93.24 96.20 96.48 94.79 96.10 95.24 95.61 96.54 96.29 95.35 93.99 94.88

125 95.10 94.00 96.12 95.79 95.81 95.57 94.35 96.34 94.73 95.39 94.28 93.49

150 96.14 94.35 95.37 95.62 96.13 95.12 93.33 95.31 93.67 94.98 94.87 94.96

Table 6: Comparison of KCA using: (i) Multivariate Time Series, (ii) Univariate Time Series and (iii) a Feature Vector based

representation (best results in bold font).

Dataset

Multivariate Time Univariate Time Feature Vector-

Series Based KCA Series Based KCA Based KCA

FAR FRR Acc. FAR FRR Acc. FAR FRR Acc.

ACB 0.045 1.922 98.39 0.05 1.961 96.20 8.60 11.10 80.82

VHHS 0.027 1.950 97.32 0.03 1.970 94.83 9.09 7.13 89.15

Average 0.036 1.936 97.86 0.04 1.965 95.51 8.75 5.93 83.71

Figure 3: The accuracy obtained for multivariate time se-

ries representation, univariate time series representation and

feature vector representation with respect to KCA applica-

tion.

K H

, and to monitor such multivariate time series

for the purpose of real time KCA. More speciﬁcally

to periodically extract, from this data stream, subse-

quences that can be used for authentication purposes.

In the proposed process, on start-up, the ﬁrst sub-

sequence (window) extracted for the subject will be

compared to a reference proﬁle (time series); sub-

sequence S

will then be compared to the immedi-

ate predecessor subsequence S

i−1

, and so on. In this

manner continuous, real time, user authentication can

take place. The advantage offered is ﬁrst that the time

series approach is much more efﬁcient than the fea-

ture vector based approach used in earlier work. The

presented evaluation indicated a speed up of approx-

imately 1 : 29 using ω = 100, consequently real time

authentication becomes a realistic option.

The second advantage, again as demonstrated in

the paper, is that the approach is more effective; a

best overall accuracy of 97.86% was recorded with re-

spect to the proposed mechanism as opposed to a best

overall average accuracy of 95.51% using a univari-

ate approach and 83.71% when an established feature

vector technique was used (based on that presented

in (Gunetti and Picardi, 2005)). For future work, the

authors intend to investigate the use different time se-

ries representation methods, such as the Fourier trans-

form, to determine the effectiveness of such different

representation methods for real time KCA. Further-

more, the time complexity of DTW, in the context of

keystroke multivariate time series similarity, remains

an open topic for future work. We wish to optimise

the operation of DTW with respect to such keystroke

multivariate time series.

REFERENCES

Ahmed, A. A. and Traore, I. (2014). Biometric recognition

based on free-text keystroke dynamics. Cybernetics,

IEEE Transactions on, 44(4):458–472.

Alshehri, A., Coenen, F., and Bollegala, D. (2016a). Key-

board usage authentication using time series analy-

sis. In International Conference on Big Data Analytics

and Knowledge Discovery, pages 239–252. Springer.

Alshehri, A., Coenen, F., and Bollegala, D. (2016b). To-

wards keystroke continuous authentication using time

series analytics. In Proc. AI 2016, Research and

Development in Intelligent Systems XXXIII, Springer,

pp275-287., pages 325–338. Springer.

Berndt, D. J. and Clifford, J. (1994). Using dynamic time

warping to ﬁnd patterns in time series. In KDD work-

shop, pages 359–370. Seattle, WA.

Bours, P. (2012). Continuous keystroke dynamics: A dif-

ferent perspective towards biometric evaluation. In-

formation Security Technical Report, 17(1):36–43.

Cao, D. and Liu, J. (2016). Research on dynamic time

warping multivariate time series similarity matching

based on shape feature and inclination angle. Journal

of Cloud Computing, 5(1):11.

Clark, R. C. and Mayer, R. E. (2016). E-learning and

the science of instruction: Proven guidelines for con-

sumers and designers of multimedia learning. John

Wiley & Sons.

Dowland, P. S. and Furnell, S. M. (2004). A long-term trial

of keystroke proﬁling using digraph, trigraph and key-

word latencies. In Security and Protection in Informa-

tion Processing Systems, pages 275–289. Springer.

Gaines, R. S., Lisowski, W., Press, S. J., and Shapiro, N.

(1980). Authentication by keystroke timing: Some

preliminary results. Technical report, DTIC Docu-

ment.

Giancardo, L., Arroyo-Gallego, T., Butterworth, I., Men-

doza, C., Montero, P., Matarazzo, M., and Sanchez-

Ferro, A. (2016). Computer keyboard interaction as an

indicator of early parkinson’s disease. arXiv preprint

arXiv:1604.08620.

Gunetti, D. and Picardi, C. (2005). Keystroke analysis of

free text. ACM Transactions on Information and Sys-

tem Security (TISSEC), 8(3):312–347.

Gunetti, D. and Ruffo, G. (1999). Intrusion detection

through behavioral data. In Advances in Intelligent

Data Analysis, pages 383–394. Springer.

Hu, B., Chen, Y., Zakaria, J., Ulanova, L., and Keogh, E.

(2013). Classiﬁcation of multi-dimensional streaming

time series by weighting each classiﬁer’s track record.

In Data Mining (ICDM), 2013 IEEE 13th Interna-

tional Conference on, pages 281–290. IEEE.

Itakura, F. (1975). Minimum prediction residual principle

applied to speech recognition. IEEETrans. Acoustics,

Speech, and Signal Processing, pages 52–72.

Joyce, R. and Gupta, G. (1990). Identity authentication

based on keystroke latencies. Communications of the

ACM, 33(2):168–176.

Killourhy, K. S. and Maxion, R. A. (2009). Compar-

ing anomaly-detection algorithms for keystroke dy-

namics. In Dependable Systems & Networks, 2009.

DSN’09. IEEE/IFIP International Conference on,

pages 125–134. IEEE.

Lines, J., Davis, L. M., Hills, J., and Bagnall, A. (2012).

A shapelet transform for time series classiﬁcation. In

Proceedings of the 18th ACM SIGKDD international

conference on Knowledge discovery and data mining,

pages 289–297. ACM.

Monrose, F., Reiter, M. K., and Wetzel, S. (2002). Password

hardening based on keystroke dynamics. International

Journal of Information Security, 1(2):69–83.

Polemi, D. (1997). Biometric techniques: review and evalu-

ation of biometric techniques for identiﬁcation and au-

thentication, including an appraisal of the areas where

they are most applicable. Reported prepared for the

European Commision DG XIIIC, 4.

Raja, M. and Sigg, S. (2016). Applicability of rf-based

methods for emotion recognition: A survey. In 2016

IEEE International Conference on Pervasive Comput-

ing and Communication Workshops (PerCom Work-

shops), pages 1–6. IEEE.

Richardson, A., Kaminka, G. A., and Kraus, S. (2014).

Reef: Resolving length bias in frequent sequence min-

ing using sampling. International Journal On Ad-

vances in Intelligent Systems, 7(1):2.

Sakoe, H. and Chiba, S. (1978). Dynamic programming

algorithm optimization fro spoken word recognition.

IEEE Trans. Acoustics, Speech, and Signal Process-

ing, pages 43–49.

Shepherd, S. (1995). Continuous authentication by anal-

ysis of keyboard typing characteristics. In Security

and Detection, 1995., European Convention on, pages

111–114. IET.

Syed, Z., Banerjee, S., and Cukic, B. (2014). Normaliz-

ing variations in feature vector structure in keystroke

dynamics authentication systems. Software Quality

Journal, pages 1–21.

Vlachos, M., Hadjieleftheriou, M., Gunopulos, D., and

Keogh, E. (2003). Indexing multi-dimensional time-

series with support for multiple distance measures. In

Proceedings of the ninth ACM SIGKDD international

conference on Knowledge discovery and data mining,

pages 216–225. ACM.

Vural, E., Huang, J., Hou, D., and Schuckers, S. (2014).

Shared research dataset to support development of

keystroke authentication. In Biometrics (IJCB), 2014

IEEE International Joint Conference on, pages 1–8.

IEEE.

Wang, X., Mueen, A., Ding, H., Trajcevski, G., Scheuer-

mann, P., and Keogh, E. (2013). Experimental com-

parison of representation methods and distance mea-

sures for time series data. Data Mining and Knowl-

edge Discovery, 26(2):275–309.
