NewSQL Databases

MemSQL and VoltDB Experimental Evaluation

João Oliveira

and Jorge Bernardino

1,2

ISEC, Polytechnic of Coimbra, Rua Pedro Nunes, Coimbra, Portugal

CISUC – Centre for Informatics and Systems of the University of Coimbra, Coimbra, Portugal

Keywords: NewSQL Databases, NewSQL, MemSQL, VoltDB, TPC-H.

Abstract: NewSQL databases are a set of new relational databases that provide better performance than the existing

systems, while maintaining the use of the SQL language. Due to the huge amounts of data stored by

organizations these types of databases are suitable to process efficiently this information. In this paper, we

describe and test two of the most popular NewSQL databases: MemSQL and VoltDB. We show the

advantages of the NewSQL databases engines using the TPC-H benchmark. The experimental evaluation

demonstrated the ability of MemSQL and VoltDB to execute effectively TPC-H benchmark queries.

1 INTRODUCTION

NewSQL is a set of new SQL databases engines with

high-performance and scalability. These engines seek

to promote the same performance and scalability

improvement of NoSQL systems, designed solutions

that have the advantages of the relational model, and

with the benefit of using SQL language (Stonebraker,

2012).

The term NewSQL was first used by analyst

Matthew Aslett in 2011 in this “NoSQL, NewSQL

and Beyond” (Aslett, 2011) business analysis report,

which discussed the emergence of new databases

systems.

NewSQL aims to provide the same performance

as NoSQL systems for OLTP loads and still maintain

the ACID (Atomicity, Consistency, Isolation,

Durability) guarantees of traditional databases.

Matthew Aslett says NewSQL databases are

designed to meet the scalability requirements of

distributed architectures or to improve performance

such that horizontal scalability is no longer a

necessity, including new storage mechanisms,

transparent shadowing technologies, and databases

completely new.

The relational databases technology was invented

in 1970 by Edgar Frank Codd, where he demonstrated

the functionalities of this technology. Simultaneously

was developed the SQL language that has become the

standard language for manipulation of relational

model. SQL is a complete language, used both to

create and to manage, update, retrieve, or share

information. Relational databases have been a

common choice for storing information since the

1980s. Despite all the advantages, SQL also has many

limitations both at the level of databases

management, such as scalability, performance and

size. SQL databases are losing processing power with

the increase in data volume. The main problem is the

existence of differences in language that allows

access to the databases, because not all vendors use

the standard in their entirety. The existence of

differences in the syntax rules in each product, makes

databases difficult to use. So, it can be said that

NewSQL aims to achieve high performance and have

great ability to resize, and intends to preserve SQL.

There are two characteristics that are common,

supporting the relational data model and the use of

SQL as the main interface (Pavlo and Aslett, 2016).

In this paper, we intend to study and test NewSQL

databases, for the experimental evaluation we

considered the MemSQL and VoltDB engines, using

the TPC-H benchmark.

The rest of this paper is structured as follows. The

next section presents related work. Section 3

describes MemSQL and VoltDB NewSQL databases.

Section 4 describes the TPC-H benchmark used.

Section 5 presents the configuration used for testing

followed by experimental evaluation and results.

Finally, section 6 presents the conclusions and future

work.

Oliveira J. and Bernardino J.

NewSQL Databases - MemSQL and VoltDB Experimental Evaluation.

DOI: 10.5220/0006518902760281

In Proceedings of the 9th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (KEOD 2017), pages 276-281

ISBN: 978-989-758-272-1

2 RELATED WORK

In this section we describe some approaches,

functionalities, comparisons of relational databases,

NoSQL and NewSQL related to our work.

Pavlo and Aslett (2016) discussed the emergence

of NewSQL databases, providing a detailed

explanation of the term NewSQL, and their

characteristics. More specifically, they studied the

new DBMS constructed from scratch. Instead of

focusing on an existing system, they started from a

database without any architectural approach,

representing a development of database technologies

that incorporates existing ideas into unique platforms

that form new engines, in a new era in which

computing resources are abundant and accessible.

In (Moniruzzaman, 2014), the authors discusses

the NewSQL data management system and compares

with NoSQL and with the traditional database system.

This article discusses the architecture, characteristics,

and classification of NewSQL databases for online

transaction processing (OLTP) for managing large

data.

In (Grolinger et al., 2013) the authors analyse

NoSQL and NewSQL solutions with the goal of

providing guidance to professionals. They also give a

survey to choose the appropriate storage of data, and

identity challenges and opportunities, scaling data

storage are investigated, partitioning, replication,

consistency, and concurrency control. In addition, the

use cases and scenarios in which the NoSQL an

NewSQL data stores were used are discussed and the

suitability of various solutions for different sets of

applications are examined.

In (Kumar et al., 2014) the authors include the

basic concept of large data and its benefits, as well as

the data types, and the introduction to Apache

Hadoop. In addition, this article contains the

introduction of NoSQL, NewSQL as well as its

features and analyses how to handle data through

Hadoop, NoSQL and NewSQL.

Binani, Gutti and Upadhyay (2016) describe an

approach of SQL databases also known as RDBMS

(Relational Database Management Systems) to meet

the needs of big data systems, which are mainly

unstructured in nature and expect quick response and

scalability. NoSQL databases are also analysed to

provide scalability and a structured platform for big

data applications. However, due to some

disadvantages, NewSQL comes up, it is a relational

database with scalability properties. This paper

discusses each of these database systems and tries to

solve problems of data requirements.

In (Lourenco et al., 2015a), the authors used a real

world enterprise system with real corporate data to

evaluate the performance characteristics of popular

NoSQL databases and compare them to SQL

counterparts. They tested Cassandra, MongoDB,

Couchbase Server and MS SQL Server databases and

compared their performance while handling

demanding and large recording write requests from a

real company data with an electrical measurement

enterprise system.

In (Lourenço et al., 2015b), the authors make a

concise and up-to-date comparison of NoSQL

engines. The most beneficial use case scenarios from

the software engineer´s point of view, their

advantages and drawbacks by surveying the currently

available literature were described.

In our work, the focus is to conduct an

experimental evaluation using two popular NewSQL

engines, more specifically testing the execution time

of TPC-H benchmark queries.

3 NEWSQL DATABASES

In this section we describe two of the most popular

NewSQL databases engines: MemSQL and VoltDB.

3.1 MemSQL

MemSQL is a distributed, in-memory, relational

database management system (RDBMS), which

comply with structured query language (SQL).

MemSQL uses a two-tiered architecture

consisting of aggregator nodes and leaf nodes.

Aggregator nodes are cluster-aware query routers that

act as a gateway into the distributed system. They

store only metadata and reference data. Aggregators

intelligently distribute queries across the leaf nodes

and aggregate results that are sent to the client.

Increasing the number of aggregators will improve

operations like data loading and will allow MemSQL

to process more client requests concurrently.

Leaf nodes function as storage and compute

nodes. Data is automatically distributed across leaf

nodes into partitions to enable parallelized query

execution. Increasing the number of leaf nodes will

increase the overall capacity of the cluster and speed

up query execution, especially queries that require

large table scans and aggregations. Additional leaf

nodes also allow the cluster to process more queries

in parallel. The number of aggregator and leaf nodes

deployed determines cluster capacity and

performance. Figure 1 shows MemSQL architecture.

Figure 1: MemSQL Architecture (MemSQL Documenta-

tion, 2017).

Allocation of data is through two types, replicate

tables, and distributed tables. Replicated tables are

copied to all nodes, and fragmented nodes are

distributed through fragmentation keys, which

facilitates the execution of join operations. To

fragment a table, MemSQL supports both primary

and derived fragmentation. Primary fragmentation

can be accomplished by any attribute of the tables that

is specified as a fragmentation key. Derived

fragmentation is a strategy to try to allocate fragments

that have the same key value in the same node.

For concurrency control, MemSQL uses the

MVCC protocol in conjunction with non-blocking

indexes to ensure better performance in scenarios

with concurrent operations compromising

consistency, so read operations do not block writes

(Chen et al., 2016).

MemSQL can dynamically add nodes to increase

storage capacity or processing power. Queries are

compiled and converting into C++ code, then stored

in a cache. The code is reusable, but the cache does

not store results of executions from previous queries.

In addition to redundancy, MemSQL ensures

durability with logging and full database snapshots. If

a node goes down, its state can be recreated by

replaying the most recent snapshot and log files.

(Pavlo and Aslett, 2016).

In Figure 2, the query is received, MemSQL

checks whether there is already hashed code, if the

parameters are passed to the already compiled code

the query is executed, otherwise the query will be

compiled and stored in the hash table. In Table 1 we

present MemSQL properties.

Figure 2: Query execution in MemSQL (MemSQL

Documentation, 2017).

Table 1: MemSQL features (DB Engines, 2017).

MemSQL

Memory Storage Yes

Partitioning Yes

Concurrency Control MVCC

Replication Strong + Passive

Development language C++

3.2 VoltDB

VoltDB is an in-memory database, which depends on

the main memory for data storage. This system was

designed in 2010 by the well-known database

researchers, Michael Stonebraker, Sam Madden, and

Daniel Abadi (Stonebraker, 2012).

VoltDB is an ACID relational database that uses

a shared-nothing architecture, ensuring that the data

is always correct and available. The data is organized

into memory partitions, and transactions are sent by

clients connected to the database.

VoltDB uses horizontal scalability to increase the

capacity of the nodes of the existing database, or the

number of nodes in a shared-nothing cluster.

For high availability VoltDB uses partitions

which are transparently replicated across multiple

servers. If one fails all data remains available and

consistent for continuum operation. Memory

performance with durability on the disk is possible

with the VoltDB snapshot. The snapshot is a complete

copy of the database at a certain point in time that is

written on the disk.

VoltDB uses asynchronous replication on the

WAN (Wide Area Network) for loss recovery. The

remote copy is a read-only while it is not considered

to be the primary database.

In Figure 3 we present the architecture of VoltDB

and in Table 2 its main features (Stonebraker, 2012).

Figure 3: VoltDB Architecture (VoltDB Documentation,

2017).

Table 2: VoltDB features (DBEngines, 2017).

VoltDB

Memory Storage Yes

Partitioning Yes

Concurrency Control Yes

Replication Strong + Passive

Development language Java, C++

4 TPC-H BENCHMARK

TPC-H is a decision-support benchmark consisting of

a set of business-oriented ad-hoc queries. This

benchmark evaluates the performance of various

decision support types by performing a set of

controlled queries on the databases under test. These

queries are much more complex than most OLTP

transaction and include a wide set of operators and

selectivity constraints. The purpose of this benchmark

is to reduce the diversity of operations found in an

information analysis application, while retaining the

application's essential performance characteristics,

namely: the level of system utilization and the

complexity of operations. As example, we show

below Q1 that is a pricing summary report query. This

query reports the amount of business that was billed,

shipped, and returned The pricing summary report

query provides a summary pricing report for all

lineitems shipped as of a given date:

select l_returnflag, l_linestatus,

sum(l_quantity) as sum_qty,

sum(l_extendedprice) as sum_base_price,

sum(l_extendedprice * (1 - l_discount)) as

sum_disc_price, sum(l_extendedprice * (1 -

l_discount) * (1 + l_tax)) as sum_charge,

avg(l_quantity) as avg_qty,

avg(l_extendedprice) as avg_price,

avg(l_discount) as avg_disc, count(*) as

count_order

from LINEITEM where l_shipdate <= '1998-12-

01' - interval '117' day

group by l_returnflag, l_linestatus

order by l_returnflag, l_linestatus;

The TPC-H is a data model having eight tables as

we can see in figure 4, which involves customers,

suppliers and purchases of items. Five continents are

represented, which contains twenty-five nations,

represented by the Region and Nation tables.

Customers and suppliers are stored in the tables,

Supplier and Customer, which are associated with the

nations. The Orders table places purchase orders.

There is the Partsupp table to record the relationship

between vendors and items. Finally, there is the more

bulky table, Lineitem that associates purchase items

with orders (Santos et al., 2011).

Figure 4: TPC-H benchmark schema.

Table 3 presents TPC-H eight tables as well as the

number of records that each table has for 1GB.

Table 3: Number of records for TPC-H with 1GB.

Tables #Records for 1GB

Nation 25

Region 5

Part 200 000

Supplier 10 000

Partsupp 800 000

Customer 150 000

Orders 1 500 000

Lineitem 6 001 215

TOTAL 8 661 245

5 EXPERIMENTAL

EVALUATION

In the next sections, we will give information about

the experimental setup. It is described the

characteristics of computers used, the load times of

the tables in the MemSQL and VoltDB engines, the

execution time of the queries. Finally, we will discuss

the results obtained in the experimental evaluation.

5.1 Experimental Setup

We evaluate MemSQL and VoltDB database with the

TPC-H benchmark queries using a scale factor of 1.

The tests were performed on a computer with the

following characteristics:

- Operating system Ubuntu 16.04 64-bit LTS

- Intel Xeon (R) CPU X5570 @ 2.93GHz x16,

40GB memory (RAM) and 250GB disk.

Figure 5: Average query execution time of TPC-H queries.

5.2 Loading Information

In this section, we present the results of the time in

the insertion of data obtained from each of the eight

tables in the TPC-H benchmark. The results are for

loading data using the two NewSQL engines,

MemSQL and VoltDB. The loading time was

obtained on the computer with the specifications

mentioned in the setup of the experimental setup

section.

Table 4 below shows the insertion time in

seconds.

Table 4: Loading times for 1GB of data.

Tables VoltDB MemSQL

Nation 0.32 sec 0.17 sec

Region 0.48 sec 0.18 sec

Part 9.64 sec 0.65 sec

Supplier 0.89 sec 0.35 sec

Partsupp 32.56 sec 0.86 sec

Customer 7.14 sec 0.49 sec

Orders 68.74 sec 2.90 sec

Lineitem 339.71 sec 33.58 sec

From the table above, it can be verified that the

Lineitem table is the one that took the most time to

load the data in the two systems due to having 6 001

215 rows and the 25 rows Nation table was the least

time consuming to insert the data.

Summing up all the loading times for each of

NewSQL databases it can be verified that the value

obtained to VoltDB is 459.48 seconds and only 39.18

seconds to MemSQL, meaning that it is 11.7 times

faster.

5.3 Results and Discussion

The experimental evaluation was performed with a

TPC-H scale factor of 1, which corresponds to a 1 GB

data size. The tests were performed through five

executions of the 20 queries sequentially, so we

intend to avoid the effects of caching, and the final

value shown in the results is the average value.

In this experimental evaluation, it was not

possible to execute all the 22 queries of TPC-H.

Query Q11 could not be executed in the NewSQL

engines because it did not support the Having

condition, and query Q15 because it is not possible to

create views. Query Q19 in VoltDB did not produce

any results, after several hours of execution, we

cancel it execution; this is because VoltDB uses a

large quantity of memory (RAM) to perform the

searches.

In Figure 5, we present the average query

execution time obtained for TPC-H queries. The time

presented is expressed in milliseconds, with

logarithmic scale of base 10.

When analyzing the results of the queries it is

verified that MemSQL execution time, are smaller

compared to those of the VoltDB.

The queries, Q1, Q8, Q17, Q19, Q21 are those that

have higher execution times in VoltDB, since they

search information in a larger number of tables and

need to do more computations to present the result.

The remaining ones’, search information in a smaller

number of tables and in a row limit, which leads to

the search for a smaller number of information,

therefore, a shorter execution time.

Queries, Q1, Q5, Q9, Q18 and Q20 have a longer

execution time in MemSQL, for the same reason

mentioned for the VoltDB, they search information in

a larger number of tables and the remaining queries

in a smaller number of tables with limitation of lines

that explain a shorter execution time.

When analyzing the execution times of the queries

used, it was verified that the queries take more time

in the VoltDB engine compared to the MemSQL.

Longer searches look for information in the TPC-H

tables with the largest number of information

(Lineitem, Orders, Customer, Supplier). It is

understandable that the search time is longer when it

is necessary to look up information in the tables with

largest number of rows. We also verify that queries

with aggregations have the slowest execution time.

Based on the experimental results, it is possible to

verify that MemSQL stands out, with a 92%

improvement over VoltDB. As mentioned in section

3.1 in MemSQL, when a new search is received on

the system, it checks if there is already a hash code,

then it reuses the previously compiled code, passing

the parameters to the already compiled code,

significantly reducing the processing time. Due to this

distinct feature, the query execution time of

MemSQL queries are smaller compared to VoltDB.

In this way it was verified that the two NewSQL

engines are fast to present the results of the searches

but the MemSQL was able to surpass the VoltDB in

all the searches as we can verify in Figure 5. The

VoltDB being a system based on the memory, uses

the memory on the computer considerably, and

consequently led to longer execution times.

6 CONCLUSIONS AND FUTURE

WORK

Today information is vital for organizations that have

multiple data sources and systems to store them.

However, there is a huge problem due to the massive

quantity of data inserted in the databases, that causes

poor query performance and worse data analysis.

These problems highlighted the advantage of

NewSQL databases by providing increased

throughput, and improved performance, solving also

storage problems. With this it is possible to solve the

current storage problems, but also fix some flaws that

exist in other database systems, that is why NewSQL

databases are designed to be scalable and support

large amounts of data and remain efficient.

During the evaluation of the tests, only Q19 was

not possible to execute. Therefore, it is possible to

verify that NewSQL systems use considerably the

primary memory to perform searches. To obtain good

performance it is necessary to have a computer with

good processing and storage capacity that contributes

to the better results of NewSQL databases.

We can conclude that MemSQL NewSQL engine

behaved better than the VoltDB for 1GB of data.

Moreover, MemSQL use standard SQL, without the

necessity of queries rewriting, while in VoltDB it is

necessary to rewrite the queries. For example,

VoltDB does not support the date type, but only the

timestamp date type.

As a future work, we intend to evaluate other

NewSQL database engines and comparing the

performance with traditional relational databases,

such as MySQL or PostgreSQL. We also intend to

increase the scale factor of TPC-H using a database

size of 10GB and more.

REFERENCES

Aslett, Matthew, 2011. NoSQL, NewSQL and Beyond,

https://blogs.the451group.com/information_managemen

t/2011/04/15/nosql-NewSQL-and-beyond/

Binani, S., Gutti, A. and Upadhyay, S. (2016) ‘SQL vs.

NoSQL vs. NewSQL-A Comparative Study’, Commu-

nications on Applied Electronics, 6(1), pp. 43–46.

Chen, J. et al. (2016) ‘The MemSQL Query Optimizer : A

modern optimizer for real-time analytics in a distributed

database’, 9(13), pp. 1401–1412. doi: 10.14778/

3007263.3007277.

DBEngines (2017). [online] Available at https://db-

engines.com/en/ranking [Accessed 7 Jun. 2017].

Grolinger, K. et al. (2013) ‘Data management in cloud

environments: NoSQL and NewSQL data stores’,

Journal of Cloud Computing: Advances, Systems and

Applications, 2, p. 22.

Kumar, R. et al. (2014) ‘Apache Hadoop, NoSQL and

NewSQL Solutions of Big Data’, International Journal

of Advance Foundation and Research in Science &

Engineering, 1(6), pp. 28–36.

Lourenço, J.R. et al. (2015a) ‘Choosing the right NoSQL

database for the job: a quality attribute evaluation’,

Journal of Big Data, 2 (1), art. no. 18.

Lourenço, J. R., et al. (2015b) ‘NOSQL databases: A

software engineering perspective’, Springer Advances in

Intelligent Systems and Computing, 353(6), pp. 741–750.

Moniruzzaman, A. B. M. (2014) ‘NewSQL : Towards Next-

Generation Scalable RDBMS for Online Transaction

Processing (OLTP) for Big Data Management’,

International Journal of Database Theory &

Application, 7(6), pp. 121–130.

Pavlo, A. and Aslett, M. (2016) ‘What’s Really New with

NewSQL?’, SIGMOD Record, 45(2), pp. 45–55. doi:

10.1145/3003665.3003674.

Santos, R. J., Bernardino, J. and Vieira, M. (2011) ‘Balancing

security and performance for enhancing data privacy in

data warehouses’, Proc. 10th IEEE Int. Conf. on Trust,

Security and Privacy in Computing and

Communications, TrustCom 2011, pp. 242-249.

Stonebraker, M. (2012) ‘New opportunities for New SQL’,

Communications of the ACM, 55(11), p. 10. doi:

10.1145/2366316.2366319.

TPC-H Documentation. (2017, July) Retrevied from

http://www.tpc.org/tpch/default.asp

VoltDB Documentation. (2017, July) Retrevied from

https://www.voltdb.com.
