Cybersecurity Safeguards for the Automotive Emergency Response

Vehicles

Pasi Kämppi

, Paresh Rathod

and Timo Hämäläinen

Laurea University of Applied Sciences, Vanha maantie 9, FI-02650 Espoo, Finland

Department of Mathematical Information Technology, University of Jyväskylä, Finland

Keywords: Cyber Security, Safeguard, Cross-Border Collaboration, Information Security, Emergency Response

Vehicles, KATAKRI.

Abstract: A modern Emergency Response Vehicle (ERV) is a combination of emergency services and functional mobile

office on the wheels. Researchers have observed that emergency response personnel including Law

Enforcement Authorities (LEAs), Police and border guards, could be on the duty while having possibility to

use same services compared to fixed office. During our research study, users have registered special demand

for mobile office. To meet this demand, designers and engineers have combined a modern vehicle platform

with computers, monitors, wireless connectivity and many other devices needed in everyday activities.

However, there is continue challenge, the standards are not covering information and cyber security properly.

This research paper fulfils that gap by applying the Finnish National Security Auditing Criteria version 2

(KATAKRI II) on eight asset classes that have recognised in Mobile Object Bus Integration (MOBI) project.

The outcome is a pragmatic solution that provides large set of safeguards for guaranteeing ERV information

and cyber security.

1 INTRODUCTION

Law enforcement authorities (LEA), including police

officers and border guards, are spending significant

of their day-to-day service time on the road. This

situation is demanding and their vehicles need to offer

same facilities compared to working in the office. To

meet this requirement, a modern emergency response

vehicle (ERV) is converted as an office on the wheels,

technically known as the mobile office. It is evident

that the mobile office has to meet high requirements

for data confidentially, integrity and availability

(CIA).

Currently, commercial vehicles are converted to

ERVs. Therefore, a common approach to reach CIA

requirement is to handle a commercial vehicle as a

vehicle platform and modify such vehicle platform as

per the LEA needs (Rajamäki, 2013). The vehicle

platforms are equipped with computers, monitors and

many other additional electronic devices. Many

researchers have reported that the standardization of

ERVs is very fragmented. In addition, many

associations have released the standards of their own

(Rajamäki, 2013; NFPA, 2016; FAMA, 2016). The

current standards are focusing on mainly safety,

performance and testing. On the other hand,

information and cyber security is usually out of the

scope. The new demands of ICT systems and

evolving threat vectors requires specific security

solution to address these issues.

The main purpose of this study is to propose the

novel solution for ERV information and cyber

security safeguards by applying environment and

technology independent Finnish National Security

Auditing Criteria known as the KATAKRI (an

acronym in Finnish language). The proposal covers

safeguards for vehicle preparedness, vehicle

equipment, vehicle interior design, integrated ICT-

and communications systems and power supply

system.

The paper is structured as follow: section 2

recognizes the research gap, missing cybersecurity

guidelines for ERVs, and makes review for existing

ERV standards, automotive standards and research

activities. In section 3 we present our research

approach and methodologies. Section 4 introduces a

case study; how a van sized ERV can be seen as

protectable asset. In section 5 we propose a practical

solution that fulfils the research gap; we propose a set

cybersecurity safeguards for ERVs. The last section,

KÃd’mppi P., Rathod P. and HÃd’mÃd’lÃd’inen T.

Cybersecurity Safeguards for the Automotive Emergency Response Vehicles.

DOI: 10.5220/0006587802910298

In Proceedings of the 9th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (KMIS 2017), pages 291-298

ISBN: 978-989-758-273-8

discusses about strengths, weaknesses and scalability

of proposed solution.

2 CURRENT STATE OF THE

ART AND RESEARCH GAP

The study started with literature review to find-out

how current ERVs and automobile industry are

addressing the information and cyber security related

standardization? The current-state-of-the-art also

reveals other aspects of ERVs; how researchers are

seeing modern automobile as protectable asset?

2.1 ERV Standards

There are few forefront European and International

standards on building emergency vehicles. The series

of European Standards EN 1846-x focuses on three

areas of firefighting and rescue service vehicle: (1)

Nomenclature and designation, (2) Common

requirements - safety and performance, and (3)

Permanently installed equipment – safety and

performance (EC Cen EN 1846-2, 2009; EC Cen EN

1846-3, 2008; EC Cen EN 1846-1, 2011).

On the contrary, the US ambulance manufacturing

division (AMD) of the National Truck Equipment

Association released Ambulance Standards in year

2007. In 2014, the American Society of Automotive

Engineers also released updated and more advance set

of recommendations for ambulances and its safety

standards. These recommendation is cumulative

iteration and updates on KKK-A1822 document by

General Service Administration. Researchers have

often argued and questioned the KKK-A1822 for its

outdated recommendation not meeting modern

requirements. Our study demonstrated – European

and American ERV standards are lacking structured

recommendation for information and cyber security.

The most widely accepted and admired standards

for building emergency vehicles came from an

international non-profit organization, namely The

National Fire Protection Association (NFPA). NFPA

have released a set of standards on fire and rescue

services, products and solutions. NFPA 414: Standard

for Aircraft Rescue and Fire-Fighting Vehicles and

NFPA 1917: Standard for Automotive Ambulances is

closely related to the Emergency Response Vehicle.

NFPA 414 revolves around the design, performance

and acceptance criteria for rescue and fire-fighting

vehicles. NFPA 1917 defines the design, performance

and testing requirements for ambulances. These

standards have specified targets such as aircraft vehi-

cles and medical emergency ambulances.

There are two more NFPA standards which

address education and training requirements for

Emergency Vehicles: NFPA 1071: Standard for

Emergency Vehicle Technician Professional

Qualifications and NFPA 1451: Standard for a Fire

and Emergency Services Vehicle Operations Training

Program. NFPA has considered international and US

Federal Specifications when developing these

standards. However, NFPA does not offer any

guidelines how to cover information and cyber

security when designing or testing ERV's.

The Fire Apparatus Manufacturers’

Association (FAMA) is another non-profit trade

association which provides some guidelines for

emergency response vehicles. However, FAMA has

not released any public guidelines on how to build an

emergency response vehicle. Another similar work

found in the literature is from the Ministry of Health

and Long-term Care of Ontario, Canada. They have

released standards for the minimum acceptance

requirements for land ambulances. A diverse range of

studies have been done on various specific areas of

emergency vehicles including the dispatching system

(Han-tao et al., 2009) the intelligent navigation

system (Salehinejad et al., 2011) the vehicle location

finder (Alsalloum and Rand, 2006), the safety and

security of onboard personnel and customers (Perry

and Lindell, 2003), communication systems (Chen,

2010) and others.

2.2 Automotive Standards

Research study also suggests that automotive

standards are not widely covering information and

cyber security. Society of Automotive Engineers

(SAE) has released a few standards for covering

electric vehicles and diagnostics interface; SAE

J2186_200506: E/E Data Link Security,

J1939/73_20130: Application Layer – Diagnostics

and SAE J2931/1_201412: Digital Communications

for Plug-in Electric Vehicles. In nutshell, current

situation is not able to define automotive information

and cyber security systematically. Again, the

practices are very fragmented and seeks more

targeted solution.

Recently, Society of Automotive Engineers

(SAE) has put their effort and work towards

information and cyber security. They released their

guidelines, SAE J3061: Cybersecurity Guidebook for

Cyber-Physical Automotive Systems, in 2016. Their

approach is to find out if the existing concepts and

methods could be applied in automotive industry. The

demand to cover holistic automotive cyber security

created an opportunity for the Alliance of Automobile

Manufacturers and the Association of Global

Automakers to found Automotive Information and

Sharing Center (Auto-ISAC). Auto-ISAC combines

work forces of auto manufacturers, standardization,

other industry and academia to find out the best

possible solution regarding automotive cyber security

(Auto alliance, 2015).

2.3 Research and Innovation Activities

Academic researchers have also put significant effort

for automotive cyber security. Their focus is to handle

the combination of the vehicles and ICT as cyber

physical systems (Fallah and Sengupta, 2012;

McMillen and Sinha, 2010). Their research target is

to find out possible physical threats caused via ICT

instead of applying existing information and cyber

security frameworks in automotive ecosystem.

Petit et al., (2015) are presenting analysis for

potential risks for automated vehicles without any

standardised safeguards against potential threats.

They are using Failure Modes and Effects Analysis

(FMEA) to find out the most remarkable risks

regarding automated vehicles. Their research work

reveals many unseen trends. According to their

research the Global Navigation Satellite System

(GNSS) will be the most vulnerable part of the

automated vehicle ecosystem, the observation

previously omitted by researchers. Famous hacking

conferences, like Def Con and Black Hat, are also

interested to share the latest findings regarding

automobiles and especially trendy cars. In 2013,

Hackers revealed the first vulnerabilities in Def Con

21 when they could control the car remotely

(Rosenblath, 2013). After Def Con 21 car hacking has

been permanently in the conference schedule.

3 RESEARCH APPROACH AND

METHODOLOGIES

This study focuses on developing a pragmatic

information and cyber security solutions for ERVs.

The research approach and methodologies are also

reflecting the solution oriented target. This research

study is aiming to develop a systematic information

and cyber security framework for ERVs using

inductive reasoning scientific method considering

specific analytic reasoning process. The method is

strongly based on providing solutions. The analytic

reasoning method draws the premises from unknown

to known with iterative process that develops

confidence in achieved solutions and hence ensures

the trust. In this method, the goal of analyst is to reach

a judgement about an issue or problem. The outcome

of analyses presents the tangible results in the form of

a product (Cook and Thomas, 2005).

The process starts with planning of proving

solutions to given issues. The planning phase includes

resource usage and timeline plan. The second step in

the process includes gathering and familiarizing with

available information on top of the already gathered

information. Next, the analyst hypotheses and

outlines multiple candidates with explanations.

Indeed, analyst aiming to reach a judgement by

evaluating alternative explanations. The whole

process allows to expand and broaden understanding

of analyst’s previous thinking. The final step allows

analyst to summarize the judgement with creation of

reports, documents and products. The inductive

reasoning method starts with the specific

observations and measures that allows to detect

patterns and regularities, and resulting into formulate

some tentative hypotheses to explore. Finally, the

explorations of hypothesis end with broader

generalizations, developing conclusions or drawing

model. In general, this research method is an

ongoing-iterative and highly collaborative process

where people, process and technology synchronously

scale to support cyber security reasoning, assessment

and actions to implement safeguards in ERVs.

4 A CASE STUDY – VAN SIZED

ERV

Typically, ERVs are built on the top of the

commercial vehicle platforms (Rajamäki, 2013). The

type or model of the platform is selected according to

purpose and need. There are several options available

on the market including sedan, wagon, van or truck.

In this study, we have taken a case of a van sized

ERVs.

The interior space of the van sized vehicle can be

modified and tailored according to customer need. In

our previous studies, we have piloted new approach

with Finnish Police (Rajamäki, 2013; Rajamäki and

Rathod, 2013). The Finnish Police has divided

interior space in three compartments; (1) Vehicle

Control (or) Driver’s Space (or) Cabin (2) Mobile

Office Space, and (3) Transport Space.

The driver space is reserved for the driver and his

pair. It contains all vehicle control related features

like steering, gear control and break control.

Additionally, there could be installed equipment that

is used in everyday activities; onboard computer,

touch screen display, keyboard, mouse, voice

communications equipment and extra batteries for

mission critical systems. The second compartment,

mobile office space, acts like an office and it is

designed to offer facilities for bigger operations when

the vehicle is parked and stabilized. It contains seats,

table, storage for equipment, printer and touch screen

display. The third compartment, transport space, is

reserved for prison or equipment transportation. It has

bench and locker. Following Figure-1 presents ERV’s

integrated system components:

Figure 1: ERV compartments and equipment integration.

For example, Figure 1 demonstrates (A) dedicated

start-up battery, (B) dedicated battery for equipment,

charging, (D) standby main unit for manual

equipment control & intelligent power management,

(E) on-board computer, (F) standby control panel/

display and (G) touch screen display, (H) keyboard,

(I) mouse, (J) voice communication equipment and

(K) data connection equipment.

4.1 Protectable Assets

The ERV design process is highly demanding. The

rigorous process should be able to cover required

aspects, including information and cyber security.

Our previous study focused on user-centric research

and it produced user requirements specification based

on the real needs of the Finnish police officers

(Rathod and Kämppi, 2013). The outcomes of the

research study have recognized eight main categories

within ERV assets to be protected, as presented in

Figure 2, including Emergency Response

Preparedness, Vehicle Features, Vehicle Equipment,

Interior Space and Cabin Design, ICT Systems, Data

Communications, Voice Communications and Power

Supply Systems. The scope of previous study did not

cover information and cyber security including

recognized processes, features, systems and devices.

The risk and threat vectors have been significantly

increased since our previous studies. In this study, we

will use recognized processes, features, systems and

devices as assets and functional requirements (FR)

with information and cyber security safeguards.

Figure 2: ERV protectable assets categories.

5 SOLUTION - CYBERSECURITY

SAFEGUARDS

In the second phase of the study, we have identified

appropriate standard for applying cyber security

safeguards using Finnish National Security Auditing

Criteria (KATAKRI) for ERVs (Finnish Ministry of

Defense, 2011). The KATAKRI provides significant

standardized way to implement cyber security

auditing criteria and apply relevant safeguards. The

secure ERVs demands protections of different asset

classes and components. Following subsection

explains our proposed solution and outcome of pilot

case.

5.1 Emergency Response Preparedness

The emergency response preparedness functional

requirement is focusing on making sure the ERV is

ready on a standby for operation at any time. ERV

preparedness can be ensured by three different type

of checks and quick functional auditing; routine

check, before mission check and after mission check

(Rathod and Kämppi, 2013). The routine check is

based on car manufacturers’ recommendation and it

is made on mileage or time basis. The routine check

is comparable for any vehicle maintenance program.

The before mission check is made by vehicle

embedded diagnosis system and ERV personnel.

When the ERV is powered on, vehicle embedded

diagnosis system starts and indicates immediately if

something is wrong. Next, the ERV personnel will go

through a checklist according to their mission. After

mission, the ERV personnel will check the vehicle

again and they will report observed faults (if any) to

maintenance personnel.

The regular maintenance program should contain

procedures for maintaining required information and

cyber security level. At first place, there should be

clear policy how the system is documented and how

the documentation is updated, who has rights to install

new hardware and software and what criteria must be

followed in system acceptance process. All devices,

software and licenses should be registered to avoid

situations where expired license or software could

cause security vulnerabilities.

To guarantee system confidentially, integrity and

availability, all new hardware and software need to be

verified in testbed before integration into real ERV. It

is also important that ERV configuration changes can

be made only by authorized personnel. Test accounts

and test data should be removed when they are not

needed anymore. As there is need for frequent

maintenance cycle for engine or brakes, same

principle should be applied also with ERV ICT-

systems. Software and security updates need to be

installed in regular basis, systems need to be scanned

frequently to find out possible vulnerabilities and

vehicle body need to be checked for tracking or

espionage devices. After maintenance work systems

should be locked and vehicle is checked according

clear desk policy.

5.2 Vehicle Features

The features of emergency response and patrol

vehicles are extremely critical to provide effective

and timely incident response. Some of the emergency

vehicle features accelerate the performance and

increase the safety of personnel (Wang and Shih,

2013). The list of required features comprises a broad

range of aspects that are embedded with the vehicle

platform including car size, sustainable functioning,

ground clearance and performance of car, vehicle

type, interior and exterior of vehicles and others. But

the nature of the car is changed dramatically during

last decades. A modern car is like data center on the

wheels and it can contain 50-70 Electronic Control

Units (ECU) that are responsible for e.g. cruise

control, navigation and safety systems (Larson and

Nilsson, 2008). Cars are also connected to background

systems and it increases possibilities for having

vulnerabilities via wireless networks.

KATAKRI does not provide directly any

safeguards for vehicle specific features. Anyhow, the

latest research results can be used to complete

KATAKRI. Larson et al states that connected vehicle

enables remote software updates for ECUs, same time

also the number security risks increases (Larson and

Nilsson, 2008). Wang et al (2014) found that the

vehicle internal communication network, Controller

Area Network (CAN), does not provide message

authentication mechanism. This vulnerability makes

possible to control ECUs via On Board Diagnostics

(OBD) interface. In practice, the attacker could control

ECUs via USB or Bluetooth enabled OBD-adapter.

Checkoway et al., (2011) raises even more potential

vulnerabilities. They state that embedded CD-drive,

internal Wi-Fi, embedded Bluetooth, smart phone

integration possibilities, remote keyless entry and Tire

Pressure Management System (TPMS) could open

doors for attackers.

There is no comprehensive list for vehicle features

related safeguards available, we can make some

recommendations. We recommend protecting OBD

service interface in a way there is no possibility to

install devices for unauthorized access. We also

recommend disabling Bluetooth, avoid using smart

phone integration and following latest research results

to get up to date information about car related

information and cyber security vulnerabilities.

5.3 Vehicle Equipment

Police officers, firefighters, public safety officers and

other personnel of emergency response carry various

types of equipment in their vehicles (Rathod and

Kämppi, 2013). Some of them are use specific like

speed radars, explosion meters, carbon meters and

thermal cameras. There are also many commercial

devices used in the ERV. We can name navigators,

cellular phones, voice recorders, printers and USB-

sticks. As a summary, the list of the used equipment

can be long and heterogeneous.

Before installing any new equipment in the ERV

it should be ensured that installation process follows

company policies, new device meets specified

technical requirements and security controls are

protective enough without having negative effect for

usability. New devices should have possibility for

mass memory protection and the mass memory

should be removed or erased if the device is sent for

maintenance. Printers require memory encryption

features. All unused Bluetooth- and WLAN-

connections are disabled if they are not used and

secured. As a basic principle, there must be verified

that new devices do not create any new information

and cyber security risks. When the new device is

installed, the device hardware and software

information need to be updated to vehicle specific

needed software updates in conjunction with vehicle

maintenance program.

5.4 Interior Space and Cabin Design

The design principles for interior space and cabin has

important role in everyday activities. Design

principles focus on the interior design and build of the

vehicle, considering the optimum use of available

space, ergonomics, safety, material consumption and

easy maintenance.

TIn information and cyber security point of view,

we could concentrate on data confidentially and

availability. Interior space should offer lockable

storage space for confidential material. For data

availability, there should be available suitable space

for ICT-systems and cable routings.

5.5 ICT Systems

The MOBI project introduced an approach where

ERV is equipped with rugged on-board computer

with Windows OS, touch screen displays, keyboard,

mouse and printer. This approach is very flexible and

it enables users to access their software applications

including office, email, diary, and reporting.

Additionally, there could be included portable

devices like laptops and tablets. Figure 4 describes

typical ICT-system setup in the ERV.

KATAKRI offers very comprehensive set of

safeguards that can be implemented in on-board

computer. The most important safeguard is properly

configured host based firewall and malware

protection application. KATAKRI defines that only

predefined traffic is allowed and denied traffic is

logged. There should be also a clear policy for

firewall configuration, documentation and frequent

rule base review. Operating system needs to be

hardened; only needed services are activated,

applications have minimal number of user rights,

mass memory is encrypted, default passwords are

changed and all unnecessary physical interfaces are

disabled. And finally, all detected security breaches

need to be logged.

5.6 Data Communications

A mobile office requires data communication channel

that can guarantee data transmission confidentially,

integrity and availability. The most economical way

is to use commercial mobile networks due the fact

that dedicated authority networks are optimized for

voice communications (Boris and Wood, 2013).

Anyhow, commercial networks are not optimized for

availability in critical communications point of view.

The availability requirements can be fulfilled by

special devices, multi-channel routers, which are able

to combine several data bearers as a single transparent

data bearer. The multi-channel router offers local data

connectivity for end users via both wired and wireless

Wi-Fi connections.

The most important safeguards for external data

communications is support for strong data encryption

and possibility to use redundant connections. Secret

keys for encryption are used only by authorized users.

The session management should meet requirements;

re-activation of closed session is prevented; inactive

sessions are terminated and the length of the session

has certain time limit. And finally, routing messages

are verified and filtered. If the data connection is

shared locally for the end users by Wi-Fi, the

connection should be protected according best

practices. The Service Set Identifier (SSID) needs to

be hidden, users are authenticated and the connection

is encrypted by IEEE 802.11i (WPA2) and the system

uses private IP-addresses for the local

communication.

5.7 Voice Communications

Voice communication systems include dispatching

systems, telephone systems, public reporting systems,

and radio systems (Welch et al., 2013). Voice

communication systems provide the following

functions: communication between the public and

emergency response agencies, communication within

the emergency response agency under given

conditions and communication among emergency

response agencies (Boris and Wood, 2013).

The most used technologies for voice

communications are Terrestrial Trunked Radio

(TETRA), TETRAPOL and Project 25 (P25). The

technologies are designed to meet high security and

availability requirements for critical voice

communications. Anyhow, we can present a few

safeguards for handheld terminals. The terminals

should be protected by password if feasible and all

additional connection types like Bluetooth and Wi-Fi

should be disabled if they are not needed. Mass

memory is encrypted and the system should support

terminal remote management (locking and erasing).

5.8 Power Supply System

The power supply system acts very important role in

any modern vehicle. In case of ERV the situation is

more critical. ERVs are loaded with additional

equipment that requires extra power to guarantee

maximum availability.

The situation could be solved by installing two

separate batteries in ERV; one battery for vehicle

infrastructure and one battery for additional

equipment. The battery system should be designed

properly and it should have enough capacity for

standby missions, possibility for external charging

and it should have real time indication for low

charging level (Kämppi and Rathod, 2013).

Researchers have worked on finding a holistic

solution and finally using NFPA 110 where power

systems include “power sources, transfer equipment,

controls, supervisory equipment, and all related

electrical and mechanical auxiliary and accessory

equipment needed to supply electrical power to the

load terminals of the transfer equipment” (NFPA,

2016). Researchers also suggested using alternative

power systems during failures of the main power

systems, for example Emergency Power Supply

System (EPSS). In electric vehicles, the integrated

on-board batteries could solve power supply related

problems.

6 CONCLUSIONS

This paper presented and discussed, the modern

emergency vehicle is a very complicated combination

of different technologies and assembly. The relevant

standardization is focused to cover safety,

performance and testing issues. Information and

cyber security is still uncovered although ERVs has

been equipped with additional equipment during

many years.

In this study, we made a feasibility study how

KATAKRI audit criteria could be applied with van

sized ERVs that are equipped with additional devices

and ICT-technologies. We found that KATAKRI

does provides large set of safeguards if we are

protecting legacy systems or on-the-self products;

commercial hardware and standard operating

systems. We also discovered that maintenance of the

additional technology, including hardware and

software, should be integrated as a part of vehicle

maintenance program. Continuous maintenance is the

key issue for maintaining reached level of

information and cyber security.

It is obvious that the traditional information and

cyber security standards and frameworks, like

KATAKRI, are not able to cover unidentified or

unknown information and cyber security risks of

modern vehicle platforms. Traditional information

and cyber security standards and frameworks can be

used as guidelines but there is needed a lot of research

work to recognize vehicle platform related

information and cyber security risks.

Anyhow, the proposed model is vehicle platform

and technology independent solution. It can be

applied for any type of vehicle including van, sedan,

truck, hybrid or electric vehicles as long as the vehicle

platform is integrated with additional legacy

hardware and software. Secondly, the proposed

model is extendable and it can be complemented with

more comprehensive risk analysis procedure if there

is any deeper integration with vehicle platform

computing systems. The future research work should

concentrate for covering ERV as one protectable asset

including vehicle platform and additional equipment

and software as a whole.

ACKNOWLEDGEMENTS

The research study could not have been smooth and

applied without support of Finnish Emergency

Response Organisations including Finnish Police,

Airbus-Finland, Research Lead Rajamäki, J., and

working life organisations. We also appreciate Laurea

University of Applied Sciences and their students to

be part of Learning by Developing RDI work. We are

acknowledging and thanking your contribution.

REFERENCES

Alsalloum, O.I. & Rand, G.K. 2006, "Extensions to

emergency vehicle location models ", Computers &

Operations Research, vol. 33, no. 9, pp. 2725-2743.

Automakers Announce Initiative to Further Enhance

Cyber-security in Autos | Alliance of Automobile

Manufacturers 2015, July 14-last update. Retrieved

November 20, 2015, from http://www.autoalliance.org/

Beene, R. 2015, August 14-last update, Automakers form

alliance to bolster cybersecurity Retrieved November

20, 2015, from http://www.autonews.com/

article/20150824/OEM06/308249985/automakers-

form-alliance-to-bolster-cybersecurity

Borislow, D.M. & Wood, G.L. 2013, Computer-related

devices and techniques for facilitating an emergency

call via a cellular or data network using remote

communication device identifying information, Google

Patents.

Chen, C. & Chang, C. 2010, "A Secure Fire Truck

Communication Protocol for VANET", Proceedings of

the 10th WSEAS International Conference on Signal

Processing, Computational Geometry and Artificial

Vision (World Scientific and Engineering Academy and

Society – WSEAS 2010).

Chin-Ling Chen, C.C. 2010, "A secure fire truck

communication protocol for VANET ", pp. 58-63.

Cook, K.A. & Thomas, J.J. 2005, "Illuminating the path:

The research and development agenda for visual

analytics".

ETSI - TETRA 2015-last update. Retrieved November 20,

2015, from http://www.etsi.org/technologiesclusters/

technologies/

Hao-you Wang & Huang-Chia Shih 2013, "A robust

vehicle model construction and identification system

using local feature alignment", Consumer Electronics

(ISCE), 2013 IEEE 17th International Symposium on,

pp. 57.

Home | Fire Apparatus Manufacturers' Assocation.

Retrieved November 17, 2015, from

http://www.fama.org/

Home | National Fire Protection Association. Retrieved

November 16, 2015, from http://www.nfpa.org/

J2186: E/E Data Link Security - SAE International.

Retrieved November 16, 2015, from

http://standards.sae.org/j2186_200506/

Kamppi, P. & Rathod, P. 2013, "Smart battery system for

emergency vehicles: Results from a pilot field study",

Connected Vehicles and Expo (ICCVE), 2013

International Conference on, pp. 182.

Larson, U.E. & Nilsson, D.K. 2008, "Securing Vehicles

Against Cyber Attacks", Proceedings of the 4th Annual

Workshop on Cyber Security and Information

Intelligence Research: Developing Strategies to Meet

the Cyber Security and Information Intelligence

Challenges AheadACM, New York, NY, USA, pp.

30:1.

Ministry of Defence Finland 2011, KATAKRI, National

Security Auditing Criteria. Version II.

Mission | Fire Apparatus Manufacturers' Association.

Retrieved November 18, 2015, from

http://www.fama.org/about-fama/mission/

Moore, R., Lopes, J., 1999. Paper templates. In

TEMPLATE’06, 1st International Conference on

Template Production. SCITEPRESS.

National Truck Equipment Association August 2007,

Ambulance Manufacture Division Standards 001-025.

NFPA 110: Standard for Emergency and Standby Power

Systems, NFPA 110 2013.

Onishi, H. 2014, "Approaches for vehicle cyber security",

Communications and Network Security (CNS), 2014

IEEE Conference on, pp. 506.

P. Rathod and P. Kämppi, 2013 (unpublished), User

requirements specification: MOBI work package 2.

Perry, R.W. & Lindell, M.K. 2003, "Preparedness for

Emergency Response: Guidelines for the Emergency

Planning Process ", Disasters, vol. 27, no. 4, pp. 336-

350.

Petit, J. & Shladover, S.E. 2015, "Potential Cyberattacks on

Automated Vehicles", Intelligent Transportation

Systems, IEEE Transactions on, vol. 16, no. 2, pp. 546-

556.

Petnga, L. & Austin, M. 2013, "Cyber-physical architecture

for modeling and enhanced operations of connected-

vehicle systems", Connected Vehicles and Expo

(ICCVE), 2013 International Conference on, pp. 350.

Qiyan Wang & Sawhney, S. 2014, "VeCure: A practical

security framework to protect the CAN bus of

vehicles", Internet of Things (IOT), 2014 International

Conference on the, pp. 13.

Rajamaki, J. 2013, "The MOBI Project: Designing the

Future Emergency Service Vehicle", Vehicular

Technology Magazine, IEEE, vol. 8, no. 2, pp. 92-99.

Rajamaki, J., Rathod, P. & Kamppi, P. 2013, "A New

Redundant Tracking System for Emergency Response",

Intelligence and Security Informatics Conference

(EISIC), 2013 European, pp. 218.

Rosenblath, S. 2013, 2013, August 2-last update, Car

hacking code released at Defcon - CNET. Retrieved

November 21, 2015, from http://www.cnet.com/news/

car-hacking-code-released- at-defcon/

SAE committee busy developing standards to confront the

cybersecurity threat - SAE International 2015, Jan 05-

last update. Retrieved (n.d.), from

http://articles.sae.org

Sengupta, R. 2012, "A Cyber-physical Systems Approach

to the Design of Vehicle Safety Networks", Distributed

Computing Systems Workshops (ICDCSW), 2012 32nd

International Conference on, pp. 324.

Smith, J., 1998. The book, The publishing company.

London, 2

edition.

Society of Automotive Engineers 2014, Digital

Communications for Plug-in Electric Vehicles,

J2931/1_201412.

Society of Automotive Engineers 2015, Application Layer

-Diagnostics,J1939/73_201508, http://standards.sae.

org/j1939/73_201508/ edn.

Society of Automotive Engineers 2015, Cybersecurity

Guidebook for Cyber-Physical Vehicle Systems,

J3061.

Stephen Checkoway, Damon McCoy, Brian Kantor, Danny

Anderson, Hovav Shacham, Stefan Savage, Karl

Koscher, Alexei Czeskis, Franziska Roesner,

Tadayoshi Kohno, 2011, "Comprehensive

Experimental Analyses of Automotive Attack

Surfaces", USENIX Security.

Welch, S.J., Cheung, D.S., Apker, J. & Patterson, E.S.,

2013, "Strategies for Improving Communication in the

Emergency Department: Mediums and Messages in a

Noisy Environment", The Joint Commission Journal on

Quality and Patient Safety, vol. 39, no. 6, pp. 279-286.
